KBCIX260MPIA555BTGoBook II

Getting Started Congratulations on your purchase of the Itronix GoBook II computer! Your new GoBook II features the most innovative advances in portable computing technology. It combines state-of-the-art ergonomics with a rugged, durable architecture to provide you with a notebook computer that is compact, powerful, rugged and easy to use. Designed for a wide range of business and personal productivity applications, the GoBook II is an ideal choice for use in applications that require durability and performance. For maximum expandability without compromising portability, the GoBook II has a USB interface and a PC card slot. The high capacity hard disk drive provides you with plenty of storage space for multimedia files and applications. The GoBook II features a standard 87-key Nitevue® keyboard (89-key international). The high-resolution 12.1-inch touch screen LCD panel provides clear and crisp viewing with the convenience of a touch screen. This online document, GoBook II Help, contains all the information you need to set up and use your new GoBook II. It describes all the features of the GoBook II in an easy-to-read yet thorough manner. For information on printing, navigating or otherwise using GoBook II Help see How to Use This Help System. Checklists GoBook II™ Help Page 1 of 74GoBook II Help 11/19/2003file://C:\Documents%20and%20Settings\harwoodm.ITRXNT1\Local%20Settings\Temp\~hh94AA.htm After opening the package, carefully inspect the contents. Contact your dealer if any items are missing or appear damaged. The shipping carton should contain the following: STANDARD The Itronix GoBook II computer Battery ADP-90AB or ADP-75FB AC adapter with power cord 12.1 inch XGA display Stylus Shoulder Strap GoBook II Quick Start Guide OPTIONS The following items are normally optional, but some vendors may include them in the standard package. Some items may not be available in some countries, or some vendors may choose not to carry all the items. Floppy disk drive CD-ROM drive CD-RW Drive DVD-ROM drive SVGA display Soft Handle Media Bay Li-Ion battery pack (3000 mAhr) Hard Disk Drive Heater LCD Heater CAUTION When purchasing any of the accessories listed above, purchase only those accessories that are approved for use with your computer. The above accessories are proprietary items. Your system vendor can obtain these approved accessories. If you use items that are not approved for use with this computer, you may cause your computer to malfunction, or to emit or receive electromagnetic radiation in excess of local regulations. For non-proprietary accessories such as PC Cards or printers, ensure that the accessory functions properly in your computer before making the purchase. Your system vendor may be able to recommend reliable brands and models. Page 2 of 74GoBook II Help 11/19/2003file://C:\Documents%20and%20Settings\harwoodm.ITRXNT1\Local%20Settings\Temp\~hh94AA.htm Features High Capacity Hard Disk Drive The computer has a high capacity hard disk drive, enabling you to install your favorite programs and store large multimedia files. Full Array of Ports and Connectors Your computer includes standard ports for connecting to peripherals such as USB devices and monitors. USB ports allow you to add many types of peripherals. Large SVGA or XGA LCD Your computer has a large, easy to view SVGA or XGA LCD panel. Built-in Microphone and Stereo Speakers The stereo speakers and internal microphone enable you to run a variety of multimedia applications. Function Keys Function keys allow you to suspend your computer, shut the LCDs off, and give you easy control of audio and your monitor. Where to Look For Information About Your Computer This Help System describes the key elements of your computer. New users can find a simple step-by- step orientation in this chapter. About Windows For more extensive information and help about Windows go to Help and Support, found on the Start Menu. Go to Start, Programs, Accessories to open , an online orientation of Windows XP. 72_0103_003 10 December 2002 © 2002 Itronix Corporation. All rights reserved. GoBook II™ Help Page 3 of 74GoBook II Help 11/19/2003file://C:\Documents%20and%20Settings\harwoodm.ITRXNT1\Local%20Settings\Temp\~hh94AA.htm Precautions You can use your computer under a wide range of environmental conditions. However, to ensure long use and continued high performance, consider the following factors when setting up your computer: Follow all warnings and instructions noted in this documentation and in the Windows Help and Support, found on the Start Menu. The first time you use your computer, we recommend that you carefully read the section on Power Management to familiarize yourself with some basic battery information and to ensure optimum performance There is danger of explosion if the battery is incorrectly replaced. Replace only with the same or equivalent type recommended by the manufacturer. Dispose of used batteries according to the manufacturer's instructions. Do not open the RAM door by yourself. Unplug the computer from the power outlet before cleaning. Use a damp cloth for cleaning. Do not use aerosols, solvents, or strong detergents Slots and openings in the computer case are for ventilation purposes. Do not block or cover these openings or the system could overheat On the bottom of the GoBook II, there is a label with information on the power requirements of this system. These requirements must be followed. If you are unsure of your local power supply, consult your dealer or local Power Company Do not step on or place anything on the power cord If you use the computer with an extension cord, ensure that the total ampere ratings of all the devices sharing the extension do not exceed the rating of the extension cord or the rating of the wall outlet Unless instructed, never push foreign objects into the computer through any of the slots or openings. Dangerous voltages are present, which could cau…

Text truncated - open the document above for the full version.

Identification GoBook II (IX260) Help December 2002 · Revision 003 Copyright Notice © Copyright 2002 Itronix Corporation. All rights reserved. No part of this document may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any other language or computer language in whole or in part, in any form or by any means, whether it be electronic, mechanical, magnetic, optical, manual, or otherwise, without the prior written consent of Itronix Corporation, South 801 Stevens Street, Spokane, Washington 99204. Disclaimer This document is printed in the U.S.A. Itronix Corporation reserves the right to revise the manual and make periodic changes to the content without a direct or inferred obligation to Itronix to notify any person of such revision or changes. Itronix Corporation does not assume responsibility for the use of this help manual, nor for any patent infringements or other rights or third parties who may use the manual. This document contains valuable trade secrets and proprietary information of Itronix Corporation. This product is available for purchase under the terms of the Itronix Hardware Purchase and Software License Agreement. Itronix hardware products may be reconditioned, or be manufactured from parts and components that may be new, used, rebuilt, or recycled and in some cases, the hardware product may not be new and may have been previously installed. In any event, Itronix warranty terms apply. Trademark and Patent Notice Itronix is a registered trademark of Itronix Corporation. GoBook II is a registered trademark of Itronix Corporation Microsoft, MS, Windows, and MS-DOS are registered trademarks of Microsoft Corporation. IBM is a trademark of International Business Machines Corporation. The following United States Patent Numbers apply to any unit which incorporates a DVD drive - 5,434,678; 5,589,945; 5,913,013; 6,151,444; and 6,208,805. Compliance Statements The GoBook II (IX260) computer may have installed, multiple radio's . Each radio may have an individual FCC identifier. Only the FCC identifier that is on the Itronix Label is Valid for this configuration. The GoBook II (IX260) computer has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help. The GoBook II (IX260) computer complies with Part 68 of the FCC Rules. On the bottom of this equipment is a label that contains, among other information, the FCC registration number and ringer equivalence number (REN) for this equipment. If requested, this information must be provided to the telephone company. GoBook II™ Help Legal Information Page 1 of 3Legal Information 11/19/2003mk:@MSITStore:C:\ix260manualmods\KBCIX260mpia555bt\gobookII.chm::/terms.htm The REN is used to determine the quantity of devices which may be connected to the telephone line. Excessive RENs on the telephone line may result in the devices not ringing in response to an incoming call. In most, but not all areas, the sum of the RENs should not exceed five (5.0). To be certain of the number of devices that may be connected to the line, as determined by the total RENs, contact the telephone company to determine the IIimum REN for the calling area. Changes or modifications not expressly approved by the party responsible for compliance could void the users authority to operate the equipment. The GoBook II (IX260) computer may be connected to the telephone network using the RJ-11 jack provided. If this equipment causes harm to the telephone network, the telephone company will notify you in advance that temporary discontinuance of service may be required. If advance notice isn’ t practical, the telephone company will notify the customer as soon as possible. Also, you will be advised of your right to file a complaint with the FCC if you believe it is necessary. The telephone company may make changes in its facilities, equipment, operations, or procedures that could affect the operation of the equipment. If this happens, the telephone company will provide advance notice in order for you to make the necessary modifications in order to maintain uninterrupted service. If trouble is experienced with this equipment, please contact the equipment manufacturer for repair and/or warranty information. Do not attempt repairs of this equipment yourself without obtaining manufacturer authorized parts and documentation. If the trouble is causing harm to the telephone network, the telephone company may request you remove the equipment from the network until the problem is resolved. Compliance Statement for Canada NOTICE The Industry Canada label identifies certified equipment. This certification means that the equipment meets certain telecommunications network protective, operational and safety requirements as prescribed in the appropriate Terminal Equipment Technical Requirements document(s). The Department does not guarantee the equipment will operate to the user’s satisfaction. Before installing this equipment, users should ensure that it is permissible to be connec…

Text truncated - open the document above for the full version.

Exhibit 13 EXHIBIT XIII - Cover Letters New Certification Report for the FCC ID: KBCIX260MPIA555BT Cover Letter 1.) Certification Action Requested Cover Letter 2.) Request for Confidentiality under Part 0.459. Cover Letter 3.) ITRONIX Agent Authorization letter allowing Rod Munro to sign FCC Form 731 on behalf of ITRONIX, Corp. Cover Letter 4.) ITRONIX to TCB cover letter regarding FCC labeling

American Telecommunications Certification Body Inc. 6731 Whittier Ave, McLean, VA 22101 December 7, 2003 RE: FCC ID: KBCIX260MPIA555BT Attention: Rod Munro I have a few comments on this Application. 1. Please note that the request for confidentiality states (Circuit Diagrams, ...., Procedure, Operational Description). Please verify if ‘Procedure” is speaking of the tune up procedures. 2. Please note that in the ‘ Certification Action Requested” exhibit you state that the certification requested is for collocated ‘portable’ transmitters. Please note that the application is for mobile use in the laptop. Please explain. 3. Please note that each FCC ID application must stand on its own and references to existing grants or products is not sufficient. As such, each application must contain all of the appropriate information (ATCB cannot search the FCC website to find associated data, this data is required to be in the filing). Please note that reports for part 15 devices must be in accordance with ANSI C63.4. As such for each test result a report must provide the following data at a minimum: a. Shall be clearly written, in unambiguous language (i.e. the test object must be clearly identified by model and serial number, etc). b. A complete list of all test equipment used shall be included with the test report. Manufacturer’s model and serial numbers, and date of last calibration and calibration interval, shall be included. c. Test procedures used are to be clearly identified in each test. Please note that the files ‘Exhibit 6 MPI350 PSD.pdf’ and ‘Exhibit 6 MPI350 Part 15.247-6db BW_Ant Cond Spur.pdf’, Exhibit 6 MPI350Band Edge.pdf do not clearly identify the device being tested, the procedures used nor do they provide information on the test equipment used (calibration dates, and equipment types, etc). Please clearly identify the device tested in these files (e.g. place the FCC ID number in the report, place the model and serial number of the device tested and place the test equipment information used in the report; alternately, place a cover page to the separate report addendums and place them in one file with the required ANSI C63.4 reporting information and explain why these files are relevant). 4. Please note that “Exhibit 6 Pt 15.247 MPI350 WLAN Test Report” states that for conducted power measurements the WLAN was tested in the “IX260 Rugged Laptop with Aircard 750 GPRS radio modem” but the actual device to be certified is with the Aircard 555. Please explain how this data is relevant to the device for which certification is being requested. Please provide the test date and the calibration date of the test equipment used. 5. From the plot on page 56 of the part 22/24 report (IX260MPIA555BT EMC Test Report Part 22-24 Rev1.pdf), it is unclear if the band edge at 849MHz is compliance. Please provide clear evidence that the device is compliant at this band edge. 6. The MPE calculations were apparently performed using the highest gain and no cable loss. However, as this has three transmitters were efforts done to project or estimated the MPE at various locations around the device to substantiate the calculated MPE? Dennis Ward mailto:[email protected] The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information may result in application termination. Correspondence should be considered part of the permanent submission and may be viewed from the Internet after a Grant of Equipment Authorization is issued. z Page 2 December 7, 2003 Please do not respond to this correspondence using the email reply button. In order for your response to be processed expeditiously, you must submit your documents through the AmericanTCB.com website. Also, please note that partial responses increase processing time and should not be submitted. Any questions about the content of this correspondence should be directed to the sender.

December 9, 2003 ATCB 6731 Whittier Ave., McLean, VA 22101 Attn: Dennis Ward [email protected] Re: FCC ID: KBCIX260MPIA555BT Reply to 12/7/03 comments, referenced by Item. Item 1The procedure referenced is in fact the tune up procedure. The word tune up was inadvertently left out. Item 2A new “Exhibit 13 Request for action, Confidentiality, Agent Authorization TCB label letter Rev1.pdf” is submitted to correct the mistake in the letter “Certification Action Requested” and replace the word “portable” with “mobile” as this application is intended for mobile use only in laptop. Item 3A new “Exhibit 6 Original Complete LDK102042 WLAN Test Report.pdf” is submitted. The individual excerpts previously submitted were from this report. I believe this complete report addresses the Part 15 report requirements in accordance with ANSI C63.4. The referenced FCC ID is physically and electrically identical as defined by Part 2.907 to the device installed in the IX260. The antenna conducted measurements made for the OEM contained in this original report should remain representative of this identical device when installed in the Model: IX260. New measurements were previously submitted in the supplemental test report to address the radiated emissions characteristics in the IX260 with a new antenna. Item 4A new “Exhibit 6 MPI350 WLAN.pdf” Test Report Rev1 is submitted with revisions to the report to replace the incorrect reference to Aircard 750 and replace with the correct Aircard 555. The test dates have been added to the report. The report table of contents has had a note added referring the reader to Exhibit 7 submitted with the original report. Exhibit 7 contains the Spectrum Technology , Inc., list of test equipment and the calibration dates as well as a block diagram of the radiated test setup and the EUT test setup photos. Item 5Celltech labs will respond directly to this item. Item 6On the second page of Exhibit 11 MPE we describe how we arrived at our worst case estimate of MPE. We did not estimate the MPE at multiple locations. The summed ratios of the power density for the three transmitters has reasonable margin below the limit so further projections were not made. We believe that we have addressed all of the concerns detailed in your 12/7/03 comments. We would be glad to provide any further information you find necessary to assist in your review of this application for Certification. Best Regards, Rod Munro [email protected]

© 2003 Celltech Labs Inc. ITRONIX CORPORATION FCC ID: KBCIX260MPIA555IBT (Model: IX260) Rugged Laptop PC with AirCard 555 CDMA Modem, WLAN, & Bluetooth Transmitters EXTERNAL EUT PHOTOGRAPHS © 2003 Celltech Labs Inc. ITRONIX CORPORATION FCC ID: KBCIX260MPIA555IBT (Model: IX260) Rugged Laptop PC with AirCard 555 CDMA Modem, WLAN, & Bluetooth Transmitters EXTERNAL EUT PHOTOGRAPHS © 2003 Celltech Labs Inc. ITRONIX CORPORATION FCC ID: KBCIX260MPIA555IBT (Model: IX260) Rugged Laptop PC with AirCard 555 CDMA Modem, WLAN, & Bluetooth Transmitters EXTERNAL EUT PHOTOGRAPHS © 2003 Celltech Labs Inc. ITRONIX CORPORATION FCC ID: KBCIX260MPIA555IBT (Model: IX260) Rugged Laptop PC with AirCard 555 CDMA Modem, WLAN, & Bluetooth Transmitters EXTERNAL EUT PHOTOGRAPHS with Vehicle Cradle & 3 dBi Gain Vehicle Antenna (MaxRad P/N: WMLPVDB800/1900) © 2003 Celltech Labs Inc. ITRONIX CORPORATION FCC ID: KBCIX260MPIA555IBT (Model: IX260) Rugged Laptop PC with AirCard 555 CDMA Modem, WLAN, & Bluetooth Transmitters EXTERNAL EUT PHOTOGRAPHS Vehicle Cradle

Applicant: ITRONIX, Corp. FCC ID: KBCIX260MPIA555BT Exhibit 1 LIST OF EXHIBITS DESCRIPTION EXHIBITS REFERENCE I.Identification label Information1 2.1033 (b) 7 & 2.925 & General Information1A 1. Production Plans2.1031 2. Application ReferencesN/A 3. Data submittal Procedure 4. Similar Certified Transmitter II.Certification Data2 III.External Photographs32.1033 (b) 7 IV.Block Diagrams (Circuit Diagrams) confidential42.1033 (b) 5 V. Schematic Diagrams & Antenna Assembly confidential52.1033 (b) 5 VI.VI.Supplemental Test Report WLAN Supplemental Test Report WLAN 62.1033 (b) 6 Part 15.247 – DTS, WLAN IX 260 EMC Test Report,Part 15.247 – DTS, WLAN IX 260 EMC Test Report, With previously Certified Intentional Radiator MPI350 SeriesWith previously Certified Intentional Radiator MPI350 Series CISCO System, Inc., FCC ID: LDK 102042CISCO System, Inc., FCC ID: LDK 102042 1) Conducted Output Power Section 15.247(b)1 2) EIRP limit Section 15.247(b)3 3) Spurious Emissions Section 15.247 (c) 4) 20 dB Bandwidh and Antenna Conducted Spur’s (submitted in a separate file) Note: We reference some of the original test report exhibits for items required by Part 15.247 (a, b, c, g, h) VI.VI. Test Report Bluetooth New CertificationTest Report Bluetooth New Certification62.1033 (b) 6 Part 15.247 – FHSS, EMC Test Report of the previouslyPart 15.247 – FHSS, EMC Test Report of the previously Certified Bluetooth Intentional Radiator, Model: WML-C11NU,Certified Bluetooth Intentional Radiator, Model: WML-C11NU, Mutsumi, Elec. Co., Ltd., FCC ID: POOWML-C11XXMutsumi, Elec. Co., Ltd., FCC ID: POOWML-C11XX Eleven Common Bluetooth Items6 Six tests required6 15.247 (a, b, c, g, h) 1) The Occupied Bandwidth Section 15.247(a)!ii 2) Conducted Output Power Section 15.247(b)1 3) EIRP limit Section 15.247(b)3 4) RF safety Section 15.247(b)4 see Exhibit XII 5) Spurious Emissions Section 15.247 (c) 6) Power Spectral Density in Acquistion Mode AC Power Conducted Emissions Measurements AC Power Conducted Emissions Measurements 6 15.107, 15.207 Co-located Simultaneous transmit of Bluetooth and WLAN transmitterCo-located Simultaneous transmit of Bluetooth and WLAN transmitter VII.Test Set-up Procedures72.1041 Applicant: ITRONIX, Corp. FCC ID: KBCIX260MPIA555BT Exhibit 1 VIII.Instruction Manual82.1033 (b) 3 IX.Internal Photographs92.1033 (b) 7 X.Part List and Tune Up Procedures102.1033 XI.MPE RF Exposure Information112.1093 & 15.247 (b)4 XII.Operational Descriptionconfidential122.1033 (b) 1, 2, 4, 8 Antenna Requirements1215.203 XIII. Cover Letter, Action Requested13 Cover Letter, Request For Confidentiality13 Cover Letter, Authorization to sign FCC Form 73113 Please NOTE: Exhibits 4, 5 and 12 are requested to held confidential EXHIBIT 1. FCC IDENTIFICATION LABELEXHIBIT 1. FCC IDENTIFICATION LABEL Required Under Section: 47 CFR 2.1033(c) 11 for the FCC ID:FCC ID: KBCIX260MPIA555BTKBCIX260MPIA555BT, is located on page following. Applicant: ITRONIX, Corp. FCC ID: KBCIX260MPIA555BT Exhibit 1 FCC ID label Location On Bottom of the PC FCC ID Label is the large label, with a silver background, located right of center, between the RAM and Battery covers IIII II II VV Part 15.19 labeling requirement and compliance statement, upper left black label

© 2003 Celltech Labs Inc. ITRONIX CORPORATION FCC ID: KBCIX260MPIA555IBT (Model: IX260) Rugged Laptop PC with AirCard 555 CDMA Modem, WLAN, & Bluetooth Transmitters INTERNAL EUT PHOTOGRAPHS Cradle Contact Board © 2003 Celltech Labs Inc. ITRONIX CORPORATION FCC ID: KBCIX260MPIA555IBT (Model: IX260) Rugged Laptop PC with AirCard 555 CDMA Modem, WLAN, & Bluetooth Transmitters INTERNAL EUT PHOTOGRAPHS Sierra Wireless AirCard 555 Dual-Band CDMA Modem Card © 2003 Celltech Labs Inc. ITRONIX CORPORATION FCC ID: KBCIX260MPIA555IBT (Model: IX260) Rugged Laptop PC with AirCard 555 CDMA Modem, WLAN, & Bluetooth Transmitters INTERNAL EUT PHOTOGRAPHS Sierra Wireless AirCard 555 Dual-Band CDMA Modem Card © 2003 Celltech Labs Inc. ITRONIX CORPORATION FCC ID: KBCIX260MPIA555IBT (Model: IX260) Rugged Laptop PC with AirCard 555 CDMA Modem, WLAN, & Bluetooth Transmitters INTERNAL EUT PHOTOGRAPHS Sierra Wireless AirCard 555 Dual-Band CDMA Modem Card 08/03/2001 file://H:\Rosetta\docs\Re g ulator y %20A pp rovals\FCC\Part%2024\ p hotos\Ima g e001-2.JPG INTERNAL EUT PHOTOGRAPHS 08/03/2001 file://H:\Rosetta\docs\Re g ulator y %20A pp rovals\FCC\Part%2024\ p hotos\Ima g e004-4. jpg INTERNAL EUT PHOTOGRAPHS 08/03/2001 file://H:\Rosetta\docs\Re g ulator y %20A pp rovals\FCC\Part%2024\ p hotos\Ima g e006-6. jpg INTERNAL EUT PHOTOGRAPHS 08/03/2001 file://H:\Rosetta\docs\Re g ulator y %20A pp rovals\FCC\Part%2024\ p hotos\Ima g e010. jpg INTERNAL EUT PHOTOGRAPHS © 2003 Celltech Labs Inc. ITRONIX CORPORATION FCC ID: KBCIX260MPIA555IBT (Model: IX260) Rugged Laptop PC with AirCard 555 CDMA Modem, WLAN, & Bluetooth Transmitters INTERNAL EUT PHOTOGRAPHS Co-located Mini-PCI DSSS WLAN Card (Cisco MPI-350) © 2003 Celltech Labs Inc. ITRONIX CORPORATION FCC ID: KBCIX260MPIA555IBT (Model: IX260) Rugged Laptop PC with AirCard 555 CDMA Modem, WLAN, & Bluetooth Transmitters INTERNAL EUT PHOTOGRAPHS Co-located Bluetooth Transmitter Bluetooth Transmitter Bluetooth Transmitter © 2003 Celltech Labs Inc. ITRONIX CORPORATION FCC ID: KBCIX260MPIA555IBT (Model: IX260) Rugged Laptop PC with AirCard 555 CDMA Modem, WLAN, & Bluetooth Transmitters Right Side WLAN Antenna Left Side Bluetooth Antenna INTERNAL EUT PHOTOGRAPHS Internal Antennas for Co-located Cisco MPI-350 Mini-PCI DSSS WLAN Card and Bluetooth Transmitter Distance at LCD back-side between dipole antenna feed/swivel-joint and WLAN and Bluetooth antennas © 2003 Celltech Labs Inc. ITRONIX CORPORATION FCC ID: KBCIX260MPIA555IBT (Model: IX260) Rugged Laptop PC with AirCard 555 CDMA Modem, WLAN, & Bluetooth Transmitters Distance at LCD back-side between dipole antenna feed/swivel-joint and Bluetooth left-side antenna INTERNAL EUT PHOTOGRAPHS Internal Antenna for Co-located Cisco MPI-350 Mini-PCI DSSS WLAN Card and Bluetooth Transmitter Distance at LCD back-side between dipole antenna feed/swivel-joint and WLAN right-side antenna © 2003 Celltech Labs Inc. ITRONIX CORPORATION FCC ID: KBCIX260MPIA555IBT (Model: IX260) Rugged Laptop PC with AirCard 555 CDMA Modem, WLAN, & Bluetooth Transmitters Back of LCD Display - Left-Side Antenna Back of LCD Display - Right-Side Antenna INTERNAL EUT PHOTOGRAPHS Internal Antenna for Co-located Cisco MPI-350 Mini-PCI DSSS WLAN Card and Bluetooth Transmitter © 2003 Celltech Labs Inc. ITRONIX CORPORATION FCC ID: KBCIX260MPIA555IBT (Model: IX260) Rugged Laptop PC with AirCard 555 CDMA Modem, WLAN, & Bluetooth Transmitters INTERNAL EUT PHOTOGRAPHS Co-located Cisco MPI-350 Mini-PCI DSSS WLAN Card © 2003 Celltech Labs Inc. ITRONIX CORPORATION FCC ID: KBCIX260MPIA555IBT (Model: IX260) Rugged Laptop PC with AirCard 555 CDMA Modem, WLAN, & Bluetooth Transmitters INTERNAL EUT PHOTOGRAPHS Co-located Bluetooth Transmitter

Applicant: ITRONIX, Corp.FCC ID: KBCIX260MPIA555BT Exhibit 11 1 EXHIBIT 11 - MPE CALCULATION DATA FCC ID: KBCIX260MPIA555BT Applicant: ITRONIX, Corp. Model: IX260 with three co-located transmitters listed below 1.) AIRCARD555 with IX260 blade antenna-supporting calculations on pages 3 & 4 Max Peak Average Tx Freq: 824.47 Power @ antenna terminal input: 24.6523.0 Tx Freq: 835.89 Power @ antenna terminal input: 24.3623.0 Tx Freq: 848.31 Power @ antenna terminal input: 24.4723.0 Antenna gain: –0.4 dB Tx Freq: 1851.25 Power @ antenna terminal input: 24.4223.0 Tx Freq: 1880.00 Power @ antenna terminal input: 24.4223.0 Tx Freq: 1908.75 Power @ antenna terminal input: 24.3523.0 Antenna Gain: -3.2 dBi 2.) MPI350 with Rangestar antenna PN 100929-supporting calculations on page 5 Tx Freq: 2412 MHz Max Peak Power @ antenna terminal input: 21.2 dBm Antenna Gain: 4.5 dBi 3.) Bluetooth with Rangestar antenna PN 100929-supporting calculations on page 6 Tx Freq: 2402 MHz Max Peak Power @ antenna terminal input: 14.46 dBm Antenna Gain: 4.5 dBi Multiple Frequency Exposure Requirements The MPE calculations are submitted for multiple frequency exposure criteria. The ratio of the field strength or power density to the applicable exposure limit at the exposure location was determined for each transmitter below and the sum of these ratios does not exceed the 1 mW/cm^2 limit for uncontrolled exposure / general population exposure limits detailed in CFR 47, Part 1.1310. Ratio 1Ratio 2Ratio 3Limit mW/cm^2 AIRCARD555/Cell CDMA MPI350Bluetooth<1.0 0.056/0.550.074/1.00.016/1<1.0 = .101= .074= .016<1.0 Sum = .191 (mW/cm^2)<1.0 Ratio 1Ratio 2Ratio 3Limit mW/cm^2 AIRCARD555/PCS CDMA MPI350Bluetooth<1.0 0.056/10.074/1.00.016/1<1.0 = .056= .074= .016<1.0 Sum = .146 (mW/cm^2)<1.0 S= power density P= power input to the antenna G= power gain of the antenna in the direction of 2 interest relative to an isotropic radiator R= distance to the center of radiation of the antenna Choose ENTER Occupational/Controlled General Population/Uncontrolled Tx Frequency: 824.47 (MHz) Maximum Peak Power at Antenna Input Terminal: 24.65 (dBm) Antenna gain (typical)+9dB for 8-element array: -0.10 (dBi) S=0.55 (mW/cm^2) P=291.7427 (mW) G=0.98 (numeric) R =6.42(cm) S (mw/cm^2) at 20cm 0.056657756 OET Bulletin 65, Edition 97-01 Prediction of MPE Limit 2 4R PG S   4 R PG S  == S= power density P= power input to the antenna G= power gain of the antenna in the direction of 2 interest relative to an isotropic radiator R= distance to the center of radiation of the antenna Choose ENTER Occupational/Controlled General Population/Uncontrolled Tx Frequency: 1880.00 (MHz) Maximum Peak Power at Antenna Input Terminal: 24.42 (dBm) Antenna gain (typical)+9dB for 8-element array: -3.20 (dBi) S=1.00 (mW/cm^2) P=276.6942 (mW) G=0.48 (numeric) R =3.25(cm) S (mw/cm^2) at 20cm 0.026318393 OET Bulletin 65, Edition 97-01 Prediction of MPE Limit 2 4R PG S   4 R PG S  == S= power density P= power input to the antenna G= power gain of the antenna in the direction of 2 interest relative to an isotropic radiator R= distance to the center of radiation of the antenna Choose ENTER Occupa…
