JNF-BRC-CR90BT WIRELESS COMMUNICATION CRADLE

Advanced Handheld High‐Speed Laser Scanner 1 Wireless Handheld Gun Type Scanner i USER’S MANUAL Revision History Changes to the original manual are listed below: Version Date Description of Version 1.0 August. 24, 2011 Initial release Wireless Handheld Gun Type Scanner ii USER’S MANUAL Important Notice No warranty of any kind is made in regard to this material, including, but not limited to, implied warranties of merchantability or fitness for any particular purpose. We are not liable for any errors contained herein nor for incidental or consequential damages in connection with furnishing, performance or use of this material. We shall be under no liability in respect of any defect arising from fair wear and tear, willful damage, negligence, abnormal working conditions, failure to follow the instructions and warnings, or misuse or alteration or repair of the products without written approval. No part of this document may be reproduced, transmitted, stored in a retrieval system, transcribed, or translated into any human or computer or other language in any form or by any means electronic, mechanical, magnetic, optical, chemical, biological, manual or otherwise, except for brief passages which may be quoted for purposes of scholastic or literary review, without express written consent and authorization. We reserve the right to make changes in product design without reservation and without notification. The material in this guide is for information only and is subject to change without notice. All trademarks mentioned herein, registered or otherwise, are the properties of their various, ill, assorted owners. General Handling Precautions Do not dispose the scanner in fire. Do not put the scanner directly in the sun or by any heat source. Do not use or store the scanner in a very humid place. Do not drop the scanner or allow it to collide violently with other objects. Do not take the scanner apart without authorization Guidance for Printing This manual is in A5 size. Please double check your printer setting before printing it out. When the barcodes are to be printed out for programming, the use of a high‐resolution laser printer is strongly suggested for the best scan result. Copyright © 2011. All rights reserved. Wireless Handheld Gun Type Scanner iii USER’S MANUAL Radio Notice This equipment generates uses and can radiate radio frequency energy. If not installed and used in accordance with the instructions in this manual, it may cause interference to radio communications. The equipment has been tested and found to comply with the limits for a Class A computing device pursuant to EN55022 and 47 CFR, Part 2 and Part 15 of the FCC rules. These specifications are designed to provide reasonable protection against interference when operated in a commercial environment. Radio and Television Interference Operation of this equipment in a residential area can cause interference to radio or television reception. This can be determined by turning the equipment off and on. The user is encouraged to try to correct the interference by one or more of the following measures: ‐ Reorient the receiving antenna. ‐ Relocate the device with respect to the receiver. ‐ Move the device away from the receiver. ‐ Plug the device into a different outlet so that the device and the receiver are on different branch circuits. If necessary the user may consult the manufacturer, and authorized dealer, or experienced radio/television technician for additional suggestions. The user may find the following booklet prepared by the Federal Communications Commission helpful: “How to Identify and Resolve Radio‐TV Interference Problems.” This booklet is available from the U.S. Government Printing Office, Washington, DC 20402 U.S.A., Stock No. 004000003454. Laser Safety This equipment generates, uses, and can radiate radio frequency energy. If not installed and used in accordance with the instructions in this manual, it may cause interference to radio communications. The equipment has been tested and found to comply with the limits for a Class A computing device pursuant to EN55022 and 47 CFR, Part 2 and Part 15 of FCC Rules. These specifications are designed to provide reasonable protection against interference when operated in a commercial environment. Radiant Energy: The laser scanner uses one low‐power visible laser diodes operating at 650nm in an opto‐mechanical scanner resulting in less than 3.9μW radiated power as observed through a 7mm aperture and averaged over 10 seconds. Do not attempt to remove the protective housing of the scanner, as unscanned laser light with a peak output up to 0.8mW would be accessible inside. Wireless Handheld Gun Type Scanner iv USER’S MANUAL Laser Light Viewing: The scan window is the only aperture through which laser light may be observed from this product. A failure of the scanner engine, while the laser diode continues to emit a laser beam, may cause emission levels to exceed those for safe operation. The scanner has safeguards to prevent this occurrence. If, however, a stationary laser beam is emitted, the failing scanner should be disconnected from its power source immediately. Adjustments: Do not attempt any adjustments or alteration of this product. Do not remove the protective housing of the scanner. There are no user‐serviceable parts inside. Optical: The use of optical instruments with this product will increase the eye hazard. Optical instruments include binoculars, magnifying glasses, and microscopes but do not include normal eye glasses worn by the user. CAUTION: Use of controls or adjustments or performance of procedures other than those specified herein may result in hazardous radiation exposure. For CE‐Countries This scanner is in conformity with CE standards. Please note that an approved, CE‐marked power supply unit should be used in order to maintain CE conformance. Power Supply  Use only the type of battery and the charging equipments that came with your scanner.  Using any othe…

Text truncated - open the document above for the full version.

ZEBEX INDUSTRIES INC. B1-1, No. 207, Sec. 3, Beisin Road, Sindian-Tien City 231, Taiwan. Bluetooth Declaration Per FCC 15.247 Requirements 1 Output power and channel separation of a Bluetooth device in the different operating modes: The different operating modes (data-mode, acquisition-mode) of a Bluetooth device don’t influence the output power and the channel spacing. There is only one transmitter which is driven by identical input parameters concerning these two parameters. Only a different hopping sequence will be used. For this reason the check of these RF parameters in one op-mode is sufficient. 2 Frequency range of a Bluetooth device: Hereby we declare that the maximum frequency of this device is: 2402 – 2480 MHz. This is according the Bluetooth Core Specification (+ critical errata) for devices which will be operated in the USA. This was checked during the Bluetooth Qualification tests (Test Case: TRM/CA/04-E). Other frequency ranges ( e.g. for Spain, France, Japan) which are allowed according the Core Specification are not supported by this device. 3 Co-ordination of the hopping sequence in data mode to avoid simultaneous occupancy by multiple transmitters: Bluetooth units which want to communicate with other units must be organized in a structure called piconet. This piconet consist of max. 8 Bluetooth units. One unit is the master the other seven are the slaves. The master co-ordinates frequency occupation in this piconet for all units. As the master hop sequence is derived from it’s BD address which is unique for every Bluetooth device, additional masters intending to establish new piconets will always use different hop sequences. 4 Example of a hopping sequence in data mode: Example of a 79 hopping sequence in data mode: 40, 21, 44, 23, 42, 53, 46, 55, 48, 33, 52, 35, 50, 65, 54, 67, 56, 37, 60, 39, 58, 69, 62, 71, 64, 25, 68, 27, 66, 57, 70, 59, 72, 29, 76, 31, 74, 61, 78, 63, 01, 41, 05, 43, 03, 73, 07, 75, 09, 45, 13, 47, 11, 77, 15, 00, 64, 49, 66, 53, 68, 02, 70, 06, 01, 51, 03, 55, 05, 04 5 Equally average use of frequencies in data mode and behaviour for short transmissions: The generation of the hopping sequence in connection mode depends essentially on two input values: 1. LAP/UAP of the master of the connection 2. Internal master clock The LAP (lower address part) are the 24 LSB’s of the 48 BD_ADDRESS. The BD_ADDRESS is an unambiguous number of every Bluetooth unit. The UAP (upper address part) are the 24 MSB’s of the 48 BD_ADDRESS. The internal clock of a Bluetooth unit is derived from a free running clock which is never adjusted and is never turned off. For synchronisation with other units only offset are used. It has no relation to the time of the day. Its resolution is at least half the RX/TX slot length of 312.5 μs. The clock has a cycle of about one day (23h30). In most case it is implemented as 28 bit counter. For the deriving of the hopping sequence the entire LAP (24 bits), 4 LSB’s (4 bits) (Input 1) and the 27 MSB’s of the clock (Input 2) are used. With this input values different mathematical procedures (permutations, additions, XOR-operations) are performed to generate the sequence. This will be done at the beginning of every new transmission. Regarding short transmissions the Bluetooth system has the following behaviors: The first connection between the two devices is established, a hopping sequence was generated. For transmitting the wanted data the complete hopping sequence was not used. The connection ended. The second connection will be established. A new hopping sequence is generated. Due to the fact that the Bluetooth clock has a different value, because the period between the two transmission is longer (and it cannot be shorter) than the minimum resolution of the clock (312.5 μs). The hopping sequence will always differ from the first one. 6 Receiver input bandwidth and behaviors for repeated single or multiple packets: The input bandwidth of the receiver is 1 MHz. In every connection one Bluetooth device is the master and the other one is the slave. The master determines the hopping sequence (see chapter 5). The slave follows this sequence. Both devices shift between RX and TX time slot according to the clock of the master. Additionally the type of connection (e.g. single or multislot packet) is set up at the beginning of the connection. The master adapts its hopping frequency and its TX/RX timing according to the packet type of the connection. Also the slave of the connection will use these settings. Repeating of a packet has no influence on the hopping sequence. The hopping sequence generated by the master of the connection will be followed in any case. That means, a repeated packet will not be send on the same frequency, it is send on the next frequency of the hopping sequence. 7 Dwell time in data mode The dwell time of 0.3797s within a 30 second period in data mode is independent from the packet type (packet length). The calculation for a 30 second period is a follows: Dwell time = time slot length * hop rate / number of hopping channels *30s Example for a DH1 packet (with a maximum length of one time slot) Dwell time = 625 μs * 1600 1/s / 79 * 30s = 0.3797s (in a 30s period) For multislot packet the hopping is reduced according to the length of the packet. Example for a DH5 packet (with a maximum length of five time slots) Dwell time = 5 * 625 μs * 1600 * 1/5 *1/s / 79 * 30s = 0.3797s (in a 30s period) This is according the Bluetooth Core Specification V 1.0B (+ critical errata) for all Bluetooth devices. There for all Bluetooth devices comply with the FCC dwell time requirement in data mode. This was checked during the Bluetooth Qualification tests. The Dwell time in hybrid mode is measured and stated in the test report. 8 Channel Separation in hybrid mode The nominal channel spacing of the Bluetooth system is 1Mhz independent of the operating mode. The maximum “initial carrier frequency tolerance” which is allowed for Bluetooth is fcent…

Text truncated - open the document above for the full version.

ZEBEX INDUSTRIES INC. B1-1, No. 207, Sec. 3, Beisin Road, Sindian-Tien City 231, Taiwan. Date:November 11, 2011 Federal Communications Commission Authorization and Evaluation Division FCC IDJNF-BRC-CR90 Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the applicant hereby requests confidential treatment of information applied this application as outlined below: 1. Block Diagram 2. Schematics 3. Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application Sincerely, _____________ Name/Title:Sherry Lin/ CEO Company Name: ZEBEX INDUSTRIES INC. Address: B1-1, No. 207, Sec. 3, Beisin Road, Sindian-Tien City 231, Taiwan. TEL: 8913-2598 FAX: 8913-2596 Email:[email protected]

ZEBEX INDUSTRIES INC. B1-1, No. 207, Sec. 3, Beisin Road, Sindian-Tien City 231, Taiwan. Date:November 11, 2011 Dear Sir, I hereby have entrusted the following person to be a proxy regarding application for Type Certification. Compliance Certification Services Inc. Address: No.11, Wu-Gong 6 th Rd., Wugu Industrial Park, New Taipei City 248, Taiwan(R.O.C.) Mr. Jason Lin Job Title: Section Manager Email: [email protected] I am therefore responsible for the contents of the application. Brand Name and Model Name of the specified radio equipment: ZEBEX / CR-90 FCC ID: JNF-BRC-CR90 Product Name: BT wireless communication cradle _________________ Name/Title:Sherry Lin/ CEO Company Name: ZEBEX INDUSTRIES INC. Address: B1-1, No. 207, Sec. 3, Beisin Road, Sindian-Tien City 231, Taiwan. TEL: 8913-2598 FAX: 8913-2596 Email:[email protected]

Compliance Certification Services Inc. Report No.: T110928209 Date of Issue: October 25, 2011 A1 - 1 / 12 APPENDIX 1 - PHOTOGRAPHS OF EUT EXTERNAL PHOTOGRAPHS OF EUT Compliance Certification Services Inc. Report No.: T110928209 Date of Issue: October 25, 2011 A1 - 2 / 12 Compliance Certification Services Inc. Report No.: T110928209 Date of Issue: October 25, 2011 A1 - 3 / 12 Compliance Certification Services Inc. Report No.: T110928209 Date of Issue: October 25, 2011 A1 - 4 Compliance Certification Services Inc. Report No.: T110928209 Date of Issue: October 25, 2011 A1 - 5 Compliance Certification Services Inc. Report No.: T110928209 Date of Issue: October 25, 2011 A1 - 6 Compliance Certification Services Inc. Report No.: T110928209 Date of Issue: October 25, 2011 A1 - 7 Compliance Certification Services Inc. Report No.: T110928209 Date of Issue: October 25, 2011 A1 - 8 Compliance Certification Services Inc. Report No.: T110928209 Date of Issue: October 25, 2011 A1 - 9

Compliance Certification Services Inc. Report No.: T110928209 Date of Issue: October 25, 2011 A1 - 10 INTERNAL PHOTOGRAPHS OF EUT Compliance Certification Services Inc. Report No.: T110928209 Date of Issue: October 25, 2011 A1 - 11 Compliance Certification Services Inc. Report No.: T110928209 Date of Issue: October 25, 2011 A1 - 12

Walsin Technology Corporation Introduction of RFANT7635110A1T June. 2005



                                                              L L T T C C C C M M u u l l t t i i L L a a y y e e r r C C h h i i p p A A n n t t e e n n n n a a – – B B r r o o a a d d B B a a n n d d T T y y p p e e F F o o r r I I S S M M B B a a n n d d 2 2 . . 4 4 G G H H z z A A p p p p l l i i c c a a t t i i o o n n




Surface Mounted Devices with a small dimension of 7.6 x 3.5 x 1.1 mm 3 future meet miniaturization trend.
380MHz broad bandwidth design makes less influence, less frequency shifting due to outside environmental deviation, enlarge your manufacturing process window.
Embedded and LTCC (Low Temperature Co-fired Ceramic) technology is able to future integrate with system design as well as beautifying the housing of final product.
High Stability in Temperature / Humidity Change
 Suitable for ISM band 2.4 GHz Working Frequency Operation



Item Specification Central frequency 2.450 GHz (*Note 1) Bandwidth 380 MHz (Typical value) Gain 0 ~ 2 dBi VSWR 2 max. Polarization Linear Azimuth Beamwidth Omni-directional Impedance 50W *Note 1. Central Frequency should be defined after customers’ application approval.





Bluetooth
Wireless LAN
HormRF
ISM band 2.4GHz applications.



   Outline of 2.4GHz Chip Antenna



   Symbol Dimension Port Definition L 7.60 ± 0.30 mm - W 3.50 ± 0.20 mm - T 1.10 ± 0.10 mm - F 0.50 ± 0.20 mm Feed termination G 0.80 ± 0.20 mm Ground termination C 0.50 ± 0.20 mm D 0.50 ± 0.20 mm P1 0.80 ± 0.20 mm Solder termination P2 0.80 ± 0.20 mm Solder termination P3 0.50 ± 0.10 mm Solder termination Patent Pending Walsin Technology Corporation Introduction of RFANT7635110A1T June. 2005


  Symbol Dimension L 8.10 ± 0.10 mm Lp 1.00 ± 0.10 mm Wp 1.20 ± 0.10 mm Lf 1.50 ± 0.10 mm Wf 0.80 ± 0.10 mm Lg 1.50 ± 0.10 mm Wg 1.50 ± 0.10 mm   Upon customer requested, max. 5-digit code is allowed.

Radiation Pattern and Gain were dependent on measurement board design. Walsin’s LTCC chip antenna is an electrically small antenna (size smaller than 1/10 l ). The specification of RFANT7635110A1T series chip antenna was measured based on the PCB size and installation position as shown in the figure at table-1. Test Board-2 Return Loss (S11)


 50 W


 50 W    E-Plane H-Plane The typical tuning range of Walsin’s chip antenna is about ±150MHz. The performance of embedded ceramic antenna is sensitive influenced by customer's ground area, PC board size, thickness, material, mechanical design and the material of housing for end product, actually, we need customer below information so that we could provide optimal layout design services for the customer’s antenna installation reference: 1. Dimension of PC board includes thickness and material. 2. The dimension of area where will be reserved for antenna mounting. (Please note, this area should not have ground on the back-side) 3. Grounding size dimension 4. Mechanism design, included housing 5. Housing material 6. Any metal shielding existed on PCB or mechanism. WTC engineers have significant expertise on embedded antenna designs and applications. We can work closely with you to ensure the requirements are met, and optimise the WTC’s antenna performance when installing on your application. CONTACT INFORMATION For more information, please contact with Walsin Technology Corporation. Tel : 886-3-475-8711 Fax : 886-3-475-5197 E mail : [email protected] Web Site : http://www.passivecomponent.com Specification subject to change without prior notice.

Compliance Certification Services Inc. FCC ID: JNF-BRC-CR90 Report No.: T110928209-RP1 Note: This report shall not be reproduced except in full, without the written approval of Compliance Certification Services Inc. This document may be altered or revised by Compliance Certification Services Inc. personnel only, and shall be noted in the revision section of the document. Page 1 / 69 FCC 47 CFR PART 15 SUBPART C TEST REPORT For BT wireless communication cradle Model: CR-90 Trade Name: ZEBEX Issued to ZEBEX INDUSTRIES INC. B1F.-1, No. 207, Sec. 3, Beixin Rd, Xindian Dist, New Taipei City 23143, Taiwan Issued by Compliance Certification Services Inc. No.11, Wu-Gong 6th Rd., Wugu Industrial Park, New Taipei City 248, Taiwan (R.O.C.) http://www.ccsrf.com [email protected] Issued Date: October 24, 2011 Compliance Certification Services Inc. FCC ID: JNF-BRC-CR90 Report No.: T110928209-RP1 Page 2 Revision History Rev. Issue Date Revisions Effect Page Revised By 00 October 24, 2011 Initial Issue ALL Jessica Ho Compliance Certification Services Inc. FCC ID: JNF-BRC-CR90 Report No.: T110928209-RP1 Page 3 TABLE OF CONTENTS 1. TEST RESULT CERTIFICATION.................................................................................................4 2. EUT DESCRIPTION ........................................................................................................................5 3. TEST METHODOLOGY .................................................................................................................6 3.1 EUT CONFIGURATION.....................................................................................................................6 3.2 EUT EXERCISE.................................................................................................................................6 3.3 GENERAL TEST PROCEDURES..........................................................................................................6 3.4 FCC PART 15.205 RESTRICTED BANDS OF OPERATIONS......................................................7 3.5 DESCRIPTION OF TEST MODES........................................................................................................8 4. INSTRUMENT CALIBRATION.....................................................................................................9 4.1 MEASURING INSTRUMENT CALIBRATION...................................................................................9 4.2 MEASUREMENT EQUIPMENT USED ......................................................................................9 4.3 MEASUREMENT UNCERTAINTY ..........................................................................................10 5. FACILITIES AND ACCREDITATIONS .....................................................................................11 5.1 FACILITIES ....................................................................................................................................11 5.2 EQUIPMENT...................................................................................................................................11 5.3 TABLE OF ACCREDITATIONS AND LISTINGS..................................................................................12 6. SETUP OF EQUIPMENT UNDER TEST ....................................................................................13 6.1 SETUP CONFIGURATION OF EUT....................................................................................................13 6.2 SUPPORT EQUIPMENT ............................................................................................................13 7. FCC PART 15.247 REQUIREMENTS..........................................................................................14 7.1 20 DB BANDWIDTH..................................................................................................................14 7.2 PEAK POWER.................................................................................................................................21 7.3 A VERAGE POWER.........................................................................................................................23 7.4 BAND EDGES MEASUREMENT .............................................................................................23 7.5 FREQUENCY SEPARATION ....................................................................................................32 7.6 NUMBER OF HOPPING FREQUENCY....................................................................................38 7.7 TIME OF OCCUPANCY (DWELL TIME) ................................................................................43 7.8 SPURIO US EMISSIONS .............................................................................................................52 7.9 POWERLINE CONDUCTED EMISSIONS............................................................................................63 APPENDIX I RADIO FREQUENCY EXPOSURE ............................................................................66 APPENDIX II PHOTOGRAPHS OF TEST SETUP ..........................................................................67 APPENDIX 1 - PHOTOGRAPHS OF EUT Compliance Certification Services Inc. FCC ID: JNF-BRC-CR90 Report No.: T110928209-RP1 Page 4 1. TEST RESULT CERTIFICATION Applicant: ZEBEX INDUSTRIES INC. B1F.-1, No. 207, Sec. 3, Beixin Rd, Xindian Dist, New Taipei City 23143, Taiwan Equipment Under Test: BT wireless communication cradle Tr a d e N a m e : ZEBEX Model: CR-90 Date of Test: September 28 ~ October 10, 2011 APPLICABLE STANDARDS STANDARD TEST RESULT FCC 47 CFR Part 15 Subpart C No non-compliance noted We hereby certify that: The above equipment was tested by Compliance Certification Services Inc. The test data, data evaluation, test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.4: 2003 and the energy emitted by the sample EUT tested as described in this report is in complian…
