KBCXC6250RIM801DLaptop PC with RIM 801D ARDIS Radio Module

General Dynamics Itronix Corporation

Click to zoom

Application Details

Equipment Class: TNB - Licensed Non-Broadcast Station Transmitter
Date of Grant: Sep 14, 2000
Application Purpose: Original Equipment
Date of Application: Aug 23, 2000
Equipment Note: Laptop PC with RIM 801D ARDIS Radio Module
Frequency Range: 806.00000000 - 821.00000000
Company: General Dynamics Itronix Corporation
Country: United States

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

Integrator’s Guide RIM 801D OEM Radio Modem version 1.0 RIM 801D OEM Radio Modem Integrator’s Guide Last Revised: 22 February 1999 Part Number: MAT-01769-002 Rev. 001 ©1998, RESEARCH IN MOTION LIMITED Research In Motion and RIM are registered trademarks of Research In Motion Limited. DataTAC and RD-LAP are trademarks of Motorola. MS-DOS is a registered trademark, and Windows is a trademark, of Microsoft Corporation. Velcro is a registered trademark of Velcro Canada Incorporated. Scotchmate and Dual Lock are trademarks of 3M Corporation. Warning: This document is for the use of licensed users only. Any unauthorized copying, distribution or disclosure of information is a violation of copyright laws. While every effort has been made to ensure technical accuracy, information in this document is subject to change without notice and does not represent a commitment on the part of Research In Motion Limited. Research In Motion 295 Phillip Street Waterloo, Ontario Canada N2L 3W8 tel. (519) 888-7465 fax (519) 888-6906 Internet:[email protected] Web site: www.rim.net Printed in CanadaAM0598R801D-int DATATAC Interface, specified DataTAC Open Protocol Specification 970.0775R1 FCC Compliance Statement (USA) FCC Class B Part 15 This device complies with Part 15 of FCC Rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference, and 2. This device must accept any interference received, including interference that may cause undesired operation. Warning Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate this equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the manufacturer’s instructions,maycauseharmfulinterferencetoradio communications. There is no guarantee, however, that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Re-orient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help. Contents FCC Compliance Statement (USA).......................................... i Figures, tables and equations ................................................. v About this guide..................................................................... vii 1.Introduction ................................................................. 1 Radio modem features .....................................................................1 DataTAC network technology .........................................................3 2.Mechanical specifications and mounting needs........ 5 Environmental properties ................................................................5 Physical properties ..........................................................................6 Mounting the RIM 801D .................................................................8 3.Power requirements .................................................. 11 Load specifications........................................................................11 Automotive supplies ......................................................................13 Rechargeable batteries...................................................................13 Single use batteries ........................................................................14 Plug-in supplies .............................................................................15 Connecting the power source ........................................................16 4.Serial interface specification .................................... 17 Signal specifications (Standard 5V interface) ...............................17 Connecting the serial cable............................................................18 Detailed pin description.................................................................19 Turning the radio ON ....................................................................23 Turning the radio OFF...................................................................23 5.Antenna integration .................................................. 25 Antenna requirements....................................................................25 Positioning the antenna..................................................................27 Antenna cabling.............................................................................28 Shielding........................................................................................30 6.Protocol support ........................................................ 33 Service Data Units (SDUs)........................................................... 34 NCL Protocol ............................................................................... 35 Radio Access Protocol (RAP) ...................................................... 35 Summary....................................................................................... 41 7.Interfacing and controlling the RIM 801D ............. 43 Interfacing to an RS232 device..................................................... 43 Controlling the RIM 801D ........................................................... 44 Serial port interface ...................................................................... 44 Specifications ....…

Text truncated - open the document above for the full version.

Users Manual

X-C 6250 Pro User’s Manual ii X-C 6250 Pro Users Manual 79-0003-003 22 October 1999 Identification X-C 6250 Pro Users Manual October 1999 · Revision 003 Copyright Notice © Copyright 1999 Itronix Corporation. All rights reserved. No part of this document may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any other language or computer language in whole or in part, in any form or by any means, whether it be electronic, mechanical, magnetic, optical, manual, or otherwise, without the prior written consent of Itronix Corporation, South 801 Stevens Street, Spokane, Washington 99204. Disclaimer This document is printed in the U.S.A. Itronix Corporation reserves the right to revise the manual and make periodic changes to the content without a direct or inferred obligation to Itronix to notify any person of such revision or changes. Itronix Corporation does not assume responsibility for the use of this manual, nor for any patent infringements or other rights or third parties who may use the manual. This document contains valuable trade secrets and proprietary information of Itronix Corporation. This product is available for purchase under the terms of the Itronix Hardware Purchase and Software License Agreement. Itronix hardware products may be reconditioned, or be manufactured from parts and components that may be new, used, rebuilt, or recycled and in some cases, the hardware product may not be new and may have been previously installed. In any event, Itronix warranty terms apply. Trademark Notice Itronix is a registered trademark of Itronix Corporation. Microsoft, MS, Windows, and MS-DOS are registered trademarks of Microsoft Corporation. IBM is a trademark of International Business Machines Corporation. iii 79-0003-003 22 October 1999 Compliance Statements The X-C 6250 Pro computer has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: •Reorient or relocate the receiving antenna. •Increase the separation between the equipment and receiver. •Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. •Consult the dealer or an experienced radio/TV technician for help. The X-C 6250 Pro computer complies with Part 68 of the FCC Rules. On the bottom of this equipment is a label that contains, among other information, the FCC registration number and ringer equivalence number (REN) for this equipment. If requested, this information must be provided to the telephone company. The REN is used to determine the quantity of devices which may be connected to the telephone line. Excessive RENs on the telephone line may result in the devices not ringing in response to an incoming call. In most, but not all areas, the sum of the RENs should not exceed five (5.0). To be certain of the number of devices that may be connected to the line, as determined by the total RENs, contact the telephone company to determine the maximum REN for the calling area. The X-C 6250 Pro computer may be connected to the telephone network using the RJ-11 jack provided. If this equipment causes harm to the telephone network, the telephone company will notify you in advance that temporary discontinuance of service may be required. If advance notice isnt practical, the telephone company will notify the customer as soon as possible. Also, you will be advised of your right to file a complaint with the FCC if you believe it is necessary. The telephone company may make changes in its facilities, equipment, operations, or procedures that could affect the operation of the equipment. If iv X-C 6250 Pro Users Manual 79-0003-003 22 October 1999 this happens, the telephone company will provide advance notice in order for you to make the necessary modifications in order to maintain uninterrupted service. If trouble is experienced with this equipment, please contact the equipment manufacturer for repair and/or warranty information. Do not attempt repairs of this equipment yourself without obtaining manufacturer authorized parts and documentation. If the trouble is causing harm to the telephone network, the telephone company may request you remove the equipment from the network until the problem is resolved. Compliance Statement for Canada NOTICE: The Industry Canada label identifies certified equipment. This certification means that the equipment meets certain telecommunications network protective, operational and safety requirements as prescribed in the appropriate Terminal Equipment Technical Requirements document(s). The Department does not guarantee the equipment will operate to the users satisfaction. Before installing this equipment, users should ensure that it is permissible to be connected to the facilities of the local telecommunications company. The equipment must also be installed using an acceptable method of connection. The customer should be aware that compliance with the above conditions may not prevent degradation of service in some situations. Repairs to certified equipment should be made by a representative designated by the supplier. Any repairs or alterations made by the user to this equipment, or equipment malfunctions, may give the telecommunications company cause to request the user to disconnect the equipment. Users should ensu…

Text truncated - open the document above for the full version.

Cover Letter(s)

RESEARCH IN MOTION Research In Motion Limited 295 Phillip Street Waterloo, Ontario Canada N2L 3W8 +1 519 888 7465, fax +1 519 888 6906 E-mail: [email protected] Our Ref: 02400-CERT-FCC-COVER-021_modAugust 25, 2000 Federal Communication Commission Equipment Authorization Division Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21045 Reference : FCC ID : L6AR800D-15-O Subject : Letter requesting confidentiality of R800D-15-O radio modem device FCC Certification application. Pursuant to CFR 47 Chapter 1 Section 0.459, Research In Motion Limited (RIM) requests that the following identified detailed technical information regarding the R800D-15-O device be held confidential by the Federal Communication Commission (FCC) and as such be withheld from public inspection. RIM does not disclose proprietary confidential information about our products to any third parties and as such we request that the FCC does the same and forward the confidentiality acceptance letter to RIM. Our FCC submissions are considered proprietary confidential information. Pursuant to CFR 47 Chapter 1 Sections 0.457(d) and 0.457(d)(2)(i) the exhibits contain details of trade secrets and technical data that is customarily guarded from competitors and not released to the public by Research In Motion Limited. The specific parts of the Exhibits indicated in this letter are considered confidential by RIM and as such should be prevented from to public and competitors. RIM has taken necessary measures to have limited access to confidential documents only to RIM internal employees on a need-to-know basis, and have signed confidentiality agreements with employees. If the disclosure of such information is made public, it will cause serious competitive harm to RIM. Previously, none of the requested confidential Exhibits have been disclosed to third parties by RIM. The following Exhibits with specific sections described, submitted with the Form 731 Attachments should be held confidential: Exhibit Parts List/Tune Up Info Procedur.doc “DOC-01606-005”, Users.doc “DOC-1606-006” CFR 47 Section 2.983 (d) (9) - Description of operational, test, and device tune-up technical procedure and operators’ manual. CFR 47 Section 2.983(d) (10) (11)- Description of Circuitry and Devices provided for: frequency stabilizing circuitry, suppression of spurious radiation, circuits for modulation limiting, and circuits for power limiting Exhibit Operational Description CFR 47 Section 2.983 (d) (12) - Description of digital modulation format and necessary bandwidth Exhibit Parts List/Tune Up Info CFR 47 Section 2.983 (d) (12) – Modulation generation methods and circuits. Detailed diagrams of modulation format and generation methods and circuits Exhibit Operational Description CFR 47 Section 2.975 (a) (3), 2.983 (d) (6) and 2.1033 (b) (4)- Detailed system and functional description Exhibit Parts List/Tune Up Info CFR 47 Section 2.1033 (b) (4)- Detailed technical RF and power circuit description Exhibit Block Diagram CERT-01677-“R800D-15-O RADIO BLOCK”, CFR 47 Section 2.983 (d) (6)– Detailed technical radio modem block diagram Exhibit Schematics “OEM and PGR Radio for Ardis” CFR 47 Section 2.983 (d) (7) - Complete technical schematic circuit diagrams Yours truly, Masud S. Attayi, P.Eng. Senior Certification Engineer Research In Motion Limited ( 519 ) 888 – 7465 x 2442 [email protected] Our Ref: CERT-01677-022_modAugust 25, 2000 Federal Communications Commission Equipment Authorization Division Application Processing Branch 7435 Oakland Mills Rd. Columbia, Md. 21046 FCC ID:L6AR800D-15-O Subject:FCC Part 90 Certification Application for Research In Motion Limited, Model R800D-15-O This is to inform that Research In Motion is submitting the technical documentation of our radio modem Model R800D-15-O (existing FCC ID: L6AR800D-15-O) in support of the application for Certification of our integrator, Itronix, XC6250 laptop with FCC ID KBCXC6250RIM801D. The Model R800D-15-O is a radio modem intended for integration into other equipment to allow wireless data communication. All required documents in compliance with Parts 2 and 90 of the FCC Rules have been provided in the attached Exhibits. Research In Motion would like to request confidentiality as indicated in the Form 731, Item 8 and as requested in the letter Ref: CERT-01677-021_mod, under Exhibit “Covering Letters”. Please do not hesitate to call at (519) 888-7465 x2442 or email at [email protected] should you require additional information or have any questions. Yours truly, Masud S. Attayi, P.Eng. Senior Certification Engineer Research In Motion Limited ( 519 ) 888 – 7465 x 2442 [email protected]

Cover Letter(s)

Celltech Research Inc. 1955 Moss Court, Kelowna, B.C. V1Y 9L3 Canada Tel. 250-860-3130 • Fax. 250-860-3110 • [email protected] www.globuswireless.com/celltech/celltech.htm September 14, 2000 Federal Communications Commission Equipment Approval Services 7435 Oakland Mills Road Columbia, MD 21046 Attn: Andy Leimer SUBJECT: ITRONIX CORPORATION FCC ID: KBCXC6250RIM801D 731 Confirmation No.: EA98559 Correspondence Reference No.: 16092 Dear Andy, On behalf of Itronix Corporation we hereby submit the following amendment in response to your e-mail dated September 14 requesting additional information for the subject application. 1. The modem will only be operated in the 806-821 MHz frequency range in accordance with the emission mask limits specified in 90.210(g) of the FCC Rules. The modem is capable of operating up to 825MHz and therefore was tested accordingly. Please refer to the previously submitted frequency attestation statement from the applicant confirming the above. 2. Please find attached the calibration certificate and gain information for the dipole antenna used for the ERP measurements. The following is a detailed description of the ERP signal substitution measurement method used: The EUT is first placed into the field test area at 3.0 meters. The field of maximum intensity is found by rotating the EUT approximately 360 degrees and changing the height of the receive antenna from 1 to 4 meters. Both horizontal and vertical polarizations are investigated. The field strength is recorded from a calibrated spectrum analyzer for each channel being performed. The EUT is then replaced with a calibrated dipole of a well-known gain. The dipole is fed through a directional coupler and the power at the coupler port is monitored. The field of maximum intensity is found for the dipole and the power adjusted in order to read the same on the spectrum analyzer that was found for the EUT. The feed point for the dipole is then connected to a calibrated power meter and the power adjusted to read the same as the coupler port previously recorded, to account for any mismatch in impedance, which may occur at the dipole antenna. The forward power for the dipole is then determined. The actual ERP level is determined by adding the forward power and the calibrated gain of the dipole. If you have any further questions or comments, please contact the undersigned. Sincerely, Shawn McMillen General Manager Celltech Research Inc. Testing & Engineering Lab cc: Itronix Corporation

External Photos

CELLTECH RESEARCH INC. Test Report S/N: 080800-07KBC 1955 Moss Court, Kelowna Dates of Tests: August 08-09/16, 2000 B.C. V1Y 9L3 CANADA © 2000 Celltech Research Inc. ITRONIX FCC ID: KBCXC6250RIM801D Ruggedized Laptop PC with ARDIS Radio Modem CELLTECH RESEARCH INC. Test Report S/N: 080800-07KBC 1955 Moss Court, Kelowna Dates of Tests: August 08-09/16, 2000 B.C. V1Y 9L3 CANADA © 2000 Celltech Research Inc. ITRONIX FCC ID: KBCXC6250RIM801D Ruggedized Laptop PC with ARDIS Radio Modem CELLTECH RESEARCH INC. Test Report S/N: 080800-07KBC 1955 Moss Court, Kelowna Dates of Tests: August 08-09/16, 2000 B.C. V1Y 9L3 CANADA © 2000 Celltech Research Inc. ITRONIX FCC ID: KBCXC6250RIM801D Ruggedized Laptop PC with ARDIS Radio Modem

Internal Photos

RF Exposure Info

CELLTECH RESEARCH INC. Test Report S/N: 080800-07KBC 1955 Moss Court, Kelowna, Dates of Tests: August 08-09/16, 2000 B.C. V1Y 9L3 CANADA _________________________________________________________________________________________________________ © 2000 Celltech Research Inc. CERTIFICATE OF COMPLIANCE SAR EVALUATION This wireless mobile and/or portable device has been shown to be compliant for localized specific absorption rate (SAR) for uncontrolled environment/general exposure limits specified in ANSI/IEEE Std. C95.1-1992 and had been tested in accordance with the measurement procedures specified in ANSI/IEEE Std. C95.3-1999. (See test report). I attest to the accuracy of data. All measurements were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. Celltech Research Inc. certifies that no party to this application has been denied FCC benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). Shawn McMillen General Manager Celltech Research Inc. Test Lab: CELLTECH RESEARCH INC. Testing and Engineering Lab 1955 Moss Court Kelowna, B.C. V1Y 9L3 Canada Phone: 250 - 860-3130 Fax: 250 - 860-3110 Toll Free: 1-877-545-6287 e-mail: [email protected] web site: www.globuswireless.com Applicant Name: ITRONIX CORPORATION 801 South Stevens Street Spokane, WA 99204 Attn: Fred Phillips, Certification Engineer Phone: 509-742-1506 Fax: 509-626-4204 FCC ID: KBCXC6250RIM801D Model(s): XC6250PRO, XC6250+ Equipment Type: Ruggedized Laptop PC with ARDIS Radio Modem Tx Frequency Range: 806-825 MHz Rx Frequency Range: 851-870 MHz Max. RF Output Power: 1.5 Watts FCC Rule Part(s): 2.1093; ET Docket 96.326 CELLTECH RESEARCH INC. Test Report S/N: 080800-07KBC 1955 Moss Court, Kelowna, Dates of Tests: August 08-09/16, 2000 B.C. V1Y 9L3 CANADA _________________________________________________________________________________________________________ © 2000 Celltech Research Inc. TABLE OF CONTENTS 1.0 INTRODUCTION.................................................................. 1 2.0 DESCRIPTION OF EUT.......................................................... 1 3.0 SAR MEASUREMENT SYSTEM ............................................. 2 4.0 MEASUREMENT SUMMARY.................................................. 3 4.1 SAR LIMITS........................................................................ 3 4.2 DETAILS OF SAR EVALUATION........................................... 4 4.3 EVALUATION PROCEDURES................................................. 5 a: (i) Body-worn .................................................................. 5.0 SYSTEM VALIDATION.......................................................... 5 6.0 SIMULATED EQUIVALENT TISSUES...................................... 6 6.1 TISSUE PARAMETERS......................................................... 6 7.1 SYSTEM SPECIFICATIONS.................................................... 7 8.0 TEST EQUIPMENT LIST........................................................ 8 9.0 MEASUREMENT UNCERTAINTIES........................................ 9 10.0 REFERENCES...................................................................... 10 APPENDIX A - SAR MEASUREMENT DATA........................................ 11 APPENDIX B - DIPOLE VALIDATION................................................ 12 APPENDIX C - PROBE CALIBRATION............................................... 13 APPENDIX D - TEST SETUP PHOTOGRAPHS..................................... 14 CELLTECH RESEARCH INC. Test Report S/N: 080800-07KBC 1955 Moss Court, Kelowna, Dates of Tests: August 08-09/16, 2000 B.C. V1Y 9L3 CANADA _________________________________________________________________________________________________________ © 2000 Celltech Research Inc. ITRONIX FCC ID: KBCXC6250RIM801D 1 Ruggedized Laptop PC with ARDIS Radio Modem 1.0 INTRODUCTION This measurement report is designed to show compliance of the Itronix Model: XC6250 Rugged Notebook PC with RIM 801D Wireless Radio Modem FCC ID: KBCXC6250RIM801D with FCC Part 2, 1093, ET Docket 96-326 Rules for mobile and portable devices. The test procedures, as described in American National Standards Institute C95.1 - 1992 (1), FCC OET Bulletin 65–1997 were employed. A description of the product and operating configuration, detailed summary of the test results, methodology and procedures used in the evaluation, equipment used, and the various provisions of the rules are included within this test report. 2.0 DESCRIPTION of Equipment Under Test (EUT) Figure 1. Front of EUT Figure 2. Side of EUT Figure 3. Rear of EUT EUT Type Ruggedized Laptop PC w/ ARDIS Radio Modem Equipment Class Licensed Non-Broadcast Station Transmitter (TNB) Radio Type RIM 801D (ARDIS Network) Model No.(s) XC6250 PRO XC6250+ FCC ID KBCXC6250RIM801D S/N No. Pre-production Tx Frequency Range (MHz) 806-825 Max. RF Output Power 1.5 Watts Rx Frequency Range (MHz) 851-870 Signal Modulation(s) FSK MDC, RD-LAP Antenna Type Omni-Directional (λ/2) Antenna Length 175 mm AC Adapter ITE AD50W1P-244 Battery Itronix 7.2V 4500mAhr NiMH CELLTECH RESEARCH INC. Test Report S/N: 080800-07KBC 1955 Moss Court, Kelowna, Dates of Tests: August 08-09/16, 2000 B.C. V1Y 9L3 CANADA _________________________________________________________________________________________________________ © 2000 Celltech Research Inc. ITRONIX FCC ID: KBCXC6250RIM801D 2 Ruggedized Laptop PC with ARDIS Radio Modem 3.0 SAR MEASUREMENT SYSTEM Celltech Research SAR measurement facility utilizes the Dosimetric Assessment System (DASY™) manufactured by Schmid & Partner Engineering AG (SPEAG™) of Zurich, Switzerland. The DASY system is comprised of the robot controller, computer, near-field probe, probe alignment sensor, and the generic twin phantom containing brain or muscle equivalent material (see Figure 6). The robot is a six-axis …

Text truncated - open the document above for the full version.

RF Exposure Info

Section 4. If You Have a Radio Modem with your communications software for information on using the program with a radio network. Your network provider can answer questions regarding specific network features, host connectivity, registration options, billing, and geographic coverage areas. In some cases, your network provider can also assist you with selecting modem setup options for your communications software. Using the Integrated Radio Modem This section provides basic information on operating your mobile computer’s integrated radio modem. Antenna Positioning The mobile computer radio antenna has maximum sensitivity in the full vertical upright position. For best radio reception, position the antenna as shown below. You can fold the antenna down while the radio is not being used. While the display is open CAUTION For RIM 901 Radios: While the radio is operating, its antenna must be at least 5 cm from all persons in order to comply with the FCC RF exposure limit. Radio operators must make sure their radio unit is in compliance with these FCC regulations. See Section 9 for important information about vehicle-mounted antennas. CAUTION For RIM 801 Radios: To comply with FCC RF exposure requirements this device must be operated with a minimum separation distance of 3 cm (1.2 inches) between the user/nearby person and the antenna, with the antenna in the vertical upright position. This is the intended position of the antenna when using the RIM 801D radio modem installed in the unit. 50 79-0003-003 22 October 1999

Test Report

CELLTECH RESEARCH INC. Test Report S/N: 080800-07KBC 1955 Moss Court, Kelowna Dates of Tests: August 08-09/16, 2000 B.C. V1Y 9L3 CANADA ____________________________________________________________________________________________________________________ © 2000 Celltech Research Inc. CERTIFICATE OF COMPLIANCE FCC PART …
