IDHFELONN02onn Item Locator Card

Fellowes Inc Covered Equipment Certification Attestation Letter 3/30/2026 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA ATTN.: Reviewing Engineer FCC ID: IDHFELONN02 Fellowes Inc (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Note: If the equipment for which the applicant seeks authorization is produced by any of the entities identified on the current Covered List, the applicant should include an explanation on why the equipment is not “covered” equipment. Fellowes Inc (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List (as a specifically named entity or any of its subsidiaries or affiliates) as an entity producing “covered” equipment. Fellowes Inc (“the applicant”) certifies that the equipment for which authorization is sought does not include cybersecurity or anti-virus software produced or provided by Kaspersky Lab, Inc. or any of its successors and assignees, including equipment with integrated Kaspersky Lab, Inc. (or any of its successors and assignees) cybersecurity or anti-virus software pursuant to DA-24-886 and KDB 986446 D01 Covered Equipment Guidance section B(2a). Signed: Printed name: Michael Kelley Title: Compliance Manager Company Name: Fellowes Inc. Date: 3/30/2026

Fellowes Inc * the applicant must designate a contact located in the United States for purposes of acting as the applicant’s agent for service of process, regardless of whether the applicant is a domestic or foreign entity. An applicant located in the United States may designate itself as the agent for service of process. U.S. Agent Designation for Service of Process - Certification Attestation Letter 4/13/2026 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA ATTN.: Reviewing Engineer FCC ID: IDHFELONN02 FRN of applicant: 0006094130 Per section 2.911(d)(7) of the FCC rules, Fellowes Inc (“the applicant”) certifies that the equipment for which authorization is sought is designated to the following U.S. agent* for service of process: Company Name: Fellowes Inc FCC Registration Number (FRN): 0006094130 Physical U.S. Company Address: 1789 Norwood Avenue, Itasca, Illinois 60143-1095, United States Contact Person: Michael Kelley Agent Email Address: [email protected] The above contact person accepts the obligation for service of process. The applicant accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. Applicant Signed: Agent Signed (if different from Applicant): Signed: Signed: Printed name: Michael Kelley Printed name: Michael Kelley Title: Compliance Manager Title: Compliance Manager Company Name: Fellowes Inc Company Name: Fellowes Inc Date: 4/13/2026 Date: 4/13/2026

DATE : 4/13/2026 Federal Communications Commission Authorization & Evaluation Division 7345 Oakland Mills Road Columbia, Maryland 21046 Authority to Act as Agent On our behalf, I appoint EST Technology Co., Ltd. Address:Chilingxiang, Qishantou, Santun, Houjie, Dongguan, Guangdong, China to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in the Federal Communications Commission’s regulations will have affixed to it a label identical to that submitted for approval with this application. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for certification, still resides with Fellowes Inc Address: 1789 Norwood Avenue, Itasca, Illinois 60143-1095, United States Name：Michael Kelley Title：Compliance Manager Applicant Company：Fellowes Inc.

DATE : 4/13/2026 Federal Communications Commission Authorization & Evaluation Division 7345 Oakland Mills Road Columbia, Maryland 21046 RE: LETTER OF AGENT AUTHORIZATION To Whom It May Concern: We, the undersigned, hereby authorize Compliance Testing, LLC to act on our behalf in all matters relating to application for equipment authorization, including the signing of all documents relating to these matters. We also hereby certify that no party to the application authorized hereunder is subject to the denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C.853(a). Sincerely, Name：Michael Kelley Title：Compliance Manager Company：Fellowes Inc.

DATE : 4/13/2026 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: IDHFELONN02 Product Name: onn Item Locator Card Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commissions rules, we hereby request that the following documents be held confidential: • Schematics • Block diagram • Operation description These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. Name：Michael Kelley Title：Compliance Manager Company：Fellowes Inc.

DATE : 4/13/2026 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: IDHFELONN02 Product Name: onn Item Locator Card Request for Short-Term Confidentiality Pursuant to Sections 0.457 and 0.459 of the commission rules, and in accordance with the FCC Public notice dated June 15, 2004 (DA 04-1705), we hereby request short-term confidentiality for the following items prior to marketing the device.:  Test Setup Photos  External Photos  Internal Photos  User Manual The applicant requests the exhibits selected above as short term confidential be withheld from public view for a period of 180 days from the date of the Grant of Equipment Authorization and prior to marketing. This is to avoid premature release of sensitive information prior to marketing or release of the product to the public. Name：Michael Kelley Title：Compliance Manager Company：Fellowes Inc.

Page 1 of 3 Report No. ESTE-R2603385 FCC RF EXPOSURE REPORT Fellowes Inc onn Item Locator Card Model Number: GAILCC36025874 FCC ID: IDHFELONN02 Applicant: Fellowes Inc Address: 1789 Norwood Avenue, Itasca, Illinois 60143-1095, United States Prepared By: EST Technology Co., Ltd. Chilingxiang, Qishantou, Santun, Houjie, Dongguan, Guangdong, China Tel: 86-769-83081888-808 Report Number: ESTE-R2603385 Date of Test: Mar. 12, 2026 to Apr. 01, 2026 Date of Report: Apr. 01, 2026 Page 2 of 3 Report No. ESTE-R2603385 1. Applicable Standards FCC Part 2(Section 2.1093) FCC KDB 447498 D01 General RF Exposure Guidance v06 2. Exposure Evaluation of Portable or Mobile Devices Human exposure to RF emissions from portable devices (47 CFR §2.1093), as defined by the FCC, must be evaluated with respect to the FCC-adopted limits for SAR. Evaluation of mobile devices, as defined by the FCC, may also be performed with respect to SAR limits, but in such cases it is usually simpler and more cost-effective to evaluate compliance with respect to field strength or power density limits. For certain devices that are designed to be used in both mobile and portable configurations similar to those described in 47 CFR §2.1091(d)(4), such as certain desktop phones and wireless modem modules, compliance for mobile configurations is also satisfied when the same device is evaluated for SAR compliance in portable configurations. 3. SAR Test Exclusion Threshold For 100MHz to 6GHz and ≤50mm The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] · [√f(GHz)] ≤3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, where •f(GHz) is the RF channel transmit frequency in GHz • Power and distance are rounded to the nearest mW and mm before calculation • The result is rounded to one decimal place for comparison The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm is applied to determine SAR test exclusion. Page 3 of 3 Report No. ESTE-R2603385 4. Evaluation Results Mode Frequency (MHz) Peak output Power (dBm) Peak output Power (mW) Target power (dBm) Results BLE 1M 2402 5.39 3.459 5±1 1.234 2440 5.08 3.221 5±1 1.244 2480 4.88 3.076 4±1 0.996 BLE 2M 2402 5.47 3.524 5±1 1.234 2440 5.16 3.281 5±1 1.244 2480 4.99 3.155 4±1 0.996 Note: 1. [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] * [√f(GHz)] < 3.0 2. SAR Test Exclusion Thresholds is 3.0 for separation distance 5mm. Therefore, SAR test is not required. End of Test Report

Page 1 of 25 Report No.ESTE-R2603384 Appendix A: DTS Bandwidth Test Result Test Mode Antenna Frequency[MHz] DTS BW [MHz] FL[MHz] FH[MHz] Limit[MHz] Verdict BLE_1M Ant1 2402 0.723 2401.628 2402.351 0.5 PASS BLE_1M Ant1 2440 0.720 2439.631 2440.351 0.5 PASS BLE_1M Ant1 2480 0.732 2479.622 2480.354 0.5 PASS BLE_2M Ant1 2402 1.398 2401.310 2402.708 0.5 PASS BLE_2M Ant1 2440 1.398 2439.310 2440.708 0.5 PASS BLE_2M Ant1 2480 1.404 2479.304 2480.708 0.5 PASS Page 2 of 25 Report No.ESTE-R2603384 Test Graphs BLE_1M-Ant1-2402-PASS BLE_1M-Ant1-2440-PASS BLE_1M-Ant1-2480-PASS Page 3 of 25 Report No.ESTE-R2603384 BLE_2M-Ant1-2402-PASS BLE_2M-Ant1-2440-PASS Page 4 of 25 Report No.ESTE-R2603384 BLE_2M-Ant1-2480-PASS Page 5 of 25 Report No.ESTE-R2603384 Appendix B: Maximum conducted output power Test Result Peak Test Mode Antenna Frequency[MHz] Conducted Peak Power[dBm] Conducted Limit[dBm] Verdict BLE_1M Ant1 2402 5.39 ≤30 PASS BLE_1M Ant1 2440 5.08 ≤30 PASS BLE_1M Ant1 2480 4.88 ≤30 PASS BLE_2M Ant1 2402 5.47 ≤30 PASS BLE_2M Ant1 2440 5.16 ≤30 PASS BLE_2M Ant1 2480 4.99 ≤30 PASS Test Graphs Peak BLE_1M-Ant1-2402-PASS BLE_1M-Ant1-2440-PASS Page 6 of 25 Report No.ESTE-R2603384 BLE_1M-Ant1-2480-PASS BLE_2M-Ant1-2402-PASS Page 7 of 25 Report No.ESTE-R2603384 BLE_2M-Ant1-2440-PASS BLE_2M-Ant1-2480-PASS Page 8 of 25 Report No.ESTE-R2603384 Page 9 of 25 Report No.ESTE-R2603384 Appendix C: Maximum power spectral density Test Result Test Mode Antenna Frequency[MHz] Result[dBm/3kHz] Limit[dBm/3kHz] Verdict BLE_1M Ant1 2402 -11.13 ≤8.00 PASS BLE_1M Ant1 2440 -11.50 ≤8.00 PASS BLE_1M Ant1 2480 -11.59 ≤8.00 PASS BLE_2M Ant1 2402 -15.92 ≤8.00 PASS BLE_2M Ant1 2440 -16.24 ≤8.00 PASS BLE_2M Ant1 2480 -15.92 ≤8.00 PASS Page 10 of 25 Report No.ESTE-R2603384 Test Graphs BLE_1M-Ant1-2402-PASS BLE_1M-Ant1-2440-PASS BLE_1M-Ant1-2480-PASS Page 11 of 25 Report No.ESTE-R2603384 BLE_2M-Ant1-2402-PASS BLE_2M-Ant1-2440-PASS Page 12 of 25 Report No.ESTE-R2603384 BLE_2M-Ant1-2480-PASS Page 13 of 25 Report No.ESTE-R2603384 Appendix D: Reference level measurement Test Result Test Mode Antenna Freq(MHz) Max.Point[MHz] Result[dBm] BLE_1M Ant1 2402 2402.24 4.43 BLE_1M Ant1 2440 2440.24 4.14 BLE_1M Ant1 2480 2480.23 3.96 BLE_2M Ant1 2402 2401.49 2.03 BLE_2M Ant1 2440 2439.49 1.73 BLE_2M Ant1 2480 2479.49 1.58 Page 14 of 25 Report No.ESTE-R2603384 Test Graphs BLE_1M-Ant1-2402-PASS BLE_1M-Ant1-2440-PASS BLE_1M-Ant1-2480-PASS Page 15 of 25 Report No.ESTE-R2603384 BLE_2M-Ant1-2402-PASS BLE_2M-Ant1-2440-PASS Page 16 of 25 Report No.ESTE-R2603384 BLE_2M-Ant1-2480-PASS Page 17 of 25 Report No.ESTE-R2603384 Appendix E: Band edge measurements Test Result Test Mode Antenna Ch Name Frequency [MHz] Ref Level[dBm] Result [dBm] Limit [dBm] Verdict BLE_1M Ant1 Low 2402 4.43 -40.95 ≤-15.57 PASS BLE_1M Ant1 High 2480 3.96 -40.91 ≤-16.04 PASS BLE_2M Ant1 Low 2402 2.03 -29.57 ≤-17.97 PASS BLE_2M Ant1 High 2480 1.58 -41.16 ≤-18.42 PASS Page 18 of 25 Report No.ESTE-R2603384 Test Graphs BLE_1M-Ant1-2402-PASS BLE_1M-Ant1-2480-PASS BLE_2M-Ant1-2402-PASS Page 19 of 25 Report No.ESTE-R2603384 BLE_2M-Ant1-2480-PASS Page 20 of 25 Report No.ESTE-R2603384 Appendix F: Conducted Spurious Emission Test Result Test Mode Antenna Frequency [MHz] FreqRange [MHz] RefLevel [dBm] Result[dBm] Limit[dBm] Verdict BLE_1M Ant1 2402 30~26500 4.43 -43.23 ≤-15.57 PASS BLE_1M Ant1 2440 30~26500 4.14 -43.41 ≤-15.86 PASS BLE_1M Ant1 2480 30~26500 3.96 -43.66 ≤-16.04 PASS BLE_2M Ant1 2402 30~26500 2.03 -43.22 ≤-17.97 PASS BLE_2M Ant1 2440 30~26500 1.73 -43.38 ≤-18.27 PASS BLE_2M Ant1 2480 30~26500 1.58 -42.98 ≤-18.42 PASS Page 21 of 25 Report No.ESTE-R2603384 Test Graphs BLE_1M-Ant1-2402-30~26500-PASS BLE_1M-Ant1-2440-30~26500-PASS BLE_1M-Ant1-2480-30~26500-PASS Page 22 of 25 Report No.ESTE-R2603384 BLE_2M-Ant1-2402-30~26500-PASS BLE_2M-Ant1-2440-30~26500-PASS Page 23 of 25 Report No.ESTE-R2603384 BLE_2M-Ant1-2480-30~26500-PASS Page 24 of 25 Report No.ESTE-R2603384 Appendix G: Duty Cycle Test Result Test Mode Antenna Frequency[MHz] ON Time [ms] Period [ms] Duty Cycle [%] Duty Cycle Factor[dB] BLE_1M Ant1 2440 20.00 20.00 100.00 0.00 BLE_2M Ant1 2440 18.00 18.00 100.00 0.00 Page 25 of 25 Report No.ESTE-R2603384 Test Graphs NTNV-BLE_1M-Ant1-2440 NTNV-BLE_2M-Ant1-2440

Page 1 of 35 Report No.ESTE-R2603384 FCC PART 15C TEST REPORT FOR CERTIFICATION On Behalf of Fellowes Inc onn Item Locator Card Model Number: GAILCC36025874 FCC ID: IDHFELONN02 Applicant: Fellowes Inc Address: 1789 Norwood Avenue, Itasca, Illinois 60143-1095, United States Prepared By: EST Technology Co., Ltd. Chilingxiang, Qishantou, Santun, Houjie, Dongguan, Guangdong, China Tel: 86-769-83081888-808 Report Number: ESTE-R2603384 Date of Test: Mar. 12, 2026 to Apr. 01, 2026 Date of Report: Apr. 01, 2026 Page 2 of 35 Report No.ESTE-R2603384 TABLE OF CONTENTS Description Page TEST REPORT VERIFICATION .......................................................................................................... 3 1. GENERAL INFORMATION ................................................................................................................... 5 1.1. Description of Device (EUT) ............................................................................................................ 5 1.2. Antenna Information ......................................................................................................................... 5 1.3. Information of RF Cable ................................................................................................................... 5 2. SUMMARY OF TEST ........................................................................................................................... 6 2.1. Summary of test result ..................................................................................................................... 6 2.2. Test Facilities ..................................................................................................................................... 7 2.3. Measurement uncertainty ................................................................................................................ 8 2.4. Assistant equipment used for test .................................................................................................. 8 2.5. Block Diagram ................................................................................................................................... 8 2.6. Test Mode .......................................................................................................................................... 9 2.7. Power Setting of Test Software ...................................................................................................... 9 2.8. Duty Cycle .......................................................................................................................................... 9 2.9. Channel List ..................................................................................................................................... 10 2.10. Test Equipment List ...................................................................................................................... 11 3. 6DB BANDWIDTH ............................................................................................................................ 12 3.1. Limit ................................................................................................................................................... 12 3.2. Test Setup ........................................................................................................................................ 12 3.3. Spectrum Analyzer Setting ............................................................................................................ 12 3.4. Test Procedure ................................................................................................................................ 12 3.5. Test Result ....................................................................................................................................... 12 4. MAXIMUM PEAK OUTPUT POWER .................................................................................................. 13 4.1. Limit ................................................................................................................................................... 13 4.2. Test Setup ........................................................................................................................................ 13 4.3. Spectrum Analyzer Setting ............................................................................................................ 13 4.4. Test Procedure ................................................................................................................................ 13 4.5. Test Result ....................................................................................................................................... 13 5. POWER SPECTRAL DENSITY .......................................................................................................... 14 5.1. Limit ................................................................................................................................................... 14 5.2. Test Setup ........................................................................................................................................ 14 5.3. Spectrum Analyzer Setting ............................................................................................................ 14 5.4. Test Procedure ................................................................................................................................ 14 5.5. Test Result ....................................................................................................................................... 14 6. CONDUCTED BAND EDGE .............................................................................................................. 15 6.1. Limit ................................................................................................................................................... 15 6.2. Test Setup ..........................…

Text truncated - open the document above for the full version.
