KLS-PLB-4-GPSFastfind MaxG, Safelink Pro, XS-ER GPS

Fastfind MaxG, Fastfind MaxG(B) & Fastfind Max Personal Location Beacon User manual mcmurdo mcmurdomcmurdo mcmurdo ii i Your PLBs unique identification information Notices to Purchasers Personal Location Beacons (PLB) must be registered with the appropriate National Authority. Failure to register your PLB could delay a Search and Rescue (SAR) response and maybe unlawful. WARNING A PLB should only be activated in situations of grave and imminent danger to life. Misuse or false activation is unlawful and could result in a penalty Important PLBs are intended for use within the maritime, aviation and land environments where permitted by national administrations. When activated, the PLB sends an emergency alert to the COSPAS-SARSAT satellite system. The time taken for the alert to be processed is dependant upon the extent of satellite system coverage at that time and any overhead obstruction that could impair the signal path to the satellite. The actual time to rescue in an emergency will be dependant upon the performance of all factors within the SAR (Search and Rescue) system, and as such, is outside the control of McMurdo Ltd. Applicability of this manual Fastfind Max and MaxG build standard: May 2008 This manual is applicable to both the Fastfind Max & MaxG models. Only MaxG versions have an inbuilt GPS receiver, consequently references to GPS and the GPS system will only apply to the MaxG and MaxG(B) models. Stick copy Programming label here ii Contents Safety notices...............................................................................................1 Quick start checklist.....................................................................................2 Emergency operation...........................................................................................2 Introduction...................................................................................................3 Preparing the PLB for use............................................................................3 Handling false alerts.....................................................................................4 Emergency Operation..................................................................................5 Switching off an active PLB..................................................................................6 Emergency Operation with GPS (Fastfind MaxG)................................................7 Self-test........................................................................................................8 Getting the best from the PLB......................................................................9 General use..........................................................................................................9 Get the best from GPS PLBs...............................................................................9 Satellite Distress Beacons explained.........................................................13 Why GPS PLBs?................................................................................................13 How does your PLB work?.........................................................................14 Registration and Licensing.........................................................................15 Radio transmitter Licence requirements.............................................................16 Service and Maintenance...........................................................................17 Deactivation................................................................................................18 Battery Pack...............................................................................................18 How to assemble your PLB........................................................................19 Fitting the battery................................................................................................19 Technical Specifications.............................................................................20 Usage statement................................................................................................22 Declaration of Conformity...........................................................................23 Product Warranty.......................................................................................24 End of Life Statement.................................................................................25 Battery Removal.................................................................................................25 Disposal.............................................................................................................25 Annex 1. Registration information..............................................................26 Annex 2. Quick user card detail.................................................................29 1 Safety notices Please take time to read this manual fully as it contains important information regarding the correct use and maintenance of your PLB. Important The PLB (Personal Locator Beacon) is an emergency radio beacon; only ever operate it in situations of grave and imminent danger to life. CAUTION: False alerts endanger lives and cause expensive disruption to Search and Rescue services, deliberate misuse of the PLB could result in penalty. CAUTION: The PLB and battery pack contain no user-serviceable parts. Do not dismantle the PLB or the battery pack. CAUTION: The battery pack contains lithium batteries. Do not attempt to recharge the battery under any circumstances. Do not incinerate, puncture, deform, or short-circuit. Dispose of spent battery packs safely and in accordance with local waste disposal regulations. Refer to End of Life Statement. CAUTION: Avoid using chemical solvents to clean the PLB as some solvents can damage the case material. CAUTION: Radio licensing, the PLB is a radio transmitter. Some administrations may require that the user holds a valid radio licence …

Text truncated - open the document above for the full version.

XS-ER GPS Personal Locator Beacon User manual ii i Your PLBs unique identification information Notices to Purchasers Personal Locator Beacons (PLB) must be registered with the appropriate National Authority. Failure to register your PLB could delay a Search and Rescue (SAR) response and maybe unlawful. WARNING A PLB should only be activated in situations of grave and imminent danger to life. Misuse or false activation is unlawful and could result in a penalty Important PLBs are intended for use within the maritime, aviation and land environments where permitted by national administrations. When activated, the PLB sends an emergency alert to the COSPAS-SARSAT satellite system. The time taken for the alert to be processed is dependant upon the extent of satellite system coverage at that time and any overhead obstruction that could impair the signal path to the satellite. The actual time to rescue in an emergency will be dependant upon the performance of all factors within the SAR (Search and Rescue) system, and as such, is outside the control of Kannad. Stick copy Programming label here ii Contents Safety notices...............................................................................................1 Quick start checklist.....................................................................................2 Emergency operation...........................................................................................2 Introduction...................................................................................................3 Preparing the PLB for use............................................................................3 Handling false alerts.....................................................................................4 Emergency Operation..................................................................................5 Switching off an active PLB..................................................................................6 Emergency Operation with GPS..........................................................................7 Self-test........................................................................................................8 Getting the best from the PLB......................................................................9 General use..........................................................................................................9 Get the best from GPS PLBs...............................................................................9 Satellite Distress Beacons explained.........................................................13 Why GPS PLBs?................................................................................................13 How does your PLB work?.........................................................................14 Registration and Licensing.........................................................................15 Radio transmitter Licence requirements.............................................................16 Service and Maintenance...........................................................................17 Deactivation................................................................................................18 Battery Pack...............................................................................................18 How to assemble your PLB........................................................................19 Fitting the battery................................................................................................19 Technical Specifications.............................................................................20 Usage statement................................................................................................22 Declaration of Conformity...........................................................................23 Product Warranty.......................................................................................24 End of Life Statement.................................................................................25 Battery Removal.................................................................................................25 Disposal.............................................................................................................25 Annex 1. Registration information..............................................................26 Annex 2. Quick user card detail.................................................................29 1 Safety notices Please take time to read this manual fully as it contains important information regarding the correct use and maintenance of your PLB. Important The PLB (Personal Locator Beacon) is an emergency radio beacon; only ever operate it in situations of grave and imminent danger to life. CAUTION: False alerts endanger lives and cause expensive disruption to Search and Rescue services, deliberate misuse of the PLB could result in penalty. CAUTION: The PLB and battery pack contain no user-serviceable parts. Do not dismantle the PLB or the battery pack. CAUTION: The battery pack contains lithium batteries. Do not attempt to recharge the battery under any circumstances. Do not incinerate, puncture, deform, or short-circuit. Dispose of spent battery packs safely and in accordance with local waste disposal regulations. Refer to End of Life Statement. CAUTION: Avoid using chemical solvents to clean the PLB as some solvents can damage the case material. CAUTION: Radio licensing, the PLB is a radio transmitter. Some administrations may require that the user holds a valid radio licence to cover its ownership and use. Radio Frequency Exposure Warning WARNING: The PLB is a radio transmitter which emits radio frequency radiation when activated. Because of the low power levels used and the intermittency of these transmissions PLBs should not expose users to RF energy in excess of safe limits. However it is advisable not to handle the ant…

Text truncated - open the document above for the full version.

Kannad Marine Safelink PRO Personal Location Beacon User manual ii i Your PLBs unique identification information Notices to Purchasers Personal Location Beacons (PLB) must be registered with the appropriate National Authority. Failure to register your PLB could delay a Search and Rescue (SAR) response and maybe unlawful. WARNING A PLB should only be activated in situations of grave and imminent danger to life. Misuse or false activation is unlawful and could result in a penalty Important PLBs are intended for use within the maritime, aviation and land environments where permitted by national administrations. When activated, the PLB sends an emergency alert to the COSPAS-SARSAT satellite system. The time taken for the alert to be processed is dependant upon the extent of satellite system coverage at that time and any overhead obstruction that could impair the signal path to the satellite. The actual time to rescue in an emergency will be dependant upon the performance of all factors within the SAR (Search and Rescue) system, and as such, is outside the control of Kannad Marine. Applicability of this manual This manual is applicable to the Safelink PRO build standard: Feb 2010 Stick copy Programming label here ii Contents Safety notices...............................................................................................1 Quick start checklist.....................................................................................2 Emergency operation...........................................................................................2 Introduction...................................................................................................3 Preparing the PLB for use............................................................................3 Handling false alerts.....................................................................................4 Emergency Operation..................................................................................5 Switching off an active PLB..................................................................................6 Emergency Operation with GPS..........................................................................7 Self-test........................................................................................................8 Getting the best from the PLB......................................................................9 General use..........................................................................................................9 Get the best from GPS PLBs...............................................................................9 Satellite Distress Beacons explained.........................................................13 Why GPS PLBs?................................................................................................13 How does your PLB work?.........................................................................14 Registration and Licensing.........................................................................15 Radio transmitter Licence requirements.............................................................16 Service and Maintenance...........................................................................17 Deactivation................................................................................................18 Battery Pack...............................................................................................18 How to assemble your PLB........................................................................19 Fitting the battery................................................................................................19 Technical Specifications.............................................................................20 Usage statement................................................................................................22 Declaration of Conformity...........................................................................23 Product Warranty.......................................................................................24 Battery Removal.................................................................................................25 Disposal.............................................................................................................25 Annex 1. Registration information..............................................................26 Annex 2. Quick user card detail.................................................................29 1 Safety notices Please take time to read this manual fully as it contains important information regarding the correct use and maintenance of your PLB. Important The PLB (Personal Locator Beacon) is an emergency radio beacon; only ever operate it in situations of grave and imminent danger to life. CAUTION: False alerts endanger lives and cause expensive disruption to Search and Rescue services, deliberate misuse of the PLB could result in penalty. CAUTION: The PLB and battery pack contain no user-serviceable parts. Do not dismantle the PLB or the battery pack. CAUTION: The battery pack contains lithium batteries. Do not attempt to recharge the battery under any circumstances. Do not incinerate, puncture, deform, or short-circuit. Dispose of spent battery packs safely and in accordance with local waste disposal regulations. Refer to End of Life Statement. CAUTION: Avoid using chemical solvents to clean the PLB as some solvents can damage the case material. CAUTION: Radio licensing, the PLB is a radio transmitter. Some administrations may require that the user holds a valid radio licence to cover its ownership and use. Radio Frequency Exposure Warning WARNING: The PLB is a radio transmitter which emits radio frequency radiation when activated. Because of the low power levels used and the intermittency of these transmissions PLBs should not expose users to RF energy in excess of safe limits. However it is advisable …

Text truncated - open the document above for the full version.

AA Classification: "C ylindrical Lithium" Chemical S ystem: Lithium/Iron Disulfide (Li/FeS 2 ) Desi gnation:ANSI 15-LF, IEC-FR6 Nominal Volta ge:1.5 Volts Stora ge Temp:-40°C to 60°C (-40°F to 140°F) Operating Temp:-40°C to 60°C (-40°F to 140°F) Typical Weight:14.5 grams (0.5 oz.) Typical Volume:8.0 cubic centimeters (0.5 cubic inch) Max Discharge: 2.0 Am ps Continuous (single battery only) 3.0 Amps Pulse (2 sec on / 8 sec off) Max Rev Current:2 uA Typical Li Content:0.98 grams (0.03 oz.) Typical IR:90 to 150 milliohms* Shelf Life: 15 years at 21°C (90% of rated capacity) Transportation: For complete details, please re ference: S pecial Provision A45 of the International Air Transport Association Dangerous Goods Re gulations 49 CFR 173.185 ENERGIZER L91 Industry Standard Dimensions Milliamp-Hours Capacity Constant Current Discharge to 0.9 Volts at 21°C Global (except US): Ultimate Lithium United States: mm (inches) Specifications * For additional information, please reference the IR technical white paper. PRODUCT DATASHEET 1-800-383-7323 / USA 1-800-383-7323 / CANADA 1-800-383-7323 US/CAN www.energizer.com 3000 4000 h ) AA LithiumAA Alkaline 5.50 (0.217) Maximum 14.50 (0.571) 13.50 (0.531) 1.00 (0.039) Minimum 50.50 (1.988) 49.50 (1.949) (+) This datasheet contains typical information specific to products manufactured at the time of its publication. Constant Power Discharge to 1.0 Volts at 0°C and 21°C ©Energizer Holdings, Inc. - Contents herein do not constitute a warranty. Milliwatt-Hours Capacity at Cold/Room Temperature Important Notice 0 1000 2000 3000 4000 5000 502505001000 Capacity (mWh) Discharge (mW) Cold Temperature (0°C) Constant Power Discharge AA LithiumAA Alkaline 0 1000 2000 3000 4000 5000 502505001000 Capacity (mWh) Discharge (mW) Room Temperature (21°C) Constant Power Discharge AA LithiumAA Alkaline 0 1000 2000 3000 252505001000 Capapcity (mA h Discharge (mA) This battery has Underwriters Laboratories component recognition (MH29980) 0.10 (0.004) T ypical 7.00 (0.276) Minimum (-) Form No. EBC - 4201PPage 1 of 2 AA Constant Current Performance ENERGIZER L91 Typical Discharge Curve Characteristics Constant Power Performance High Drain Performance 50mA Continuous (21°C)1000mA Continuous (21°C) Constant Current Discharge at 21°C (low and high drains) Low Drain Performance Typical Characteristics to 1.0 Volts (21°C) Typical Characteristics to 1.0 Volts (21°C) 1000 s AA Lithium AA Lithium 1000 r s AA Lithium AA Lithium PRODUCT DATASHEET 1-800-383-7323 US/CAN www.energizer.com 0.8 1.0 1.2 1.4 1.6 0 1530456075 Voltage (CCV) Service (hours) AA LithiumAA Alkaline 0.8 1.0 1.2 1.4 1.6 0.00.51.01.52.02.53.0 Voltage (CCV) Service (hours) AA LithiumAA Alkaline This datasheet contains typical information specific to products manufactured at the time of its publication. ©Energizer Holdings, Inc. - Contents herein do not constitute a warranty. Important Notice Application Tests (21°C) Application Tests (21°C) Industry Standard Tests (21°C) Application Tests (21°C) 1 10 100 101001000 Service, Hour s Discharge (mW) 1 10 100 101001000 Service, Hou r Discharge (mA) 0.8 1.0 1.2 1.4 1.6 0 20406080100 Voltage (CCV) Service (hours) REMOTE 24 ohm 15 sec/min 8 hrs/day RADIO 43 ohm 4 hrs/day REMOTERADIO 0.8 1.0 1.2 1.4 1.6 0714212835 Voltage (CCV) Service (hours) CD/GAMES 250 mA 1 hr/day DIGITAL AUDIO 100 mA 1 hr/day CD/GAMESTAPE PLAYER 0.8 1.0 1.2 1.4 1.6 0246810 Voltage (CCV) Service (hours) PORTABLE LIGHTING 3.3 ohm LIF TOY 3.9 ohm 1 hr/day LIGHT TOY TOOTHBRUSH 500 mA 1/13 min 24 hrs/day BRUSH 0.8 1.0 1.2 1.4 1.6 0100200300400 Voltage (CCV) Service (minutes) DIGITAL CAMERA 1.5/.65K mW 2/.1/27.9s 10X PHOTOFLASH 1K mA 10 sec/min 1 hr/day PHOTO DIGITAL CAMERA Form No. EBC - 4201PPage 2 of 2

Page 1 of 3 Lithium Iron Disulfide Batteries September 2007 ©2007 Energizer As a courtesy to our customers, Energizer has prepared copyrighted Product Safety Datasheets to provide information on the different Eveready/Energizer battery systems. As defined in OSHA Hazard Communication Standard, Section 1910.1200 (c), Eveready/Energizer batteries are manufactured “articles”, which do not result in exposure to a hazardous chemical under normal conditions of use. For this reason, Material Safety Datasheets are not required. The information and recommendations set forth herein are made in good faith, for information only, and are believed to be accurate as of the date of preparation. However, ENERGIZER BATTERY MANUFACTURING, INC., MAKES NO WARRANTY, EITHER EXPRESS OR IMPLIED, WITH RESPECT TO THIS INFORMATION AND DISCLAIMS ALL LIABILITY FROM REFERENCE ON IT. PRODUCT SAFETY DATA SHEET PRODUCT NAME: ENERGIZER Battery Type No.: L91, L92 Volts: 1.5 TRADE NAME: ENERGIZER, Lithium-Iron Disulfide Battery Approximate Weight: CHEMICAL SYSTEM: Lithium-Iron Disulfide Designed for Recharge: No SECTION I - MANUFACTURER INFORMATION Energizer Battery Manufacturing, Inc. Telephone Number for Information: 1359 Columbia Rd. Westlake, OH 44145 800-383-7323 (USA / CANADA) Date Prepared: September 2007 SECTION II - HAZARDOUS INGREDIENTS IMPORTANT NOTE: The battery should not be opened or burned. Exposure to the ingredients contained within or their combustion products could be harmful. MATERIAL OR INGREDIENT PEL (OSHA) TLV (ACGIH) %/wt. Carbon Black (CAS# 1333-86-4) 3.5 mg/m 3 TWA 3.5 mg/m 3 TWA 0-4 1,2-Dimethoxyethane (CAS# 110-71-4) None established None established 2-4 1,3-Dioxolane (CAS# 646-06-0) None established 20 ppm 5-9 Graphite (CAS# 7782-42-5) 15 mg/m 3 TWA (total dust) 5 mg/m 3 TWA (respirable fraction) 2 mg/m 3 TWA (respirable fraction) 0-4 Iron Disulfide (CAS# 1309-36-0) None established None established 24-35 Lithium or Lithium Alloy (CAS# 7439-93-2) None established None established 5-8 Lithium Iodide (CAS# 10377-51-2) None established None established 0.5-3 SECTION III - FIRE AND EXPLOSION HAZARD DATA In case of fire where lithium batteries are present, flood area with water or smother with a Class D fire extinguishant appropriate for lithium metal, such as Lith-X. Water may not extinguish burning batteries but will cool the adjacent batteries and control the spread of fire. Burning batteries will burn themselves out. Virtually all fires involving lithium batteries can be controlled by flooding with water. However, the contents of the battery will react with water and form hydrogen gas. In a confined space, hydrogen gas can form an explosive mixture. In this situation, smothering agents are recommended. A smothering agent will extinguish burning lithium batteries. Emergency Responders should wear self-contained breathing apparatus. Burning lithium-iron disulfide batteries produce toxic and corrosive lithium hydroxide fumes and sulfur dioxide gas. SECTION IV - HEALTH HAZARD DATA Page 2 of 3 Lithium Iron Disulfide Batteries September 2007 ©2007 Energizer Under normal conditions of use, the battery is hermetically sealed. Ingestion: Swallowing a battery can be harmful. Contents of an open battery can cause serious chemical burns of mouth, esophagus, and gastrointestinal tract. If battery or open battery is ingested, do not induce vomiting or give food or drink. Seek medical attention immediately. CALL NATIONAL BATTERY INGESTION HOTLINE for advice and follow-up (202-625-3333) collect, day or night. Inhalation: Contents of an open battery can cause respiratory irritation. Provide fresh air and seek medical attention. Skin Absorption: Dimethoxyethane and dioxolane may be absorbed through the skin, causing localized inflammation. Skin Contact: Contents of an open battery can cause skin irritation and/or chemical burns. Remove contaminated clothing and wash skin with soap and water. If a chemical burn occurs or if irritation persists, seek medical attention. Eye Contact: Contents of an open battery can cause severe irritation and chemical burns. Immediately flush eyes thoroughly with water for at least 15 minutes, lifting upper and lower lids, until no evidence of the chemical remains. Seek medical attention. Note: Carbon black is listed as a possible carcinogen by International Agency for Research on Cancer (IARC). SECTION V - PRECAUTIONS FOR SAFE HANDLING AND USE Storage: Store in a cool, well ventilated area. Elevated temperatures can result in shortened battery life. In locations that handle large quantities of lithium batteries, such as warehouses, lithium batteries should be isolated from unnecessary combustibles. Mechanical Containment: If potting or sealing the battery in an airtight or watertight container is required, consult your Energizer Battery Manufacturing, Inc. representative for precautionary suggestions. Do not obstruct safety release vents on batteries. Encapsulation of batteries will not allow cell venting and can cause high pressure rupture. Handling: Accidental short circuit for a few seconds will not seriously affect the battery. Prolonged short circuit will cause the battery to lose energy, generate significant heat and can cause the safety release vent to open. Sources of short circuits include jumbled batteries in bulk containers, metal jewelry, metal covered tables or metal belts used for assembly of batteries into devices. Damaging a lithium battery may result in an internal short circuit. The contents of an open battery, including a vented battery, when exposed to water, may result in a fire and/or explosion. Crushed or damaged batteries may result in a fire. If soldering or welding to the battery is required, consult your Energizer representative for proper precautions to prevent seal damage or short circuit. Charging: This battery is manufactured in a ready-to-use state. It is not designed for recharging. Recharging can cause battery leakage or, in some cases, can cause the…

Text truncated - open the document above for the full version.

Product safety information FastFind PLBs –20° 85-FF20-PSI Issue 4 Page 1 of 3 FastFind PLB 85-620-004A 85-826-004A 85-860-004A 85-860-800A 85-880-002A FastFind Plus PLB 85-520-004A 85-825-004A 85-850-004A 85-850-800A 85-850-900A 85-890-002A 85-890-003A FastFind Max PLB 85-880-001A FastFind MaxG PLB 85-890-001A FastFind MaxG(B) PLB 85-890-007A Safelink Pro PLB K85-890-004A Kannad XS-ER GPS PLB 85-890-005A Manufacturer: McMurdo Ltd Silver Point, Airport Service Road, Portsmouth, UK PO3 5PB Emergency Contact: USA 800 535 5053 or 800 323 3500 non-USA +44 (0) 23 92623900 or +44 (0) 7738 046584 or +44 (0) 7866 913321 or +44 (0) 7791 256182 Description: the product is an emergency Personal Locator Beacon powered by Lithium batteries. Sealed inside the product, the batteries are in a pack containing seven small hermetically-sealed primary Lithium – Iron Disulfide cells. The pack has its own plastic casing, and incorporates physical and electrical short-circuit protection. Use Information The batteries in this product have a limited service life: see label for expiry date. The product contains no user-serviceable parts. The product should only be disassembled by qualified service personnel. DO NOT ATTEMPT TO RECHARGE THE BATTERIES. Product safety information FastFind PLBs –20° 85-FF20-PSI Issue 4 Page 2 of 3 Hazardous Substances Under EC and US legislation this product is classified as a manufactured article, which does not result in exposure to any hazardous chemicals under normal conditions of use. As such the product does not require a Material Safety Data Sheet, and the following information is provided as a courtesy: The total Lithium content of the product is 6.86 g. The cells within the product contain the following active ingredients, by CAS number and name: 1309-36-0 Iron Disulfide 646-06-0 Dioxolane 7439-93-2 Lithium Metal 110-71-4 1,2-Dimethoxy Ethane 10377-51-2 Lithium Iodide 1333-86-4 Carbon 7782-42-5 Graphite No chemical hazard will be posed as long as the cells remain in their sealed condition. This information is given in good faith, and is believed to be accurate at the date of preparation. McMurdo Ltd makes no warranty, either express or implied, with respect to this information, and disclaims all liabilit…

Text truncated - open the document above for the full version.
