KL7-650MR-V6RFID Reader

Savi Mobile Reader SMR-650-217 and SMR-650-218 U.S. Regulatory Approvals - Compliance Notice Keep This Document Savi P/N 805-07085-901 (Rev. A) Published June 2010 Federal Communications Commission (FCC) Notice The Federal Communications Commission has established technical standards regarding radio frequency energy emitted by computer devices. This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference with radio/TV reception. Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense. Hazardous Location Safety Conforms to STD UL1604 for use in Division 2, Class I Groups A, B, C, D, Class II, Groups F, G, Class III Hazardous (Classified) Location Class I, Division 2, Groups A, B, C, D Class II, Division 2, Groups F, G Class III, Division 2 The installation must be in accordance with the National Electric Code, NFPA 70, Articles 504 and 505, and ANSI/ISA-RP12.06.01. Warning:EXPLOSION HAZARD. Do not disconnect while the circuit is live or unless the area is known to be free of ignitable concentrations. The following additional warnings must be observed for the safety of the operator and others in potentially hazardous locations: ◆The SMR-650-217 or SMR-650-218 may not be connected to any of its available accessories while in potentially hazardous locations. All allowed connections must be made while outside of the potentially hazardous location. ◆Any connector cover removed while in ordinary locations must be reinstalled prior to entering a potentially hazardous location. Federal Communications Commission (FCC) Label Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following conditions: ◆This device may not cause harmful interference, and ◆This device must accept any interference received, including interference that may cause undesired operation. The label statement corresponds to the following devices: Warning:Changes or modifications to this equipment that are not expressly approved by Savi Technology could void the warranty and the authority to operate this equipment. Savi Technology is not responsible for radio/TV interference caused by using unauthorized cable or by making unauthorized changes to this equipment. Product Safety AC adapter: UL approved (UL 60950) Savi Technology 351 E. Evelyn Avenue Mountain View, CA 94041-1530 Phone: (650) 316-4700 Fax:(650) 316-4750 E-mail: [email protected] Web site:www.savi.com Copyright © 2010, Savi Technology. All rights reserved. Copyright protection claimed includes all forms and matters of copyrightable material and information, now allowed by statutory or judicial law or hereinafter granted. Information in this guide is subject to change without notice and does not represent a commitment from the vendor. Savi is a registered trademark of Savi Technology, Inc. Other product names mentioned in this guide may be trademarks or registered trademarks of their respective owners and are hereby acknowledged. DeviceModelFCC ID Radio mobile readerSMR-650-217KL7-650MR-V6 Radio mobile readerSMR-650-218KL7-650MR-V6 Savi Mobile Reader SMR-650-217 and SMR-650-218 U.S. Regulatory Approvals Compliance Notice FCC Registration Requirement for Operation Under Rule 15.240 Radio transmissions from the Savi Mobile Reader SMR-650-217 and SMR-650-218 are governed in the USA by FCC Part 15 rules, and in Canada by corresponding Industry Canada regulation RSS-210. Other regulations apply in other countries. The Savi Mobile Reader SMR-650-217 and SMR-650-218 are shipped with the default mode of operation corresponding to FCC Part 15.231. All prior Savi equipment complies with FCC Part 15.231. Equipment operating under this rule does not require FCC registration. However, operation according the FCC Rule 15.240 offers some advantages in throughput and flexibility for applications involving containerized cargo. The Savi Mobile Reader SMR-650-217 and SMR-650-218 can be configured for operation under this rule, but only by a qualified technician. There are restrictions in the geographical locations where such equipment may be deployed so as to maintain a 40 km separation from five long-range USAF radar installations in the continental USA and Alaska. For this reason, the FCC requires notification of the locations where Part 15.240 operating equipment is to be installed. Savi Technology, Inc. notifies the FCC of the initial shipping destination, but it is the responsibility of the end user to mail a notice of installation, as described in the form provided below, to the FCC. This must be done at the initial installation and again if the equipment is relocated. Mail this form to: Experimental Licensing Branch, OET Federal Communications Commission 445 12th Street, SW Washington, DC 20554 ATTN: RFID registration Selected text from FCC Rule 15.240 operation in the 433.5 - 434.5 MHz band: a.Operation under this section is restricted to devices that use radio frequency energy to identify the contents of commercial shipping containers. Operations must be limited to commercial and industrial area such as ports, rail terminals, and warehouses. b.To prevent interference to Federal Government radar systems, operation under the provisions of this section is not permitted within 40 kilometers of the following locations: DoD Radar InstallationLatitudeLongitude Beale Air Force Base39º08’10”N121º21’04” Cape Cod Air Force Base41º45’07”N070º32’17” Clear Air Force Base64º55’16”N143º05’02” Cavalier Air Force Base48º43’12”N097º54’00” Eglin Air Force Ba…

Text truncated - open the document above for the full version.

Savi Mobile Reader SMR-650-217 and SMR-650-218 User Guide 1 About the Mobile Readers The Savi® Mobile Reader SMR-650-217 and SMR-650-218 are portable radio frequency identification (RFID) readers that communicate with active Savi RFID tags. The SMR-650-217 Reader and SMR-650-218 Reader include a USB interface connector and work with a notebook or desktop computer or other devices with standard USB serial connectors. The only difference between the SMR-650-217 Reader and the SMR-650-218 Reader is the length of the cable for the USB connector. The SMR-650-217 Reader has a 20 inch (50.8 cm) cable and is designed to plug into a computer USB port or a USB hub. The SMR-650-218 Reader has a 9-foot (2.74 m) cable and is designed to operate in the Savi Total Asset Visibility Portable Deployment Kit (TAV-PDK). See the Savi Total Asset Visibility Portable Deployment Kit User Guide for instructions on where to plug in the Savi Mobile Reader SMR-650-218. NOTE: In this guide, when the model of the mobile reader is not specifically mentioned, the information applies to both Savi Mobile Reader models and kits. SMR-650 Reader Communication The SMR-650 Reader has an ultra high frequency (UHF) transceiver and low frequency (LF) transmitter that communicate with all Savi RFID tags via UHF and LF antennas. The software on the computer or device determines if you use UHF or LF commands. UHF Mode The UHF transmitter sends commands and write information to Savi RFID tags. In UHF mode, the mobile reader supports single and continuous collections. When the mobile reader is in single UHF mode, you can only perform one tag collection within a fixed radius. When the mobile reader is in continuous UHF mode, you can perform multiple tag collections while moving through a facility. The amber status LED is visible when the SMR-650 reader is receiving a UHF signal and is an indication that the tag ID and the information in the data packets is being validated. When the amber LED flashes, it indicates that the mobile reader received a valid data packet. The amber LED is only functional when receiving UHF data and is not functional during UHF or LF transmission. Amber LED flashes to indicate that the mobile reader is receiving data 2Savi Mobile Reader SMR-650-217 and SMR-650-218 User Guide LF Mode LF mode is controlled by the software running on the computer or mobile device. LF mode is compatible only with Savi tags. With the software, you can use LF mode to perform short-range communications up to 3 feet (.91 m). To use LF mode, you must turn it on in the software. Please refer to Savi SmartChain Mobile and Savi SmartChain Workstation documentation. Software Compatibility The Savi Mobile Reader SMR-650 is compatible with the following Savi software products: •Savi SmartChain® Site Manager, version 6.0 and greater •Savi SmartChain Mobile, version 6.0 and greater •Savi SmartChain WorkStation, version 6.0 and greater USB Driver Updates Drivers are small software programs that allow Microsoft® Windows® to communicate with other software programs and hardware. Without drivers, the hardware you connect to your computer, such as the SMR-650-217 or SMR-650-218 reader will not work properly. The latest drivers are factory installed with the Savi software listed above. Savi may release USB driver updates as required. To check for updates contact Savi Global Support Services. See “Contacting Savi Global Support Services” on page 3. Optimizing the SMR-650 Reader Tag Collection Range Factors that can limit the SMR-650 reader collection range include: •Obstructions such as multiple walls, chained areas, solid-core doors, and enclosures •RF interference from other equipment such as computers, cellular phones, walkie-talkies, elevators, electrical motors, or other RF-emitting devices •Reflection from the ground and from nearby objects •Position and orientation of the SMR-650 reader •Metal or RF-absorbent surface on the tracked item •Tag location relative to the SMR-650 reader, such as behind a metal obstruction or stacked under multiple layers Radio interference also affects the probability of collecting any given tag, and you can expect some variance in repeatability in the field. Recharging the SMR-650 Reader Battery The SMR-650-217 and SMR-650-218 readers have an internal Lithium-Ion battery that is not replaceable. The reader battery is recharged through the USB serial connection when connected to a laptop computer, TAV-PDK, or other device that is powered on. NOTE: You must charge the SMR at least 4 hours before you use it the first time. It is recommended that you plug the SMR into a USB port on a PC or a USB hub to charge it at least every 21 days whether it is in use or in storage. It is okay to leave the unit plugged in to maintain charge. Savi Mobile Reader SMR-650-217 and SMR-650-218 User Guide3 Resetting the Mobile Reader The reset contacts on the SMR-650-217 and SMR-650-218 are located in the pinholes on the unit as illustrated below. If the SMR-650 Reader is not communicating with Savi RFID tags, simultaneously insert the tips of an unfolded metal paper clip (made into a U-shape) into the pinholes to reset the unit. The LED will blink for a second to indicate that the reset has occurred. Contacting Savi Global Support Services Savi Global Support Services operates 24x7. Access to 24x7 support depends on your Savi support plan. For product information, including firmware updates: •Go to www.savi.com and click SAVI SUPPORT. •Send an email to [email protected]. •Call 1-888-994-7284 (North America only) or 1-650-316-4760. When you contact Savi Global Support Services by telephone or email, have the following information available: •Contact information (company name, your name, email, and phone number) •Problem description •Product name/model •Product/software version •Serial number or license information Reset contacts in pinholes 4Savi P/N 805-07087-901 (Rev. A) Published July 2010 Savi Mobile Reader SMR-650-217 and SMR-650-218 Us…

Text truncated - open the document above for the full version.

Page 1 of 1 August 10, 2010 American TCB 6731 Whittier Avenue, Suite C110 McLean, VA. 22101 To whom it may concern: The enclosed documents constitute a formal submittal and application for Equipment Authorization for a mobile RFID Reader pursuant to the following rules: Subpart C of Part 15 of FCC Rules (CFR 47), specifically parts 15.209, 15.231 and 15.240. RSS-Gen Issue 2, June 2007, “General Requirements and Information for the Certification of Radiocommunication Equipment” RSS-210, Issue 7, June 2007, “Low-power Licence-exempt Radiocommunication Devices (All Frequency Bands): Category I Equipment” Elliott Laboratories, as duly authorized agent prepared this submittal. A copy of the letter of our appointment as agent is included with the application. If there are any questions or if further information is needed, please contact Elliott Laboratories for assistance. Sincerely, David W. Bare Chief Engineer

REVISION DESCRIPTION OF CHANGE A ECO-5454: INITIAL RELEASE By: T. TRAN THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE PROPERTY OF SAVI TECHNOLOGY. ANY REPRODUCTION IN PART OR WHOLE WITHOUT THE WRITTEN PERMISSION OF SAVI TECHNOLOGY IS PROHIBITED. SAVI TECHNOLOGY, INC., CONFIDENTIAL AND PROPRIETARY TITLE: LABEL, MODEL #, COMPLIANCE MARKING, 650 MOBILE READER USB (-217, -218) DRAWING No: 735-04751-TAB REV. A FILENAME: 73504751A.doc Drawing By: T. TRAN Date: 07/09/10 T.T. SHEET 1 OF 2 7. All components, hardware, materials, plating, finishes, mask, solders and coatings to meet the requirements of RoHs directive 2002/95 EC on the restriction of the use of certain hazardous substances in electrical and electronic equipment. 6. Do not substitute or modify without compliance approval. 5. All markings and symbols are in accordance with specification, 735-03938-001. 4. Label dimensions may be adjusted to closest standard die. 3. Specifications: Material Polyester film minimum thickness 2 mils, with 1 mil acrylic adhesive compliant with UL-969 requirements for adhesion, text rubbing, temperature, UV and water resistance. Approved suppliers are: 3M, Flexmark, Sidco. Color Black letters on white background Font Arial, Arial Bold, Tahoma Artworks Savi-provided editable Adobe PhotoShop (.psd) file and JPEG file Lamination 1 mil Clear Polyester 2. Label shall be manufactured using UL-listed label stock and thermal transfer printing process compliant to requirements of UL-969. 1. Dimensions are in inches, ±.02”. Notes: Unless otherwise specified: 735-04751-TAB rev. A sheet 2 of 2 LABEL, MODEL #, FCC ID, COMPLIANCE MARKING, 650 MOBILE READER USB (-217, -218) THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE PROPERTY OF SAVI TECHNOLOGY. ANY REPRODUCTION IN PART OR WHOLE WITHOUT THE WRITTEN PERMISSION OF SAVI TECHNOLOGY IS PROHIBITED. SAVI TECHNOLOGY, INC., CONFIDENTIAL AND PROPRIETARY -901 -902 -903 -904 -905 -906 -907 -908 -TAB Model: Artwork Files -901 SMR-650-217 04751-901A.psd 04751-901A.jpg -902 SMR-650-218 04751-902A.psd 04751-902A.jpg -903 SMR-650-217 04751-903A.psd 04751-903A.jpg -904 SMR-650-218 04751-904A.psd 04751-904A.jpg -905 SMR-650-217 04751-905A.psd 04751-905A.jpg -906 SMR-650-218 04751-906A.psd 04751-906A.jpg -907 SMR-650-217 04751-907A.psd 04751-907A.jpg -908 SMR-650-218 04751-908A.psd 04751-908A.jpg -946 SMR-650-217 None -947 SMR-650-218 None 1.95 1.10 R.050 See table for Model no. 1.50 0.50 R 0.050 SAVI TECHNOLOGY Model: SMR-650-21X Font: Arial 10pt, centered text Model no.: see table -946 -947 849-04751-901 Rev B sheet 1 of 1 ASSY INSTRUCTIONS, USB SMR-650 SUB-ASSY (with 100 mA charging current) THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE PROPERTY OF SAVI TECHNOLOGY. ANY REPRODUCTION IN PART OR WHOLE WITHOUT THE WRITTEN PERMISSION OF SAVI TECHNOLOGY IS PROHIBITED. SAVI TECHNOLOGY, INC., CONFIDENTIAL AND PROPRIETARY Test per test procedures: With Compliance approval: Apply label (735-04751-xxx) in this location. Add WEEE label (735-00016-001) Attach Serial Label (510-00015-001) to the connector end of the SMR, after ultrasonic welding. Reference 199-00015-001 for assignment of serial numbers each month With Compliance approval: Add Signapore Label (735-03917-001) If not on BOM then don’t apply it.

File: R79826 Page 1 of 20 EMC Test Report Application for Grant of Equipment Authorization pursuant to Industry Canada RSS-Gen Issue 2 / RSS 210 Issue 7 FCC Part 15 Subpart C Models: SMR-650-217 & SMR-650-218 IC CERTIFICATION #: 2404A-650MR4 FCC ID: KL7-650MR-V6 APPLICANT: Savi Technology, Inc. 351 E. Evelyn Ave. Mountain View, CA 94041 TEST SITE(S): Elliott Laboratories 41039 Boyce Road. Fremont, CA. 94538-2435 IC SITE REGISTRATION #: 2845B-4 REPORT DATE: August 10, 2010 FINAL TEST DATES: June 2, 17 and 21, 2010 AUTHORIZED SIGNATORY: ______________________________ David W. Bare Chief Engineer Elliott Laboratories Elliott Laboratories is accredited by the A2LA, certificate number 2016-01, to perform the test(s) listed in this report, except where noted otherwise. This report shall not be reproduced, except in its entirety, without the written approval of Elliott Laboratories Elliott Laboratories -- EMC Department Test Report Report Date: August 10, 2010 File: R79826 Page 2 of 20 REVISION HISTORY Rev# Date Comments Modified By 1 8/10/2010 First release Elliott Laboratories -- EMC Department Test Report Report Date: August 10, 2010 File: R79826 Page 3 of 20 TABLE OF CONTENTS REVISION HISTORY ................................................................................................................................................2 TABLE OF CONTENTS ............................................................................................................................................3 SCOPE..........................................................................................................................................................................4 OBJECTIVE ................................................................................................................................................................4 STATEMENT OF COMPLIANCE...........................................................................................................................5 DEVIATIONS FROM THE STANDARDS ..............................................................................................................5 TEST RESULTS SUMMARY ...................................................................................................................................6 MOMENTARILY OPERATED DEVICES – CONTROL SIGNALS.....................................................................6 GENERAL REQUIREMENTS APPLICABLE TO ALL BANDS..........................................................................7 MEASUREMENT UNCERTAINTIES....................................................................................................................8 EQUIPMENT UNDER TEST (EUT) DETAILS ......................................................................................................9 GENERAL................................................................................................................................................................9 OTHER EUT DETAILS...........................................................................................................................................9 ENCLOSURE...........................................................................................................................................................9 ANTENNA SYSTEM ..............................................................................................................................................9 MODIFICATIONS.................................................................................................................................................10 SUPPORT EQUIPMENT.......................................................................................................................................10 EUT INTERFACE PORTS ....................................................................................................................................10 EUT OPERATION .................................................................................................................................................10 TEST SITE.................................................................................................................................................................11 GENERAL INFORMATION .................................................................................................................................11 RADIATED EMISSIONS CONSIDERATIONS ..................................................................................................11 MEASUREMENT INSTRUMENTATION ............................................................................................................12 RECEIVER SYSTEM ............................................................................................................................................12 INSTRUMENT CONTROL COMPUTER ............................................................................................................12 LINE IMPEDANCE STABILIZATION NETWORK (LISN)...............................................................................12 FILTERS/ATTENUATORS ..................................................................................................................................13 ANTENNAS...........................................................................................................................................................13 ANTENNA MAST AND EQUIPMENT TURNTABLE .......................................................................................13 INSTRUMENT CALIBRATION...........................................................................................................................13 TEST PROCEDURES ..............................................................................................................................................14 EUT AND CABLE PLACEMENT .......................................................................................…

Text truncated - open the document above for the full version.
