K9R900042Pipe location system

FCC ID:K9R900042 FCC Information for MOLE MAP The MOLE MAP IV receiver has been certified under FCC rules, part 15, and requires no licensing. Note: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense. A shielded serial cable must be used in order maintain compliance to the FCC rules Changes or modifications not expressly approved by Chori America or an authorized representative could void the user's authority to operate the equipment. The MOLE MAP IV is authorized for use only with the standard antenna.

FCC ID: K9R900042

FCC ID: K9R900042 Front View of EUT Rear view of EUT

FCC ID XXXXXXXX This device complies with part 14 of the FCC Rules. Operation is subject to the following two conditions:(1) This decice may not cuse harmful interference,and (2) This device must accept any interference received, including interference that may causeundesired operation. FCC ID K9R90042 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, (2) This device must accept any interference received, includinginterference that may cause undesired operation. Front View Side View MOLEMAP IV REMOTE GUIDANCE SYSTEM MoleMap Remote Guidance Unit showing FCC Label placement location

FCC ID: K9R900042 EUT Back Cover removed EUT Boards partially disassembled Processor Board. The receiver is inside the gold box. The processor board is not fully scanned as it does not contain any RF circuitry Receiver Board: Component side Receiver Board: Foil side

Page 1 of 1 FCC ID: K9R900041 Product Description 1.1 Product Description The EUT is an 18 mW UHF transmitter and is battery powered. The transmitter is a frequency modulated device operating at one of two fixed frequencies. The transmitter operates at 469.500 and 469.550 MHz. The necessary bandwidth of the transmitted signal is 18 kHz. The emission designator is 18K0F2D. The EUT is a part of a pipe locating system. The transmitter receives data from a sensor that acts a pipe locator and sends data to a remote monitor. The sensor is a Model Number MPL-H5E sensor. The sensor receives a signal at 38 kHz. The remote monitor has a UHF receiver. The transmitter cannot send voice transmissions. The RF amplifier finals are supplied with 4.6 VDC and draw a current of 11 milliamperes under normal operation. The EUT will only be used for data transmission. The EUT uses only frequency modulation. The transmission is a single channel containing quantized information using a modulating subcarrier of 1.28 kHz. The data is encoded into the modulation signal as binary steps from 1.28 to 2.1 kHz with a peak to peak voltage of 1.4 Volts. The deviation is proportional to modulation signal amplitude. It sends only data transmissions. Therefore according to FCC part 2.201, the emissions designator is F2D. There are no provisions for any external or alternate modulating sources. The 18 kHz authorized bandwidth specified is larger than necessary bandwidth. The maximum modulation frequency (M) measured is 2.1 kHz. The peak deviation (D) measured is 2.5 kHz. The manufacturer allowable signal distortion is 10 per cent. Therefore K is equal to 1.1. The necessary bandwidth is 2M+2DK or 9.7 kHz. <Insert Product Description>

Page 1 of 1 FCC ID: K9R900042 Product Description 1.1 Product Description The Mole Map IV is a part of a pipe locating system. The Mole Map IV This unit is a UHF receiver to be used as a remote monitoring system for a pipe locating system. The Mole Map IV receives data transmission only. The Mole Map IV is battery powered and operates at 464.500, 464.550, 469.500 and 469.550 MHz. The pipe locator operates at 38 kHz is under FCC rules for intentional radiators. It is subject to the FCC requirements pursuant to the Verification equipment authorization under Part 15.213.

Radiometrics Midwest Corporation Test Document RP-4082 Issue Date: 10/19/99 This report concerns: Original grant Equipment type: UHF Receiver Tests Performed ForTest Facility Chori America, Inc. One Penn Plaza Suite 5440 New York, NY 10119-5498 Radiometrics Midwest Corporation 12 East Devonwood Romeoville, IL 60446 Phone: (815) 293-0772 FAX: (815) 293-0820 [email protected] Test Report Written ByTest Report Approved By Joseph Strzelecki Senior EMC Engineer NARTE EMC-000877-NE Chris W. Carlson Director of Engineering NARTE EMC-000921-NE MEASUREMENT/TECHNICAL REPORT Chori America, Inc. Model Mole Map IV FCC ID: K9R900042 APPLICATION FOR CERTIFICATION RF Emission Measurements Performed For Determination of Compliance with the US Code of Federal Regulations Title 47, Chapter I, FCC Part 15 As Required for Certification for Unintentional Radiators Tests Performed ForFCC IDRadiometrics Test DocumentPage Chori America, Inc. K9R900042RP-4082A2 of 9 Table of Contents 1.0 General Information ........................................................................................................... 3 1.1 Product Description ........................................................................................................3 1.2 Related Submittals .........................................................................................................3 1.3 Tested System Details.................................................................................................... 3 1.4 Test Methodology ...........................................................................................................3 1.5 Test Facility .................................................................................................................... 4 1.6 Test Equipment ..............................................................................................................4 2.0 System Test Configuration ................................................................................................ 4 2.1 Test System and Justification......................................................................................... 4 2.2 Operating Conditions of EUT.......................................................................................... 4 2.2.1 Test Frequencies...................................................................................................... 5 2.3 Special Accessories ....................................................................................................... 5 2.4 Equipment Modifications ................................................................................................ 5 Figure 2.1 Configuration of Tested System .......................................................................... 6 3.0 Radiated Emissions Data .................................................................................................. 7 3.1 Radiated Emissions Data ............................................................................................... 7 3.4 Radiated Emissions Summary ....................................................................................... 8 3.5 Field Strength Calculation .............................................................................................. 8 4.0 Conducted Emission Data ................................................................................................. 9 Notice: This report must not be reproduced (except in full) without the written approval of Radiometrics Midwest Corporation. Tests Performed ForFCC IDRadiometrics Test DocumentPage Chori America, Inc. K9R900042RP-4082A3 of 9 1.0 General Information 1.1 Product Description The Model Mole Map IV (referred to as the EUT in this report) is a remote display for a pipe location system. The product may be operated as a stand-alone unit or in conjunction with a PC to provide real time on-screen presentation of pipe location. Chori Corporation manufactures the EUT. 1.2 Related Submittals The associated Transmitter is operated under FCC rules for intentional radiators. It is subject to the FCC requirements pursuant to the Certification equipment authorization under Part 90.217 and is being currently submitted as FCC ID: K9R900042. 1.3 Tested System Details The FCC ID's for all equipment, plus descriptions of all cables used in the tested system which have grants, are: Model Number Serial NumberFCC ID Manufacturer & Description Cable Descriptions M/N: Mole Map IV (EUT) S/N: N/A K9R900041Chori Remote indicator DC Power (1m, US) Serial cables (1.8m, SH) M/N: P5/90 S/N: F825K4QUIN51DParagon Development Desktop Computer Power (1.8m, US) M/N: FKB4700 S/N: J8633249 C9SKB4700-2Paragon Development Key Board Integral Coiled (2 m) M/N: NX-1001 S/N: 510010542390 B6DZ150LStar Printer Power (1.8m, US) Parallel cable w/ Metal Shell (1.8m, SH) M/N: CJ4685 S/N: 00500993V A3L9QNCJ468Samsung VGA Monitor Video (1.8m, SH) Power (2.2m, US) Note: SH = Shielded; US = Unshielded; m = Cable Length in Meters, 1.4 Test Methodology The test procedures used are in accordance with the ANSI document C63.4-1992, (July 17, 1992) "Methods of Measurement of Radio Noise Emissions from Low-Voltage Electrical and Electronic Equipment in the Range of 9 kHz to 40 GHz". The specific procedures are described herein. Radiated testing was performed at an antenna to EUT distance of 3 meters. The antenna was raised and lowered from 1 to 4 meters. Tests Performed ForFCC IDRadiometrics Test DocumentPage Chori America, Inc. K9R900042RP-4082A4 of 9 1.5 Test Facility The open area test site used to collect the radiated data is located on 8625 Helmar Road in Newark, Illinois. The open field test site has a metal ground screen. Details of the site characteristics are on file with the FCC. Conducted emission measurements and preliminary radiated emission scans were performed in an Anechoic Chamber “A” at Radiometrics' Romeoville, Illinois EMI test lab. These sites have been fully described in a report and …
