KBCIX260PNL3BM390RUGGED LAPTOP PC W/ MOBITEX MODEM & 802.11b/g WLAN

General Dynamics Itronix Corporation

Click to zoom

Application Details

Equipment Class: TNB - Licensed Non-Broadcast Station Transmitter
Date of Grant: Nov 18, 2004
Application Purpose: Original Equipment
Date of Application: Nov 18, 2004
Equipment Note: RUGGED LAPTOP PC W/ MOBITEX MODEM & 802.11b/g WLAN
Frequency Range: 896.00000000 - 901.00000000
Company: General Dynamics Itronix Corporation
Country: United States

Documents & Files

Select a file to view

ID Label/Location Info

Internal Photos

↗

Test Report

↗

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

Getting Started Congratulations on your purchase of the Itronix GoBook III computer! Your new GoBook III features the most innovative advances in portable computing technology. It combines state-of-the-art ergonomics with a rugged, durable architecture to provide you with a notebook computer that is compact, powerful, rugged and easy to use. Designed for a wide range of business and personal productivity applications, the GoBook III is an ideal choice for use in applications that require durability and performance. For maximum expandability without compromising portability, the GoBook III has a USB interface and aPC card slot. The high capacity hard disk drive provides you with plenty of storage space for multimedia files and applications. The GoBook III features a standard 87-key Nitevue® keyboard (89-key international). The high- resolution 12.1-inch touch screen LCD panel provides clear and crisp viewing with the convenience of a touch screen. This online document, GoBook III Help , contains all the information you need to set up and use your new GoBook III. It describes all the features of the GoBook III in an easy-to-read yet thorough manner. For information on printing, navigating or otherwise using GoBook III Help see How to Use This Help System. GoBook III ® Help Page 1 of 80GoBook III Help 7/5/2004file://C:\Documents%20and%20Settings\harwoodm.ITRXNT1\Local%20Settings\Temp\~h... Checklists After opening the package, carefully inspect the contents. Contact your dealer if any items are missing or appear damaged. The shipping carton should contain the following: STANDARD z The Itronix GoBook III computer z Battery z ADP-90AB or ADP-75FB AC adapter with power cord z 12.1 inch XGA display z Stylus z Shoulder Strap z GoBook III Quick Start Guide OPTIONS The following items are normally optional, but some vendors may include them in the standard package. Some items may not be available in some countries, or some vendors may choose not to carry all the items. z Floppy disk drive z CD-ROM drive z CD-RW Drive z DVD-ROM drive z Soft Handle z Media Bay Li-Ion battery pack z Hard Disk Drive Heater z LCD Heater CAUTION When purchasing any of the accessories listed above, purchase only those accessories that are approved for use with your computer. The above accessories are proprietary items. Your system vendor can obtain these approved accessories. If you use items that are not approved for use with this computer, you may cause your computer to malfunction, or to emit or receive electromagnetic radiation in excess of local regulations. For non-proprietary accessories such as PC Cards or printers, ensure that the accessor y functions properly in your computer before making the purchase. Your system vendor Page 2 of 80GoBook III Help 7/5/2004file://C:\Documents%20and%20Settings\harwoodm.ITRXNT1\Local%20Settings\Temp\~h... may be able to recommend reliable brands and models. Features High Capacity Hard Disk Drive The computer has a high capacity hard disk drive, enabling you to install your favorite programs and store large multimedia files. Full Array of Ports and Connectors Your computer includes standard ports for connecting to peripherals such as USB devices and monitors. USB ports allow you to add many types of peripherals. Large XGA LCD Your computer has a large, easy to view XGA LCD panel. Built-in Microphone and Stereo Speakers The stereo speakers and internal microphone enable you to run a variety of multimedia applications. Function Keys Function keys allow you to suspend your computer, shut the LCDs off, and give you easy control of audio and your monitor. Where to Look For Information About Your Computer This Help System describes the key elements of your computer. New users can find a simple step-by- step orientation in this chapter. About Windows For more extensive information and help about Windows go to Help and Support, found on the Start Menu. 72_0119_001 28 June 2004 © 2004 Itronix Corporation. All rights reserved. Page 3 of 80GoBook III Help 7/5/2004file://C:\Documents%20and%20Settings\harwoodm.ITRXNT1\Local%20Settings\Temp\~h... Precautions You can use your computer under a wide range of environmental conditions. However, to ensure long use and continued high performance, consider the following factors when setting up your computer: z Follow all warnings and instructions noted in this documentation and in Windows Help and Support, found on the Start Menu. z The first time you use your computer, we recommend that you carefully read the section on Power Management to familiarize yourself with some basic battery information and to ensure optimum performance z There is danger of explosion if the battery is incorrectly replaced. Replace only with the same or equivalent type recommended by the manufacturer. Dispose of used batteries according to the manufacturer's instructions. z Do not open the RAM door by yourself. z Unplug the computer from the power outlet before cleaning. Use a damp cloth for cleaning. Do not use aerosols, solvents, or strong detergents z Slots and openings in the computer case are for ventilation purposes. Do not block or cover these openings or the system could overheat z On the bottom of the GoBook III, there is a label with information on the power requirements of this system. These requirements must be followed. If you are unsure of your local power supply, consult your dealer or local Power Company z Do not step on or place anything on the power cord z If you use the computer with an extension cord, ensure that the total ampere ratings of all the devices sharing the extension do not exceed the rating of the extension cord or the rating of the wall outlet z Unless instructed, never push foreign objects into the computer through any of the slots or openings. Dangerous voltages are present, which could cause electric shock, fire, or damage sensitive components z For best results, use a power strip with a built-in surge protector. Do not use inferior extensi…

Text truncated - open the document above for the full version.

Cover Letter(s)

801 S. STEVENS STREET SPOKANE, WA 99204 509.624.6600 800.441.1309 FAX 509.626.4203 www.itronix.com November 15, 2004 Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 Re: Itronix Corporation FCC ID: KBCIX260PNL3BM390 FCC Part 90 Certification Request for Confidentiality In accordance with 0.459 of CFR 47, Itronix Corporation and Wavenet Technology Pty Ltd. hereby requests confidentiality of the Block Diagram, Schematic Diagrams, Parts List, Operational Description, and Antenna Specification exhibits for the subject application. These documents contain detailed system and equipment description and related information about the product in which Itronix Corporation and Wavenet Technology Pty. Ltd. considers to be proprietary, confidential, and a custom design and, otherwise, would not release to the general public. Since this design is a basis from which future technological products will evolve, Itronix Corporation considers that this information would be of benefit to its competitors, and that the disclosure of the information in these documents would give competitors an unfair advantage in the market. Sincerely,

External Photos

Internal Photos

© 2004 Celltech Labs Inc. ITRONIX CORPORATION FCC ID: KBCIX260PNL3BM390 (Model: IX260PNL3BM390) IX260+ Rugged Laptop PC with Wavenet Mobitex Radio Modem & Co-located Senao WLAN Celltech Project No.: 566 INTERNAL DUT PHOTOGRAPHS Cradle Contact Board © 2004 Celltech Labs Inc. ITRONIX CORPORATION FCC ID: KBCIX260PNL3BM390 (Model: IX260PNL3BM390) IX260+ Rugged Laptop PC with Wavenet Mobitex Radio Modem & Co-located Senao WLAN Celltech Project No.: 566 INTERNAL DUT PHOTOGRAPHS with Wavenet BM3-900M Mobitex Radio Modem © 2004 Celltech Labs Inc. ITRONIX CORPORATION FCC ID: KBCIX260PNL3BM390 (Model: IX260PNL3BM390) IX260+ Rugged Laptop PC with Wavenet Mobitex Radio Modem & Co-located Senao WLAN Celltech Project No.: 566 INTERNAL DUT PHOTOGRAPHS with Wavenet BM3-900M Mobitex Radio Modem © 2004 Celltech Labs Inc. ITRONIX CORPORATION FCC ID: KBCIX260PNL3BM390 (Model: IX260PNL3BM390) IX260+ Rugged Laptop PC with Wavenet Mobitex Radio Modem & Co-located Senao WLAN Celltech Project No.: 566 INTERNAL DUT PHOTOGRAPHS with Wavenet BM3-900M Mobitex Radio Modem © 2004 Celltech Labs Inc. ITRONIX CORPORATION FCC ID: KBCIX260PNL3BM390 (Model: IX260PNL3BM390) IX260+ Rugged Laptop PC with Wavenet Mobitex Radio Modem & Co-located Senao WLAN Celltech Project No.: 566 INTERNAL DUT PHOTOGRAPHS with Wavenet BM3-900M Mobitex Radio Modem © 2004 Celltech Labs Inc. ITRONIX CORPORATION FCC ID: KBCIX260PNL3BM390 (Model: IX260PNL3BM390) IX260+ Rugged Laptop PC with Wavenet Mobitex Radio Modem & Co-located Senao WLAN Celltech Project No.: 566 INTERNAL DUT PHOTOGRAPHS Wavenet BM3-900M Mobitex Radio Modem © 2004 Celltech Labs Inc. ITRONIX CORPORATION FCC ID: KBCIX260PNL3BM390 (Model: IX260PNL3BM390) IX260+ Rugged Laptop PC with Wavenet Mobitex Radio Modem & Co-located Senao WLAN Celltech Project No.: 566 INTERNAL DUT PHOTOGRAPHS Wavenet BM3-900M Mobitex Radio Modem © 2004 Celltech Labs Inc. ITRONIX CORPORATION FCC ID: KBCIX260PNL3BM390 (Model: IX260PNL3BM390) IX260+ Rugged Laptop PC with Wavenet Mobitex Radio Modem & Co-located Senao WLAN Celltech Project No.: 566 INTERNAL DUT PHOTOGRAPHS Wavenet BM3-900M Mobitex Radio Modem © 2004 Celltech Labs Inc. ITRONIX CORPORATION FCC ID: KBCIX260PNL3BM390 (Model: IX260PNL3BM390) IX260+ Rugged Laptop PC with Wavenet Mobitex Radio Modem & Co-located Senao WLAN Celltech Project No.: 566 INTERNAL DUT PHOTOGRAPHS Wavenet BM3-900M Mobitex Radio Modem © 2004 Celltech Labs Inc. ITRONIX CORPORATION FCC ID: KBCIX260PNL3BM390 (Model: IX260PNL3BM390) IX260+ Rugged Laptop PC with Wavenet Mobitex Radio Modem & Co-located Senao WLAN Celltech Project No.: 566 Senao NL-3054MP 802.11b/g WLAN INTERNAL DUT PHOTOGRAPHS Rugged Laptop PC with Senao NL-3054MP WLAN © 2004 Celltech Labs Inc. ITRONIX CORPORATION FCC ID: KBCIX260PNL3BM390 (Model: IX260PNL3BM390) IX260+ Rugged Laptop PC with Wavenet Mobitex Radio Modem & Co-located Senao WLAN Celltech Project No.: 566 INTERNAL DUT PHOTOGRAPHS Rugged Laptop PC with Senao NL-3054MP WLAN © 2004 Celltech Labs Inc. ITRONIX CORPORATION FCC ID: KBCIX260PNL3BM390 (Model: IX260PNL3BM390) IX260+ Rugged Laptop PC with Wavenet Mobitex Radio Modem & Co-located Senao WLAN Celltech Project No.: 566 INTERNAL DUT PHOTOGRAPHS Rugged Laptop PC with Senao NL-3054MP WLAN © 2004 Celltech Labs Inc. ITRONIX CORPORATION FCC ID: KBCIX260PNL3BM390 (Model: IX260PNL3BM390) IX260+ Rugged Laptop PC with Wavenet Mobitex Radio Modem & Co-located Senao WLAN Celltech Project No.: 566 INTERNAL DUT PHOTOGRAPHS Senao NL-3054MP WLAN © 2004 Celltech Labs Inc. ITRONIX CORPORATION FCC ID: KBCIX260PNL3BM390 (Model: IX260PNL3BM390) IX260+ Rugged Laptop PC with Wavenet Mobitex Radio Modem & Co-located Senao WLAN Celltech Project No.: 566 INTERNAL DUT PHOTOGRAPHS Senao NL-3054MP WLAN © 2004 Celltech Labs Inc. ITRONIX CORPORATION FCC ID: KBCIX260PNL3BM390 (Model: IX260PNL3BM390) IX260+ Rugged Laptop PC with Wavenet Mobitex Radio Modem & Co-located Senao WLAN Celltech Project No.: 566 INTERNAL DUT PHOTOGRAPHS Dual Internal Antennas for Senao NL-3054MP WLAN Primary Antenna (Transmit and Receive) Auxiliary Antenna (Receive only) © 2004 Celltech Labs Inc. ITRONIX CORPORATION FCC ID: KBCIX260PNL3BM390 (Model: IX260PNL3BM390) IX260+ Rugged Laptop PC with Wavenet Mobitex Radio Modem & Co-located Senao WLAN Celltech Project No.: 566 Primary Antenna (Transmit and Receive) Auxiliary Antenna (Receive only) INTERNAL DUT PHOTOGRAPHS Dual Internal Antennas for Senao NL-3054MP WLAN © 2004 Celltech Labs Inc. ITRONIX CORPORATION FCC ID: KBCIX260PNL3BM390 (Model: IX260PNL3BM390) IX260+ Rugged Laptop PC with Wavenet Mobitex Radio Modem & Co-located Senao WLAN Celltech Project No.: 566 INTERNAL DUT PHOTOGRAPHS Dual Internal Antennas for Senao NL-3054MP WLAN Primary Antenna (Transmit & Receive) Auxiliary Antenna (Receive only)

Test Report

FCC PARTS 2 & 90, SUBPART I, NON-BROADCAST RADIO TRANSCEIVERS Page 11 Boomer-III Mobitex Wireless OEM Modem Module, Model BM3-900M FCC ID: PQS-BM3900M ULTRATECH GROUP OF LABS File #: WTP015QFCC90 3000 Bristol Circle, Oakville, Ontario, Canada L6H 6G4 October 01, 2003 Tel. #: 905-829-1570, Fax. #: 905-829-8050, Email: [email protected] , Website: http://www.ultratech-labs.com All test results contained in this engineering test report are traceable to National Institute of Standards and Technology (NIST) 6.4.1. RF power output @ FCC 2.1046 & 90.205 6.4.2. Limits @ FCC 90.205. Please refer to FCC CFR 47, Part 90, Subpart I, Para. 90.205 for specification details. Please refer to FCC CFR 47, Paragraph 90.205 for power limit for frequency band: EUT’s Operating Frequency Band (MHz) FCC Allowable Frequency band (MHz) FCC Rules FCC Maximum ERP Limits (Watts) 896-901 MHz 896-901 90.635 100 Watts peak ERP for mobile station. 6.4.3. Method of Measurements Refer to Exhibit 8, § 8.1 (Conducted) and 8.2 (Radiated) of this report for measurement details 6.4.4. Test Equipment List Test Instruments Manufacturer Model No. Serial No. Frequency Range Attenuator(s) Bird ... ... DC – 22 GHz Attenuator(s) Weinschel Corp 24-20-34 BJ2357 DC – 8.5 GHz Power Meter Hewlett Packard 436A 1725A0224 9 10 kHz – 50 GHz, sensor dependent Power Sensor Hewlett Packard 8481A 2702A6898 3 10 MHz – 18 GHz 6.4.5. Test Arrangement • Power at RF Power Output Terminals Transmitter 20 dB Atttenuator Power Sensor 436A Power Meter FCC PARTS 2 & 90, SUBPART I, NON-BROADCAST RADIO TRANSCEIVERS Page 12 Boomer-III Mobitex Wireless OEM Modem Module, Model BM3-900M FCC ID: PQS-BM3900M ULTRATECH GROUP OF LABS File #: WTP015QFCC90 3000 Bristol Circle, Oakville, Ontario, Canada L6H 6G4 October 01, 2003 Tel. #: 905-829-1570, Fax. #: 905-829-8050, Email: [email protected] , Website: http://www.ultratech-labs.com All test results contained in this engineering test report are traceable to National Institute of Standards and Technology (NIST) 6.4.6. Test Data : Conducted Power High Power Setting: Transmitter Channel Output Fundamental Frequency (MHz) Measured (Peak) Power (dBm) Power Rating (dBm) Lowest 896.0 33.29 33.0 Middle 898.5 33.29 33.0 Highest 901.0 33.31 33.0 Low Power Setting: Transmitter Channel Output Fundamental Frequency (MHz) Measured (Peak) Power (dBm) Power Rating (dBm) Lowest 896.0 15.18 15.0 Middle 898.5 15.18 15.0 Highest 901.0 15.18 15.0

Test Report

FCC PARTS 2 & 90, SUBPART I, NON-BROADCAST RADIO TRANSCEIVERS Page 32 Boomer-III Mobitex Wireless OEM Modem Module, Model BM3-900M FCC ID: PQS-BM3900M ULTRATECH GROUP OF LABS File #: WTP015QFCC90 3000 Bristol Circle, Oakville, Ontario, Canada L6H 6G4 October 01, 2003 Tel. #: 905-829-1570, Fax. #: 905-829-8050, Email: [email protected] , Website: http://www.ultratech-labs.com All test results contained in this engineering test report are traceable to National Institute of Standards and Technology (NIST) 6.9. TRANSMITTER ANTENNA POWER SPURIOUS/HARMONIC CONDUCTED EMISSIONS @ FCC 90.210 6.9.1. Limits @ 90.210 Emissions shall be attenuated below the mean output power of the transmitter as follows: Frequency Band Frequency Range Attenuation Limit (dBc) 896-901MHz 10 MHz to Lowest frequency of the radio to 10 th harmonic of the highest frequency of the radio 50+10*log(P) or -20 dBm or 70 dBc whichever is less 6.9.2. Method of Measurements Refer to Exhibit 8 § 8.5 of this report for measurement details 6.9.3. Test Equipment List Test Instruments Manufacturer Model No. Serial No. Frequency Range EMI Receiver/ EMI Receiver Hewlett Packard HP 8593EM 3412A00103 9 kHz – 26.5 GHz Attenuator(s) Bird .. ... DC – 22 GHz Audio Oscillator Hewlett Packard HP 204C 0989A08798 DC to 1.2 MHz Highpass Filter, Microphase Microphase CR220HID IITI11000AC Cut-off Frequency at 600 MHz, 1.3 GHz or 4 GHz 6.9.4. Test Arrangement TRANSMITTER 20 dB ATTENUATOR EMI RECEIVER HIGHPASS FILTER FCC PARTS 2 & 90, SUBPART I, NON-BROADCAST RADIO TRANSCEIVERS Page 33 Boomer-III Mobitex Wireless OEM Modem Module, Model BM3-900M FCC ID: PQS-BM3900M ULTRATECH GROUP OF LABS File #: WTP015QFCC90 3000 Bristol Circle, Oakville, Ontario, Canada L6H 6G4 October 01, 2003 Tel. #: 905-829-1570, Fax. #: 905-829-8050, Email: [email protected] , Website: http://www.ultratech-labs.com All test results contained in this engineering test report are traceable to National Institute of Standards and Technology (NIST) 6.9.5. Test Data 6.9.5.1. High Power Setting (2 Watts) at Lowest Frequency (896 MHz) Fundamental Frequency: 896 MHz RF Output Power: 33.3 dBm (Conducted) Modulation: 2 level 8kbps GMSK FREQUENCY TRANSMITTER ANTENNA CONDUCTED EMISSIONS LIMIT MARGIN PASS/ (MHz) (dBm) (dBc) (dBc) (dB) FAIL 4480.9 -37.4 -70.7 -53.3 -17.4 PASS 5382.7 -27.8 -61.1 -53.3 -7.8 PASS 6266.5 -31.6 -64.9 -53.3 -11.6 PASS • ** The emissions were scanned from 10 MHz to 10 GHz and all emissions within 20 dB below the limits were recorded. • Please refer to plots # 11 & 12 for details of measurement. 6.9.5.2. High Power Setting (2 Watts) at Middle Frequency (898.5 MHz) Fundamental Frequency: 898.5 MHz RF Output Power: 33.3 dBm (Conducted) Modulation: 2 level 8kbps GMSK FREQUENCY TRANSMITTER ANTENNA CONDUCTED EMISSIONS LIMIT MARGIN PASS/ (MHz) (dBm) (dBc) (dBc) (dB) FAIL 4499.0 -37.4 -70.7 -53.3 -17.4 PASS 5382.7 -28.0 -61.3 -53.3 -8.0 PASS 6284.5 -31.5 -64.8 -53.3 -11.5 PASS • ** The emissions were scanned from 10 MHz to 10 GHz and all emissions within 20 dB below the limits were recorded. • Please refer to plots # 13 & 14 for details of measurement. 6.9.5.3. High Power Setting (2 Watts) at Highest Frequency (901 MHz) Fundamental Frequency: 901 MHz RF Output Power: 33.3 dBm (Conducted) Modulation: 2 level 8kbps GMSK FREQUENCY TRANSMITTER ANTENNA CONDUCTED EMISSIONS LIMIT MARGIN PASS/ (MHz) (dBm) (dBc) (dBc) (dB) FAIL 4499.0 -37.7 -71.0 -53.3 -17.7 PASS 5400.8 -27.6 -60.9 -53.3 -7.6 PASS 6302.6 -31.6 -64.9 -53.3 -11.6 PASS • ** The emissions were scanned from 10 MHz to 10 GHz and all emissions within 20 dB below the limits were recorded. • Please refer to plots # 15 & 16 for details of measurement. FCC PARTS 2 & 90, SUBPART I, NON-BROADCAST RADIO TRANSCEIVERS Page 34 Boomer-III Mobitex Wireless OEM Modem Module, Model BM3-900M FCC ID: PQS-BM3900M ULTRATECH GROUP OF LABS File #: WTP015QFCC90 3000 Bristol Circle, Oakville, Ontario, Canada L6H 6G4 October 01, 2003 Tel. #: 905-829-1570, Fax. #: 905-829-8050, Email: [email protected] , Website: http://www.ultratech-labs.com All test results contained in this engineering test report are traceable to National Institute of Standards and Technology (NIST) 6.9.5.4. Low Power Setting (0.033 Watts) at Lowest Frequency (896 MHz) Fundamental Frequency: 896 MHz RF Output Power: 15.2 dBm (Conducted) Modulation: 2 level 8kbps GMSK FREQUENCY TRANSMITTER ANTENNA CONDUCTED EMISSIONS LIMIT MARGIN PASS/ (MHz) (dBm) (dBc) (dBc) (dB) FAIL 1793.6 -42.6 -57.8 -35.2 -22.6 PASS 6266.5 -38.1 -53.3 -35.2 -18.1 PASS • ** The emissions were scanned from 10 MHz to 10 GHz and all emissions within 20 dB below the limits were recorded. • Please refer to plots # 17 & 18 for details of measurement. 6.9.5.5. Low Power Setting (0.033 Watts) at Middle Frequency (898.5 MHz) Fundamental Frequency: 898.5 MHz RF Output Power: 15.2 dBm (Conducted) Modulation: 2 level 8kbps GMSK FREQUENCY TRANSMITTER ANTENNA CONDUCTED EMISSIONS LIMIT MARGIN PASS/ (MHz) (dBm) (dBc) (dBc) (dB) FAIL 1793.6 -41.7 -56.9 -35.2 -21.7 PASS 6284.5 -38.3 -53.5 -35.2 -18.3 PASS • ** The emissions were scanned from 10 MHz to 10 GHz and all emissions within 20 dB below the limits were recorded. • Please refer to plots # 19 & 20 for details of measurement. 6.9.5.6. Low Power Setting (0.033 Watts) at Highest Frequency (901 MHz) Fundamental Frequency: 901 MHz RF Output Power: 15.2 dBm (Conducted) Modulation: 2 level 8kbps GMSK FREQUENCY TRANSMITTER ANTENNA CONDUCTED EMISSIONS LIMIT MARGIN PASS/ (MHz) (dBm) (dBc) (dBc) (dB) FAIL 1793.6 -40.5 -55.7 -35.2 -20.5 PASS 6302.6 -39.1 -54.3 -35.2 -19.1 PASS • ** The emissions were scanned from 10 MHz to 10 GHz and all emissions within 20 dB below the limits were recorded. • Please refer to plots # 21 & 22 for details of measurement. FCC PARTS 2 & 90, SUBPART I, NON-BROADCAST RADIO TRANSCEIVERS Page 35 Boomer-III Mobitex Wireless OEM Modem Module, Model BM3-900M FCC ID: PQS-BM3900M ULTRATECH GROUP OF LABS File #: WTP015QFCC90 3000 Bristol Cir…

Text truncated - open the document above for the full version.

Test Report

FCC PARTS 2 & 90, SUBPART I, NON-BROADCAST RADIO TRANSCEIVERS Page 17 Boomer-III Mobitex Wireless OEM Modem Module, Model BM3-900M FCC ID: PQS-BM3900M ULTRATECH GROUP OF LABS File #: WTP015QFCC90 3000 Bristol Circle, Oakville, Ontario, Canada L6H 6G4 October 01, 2003 Tel. #: 905-829-1570, Fax. #: 905-829-8050, Email: [email protected] , Website: http://www.ultratech-labs.com All test results contained in this engineering test report are traceable to National Institute of Standards and Technology (NIST) 6.6. FREQUENCY STABILITY @ FCC 2.1055 & 90.213 6.6.1. Limits @ FCC 90.213 Please refer to FCC CFR 47, Part 90, Subpart I, Para. 90.213 for specification details. FREQUENCY RANGE (MHz) FIXED & BASE STATIONS (ppm) MOBILE STATIONS (ppm) < 2 W 896-901 0.1 1.5 6.6.2. Method of Measurements Refer to Exhibit 8, § 8.3 of this report for measurement details 6.6.3. Test Equipment List Test Instruments Manufacturer Model No. Serial No. Frequency Range EMI Receiver/ EMI Receiver Hewlett Packard HP 8593EM 3412A00103 9 kHz – 26.5 GHz Attenuator(s) Bird .. ... DC – 22 GHz Temperature & Humidity Chamber Tenney T5 9723B -40 o to +60 o C range 6.6.4. Test Arrangement TRANSMITTER 20 dB ATTENUATOR SPECTRUM ANLYZER Environmental Chamber FCC PARTS 2 & 90, SUBPART I, NON-BROADCAST RADIO TRANSCEIVERS Page 18 Boomer-III Mobitex Wireless OEM Modem Module, Model BM3-900M FCC ID: PQS-BM3900M ULTRATECH GROUP OF LABS File #: WTP015QFCC90 3000 Bristol Circle, Oakville, Ontario, Canada L6H 6G4 October 01, 2003 Tel. #: 905-829-1570, Fax. #: 905-829-8050, Email: [email protected] , Website: http://www.ultratech-labs.com All test results contained in this engineering test report are traceable to National Institute of Standards and Technology (NIST) 6.6.5. Test Data Product Name: Model No.: Boomer-III Mobitex Wireless OEM Modem Module BM3-900M Center Frequency: 896 MHz Full Power Level: 33 dBm Frequency Tolerance Limit: + 1.5 ppm or +1344 Hz at 896 MHz Max. Frequency Tolerance Measured: -0.73 ppm or -662 Hz Input Voltage Rating: 3.8 VDC CENTER FREQUENCY & RF POWER OUTPUT VARIATION Ambient Temperature Supply Voltage (Nominal) 3.8 Volts Supply Voltage (85% of Nominal) 3.2 Volts Supply Voltage (115% of Nominal) 4.4 Volts ( o C) Hz Hz Hz -30 515 N/A N/A -25 233 N/A N/A -20 -304 N/A N/A -15 -614 N/A N/A -10 -662 N/A N/A -5 -586 N/A N/A 0 -456 N/A N/A +5 -273 N/A N/A +10 -166 N/A N/A +15 -79 N/A N/A +20 -6 +14 +22 +25 -7 N/A N/A +30 -56 N/A N/A +35 -75 N/A N/A +45 -64 N/A N/A +50 -3 N/A N/A +55 55 N/A N/A +60 185 N/A N/A

Test Report

© 2004 Celltech Labs Inc. ITRONIX CORPORATION FCC ID: KBCIX260PNL3BM390 (Model: IX260PNL3BM390) 1 of 3 Rugged Laptop PC with Wavenet Mobitex Radio Modem and co-located Senao WLAN Antenna Types Evaluated: Swivel Dipole and (3) Vehicle-Mount (with Vehicle Cradle) Test Report S/N: 100504KBC-T566-M90M Test Type: MPE Evaluation This mobile device is compliant with localized Maximum Permissible Exposure (MPE) for the Uncontrolled Exposure / General Population limits specified in FCC 47 CFR §1.1310, in accordance with the requirements of FCC OET Bulletin 65, Edition 97-01, ANSI / IEEE C95.1-1992, and ANSI / IEEE C95.3-1992. I attest to the accuracy of data. All measurements and/or calculations were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. This evaluation report shall not be reproduced partially, or in full, without the prior written approval of Celltech Labs Inc. The results and statements contained in this report pertain only to the device(s) evaluated. _____________________ Duane M. Friesen EMC Manager Celltech Labs Inc. DECLARATION OF COMPLIANCE MPE EVALUATION REPORT Test Lab CELLTECH LABS INC. 1955 Moss Court Kelowna, B.C. Canada V1Y 9L3 Phone: 250-448-7047 Fax: 250-448-7046 e-mail: [email protected] web site: www.celltechlabs.com Applicant Information ITRONIX CORPORATION 801 South Stevens Street Spokane, WA 99204 United States FCC Rule Part(s): 47 CFR §90; 15.247; §2.1091; §1.1310 FCC Classification: Licensed Non-Broadcast Station Transmitter (TNB) Device Description: Rugged Laptop PC with Wavenet BM3-900M Mobitex Radio Modem (co-located with Senao NL-3054MP 802.11b/g WLAN & Internal Antenna) with Swivel Dipole Antenna, (3) Vehicle-Mount Antennas, & Vehicle Cradle FCC IDENTIFER: KBCIX260PNL3BM390 Model(s): IX260PNL3BM390 Tx Frequency Range(s): 896.0 - 901.0 MHz Max. RF Conducted Power: 33.2 dBm (Peak) Source-Based Time-Av. Power: 28.0 dBm (Max. Peak Conducted) Max. Duty Cycle Evaluated: 30 % (Source-Based Time-Averaged) Antenna Type(s): Itronix IX260+ External Swivel Dipole MaxRad Z563 Vehicle-Mount - Unity Gain MaxRad Z567 Vehicle-Mount - 5 dB Gain MaxRad Z573 Vehicle-Mount - 5 dB Gain © 2004 Celltech Labs Inc. ITRONIX CORPORATION FCC ID: KBCIX260PNL3BM390 (Model: IX260PNL3BM390) 2 of 3 Rugged Laptop PC with Wavenet Mobitex Radio Modem and co-located Senao WLAN Antenna Types Evaluated: Swivel Dipole and (3) Vehicle-Mount (with Vehicle Cradle) Test Report S/N: 100504KBC-T566-M90M Test Type: MPE Evaluation 1. Itronix IX260+ Swivel Dipole Antenna 2. MaxRad Z563 Unity Gain Vehicle Antenna 3. MaxRad Z567 & Z573 5 dBd Gain Vehicle Antennas Z567 Z573 1.1 MPE Calculation Data Z563 Itronix IX260+ Swivel Dipole Antenna Tx Frequency: 900.0 (MHz) Source-Based Time-Averaged Power at Antenna Input Terminal: 28.0 (dBm) Antenna gain: 2.6 (dBi) S=0.60 (mW/cm^2) P=630.9573 (mW) G=1.82 (numeric) R =12.34(cm) 0.228170434 S (mw/cm^2) at 20cm Tx Frequency: 900.0 (MHz) Source-Based Time-Averaged Power at Antenna Input Terminal: 28.0 (dBm) Antenna Gain (including 1.89 dB cable loss for 17ft cable): 0.25 (dBi) S=0.60 (mW/cm^2) P=630.9573 (mW) G=1.06 (numeric) R =9.41(cm) 0.132818744 S (mw/cm^2) at 20cm Tx Frequency: 900.0 (MHz) Source-Based Time-Averaged Power at Antenna Input Terminal: 28.0 (dBm) Antenna Gain (including 1.89 dB cable loss for 17ft cable): 5.25 (dBi) S=0.60 (mW/cm^2) P=630.9573 (mW) G=3.35 (numeric) R =16.74(cm) 0.420009746 S (mw/cm^2) at 20cm © 2004 Celltech Labs Inc. ITRONIX CORPORATION FCC ID: KBCIX260PNL3BM390 (Model: IX260PNL3BM390) 3 of 3 Rugged Laptop PC with Wavenet Mobitex Radio Modem and co-located Senao WLAN Antenna Types Evaluated: Swivel Dipole and (3) Vehicle-Mount (with Vehicle Cradle) Test Report S/N: 100504KBC-T566-M90M Test Type: MPE Evaluation According to FCC 47 CFR 1.1310: The criteria listed in the following table shall be used to evaluate the environmental impact of human exposure to radio frequency (RF) radiation as specified in 1.1307(b). The Maximum Permissible Exposure (MPE) limit for the frequency range in the Mobitex band (900MHz) is 0.6 mW/cm^ 2 (F/1500) for the General Population / Uncontrolled Exposure environment. The data in this report demonstrates that the Itronix Corporation Model: IX260PNL3BM390 Rugged Laptop PC FCC ID: KBCIX260PNL3BM390, with Wavenet BM3- 900M Mobitex Radio Modem utilizing an external swivel dipole antenna and (3) vehicle-mount antennas with vehicle cradle, complies with the Maximum Permissible Exposure (MPE) requirements specified in FCC §2.1091, §1.1310, and OET Bulletin 65 (Edition 97-01), for the General Population / Uncontrolled Exposure enviro…

Text truncated - open the document above for the full version.

Contact Information

Applicant

Ray Garcia(Agency Manager)

[email protected]954.846.3350Fax: 954.846.3392

Test Firm

Celltech Labs Inc.Ben Hewson

[email protected]250-765-7650Fax: 250-765-7645

Technical Specifications

#	Rule Parts	Frequency Range	Power Output	Emission	Tolerance
1	90	896 MHz - 901 MHz	2.09 W	12K0F1D	0.0001500000 %

Confidentiality

Long Term

Grant Notes

Power listed is conducted. The antenna installation and operating configurations of this transmitter, including any applicable source-based time-averaging duty factor, antenna gain and cable loss must satisfy MPE categorical Exclusion Requirements of �2.1091. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. Users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance.
