Getting Started Congratulations on your purchase of the Itronix GoBook II computer! Your new GoBook II features the most innovative advances in portable computing technology. It combines state-of-the-art ergonomics with a rugged, durable architecture to provide you with a notebook computer that is compact, powerful, rugged and easy to use. Designed for a wide range of business and personal productivity applications, the GoBook II is an ideal choice for use in applications that require durability and performance. For maximum expandability without compromising portability, the GoBook II has a USB interface and aPC card slot. The high capacity hard diskdrive provides you with plenty of storage space for multimedia files and applications. The GoBook II features a standard 87-key Nitevue® keyboard (89-key international). The high- resolution 12.1-inch touch screen LCD panel provides clear and crisp viewing with the convenience of a touch screen. This online document, GoBook II Help , contains all the information you need to set up and use your new GoBook II. It describes all the features of the GoBook II in an easy-to-read yet thorough manner. For information on printing, navigating or otherwise using GoBook II Help see How to Use This Help System. Checklists GoBook II™Help Page 1 of 71GoBook II Help 3/11/2004file://C:\Documents%20and%20Settings\harwoodm.ITRXNT1\Local%20Settings\Temp\~... After opening the package, carefully inspect the contents. Contact your dealer if any items are missing or appear damaged. The shipping carton should contain the following: STANDARD z The Itronix GoBook II computer z Battery z ADP-90AB or ADP -75FB AC adapter with power cord z 12.1 inch XGA display z Stylus z Shoulder Strap z GoBook II Quick Start Guide OPTIONS The following items are normally optional, but some vendors may include them in the standard package. Some items may not be available in some countries, or some vendors may choose not to carry all the items. z Floppy disk drive z CD-ROM drive z CD-RW Drive z DVD-ROM drive z SVGA display z Soft Handle z Media Bay Li-Ion battery pack (3000 mAhr) z Hard Disk Drive Heater z LCD Heater CAUTION When purchasing any of the accessories listed above, purchase only those accessories that are approved for use with your computer. The above accessories are proprietary items. Your system vendor can obtain these approved accessories. If you use items that are not approved for use with this computer, you may cause your computer to malfunction, or to emit or receive electromagnetic radiation in excess of local regulations. For non-proprietary accessories such as PC Cards or printers, ensure that the accessory functions properly in your computer before making the purchase. Your system vendor may be able to recommend reliable brands and models. Features Page 2 of 71GoBook II Help 3/11/2004file://C:\Documents%20and%20Settings\harwoodm.ITRXNT1\Local%20Settings\Temp\~... High Capacity Hard Disk Drive The computer has a high capacity hard disk drive, enabling you to install your favorite programs and store large multimedia files. Full Array of Ports and Connectors Your computer includes standard ports for connecting to peripherals such as USB devices and monitors. USB ports allow you to add many types of peripherals. Large SVGA or XGA LCD Your computer has a large, easy to view SVGA or XGA LCD panel. Built-in Microphone and Stereo Speakers The stereo speakers and internal microphone enable you to run a variety of multimedia applications. Function Keys Function keys allow you to suspend your computer, shut the LCDs off, and give you easy control of audio and your monitor. Where to Look For Information About Your Computer This Help System describes the key elements of your computer. New users can find a simple step-by- step orientation in this chapter. About Windows For more extensive information and help about Windows go to Help and Support , found on the Start Menu. Go to Start, Programs, Accessories to open , an online orientation of Windows XP. 72_0103_003 10 December 2002 © 2002 Itronix Corporation. All rights reserved. Precautions You can use your computer under a wide range of environmental conditions. However, to ensure long GoBook II™Help Page 3 of 71GoBook II Help 3/11/2004file://C:\Documents%20and%20Settings\harwoodm.ITRXNT1\Local%20Settings\Temp\~... use and continued high performance, consider the following factors when setting up your computer: z Follow all warnings and instructions noted in this documentation and in the Windows Help and Support, found on the Start Menu. z The first time you use your computer, we recommend that you carefully read the section on Power Management to familiarize yourself with some basic battery information and to ensure optimum performance z There is danger of explosion if the battery is incorrectly replaced. Replace only with the same or equivalent type recommended by the manufacturer. Dispose of used batteries according to the manufacturer's instructions. z Do not open the RAM door by yourself. z Unplug the computer from the power outlet before cleaning. Use a damp cloth for cleaning. Do not use aerosols, solvents, or strong detergents z Slots and openings in the computer case are for ventilation purposes. Do not block or cover these openings or the system could overheat z On the bottom of the GoBook II, there is a label with information on the power requirements of this system. These requirements must be followed. If you are unsure of your local power supply, consult your dealer or local Power Company z Do not step on or place anything on the power cord z If you use the computer with an extension cord, ensure that the total ampere ratings of all the devices sharing the extension do not exceed the rating of the extension cord or the rating of the wall outlet z Unless instructed, never push foreign objects into the computer through any of the slots or openings. Dangerous voltages are present, which could cause electric shock, fire,…

Text truncated - open the document above for the full version.

Identification GoBook II (IX260) Help FCC DoC Responsibility Party: Itronix Corporation, 801 South Stevens Street, Spokane Washington, 99204 (Tel. 509-624- 6600). December 2002 · Revision 003 Copyright Notice © Copyright 2002 Itronix Corporation. All rights reserved. No part of this document may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any other language or computer language in whole or in part, in any form or by any means, whether it be electronic, mechanical, magnetic, optical, manual, or otherwise, without the prior written consent of Itronix Corporation, South 801 Stevens Street, Spokane, Washington 99204. Disclaimer This document is printed in the U.S.A. Itronix Corporation reserves the right to revise the manual and make periodic changes to the content without a direct or inferred obligation to Itronix to notify any person of such revision or changes. Itronix Corporation does not assume responsibility for the use of this help manual, nor for any patent infringements or other rights or third parties who may use the manual. This document contains valuable trade secrets and proprietary information of Itronix Corporation. This product is available for purchase under the terms of the Itronix Hardware Purchase and Software License Agreement. Itronix hardware products may be reconditioned, or be manufactured from parts and components that may be new, used, rebuilt, or recycled and in some cases, the hardware product may not be new and may have been previously installed. In any event, Itronix warranty terms apply. Trademark and Patent Notice Itronix is a registered trademark of Itronix Corporation. GoBook II is a registered trademark of Itronix Corporation Microsoft, MS, Windows, and MS-DOS are registered trademarks of Microsoft Corporation. IBM is a trademark of International Business Machines Corporation. The following United States Patent Numbers apply to any unit which incorporates a DVD drive - 5,434,678; 5,589,945; 5,913,013; 6,151,444; and 6,208,805. Compliance Statements The GoBook II (IX260) computer has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. Changes or modifications not expressly approved by the party responsible for compliance could void the users authority to operate the equipment. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: l Reorient or relocate the receiving antenna. l Increase the separation between the equipment and receiver. l Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. GoBook II™ Help Legal Information Page 1 of 4Legal Information 3/11/2004file://C:\ix260-manualmods\CoLocated%20Sony%20Ericsson%20mpi%20350%20WLAN... l Consult the dealer or an experienced radio/TV technician for help. The GoBook II (IX260) computer complies with Part 68 of the FCC Rules. On the bottom of this equipment is a label that contains, among other information, the FCC registration number and ringer equivalence number (REN) for this equipment. If requested, this information must be provided to the telephone company. The REN is used to determine the quantity of devices which may be connected to the telephone line. Excessive RENs on the telephone line may result in the devices not ringing in response to an incoming call. In most, but not all areas, the sum of the RENs should not exceed five (5.0). To be certain of the number of devices that may be connected to the line, as determined by the total RENs, contact the telephone company to determine the IIimum REN for the calling area. Changes or modifications not expressly approved by the party responsible for compliance could void the users authority to operate the equipment. The GoBook II (IX260) computer may be connected to the telephone network using the RJ-11 jack provided. If this equipment causes harm to the telephone network, the telephone company will notify you in advance that temporary discontinuance of service may be required. If advance notice isn’t practical, the telephone company will notify the customer as soon as possible. Also, you will be advised of your right to file a complaint with the FCC if you believe it is necessary. The telephone company may make changes in its facilities, equipment, operations, or procedures that could affect the operation of the equipment. If this happens, the telephone company will provide advance notice in order for you to make the necessary modifications in order to maintain uninterrupted service. If trouble is experienced with this equipment, please contact the equipment manufacturer for repair and/or warranty information. Do not attempt repairs of this equipment yourself without obtaining manufacturer authorized parts and documentation. If the trouble is causing harm to the telephone network, the telephone company may request you remove the equipment from the network until the problem is resolved. Compliance Statement for Canada NOTICE The Industry Canada label identifies certified equipment. This certification means that the equipment meets certain telecommunications network protective, operational and safety requirements as prescribed in the appropriate Terminal Equipment Technical Requirements document(s). The Department does not guarantee the equipment will operate to the user’s satisfaction. Before installing this equ…

Text truncated - open the document above for the full version.

801 S. STEVENS STREET SPOKANE, WA 99204 509.624.6600 800.441.1309 FAX 509.626.4203 www.itronix.com March 26, 2004 American Telecommunications Certification Body, Inc. 6731 Whittier Avenue, Suite C110 McLean, VA 22101 SUBJECT: ITRONIX CORPORATION FCC ID: KBCIX260MPIGC82 Part 15.247 Certification To Whom It May Concern: ITRONIX CORPORATION is hereby submitting a Part 15.247 Certification application for the above referenced Rugged Laptop PC with Cisco MPI-350 WLAN transmitter co-located with Sony Ericsson GC82 GSM radio modem. The Part 15.247 test data submitted for the Cisco MPI-350 WLAN transmitter is partially taken from previously certified application FCC ID: KBCIX260MPIRIM902 (File No.: ATCB000608) with the same WLAN transmitter installed with co-located RIM 902M Mobitex radio modem (tested by Spectrum Technology, Inc.). The band edge measurement data is taken from the previously certified application FCC ID: KBCIX260MPIBM3900 (File No.: ATCB001142) with the same WLAN transmitter installed with co-located Wavenet BM3-900M Mobitex radio modem (tested by Spectrum Technology, Inc.). The power spectral density measurement data is taken from the same previously certified Cisco MPI-350 WLAN transmitter FCC ID: LDK102042 (tested by Rhein Tech Laboratories, Inc.). The submitted test data listed below demonstrates compliance of the Cisco MPI-350 WLAN transmitter with FCC Part 15.247 requirements. Conducted Output Power - Spectrum Technology (FCC ID: KBCIX260MPIRIM902 / ATCB000608) Equivalent Isotropic Radiated Power - Spectrum Technology (FCC ID: KBCIX260MPIRIM902 / ATCB000608) Field Strength of Fundamental - Spectrum Technology (FCC ID: KBCIX260MPIRIM902 / ATCB000608) Radiated Harmonics & Spurious Emissions - Spectrum Technology (FCC ID: KBCIX260MPIRIM902 / ATCB000608) 6 dB Bandwidth & Conducted Spurious - Spectrum Technology (FCC ID: KBCIX260MPIRIM902 / ATCB000608) Band Edge - Spectrum Technology (FCC ID: KBCIX260MPIBM3900 / ATCB001142) Power Spectral Density - Rhein Tech Laboratories (FCC ID: LDK102042) The WLAN, IX260 Laptop PC, and antennas from the above-referenced FCC Part 15.247 EMC test reports are identical to those described and tested in this filing, including the placement of antennas, power levels, transmitter board and cabling. Sincerely,

801 S. STEVENS STREET SPOKANE, WA 99204 509.624.6600 800.441.1309 FAX 509.626.4203 www.itronix.com March 26, 2004 Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 Re: Itronix Corporation FCC ID: KBCIX260MPIGC82 FCC Part 15.247 Certification Request for Confidentiality In accordance with 0.457 and 0.459 of CFR 47, Itronix Corporation hereby requests confidentiality of the Block Diagram, Schematic Diagrams, and Operational Description exhibits for the subject application. These documents contain detailed system and equipment description and related information about the product in which Itronix Corporation considers to be proprietary, confidential, and a custom design and, otherwise, would not release to the general public. Since this design is a basis from which future technological products will evolve, Itronix Corporation considers that this information would be of benefit to its competitors, and that the disclosure of the information in these documents would give competitors an unfair advantage in the market. Sincerely,

Celltech Labs Inc. 1955 Moss Court, Kelowna, B.C. Canada V1Y 9L3 Tel. 250-448-7047 • Fax. 250-448-7046 • e-mail: [email protected] www.celltechlabs.com April 7, 2004 American Telecommunications Certification Body, Inc. 6731 Whittier Avenue, Suite C110 McLean, VA 22101 SUBJECT: ITRONIX CORPORATION FCC ID: KBCIX260MPIGC82 Part 15.247 - Certification On behalf of Itronix Corporation is an application for Part 15.247 Certification of Itronix IX260 Rugged Laptop PC with internal Cisco Systems, Inc. MPI-350 Mini-PCI DSSS WLAN Card (FCC ID: LDK102042, originally granted May 30, 2001) with internal 802.11b surface-mount dual antenna located in the upper rear sides of the LCD display, co-located with internal GC82 Dual-Band PCS/Cellular GSM GPRS/EDGE PCMCIA Radio Modem (manufactured by Sony Ericsson Mobile Communications AB (FCC ID: PY7F1041011, originally granted October 28, 2003), utilizing an external dipole antenna mounted on the upper right side of the LCD display. A Part 22/24 certification application for the co- located Sony Ericsson GC82 GSM GPRS/EDGE radio modem portion of the IX260 is also submitted simultaneously with this application. Model: IX260 Device Class: Digital Transmission System (DTS) Device Type: Rugged Laptop PC with internal Cisco MPI-350 Mini-PCI WLAN Card (co-located with Sony Ericsson GC82 GSM PCMCIA Radio Modem) Modulation: Direct Sequence Spread Spectrum (DSSS) Tx Freq. Range: 2412 - 2462 MHz Antenna Type(s): Internal Rangestar 802.11b Dual Surface-Mount (P/N: 100929) RF Conducted Power Tested: 21.2 dBm (Max.) Max. RF Output Power: 0.372 Watts (EIRP) Attached is the applicant’s confidentiality request, attestation letter, Part 15.247 EMC measurement report data and photographs (Spectrum Technology and Rhein Tech Laboratories), MPE RF exposure evaluation report data & photographs (Celltech Labs), FCC ID label and location, internal and external photographs, block diagram(s) (confidential), schematic diagram(s) (confidential), operational description (confidential), antenna specifications (confidential), and the user's manual with RF exposure warning statement(s). For the WLAN confidential exhibits, please refer to the previously certified Itronix IX260 FCC ID: KBCIX260MPIBM3900 (File No.: ATCB001160). If you have any questions or comments concerning the above, please contact the undersigned. Sincerely, Jonathan Hughes General Manager Celltech Labs Inc. cc: Itronix Corporation Spectrum Technology Inc.

© 2004 Celltech Labs Inc. ITRONIX CORPORATION FCC ID: KBCIX260MPIGC82 (Model: IX260) Rugged Laptop PC with Sony Ericsson GSM Modem & Co-located Cisco WLAN Test Report S/N: 031004-487/488KBC EXTERNAL EUT PHOTOGRAPHS © 2004 Celltech Labs Inc. ITRONIX CORPORATION FCC ID: KBCIX260MPIGC82 (Model: IX260) Rugged Laptop PC with Sony Ericsson GSM Modem & Co-located Cisco WLAN Test Report S/N: 031004-487/488KBC Dual-Band GSM External Swivel Dipole Antenna EXTERNAL EUT PHOTOGRAPHS © 2004 Celltech Labs Inc. ITRONIX CORPORATION FCC ID: KBCIX260MPIGC82 (Model: IX260) Rugged Laptop PC with Sony Ericsson GSM Modem & Co-located Cisco WLAN Test Report S/N: 031004-487/488KBC EXTERNAL EUT PHOTOGRAPHS © 2004 Celltech Labs Inc. ITRONIX CORPORATION FCC ID: KBCIX260MPIGC82 (Model: IX260) Rugged Laptop PC with Sony Ericsson GSM Modem & Co-located Cisco WLAN Test Report S/N: 031004-487/488KBC EXTERNAL EUT PHOTOGRAPHS with Vehicle Cradle & 3 dBi Gain Vehicle Antenna (MaxRad P/N: WMLPVDB800/1900) © 2004 Celltech Labs Inc. ITRONIX CORPORATION FCC ID: KBCIX260MPIGC82 (Model: IX260) Rugged Laptop PC with Sony Ericsson GSM Modem & Co-located Cisco WLAN Test Report S/N: 031004-487/488KBC EXTERNAL EUT PHOTOGRAPHS Vehicle Cradle

© 2004 Celltech Labs Inc. ITRONIX CORPORATION FCC ID: KBCIX260MPIGC82 (Model: IX260) Rugged Laptop PC with Sony Ericsson GSM Modem & Co-located Cisco WLAN Test Report S/N: 031004-487/488KBC LABELING REQUIREMENTS PER §2.925 The label(s) shall be permanently affixed at a conspicuous location on the device. SEE NEXT PAGE(S) FOR PART 24/22 FCC ID LABEL SEE NEXT PAGE(S) FOR PART 15(B) DoC LABEL FCC ID LABEL & LOCATION Corporation Design Col or R equi rem ent: P FCC Label For P16 Background : TCG-426P Text : Pantone 441C P16 Wen Fu Chieng PC , Thickness 0.8mm 1 : 1 1 1 08 / 19 / 02 63-040210-00 0 63-040210-00 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Made in Taiwan MODEL NO. : IX260 FOR HOME OR OFFICE USEFCC StandardsTested To Comply With C US LR86520 NOTEBOOK : DC 19V 3.95A E4309 ICES-003. NMB-003 du Canada. Cet appareil numerique de la classe B est conforme a la norme This Class B digital apparatus complies with Canadian ` ` X260) (I

© 2004 Celltech Labs Inc. ITRONIX CORPORATION FCC ID: KBCIX260MPIGC82 (Model: IX260) Rugged Laptop PC with Sony Ericsson GSM Modem & Co-located Cisco WLAN Test Report S/N: 031004-487/488KBC INTERNAL EUT PHOTOGRAPHS Cradle Contact Board © 2004 Celltech Labs Inc. ITRONIX CORPORATION FCC ID: KBCIX260MPIGC82 (Model: IX260) Rugged Laptop PC with Sony Ericsson GSM Modem & Co-located Cisco WLAN Test Report S/N: 031004-487/488KBC INTERNAL EUT PHOTOGRAPHS Sony Ericsson GC82 GSM GPRS/EDGE PCMCIA Modem Card © 2004 Celltech Labs Inc. ITRONIX CORPORATION FCC ID: KBCIX260MPIGC82 (Model: IX260) Rugged Laptop PC with Sony Ericsson GSM Modem & Co-located Cisco WLAN Test Report S/N: 031004-487/488KBC INTERNAL EUT PHOTOGRAPHS Sony Ericsson GC82 GSM GPRS/EDGE PCMCIA Modem Card © 2004 Celltech Labs Inc. ITRONIX CORPORATION FCC ID: KBCIX260MPIGC82 (Model: IX260) Rugged Laptop PC with Sony Ericsson GSM Modem & Co-located Cisco WLAN Test Report S/N: 031004-487/488KBC INTERNAL EUT PHOTOGRAPHS Sony Ericsson GC82 GSM GPRS/EDGE PCMCIA Modem Card © 2004 Celltech Labs Inc. ITRONIX CORPORATION FCC ID: KBCIX260MPIGC82 (Model: IX260) Rugged Laptop PC with Sony Ericsson GSM Modem & Co-located Cisco WLAN Test Report S/N: 031004-487/488KBC INTERNAL EUT PHOTOGRAPHS Sony Ericsson GC82 GSM GPRS/EDGE PCMCIA Modem Card © 2004 Celltech Labs Inc. ITRONIX CORPORATION FCC ID: KBCIX260MPIGC82 (Model: IX260) Rugged Laptop PC with Sony Ericsson GSM Modem & Co-located Cisco WLAN Test Report S/N: 031004-487/488KBC INTERNAL EUT PHOTOGRAPHS Co-located Cisco MPI-350 Mini-PCI DSSS WLAN Card © 2004 Celltech Labs Inc. ITRONIX CORPORATION FCC ID: KBCIX260MPIGC82 (Model: IX260) Rugged Laptop PC with Sony Ericsson GSM Modem & Co-located Cisco WLAN Test Report S/N: 031004-487/488KBC Right Side Antenna INTERNAL EUT PHOTOGRAPHS Dual Internal Antennas for Co-located Cisco MPI-350 Mini-PCI DSSS WLAN Card Back Side of LCD Display Left Side Antenna Distance at LCD back-side between dipole antenna feed/swivel-joint and WLAN dual antennas © 2004 Celltech Labs Inc. ITRONIX CORPORATION FCC ID: KBCIX260MPIGC82 (Model: IX260) Rugged Laptop PC with Sony Ericsson GSM Modem & Co-located Cisco WLAN Test Report S/N: 031004-487/488KBC INTERNAL EUT PHOTOGRAPHS Dual Internal Antennas for Co-located Cisco MPI-350 Mini-PCI DSSS WLAN Card Distance at LCD back-side between dipole antenna feed/swivel-joint and WLAN right-side antenna Distance at LCD back-side between dipole antenna feed/swivel-joint and WLAN left-side antenna © 2004 Celltech Labs Inc. ITRONIX CORPORATION FCC ID: KBCIX260MPIGC82 (Model: IX260) Rugged Laptop PC with Sony Ericsson GSM Modem & Co-located Cisco WLAN Test Report S/N: 031004-487/488KBC Back of LCD Display - Left-Side Antenna Back of LCD Display - Right-Side Antenna INTERNAL EUT PHOTOGRAPHS Dual Internal Antennas for Co-located Cisco MPI-350 Mini-PCI DSSS WLAN Card © 2004 Celltech Labs Inc. ITRONIX CORPORATION FCC ID: KBCIX260MPIGC82 (Model: IX260) Rugged Laptop PC with Sony Ericsson GSM Modem & Co-located Cisco WLAN Test Report S/N: 031004-487/488KBC INTERNAL EUT PHOTOGRAPHS Co-located Cisco MPI-350 Mini-PCI DSSS WLAN Card Top view of the board without shielding Bottom view of the board without shielding

© 2004 Celltech Labs Inc. ITRONIX CORPORATION FCC ID: KBCIX260MPIGC82 (Model: IX260) 1 of 4 Rugged Laptop PC with Sony Ericsson GSM Modem & co-located Cisco WLAN Antenna Types: External Dipole, Internal 802.11b Surface-Mount, Mobile Vehicle-Mount Test Report S/N: 031004-488KBC Test Type: MPE Evaluation This mobile device, with internal co-located transmitters, is determined to be compliant with localized Maximum Permissible Exposure (MPE) for Uncontrolled Exposure / General Population limits specified in FCC 47 CFR §1.1310 and Industry Canada RSS-102 Issue 1 (Provisional), in accordance with the requirements of FCC OET Bulletin 65, Edition 97-01, Health Canada’s Safety Code 6, ANSI / IEEE C95.1-1992, and ANSI / IEEE C95.3-1992. I attest to the accuracy of data. All measurements and/or calculations were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. This evaluation report shall not be reproduced partially, or in full, without the prior written approval of Celltech Labs Inc. The results and statements contained in this report pertain only to the device(s) evaluated. Russell Pipe Senior Compliance Technologist Celltech Labs Inc. DECLARATION OF COMPLIANCE MPE EVALUATION REPORT Test Lab CELLTECH LABS INC. 1955 Moss Court Kelowna, B.C. Canada V1Y 9L3 Phone: 250-448-7047 Fax: 250-448-7046 e-mail: [email protected] web site: www.celltechlabs.com Applicant Information ITRONIX CORPORATION 801 South Stevens Street Spokane, WA 99210 FCC Rule Part(s): 47 CFR §24(E), §22(H); §15.247; §2.1091; §1.1310 IC Rule Part(s): RSS-133 Issue 2, RSS-132 Issue 1 (Provisional), RSS-210 Issue 5, RSS-102 Issue 1 (Provisional) FCC Classification: PCS Licensed Transmitter (PCB) IC Classification: 2 GHz Personal Communication Services (RSS-133) 800 MHz Cellular Telephones Employing New Technologies (RSS-132) Device Type: Rugged Laptop PC with Sony Ericsson GC82 GSM Radio Modem (co-located with Cisco MPI-350 Mini-PCI 2.4GHz DSSS WLAN Card) with External Swivel Dipole Antenna (GSM), Internal Antenna (WLAN), External Mobile Vehicle-Mount Antenna (GSM), & Vehicle Cradle FCC ID: KBCIX260MPIGC82 Model(s): IX260 Tx Frequency Range(s): 1850.2 - 1909.8 MHz (PCS GSM) 824.2 - 848.8 MHz (Cellular GSM) 2412 - 2462 MHz (WLAN) Max. Conducted Power Measured: 30.06 dBm Peak (PCS GSM) / 32.37 dBm Peak (Cellular GSM) 21.2 dBm Peak (WLAN) Mode(s) / Time Slot(s) Tested: GSM EDGE / 2-out-of-8 Time Slots (Max. Data Rate: 61.85 kbps per slot) Source-Based Time-Av. Duty Cycle: 25 % Max. Source-Based Time-Av. Cond. Pwr: 24.04 dBm Peak (PCS GSM) / 26.35 dBm Peak (Cellular GSM) Antenna Type(s) Evaluated: Itronix IX260 External Swivel Dipole (GSM) Rangestar P/N: 100929 802.11b Dual Internal Surface-Mount (WLAN) MaxRad 3 dBi Gain Vehicle-Mount P/N: WMLPVDB800/1900 (GSM) © 2004 Celltech Labs Inc. ITRONIX CORPORATION FCC ID: KBCIX260MPIGC82 (Model: IX260) 2 of 4 Rugged Laptop PC with Sony Ericsson GSM Modem & co-located Cisco WLAN Antenna Types: External Dipole, Internal 802.11b Surface-Mount, Mobile Vehicle-Mount Test Report S/N: 031004-488KBC Test Type: MPE Evaluation 1.1 MPE Calculation Data 1. Itronix IX260 Swivel Dipole Antenna PCS GSM Band Field Density @ 20 cm = 0.092 (mW/cm^2) Cellular GSM Band Field Density @ 20 cm = 0.156 (mW/cm^2) 2. Rangestar 802.11b Internal Antenna Field Density @ 20 cm = 0.074 (mW/cm^2) Itronix IX260 Swivel Dipole Antenna Rangestar 802.11b Internal Antenna Tx Frequency: 2450.00 (MHz) Maximum Peak Power at Antenna Input Terminal: 21.20 (dBm) Antenna gain: 4.50 (dBi) S=1.00 (mW/cm^2) P=131.8257 (mW) G=2.82 (numeric) R =5.44(cm) Tx Frequency: 1880.00 (MHz) Source-Based Time-Averaged Power at Antenna Input Terminal: 24.04 (dBm) Antenna gain: 2.60 (dBi) S=1.00 (mW/cm^2) P=253.5129 (mW) G=1.82 (numeric) R =6.06(cm) Tx Frequency: 848.80 (MHz) Source-Based Time-Averaged Power at Antenna Input Terminal: 26.35 (dBm) Antenna gain: 2.60 (dBi) S=0.57 (mW/cm^2) P=431.5191 (mW) G=1.82 (numeric) R =10.51(cm) © 2004 Celltech Labs Inc. ITRONIX CORPORATION FCC ID: KBCIX260MPIGC82 (Model: IX260) 3 of 4 Rugged Laptop PC with Sony Ericsson GSM Modem & co-located Cisco WLAN Antenna Types: External Dipole, Internal 802.11b Surface-Mount, Mobile Vehicle-Mount Test Report S/N: 031004-488KBC Test Type: MPE Evaluation MPE Calculation Data (Cont.) According to FCC training materials (May 2003): Multiple frequency exposure criteria, the ratio of field strength or power density to the applicable exposure limit at the exposure location should be determined for each transmitter and the sum of these ratios must not exceed 1.0. 3. MaxRad 3 dBi Gain Vehicle-Mount Antenna (P/N: WMLPVDB800/1900) PCS GSM Band Field Density @ 20 cm = 0.053 (mW/cm^2) Cellular GSM Band Field Density @ 20 cm = 0.111 (mW/cm^2) MaxRad 3 dBi Gain Vehicle-Mount Antenna P/N: WMLPVDB800/1900 Ratio 1 Ratio 2 Limit 0.156/0.6 0.074/1.0 < 1.0 = 0.260 = 0.074 < 1.0 Sum = 0.334 (mW/cm^2) < 1.0 Tx Frequency: 1880.00 (MHz) Source Based Time Averaged Power at Antenna Input Terminal: 24.04 (dBm) 3 dBi Antenna Gain minus 2.80 dB cable loss for 17 ft cable: 0.20 (dBi) S=1.00 (mW/cm^2) P=253.5129 (mW) G=1.05 (numeric) R =4.60(cm) Tx Frequency: 848.80 (MHz) Source Based Time Averaged Power at Antenna Input Terminal: 26.35 (dBm) 3 dBi Antenna Gain minus 1.89 dB cable loss for 17 ft cable: 1.11 (dBi) S=0.57 (mW/cm^2) P=431.5191 (mW) G=1.29 (numeric) R =8.85(cm) © 2004 Celltech Labs Inc. ITRONIX CORPORATION FCC ID: KBCIX260MPIGC82 (Model: IX260) 4 of 4 Rugged Laptop PC with Sony Ericsson GSM Modem & co-located Cisco WLAN Antenna Types: External Dipole, Internal 802.11b Surface-Mount, Mobile Vehicle-Mount Test Report S/N: 031004-488KBC Test Type: MPE Evaluation 2.1 Calculation to determine MPE 3.1 MPE Limits According to FCC 47 CFR 1.1310: The criteria listed in the following table shall be used to evaluate th…
