KQ9VIB-999Wireless acquisition unit for seismic data

Unit User Manual VIB-E-DD-389A-0.1 11 July 2007 VIB-E-DD-389A-0.1; 12/07/2007 2 of 6 Copyright Information: This document may not in whole or part be copied, reproduced, or reduced to any medium without prior consent, in writing, from Vibration Technology Ltd. Disclaimer: Every effort has been made to ensure the accuracy of the material provided herein; however Vibtech assumes no responsibility regarding the use of the material. Additionally, Vibration Technology Ltd. shall not be liable for any misuse of this product. Contact Information: Vibration Technology Limited, A Sercel Company Vibtech House 5 Central Boulevard, Central Park Larbert, FK5 4RU SCOTLAND, UK Tel: +44 (0)1324 556 777 Fax: +44 (0)1324 556 222 Email: [email protected] Website: http://www.vibtech.co.uk VIB-E-DD-389A-0.1; 12/07/2007 3 of 6 1 INTRODUCTION ..................................................................................................................................... 4 1.1 Related Documents.............................................................................................................................. 4 2 ELECTRICAL INTERFACE AND CONNECTORS................................................................................... 4 2.1 Pin Numbering ..................................................................................................................................... 4 2.1.1 Power/Ethernet Connector ............................................................................................................ 4 2.1.2 Sensor Connector ......................................................................................................................... 4 3 LEDS ....................................................................................................................................................... 5 4 WLAN INFORMATION ............................................................................................................................ 5 5 REGULATORY INFORMATION .............................................................................................................. 5 5.1 FCC and IC Compliance ...................................................................................................................... 5 5.1.1 FCC Statement ............................................................................................................................. 5 5.1.2 Caution ......................................................................................................................................... 5 5.1.3 IC Compliance .............................................................................................................................. 6 5.1.4 RF exposure statement ................................................................................................................. 6 6 GUIDELINES FOR SAFE AND EFFICIENT USE .................................................................................... 6 6.1 General ................................................................................................................................................ 6 6.2 Product Care ........................................................................................................................................ 6 6.3 Personal Care .......................................................................................Error! Bookmark not defined. VIB-E-DD-389A-0.1; 12/07/2007 4 of 6 1 Introduction This User Manual contains some important information about the Vibration Technology Ltd seismic data acquisition Unit. It is important that you read the information contained herein before putting your Unit into operation. 1.1 Related Documents VIB-E-US-388 Unite System Installation & Network Deployment Manual VIB-E-US-390 Unite System Maintenance Manual VIB-E-PC-146 Unite System Software Update Procedure VIB-E-US-389 Unite System User Manual 2 Electrical Interface and Connectors 2.1 Pin Numbering 2.1.1 Power/Ethernet Connector Pin Signal A PWR (external battery) B GND (external battery) C Internal battery pack enable D n/c E TX+ F TX- G RX+ H RX- 2.1.2 Sensor Connector Pin Signal 1 Sensor +ve 2 Sensor -ve VIB-E-DD-389A-0.1; 12/07/2007 5 of 6 3 LEDs State LEDop LEDcomm Critical Low Battery OFF OFF Bootloader fails to start AMBER AMBER Bootloader fail RED FLASHING OFF Critical internal failure (e.g. boot test fail) RED OFF Low (or no external) battery + Sensor Resistance pass AMBER Any Running correctly (e.g. booted) + Sensor Resistance pass GREEN Any Low (or no external) battery + Sensor Resistance fail FLASHING AMBER Any Running correctly (e.g. booted) + Sensor Resistance fail FLASHING GREEN Any RSSI good (RSSI>=TBD) or LAN connected Any GREEN RSSI moderate (TBD<=RSSI<TBD) Any AMBER RSSI poor (TBD<=RSSI<TBD) or No Infrastructure Connection (Autonomous) Any RED No GPS Lock Any FLASHING Any 4 WLAN Information The table below contains the WLAN properties Parameter Data Radio Phillips BGW200 RF output power max 16dBm Receiver sensitivity -86dBm Receiver input level (max) -20dBm Operating frequency 2.402 – 2.480 GHz, ISM band Antenna Mobile Mark SDM202400/1575 Rev B Gain 2dBi 5 Regulatory Information 5.1 FCC and IC Compliance 5.1.1 FCC Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. NOTE: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmf…

Text truncated - open the document above for the full version.

American Telecommunications Certification Body Inc. 6731 Whittier Ave, McLean, VA 22101 July 19, 2007 RE: FCC ID: KQ9VIB-999_ATCB005148 Attention: Michael Xie I have a few comments on this Application. Please note that further comments may arise in response to answers provided to the questions below. 1. Please note that while a block diagram of the system has been provided the block diagram required is that of the WLAN transmitter itself. Please provide the block diagram for this transmitter. 2. FYI – Please note that unless this device is also a computer peripheral device or one of the other devices under which a DoC is allowed the use of the FCC logo is improper and violates FCC regulations. This situation should be addressed. 3. Please provide the schematics for the WLAN transmitter itself. 4. Please note that the test report for the WLAN device states that final testing between 30MHz to 1GHz was performed on an OATS site (see page 9 of the report). Please note that the same report clearly indicates that final emissions measurements between 1-25GHz was performed in an anechoic chamber. Please note that while preliminary measurements may be done in an anechoic chamber, this is not an acceptable test method for final emissions data. All final testing of Part 15 devices must be done on an OATS or semi anechoic chamber meeting ANSI C63.4 NSA requirements. It appears that the module was improperly certified for the following reasons. Please note that the test setup photos for the WLAN device (WLAN Test Setup Photo -4.bmp, WLAN Test Setup Photo -5.bmp and WLAN Test Setup Photo -6.bmp) used in the original certification all appear to indicate that testing was not performed on an OATS nor in a semi anechoic chamber meeting NSA requirements, but was tested in a semi-anechoic chamber with absorbers on the floor between the WLAN and the receive antenna. Please note that this is not an acceptable test method for 47CFR Part 15 devices. Please note that as you are seeking certification for your product you will have to provide appropriately correct data showing testing was performed properly in accordance with the FCC rules and requirements. Please re-test in accordance with acceptable test methods approved by the FCC. 5. FYI – In conjunction with item 4 above please note that while the module may or may not be approved separately as a modular approval, the application is for a different FCC ID number. Please note that the test report UnITe test report- 2347TR2.pdf states “The manufacturer has stated that this is a bought in and is approved to the required standards. The emissions tests performed for this report do not cover the radio type approval/type testing of the wireless module.” Please note that while the unintentional radiator portion of this device may be Class A, the intentional radiator portion of this device must meet the limits of 15.209 (basically Class B). Also, please note that as this is not a modular approval and as a separate FCC ID is being sought, radiated emissions testing of the WLAN device should be performed in the host unit in its associated location with the other circuitry to 15.209 limits. Please consider this aspect of the product. 6. Please note that the test report for the WLAN only appears to contain radiated test data. Please provide the following required test data: 6dB band width plots, Power output, Power Spectral Density plots, Band Edge plots and conducted emissions data. 7. Please note that further comments may result depending on the resolution of the above items. z Page 2 July 19, 2007 Dennis Ward mailto:[email protected] The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information may result in application termination. Correspondence should be considered part of the permanent submission and may be viewed from the Internet after a Grant of Equipment Authorization is issued. Please do not respond to this correspondence using the email reply button. In order for your response to be processed expeditiously, you must submit your documents through the AmericanTCB.com website. Also, please note that partial responses increase processing time and should not be submitted. Any questions about the content of this correspondence should be directed to the sender.

Unite EMC midplate (and retaining foam) removed from top section Unite electronics removed from top section Unite base section showing internal battery and cable assemblies Unite top section (electronics removed) showing antenna mounted within dome Unite top section (electronics removed) with WLAN/GPS antenna removed from dome Unite electronics

S= power density P= power input to the antenna G= power gain of the antenna in the direction of 2 interest relative to an isotropic radiator R= distance to the center of radiation of the antenna Choose Occupational/Controlled General Population/Uncontrolled Tx Frequency: 2400.00 (MHz) Maximum Peak Power at Antenna Input Terminal: 16.021 (dBm) Antenna gain : 2.00 (dBi) S=1.0000 (mW/cm^2) P=40.0000 (mW) G=1.5849 (numeric) R =2.2461(cm) S (mw/cm^2) at specific distance in cm Enter distance desired in cm 0.01259851520 OET Bulletin 65, Edition 97-01 Prediction of MPE Limit Equation from page 18 2 4R PG S π = 4 R PG S π =
