Savi Tag ST-696-001 ISO Container Door Tag with GPS/GPRS and Sensors U.S. Regulatory Approvals Compliance Notice 1 Federal Communications Commission (FCC) Notice The Federal Communications Commission has established technical standards regarding radio frequency energy emitted by computer devices. This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference with radio/TV reception. Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense. Warning: Changes or modifications to this equipment that are not expressly approved by Savi Technology could void the warranty and the authority to operate this equipment. Savi Technology is not responsible for radio/TV interference caused by using unauthorized cable or by making unauthorized changes to this equipment. Federal Communications Commission (FCC) Label Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following conditions: • This device may not cause harmful interference, and • This device must accept any interference received, including interference that may cause undesired operation. The label statement corresponds to the following devices: Device Model FCC ID Radio Tag Savi Tag KL7-696T-V1 ST-696-001 ISO Container Door Tag with GPS/GPRS And Sensors Savi Technology, Inc. A Lockheed Martin Company 351 E. Evelyn Avenue Mountain View, CA 94041-1530 Phone: (650) 316-4700 Fax: (650) 316-4750 E-mail: [email protected] Web site: www.savi.com Copyright © 2007, Savi Technology Incorporated. All rights reserved. Published March 2007. Copyright protection claimed includes all forms and matters of copyrightable material and information, now allowed by statutory or judicial law or hereinafter granted. Information in this guide is subject to change without notice and does not represent a commitment from the vendor. Savi is a registered trademark and EchoPoint is a trademark of Savi Technology Incorporated. Other product names mentioned in this guide may be trademarks or registered trademarks of their respective owners and are hereby acknowledged. Keep This Document Savi P/N 805-05757-001 (Rev. A)

Savi Tag ST-696-001 ISO Container Door Tag with GPS/GPRS and Sensors International Regulatory Approvals Compliance Notice 1 Declaration of Conformity Hereby, Savi Technology, Inc., 351 E. Evelyn Avenue, Mountain View, CA 94041-1530 declares that the Savi SensorTag ST-696-001 ISO Container Door Tag with Sensors are in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC. Industry Canada Notice: IC: 2404A-696T This Class A digital apparatus complies with Canadian ICES-003 Cet appareil numérique de la classe A est confomé à la norme NMB- 003 du Canada. Warning This is a Class A product. In a domestic environment this product may cause radio interference in which case the user may be required to take adequate measures. Savi Technology, Inc. A Lockheed Martin Company 351 E. Evelyn Avenue Mountain View, CA 94041-1530 Phone: (650) 316-4700 Fax: (650) 316-4750 E-mail: [email protected] Web site: www.savi.com Copyright © 2007, Savi Technology Incorporated. All rights reserved. Published March 2007. Copyright protection claimed includes all forms and matters of copyrightable material and information, now allowed by statutory or judicial law or hereinafter granted. Information in this guide is subject to change without notice and does not represent a commitment from the vendor. Savi is a registered trademark and EchoPoint is a trademark of Savi Technology Incorporated. Other product names mentioned in this guide may be trademarks or registered trademarks of their respective owners and are hereby acknowledged. Keep This Document Savi P/N 805-05757-002 (Rev. A) International Compliance Czech Savi Technology, Inc. tímto prohlašuje, že tento Savi SensorTag ST-696- 001 ISO Container Door Tag with Sensors je ve shodě se základními po_adavky a dalšími příslušnými ustanoveními směrnice 1999/5/ES. Danish Undertegnede Savi Technology, Inc. erklærer herved, at følgende udstyr Savi SensorTag ST-696-001 ISO Container Door Tag with Sensors overholder de væsentlige krav og øvrige relevante krav i direktiv 1999/5/EF. German Hiermit erklärt Savi Technology, Inc., dass sich das Gerät Savi SensorTag ST-696-001 ISO Container Door Tag with Sensors in Übereinstimmung mit den grundlegenden Anforderungen und den übrigen einschlägigen Bestimmungen der Richtlinie 1999/5/EG befindet. Estonian Käesolevaga kinnitab Savi Technology, Inc. seadme Savi SensorTag ST- 696-001 ISO Container Door Tag with Sensors vastavust direktiivi 1999/5/EÜ põhinõuetele ja nimetatud direktiivist tulenevatele teistele asjakohastele sätetele. English Hereby, Savi Technology, Inc., declares that this Savi SensorTag ST-696- 001 ISO Container Door Tag with Sensors is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC. Spanish Por medio de la presente Savi Technology, Inc. declara que el Savi SensorTag ST-696-001 ISO Container Door Tag with Sensors cumple con los requisitos esenciales y cualesquiera otras disposiciones aplicables o exigibles de la Directiva 1999/5/CE. Greek ΜΕ ΤΗΝ ΠΑΡΟΥΣΑ Savi Technology, Inc. ΔΗΛΩΝΕΙ ΟΤΙ Savi SensorTag ST-696-001 ISO Container Door Tag with Sensors ΣΥΜΜΟΡΦΩΝΕΤΑΙ ΠΡΟΣ ΤΙΣ ΟΥΣΙΩΔΕΙΣ ΑΠΑΙΤΗΣΕΙΣ ΚΑΙ ΤΙΣ ΛΟΙΠΕΣ ΣΧΕΤΙΚΕΣ ΔΙΑΤΑΞΕΙΣ ΤΗΣ ΟΔΗΓΙΑΣ 1999/5/ΕΚ. French Par la présente Savi Technology, Inc. déclare que l'appareil Savi SensorTag ST-696-001 ISO Container Door Tag with Sensors est conformé aux exigences essentielles et aux autres dispositions pertinentes de la directive 1999/5/CE. Italian Con la presente Savi Technology, Inc. dichiara che questo Savi SensorTag ST-696-001 ISO Container Door Tag with Sensors è conforme ai requisiti essenziali ed alle altre disposizioni pertinenti stabilite dalla direttiva 1999/5/CE. Latvian Ar šo Savi Technology, Inc. deklarē, ka Savi SensorTag ST-696-001 ISO Container Door Tag with Sensors atbilst Direktīvas 1999/5/EK būtiskajām prasībām un citiem ar to saistītajiem noteikumiem. Lithuanian Šiuo Savi Technology, Inc. deklaruoja, kad šis Savi SensorTag ST-696-001 ISO Container Door Tag with Sensors atitinka esminius reikalavimus ir kitas 1999/5/EB Direktyvos nuostatas. Dutch Hierbij verklaart Savi Technology, Inc. dat het toestel Savi SensorTag ST- 696-001 ISO Container Door Tag with Sensors in overeenstemming is met de essentiële eisen en de andere relevante bepalingen van richtlijn 1999/5/EG. Maltese Hawnhekk, Savi Technology, Inc., jiddikjara li dan Savi SensorTag ST-696- 001 ISO Container Door Tag with Sensors jikkonforma mal-htigijiet essenzjali u ma provvedimenti ohrajn relevanti li hemm fid-Dirrettiva 1999/5/EC. Hungarian Alulírott, Savi Technology, Inc. nyilatkozom, hogy a Savi SensorTag ST- 696-001 ISO Container Door Tag with Sensors megfelel a vonatkozó alapvetõ követelményeknek és az 1999/5/EC irányelv egyéb elõírásainak Savi Tag ST-696-001 Polish Niniejszym Savi Technology, Inc. oświadcza, że Savi SensorTag ST-696- 001 ISO Container Door Tag with Sensors jest zgodny z zasadniczymi wymogami oraz pozostałymi stosownymi postanowieniami Dyrektywy 1999/5/EC. Portuguese Savi Technology, Inc. declara que este Savi SensorTag ST-696-001 ISO Container Door Tag with Sensors está conforme com os requisitos essenciais e outras disposições da Directiva 1999/5/CE. Slovenian Savi Technology, Inc. izjavlja, da je ta Savi SensorTag ST-696-001 ISO Container Door Tag with Sensors v skladu z bistvenimi zahtevami in ostalimi relevantnimi določili direktive 1999/5/ES. Slovak Savi Technology, Inc. týmto vyhlasuje, že Savi SensorTag ST-696-001 ISO Container Door Tag with Sensors spĺňa základné požiadavky a všetky príslušné ustanovenia Smernice 1999/5/ES. Finnish Savi Technology, Inc. vakuuttaa täten että Savi SensorTag ST-696-001 ISO Container Door Tag with Sensors tyyppinen laite on direktiivin 1999/5/EY oleellisten vaatimusten ja sitä koskevien direktiivin muiden ehtojen mukainen. Swedish Härmed intygar Savi Technology, Inc. att denna Savi SensorTag ST-696- 001 ISO Container Door Tag with Sensors står I överensstämme…

Text truncated - open the document above for the full version.

Savi Tag ST-696-001 ISO Container Door Tag with GPS/GPRS and Sensors International Regulatory Approvals Compliance Notice 1 Declaration of Conformity Hereby, Savi Technology, Inc., 351 E. Evelyn Avenue, Mountain View, CA 94041-1530 declares that the Savi SensorTag ST-696-001 ISO Container Door Tag with Sensors are in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC. 0889 Industry Canada Notice: IC: 2404A-696T This Class A digital apparatus complies with Canadian ICES-003 Cet appareil numérique de la classe A est confomé à la norme NMB- 003 du Canada. Warning This is a Class A product. In a domestic environment this product may cause radio interference in which case the user may be required to take adequate measures. Savi Technology, Inc. A Lockheed Martin Company 351 E. Evelyn Avenue Mountain View, CA 94041-1530 Phone: (650) 316-4700 Fax: (650) 316-4750 E-mail: [email protected] Web site: www.savi.com Copyright © 2007, Savi Technology Incorporated. All rights reserved. Published March 2007. Copyright protection claimed includes all forms and matters of copyrightable material and information, now allowed by statutory or judicial law or hereinafter granted. Information in this guide is subject to change without notice and does not represent a commitment from the vendor. Savi is a registered trademark and EchoPoint is a trademark of Savi Technology Incorporated. Other product names mentioned in this guide may be trademarks or registered trademarks of their respective owners and are hereby acknowledged. Keep This Document Savi P/N 805-05757-003 (Rev. A) International Compliance Czech Savi Technology, Inc. tímto prohlašuje, že tento Savi SensorTag ST-696- 001 ISO Container Door Tag with Sensors je ve shodě se základními po_adavky a dalšími příslušnými ustanoveními směrnice 1999/5/ES. Danish Undertegnede Savi Technology, Inc. erklærer herved, at følgende udstyr Savi SensorTag ST-696-001 ISO Container Door Tag with Sensors overholder de væsentlige krav og øvrige relevante krav i direktiv 1999/5/EF. German Hiermit erklärt Savi Technology, Inc., dass sich das Gerät Savi SensorTag ST-696-001 ISO Container Door Tag with Sensors in Übereinstimmung mit den grundlegenden Anforderungen und den übrigen einschlägigen Bestimmungen der Richtlinie 1999/5/EG befindet. Estonian Käesolevaga kinnitab Savi Technology, Inc. seadme Savi SensorTag ST- 696-001 ISO Container Door Tag with Sensors vastavust direktiivi 1999/5/EÜ põhinõuetele ja nimetatud direktiivist tulenevatele teistele asjakohastele sätetele. English Hereby, Savi Technology, Inc., declares that this Savi SensorTag ST-696- 001 ISO Container Door Tag with Sensors is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC. Spanish Por medio de la presente Savi Technology, Inc. declara que el Savi SensorTag ST-696-001 ISO Container Door Tag with Sensors cumple con los requisitos esenciales y cualesquiera otras disposiciones aplicables o exigibles de la Directiva 1999/5/CE. Greek ΜΕ ΤΗΝ ΠΑΡΟΥΣΑ Savi Technology, Inc. ΔΗΛΩΝΕΙ ΟΤΙ Savi SensorTag ST-696-001 ISO Container Door Tag with Sensors ΣΥΜΜΟΡΦΩΝΕΤΑΙ ΠΡΟΣ ΤΙΣ ΟΥΣΙΩΔΕΙΣ ΑΠΑΙΤΗΣΕΙΣ ΚΑΙ ΤΙΣ ΛΟΙΠΕΣ ΣΧΕΤΙΚΕΣ ΔΙΑΤΑΞΕΙΣ ΤΗΣ ΟΔΗΓΙΑΣ 1999/5/ΕΚ. French Par la présente Savi Technology, Inc. déclare que l'appareil Savi SensorTag ST-696-001 ISO Container Door Tag with Sensors est conformé aux exigences essentielles et aux autres dispositions pertinentes de la directive 1999/5/CE. Italian Con la presente Savi Technology, Inc. dichiara che questo Savi SensorTag ST-696-001 ISO Container Door Tag with Sensors è conforme ai requisiti essenziali ed alle altre disposizioni pertinenti stabilite dalla direttiva 1999/5/CE. Latvian Ar šo Savi Technology, Inc. deklarē, ka Savi SensorTag ST-696-001 ISO Container Door Tag with Sensors atbilst Direktīvas 1999/5/EK būtiskajām prasībām un citiem ar to saistītajiem noteikumiem. Lithuanian Šiuo Savi Technology, Inc. deklaruoja, kad šis Savi SensorTag ST-696-001 ISO Container Door Tag with Sensors atitinka esminius reikalavimus ir kitas 1999/5/EB Direktyvos nuostatas. Dutch Hierbij verklaart Savi Technology, Inc. dat het toestel Savi SensorTag ST- 696-001 ISO Container Door Tag with Sensors in overeenstemming is met de essentiële eisen en de andere relevante bepalingen van richtlijn 1999/5/EG. Maltese Hawnhekk, Savi Technology, Inc., jiddikjara li dan Savi SensorTag ST-696- 001 ISO Container Door Tag with Sensors jikkonforma mal-htigijiet essenzjali u ma provvedimenti ohrajn relevanti li hemm fid-Dirrettiva 1999/5/EC. Hungarian Alulírott, Savi Technology, Inc. nyilatkozom, hogy a Savi SensorTag ST- 696-001 ISO Container Door Tag with Sensors megfelel a vonatkozó alapvetõ követelményeknek és az 1999/5/EC irányelv egyéb elõírásainak Savi Tag ST-696-001 Polish Niniejszym Savi Technology, Inc. oświadcza, że Savi SensorTag ST-696- 001 ISO Container Door Tag with Sensors jest zgodny z zasadniczymi wymogami oraz pozostałymi stosownymi postanowieniami Dyrektywy 1999/5/EC. Portuguese Savi Technology, Inc. declara que este Savi SensorTag ST-696-001 ISO Container Door Tag with Sensors está conforme com os requisitos essenciais e outras disposições da Directiva 1999/5/CE. Slovenian Savi Technology, Inc. izjavlja, da je ta Savi SensorTag ST-696-001 ISO Container Door Tag with Sensors v skladu z bistvenimi zahtevami in ostalimi relevantnimi določili direktive 1999/5/ES. Slovak Savi Technology, Inc. týmto vyhlasuje, že Savi SensorTag ST-696-001 ISO Container Door Tag with Sensors spĺňa základné požiadavky a všetky príslušné ustanovenia Smernice 1999/5/ES. Finnish Savi Technology, Inc. vakuuttaa täten että Savi SensorTag ST-696-001 ISO Container Door Tag with Sensors tyyppinen laite on direktiivin 1999/5/EY oleellisten vaatimusten ja sitä koskevien direktiivin muiden ehtojen mukainen. Swedish Härmed intygar Savi Technology, Inc. att denna Savi SensorTag ST-696- 001 ISO Container Door Tag with Sensors står I överenss…

Text truncated - open the document above for the full version.

Savi Tag ST-696-001 ISO Container Door Tag with GPRS/GPS and Sensors Installation Guide 1 Installation Guide Savi Tag ST-696-001 ISO Container Door Tag with GPS/GPRS and Sensors Savi Tag ST-696-001 ISO Container Door Tag with GPRS/GPS and Sensors Installation Guide 2 Published December 2007 Part number 805-02001-001 Rev 01 Documentation for Savi Tag ST-696-001 ISO Container Door Tag with GPS/GPRS and Sensors Copyright ©2007 Savi Technology, Inc. All rights reserved. Unpublished rights reserved under the Copyright Laws of the United States. EchoPoint, Savi, Savi Tag, Savi SmartChain, Savi SmartStart, Savi Technology, SaviTag, SmartChain, the EchoPoint Logo, the Savi Logo, the UDAP Logo, and UDAP are trademarks or registered trademarks of Savi Technology, Inc. in the United States and other countries. Information in this manual is subject to change without notice and does not represent a commitment from the vendor. The software and/or databases described in this document are furnished under a license agreement or nondisclosure agreement. The software and/or databases may be used or copied only in accordance with the terms of the agreement. It is against the law to copy the software on any medium except as specifically allowed in the license or nondisclosure agreement. THIS DOCUMENTATION CONTAINS CONFIDENTIAL INFORMATION AND TRADE SECRETS OF SAVI TECHNOLOGY, INC. USE, DISCLOSURE OR REPRODUCTION IS PROHIBITED WITHOUT THE PRIOR EXPRESS WRITTEN PERMISSION OF SAVI TECHNOLOGY, INC. U.S. GOVERNMENT RIGHTS Use, duplication or disclosure by the U.S. government is subject to restrictions set forth in the Savi Technology, Inc. license agreement and as provided in DFARS 227.7202-1(a) and 227.7202-3(a) (1995), DFARS 252.227-7013(c)(1)(ii) (OCT 1988), FAR 12.212(a) (1995), FAR 52.227-19 or FAR 52.227-14 (ALT III), as applicable. Savi Technology, Inc. Other product names mentioned in this guide may be trademarks or registered trademarks of their respective owners and are hereby acknowledged. Savi Technology, Inc. A Lockheed Martin Company 351 E. Evelyn Avenue Mountain View, CA 94041-1530 Phone: 1-650-316-4700 Facsimile: 1-650-316-4750 www.savi.com Savi Tag ST-696-001 ISO Container Door Tag with GPRS/GPS and Sensors Installation Guide 3 Contents About Savi Tag ST-696-001 ISO Container Door Tag with GPS/GPRS and Sensors Features . . . 4 Description . . . 5 For More Information . . . 7 Guides to Read . . . 7 Contacting Savi Global Support Services . . . 7 Installing Savi Sensor Tag ST-696-001 ISO Container Door Tag with GPS/GPRS and Sensors Required Tools and Materials . . . 8 Commissioning the Tag with SaviTag Write Cable STA-1030 . . . 8 Replacing the Battery . . . 10 Tag Placement . . . 11 ST-696-001 ISO Container Door Tag with GPS/GPRS and Sensors Specifications 13 Savi Tag ST-696-001 ISO Container Door Tag with GPRS/GPS and Sensors Installation Guide 4 About Savi Sensor Tag ST-696-001 ISO ontainer Door Tag 1 C Savi® Tag ST-696-001 ISO Container Door Tag with GPS/GPRS and Sensors is a high performance active RFID tag that works with Savi software to track and monitor the security status of containers as they move through the global supply chain. This device is fully compatible with fixed and portable Savi readers and features up to 300 feet (91.44 meters) of omni-directional line-of-sight range. In addition, ST-696-001 Tag utilizes GPS receiver to report and recorded asset location using GSM/GPRS cellular network. Rechargeable Lithium Ion battery life is typically 90 days between the charges. The ST-696-001 tag is available with 128K of programmable memory. It includes a door clamp and external antennas. Using the door clamp, you affix the tag to the left door of an ISO-compliant container. Note: Savi Tag ST-696-001 ISO Container Door Tag only supports ISO 668: 1995(E) Series 1 freight containers. Features ◆ 433 MHz, active RFID technology with up to 300-foot (91.44-meter) range for monitor, wake-up, RF write/read ◆ 123 KHz receiver for slot level, portal, or chokepoint tag wake-up and short range commissioning (12 feet [3.7 meters] or less) ◆ GSP Receiver for asset real time location ◆ GSM/GPRS modem for worldwide communication to cellular networks ◆ Small form factor, ideally suited for shipping containers ◆ Rugged, weatherproof design ◆ Powered by a rechargeable Lithium Ion battery ◆ Intrusion detection sensors monitor door and light status ◆ Expandable sensor port connects to third-party sensor equipment ◆ Temperature, humidity, and shock sensors monitor the internal environment of a container ◆ 128KB nonvolatile memory for logging GPS location coordinates and sensor data Savi Tag ST-696-001 ISO Container Door Tag with GPRS/GPS and Sensors Installation Guide 5 D escription Figure 1-1 Savi Tag ST-696-001 ISO Container Door Tag Savi Tag ST-696-001 ISO Container Door Tag with GPRS/GPS and Sensors Installation Guide 6 Intrusion Detection Sensors The ST-696-001 tags include door and light sensors. The door sensor monitors the amount of pressure between the door and the device. If the door is open and the device has not been electronically unsealed, the device sends a message to the monitoring software indicating that the device has been tampered. It also writes the time and date of the tamper to an event log. The device also includes a light sensor that triggers an alarm if light is detected inside the container. Environmental Sensors The environmental sensors on the ST-696-001 tags monitor the temperature and humidity within the container. You can set the maximum and minimum values, and if the temperature or humidity rises above or falls below this range, the device writes the time and date of the breach to the event log. For example, if you are shipping a product that needs to be kept at temperatures between x and y degrees, you can set the ST- 696-001 tag to record the date and time whenever the temperature breaches the maximum or minimum value. Tamper-Protection Plate The tamper-protection plate’s ri…

Text truncated - open the document above for the full version.

RE: SAVI PUBLIC JK Letter2 From: Hilliard, David [[email protected]] Sent: Wednesday, December 07, 2005 1:14 PM To: Rod Thorne Subject: FW: SAVI PUBLIC JK Letter2 -----Original Message----- From: Rashmi Doshi [mailto:[email protected]] Sent: Tuesday, December 06, 2005 6:11 PM To: Julius Knapp; [email protected] Cc: [email protected]; Hilliard, David; Joe Dichoso Subject: RE: SAVI PUBLIC JK Letter2 Dennis: Just one extra reminder. Please include the letter as a part of the filing so that we have on our record. If you have any questions, please feel free to contact Joe Dichoso or me. Thanks, Rashmi Doshi, PhD Chief, FCC Laboratories -----Original Message----- From: Julius Knapp Sent: Tuesday, December 06, 2005 5:47 PM To: '[email protected]' Cc: '[email protected]'; '[email protected]'; Rashmi Doshi; Joe Dichoso Subject: SAVI PUBLIC JK Letter2 << File: SAVI PUBLIC JK Letter2.doc >> Dennis: Here is the letter we discussed in our teleconference this afternoon. As I stated over the phone, we have determined that the operations described in the letter are permissible. We expect to send a formal response confirming this shortly, but in the meantime there is no reason to hold up action on the application for certification provided it is consistent with the description in the letter and meets the relevant technical requirements. Thanks, Julius Knapp, Deputy Chief, Office of Engineering and Technology NOTICE: This message (including any attachments) from Wiley Rein & Fielding LLP may constitute an attorney-client communication and may contain information that is PRIVILEGED and CONFIDENTIAL and/or ATTORNEY WORK PRODUCT. If you are not an intended recipient, you are hereby notified that any dissemination of this message is strictly file:///P|/S/Savi%20Technology/J69830%20(ST-696-0...l%20items/FW%20SAVI%20PUBLIC%20JK%20Letter2a4.htm (1 of 2) [1/16/2008 4:00:03 PM] RE: SAVI PUBLIC JK Letter2 prohibited. If you have received this message in error, please do not read, copy or forward this message. Please permanently delete all copies and any attachments and notify the sender immediately by reply email or by calling our Administrative Office at 202.719.7201. Thank You. file:///P|/S/Savi%20Technology/J69830%20(ST-696-0...l%20items/FW%20SAVI%20PUBLIC%20JK%20Letter2a4.htm (2 of 2) [1/16/2008 4:00:03 PM]

R R o o b b e e r r t t L L . . P P e e t t t t i i t t 2 2 0 0 2 2 . . 7 7 1 1 9 9 . . 7 7 0 0 1 1 9 9 r r p p e e t t t t i i t t @ @ w w r r f f . . c c o o m m 1776 K STREET NW WASHINGTON, DC 20006 PHONE 202.719.7000 FAX 202.719.7049 Virginia Office 7925 JONES BRANCH DRIVE SUITE 6200 McLEAN, VA 22102 PHONE 703.905.2800 FAX 703.905.2820 www.wrf.com November 30, 2005 Mr. Julius Knapp Deputy Chief Office of Engineering and Technology Federal Communications Commission 445 12 th Street, SW Washington, DC 20554 Re: Operation of New RFID System from Savi Technology, Inc. Dear Mr. Knapp: Savi Technology, Inc. (“Savi”), 1 is developing an RFID system for operation under Sections 15.231(a) and 15.240 of the FCC Rules, and the company respectfully requests that OET confirm Savi’s understanding of the applicability of the technical requirements in these rule sections to the RF devices that comprise the new system. The new approach is made possible by: (i) the recent change to Section 15.231(a) to allow the transmission of data along with a control signal, and (ii) the flexibility afforded to RFID devices by new rule Section 15.240. The Savi RFID system consists of a Low Frequency (“LF”) Transmitter, a UHF Reader and a Tag. LF Transmitters are fixed devices (e.g., they are mounted on a signpost or entranceway to a building). UHF Readers may be fixed or portable. Savi refers to its fixed UHF Reader as the Savi Reader (“SR”) and the portable UHF Reader as the Savi Mobile Reader (“SMR”). Each device’s field strength of emissions and signal bandwidth will comply with the requirements in the applicable rule section. This includes compliance with Section 15.35 of the FCC Rules. The system has a number of operational modes as described below. In accordance with Section 15.231(a), the signals from the UHF Reader and the Tag combine control signals with data. The UHF Reader sends commands along with data to the Tag pursuant to the operational modes described below. Similarly, the Tag signal includes commands that instruct the RFID system to take certain actions 1 Savi Technology is a worldwide leader in RFID solutions that enhance homeland security and deliver value through asset management applications. The company is the primary technology provider for the world’s largest RFID consignment monitoring network for the U.S. Department of Defense, which employs RFID, barcode, cellular and satellite communications systems to track more than 35,000 conveyances daily across a global network of 1,400 locations in more than 45 countries. Savi’s solutions have been proven to enhance operational efficiency, deliver substantial cost savings, reduce capital investment in supply chain assets, and optimize inventory levels. Mr. Julius Knapp November 30, 2005 Page 2 in response to the Tag and its associated asset. The Tag’s signal includes the Tag ID, LF Transmitter (or UHF Reader) ID, as well as asset routing and status information. The RFID System uses the information in the UHF Reader and Tag signaling to regulate, direct, and influence actions of the system. In particular, the ability of the Tag to direct certain actions is critical to the overall operation of the system. 2 Savi’s RFID system will be used to control and monitor the movement of tagged assets at border crossings, on planes, trains, boats, and trucks, and in warehouses and retail stores. The Tag signal provides direction to the RFID system that is used to take specific actions that control the physical movement of the asset. For example, the Tag signal sent in response to an LF signpost transmission may control the opening and closing of doors and gates, or control the automatic routing of a tagged asset to its intended destination, such as those used with airport baggage handling systems. The operational modes for the new RFID system are as follows: 1) LF Transmitter - Signpost Wakeup Command In the Signpost mode, the short-range LF Transmitter wakes up a Tag using a 123 kHz modulated signal that complies with Section 15.209 of the FCC Rules. A Tag that receives the Wakeup command responds by transmitting a 433.92 MHz control signal to a UHF Reader. The Tag may retransmit the same message if the Tag does not receive an acknowledgement from the UHF Reader, but in no event will the Tag’s total transmission time exceed 5 seconds. Thus, the Tag transmission sequence complies with Section 15.231(a). The UHF Reader acknowledges receipt of the Tag message by transmitting a control signal to place the Tag into the Sleep mode. A timing diagram depicting the transmissions from the LF Transmitter, the Tag, and UHF Reader is shown below. 2 Savi’s RFID system uses the control information in the Tag signal to take action with regard to specific assets. For example, the Tag’s request to be interrogated by UHF Readers at inspection locations leads to segregation (and possible human intervention) if specific assets are identified or if security, battery maintenance, asset damage, or environmental threshold alarm flags are activated. The alarm flags associated with an asset may change state at any time. Thus, the Tag transmission commands the system to evaluate these parameters, to update them where appropriate, and to take appropriate action. Additionally, based on the Tag’s commands, the system will either initiate follow-on communication or put the Tag to sleep. Mr. Julius Knapp November 30, 2005 Page 2 15.231a LF Transmitter LF Transmitter Tag Response Single Tag 15.209 Tag Response max 5 sec. Min 100 ms Signpost Wake Up Command UHF Reader puts Tag to Sleep mode 2) UHF Reader Wakeup Command Fixed Reader. The Wakeup command from a fixed UHF Reader is comprised of a continuous 31.25 kHz FSK modulated signal on a 433.92 MHz carrier for 4.8 seconds, followed by a silent period and a Hello command. The entire signal lasts for 4.9 seconds, which complies with the 5 second limit set forth in Section 15.231(a). A timing diagram is depicted below. A Tag that receives the Wa…

Text truncated - open the document above for the full version.

Page 1 of 2 January 30, 2008 RE: Savi Technology, Inc., FCC ID: KL7-696T-V1 Attention: Tim Johnson Please find our responses to your comments on this application below: 1) For FCC: 731 Form cites this is a Class 2 Permissive Change application. However review of the FCC site and information uploaded appears to suggest this is a new original Certification. Please clarify and correct any exhibits. For IC: IC Form cites this is an Existing Family application (in addition to Single application). However review of the IC site and information uploaded appears to suggest this is only a new single application. Please clarify and correct any exhibits. Our apologies for the confusion, these are indeed new certifications and the ATCB form 731 and Industry Canada forms have been revised and uploaded (filenames are ATCB Form 731 _15.240 rev2.pdf, ATCB Form 731 _15.231_rev2.pdf and ATCB-Appendix I and II rev2.pdf) 2) Due to the Canadian Freedom of Information Act, a confidentiality letter should also be provided with the application for Canada. As duly authorized …
