I4S-PLL16DWireless Receiver

www.peavey.com Operating Manual Wireless Receiver PLL-16D(RECEIVER) 1 Intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. Intended to alert the user of the presence of important operating and maintenance (servicing) instructions in the literature accompanying the product. CAUTION: Risk of electrical shock — DO NOT OPEN! CAUTION: To reduce the risk of electric shock, do not remove cover. No user serviceable parts inside. Refer servicing to qualified service personnel. WARNING: To prevent electrical shock or fire hazard, this apparatus should not be exposed to rain or moisture‚ and objects filled with liquids‚ such as vases‚ should not be placed on this apparatus. Before using this apparatus‚ read the operating guide for further warnings. Este símbolo tiene el propósito, de alertar al usuario de la presencia de “(voltaje) peligroso” sin aislamiento dentro de la caja del producto y que puede tener una magnitud suficiente como para constituir riesgo de descarga eléctrica. Este símbolo tiene el propósito de alertar al usario de la presencia de instruccones importantes sobre la operación y mantenimiento en la información que viene con el producto. PRECAUCION: Riesgo de descarga eléctrica ¡NO ABRIR! PRECAUCION: Para disminuír el riesgo de descarga eléctrica, no abra la cubierta. No hay piezas útiles dentro. Deje todo mantenimiento en manos del personal técnico cualificado. ADVERTENCIA: Para prevenir choque electrico o riesgo de incendios, este aparato no se debe exponer a la lluvia o a la humedad. Los objetos llenos de liquidos, como los floreros, no se deben colocar encima de este aparato. Antes de usar este aparato, lea la guia de funcionamiento para otras advertencias. Ce symbole est utilisé dans ce manuel pour indiquer à l’utilisateur la présence d’une tension dangereuse pouvant être d’amplitude suffisante pour constituer un risque de choc électrique. Ce symbole est utilisé dans ce manuel pour indiquer à l’utilisateur qu’il ou qu’elle trouvera d’importantes instructions concernant l’utilisation et l’entretien de l’appareil dans le paragraphe signalé. ATTENTION: Risques de choc électrique — NE PAS OUVRIR! ATTENTION: Afin de réduire le risque de choc électrique, ne pas enlever le couvercle. Il ne se trouve à l’intérieur aucune pièce pouvant être reparée par l’utilisateur. Confiez I’entretien et la réparation de l’appareil à un réparateur Peavey agréé. AVIS: Dans le but de reduire les risques d’incendie ou de decharge electrique, cet appareil ne doit pas etre expose a la pluie ou a l’humidite et aucun objet rempli de liquide, tel qu’un vase, ne doit etre pose sur celui-ci. Avant d’utiliser de cet appareil, lisez attentivement le guide fonctionnant pour avertissements supplémentaires. Dieses Symbol soll den Anwender vor unisolierten gefährlichen Spannungen innerhalb des Gehäuses warnen, die von Ausreichender Stärke sind, um einen elektrischen Schlag verursachen zu können. Dieses Symbol soll den Benutzer auf wichtige Instruktionen in der Bedienungsanleitung aufmerksam machen, die Handhabung und Wartung des Produkts betreffen. VORSICHT: Risiko — Elektrischer Schlag! Nicht öffnen! VORSICHT: Um das Risiko eines elektrischen Schlages zu vermeiden, nicht die Abdeckung enfernen. Es befinden sich keine Teile darin, die vom Anwender repariert werden könnten. Reparaturen nur von qualifiziertem Fachpersonal durchführen lassen. WARNUNG: Um elektrischen Schlag oder Brandgefahr zu verhindern, sollte dieser Apparat nicht Regen oder Feuchtigkeit ausgesetzt werden und Gegenstände mit Flüssigkeiten gefuellt, wie Vasen, nicht auf diesen Apparat gesetzt werden. Bevor dieser Apparat verwendet wird, lesen Sie bitte den Funktionsführer für weitere Warnungen. Intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. Intended to alert the user of the presence of important operating and maintenance (servicing) instructions in the literature accompanying the product. CAUTION: Risk of electrical shock — DO NOT OPEN! CAUTION: To reduce the risk of electric shock, do not remove cover. No user serviceable parts inside. Refer servicing to qualified service personnel. WARNING: To prevent electrical shock or fire hazard, this apparatus should not be exposed to rain or moisture‚ and objects filled with liquids‚ such as vases‚ should not be placed on this apparatus. Before using this apparatus‚ read the operating guide for further warnings. Este símbolo tiene el propósito, de alertar al usuario de la presencia de “(voltaje) peligroso” sin aislamiento dentro de la caja del producto y que puede tener una magnitud suficiente como para constituir riesgo de descarga eléctrica. Este símbolo tiene el propósito de alertar al usario de la presencia de instruccones importantes sobre la operación y mantenimiento en la información que viene con el producto. PRECAUCION: Riesgo de descarga eléctrica ¡NO ABRIR! PRECAUCION: Para disminuír el riesgo de descarga eléctrica, no abra la cubierta. No hay piezas útiles dentro. Deje todo mantenimiento en manos del personal técnico cualificado. ADVERTENCIA: Para prevenir choque electrico o riesgo de incendios, este aparato no se debe exponer a la lluvia o a la humedad. Los objetos llenos de liquidos, como los floreros, no se deben colocar encima de este aparato. Antes de usar este aparato, lea la guia de funcionamiento para otras advertencias. Ce symbole est utilisé dans ce manuel pour indiquer à l’utilisateur la présence d’une tension dangereuse pouvant être d’amplitude suffisante pour constituer un risque de choc électrique. Ce symbole est utilisé dans ce manuel pour indiquer à l’utilisateur qu’il ou qu’elle trouvera d’importantes instructions concernant l’utilisation et l’entretien de l’appareil dans le paragraphe signalé. A…

Text truncated - open the document above for the full version.

Peavey Electronics Corporation Address：5022 Hartley Peavey Drive, Meridian, Mississippi, United States 39305 Ersteller: D. Brandhorst Revision: 00 Erstelldatum: 02.01.2012 Datum: 00.00.0000 Seite 1 von 1 Long/Short-term Confidentiality Request PHOENIX TESTLAB GmbH Date: 13 December 2015 Product Certification Königswinkel 10 D 32825 Blomberg FCC ID: I4S-PLL16D To Whom it may concerns, Pursuant to sections 0.457(d) and 0.459 of CFR 47 and to avoid premature release of sensitive information prior to marketing or release of the product to the public, we hereby requests long-term confidential treatment of information accompanying this application as outlined below: Schematics Parts List Block Diagram Tune-Up Info Operational Description In addition we hereby request the following exhibits contained in this application to be temporarily (short-term confidentilality) withheld from the public disclosure for an initial period of days until: not applicable External Photos Test Setup Photos Internal Photos Users Manual The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to rule 0.457(d), disclosure of this application and all accompanying documentation will not be made before the date of the GRANT for this application. Thank you for your attention in this matter. Applicant’s Company: Peavey Electronics Corporation address : 5022 Hartley Peavey Drive, Meridian, Mississippi, United States 39305 Signature : _______ _____________________ Job Title and Dept. : Product Compliance Manager

APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Photo 1 Photo 2 Receiver ANT Photo 3 Photo 4 Photo 5 Photo 6 Photo 7

FCC ID LABELING AND LOCATION FCC ID Label Wireless Receiver Model NO.: PLL-16D(RECEIVER) FCC ID:I4S-PLL16D This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC ID Label Location The label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time purchase (Labeling requirements per 2.925)

APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Photo 1 Photo 2 Photo 3 Photo 4 Photo 5 Photo 6 Photo 7 Photo 8 Photo 9

FCC TEST REPORT FCC ID:I4S-PLL16D Product： Wireless Receiver Trade Name： N/A Model Number： PLL-16D(RECEIVER) Serial Model： 16 CHANNEL UHF DIVERSITY DUAL RECEIVER WIRELESS Report No.： ISOT15070065E Prepared for Peavey Electronics Corporation 5022 Hartley Peavey Drive, Meridian, Mississippi, United States 39305 Prepared by Shenzhen ISOTek Standards Technical Services Co.,Ltd. 13/F, HuaFengRui Building, XinHu Rd., XiXiang, Bao’an District,Shenzhen,China Tel.: +86-755- 23087278 Fax.: +86-755-23087178 Http://www.ISOTek.com.cn Applican Address Manufa c Address Produc t Product Model a n Standar This dev equipme only to th This repo documen of the do Date of T Date (s) Date of I Te s t R e s C L nt’s name . ................. cturer's Na ................. t descriptio name ......... nd/or type r rds ............. vice describ ent under te he tested sa ort shall not nt may be a ocument. Test ........... of perform a ssue .......... sult .............. Compiled by Lisa Huang/ TE ................ ................ ame .......... ................ on ................... reference ................ ed above h st (EUT) is ample ident t be reprodu altered or re .................. ance of tests .................. .................. y: Project Eng EST RES : Peavey E : 5022 Ha r 39305 : Shenzhe : Bldg.91- 9 Bao'an D : Wireless : PLL-16D : FCC Par t ANSI C63 as been tes in complian tified in the uced excep evised by IS ............... : s ............. : ............... : ............... : ineer Page 2 of ULT CER Electronics C rtley Peave n Uniwisdo 94 3rd Indu District，She Receiver (RECEIVE R t15B:01 Oc 3.4:2014 sted by ISO nce with Pa repo rt. pt in full, with SOTek, pers 26 July. 2 0 10 Aug. 2 Pass f 22 RTIFICAT Corporation ey Drive, Me m Technolo ustrial Zone enzhen，P. R) t.2014 OTek, and th rt 15 of FCC hout the wri sonnel only, 015 ~10 Au 015 Approve Richard Report N TION n eridian, Mis ogies Co., L e，Lisongla R.China he test resu C/IC Rules. itten approv and shall b ug. 2015 ed by: Chen / Mana No.: ISOT150 ssissippi, U Ltd. ang，Gongm lts show tha . And it is ap val of ISOTe be noted in ager 070065E nited States mingTown， at the pplicable ek, this the revisio n s n Page 3 of 22 Report No.: ISOT15070065E Table of Contents Page 1 . TEST SUMMARY 4 1.1 TEST FACILITY 5 1.2 MEASUREMENT UNCERTAINTY 5 2 . GENERAL INFORMATION 6 2.1 GENERAL DESCRIPTION OF EUT 6 2.2 DESCRIPTION OF TEST SETUP 8 2.3 DESCRIPTION TEST PERIPHERAL AND EUT PERIPHERAL 9 2.4 MEASUREMENT INSTRUMENTS LIST 10 3 . EMC EMISSION TEST 11 3.1 CONDUCTED EMISSION MEASUREMENT 11 3.1.1 POWER LINE CONDUCTED EMISSION 11 3.1.2 TEST PROCEDURE 12 3.1.3 TEST SETUP 12 3.1.4 EUT OPERATING CONDITIONS 12 3.1.5 TEST RESULTS 13 3.2 RADIATED EMISSION MEASUREMENT 15 3.2.1 LIMITS OF RADIATED EMISSION MEASUREMENT 15 3.2.2 TEST PROCEDURE 15 3.2.3 TEST SETUP 17 3.2.4 TEST RESULTS 18 3.2.5 TEST RESULTS(1000~12400MHz) 20 4 . EUT TEST PHOTO 21 Page 4 of 22 Report No.: ISOT15070065E 1. TEST SUMMARY Test procedures according to the technical standards: EMC Emission Standard Test Item Limit Judgment Remark FCC Part15B:2014; ANSI C63.4: 2014 Conducted Emission Class B PASS Radiated Emission Class B PASS NOTE: (1) ’N/A’ denotes test is not applicable in this Test Report (2) For client’s request and manual description, the test will not be executed. Page 5 of 22 Report No.: ISOT15070065E 1.1 TEST FACILITY Shenzhen ISOTek Standards Technical Services Co.,Ltd. Add.: 13/F, HuaFengRui Building, XinHu Rd., XiXiang, Bao’an District,Shenzhen,China FCC Registration No.: 918037; IC Registration Number:20400-1 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U，where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2，providing a level of confidence of approximately 95 %. A. Conducted Measurement : Test Site Method Measurement Frequency Range U，(dB) NOTE ISOTekC01 ANSI150 KHz ~ 30MHz 3.2 B. Radiated Measurement : Test Site Method Measurement Frequency Range U，(dB) NOTE ISOTekA01 ANSI30MHz ~ 1000MHz 4.7 1GHz ~12.4GHz 5.0 Page 6 of 22 Report No.: ISOT15070065E 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF EUT Equipment Wireless Receiver Model Name PLL-16D(RECEIVER) Additional Model Number(s) 16 CHANNEL UHF DIVERSITY DUAL RECEIVER WIRELESS Model Difference Only the model name is different. Product Description The EUT is a Wireless Receive r. Connecting I/O port: DC Input, Balanced out, Unbalanced out, ANT A,ANT B Operation Frequency: 566.025~589.825 MHz (Only Receiver) Modulation Type: FM highest operating frequency 589.825 MHz Power Source AC120 V Adapter Input: 120V~, 50/60Hz Output: 13.5V, 0.4A Battery N/A Page 7 of 22 Report No.: ISOT15070065E 2.1.1 DESCRIPTION OF TEST MODES To investigate the maximum EMI emission characteristics generates from EUT, the test system was pre-scanning tested base on the consideration of following EUT operation mode or test configuration mode which possible have effect on EMI emission level. Each of these EUT operation mode(s) or test configuration mode(s) mentioned above was evaluated respectively. Pretest Mode Description Mode 1 Receive For Conducted Test Final Test Mode Description Mode 1 Receive For Radiated Test Final Test Mode Description Mode 1 Receive Page 8 of 22 Report No.: ISOT15070065E 2.2 DESCRIPTION OF TEST SETUP RE CE 0.8m Table 1.5m C-1 AC Line E-3 Load E-1 Adapter LISN E-3 EUT C-2 0.8m Table C-1 1.5m C-2 E-2 EUT E-3 Load E-1 Adapter Page 9 of 22 Report No.: ISOT15070065E 2.3 DESCRIPTION TEST PERIPHERAL AND EUT PERIPHERAL The EUT has been tested as an independent unit together with other necessary accessories or support units. The following support units or accessories were used to form a representative test configuration during the tests. Item Equipment Brand Model/Type No. Series No. Note E-1 Wireless Receive r N/A PLL-16D(RECE IVER) N/A EUT E-2 Adapter N/A FLB135400 N/A E-3 Load N/A N/A N/A Item Shielded Type Ferrite CoreLength Note C-1 NO NO 1.75m C-2 NO NO 1.0m Note:…

Text truncated - open the document above for the full version.

Page 21 of 22 Report No.: ISOT15070065E 4. EUT TEST PHOTO Radiated Measurement Photos Page 22 of 22 Report No.: ISOT15070065E Conducted Measurement Photos
