Request for Confidentiality 15 January 2003 PHOENIX TEST-LAB GmbH Kˆnigswinkel 10 D32825 Blomberg Germany RE: Certification Application FCC ID: IDHFEL3 Please be advised that the following information is to be held confidential on behalf of Fellowes Inc.: • Schematics • Block Diagram • Technical Description The application contains technical information which Fellowes Inc. deems to be trade secrets and proprietary. If made public, the information might be used to the disadvantage of the applicant in the market place. Thank you for your attention to this matter. Signatory

FCC ID: IDHFEL3 External Photos Page 1 of 3 FCC ID: IDHFEL3 External Photos Page 2 of 3 FCC ID: IDHFEL3 External Photos Page 3 of 3

FCC-ID: IDHFEL3 This device complies with Part 15 of the FCC Rules, Operation is subject to the following two conditions: (1) this device may not cause harmful interference and (2) this device must accept any interference received, including interference that may cause undesired operation.

FCC ID: IDHFEL3 Internal Photos Page 1 of 7 FCC ID: IDHFEL3 Internal Photos Page 2 of 7 FCC ID: IDHFEL3 Internal Photos Page 3 of 7 FCC ID: IDHFEL3 Internal Photos Page 4 of 7 FCC ID: IDHFEL3 Internal Photos Page 5 of 7 FCC ID: IDHFEL3 Internal Photos Page 6 of 7 FCC ID: IDHFEL3 Internal Photos Page 7 of 7

EMV-Pr ̧fzentrum EMI/EMC-Testcenter Page 1 of 21 Pages Straubing, 13 January 2003 T E S T - R E P O R T No. 56408-20846-1 for Model No. 99197 Wireless Optical Mouse Applicant: Fellowes Manufacturing Company Purpose of testing: To show compliance with FCC Code of Federal Regulations, CFR 47, Part 15, Subpart C, Section 15.227 Note: The test data of this report relate only to the individual item which has been tested. This report shall not be reproduced except in full extent without the written approval of the testing laboratory. FCC-ID: --- Test Report No. 56408-20846-1 Page 2 of 21 Pages Table of Contents 1. Administrative Data ............................................................................................. 3 2. Identification of Test Laboratory .......................................................................... 4 3. Summary of Test Results .................................................................................... 5 4. Operation Mode of EUT....................................................................................... 6 5. Configuration of EUT and Peripheral Devices ..................................................... 7 6. Measuring Methods ............................................................................................. 8 6.1. Field strength of in-band emissions (ß15.227 (a)) and unwanted emissions < 30 MHz (ß15.209 (b)) ............................................... 8 6.2. Unwanted Emission 30 MHz - 1 GHz (ß15.209 (b)) ...................................... 9 7. Photographs of Test Setups .............................................................................. 11 7.1. Radiated Emissions 30 ñ 1000 MHz (Pre-Test in Fully Anechoic Chamber) ................................................................................................... 12 7.2. Radiated Emissions 30 ñ 1000 MHz (Final Test in Open Area Test-Site).................................................................................................... 13 8. Equipment List................................................................................................... 14 9. Referenced Regulations .................................................................................... 16 10. List of Measurements ........................................................................................ 17 11. Test Results ...................................................................................................... 18 12. Charts taken during testing................................................................................ 21 FCC-ID: --- Test Report No. 56408-20846-1 Page 3 of 21 Pages 1. Administrative Data Equipment Under Test (EUT): Model No. 99197 Serial number(s): --- Type of equipment: Wireless Optical Mouse Type of emission: 10K0F1D Parts/accessories: --- FCC-ID: --- Applicant: Fellowes Manufacturing Company (full address) 12F, No. 111-6, Hsing-De Rd, Chung, Taipei Hsien, Taiwan, R.O.C. Contract identification: --- Contact person: Joan Wu (Universal Technology Co. Ltd.) Manufacturer: Fellowes Manufacturing Company Receipt of EUT: 23 December 2002 Dates of test: January 2003 Note: --- Responsible for testing: Johann Roidt Responsible for test report: Johann Roidt (cj) FCC-ID: --- Test Report No. 56408-20846-1 Page 4 of 21 Pages 2. Identification of Test Laboratory Test Laboratory: Senton GmbH EMI/EMC Test Center (full address): Aeussere Fruehlingstrasse 45 D-94315 Straubing Germany Contact person: Mr. Johann Roidt Communication: Telephone (+49) 0 94 21 / 55 22-0 Fax (+49) 0 94 21 / 55 22-99 eMail: [email protected] FCC registration number: 90926 Industry Canada file number: IC 3050 FCC-ID: --- Test Report No. 56408-20846-1 Page 5 of 21 Pages 3. Summary of Test Results The tested sample complies with the requirements for set forth in the The Code of Federal Regulations 47, Part 15, Subpart C, Section 15.227 of the Federal Communication Commission (FCC). Johann Roidt Technical Manager FCC-ID: --- Test Report No. 56408-20846-1 Page 6 of 21 Pages 4. Operation Mode of EUT Continously TX mode ( by moving mouse automaticly) FCC-ID: --- Test Report No. 56408-20846-1 Page 7 of 21 Pages 5. Configuration of EUT and Peripheral Devices Configuration of cables of EUT Not applicable Configuration of peripheral devices connected to EUT No peripheral devices connected FCC-ID: --- Test Report No. 56408-20846-1 Page 8 of 21 Pages 6. Measuring Methods 6.1. Field strength of in-band emissions (ß15.227 (a)) and unwanted emissions < 30 MHz (ß15.209 (b)) Radiated emissions in the frequency range 9 kHz ñ 30 MHz will be measured initially at a distance of 3 meters. A prescan at 3 meter distance will be performed in a shielded room with the detector of the spectrum analyzer or EMI Receiver set to peak. Final measurement is then performed at 30 meter distance. In case the regulation requires testing at other distances, the result will be extrapolated. The extrapolation factor will be determined by making a second measurement at 10 meter distance. The provisions of 15.31 (d) apply. According to section 15.209 (d) final measurementis performed with the detector set to Quasi Peak except for the frequency bands 9 ñ 90 kHz and 110 ñ 490 kHz where average detector is employed. FCC-ID: --- Test Report No. 56408-20846-1 Page 9 of 21 Pages 6.2. Unwanted Emission 30 MHz - 1 GHz (ß15.209 (b)) Radiated emissions were measured over the frequency range from 30 MHz to 1 GHz. For final testing the detector-function of the spectrum analyzer was set to quasi peak Measurements were made in both the horizontal and vertical planes of polarization. Preliminary scans were taken in a semi-anechoic room using a spectrum analyzer with the detector function set to peak and resolution bandwidth set to 100 kHz. All tests were performed at a test-distance of 3 meters. Hand-held or body-worn devices are rotated through three orthogonal axes to determine which attitude and configuration produces the highest emission rel…
