KBCIX260MPIA750BTLaptop computer with PCS, WLAN and Bluetooth

Getting Started Congratulations on your purchase of the Itronix GoBook II computer! Your new GoBook II features the most innovative advances in portable computing technology. It combines state-of-the-art ergonomics with a rugged, durable architecture to provide you with a notebook computer that is compact, powerful, rugged and easy to use. Designed for a wide range of business and personal productivity applications, the GoBook II is an ideal choice for use in applications that require durability and performance. For maximum expandability without compromising portability, the GoBook II has a USB interface and a PC card slot. The high capacity hard disk drive provides you with plenty of storage space for multimedia files and applications. The GoBook II features a standard 87-key Nitevue® keyboard (89-key international). The high-resolution 12.1-inch touch screen LCD panel provides clear and crisp viewing with the convenience of a touch screen. This online document, GoBook II Help, contains all the information you need to set up and use your new GoBook II. It describes all the features of the GoBook II in an easy-to-read yet thorough manner. For information on printing, navigating or otherwise using GoBook II Help see How to Use This Help System. Checklists GoBook II™ Help Page 1 of 74GoBook II Help 7/31/2003file://C:\Documents%20and%20Settings\harwoodm.ITRXNT1\Local%20Settings\Temp\~hh9A72.htm After opening the package, carefully inspect the contents. Contact your dealer if any items are missing or appear damaged. The shipping carton should contain the following: STANDARD The Itronix GoBook II computer Battery ADP-90AB or ADP-75FB AC adapter with power cord 12.1 inch XGA display Stylus Shoulder Strap GoBook II Quick Start Guide OPTIONS The following items are normally optional, but some vendors may include them in the standard package. Some items may not be available in some countries, or some vendors may choose not to carry all the items. Floppy disk drive CD-ROM drive CD-RW Drive DVD-ROM drive SVGA display Soft Handle Media Bay Li-Ion battery pack (3000 mAhr) Hard Disk Drive Heater LCD Heater CAUTION When purchasing any of the accessories listed above, purchase only those accessories that are approved for use with your computer. The above accessories are proprietary items. Your system vendor can obtain these approved accessories. If you use items that are not approved for use with this computer, you may cause your computer to malfunction, or to emit or receive electromagnetic radiation in excess of local regulations. For non-proprietary accessories such as PC Cards or printers, ensure that the accessory functions properly in your computer before making the purchase. Your system vendor may be able to recommend reliable brands and models. Page 2 of 74GoBook II Help 7/31/2003file://C:\Documents%20and%20Settings\harwoodm.ITRXNT1\Local%20Settings\Temp\~hh9A72.htm Features High Capacity Hard Disk Drive The computer has a high capacity hard disk drive, enabling you to install your favorite programs and store large multimedia files. Full Array of Ports and Connectors Your computer includes standard ports for connecting to peripherals such as USB devices and monitors. USB ports allow you to add many types of peripherals. Large SVGA or XGA LCD Your computer has a large, easy to view SVGA or XGA LCD panel. Built-in Microphone and Stereo Speakers The stereo speakers and internal microphone enable you to run a variety of multimedia applications. Function Keys Function keys allow you to suspend your computer, shut the LCDs off, and give you easy control of audio and your monitor. Where to Look For Information About Your Computer This Help System describes the key elements of your computer. New users can find a simple step-by- step orientation in this chapter. About Windows For more extensive information and help about Windows go to Help and Support, found on the Start Menu. Go to Start, Programs, Accessories to open , an online orientation of Windows XP. 72_0103_003 10 December 2002 © 2002 Itronix Corporation. All rights reserved. GoBook II™ Help Page 3 of 74GoBook II Help 7/31/2003file://C:\Documents%20and%20Settings\harwoodm.ITRXNT1\Local%20Settings\Temp\~hh9A72.htm Precautions You can use your computer under a wide range of environmental conditions. However, to ensure long use and continued high performance, consider the following factors when setting up your computer: Follow all warnings and instructions noted in this documentation and in the Windows Help and Support, found on the Start Menu. The first time you use your computer, we recommend that you carefully read the section on Power Management to familiarize yourself with some basic battery information and to ensure optimum performance There is danger of explosion if the battery is incorrectly replaced. Replace only with the same or equivalent type recommended by the manufacturer. Dispose of used batteries according to the manufacturer's instructions. Do not open the RAM door by yourself. Unplug the computer from the power outlet before cleaning. Use a damp cloth for cleaning. Do not use aerosols, solvents, or strong detergents Slots and openings in the computer case are for ventilation purposes. Do not block or cover these openings or the system could overheat On the bottom of the GoBook II, there is a label with information on the power requirements of this system. These requirements must be followed. If you are unsure of your local power supply, consult your dealer or local Power Company Do not step on or place anything on the power cord If you use the computer with an extension cord, ensure that the total ampere ratings of all the devices sharing the extension do not exceed the rating of the extension cord or the rating of the wall outlet Unless instructed, never push foreign objects into the computer through any of the slots or openings. Dangerous voltages are present, which could cause …

Text truncated - open the document above for the full version.

Identification GoBook II (IX260) Help December 2002 · Revision 003 Copyright Notice © Copyright 2002 Itronix Corporation. All rights reserved. No part of this document may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any other language or computer language in whole or in part, in any form or by any means, whether it be electronic, mechanical, magnetic, optical, manual, or otherwise, without the prior written consent of Itronix Corporation, South 801 Stevens Street, Spokane, Washington 99204. Disclaimer This document is printed in the U.S.A. Itronix Corporation reserves the right to revise the manual and make periodic changes to the content without a direct or inferred obligation to Itronix to notify any person of such revision or changes. Itronix Corporation does not assume responsibility for the use of this help manual, nor for any patent infringements or other rights or third parties who may use the manual. This document contains valuable trade secrets and proprietary information of Itronix Corporation. This product is available for purchase under the terms of the Itronix Hardware Purchase and Software License Agreement. Itronix hardware products may be reconditioned, or be manufactured from parts and components that may be new, used, rebuilt, or recycled and in some cases, the hardware product may not be new and may have been previously installed. In any event, Itronix warranty terms apply. Trademark and Patent Notice Itronix is a registered trademark of Itronix Corporation. GoBook II is a registered trademark of Itronix Corporation Microsoft, MS, Windows, and MS-DOS are registered trademarks of Microsoft Corporation. IBM is a trademark of International Business Machines Corporation. The following United States Patent Numbers apply to any unit which incorporates a DVD drive - 5,434,678; 5,589,945; 5,913,013; 6,151,444; and 6,208,805. Compliance Statements The GoBook II (IX260) computer has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help. The GoBook II (IX260) computer complies with Part 68 of the FCC Rules. On the bottom of this equipment is a label that contains, among other information, the FCC registration number and ringer equivalence number (REN) for this equipment. If requested, this information must be provided to the telephone company. The REN is used to determine the quantity of devices which may be connected to the telephone line. Excessive RENs on the telephone line may result in the devices not ringing in response to an incoming call. In most, but not all areas, the sum of the RENs should not exceed five (5.0). To be certain of the number of devices that may be connected to the line, as determined by the total RENs, contact the telephone GoBook II™ Help Legal Information Page 1 of 3Legal Information 7/31/2003mk:@MSITStore:C:\ix260manualmods\KBCIX260mpia750bt\gobookII.chm::/terms.htm company to determine the IIimum REN for the calling area. Changes or modifications not expressly approved by the party responsible for compliance could void the users authority to operate the equipment. The GoBook II (IX260) computer may be connected to the telephone network using the RJ-11 jack provided. If this equipment causes harm to the telephone network, the telephone company will notify you in advance that temporary discontinuance of service may be required. If advance notice isn’t practical, the telephone company will notify the customer as soon as possible. Also, you will be advised of your right to file a complaint with the FCC if you believe it is necessary. The telephone company may make changes in its facilities, equipment, operations, or procedures that could affect the operation of the equipment. If this happens, the telephone company will provide advance notice in order for you to make the necessary modifications in order to maintain uninterrupted service. If trouble is experienced with this equipment, please contact the equipment manufacturer for repair and/or warranty information. Do not attempt repairs of this equipment yourself without obtaining manufacturer authorized parts and documentation. If the trouble is causing harm to the telephone network, the telephone company may request you remove the equipment from the network until the problem is resolved. Compliance Statement for Canada NOTICE The Industry Canada label identifies certified equipment. This certification means that the equipment meets certain telecommunications network protective, operational and safety requirements as prescribed in the appropriate Terminal Equipment Technical Requirements document(s). The Department does not guarantee the equipment will operate to the user’s satisfaction. Before installing this equipment, users should ensure that it is permissible to be connected to the facilities of the local telecommunications company. The equipment must also be installed using an acceptable method of connection. The customer should be aware that compliance with the above condit…

Text truncated - open the document above for the full version.

Identification GoBook II (IX260) Help December 2002 · Revision 003 Copyright Notice © Copyright 2002 Itronix Corporation. All rights reserved. No part of this document may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any other language or computer language in whole or in part, in any form or by any means, whether it be electronic, mechanical, magnetic, optical, manual, or otherwise, without the prior written consent of Itronix Corporation, South 801 Stevens Street, Spokane, Washington 99204. Disclaimer This document is printed in the U.S.A. Itronix Corporation reserves the right to revise the manual and make periodic changes to the content without a direct or inferred obligation to Itronix to notify any person of such revision or changes. Itronix Corporation does not assume responsibility for the use of this help manual, nor for any patent infringements or other rights or third parties who may use the manual. This document contains valuable trade secrets and proprietary information of Itronix Corporation. This product is available for purchase under the terms of the Itronix Hardware Purchase and Software License Agreement. Itronix hardware products may be reconditioned, or be manufactured from parts and components that may be new, used, rebuilt, or recycled and in some cases, the hardware product may not be new and may have been previously installed. In any event, Itronix warranty terms apply. Trademark and Patent Notice Itronix is a registered trademark of Itronix Corporation. GoBook II is a registered trademark of Itronix Corporation Microsoft, MS, Windows, and MS-DOS are registered trademarks of Microsoft Corporation. IBM is a trademark of International Business Machines Corporation. The following United States Patent Numbers apply to any unit which incorporates a DVD drive - 5,434,678; 5,589,945; 5,913,013; 6,151,444; and 6,208,805. Compliance Statements The GoBook II (IX260) computer may have multiple radio's installed . Each radio may have an individual FCC identifier. Only the FCC identifier that is on the Itronix Label is Valid for this configuration. The GoBook II (IX260) computer has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help. The GoBook II (IX260) computer complies with Part 68 of the FCC Rules. On the bottom of this equipment is a label that contains, among other information, the FCC registration number and ringer equivalence number (REN) for this equipment. If requested, this information must be provided to the telephone company. GoBook II™ Help Legal Information Page 1 of 3Legal Information 9/30/2003mk:@MSITStore:C:\ix260manualmods\KBCIX260a750mpibt\gobookII.chm::/terms.htm The REN is used to determine the quantity of devices which may be connected to the telephone line. Excessive RENs on the telephone line may result in the devices not ringing in response to an incoming call. In most, but not all areas, the sum of the RENs should not exceed five (5.0). To be certain of the number of devices that may be connected to the line, as determined by the total RENs, contact the telephone company to determine the IIimum REN for the calling area. Changes or modifications not expressly approved by the party responsible for compliance could void the users authority to operate the equipment. The GoBook II (IX260) computer may be connected to the telephone network using the RJ-11 jack provided. If this equipment causes harm to the telephone network, the telephone company will notify you in advance that temporary discontinuance of service may be required. If advance notice isn’ t practical, the telephone company will notify the customer as soon as possible. Also, you will be advised of your right to file a complaint with the FCC if you believe it is necessary. The telephone company may make changes in its facilities, equipment, operations, or procedures that could affect the operation of the equipment. If this happens, the telephone company will provide advance notice in order for you to make the necessary modifications in order to maintain uninterrupted service. If trouble is experienced with this equipment, please contact the equipment manufacturer for repair and/or warranty information. Do not attempt repairs of this equipment yourself without obtaining manufacturer authorized parts and documentation. If the trouble is causing harm to the telephone network, the telephone company may request you remove the equipment from the network until the problem is resolved. Compliance Statement for Canada NOTICE The Industry Canada label identifies certified equipment. This certification means that the equipment meets certain telecommunications network protective, operational and safety requirements as prescribed in the appropriate Terminal Equipment Technical Requirements document(s). The Department does not guarantee the equipment will operate to the user’s satisfaction. Before installing this equipment, users should ensure that it is permissible to be connecte…

Text truncated - open the document above for the full version.

Jim Nicholson EMC Compliance Engineer Cisco Systems, Inc. 4125 Highlander Parkway Richfield, OH 44286 Phone: (330) 523-2094 Fax: (330) 523-2002 E-Mail: [email protected] August 11, 2003 AmericanTCB, Inc. 6731 Whittier Ave McLean, VA 22101 Re: ITRONIX FCC ID: KBCIX260MPIA750BT, ATCB File No. ATCB000671 To Whom It May Concern: The following information is to be held confidential pursuant to 47 CFR Part 0 §0.457 and Section 552(b)(4) of the Freedom of Information Act, because the information provided is proprietary and contains trade secrets. If made public, the information might be used to the disadvantage of the Cisco Systems, Inc. in the market place. In addition, this information is to be withheld from the applicant, Itronix, as well. Block Diagram Schematic Diagrams Technical Description Best Regards, Jim Nicholson EMC Compliance Engineer

American Telecommunications Certification Body Inc. 6731 Whittier Ave, McLean, VA 22101 August 13, 2003 RE: FCC ID: KBCIX260MPIA750BT Attention: Rod Munro I have a few comments on this Application. 1. The power listed in the technical specs for the Bluetooth device in the functional description file (max 20dBm or 100mW) is significantly higher than that tested (28mW or approx 14dBm). How is the power for this particular device controlled so as not to exceed the power level tested? 2. I do not find the report showing radiated spurious emissions with all three devices operating simultaneously. Please explain and provide this information. Dennis Ward mailto:[email protected] The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information may result in application termination. Correspondence should be considered part of the permanent submission and may be viewed from the Internet after a Grant of Equipment Authorization is issued. Please do not respond to this correspondence using the email reply button. In order for your response to be processed expeditiously, you must submit your documents through the AmericanTCB.com website. Also, please note that partial responses increase processing time and should not be submitted. Any questions about the content of this correspondence should be directed to the sender.

© 2003 Celltech Labs Inc. ITRONIX CORPORATION FCC ID: KBCIX260MPIA750BT (Model: IX260) Rugged Laptop PC with AirCard 750 GPRS Modem, Co-located WLAN, & Bluetooth Module Test Report S/N: 071603-401KBC EXTERNAL EUT PHOTOGRAPHS © 2003 Celltech Labs Inc. ITRONIX CORPORATION FCC ID: KBCIX260MPIA750BT (Model: IX260) Rugged Laptop PC with AirCard 750 GPRS Modem, Co-located WLAN, & Bluetooth Module Test Report S/N: 071603-401KBC EXTERNAL EUT PHOTOGRAPHS © 2003 Celltech Labs Inc. ITRONIX CORPORATION FCC ID: KBCIX260MPIA750BT (Model: IX260) Rugged Laptop PC with AirCard 750 GPRS Modem, Co-located WLAN, & Bluetooth Module Test Report S/N: 071603-401KBC EXTERNAL EUT PHOTOGRAPHS © 2003 Celltech Labs Inc. ITRONIX CORPORATION FCC ID: KBCIX260MPIA750BT (Model: IX260) Rugged Laptop PC with AirCard 750 GPRS Modem, Co-located WLAN, & Bluetooth Module Test Report S/N: 071603-401KBC EXTERNAL EUT PHOTOGRAPHS with Vehicle Cradle & 3 dBi Gain Vehicle Antenna (MaxRad P/N: WMLPVDB800/1900) © 2003 Celltech Labs Inc. ITRONIX CORPORATION FCC ID: KBCIX260MPIA750BT (Model: IX260) Rugged Laptop PC with AirCard 750 GPRS Modem, Co-located WLAN, & Bluetooth Module Test Report S/N: 071603-401KBC EXTERNAL EUT PHOTOGRAPHS Vehicle Cradle

Applicant: ITRONIX, Corp. FCC ID: KBCIX260MPIA750BT Exhibit 1 LIST OF EXHIBITS DESCRIPTION EXHIBITS REFERENCE I.Identification label Information1 2.1033 (b) 7 & 2.925 & General Information1A 1. Production Plans2.1031 2. Application ReferencesN/A 3. Data submittal Procedure 4. Similar Certified Transmitter II.Certification Data2 III.External Photographs32.1033 (b) 7 IV.Block Diagrams (Circuit Diagrams) confidential 42.1033 (b) 5 V. Schematic Diagrams & Antenna Assembly confidential 52.1033 (b) 5 VI. Test Report # 1 62.1033 (b) 6 Part 24 – C elltech Lab s, Inc. IX260 E M C Te st Report with previou sly C ertified Tran s mitter Air card 750 Sierra Wireles s, Inc, F C C ID: N7NA C750 VI.Te st Report # 2 62.1033 (b) 6 Part 15.247 – D T S, W L AN IX 260 E M C Te st Report, With previously Certified Intentional Radiator MPI350 Series CI S C O S y stem, In c., F C C ID: LD K 102042 1) Conducted Output Power Section 15.247(b)1 2) EIRP limit Section 15.247(b)3 3) Spurious Emissions Section 15.247 (c) 4) 20 dB Bandwidh and Antenna Conducted Spur’s (submitted in a separate file) Note: We may be referencing some of the original test report exhibits for items required by Part 15.247 (a, b, c, g, h) VI. Test Report # 3 62.1033 (b) 6 Part 15.247 – F H S S, EM C Te st Report of the previous ly C ertified Bluetooth Intentional Radiator, Model: WML-C1 1NU, Mutsumi, Ele c. Co., Ltd., F C C ID: P OOWML-C 11XX Eleven Common Bluetooth Items6 Six tests required6 15.247 (a, b, c, g, h) 1) The Occupied Bandwidth Section 15.247(a)!ii 2) Conducted Output Power Section 15.247(b)1 3) EIRP limit Section 15.247(b)3 4) RF safety Section 15.247(b)4 see Exhibit XII 5) Spurious Emissions Section 15.247 (c) 6) Power Spectral Density in Acquistion Mode Applicant: ITRONIX, Corp. FCC ID: KBCIX260MPIA750BT Exhibit 1 VII.Test Set-up Procedures72.1041 VIII.Instruction Manual82.1033 (b) 3 IX.Internal Photographs92.1033 (b) 7 X.Part List and Tune Up Procedures102.1033 XI.MPE RF Exposure Information112.1093 & 15.247 (b)4 XII.Operational Description confidential 122.1033 (b) 1, 2, 4, 8 Antenna Requirements1215.203 XIII. Cover Letter, Action Requested13 Cover Letter, Request For Confidentiality13 Cover Letter, Authorization to sign FCC Form 73113 Please NOTE: Exhibits 4, 5 and 12 are requested to held confidential EXHIBIT 1. FCC IDENTIFICATION LABEL Required Under Section: 47 CFR 2.1033(c) 11 for the FCC ID: KBCIX260MPIA750BT , is located on page following. Applicant: ITRONIX, Corp. FCC ID: KBCIX260MPIA750BT Exhibit 1 FCC ID label Location On Bottom of the PC It is the large label located right of center between the RAM and Battery covers I I I V Part 15.19 labeling requirement and compliance statement, upper left black label

© 2003 Celltech Labs Inc. ITRONIX CORPORATION FCC ID: KBCIX260MPIA750BT (Model: IX260) Rugged Laptop PC with AirCard 750 GPRS Modem, Co-located WLAN, & Bluetooth Module Test Report S/N: 071603-401KBC INTERNAL EUT PHOTOGRAPHS Cradle Contact Board © 2003 Celltech Labs Inc. ITRONIX CORPORATION FCC ID: KBCIX260MPIA750BT (Model: IX260) Rugged Laptop PC with AirCard 750 GPRS Modem, Co-located WLAN, & Bluetooth Module Test Report S/N: 071603-401KBC INTERNAL EUT PHOTOGRAPHS Sierra Wireless AirCard 750 PCS GPRS PCMCIA Modem Card © 2003 Celltech Labs Inc. ITRONIX CORPORATION FCC ID: KBCIX260MPIA750BT (Model: IX260) Rugged Laptop PC with AirCard 750 GPRS Modem, Co-located WLAN, & Bluetooth Module Test Report S/N: 071603-401KBC INTERNAL EUT PHOTOGRAPHS Sierra Wireless AirCard 750 PCS GPRS PCMCIA Modem Card © 2003 Celltech Labs Inc. ITRONIX CORPORATION FCC ID: KBCIX260MPIA750BT (Model: IX260) Rugged Laptop PC with AirCard 750 GPRS Modem, Co-located WLAN, & Bluetooth Module Test Report S/N: 071603-401KBC INTERNAL EUT PHOTOGRAPHS Sierra Wireless AirCard 750 PCS GPRS PCMCIA Modem Card © 2003 Celltech Labs Inc. ITRONIX CORPORATION FCC ID: KBCIX260MPIA750BT (Model: IX260) Rugged Laptop PC with AirCard 750 GPRS Modem, Co-located WLAN, & Bluetooth Module Test Report S/N: 071603-401KBC INTERNAL EUT PHOTOGRAPHS Sierra Wireless AirCard 750 PCS GPRS PCMCIA Modem Card © 2003 Celltech Labs Inc. ITRONIX CORPORATION FCC ID: KBCIX260MPIA750BT (Model: IX260) Rugged Laptop PC with AirCard 750 GPRS Modem, Co-located WLAN, & Bluetooth Module Test Report S/N: 071603-401KBC INTERNAL EUT PHOTOGRAPHS Co-located Cisco MPI-350 Mini-PCI DSSS WLAN Card © 2003 Celltech Labs Inc. ITRONIX CORPORATION FCC ID: KBCIX260MPIA750BT (Model: IX260) Rugged Laptop PC with AirCard 750 GPRS Modem, Co-located WLAN, & Bluetooth Module Test Report S/N: 071603-401KBC INTERNAL EUT PHOTOGRAPHS Co-located Bluetooth Module Bluetooth Module Bluetooth Module © 2003 Celltech Labs Inc. ITRONIX CORPORATION FCC ID: KBCIX260MPIA750BT (Model: IX260) Rugged Laptop PC with AirCard 750 GPRS Modem, Co-located WLAN, & Bluetooth Module Test Report S/N: 071603-401KBC Right Side WLAN Antenna Left Side Bluetooth Antenna INTERNAL EUT PHOTOGRAPHS Internal Antennas for Co-located Cisco MPI-350 Mini-PCI DSSS WLAN Card and Bluetooth Module Distance at LCD back-side between dipole antenna feed/swivel-joint and WLAN and Bluetooth antennas © 2003 Celltech Labs Inc. ITRONIX CORPORATION FCC ID: KBCIX260MPIA750BT (Model: IX260) Rugged Laptop PC with AirCard 750 GPRS Modem, Co-located WLAN, & Bluetooth Module Test Report S/N: 071603-401KBC Distance at LCD back-side between dipole antenna feed/swivel-joint and Bluetooth left-side antenna INTERNAL EUT PHOTOGRAPHS Internal Antenna for Co-located Cisco MPI-350 Mini-PCI DSSS WLAN Card and Bluetooth Module Distance at LCD back-side between dipole antenna feed/swivel-joint and WLAN right-side antenna © 2003 Celltech Labs Inc. ITRONIX CORPORATION FCC ID: KBCIX260MPIA750BT (Model: IX260) Rugged Laptop PC with AirCard 750 GPRS Modem, Co-located WLAN, & Bluetooth Module Test Report S/N: 071603-401KBC Back of LCD Display - Left-Side Antenna Back of LCD Display - Right-Side Antenna INTERNAL EUT PHOTOGRAPHS Internal Antenna for Co-located Cisco MPI-350 Mini-PCI DSSS WLAN Card and Bluetooth Module © 2003 Celltech Labs Inc. ITRONIX CORPORATION FCC ID: KBCIX260MPIA750BT (Model: IX260) Rugged Laptop PC with AirCard 750 GPRS Modem, Co-located WLAN, & Bluetooth Module Test Report S/N: 071603-401KBC INTERNAL EUT PHOTOGRAPHS Co-located Cisco MPI-350 Mini-PCI DSSS WLAN Card © 2003 Celltech Labs Inc. ITRONIX CORPORATION FCC ID: KBCIX260MPIA750BT (Model: IX260) Rugged Laptop PC with AirCard 750 GPRS Modem, Co-located WLAN, & Bluetooth Module Test Report S/N: 071603-401KBC INTERNAL EUT PHOTOGRAPHS Co-located Bluetooth Module

Applicant: ITRONIX, Corp.FCC ID: KBCIX260MPIA750BT Exhibit 11 1 EXHIBIT 11 - MPE CALCULATION DATA FCC ID: KBCIX260MPIA750BT Applicant: ITRONIX, Corp. Model: IX260 with the three co-located transmitters listed below. 1.) AIRCARD750-supporting calculations on pages 2-4 Tx Freq: 1850.20 Tx Freq: 1880.00 Tx Freq: 1909.00 Max Peak Power @ antenna terminal input: 28.12 Max Peak Power @ antenna terminal input: 28.08 Max Peak Power @ antenna terminal input: 28.00 Antenna Gain: 0.1dBi 2.) MPI350-supporting calculations on page 5 Tx Freq: 2450 MHz Max Peak Power @ antenna terminal input: 21.2 dBm Antenna Gain: 4.5 dBi 3.) Bluetooth-supporting calculations on page 6 Tx Freq: 2450 MHz Max Peak Power @ antenna terminal input: 14.46 dBm Antenna Gain 4.5 dBi The MPE calculations are submitted for multiple frequency exposure criteria. The ratio of the field strength or power density to the applicable exposure limit at the exposure location was determined for each transmitter below and the sum of these ratios does not exceed the 1 mW/cm^2 limit for uncontrolled exposure / general population exposure limits detailed in CFR 47, Part 1.1310. Multiple Frequency Exposure Requirements Ratio 1Ratio 2Ratio 3Limit AIRCARD750MPI350Bluetooth<1.0 0.132/10.074/1.00.016/1<1.0 = .132= .074= .016<1.0 Sum = .222 (mW/cm^2)<1.0 AIRCARD750 Tx Freq: 1850.20Tx Freq: 1880.00Tx Freq: 1909.00 Ratio 1Ratio 2Ratio 3 0.132/50.131/50.128/5 = .00264 = .00262 = .0256 Max = .00264 used for multiple frequency exposure above

Applicant: ITRONIX, Corp.FCC ID: KBCIX260MPIA750BT Exhibit 11 1 EXHIBIT 11 - MPE CALCULATION DATA FCC ID: KBCIX260MPIA750BT Applicant: ITRONIX, Corp. Model: IX260 with the three co-located transmitters listed below. 1.) AIRCARD750-supporting calculations on pages 2-4 Tx Freq: 1850.20 Tx Freq: 1880.00 Tx Freq: 1909.00 Max Peak Power @ antenna terminal input: 28.12 Max Peak Power @ antenna terminal input: 28.08 Max Peak Power @ antenna terminal input:…
