KBCXC6250SB320XC6250, Multimode wireless handheld terminal

Apr 28, 1999 Federal Communications Commission Authorization and Standards Division 7435 Oakland Mills Rd. Columbia, M.D. 21046 Dear Sir/Madam: Re: FCC ID EA93837 and Request for Confidentiality We hereby request that the documentation listed below, submitted with our application for type acceptance, be withheld from public disclosure. This request is made under the provisions of Section 0.457(d) of the Commission’s Rules, and Section 552(b)(4) of the Freedom of Information Act. We cite trade secrets as the reason and purpose of the request. 1. SB300 modem schematics (sb320_schematic.pdf) 2. SB300 detailed circuit description (sb320_dcd.pdf) Sincerely, Richard Utting OEM Systems Engineer

Apr 28, 1999 Federal Communications Commission Authorization and Standards Division 7435 Oakland Mills Rd. Columbia, M.D. 21046 Sir/Madam, Sierra Wireless Incorporated has tested this transmitter in accordance with the requirements contained in the appropriate Commission Regulations. To the best of my knowledge, these tests were performed using measurement procedures consistent with the Industry or Commission standards and demonstrates that the equipment complies with the published standard. We are unable to warrant against unpublished changes in requirements. The applicable rules are listed in the following test report. The Open Area Test Site used for these measurements is located at Fluke Park, Mulkilteo, Washington. Site information required by Public Notice 24541 in accordance with ANSI C634-1992 was filed with the FCC Authorization and Evaluation Division Sampling and Measurements Branch in July 1994. Sincerely Trent McKeen RF Engineer

Apr 28, 1999 Federal Communications Commission Authorization and Standards Division 7435 Oakland Mills Rd. Columbia, M.D. 21046 Dear Sir/Madam: Re: FCC ID EA93837 submission note This submission for FCC part 22 is being filed for the integration of the Sierra Wireless Inc., wireless modem SB320 which has FCC approval (N7NOEM3) already granted for the modem as a stand alone unit. This submission is for the SB320 modem integrated into an Itronix Corporation XC6250 ruggedized laptop. Sincerely, Richard Utting OEM Systems Engineer

APPLICATION FOR Type Acceptance EXTERNAL PHOTOS Sierra Wireless Inc. FCC ID: EA93837 MODEL: SB320 Modem Integrated into the XC6250 Prepared by: Sierra Wireless Inc. #150 - 13575 Commerce Parkway Richmond, B.C. V6V 2L1 Apr 23, 1999 Figure 1: Modem External View – Top Side Figure 2: Modem External View – Bottom Side Figure 3: Itronix XC6250 laptop

APPLICATION FOR Type Acceptance ID Label Location Photos Sierra Wireless Inc. FCC ID: EA93837 MODEL: SB320 Modem Integrated into the XC6250 Prepared by: Sierra Wireless Inc. #150 - 13575 Commerce Parkway Richmond, B.C. V6V 2L1 Canada Apr. 28, 1999 FCC ID: EA93837 2 Figure 1: Location of the FCC Approval label FCC ID: EA93837 3 Figure 2: Location of the FCC Approval label FCC ID: EA93837 4 Figure 3: Location of the FCC Approval label

SB300 / XC6250 Integration ID Label Information FCC ID: KBCXC6250SB320 Conformation Number: EA93837

1 Report on Evaluation of Compliance of a Ruggedised Laptop Computer Itronix XC6250 with a SB300 series Wireless Modem, with the FCC 96-326 Guidelines for Evaluating Environmental Effects of Radiofrequency Radiation Prepared for: Sierra Wireless, Inc. 13575 Commerce Parkway Richmond, B.C. Canada, V6V-2L1 M.Okoniewski, Ph.D., Assoc. Professor Dept. of Electrical and Computer Engineering, University of Calgary May, 1999 2 Introduction This report provides results of a numerical evaluation of the maximum specific absorption rate (SAR) produced in the human tissue by a ruggedised Laptop Computer, series XC6250, with a SB300 series modem, here-upon called a device under test or test device. The evaluation is performed for the worst case configurations of the test device and the user’s head with respect to the FCC 96-326 Guidelines. The purpose of the evaluation is to establish compliance with the Federal Communication Commission FCC 96-326 Guidelines for Evaluating the Environmental Effects of Radiofrequency Radiation, ET Docket No. 93-62, adopted August 1, 1996. The information submitted shows that even under the worst case conditions the device under test meets FCC requirements, specifically: • whole-body averaged SAR not exceeding 0.08 W/kg, • SAR averaged over 1 gram of tissue in the head not exceeding 1.6 W/kg. • SAR averaged over 10 gram of tissue in the hands not exceeding 4.0 W/kg The format of the information provided follows the list of technical items for SAR evaluation outlined in Supplement C (Edition 97-01) to OET Bulletin 65 (Edition 97-01). Test Device Setup and System Uncertainties General Information • FCC ID: KBCXC6250SB300 (SB300 Integration), KBCXC6250SB320 (SB320 Integration) • device category: portable, • RF exposure environment: uncontrolled, • test method: computation with the finite difference time domain (FDTD) method 3 • affirmative statement: the device under test complies with FCC adopted limits; “For the device user, under the worst-case realistic exposure condition 1g averaged SAR in the head does not exceed the prescribed value of 1.6 W/kg, 10g averaged SAR in hands does not exceed 4.0 W/kg, and the whole-body average SAR does not exceed 0.008 W/kg for the device user. It is unrealistic to expect that a bystander can place his/her head closer to the antenna than the user, while the device is in use”. Antenna Description • antenna type: metal strip in protective dielectric sheath • antenna location on device: top, right-hand side of the screen • antenna dimensions: length metal strip: length 150 mm, width 8.5 mm, thickness 0.3mm; protective sheath length 155 mm, width 10.2 mm, thickness 3mm. • antenna configuration: non-retractable, vertical Test Signal and Output Power • test signal: CW, no time averaging used, frequency 836MHz • output power: maximum 600 mW (specified by the manufacturer). Test Position and Conditions • head and hands position: the model of the human head is placed as close to the device screen as judged possible for a shortsighted person, who wants to read the text on the screen. Under normal circumstances, the usual and conformable work position is much further away from the computer screen. The head is slightly tilted, as illustrated in Fig.1. Simplified hands are also included, to test if the SAR in hands does not exceed the prescribed limits. As the device is equipped with a “touch screen’ capabilities, test position include one hand touching the screen in the top right corner – 4 the closest distance between antenna and the hand under normal operation. Note that the presence of the hands results in lower power deposition into the operator’s head. The following test configurations were considered: 1. Head only, reflecting worst case scenario for head exposure 2. Hands only, for maximum exposure of the hands – hands flat on the keyboard 3. Hands only, for maximum exposure of the hands; left hand on the keyboard, right hand touching top, right corner of the screen, simulating touch-screen operator action (the computer has touch-screen capabilities) 4. Head and hands in position 2 5. Head and hands in position 3 • device position: Screen is set to be at normal angle to the body of the computer (keyboard) , which results in the worst case scenario for the antenna. (Usually, the screen is tilted 120 degrees with respect to the keyboard, thus increasing the distance between the antenna and the head); • antenna position: plugged into the computer in a vertical position, connected internally with the radio-modem with a coax cable. Computation Uncertainty • description of computational uncertainties: there are several potential sources of error. The estimated uncertainty associated with them is summarized below: Anatomical model of the head; anatomy differences10 % Dielectric properties of tissues 5 % Antenna modeling 3 % Device modeling 3 % FDTD: stair-casing, dielectric properties averaging 1 % SAR averaging 1 % • estimated total uncertainty12 % 5 Information for SAR Computation Basic FDTD Parameter Description • Domain size: (orientation of the coordinates shown in Fig. 1) ÿ for the computations without the head: 300 x 250 x 410 mm, not includin PML layers. Cell size 2.5 x 2.5 x 2.5 mm 3 , time step 4.77 ps ÿ for the computations without the head: 300 x 490 x 410 mm, not including PML layers. Cell size 2.5 x 2.5 x 2.5 mm 3 , time step 4.77 ps • ABC type: PML, 7 layers, parabolic, reflection –50dB • Source excitation: CW with 50 Ω resistive Voltage source, applied at the antenna connector • Total time steps: 2800 • Method used to determine steady state: the following observation criteria are used: (i) electric field probes are place in tissue close to the expected peak SAR (determined after preliminary run), close to the antenna feed and in a farthest corner of the computational domain; the simulation is stopped, when the field changes are less than 0.2% (in spectral domain). (ii) the antenna input impedance changes are below 2%. Both condition…

Text truncated - open the document above for the full version.

Certification Report on Specific Absorption Rate (SAR) Experimental Analysis Sierra Wireless Inc for Itronix Corporation X-C 6250 with SB300 Date: 26 July, 1999 51 Spectrum Way Nepean ON K2R 1E6 Tel: (613) 820-2730 Fax: (613) 820-4161 email: [email protected] This report shall not be reproduced, except in full, without the express written approval of APREL Laboratories. Page 1 of 25© APREL Project #: SRAB- XC6250 SB300-3266 51 Spectrum WayTel. (613) 820-2730 Nepean, Ontario, K2R 1E6Fax (613) 820 4161 e-mail: [email protected] CERTIFICATION REPORT Subject:Specific Absorption Rate (SAR) Experimental Analysis Product:Itronix Corporation Ruggedized Wireless Laptop with Sierra Wireless SB300 transmitter Model:Itronix Corporation X-C 6250 Client:Sierra Wireless Inc. for Itronix Corporation Address:13575 Commerce Parkway Suite 150 Richmond, B.C. V6V 2L1 Project #:SRAB-XC6250 SB300-3266 Prepared by:APREL Laboratories 51 Spectrum Way Nepean, Ontario K2R 1E6 Tested by____________________________Date: _________________ Heike Wünschmann, C.E.T. Submitted by____________________________Date: _________________ Dr. Paul G. Cardinal Director, Laboratories Approved by_____________________________Date: _________________ Dr. Jacek J. Wojcik, P. Eng. Page 2 of 25© APREL Project #: SRAB- XC6250 SB300-3266 51 Spectrum WayTel. (613) 820-2730 Nepean, Ontario, K2R 1E6Fax (613) 820 4161 e-mail: [email protected] FCC ID:KBCXC6250SB300 Applicant:Itronix Corporation Equipment:Ruggedized Wireless Laptop Model:Itronix Corporation X-C 6250 with Sierra Wireless SB300 transmitter Standard:FCC 96 –326, Guidelines for Evaluating the Environmental Effects of Radio- Frequency Radiation ENGINEERING SUMMARY This report contains the results of the engineering evaluation performed on an Itronix Corporation X-C 6250 Ruggedized Wireless Laptop operating with a built in Sierra Wireless SB300 radio transmitter. The measurements were carried out in accordance with FCC 96- 326. The X-C 6250 Ruggedized Wireless Laptop was evaluated for its nominal maximum power level of 630 mW (28 dBm). The SB300 version of the X-C 6250 was tested at high, middle, and low frequencies, with the maximum SAR coinciding with the peak performance RF output power of channel 384 (middle, 836 MHz). Test data and graphs are presented in this report. This unit as tested, and as it will be marketed and used (with a warning in the manual to keep bystanders at least 15.2 mm from the antenna), is found to be compliant with the FCC 96-326 requirement, for an uncontrolled RF exposure environment. Page 3 of 25© APREL Project #: SRAB- XC6250 SB300-3266 51 Spectrum WayTel. (613) 820-2730 Nepean, Ontario, K2R 1E6Fax (613) 820 4161 e-mail: [email protected] TABLE OF CONTENTS 1.Introduction........................................................................................................................4 2.Applicable Documents.......................................................................................................4 3.Equipment Under Test.......................................................................................................4 4.Test Equipment..................................................................................................................5 5.Test Methodology..............................................................................................................5 6.Test Results........................................................................................................................6 6.1.Transmitter Characteristics........................................................................................6 6.2.SAR Measurements....................................................................................................7 7.Analysis............................................................................................................................10 8.Conclusions......................................................................................................................11 Appendix A..............................................................................................................................12 Appendix B..............................................................................................................................18 Appendix C..............................................................................................................................21 Appendix D..............................................................................................................................22 Appendix E...............................................................................................................................25 Page 4 of 25© APREL Project #: SRAB- XC6250 SB300-3266 51 Spectrum WayTel. (613) 820-2730 Nepean, Ontario, K2R 1E6Fax (613) 820 4161 e-mail: [email protected] 1. INTRODUCTION Tests were conducted to determine the Specific Absorption Rate (SAR) of a sample of an Itronix Corporation X-C 6250 Ruggedized Wireless Laptop which incorporates a Sierra Wireless SB300 radio transmitter. These tests were conducted at APREL Laboratories’ facility located at 51 Spectrum Way, Nepean, Ontario, Canada. A view of the SAR measurement setup can be seen in Appendix A Figure 1. This report describes the results obtained. 2. APPLICABLE DOCUMENTS The following documents are applicable to the work performed: 1) FCC 96-326, Guidelines for Evaluating the Environmental Effects of Radio- Frequency Radiation 2) ANSI/IEEE C95.1-1992, IEEE Standard for Safety Levels with Respect to Human Exposure to Radio Frequency Electromagnetic Fields, 3 kHz to 300 GHz. 3) ANSI/IEEE 95.3-1992, IEEE Recommended Practice for the Measurement of Potentially Hazardous Electromagnetic Fields – RF and Microwave. 4) OET Bulletin 65 (Edition 97-01) Supplement C (Edition 97-01), “Evaluating Compliance with FCC Guidelines for Human Exposure to Radio Frequency Electromagnetic Fields”. 3. EQUIPMENT UNDER TEST • Itro…

Text truncated - open the document above for the full version.

APPLICATION FOR TYPE ACCEPTANCE Sierra Wireless Inc. FCC ID: EA93837 MODEL: SB320 Modem Integrated into the XC6250 Prepared by: Sierra Wireless Inc. #150 - 13575 Commerce Parkway Richmond, B.C. V6V 2L1 Canada Apr. 26, 1999 FCC ID: N7NOEM3 2 Table Of Contents Table Of Contents_____________________________________________2 Letter of Submittal and Compliance_______________________________3 Applicant Introduction_________________________________________4 Operational Modes__________________________________________________________4 Expository Statement 2.983 – Modem Detailed Circuit Description_____5 Description of Terminology___________________________________________________5 SB320 Logic Detail Circuit Description_________________________________________5 SB320 Radio General Description____________________________________________11 SB320 Radio Electrical Specifications_________________________________________12 SB320 Radio Block Diagram_________________________________________________13 User Manual Pages With FCC Disclaimers_______________________16 Calculation of Necessary Bandwidth for FCC ID: EA93837__________19 For CDPD 19.2Kbps Transmission (emission type FXW)_________________________19 For AMPS Wideband Data Mode (emission type F1D)___________________________19 For AMPS Voice Channel Transmission for Modem Signaling (emission type F9W)___19 Performance Test Data________________________________________20 RF Output Power (2.985)___________________________________________________20 Occupied Bandwidth (2.989)_________________________________________________21 Spurious Emissions at Antenna Terminals (2.991)_______________________________27 Field Intensity Measurements of Spurious Radiation (2.993)_______________________32 Operation Stability Performance (2.995)_______________________________________33 Test Equipment List__________________________________________35 FCC Sample Label___________________________________________36 Finished Product Label:_____________________________________________________36 Finished Product Label Location:_____________________________________________37 Owners Manual________________________________________Enclosed Equipment Photographs_________________________________Enclosed Schematics ___________________________________________Enclosed FCC ID: N7NOEM3 3 Letter of Submittal and Compliance Apr. 26, 1999 Federal Communications Commission Authorization and Standards Division 7435 Oakland Mills Rd. Columbia, M.D. 21046 Sir/Madam, Sierra Wireless Incorporated has tested this transmitter in accordance with the requirements contained in the appropriate Commission Regulations. To the best of my knowledge, these tests were performed using measurement procedures consistent with the Industry or Commission standards and demonstrates that the equipment complies with the published standard. We are unable to warrant against unpublished changes in requirements. The applicable rules are listed in the following test report. Sincerely Trent McKeen RF Engineer FCC ID: N7NOEM3 4 Applicant Introduction Sierra Wireless, Inc., located in Richmond, B.C., Canada, designs and manufactures wireless data modems for use on Cellular networks. The company was incorporated in May of 1993 around a core engineering staff with special expertise in development of products for use in commercial mobile data systems. The SB320, is a multimode cellular data modem. It offers the capability of data communications using either CDPD (Cellular Digital Packet Data) or circuit switched cellular. It also has the capability of analog voice communication over AMPS cellular. Operational Modes Data Over Circuit Switched Cellular: The modem is capable of data transmission over the standard AMPS voice channel. For establishing a conventional AMPS cellular call, cellular control channel FSK signaling is used at 10kbps per cellular system requirements. Once the call is established, computer modem signaling is sent over the “voice” channel along with SAT. This computer signaling varies in type depending on data rate used, but is filtered so that it always fits within a 300 to 3000Hz baseband bandwidth and the deviation is factory adjusted to be less than 12kHz peak. The spectrum occupancy of transmissions in this mode are characterized by testing at the highest data rate commonly achievable on the cellular infrastructure, 16.8kbps, to generate the worst case spectrum occupancy. CDPD In addition to the analog cellular mode, the modem also can transmit using CDPD signaling. The modulation used in this case is GMSK at a single data rate of 19.2kbps. Deviation in this mode is factory adjusted to 4.8kHz peak ±5%. Test results for all of these modulation types are included in this report. FCC ID: N7NOEM3 5 Expository Statement 2.983 – Modem Detailed Circuit Description The SB320 modem is a wireless modem, which operates on both the AMPS and CDPD networks. The product operates as a stand alone modem which may connect to host device (such as a personal computer) through an available serial port. The SB320 modem consists of 2 different subcircuits which are packaged together in a PCMCIA Type III housing. These circuits are 1. Modem Logic 2. Radio Each subcircuit is discussed separately in the subsequent sections. Description of Terminology CDPDCellular Digital Packet Data DSPDigital Signal Processor EEPROMElectrically Erasable Programmable Read Only Memory MCUMicro Controller Unit SB320 Logic Detail Circuit Description The logic board can be divided into various subsystems: MCU, Memory, DSP, Radio Interface, Data Access Arrangement, Codec, and AMPS Data Processor. Figure 2-1 shows a block diagram of the whole system. FCC ID: N7NOEM3 6 Figure 2-1: Logic Board Block Diagram MCU The MCU subsystem is responsible for communicating with the host and running application and diagnostic software. It talks to the DSP through the VALV34 interface. The processor used is a MC68PM302 Integrated Multiprotocol MCU. The MC68PM302 has an MC68000…

Text truncated - open the document above for the full version.

XC6 6 in. Overmold, 59-113-1, Displ Up, Ant Up, 1Jul96 -35 -30 -25 -20 -15 -10 -5 0 5 CDPD Tx Average: - 2.6 CDPD Rx Average: - 2.7 Filename: 960701_b.dat

XC6, CDPD Antenna, 59-113-1 (includes losses in 18" cable) -35 -30 -25 -20 -15 -10 -5 0 5 CDPD Tx Average: - 2.6 CDPD Rx Average: - 2.7 Filename: 960701_b.dat

XC6, CDPD Antenna, 59-113-1 (includes losses in 18" cable) -35 -30 -25 -20 -15 -10 -5 0 5 CDPD Tx Average: - 2.6 823.5 MHz, Average: - 2.0, Max: - 0.5 826.0 MHz, Average: - 2.6, Max: - 1.1 828.5 MHz, Average: - 2.4, Max: - 0.9 831.0 MHz, Average: - 2.6, Max: - 1.1 833.5 MHz, Average: - 3.1, Max: - 1.3 836.0 MHz, Average: - 2.6, Max: - 0.7 838.5 MHz, Average: - 3.5, Max: - 1.4 841.0 MHz, Average: - 2.0, Max: - 0.1 843.5 MHz, Average: - 3.2, Max: - 1.1 846.0 MHz, Average: - 1.5, Max: 0.5 848.5 MHz, Average: - 2.6, Max: - 0.4 Filename: 960701_b.dat
