IXLPRT6KPT6RFID Reader

PRD 6•PRM 6•PRL 6•PDM 6•PRT 6 KPD 6•KPM 6•KPL 6•KPT 6 Wiring & Installation Instructions Anschluß & Installationshinweise Instructions d'Installation et de Raccordement V240306 #896347 1. Dimensions / Abmessungen (mm) PRD 6•PRM 6•PRL 6•PDM 6•PRT 6 www.deister.com It is possible that external interference sources will influence the read range, e.g. monitors, switching power supplies, power cables parallel to data cables, mounting on metal etc. LCD monitors have a minimal influence on the read range. In particular the reader should be mounted on non-metallic material, such as plastic or wood. Metal screws (M6 - ISO 1207, 4762 or 7045) for mounting the reader have an insignificant influence on the read range. The unit needs to be operated with a power source with limited power consumption according to EN 62368-1:2016-05 annex Q.1. 5.1G Note: 5.G Warning: 5.1G Hinweis: Il est possible que certaines sources d'interférences extérieures puissant influer sur la distance de lecture, ex.: moniteurs, mise en/hors service d'alimentations électriques, câbles d'alimentations à proximités des câbles de données, montage sur du métal, etc. Les moniteurs LCD ont une influence minimale sur la distance de lecture.En particulier, le lecteur devra être monté sur une surface non-métalique, comme sur du plastique ou du bois. Les vis en métal (M6 - ISO 1207, 4762 ou 7045) pour le montage du lecteur ont une influence insignifiante sur la distance de lecture. Le système doit être alimenté avec une alimentation dont la puissance de consommation est limitée conformément à la norme EN 62368-1:2016-05 annexe Q.1. Es ist möglich, das externe Störquellen die Lesereichweite beeinträchtigen. Dazu zählen z.B. Monitore, Schaltnetzteile, Stromkabel, Datenkabel oder die Montage des Lesers direkt auf Metall. LCD-Monitore haben nur einen minimalen Einfluss auf die Lesereichweite. Im Normalfall sollte der Leser auf nicht-metallisches Material wie Plastik oder Holz montiert werden. Metallschrauben (M6 - ISO 1207, 4762 oder 7045) für die Montage des Lesers haben einen unbedeutenden Einfluss auf die Lesereichweite. Das Gerät ist mit einer Stromquelle mit begrenzter Leistung nach EN 62368-1:2016-05 Anhang Q.1 zu betreiben. En augmentant la distance entre le lecteur et la source d'interférence, l'influence décroît. Utiliser seulement des alimentations électriques stabilisées. deister electronic GmbH propose des alimentations appropriées. Pour réduire l'influence d'interférences électriques externes, connecter l'écran de protection du câble à la masse (GND) de l'alimentation électrique. Bei größer werdender Entfernung der Störquelle reduziert sich deren Einfluss auf den Leser. Benutzen Sie nur linear geregelte Netzteile. Die deister electronic GmbH bietet entsprechende Netzteile an. Um den Einfluss externer, elektrischer Störungen zu vermeiden, verbinden Sie den Masseanschluß (GND) mit der Erdungsklemme des Netzteils. 5.G Warnung: 5.1G Note: 5.G Attention: With growing distance between reader and interference source, the influence decreases. Use only linear regulated power supplies. deister electronic GmbH offers suitable power supplies. To reduce the influence of external electrical interference, connect the cable shield to ground (GND) of the power supply. Hiermit erklärt deister electronic, dass der Funkanlagentyp PRD 6 / PRM 6 / PRL 6 / PDM 6 / PRT 6 / KPD 6 / KPM 6 / KPL 6 / KPT 6 der Richtlinie 2014/53/EU entspricht. Der vollständige Text der EU-Konformitätserklärung ist unter der folgenden Internetadresse verfügbar: https://go.deister.com/ce Hereby, deister electronic declares that the radio equipment type PRD 6 / PRM 6 / PRL 6 / PDM 6 / PRT 6 / KPD 6 / KPM 6 / KPL 6 / KPT 6 is in compliance with Directive 2014/53/EU. The full text of the EU declaration of conformity is available at the following internet address: http://go.deister.com/ce 6. Zulassungen für Europa: 6. Regulatory notices for Europe: Le soussigné, deister electronic, déclare que l'équipement radioélectrique du type PRD 6 / PRM 6 / PRL 6 / PDM 6 / PRT 6 / KPD 6 / KPM 6 / KPL 6 / KPT 6 est conforme à la directive 2014/53/UE. Le texte complet de la déclaration UE de conformité est disponible à l'adresse internet suivante: http://go.deister.com/ce 6. Avis Réglementation Europe: 7. FCC/IC This device complies with Industry Canada licence-exempt RSS standard(s) and part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense. Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence. L'exploitation est autorisée aux deux conditions suivantes : (1) l'appareil ne doit pas produire de brouillage, et (2) l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement. 8. Warranty Note • Garantiehinweis • Remarque garantie Bei nicht sachgemäßer Benutzung des Gerätes erlischt die Garantie! • Improper use of the device will void the warranty! • L‘utilisation incorrecte de l‘appa…

Text truncated - open the document above for the full version.

CKC Certification Services, LLC CB: US0103; NB/AB: 0976 5046 Sierra Pines Drive Mariposa, CA 95338 Phone: 1 800-500-4EMC (4362) Fax: 209-787-5568 Email: [email protected] APP-FCC-A Page 1 of 2 Rev 3 APP-FCC-A Applicant Attestation Applicant Information Company Name: Deister Electronic GmbH Deister Electronics USA, Inc. Contact Name: Bill Nuffer Contact Title: Director of Technology Company Address: 8576 Wellington Rd Manassas, VA 20109 Telephone No: +1.703.368.2739 Facsimile No: Email Address: [email protected] Certification Type / Equipment Identification Certification Program: FCC Equipment Authorization / Radio Certification Certification Number: IXLPRT6KPT6 The equipment identified above ☐ is / ☒ is not “covered” equipment prohibited from receiving an equipment authorization pursuant to 47 CFR Part 2, Subpart J, §2.903. The applicant identified above ☐ is / ☒ is not identified on the FCC’s “Covered List” as an entity, affiliate, or subsidiary which produces equipment on the “Covered List” or identified as an entity which has rebranded or relabeled equipment produced by entities identified on the “Covered List.” I hereby attest and certify that the above statements are true and correct. Signature of Authorized Individual: 1 Printed Name: William L Nuffer Title of authorized signature: Director of Technology Date 7/30/2024 Note this attestation shall be signed by the applicant or their direct appointee within the same legal entity. A third party agent is not permitted to sign on behalf of the applicant. 1 Signature is not subject to the FCC’s authorized individual policy ( KDB 852134) and may be signed by any appropriate company official. CKC Certification Services, LLC CB: US0103; NB/AB: 0976 5046 Sierra Pines Drive Mariposa, CA 95338 Phone: 1 800-500-4EMC (4362) Fax: 209-787-5568 Email: [email protected] APP-FCC-A Page 2 of 2 Rev 3 Attachment A – Additional Information The FCC’s “Covered List” includes certain “telecommunications equipment” and “video surveillance equipment” produced by specific manufacturers, their Affiliates or Subsidiaries and including any products produced by these entities which are rebranded or relabeled by other entities. (191, 184, 185, 188) 2 The FCC claims the identified equipment poses an unacceptable risk to United States national security. Telecommunications Equipment (195) : Any equipment used in fixed or mobile networks that provides advanced communications service, provided the equipment includes or uses electronic components, as defined under section 1.50001(c). Video Surveillance Equipment (205) : Any equipment that is used in fixed and mobile networks that provides advanced communications service in the form of a video surveillance service, provided the equipment includes or uses electronic components. Advanced Communications Service (195, 205) Any equipment that can be used in such a fixed or mobile broadband network to enable users to originate and receive high quality voice, data, graphics, and video telecommunications service using any technology with connection speeds of at least 200 kbps in either direction. Affiliate (183) : An entity that (directly or indirectly) owns or controls, is owned or controlled by, or is under common ownership or control with, another entity, where the term “own” means to have, possess, or otherwise control an equity interest (or the equivalent thereof) of more than 10 percent. Subsidiary (184) : Any entity in which such named entity directly or indirectly (1) holds de facto control or (2) owns or controls more than 50% of the total voting power of the entity’s outstanding voting stock. Useful Links: FCC Covered List https://www.fcc.gov/supplychain/coveredlist 47 CFR Part 2 Subpart J (including 2.903 and 2.911) https://www.ecfr.gov/current/title-47/chapter-I/subchapter-A/part-2/subpart-J FCC KDB System: https://apps.fcc.gov/oetcf/kdb/index.cfm FCC Report and Order 22-84 https://docs.fcc.gov/public/attachments/FCC-22-84A1.pdf 2 Parenthetical references are citations of paragraph numbers in FCC Report and Order FCC 22-84 (ET Docket 21.232).

Attestation For United States Agent for Service of Process CKC CS PUB FCC AFSOP v3 Applicant / Equipment Manufacturer Information Company Name: Deister Electronic GmbH Grantee Code: IXLWCU2 FRN: 0006742449 Applicant Attestation The undersigned applicant hereby consents: a) to the designation of the herein named US Agent for Service of Process; and b) to accept responsibility and obligation to maintain a US Agent for Service of Process for no less than one year after either all marketing and importation of the applicable equipment within the U.S has been permanently terminated, or the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later; and c) to promptly update the US Agent for Service of Process information on file with the FCC in accordance with 47 CFR 2.929 in the event any change occurs in either the named entity or the named entity’s contact information. Signature of Applicant: Printed Name: Stephan Eichler Date: 4/26/2023 US Agent for Service of Process Information Company Name: Deister Electronics USA, Inc. Contact Name: William Nuffer Contact Title: Director of Technology Physical Address: 8576 Wellington Road Manassas, VA 20109 USA Mailing Address: Same as above Telephone No: +1.703.368.2739 Facsimile No: +1.703.368.9791 Email Address: [email protected] FRN 1 : N/A Agent for Service of Process Attestation The undersigned attests that the named party is a valid, legal US entity with a valid, legal US presence and as the delegated US Agent for Service of Process hereby consents: a) to acknowledges and accepts responsibility to act as United States Agent for Service of Process on behalf of the applicant identified above; and b) to accept service of process in the US for matters related to the applicable equipment and at the physical address and email address identified herein on behalf of the applicant identified above for equipment authorization applications under certification pursuant to 47 CFR Part 2 Subpart J. Signature of US Agent: Printed Name: William L Nuffer Date*: 4/26/2023 *Expiration date is not permitted. 1 FRN is mandatory when the US Agent for Service of Process has an existing FRN.

Deister Electronics USA, Inc. 9817 Godwin Drive #201 Manassas, VA 20110 Direct Line: +1-703-659-9497 Direct FAX: +1-415-762-1963 Email: [email protected] www.deister.com 30 April 2019 To Whom It May Concern: We hereby delegate CKC Certification Services, LLC (CKC CS) power of attorney to act on our behalf in matters pertaining to certification of products. The actions of CKC CS shall be considered the same as our own. Sincerely, William L Nuffer President Deister Electronics USA, Inc. 9817 Godwin Drive #201 Manassas, VA 20110 1.703.368.2739

Deister Electronics USA, Inc. 8576 Wellington Road Manassas, VA 20109 7/30/2024 Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Subject: Request for Permanent Confidentiality To whom it may concern: In accordance with 47CFR Section 0.457 and Section 0.459 pertaining to confidential material, we hereby request to hold permanently confidential all information contained within the below identified exhibits/document categories submitted pursuant to radio equipment certification requirements for FCC ID: IXLPRT6KPT6 1. Block Diagram 2. Operational Description 3. Schematics 4. Parts List The above material contains trade secrets and proprietary information as specified by 47CFR 0.457(d) and technical data, which would customarily be guarded from competitors. The public disclosure of this information might be harmful to our company and provide unjustified benefits to our competitors. Sincerely, William L Nuffer Director of Technology Deister Electronics USA, Inc.

F2P31157A Page 1 of 7 2024-04-24 PHOTOGRAPHS: EXTERNAL Deister Electronics USA, Inc. – FCC ID: IXLPRT6KPT6 PRT6/5: Front PRT6/5: Rear Order No(s): F2P31157A Applicant: Deister Electronics USA, Inc. FCC ID: IXLPRT6KPT6 F2P31157A Page 2 of 7 2024-04-24 PRT6/5: Right Side PRT6/5: Left Side Order No(s): F2P31157A Applicant: Deister Electronics USA, Inc. FCC ID: IXLPRT6KPT6 F2P31157A Page 3 of 7 2024-04-24 PRT6/5: Top PRT6/5: Bottom Order No(s): F2P31157A Applicant: Deister Electronics USA, Inc. FCC ID: IXLPRT6KPT6 F2P31157A Page 4 of 7 2024-04-24 KPT6/5: Front Order No(s): F2P31157A Applicant: Deister Electronics USA, Inc. FCC ID: IXLPRT6KPT6 F2P31157A Page 5 of 7 2024-04-24 KPT6/5: Rear Order No(s): F2P31157A Applicant: Deister Electronics USA, Inc. FCC ID: IXLPRT6KPT6 F2P31157A Page 6 of 7 2024-04-24 KPT6/5: Right Side KPT6/5: Left Side Order No(s): F2P31157A Applicant: Deister Electronics USA, Inc. FCC ID: IXLPRT6KPT6 F2P31157A Page 7 of 7 2024-04-24 KPT6/5: Top KPT6/5: Bottom

Sample ID Labels Sample ID Label Placement

F2P31157A Page 1 of 8 2024-04-24 PHOTOGRAPHS: EXTERNAL Deister Electronics USA, Inc. – FCC ID: IXLPRT6KPT6 PRT6/5 Order No(s): F2P31157A Applicant: Deister Electronics USA, Inc. FCC ID: IXLPRT6KPT6 F2P31157A Page 2 of 8 2024-04-24 PRT6/5, cont’d Order No(s): F2P31157A Applicant: Deister Electronics USA, Inc. FCC ID: IXLPRT6KPT6 F2P31157A Page 3 of 8 2024-04-24 PRT6/5, cont’d Order No(s): F2P31157A Applicant: Deister Electronics USA, Inc. FCC ID: IXLPRT6KPT6 F2P31157A Page 4 of 8 2024-04-24 PRT6/5, cont’d Order No(s): F2P31157A Applicant: Deister Electronics USA, Inc. FCC ID: IXLPRT6KPT6 F2P31157A Page 5 of 8 2024-04-24 KPT6/5 Order No(s): F2P31157A Applicant: Deister Electronics USA, Inc. FCC ID: IXLPRT6KPT6 F2P31157A Page 6 of 8 2024-04-24 KPT6/5, cont’d Order No(s): F2P31157A Applicant: Deister Electronics USA, Inc. FCC ID: IXLPRT6KPT6 F2P31157A Page 7 of 8 2024-04-24 KPT6/5, cont’d Order No(s): F2P31157A Applicant: Deister Electronics USA, Inc. FCC ID: IXLPRT6KPT6 F2P31157A Page 8 of 8 2024-04-24 KPT6/5, cont’d

20240420 Report Number: F2P31157A-04E Page 1 of 8 Issue Date: 2024-08-13 F2 Labs 16740 Peters Road Middlefield, Ohio 44062 United States of America www.f2labs.com MPE REPORT Manufacturer: Deister Electronic GmbH 11 Hermann Bahlsen Str Barsinghausen D-30890 GERMANY Applicant: Deister Electronics USA, Inc. 8576 Wellington Road Manassas, Virginia 20109 USA Product Name: Deister Electronics Legic Reader Product Description: RFID Reader for reading contactless Legic & Prox credentials with output to physical access control systems in Wiegand or OSDP. Model(s): PRT6* *Denotes actual model tested as worst-case representative of product family that includes models PRT6 and KPT6. FCC ID: IXLPRT6KPT6 Testing Commenced: 2024-03-22 Testing Ended: 2024-03-28 Test Results: In Compliance The EUT complies with the EMC requirements when manufactured identically as the unit tested in this report, including any required modifications. Any changes to the design or build of this unit subsequent to this testing may deem it non- compliant. Standards: • KDB447498 • FCC 1.1310 Order No(s): F2P31157A Applicant: Deister Electronics USA, Inc. Model: PRT6 042216 Report Number: F2P31157A-04E Page 2 of 8 Issue Date: 2024-08-13 Evaluation Conducted by: Julius Chiller, Senior Wireless Project Engineer Report Reviewed by: Ken Littell, Vice President of Operations F2 Labs F2 Labs F2 Labs 26501 Ridge Road 16740 Peters Road 8583 Zionsville Road Damascus, MD 20872 Middlefield, OH 44062 Indianapolis, IN 46268 Ph 301.253.4500 Ph 440.632.5541 Ph 317.610.0611 This test report may be reproduced in full; partial reproduction only may be made with the written consent of F2 Labs. The results in this report apply only to the equipment tested. Order No(s): F2P31157A Applicant: Deister Electronics USA, Inc. Model: PRT6 042216 Report Number: F2P31157A-04E Page 3 of 8 Issue Date: 2024-08-13 TABLE OF CONTENTS 1 ADMINISTRATIVE INFORMATION 2 SUMMARY OF TEST RESULTS/MODIFICATIONS 3 ENGINEERING STATEMENT 4 EUT INFORMATION AND DATA 5 RF EXPOSURE FOR DEVICE >20cm FROM HUMAN  FCC Order No(s): F2P31157A Applicant: Deister Electronics USA, Inc. Model: PRT6 042216 Report Number: F2P31157A-04E Page 4 of 8 Issue Date: 2024-08-13 1 ADMINISTRATIVE INFORMATION 1.1 Measurement Location: F2 Labs in Middlefield, Ohio. Site description and attenuation data are on file with the FCC's Sampling and Measurement Branch at the FCC Laboratory in Columbia, MD. 1.2 Measurement Procedure: All measurements were performed according to: • KDB558074 • FCC 15.209 1.4 Document History Document Number Description Issue Date Approved By F2P31157A-04E First Issue 2024-08-13 K. Littell Order No(s): F2P31157A Applicant: Deister Electronics USA, Inc. Model: PRT6 042216 Report Number: F2P31157A-04E Page 5 of 8 Issue Date: 2024-08-13 2 SUMMARY OF TEST RESULTS Test Name Standard(s) Results RF Exposure for Device >20cm from Human KDB447498 FCC 1.1310 Complies Modifications Made to the Equipment None Order No(s): F2P31157A Applicant: Deister Electronics USA, Inc. Model: PRT6 042216 Report Number: F2P31157A-04E Page 6 of 8 Issue Date: 2024-08-13 3 ENGINEERING STATEMENT This report has been prepared on behalf of Deister Electronics USA, Inc. to provide documentation for the calculations described herein, based on the measurements taken in supporting Test Reports. This equipment has been tested and calculations were found to comply with KDB447498 and FCC 1.1310. The test results found in this test report relate only to the item(s) tested. Order No(s): F2P31157A Applicant: Deister Electronics USA, Inc. Model: PRT6 042216 Report Number: F2P31157A-04E Page 7 of 8 Issue Date: 2024-08-13 4 EUT INFORMATION AND DATA 4.1 Equipment Under Test: Product: Deister Electronics Legic Reader Model(s): PRT6* *Denotes actual model tested as worst-case representative of product family that includes models PRT6 and KPT6. Serial No(s).: 3259400118, 3259400119 Firmware Version: f66x Hardware Version: A1 FCC ID: IXLPRT6KPT6 4.2 Trade Name: Deister Electronics USA, Inc. 4.3 Power Supply: 9-24VDC from external power supply 4.4 Applicable Rules: • KDB447498 • FCC 1.1310 4.5 Equipment Category: RFID Device 4.6 Antenna: Integral 4.7 Accessories: Device Manufacturer Model Number Serial Number Power Supply BK Precision 1685B 346F17303 4.8 Test Item Condition: The equipment to be tested was received in good condition. Order No(s): F2P31157A Applicant: Deister Electronics USA, Inc. Model: PRT6 042216 Report Number: F2P31157A-04E Page 8 of 8 Issue Date: 2024-08-13 5. RF EXPOSURE FOR DEVICE >20cm FROM HUMAN 5.1 Requirements: Distance used is 20cm 푃푃(푑푑푑푑푑푑)=퐸퐸(푑푑푑푑푑푑푑푑푑푑⁄)+20퐿퐿퐿퐿퐿퐿(푑푑)−퐿퐿 −104.77 42.09 + 9.542425 + 0 - 104.77 = - 53.14dBm 푃푃(푑푑푑푑푑푑)= − 53.14 푤푤ℎ푖푖푖푖ℎ 푖푖푖푖 0.000005푑푑푚푚 for 13.56 MHz 46. 67 + 9.542425 + 0 - 104.77 = - 48.55dBm 푃푃(푑푑푑푑푑푑)= − 48.55 푤푤ℎ푖푖푖푖ℎ 푖푖푖푖 0.000014푑푑푚푚 for 125kHz Combined Power is 0.000019mW and is far less than 1mW and is exempt from the RF Exposure at any distance.

PRT6/5 & KPT6/5 Approved antennas list: Manufacturer Antenna Description Type Ω Connector Type Notes Deister Electronics. Wire Coil Inductive Coil tuned to 125 KHz Inductive Coil 50 Integral 1 Deister Electronics Patch Coil Inductive Patch tuned to 13.56 MHz Patch 50 Integral 1 Notes: 1 Antenna was tested for compliance by F2P.

20200617 Report Number: F2P31157A-01E Page 1 of 36 Issue Date: 2024-08-13 F2 Labs 16740 Peters Road Middlefield, Ohio 44062 United States of America www.f2labs.com RADIO CERTIFICATION TEST REPORT Manufacturer: Deister Electronic GmbH 11 Hermann Bahlsen Str Barsinghausen D-30890 GERMANY Applicant: Deister Electronics USA, Inc. 8576 Wellington Road Manassas, Virginia 20109 USA Product Name: Deister Electronics Legic Reader Product Description: RFID Reader for reading contactless Legic & Prox credentials with output to physical access control systems in Wiegand or OSDP. Operating Voltage/Frequency: 12-24VDC Model(s): PRT6* *Denotes actual model tested as worst-case representative of product family that includes models PRT6 and KPT6. FCC ID: IXLPRT6KPT6 Testing Commenced: 2024-03-22 Testing Ended: 2024-03-28 Summary of Test Results: In Compliance The EUT complies with the EMC requirements when manufactured identically as the unit tested in this report, including any required modifications and/or manufacturer’s statement. Any changes to the design or build of this unit subsequent to this testing may deem it non-compliant. Standards:  FCC Part 15 Subpart C, Section 15.209  FCC Part 15 Subpart C, Section 15.215(c) – Additional provisions to the general radiated emission limitations  FCC Part 15 Subpart A, Section 15.31(e) – Measurement Standards  FCC15.207 - Conducted Limits Order No(s): F2P31157A Applicant: Deister Electronics USA, Inc. Model(s): PRT6 20200617 Report Number: F2P31157A-01E Page 2 of 36 Issue Date: 2024-08-13 Evaluation Conducted by: Julius Chiller, Senior Wireless Project Engineer Report Reviewed by: Ken Littell, Vice President of Operations F2 Labs F2 Labs F2 Labs 26501 Ridge Road 16740 Peters Road 8583 Zionsville Road Damascus, MD 20872 Middlefield, OH 44062 Indianapolis, IN 46268 Ph 301.253.4500 Ph 440.632.5541 Ph 317.610.0611 This test report may be reproduced in full; partial reproduction only may be made with the written consent of F2 Labs. The results in this report apply only to the equipment tested. Order No(s): F2P31157A Applicant: Deister Electronics USA, Inc. Model(s): PRT6 20200617 Report Number: F2P31157A-01E Page 3 of 36 Issue Date: 2024-08-13 TABLE OF CONTENTS 1 ADMINISTRATIVE INFORMATION 2 SUMMARY OF TEST RESULTS/MODIFICATIONS 3 TABLE OF MEASURED RESULTS 4 ENGINEERING STATEMENT 5 EUT INFORMATION AND DATA 6 LIST OF MEASUREMENT INSTRUMENTATION 7 OCCUPIED BANDWIDTH 8 FIELD STRENGTH OF EMISSIONS/RADIATED SPURIOUS EMISSIONS 9 VARIATION OF THE INPUT POWER 10 CONDUCTED EMISSIONS 11 TEST SETUP PHOTOGRAPH(S) Order No(s): F2P31157A Applicant: Deister Electronics USA, Inc. Model(s): PRT6 20200617 Report Number: F2P31157A-01E Page 4 of 36 Issue Date: 2024-08-13 1 ADMINISTRATIVE INFORMATION 1.1 Measurement Location: F2 Labs in Middlefield, Ohio. Site description and attenuation data are on file with the FCC's Sampling and Measurement Branch at the FCC Laboratory in Columbia, MD. 1.2 Measurement Procedure: All measurements were performed according to ANSI C63.10 and recommended FCC procedure of measurement of equipment operating under Section 15.209. A list of the measurement equipment can be found in Section 6. Order No(s): F2P31157A Applicant: Deister Electronics USA, Inc. Model(s): PRT6 20200617 Report Number: F2P31157A-01E Page 5 of 36 Issue Date: 2024-08-13 1.3 Uncertainty Budget: The uncertainty in EMC measurements arises from several factors which affect the results, some associated with environmental conditions in the measurement room, the test equipment being used, and the measurement techniques adopted. The measurement uncertainty budgets detailed below are calculated from the test and calibration data and are expressed with a 95% confidence factor using a coverage factor of k=2. The Uncertainty for a laboratory is referred to as Ulab. For Radiated and Conducted Emissions, the Expanded Uncertainty is compared to the Ucispr values to determine if a specific margin is required to deem compliance. Ulab Ucispr If Ulab is less than or equal to Ucispr, then: • compliance is deemed to occur if no measured disturbance exceeds the disturbance limit; • non-compliance is deemed to occur if any measured disturbance exceeds the disturbance limit. If Ulab is greater than Ucispr in table 1, then: • compliance is deemed to occur if no measured disturbance, increased by (Ulab – Ucispr), exceeds the disturbance limit; • non-compliance is deemed to occur if any measured disturbance, increased by (Ulab – Ucispr), exceeds the disturbance limit. Note: Only measurements listed in the tables above that relate to tests included in this Test Report are applicable. Measurement Range Combined Uncertainty Expanded Uncertainty Radiated Emissions <1 GHz @ 3m 2.54dB 5.07dB Radiated Emissions <1 GHz @ 10m 2.55dB 5.09dB Radiated Emissions 1 GHz to 2.7 GHz 1.81dB 3.62dB Radiated Emissions 2.7 GHz to 18 GHz 1.55dB 3.10dB AC Power Line Conducted Emissions, 150kHz to 30 MHz 1.38dB 2.76dB AC Power Line Conducted Emissions, 9kHz to 150kHz 1.66dB 3.32dB Measurement Range Expanded Uncertainty Radiated Emissions <1 GHz @ 3m 5.2dB Radiated Emissions <1 GHz @ 10m 5.2dB Radiated Emissions 1 GHz to 2.7 GHz Under Consideration Radiated Emissions 2.7 GHz to 18 GHz Under Consideration AC Power Line Conducted Emissions, 150kHz to 30 MHz 3.6dB AC Power Line Conducted Emissions, 9kHz to 150kHz 4.0dB Order No(s): F2P31157A Applicant: Deister Electronics USA, Inc. Model(s): PRT6 20200617 Report Number: F2P31157A-01E Page 6 of 36 Issue Date: 2024-08-13 1.4 Document History: Document Number Description Issue Date Approved By F2P31157A-01E First Issue 2024-08-13 K. Littell Order No(s): F2P31157A Applicant: Deister Electronics USA, Inc. Model(s): PRT6 20200617 Report Number: F2P31157A-01E Page 7 of 36 Issue Date: 2024-08-13 2 SUMMARY OF TEST RESULTS Test Name Standard(s) Results Occupied Bandwidth CFR 47 Part 15.215(c) Complies Field Strength of Emissions CFR 47 Part 15.209 Complies Radiated Spurious Emissions CFR 47 P…
