KEALPB4520225

Trimble Navigation Ltd

UHF Radio ( Data Only) Modem Transceiver

Click to zoom

Application Details

Equipment Class: TNB - Licensed Non-Broadcast Station Transmitter
Date of Grant: Aug 30, 2001
Application Purpose: Original Equipment
Date of Application: Aug 30, 2001
Equipment Note: UHF Radio ( Data Only) Modem Transceiver
Frequency Range: 450.00000000 - 470.00000000
Company: Trimble Navigation Ltd
Country: United States

Documents & Files

Select a file to view

Users Manual

Cover Letter(s)

External Photos

ID Label/Location Info

Internal Photos

RF Exposure Info

Test Report

Test Setup Photos

Technical Specifications

#	Rule Parts	Frequency Range	Power Output	Emission	Tolerance
2	9	450 MHz - 470 MHz	2.14 W	17K8F1D	5 ppm

Confidentiality

Long Term

Grant Notes

Grant Condition: Power is conducted. Narrow band ( 8K60F1D) is single channle mode. The max. antenna gain can be used with this device is 2.4dBi. The antenna installation and operating configurations of this transmitter, including any applicable source-based time-averaging duty factor, antenna gain and cable loss must satisfy MPE categorical Exclusion Requirements of �2.1091. This device must transmit with a source-based time- averaging duty factor not exceeding 60%. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. Users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance..
