IXLRHXDoor Lock LF Read Head

Germany: deister electronic GmbH Hermann-Bahlsen-Str. 11 30890 Barsinghausen Tel.: +49 (0) 51 05 - 51 61 11 Fax: +49 (0) 51 05 - 51 62 17 [email protected] Benelux: deister electronic office Hendrik van Veldekesingel 150/56 OffiCenter 3500 Hasselt, Belgium Tel.: +32 (0) 15 – 48 02 15 Fax: +32 (0) 15 – 48 02 16 [email protected] Great Britain: deister electronic (UK) Ltd. Stapleton Way, Enterprise Park Spalding, Lincolnshire PE11 3YQ Tel.: +44 (0) 1775 - 717100 Fax: +44 (0) 1775 - 717101 [email protected] Japan: Deister Service Co., Ltd. Room 812, MG Meguro Ekimae Bld. 2-15-19 Kamiosaki, Shinagawa-ku Tokyo 141-0021, Japan phone +81 (0) 3 4540 1350 fax +81 (0) 3 4540 1000 [email protected] RHx 1 xx•RHx 2 xx Application notes Applikationshinweise Notes d'application V200302 #896401 France: deister electronic france 29, rue Jean Rostand Parc Club Orsay Université 91400 ORSAY Tel.: +33 (0) 1 47 – 35 78 78 Fax: +33 (0) 1 47 – 35 92 59 [email protected] Americas and Caribbean: deister electronics USA, Inc. 8576 Wellington Road Manassas, VA 20109 Tel.: +1 703 - 368 2739 Fax: +1 703 - 368 9791 [email protected] 1. Dimensions / Abmessungen (mm) RHx 1 xx RHx 2 xx 40 38 2. Technical Data Dimensions Ø x H: RHx 1 xx: 40 x 6 mm RHx 2 xx: 38 x 6 mm Housing Material: ASA Colour: black Protection class: IP54 / IP65 (optional) Operating Temperature: -20...+50 °C Relative Humidity: 5...95 %, non-condensing 2. Technische Daten Abmaße Ø x H: RHx 1 xx: 40 x 6 mm RHx 2 xx: 38 x 6 mm Gehäusematerial: ASA Farbe: schwarz Schutzart: IP54 / IP65 (optional) Betriebstemperatur: -20...+50 °C Relative Luftfeuchtigkeit: 5...95 %, nicht kondensierend 2. Caractéristiques techniques Dimensions Ø x H : RHx 1 xx : 40 x 6 mm RHx 2 xx : 38 x 6 mm Matériau du boitier : ASA Couleur : noir Indice de protection : IP54 / IP65 (en option) Température de fonctionnement : -20...+50 °C Humidité relative : 5...95 %, nicht kondensierend 3. FCC/IC This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Changes or modifications not expressly approved by Deister Electonics could void the user's authority to operate the equipment. This equipment has been tested and found to comply with the limits for o Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions„ may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: – Reorient or relocate the receiving antenna. – lncrease the separation between the equipment and receiver. – Connect the equipment into on outlet on o circuit different from thot to which the receiver is connected. – Consult the dealer or an experienced radio/TV technician for help. This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and Economic Development Canada ́s licence-exempt RSS(s). Operation is subject to the following two conditions: 1. This device may not cause interference. 2. This device must accept any interference; including interference that may cause undesired operation of the device. L'émetteur/récepteur exempt de licence contenu dans le présent appareil est conforme aux CNR d'innovation, Sciences et Développement économique Canada applicables aux appareils radio exempts de licence. L'exploitation est autorisée aux deux conditions suivantes : 1. L'appareil ne doit pas produire de brouillage; 2. L'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement 4. Warranty Note • Garantiehinweis • Remarque garantie Improper use of the device will void the warranty! • Bei nicht sachgemäßer Benutzung des Gerätes erlischt die Garantie! • L‘utilisation incorrecte de l‘appareil annule la garantie!

Deister Electronics USA, Inc. 9817 Godwin Drive #201 Manassas, VA 20110 Direct Line: +1-703-659-9497 Direct FAX: +1-415-762-1963 Email: [email protected] www.deister.com 30 April 2019 To Whom It May Concern: We hereby delegate CKC Certification Services, LLC (CKC CS) power of attorney to act on our behalf in matters pertaining to certification of products. The actions of CKC CS shall be considered the same as our own. Sincerely, William L Nuffer President Deister Electronics USA, Inc. 9817 Godwin Drive #201 Manassas, VA 20110 1.703.368.2739

Deister Electronics USA, Inc. 8576 Wellington Road Manassas, VA 20109 Direct Line: +1-703-659-9497 Direct FAX: +1-415-762-1963 Email: [email protected] www.deister.com 16 April 2020 Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Subject: Request for Permanent Confidentiality To whom it may concern: In accordance with 47CFR Section 0.457 and Section 0.459 pertaining to confidential material, we hereby request to hold permanently confidential all information contained within the below identified exhibits/document categories submitted pursuant to radio equipment certification requirements for FCC ID: IXLRHX 1. Block Diagram 2. Operational Description 3. Schematics 4. Parts List The above material contains trade secrets and proprietary information as specified by 47CFR 0.457(d) and technical data, which would customarily be guarded from competitors. The public disclosure of this information might be harmful to our company and provide unjustified benefits to our competitors. Sincerely, William L Nuffer President Deister Electronics USA, Inc. 8576 Wellington Road Manassas, VA 20109 1.703.368.2739

F2P23173 Page 1 of 3 Apr. 23, 2020 PHOTOGRAPHS: EXTERNAL Deister - Model RHX2 Order Number: F2P23173 Client: Deister Electronics USA, Inc. Model: RHX2 F2P23173 Page 2 of 3 Apr. 23, 2020 Order Number: F2P23173 Client: Deister Electronics USA, Inc. Model: RHX2 F2P23173 Page 3 of 3 Apr. 23, 2020

F2P23173 Page 1 of 5 June 25, 2020 PHOTOGRAPHS: INTERNAL Deister - Model RHX2 Order Number: F2P23173 Client: Deister Electronics USA, Inc. Model: RHX2 F2P23173 Page 2 of 5 June 25, 2020 Order Number: F2P23173 Client: Deister Electronics USA, Inc. Model: RHX2 F2P23173 Page 3 of 5 June 25, 2020 Order Number: F2P23173 Client: Deister Electronics USA, Inc. Model: RHX2 F2P23173 Page 4 of 5 June 25, 2020 Order Number: F2P23173 Client: Deister Electronics USA, Inc. Model: RHX2 F2P23173 Page 5 of 5 June 25, 2020

060818 Report Number: F2P23173-03E Page 1 of 23 Issue Date: July 7, 2020 F2 Labs 16740 Peters Road Middlefield, Ohio 44062 United States of America www.f2labs.com CERTIFICATION TEST REPORT Manufacturer: Deister Electronic GmbH 11 Hermann Bahlsen Str Barsinghausen 30890 GERMANY Applicant: Deister Electronics USA, Inc. 8576 Wellington Road Manassas, Virginia 20109 USA Product Name: RHX2 doorLoxx Read Head (Prox) Product Description: Digital Locking System Read Head. Reads common (920.8 MHz) Proximity Credentials and determines right of access. Operating Voltage/Frequency: Battery-Operated (3VDC) Model: RHX2 FCC ID: IXLRHX Testing Commenced: April 20, 2020 Testing Ended: July 6, 2020 Summary of Test Results: In Compliance The EUT complies with the EMC requirements when manufactured identically as the unit tested in this report, including any required modifications and/or manufacturer’s statement. Any changes to the design or build of this unit subsequent to this testing may deem it non-compliant. Standards:  FCC Part 15 Subpart C, Section 15.249  FCC Part 15 Subpart C, Section 15.215(c) – Additional provisions to the general radiated emission limitations  FCC Part 15 Subpart A, Section 15.31(e) – Measurement Standards Order Number: F2P23173 Applicant: Deister Electronics USA, Inc. Model: RHX2 060818 Report Number: F2P223173-03E Page 2 of 23 Issue Date: July 7, 2020 Evaluation Conducted by: Julius Chiller, EMC/Wireless Engineer Report Reviewed by: Ken Littell, Director of EMC & Wireless Operations F2 Labs F2 Labs F2 Labs 26501 Ridge Road 16740 Peters Road 8583 Zionsville Road Damascus, MD 20872 Middlefield, OH 44062 Indianapolis, IN 46268 Ph 301.253.4500 Ph 440.632.5541 Ph 317.610.0611 This test report may be reproduced in full; partial reproduction only may be made with the written consent of F2 Labs. The results in this report apply only to the equipment tested. Order Number: F2P23173 Applicant: Deister Electronics USA, Inc. Model: RHX2 060818 Report Number: F2P223173-03E Page 3 of 23 Issue Date: July 7, 2020 TABLE OF CONTENTS Section Title Page 1 ADMINISTRATIVE INFORMATION 4 2 SUMMARY OF TEST RESULTS/MODIFICATIONS 7 3 TABLE OF MEASURED RESULTS 8 4 ENGINEERING STATEMENT 9 5 EUT INFORMATION AND DATA 10 6 LIST OF MEASUREMENT INSTRUMENTATION 11 7 OCCUPIED BANDWIDTH 12 8 FIELD STRENGTH OF EMISSIONS/RADIATED SPURIOUS 14 9 PHOTOGRAPHS 22 Order Number: F2P23173 Applicant: Deister Electronics USA, Inc. Model: RHX2 060818 Report Number: F2P223173-03E Page 4 of 23 Issue Date: July 7, 2020 1 ADMINISTRATIVE INFORMATION 1.1 Measurement Location: F2 Labs in Middlefield, Ohio. Site description and attenuation data are on file with the FCC's Sampling and Measurement Branch at the FCC Laboratory in Columbia, MD. 1.2 Measurement Procedure: All measurements were performed according to the 2013 version of ANSI C63.10 and recommended FCC procedure of measurement for devices operating under Section 15.249. A list of the measurement equipment can be found in Section 6. Order Number: F2P23173 Applicant: Deister Electronics USA, Inc. Model: RHX2 060818 Report Number: F2P223173-03E Page 5 of 23 Issue Date: July 7, 2020 1.3 Uncertainty Budget: The uncertainty in EMC measurements arises from several factors which affect the results, some associated with environmental conditions in the measurement room, the test equipment being used, and the measurement techniques adopted. The measurement uncertainty budgets detailed below are calculated from the test and calibration data and are expressed with a 95% confidence factor using a coverage factor of k=2. The Uncertainty for a laboratory is referred to as Ulab. For Radiated and Conducted Emissions, the Expanded Uncertainty is compared to the Ucispr values to determine if a specific margin is required to deem compliance. Ulab Ucispr If Ulab is less than or equal to Ucispr, then:  compliance is deemed to occur if no measured disturbance exceeds the disturbance limit;  non-compliance is deemed to occur if any measured disturbance exceeds the disturbance limit. If Ulab is greater than Ucispr in table 1, then:  compliance is deemed to occur if no measured disturbance, increased by (Ulab – Ucispr), exceeds the disturbance limit;  non-compliance is deemed to occur if any measured disturbance, increased by (Ulab – Ucispr), exceeds the disturbance limit. Note: Only measurements listed in the tables above that relate to tests included in this Test Report are applicable. Measurement Range Combined Uncertainty Expanded Uncertainty Radiated Emissions <1 GHz @ 3m 2.54 5.07dB Radiated Emissions <1 GHz @ 10m 2.55 5.09dB Radiated Emissions 1 GHz to 2.7 GHz 1.81 3.62dB Radiated Emissions 2.7 GHz to 18 GHz 1.55 3.10dB AC Power Line Conducted Emissions, 150kHz to 30 MHz 1.38 2.76dB AC Power Line Conducted Emissions, 9kHz to 150kHz 1.66 3.32dB Measurement Range Expanded Uncertainty Radiated Emissions <1 GHz @ 3m 5.2dB Radiated Emissions <1 GHz @ 10m 5.2dB Radiated Emissions 1 GHz to 2.7 GHz Under Consideration Radiated Emissions 2.7 GHz to 18 GHz Under Consideration AC Power Line Conducted Emissions, 150kHz to 30 MHz 3.6dB AC Power Line Conducted Emissions, 9kHz to 150kHz 4.0dB Order Number: F2P23173 Applicant: Deister Electronics USA, Inc. Model: RHX2 060818 Report Number: F2P223173-03E Page 6 of 23 Issue Date: July 7, 2020 1.4 Document History: Document Number Description Issue Date Approved By F2P23173-03E First Issue July 7, 2020 K. Littell Order Number: F2P23173 Applicant: Deister Electronics USA, Inc. Model: RHX2 060818 Report Number: F2P223173-03E Page 7 of 23 Issue Date: July 7, 2020 2 SUMMARY OF TEST RESULTS Test Name Standard(s) Results -20dB Occupied Bandwidth CFR 47 Part 15.215(c) Complies Field Strength of Emissions CFR 47 Part 15.249(a)(d) Complies Conducted Emissions CFR 47 Part 15.207(a) N/A Variation of the Input Power CFR 47 Part 15.231(e) Complies* *Requirements of 15.31(e) were met by using new batteries. Modifications Made to the Equipment None Order Number: F2P23173…
