I5413-002-00-01Titian AE - Wrist Communcator

Date: 2000-02-28 TEST REPORT Page 1 of 9 No.: HM102215APPENDIX A Law Man KitKitty ChoyPatrick Wong Testing EngineerVerify byPatrick Wong for Managing Director APPLICANT: (Code : TIE003) TIGER ELECTRONICS INC. 980 WOODLANDS PARKWAY, VERNON HILLS, IL 60061, U.S.A. DATE OF SAMPLES RECEIVED: 2000-02-18 DATE OF TESTING: 2000-02-25 DESCRIPTION OF SAMPLE(S): A sample of product said to be: Product:TITAN AE - WRIST COMMUNICATOR Manufacturer:KINGTRONICS INDUSTRIAL CO., LTD. Model Number:13-002-00-01 Brand Name:TITAN AE - WRIST COMMUNICATOR Rating:4.5Vd.c. ("AAA" size battery × 3) Origin:CHINA INVESTIGATIONS REQUESTED: Measurement to the relevant clauses of F.C.C. Rules and Regulations Part 15 Subpart B - Unintentional Radiator and Subpart C - Intentional Radiator. RESULT/ REMARK:Please see attached sheet(s). CONCLUSION: From the measurement data obtained, the tested sample was considered to have COMPLIED after modification by customer with the clause 15.109(a) and ANSI C63.4-1992 Section 12.1.1.1-2 for the Receiver Section and for the Transmitter Section with the clause 15.235 of Federal Communications Commission Rules and Regulations Part 15. TEST EQUIPMENT AUDIT: Please see Appendix A. Date: 2000-02-28TEST REPORTPage 2 of 9 No.:HM102215 T E S T S U M M A R Y ***UNINTENTIONAL RADIATOR*** (A)Measurement of Radiated Emissions ...........................................Satisfactory (B)Line Conducted Voltage Test. ......................................................Not Applicable *** INTENTIONAL RADIATOR*** : (1)Measurement of Emission of RF energy on the carrier frequency...Satisfactory Measurement of the out-of band emissions including harmonics.....Satisfactory (2)Measurement of Emission Within Band Edges...............................Satisfactory (3)Measurement of Line-Conducted Voltage onto AC Power Line......Not Applicable T E S T D A T A Please refer to the attached result sheets. Date: 2000-02-28TEST REPORTPage 3 of 9 No.:HM102215 ***UNINTENTIONAL RADIATOR*** (A) Measurement of Radiated Interference TEST REFERENCE: FCC Rules Part 15 Subpart B section 15.109(a) TEST CONDITION : Normal TEST DATE : 2000-02-25 Freq. to which tuned Freq. of the emission PolarizationMeter reading (at 3m) Antenna factor Field Strength (at 3m) FCC Limit @ MHzMHzH-V dB(μV) dB dB(μV/m)μV/mμV/m 49.86049.9<1.0+15.0<16.0<6.3100 99.7<1.0+12.2<13.2<5150 149.6<1.0+9.8<10.8<3150 199.4<1.0+11.5<12.5<4150 249.3<1.0+15.9<16.9<7200 299.1<1.0+17.0<18.0<8200 349.0<1.0+17.2<18.2<8200 398.8<1.0+18.8<19.8<10200 448.7<1.0+19.7<20.7<11200 498.6<1.0+20.6<21.6<12200 548.4<1.0+22.2<23.2<14200 598.3<1.0+23.4<24.4<17200 648.1<1.0+23.5<24.5<17200 698.0<1.0+25.0<26.0<20200 747.8<1.0+26.2<27.2<25200 797.7<1.0+27.2<28.2<25200 847.5<1.0+27.2<28.2<25200 897.5<1.0+27.2<28.2<25200 947.2<1.0+27.8<28.8<27200 997.1<1.0+28.5<29.5<27500 ==========SUMMARY========== All data is within limits =========================================================== Broad-band Antennas were used and both polarizations of emissions were measured Polarizations at highest reading indicated as: H -- HorizontalV -- Vertical ============================================================ Date: 2000-02-28TEST REPORTPage 4 of 9 No.:HM102215 NOTES FOR THE RADIATION MEASUREMENT (1) Test site facility: Open field test site located at Taipo (Hong Kong) with a metal ground plane on filed with the FCC pursuant to section 2.948 of the FCC Rules. (2) Distance between the EUT and measuring antenna: 3 meters. (3) Measuring instrumentation: CISPR Quasi-peak type field strength meter (25 MHz - 1000 MHz.). 6 dB bandwidth set at 120 KHz. Also, peak level of the fundamental emissions was measured in order to determine compliance with the 20dB peak to average limit specified in Section 15.35(b) of the FCC new Rules. (4) Measuring antenna: Broad band antenna for the frequency range 25-1000 MHz, connected with 10 meters coaxial cable. Cable loss of the coaxial cable. included in the Antenna Factor for measurement data. The antenna are capable of measuring both horizontal and vertical polarizations. (5) Frequency range scanned: The frequency range from 25 MHz to 1000 MHz had been searched. Readings of the highest emissions relating to the limit were reported as above. (6) Arrangement of EUT: During the test, the sample was operated at rated supply voltage and arranged for maximum emissions. (7) Measuring Procedure: In accordance with the relevant clauses of the FCC Rules Part 15 section 15.109(a) and ANSI C63.4:1992 section 12.1.1.1-2. For superregenerative receivers, an independent signal generator had been used to radiated an unmodulated were (cw) signal to the receiver at its operating frequency in order to “cohere” or resolve the individual components of the characteristic broadband emission from such a receiver. The level of such signal may need to be adjusted in order to accomplish this. (8) Measuring Uncertainty: The calculated uncertainty for measurement performed at 3M test distance are:- 30MHz to 300MHz = ± 3.7dB, 300MHz to 1000MHz = + 3.0dB/-2.7dB. Remark: Purpose of this test is to provide the Applicant with the necessary test data of their device for the submission to FCC with application for Equipment Authorization under FCC Equipment Authorization Program. This test itself is not an Approval Test. Date: 2000-02-28TEST REPORTPage 5 of 9 No.:HM102215 ** INTENTIONAL RADIATOR *** (1) Measurement of Radiated Interference TEST REFERENCE:FCC Rules Part 15 Section 15.235(49.82-49.90 MHz) TEST CONDITION:Normal TEST DATE:2000-02-25 Emission of RF energy on the carrier frequency -- 49.860 MHz (PEAK VALUE) Emission Frequency Meter Reading PolarizationAntenna Factor Field Strength (at 3m) FCC Limit MHz dB(μV) H-VdB dB(μV/m)μV/mμV/m 49.956.5V+15.071.53758.4100000 Emission of RF energy on the carrier frequency -- 49.860 MHz (AVERAGE VALUE) Emission Frequency Meter Reading PolarizationAntenna Factor Field Strength (at 3m)FCC Limit MHz dB(μV) H-VdB dB(μV/m)μV/mμV/m 49.951.6V+15.066.62138.010000 ... t…
