TEKCOM Industries Limited Page 1 of 9 OWNER’S MANUAL FRS/GMRS RADIO TP-396 (2002-09-12) INTRODUCTION With RadioShack’s base station FRS/GMRS radio, you can stay in constant communication with your family throughout your home. In addition, they’re great for office use as well. Your radio has 22 channels and 38 different QUIET codes. If someone else is using the channel you selected and you do not want to hear that person, select another channel, or use the QUIET feature. You can talk with a person who has a FRS/GMRS radio if both radios are tuned to the same channel and QUIET code. Your radio has auto-squelch, which means you will not hear anything on a channel unless someone is transmitting nearby on the same channel. You can turn off auto-squelch to hear weaker, distant transmissions. You can connect an optional speaker/microphone and earphone to the radio. The VOX operation brings you convenient hands-free use. Your transceiver has these features: Selective Channel and QUIET ---- You can select the channel from one of the 22 FRS/GMRS channels and one of the 38 QUIET codes. The channel and Quiet code are selected on the display. PLL Controlled Circuitry ---- provides accurate and stable channel selection. QUIET (Continuous Tone Control Squelch System) ---- helps reduce interference from other systems in the area operating on the same frequency. Built-in Modulation Limiter Circuit ---- automatically adjusts for a wide variety of voice levels to ensure an understandable transmission. External Earphone and Microphone ---- Let you transmit or receive message by pressing or releasing Talk button on the headset or use VOX option for hands-free operation. Fixed Rod Antenna ---- Let you have a better performance of communication. We recommend you record your transceiver’s serial number here. This number is on the transceiver’s back panel. TEKCOM Industries Limited Page 2 of 9 Serial Number_______________________ Your transceiver might cause TV or radio interference even when it is operating properly. To determine whether your transceiver is causing the interference, turn off your transceiver. If the interference goes away, your transceiver is causing it. Try to eliminate the interference by: • Moving your transceiver away from the receiver. • Contacting your local RadioShack store for help. Connecting Power The FRS/GMRS intercom requires the supplied 6V, 500mA AC adapter and a standard AC outlet for power. Caution: You must use a Class 2 power source that supplies 6V DC and delivers at least 500 mA. Its center tip must be set to positive and its plug must fit the FRS/GMRS intercom’s DC 6V 500 mA jack. The supplied adapter meets these specifications. Using an adapter that does not meet these specifications could damage the FRS/GMRS intercom or the adapter. l Always connect the AC adapter to the FRS/GMRS intercom before you connect it to AC power. When you finish, disconnect the adapter from AC power before you disconnect if from the FRS/GMRS intercom. 1. Insert the supplied AC adapter’s barrel plug into the DC 6V 500 mA jack on the back of the FRS/GMRS intercom. 2. Route the adapter cord into the groove on the back of the intercom. 3. Plug the adapter into a standard AC outlet. 4. Raise the antenna to a vertical position. Mounting on a Wall Note: To mount the FRS/GMRS intercom on a wall, you need two screws (not supplied) with heads that fit the keyhole slots on the bottom of the FRS/GMRS intercom. 1. Drill two holes 2¾ inches (70 mm) apart. Then thread a screw into each hole, letting the screw heads extend about -inch (3.5 mm) from the wall. TEKCOM Industries Limited Page 3 of 9 2. Insert the supplied AC adapter’s barrel plug into the DC 6V 500 mA jack on the back of the FRS/GMRS intercom. 3. Route the AC adapter’s cord into the strain relief groove on the bottom left of the FRS/GMRS intercom, then plug the adapter into a standard AC outlet. 4. Place the FRS/GMRS intercom’s two keyhole slots over the screws and slide the FRS/GMRS intercom down to secure it. 5. Raise the antenna to a vertical position. SETTING THE QUIET CODE AND CHANNEL The quiet feature lets you communicate with another radio which uses the same channel and CTCSS (quiet) code as your radio. FCC INFORMATION Important: Do not open your radio to make any internal adjustments. Your radio is set up to transmit a regulated signal on one of 22 assigned frequencies. It is against the law to alter or adjust the settings inside the radio to exceed those limitations. Any adjustments to your radio must be made by a qualified technician using the proper test equipment. To be safe and sure: l Never open your radio’s case. l Never change or replace anything in your radio except the batteries. Your radio might cause TV or radio interference even when it is operating properly. To determine whether your radio is causing the interference, turn it off. If the interference goes away, your radio is causing it. Try to eliminate the interference by: l moving your radio away from the receiver l calling your local RadioShack store for help If you cannot eliminate the interference, the FCC requires that you stop using the radio. TEKCOM Industries Limited Page 4 of 9 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. SAFETY INFORMATION Your wireless transceiver contains a radio frequency transmitter. When The PTT button Is pushed the trasmitter sends out (RF) signals. CAUTION: To comply with FCC RF exposure a separation distance of at least 8 inches (20 cm) must be maintained between the antenna of this transmittre and all persons , during normal operation The antenna used for this transmitter must not be co-located or operating in conjunction with any other antenna or transmltter. Unauthorized antenas, modifications, or attachments …

Text truncated - open the document above for the full version.

12345678 A B C D 87654321 D C B A QUIET LAMP X102 20.95MHz SPEAKER MIC VOX/MENUDOWN/CALL UP/SCAN MON X301 32.768KHz SW MOD LPF LPF LPF LPF BPF 1SS356 21.4MHz 2SC5086 2SC5086 2SC4726 2SC42262SC4226 VCO & PLL UNIT MOD TX POWER AMP F101 Q110Q112 BUFF AMP 2SC4226 Q109 BUFF AMP 2SC3356 Q108 TX YOUNGER IC101 DBL5018 2nd LOCAL MIXER,SQL Q104 IF AMP CRYSTAL BPF Q101 1st MIX Q101 RF AMP D103 ANT SWANT ANT MOD TX/RX SW IC102 UNLOCK DATACLK CS AF OUT AF POWER AMP J1,J201 IC105 SL386D EXT PTT CHECK Q15 2SA1577 Q11 2SC4097 MIC AMP. IC104 A/D LM324 2/4 LM324 1/4 BEEP AF MUTE PTT DET MCU UNIT IC1 EM78P567 DATE BACKUP IC3 AT93C56 BACK LAMP-CONT IC4 TK11330 +3V TX CONTRAL RX CONTRAL TX POWER AMP. UNIT RX UNIT AUDIO Q106 DRF1601 LCD DRIVER Q301 2SC2712 C147 C148 BPF KB8825 PLL IC104 C TXVRXV POWER UNIT F102 450G 2nd-if SQL DET SQL Q105 KTC4075 2nd-IF DET T101 A001 Q4 FMA5A Q107 KRC405E VD101 BB179 PTT LCD IC2 HT1621B J303 DC6V VCC AUDIO BPF IC104B & IC103C CTC BPF IC103 D/B/A CTC VR303B 10K 1 2 3 4 5 J1 SP/MIC_JACK Q14 DTC124E AUDIO AMP. UNIT MIC AMP. UNIT VOX PLL UL / DA CLK / CS AUDIO CTC DC REF VR301B CPU VCC VOX SEN VOLUME VOX M3M2 M1 KEY BOARD VCC Q113 DTC124E L/H POWER Q16 2SA1298 AF SW AF SW R52 82K Q3 DTC124E R19 100K MIC MUTE R126 21-1846(US)BLOCK DIAGRAM

TEKCOM CODE NO.: TP396-FRS-2 CUSTOMER MODEL : 21-1846 ISSUE 3.01 7 MAY 02 POWER : 500mW(ERP) ISSUE 3.02 10 JULY 02 CUSTOMER : Radio Shack FREQUENCY : 1CH(14CH SELECTABLE);FRS;38CTCSS BRAND NAME: Radio Shack ITEMPART NO.DESCRIPTION QTYLOCATED TRANSISTOR 101-24001A0-A00DIODE WIN40011D1 201-6542512-A00LED LAMP GREEN MPG4364K2LED1,LED2 302-31601U0-A00SMT POWER TRANSISTOR DRF1601 SOT-2231Q106 402-22838D0-A00SMT DIODE EDS2838 (SDS2838&1SS184)1D111 502-2410DN0-A00SMT DIODE SDP401D (1SS356&1SS241)3D102,D103,D109 602-27000D0-A00SMT DIODE EDS7000 (SDS7000&1SS226)1D104 702-31197QY-A00SMT TRANSISTOR SSA1197Y (2SB1197K&2SA1298Y)1Q16 802-3124EC0-A00SMT TRANSISTOR DTC124EUA5Q2,Q3,Q11,Q14,Q113 902-3197910-A00SMT TRANSISTOR 2SA1979U "S&E" (2SA1577Q)1Q15 1002-3271230-A00SMT TRANSISTOR 2SC2712 (2SC1623)1Q301 1102-3335630-A00SMT TRANSISTOR 2SC33561Q108 1202-3409730-A00SMT TRANSISTOR 2SC40976Q3,Q11,Q14,Q102,Q105,Q107 1302-3500630-A00SMT TRANSISTOR 2SC5006 (2SC4226&2SC5085)3Q101,Q103,Q109 1402-3472630-A00SMT TRANSISTOR 2SC47261Q104 1502-350863Y-A00SMT TRANSISTOR 2SC5086-Y "Toshiba"2Q110,Q112 1602-3FMA5G0-A00SMT TRANSISTOR FMA5A1Q4 1702-25350P0-A00SMT DIODE BB535 "S&E" (1SV214)1VD101 IC 103-0032411-A00SMT IC LM324M & DBL324V2IC103,IC104 203-0038610-A00SMT IC LM3861IC105 303-11330BM-A00SMT IC TK11330BM1IC4 403-93C46SI-A00SMT IC ERROPE AT93C4610SI-2.71IC3 503-5018V01-A00SMT IC DBL5018V1IC101 603-8825B01-A00SMT IC PLL SIT8825B01-ROBO 16-TSSOP-00441IC102 703-HT16211-A00LCD DRIVER HT1621-DAF (DIE PACKING)1IC2 803-78P567H-A00IC OTP EM78P567H (DIE PACKING)1IC1 CRYSTAL 104-332712Y-A00CRYSTAL 32.768KHz +/-20PPM 12.5PF D2*6mm1X301 204-1214208-A00CRYSTAL FILTER 21.4MHz UM-1 "B"1F101 304-32952C8-A00CRYSTAL 20.95MHz UM-5 +/-5PPM1X102 404-64501NA-A00CERAMIC FILTER 450KHz (CFWM450G) +/-4.5KHz1F102 504-84652PK-A00SAW FILTER 465.14MHz +/-2.5MHz (HDF465M)1F103 INDUCTANCE 105-2000121-S50IFT A0011T101 205-3201662-A00SMT FM COIL 2.0T*D1.6*0.35mm (-)3L101,L103,L118 305-3301662-A00SMT FM COIL 3.0T*D1.6*0.35mm (-)3L102,L104,L105 405-3401662-A00SMT FM COIL 4.0T*D1.6*0.35mm (-)3L114,L115,L117 505-8221006-A00SMT CHOKE 1608 22nH +/-10% (ELJRE22NJF2)1L113 605-8225035-A00SMT CHOKE 2520 2.2uH +/-20% (ELJFC2R2KF)3L109,L110,L120 Page: 1 of 6 TEKCOM CODE NO.: TP396-FRS-2 CUSTOMER MODEL : 21-1846 ISSUE 3.01 7 MAY 02 POWER : 500mW(ERP) ISSUE 3.02 10 JULY 02 CUSTOMER : Radio Shack FREQUENCY : 1CH(14CH SELECTABLE);FRS;38CTCSS BRAND NAME: Radio Shack ITEMPART NO.DESCRIPTION QTYLOCATED 705-8471006-A00SMT CHOKE 1608 47nH +/-10% (ELJRE47NJF2)4L106,L107,L108,L112 805-8682035-A00SMT CHOKE 2520 0.68uH +/-20% (ELJFCR68MF)1L122 RESISTOR PART 106-5102731-A00CHIP RES 1608 1K OHM 1/10W +/-5%3R123,R154,R172 206-5122731-A00CHIP RES 1608 1.2K OHM 1/10W +/-5%1R107 306-5182731-A00CHIP RES 1608 1.8K OHM 1/10W +/-5%1R207 406-5202731-A00CHIP RES 1608 2K OHM 1/10W +/-5%1R142 506-5222731-A00CHIP RES 1608 2.2K OHM 1/10W +/-5%6R40,R73,R81,R139,R164,R197 606-5272731-A00CHIP RES 1608 2.7K OHM 1/10W +/-5%1R150 706-5302731-A00CHIP RES 1608 3K OHM 1/10W +/-5%1R155 806-5332731-A00CHIP RES 1608 3.3K OHM 1/10W +/-5%4R9,R31,R61,R79 906-5472731-A00CHIP RES 1608 4.7K OHM 1/10W +/-5%8R21,R104,R134,R152,R157 R196,R312,R315 1006-5562731-A00CHIP RES 1608 5.6K OHM 1/10W +/-5%1R25 1106-5682731-A00CHIP RES 1608 6.8K OHM 1/10W +/-5%2R84,R133 1206-5822731-A00CHIP RES 1608 8.2K OHM 1/10W +/-5%3R22,R102,R165 1306-5103731-A00CHIP RES 1608 10K OHM 1/10W +/-5%16R6,R8,R10,R11,R12 R13,R23,R42,R43,R60 R90,R151,R163,R302,R303 R309 1406-5123731-A00CHIP RES 1608 12K OHM 1/10W +/-5%2R119,R136 1506-5133731-A00CHIP RES 1608 13K OHM 1/10W +/-5%1R129 1606-5153731-A00CHIP RES 1608 15K OHM 1/10W +/-5%1R4 1706-5183731-A00CHIP RES 1608 18K OHM 1/10W +/-5%3R20,R45,R58 1806-5203731-A00CHIP RES 1608 20K OHM 1/10W +/-5%1R101 1906-5223731-A00CHIP RES 1608 22K OHM 1/10W +/-5%4R26,R57,R118,R149 2006-5303731-A00CHIP RES 1608 30K OHM 1/10W +/-5%1R137 2106-5333731-A00CHIP RES 1608 33K OHM 1/10W +/-5%1R44 2206-5473731-A00CHIP RES 1608 47K OHM 1/10W +/-5%4R106,R132,R144,R159 2306-5513631-A00CHIP RES 1608 51K OHM 1/16W +/-5%2R30,R37 2406-5563731-A00CHIP RES 1608 56K OHM 1/10W +/-5%3R54,R56,R108 2506-5683731-A00CHIP RES 1608 68K OHM 1/10W +/-5%1R130 2606-5823731-A00CHIP RES 1608 82K OHM 1/10W +/-5%1R52 2706-5104731-A00CHIP RES 1608 100K OHM 1/10W +/-5%15R7,R19,R27,R28,R32 R33,R35,R36,R39,R63 R66,R86,R100,R103,R105 2806-5124731-A00CHIP RES 1608 120K OHM 1/10W +/-5%3R48,R59,R82 2906-5134731-A00CHIP RES 1608 130K OHM 1/10W +/-5%2R41,R55 3006-5204731-A00CHIP RES 1608 200K OHM 1/10W +/-5%1R2 3106-5224731-A00CHIP RES 1608 220K OHM 1/10W +/-5%2R24,R124 3206-5274731-A00CHIP RES 1608 270K OHM 1/10W +/-5%1R29 3306-5334731-A00CHIP RES 1608 330K OHM 1/10W +/-5%1R3 3406-5394731-A00CHIP RES 1608 390K OHM 1/10W +/-5%1R97 3506-5474731-A00CHIP RES 1608 470K OHM 1/10W +/-5%2R88,R126 3606-5564731-A00CHIP RES 1608 560K OHM 1/10W +/-5%2R34,R38 Page: 2 of 6 TEKCOM CODE NO.: TP396-FRS-2 CUSTOMER MODEL : 21-1846 ISSUE 3.01 7 MAY 02 POWER : 500mW(ERP) ISSUE 3.02 10 JULY 02 CUSTOMER : Radio Shack FREQUENCY : 1CH(14CH SELECTABLE);FRS;38CTCSS BRAND NAME: Radio Shack ITEMPART NO.DESCRIPTION QTYLOCATED 3706-5684631-A00CHIP RES 1608 680K OHM 1/16W +/-5%1R46 3806-5824731-A00CHIP RES 1608 820K OHM 1/10W +/-5%2R47,R198 3906-5105731-A00CHIP RES 1608 1M OHM 1/10W +/-5%1R301 4006-5135631-A00CHIP RES 1608 1.3M OHM 1/16W +/-5%1R50,R51 4106-5155731-A00CHIP RES 1608 1.5M OHM 1/10W +/-5%1R49 4206-5225631-A00CHIP RES 1608 2.2M OHM 1/16W +/-5%1R53 4306-5245631-A00CHIP RES 1608 2.4M OHM 1/16W +/-5%1R83 4406-5047731-A00CHIP RES 1608 4.7 OHM 1/10W +/-5%4R16,R141,R162,R195 4506-5100731-A00CHIP RES 1608 10 OHM 1/10W +/-5%1R77 4606-5220731-A00CHIP RES 1608 22 OHM 1/10W +/-5%3R138,R307,R308 4706-5470731-A00CHIP RES 1608 47 OHM 1/10W +/-5%5R14,R113,R125,R146,R185 4806-5750731-A00CHIP RES 1608 75 OHM 1/10W +/-5%1R62 4906-5101731-A00CHIP RES 1608 100 OHM 1/10W +/-5%3R5,R135,R194 5006-5181731-A00CHIP RES 1608 180 OHM 1/10W +/-5%1R156 5106-5221731-A00CHIP RES 1608 220 OHM 1/10W …

Text truncated - open the document above for the full version.

12345678 A B C D 87654321 D C B A RT102 100+/-3% R101 20K R163 10K R162 4.7 R103 100K R102 8.2K R104 4.7K TP2 PD C183 22U/16VX102 20.95MHz +/-5PPM VC101 10P R198 820K R197 2.2K R196 4.7K R195 4.7 R138 22 R142 2K R150 2.7K Q110 2SC4226 VD101 1SV214 Q107 2SC4097 R156 180 C182 5P R1524.7K R157 4.7K R172 1K T101 A001 R122 470 F101 21.4M(+/-3.75KHz) R135 100 R129 13K R124 220K R123 1K R126 470K R113 0 R118 22K R119 12K R121 220 R120 300 Q108 2SC3356 Q109 2SC4226 R136 12K R141 4.7 R133 6.8K R134 4.7K R131 300 R143 220 R155 3K R154 1K Q112 2SC4226 12345678 910111213141516 IC101DBL5018 R144 47K C168 100U/10V C173 22U/16V R147 560 D104 1SS226 R105 100K R106 47K R112 220 R149 22K R194 100 C174 1800P R107 1.2K R146 0 C218 103 21-1846(US) SCHEMATIC DIAGRAM C1 100P R5 0 C6 390P R7 100K C40 104 R28 100K C78 153 C55 683 C79 104 C83 103 C80 683 R30 51K R29 270K C12 100P C84 2200P R34 560K C56 104 C81 120P C30 2200P R73 2.2K R77 10 C90 104 C37 10U/25V C32 333 R55 130K R79 3.3K R81 2.2K C75 103 C38 100U/10V C5 104 R31 3.3K R83 2.4M R86 100K R25 5.6K R40 2.2K C4 103 C36 103 C42 1U C33 1U R90 10K C8 470P C34 1000P 1234 8765 IC105 LM386D SP1 8OHM Q14 2SC4097 Q15 2SA1577 MIC EM-4F AF IN AF OUT C2 100U/10V VR103 20K C45 68P C3 1000P C21 104 R88 470K MIC_DET R97 390K CTCout C66 5600P R6 10K R20 15K VCC R37 62K R41 130K R84 6.8K R8 10K R46 680K R27 100K R16 4.7 CALL/BEEP R38 560K C41 2700P 12 13 14 IC104D LM324 10 9 8 IC104C LM324 5 6 7 IC104B LM324 3 2 1 4 11 IC104A LM324 10 9 8 IC103C LM324 12 13 14 IC103D LM324 3 2 1 4 11 IC103A LM324 5 6 7 IC103B LM324 R137 30K R3 330K R100 100K R47 820K R48 110K R24 220K R10 10K R49 1.5M R2 200K R32 100K R11 10K R12 10K R51 1M C47 223 C31 2200P C9 1000P C74 330P C11 100P C22 104 C39 8P C13 1000P C175 1200P C23 104 C46 103 C16 100P C48 560P C49 1800P C29 12P C35 2200P R33 100K R52 82K R50 1.3M R53 1.5M R21 4.7K R54 56K R26 22K R56 56K R13 10K R14 47 R4 15K R23 10K C17 100P C18 100P C26 104 C162 100P C19 100P C150 1U C43 1000P Q11 2SC4097 R45 18K R35 100K RV RV COM VCC TX REF TX REF TX REF RX REF R36 100K RX REF RX REF RX REF RX REF COM VCC R44 47K C27 104 C20 100P R57 39K C77 1000P Q16 2SA1298 COM VCC J303 DC6V D1 1N4001 Q2 DTC124E Q3 2SC4097 C7 100P R108 56K ANT C107 2.5P 1 2 3 4 5 J1 SP/MIC_JACK L101 3.0T- L103 2.0T- L104 2.0T- L105 2.0T- L106 47nH L107 47NH L108 47NH L110 2.2UH L102 3.0T- L113 22NH L122 0.68UH L115 3.0T- L120 2.2UH L117 4.0T- L118 2.0T- C106 10P C108 0.5P C165 NC C110 10P C112 NC C113 5P C117 NC C118 1000P C126 5P C131 100P C133 1000P C136 3P C137 1000P C138 1000P C139 22P C140 1000P C141 1000P C104 NC C101 473 C144 104 C145 104 C147 1000P C148 1000P C149 330P C153 1000P C102 470P C164 NC C160 5P C156 1000P C157 6P C158 470P C159 1000P C177 5P C212 1000P C172 104 C240 1000P C213 1000P C178 1000P C155 3P C180 3P C184 3P C241 1.5P C185 104 C176 470P C186 220P C188 3P C190 5P C191 12P C169 470P C187 393 C189 3P C197 470P C2088P C192 470P C142 100P C161 223 C143 3.3U C195 33P C204 100P C205 NC C200 6P C198 30P C194 47P D102 1SS356 D103 1SS356 C201 470P C202 470P C203 470P D109 1SS356 Q101 2SC4226 Q103 2SC4226 Q104 2SC4726 TVRV CALL/BEEP COM VCCVINAF_CTRLMUTE_CTRLVOL-CTCOUTVOL+CTCACCTCDCMIC_DETVOXACSQLPLLCSPLL UNLOCKPLLCKPLLDATA RV1 FNR-5K151 R125 47 Fin1 1 Vcc 2 CP1 3 GND 4 LD 5 CK 6 DATA 7 EN 8 BO 9 OSCO 10 OSCI 11 SW 12 GND 13 CP2 14 Vcc 15 Fin2 16 IC102KB8825 R207 10K Q106 DRF1601 C167 8P L114 4.0T- D111 1SS184 SEG7 1 SEG6 2 SEG5 3 SEG4 4 SEG3 5 SEG2 6 SEG1 7 SEG0 8 /CS 9 /RD 10 /WR 11 DATA 12 VSS 13 OSCO 14 OSCI 15 VLCD 16 VDD 17 /IRQ 18 BZ 19 /BZ 20 COM0 21 COM1 22 COM2 23 COM3 24 SEG31 25 SEG30 26 SEG29 27 SEG28 28 SEG27 29 SEG26 30 SEG25 31 SEG24 32 SEG23 33 SEG22 34 SEG21 35 SEG20 36 SEG19 37 SEG18 38 SEG17 39 SEG16 40 SEG15 41 SEG14 42 SEG13 43 SEG12 44 SEG11 45 SEG10 46 SEG9 47 SEG8 48 IC2HT1621B epdi 1 epck 2 epcs 3 xin 4 xout 5 pllc 6 gnd 7 beep/call 8 dispcs 9 dispck 10 data 11 micmute 12 backlight 13 vco_ctrl 14 tx_ctrl 15 rx_ctrl 16 af_ctrl 17 mute_ctrl 18 ctcout 19 ctcac 20 ctcdc 21 voxi 22 voxset 23 vref 24 avdd 25 vdd 26 reset 27 pllcs 28 pllck 29 plldt 30 pll unlock 31 ptt 32 vox 33 call 34 moni 35 quiet 36 down 37 up 38 m1 39 m2 40 m3 41 sql 42 mic_det 43 epdo 44 IC1 EM78P567 12345678 J2 8PIN CS 1 SK 2 DI 3 DO 4 GND 5 ORG 6 DC 7 VCC 8 IC3 93C46SI27 M2 VOX QUIET DOWN M3 MONI PTTKEY UP X301 32.768K C301 15P C302 15P C303 103 CALL/BEEP SQL PLLCKPLLDATAPLLCSPLL UNLOCK 123456789 10111213141516 DISP1LCD C0C1C2C3S0S1S2S3S4S5S6S7S8S9S10S11 R301 10K R302 0 R303 NC R43 10K C304 104 Q301 2SC2712 R307 10 R308 10 LED1 GREEN LED2 GREEN CPU VCCCTCACSQLTV CTCDC VOXACCTCOUTAF_CTRLMUTE_CTRLRV C0 C1 C2 C3 S0 S1 S2 S3 S4 S5 S6 S7S8 S9 S10 S11 C313 220U/10V C311 104 R312 4.7K C308 1U C309 100P Q4FMA5A MIC_DETCTCDC M1 R315 4.7K R316 NC VR303A VR301B 1 2 3 4 5 6 7 J4 7PIN 1 2 3 4 5 6 7 J5 7PIN VOL+VOL-VINVCC C316 22U/16V C315 100P VR303B 10K GNDVDDVPPOEBPGMBDATAACLKDINCK C14 1UR39 100K R58 18K R59 120K C50 103 R60 10K 1 23 4 F103 SAW465.14+/-2.5MHz R62 180 Q113 DTC124E R61 3.3K C51 100P C52 4P C53 4P R139 2.2KC58 330P C57 100P C54 103 R159 47K L109 2.2UH Q105 KTC4075 R151 2.7K R132 82K R130 100K C166 1P VCC VCC VCC C401 470P RV TV MCU UNIT CTC UNIT AF UNIT AF AMP RF POWER VCO UNIT PLL UNIT RX UNIT VOLUME VOX F102 LTM450G(+/-4.5K) C25 1000P C122 1000P C352 470P C15 100P ENUL R19 100K R63 47K C163 15P L112 47NH C206 12P R66 47K C310 392 C312 470P R109 0 C207 470P C209 470P C220 104 C221 470P C222 100U/10V C230 1000P C322 470P C324 470P C323 470P C321 470P R110 22 C28 104 C44 220P C70 NC C314 104 C71 NC C72 470P C317 22U/16V C318 470P C319 470P C214 470P C73 470P C306 1000P VR104 NC R93.3K Q102 2SC4097 C24 100P R65 3.3K R64 180K C341 470P R30410 R145 10K C325 220P R22 8.2K R164 2.2K R165 8.2K C320 104 R42 100K CPU VCC C351 470P C353 470P C355 470P C354 470P C151 1000P C350 470P COM VCC COM VCC C343470P C331470P C330 470P C342470P C333470P C334 470P C338470P C337470P C336470P C356 470P Q17 DTC124 Q19 DTC124E QUIET R317 270K QUIET Q18 2SC4097 R318 100K R31933K R320 2…

Text truncated - open the document above for the full version.

APPLICANT: TEKCOM INDUSTRIES LTD. FCC ID: KLLTP-396 REPORT #: T\TEKCOM_KLL\1035HT2\1035HT2TestReport.doc TABLE OF CONTENTS TABLE OF CONTENTS LIST APPLICANT: TEKCOM INDUSTRIES LTD. FCC ID: KLLTP-396 TEST REPORT: PAGE 1......COVER SHEET - GENERAL INFORMATION & TECHNICAL DESCR. PAGE 2......TECHNICAL DESCRIPTION CONTINUED PAGE 3......RF POWER OUTPUT PAGE 4......MODULATION CHARACTERISTICS PAGE 5......AUDIO FREQUENCY RESPONSE GRAPH PAGE 6......MODULATION LIMITING GRAPH – 300Hz PAGE 7......MODULATION LIMITING GRAPH – 1000Hz PAGE 8......MODULATION LIMITING GRAPH – 2500Hz PAGE 9......AUDIO LOW PASS FILTER GRAPH PAGE 10.....OCCUPIED BANDWIDTH PAGE 11.....OCCUPIED BANDWIDTH PLOT PAGE 12.....OCCUPIED BANDWIDTH PLOT - CW PAGE 13.....SPURIOUS EMISSIONS AT ANTENNA TERMINALS PAGE 14.....UNWANTED RADIATION PAGE 15.....METHOD OF MEASURING RADIATED SPURIOUS EMISSIONS PAGE 16.....FREQUENCY STABILITY PAGE 17-20..LIST OF TEST EQUIPMENT EXHIBITS CONTAINING: EXHIBIT 1.........FCC ID LABEL SAMPLE EXHIBIT 2.........LABEL LOCATION EXHIBIT 3.........EXTERNAL PHOTOGRAPHS EXHIBIT 4.........INTERNAL PHOTOGRAPHS EXHIBIT 5.........BLOCK DIAGRAM EXHIBIT 6.........SCHEMATICS EXHIBIT 7.........USER'S MANUAL EXHIBIT 8.........CIRCUIT DESCRIPTION EXHIBIT 9.........TEST SET UP PHOTO EXHIBIT 10........TUNING PROCEDURE APPLICANT: TEKCOM INDUSTRIES LTD. FCC ID: KLLTP-396 REPORT #: T\TEKCOM_KLL\1035HT2\1035HT2TestReport.doc TABLE OF CONTENTS GENERAL INFORMATION REQUIRED FOR CERTIFICATION 2.1033(c)(1)(2) TEKCOM INDUSTRIES LTD. will manufacture the FCCID: KLLTP-396 GMRS/FRS COMBINATION TRANSCEIVER in quantity, for use under FCC RULES PART 95. TEKCOM INDUSTRIES LTD. BLOCK C, 9/F., KAISER ESTATE, PHASE 1 41 MAN YUE STREET HUNGHOM, KOWLOON, FO TAN, N.T. HONG KONG 2.1033 (c) TECHNICAL DESCRIPTION 2.1033(c)(3) Instruction book. A draft copy of the instruction manual is included as EXHIBIT 7. 2.1033(c) (4) Type of Emission: 10K0F3E 95.631 Bn = 2M + 2DK M = 2500 D = 2500 Bn = 2(2500)+2(2500) = 10.0K GMRS Authorized Bandwidth 20.0 kHz 2.1033(c)(5) GMRS Frequency Range: 1. 462.5500 13. 462.7000 95.621 2. 462.5625 14. 462.7125 3. 462.5750 15. 462.7250 4. 462.5875 16. 467.5500 5. 462.6000 17. 467.5750 6. 462.6125 18. 467.6000 7. 462.6250 19. 467.6250 8. 462.6375 20. 467.6500 9. 462.6500 21. 467.6750 10. 462.6625 22. 467.7000 11. 462.6750 23. 467.7250 12. 462.6875 2.10311c)(6)(7) The Maximum Output Power Rating: GMRS - .6 Watts FRS - .5 Watts FRS Authorized Bandwidth 12.5KHz 2.1033(c)(5) FRS Frequency Range: 1. 462.5625 8. 467.5625 95.627 2. 462.5875 9. 467.5875 3. 462.6125 10. 467.6125 4. 462.6375 11. 467.6375 5. 462.6625 12. 467.6625 6. 462.6875 13. 467.6875 7. 462.7125 14. 467.7125 MHz APPLICANT: TEKCOM INDUSTRIES LTD. FCC ID: KLLTP-396 REPORT #: T\TEKCOM_KLL\1035HT2\1035HT2TestReport.doc Page 2 of 20 2.1033(c)(6)(7)FRS Power Output shall not exceed 0.50 Watts effective 95.639 radiated power. There can be no provisions for 95.649 increasing the power or varying the power. 2.1033(c)(8) DC Voltages and Current into Final Amplifier: FINAL AMPLIFIER ONLY FOR LOW POWER SETTING INPUT POWER: (6.0V)(.210A) = 1.26 Watts FOR HIGH POWER SETTING INPUT POWER: (6.0V)(.600A) = 3.60 Watts 2.1033(c)(10) Complete Circuit Diagrams: The circuit diagram is included as EXHIBIT 6 of this report. The block diagrams are included as EXHIBIT 5 of this report. 2.1033(c)(11) A photograph or a drawing of the equipment identification label is included as exhibit No. 1. 2.1033(c)(12) Photographs(8"X10") of the equipment of sufficient clarity to reveal equipment construction and layout, including meters, labels for controls, including any view under shields. See exhibits 3-4. 2.1033(c)(13) Digital modulation is not allowed. 2.1033(c)(14) The data required by 2.1046 through 2.1057 is submitted below. APPLICANT: TEKCOM INDUSTRIES LTD. FCC ID: KLLTP-396 REPORT #: T\TEKCOM_KLL\1035HT2\1035HT2TestReport.doc Page 3 of 20 95.639 Power Output shall not exceed 50.0 Watts effective radiated power. There can be no provisions for 95.649 increasing the power or varying the power. 2.1046(a) RF power is measured by the substitution method as outlined in TIA/EIA - 603. With a nominal battery voltage of 6.0 V, and the transmitter properly adjusted the RF output measures: OUTPUT POWER: GMRS: 0.6 Watts ERP FRS: 0.5 Watts ERP 2.1046(a) RF power output. The test procedure used was TIA/EIA-603 S2 APPLICANT: TEKCOM INDUSTRIES LTD. FCC ID: KLLTP-396 REPORT #: T\TEKCOM_KLL\1035HT2\1035HT2TestReport.doc Page 4 of 20 2.1047(a)(b) Modulation characteristics: AUDIO FREQUENCY RESPONSE The audio frequency response was measured in ac- cordance with TIA/EIA Specification 603. The audio frequency response curve is shown on the next page. The audio signal was fed into a dummy microphone circuit and into the microphone connector. The input required to produce 30 percent modulation level was measured. See Page 5 of report. 2.1047(b) Audio input versus modulation The audio input level needed for a particular per- percentage of modulation was measured in accor- dance with TIA/EIA Specification 603. The audio input curves versus modulation are on the following pages. Curves are provided for audio input frequen- cies of 300, 1000, and 3000 Hz. See Pages 6,7 & 8 of report. 95.637 Post Limiter Filter Each GMRS transmitter, except a mobile station transmitter with a power of 2.5Watts or less, must be equipped with an audio low pass filter. At any frequency between 3 & 20 kHz the filter must have an attenuation of 60log (f/3) greater than the attenuation at 1 kHz. See Page 9 of report. APPLICANT: TEKCOM INDUSTRIES LTD. FCC ID: KLLTP-396 REPORT #: T\TEKCOM_KLL\1035HT2\1035HT2TestReport.doc Page 5 of 20 AUDIO FREQUENCY RESPONSE GRAPH RadioShack Corp. 21-1846 -64 -54 -44 -34 -24 -14 100100010000 Frequency dBmV audio response APPLICANT: TEKCOM INDUSTRIES LTD. FCC ID: KLLTP-396 REPORT #: T\TEKCOM_KLL\1035HT2\1035HT2TestReport.doc Page 6 of 20 MODULATION LIMITING GRAPH – 300 Hz Modulation Limiting RadioShack Corp. 21-1846 …
