KUJCE9103Fan/Light Remote Control Transmitter

FCC ID. KUJCE9103 Page 1 of 3 FCC ID. KUJCE9103 Page 2of 3 FCC ID. KUJCE9103 FEDERAL COMMUNICATIONS COMMISSION INTERFERENCE STATEMENT This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -- Reorient or relocate the receiving antenna. -- Increase the separation between the equipment and receiver. -- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -- Consult the dealer or an experienced radio/TV technician for help. CAUTION: To assure continued FCC compliance: Any changes or modifications not expressly approved by the grantee of this device could void the user's authority to operate the equipment. Page 3of 3

Page 11 Chungear Industrial Co., Ltd. Fan/Light Remote Control (Transmitter) FCC ID. : KUJCE9103 Block Diagram [NOTE]: (1). These buttons are normally open (i.e. spring loaded to remain open and only close when pushing) (2). There is no latching circuit to lock on transmitter after initial button is pushed.

Sent: Wednesday, December 04, 2002 2:43 AM To: Mike Kuo; 'leon' Subject: Re: Chungear Industrial Co., Ltd., FCC ID:KUJCE9103, AN02T2347 Dear Mike : Attached please find the suplement dat for above 1GHz peak reading & limite, if there is any problems please let me kown soon, if there is no any problems would you please issue the certificate ASAP, thanks. Shelene ----- Original Message ----- From: "Mike Kuo" <[email protected]> Sent: Saturday, November 30, 2002 8:26 AM Subject: FW: Chungear Industrial Co., Ltd., FCC ID:KUJCE9103, AN02T2347 > > > -----Original Message----- > From: CERTADM > Sent: Friday, November 29, 2002 4:25 PM > To: '[email protected]' > Subject: Chungear Industrial Co., Ltd., FCC ID:KUJCE9103, AN02T2347 > > > Notice_content > ------------- > Question #1: The emissions data above 1GHz only with average readings. Per > 15.231(b) requirements, the peak limits also applied. Please provide the > peak readings Vs peak limits. Please given special attention to the average > data that you recorded. Per section 15.35 ( c ) requirements about average > measurement wit pulse operation. > > Best Regards > > Mike Kuo/ TCB Certifier > The items indicated above must be submitted before processing can continue > on the above referenced application. Failure to provide the requested > information within 60 days of the original e-mail date may result in > application dismissal and forfeiture of the filing fee. Also, please note > that partial responses increase processing time and should not be submitted. > Any questions about the content of this correspondence should be directed to > the e-mail address listed below the name of the sender. >

Page 6 Chungear Industrial Co., Ltd. Fan/Light Remote Control (Transmitter) FCC ID. : KUJCE9103 Photographs Photos 1 General Appearance (Front View) Photos 2 General Appearance (Rear View)

Page 4 Chungear Industrial Co., Ltd. Fan/Light Remote Control (Transmitter) FCC ID. : KUJCE9103 Label Drawing z Label Placement Location (Back Side of EUT) FCC ID：KUJCE9103 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC LABEL

Page 7 Chungear Industrial Co., Ltd. Fan/Light Remote Control (Transmitter) FCC ID. : KUJCE9103 Photos 3 Internal View (Removed Case) Photos 4 PCB View (Component Side) Page 8 Chungear Industrial Co., Ltd. Fan/Light Remote Control (Transmitter) FCC ID. : KUJCE9103 Photos 5 PCB View (Solder Side)

FCC ID. KUJCE9103 Page 2of 3

Page 12 Chungear Industrial Co., Ltd. Fan/Light Remote Control (Transmitter) FCC ID. : KUJCE9103 Schematics Diagram

FCC ID.KUJCE9103 Page 1 of 21 APPLICATION FOR CERTIFICATION On Behalf of Chungear Industrial Co., Ltd. Fan/Light Remote Control (Transmitter) Model : E08BT FCC ID：KUJCE9103 Prepared for : Chungear Industrial Co., Ltd. 106 Kanho Rd., Taichung, Taiwan, R.O.C. Prepared by : Taiwan Tokin EMC Eng. Corp. No. 53-11, Tin-Fu Tsun, Lin-Kou, Taipei Hsien, Taiwan, R.O.C. Tel : (02) 2609-9301, 2609-2133 Fax: (02) 2609-9303 File Number ： ATM-G91941 Report Number ： TTEMC-F91174 Date of Test ： Nov. 06, 2002 Date of Report ： Nov. 13, 2002 Taiwan Tokin EMC Eng. Corp. Report No.: TTEMC-F91174 FCC ID.KUJCE9103 Page 2 of 21 TABLE OF CONTENTS Description Page TEST REPORT CERTIFICATION .......................................................................................................3 1. GENERAL INFORMATION..........................................................................................................4 1.1. Description of Device (EUT) ............................................................................................................. 4 1.2. Description of Test Facility ................................................................................................................ 5 1.3. Measurement Uncertainty .................................................................................................................. 5 2. POWERLINE CONDUCTED TEST ..............................................................................................6 3. RADIATED EMISSION TEST.......................................................................................................7 3.1. Test Equipment................................................................................................................................... 7 3.2. Test Setup ........................................................................................................................................... 7 3.3. Radiation Limit (§15.231) .................................................................................................................. 8 3.4. EUT’s Configuration during Compliance Measurement.................................................................... 8 3.5. Operating Condition of EUT .............................................................................................................. 8 3.6. Test Procedure .................................................................................................................................... 9 3.7. Radiated Emission Noise Measurement Results .............................................................................. 10 4. EMISSION BANDWIDTH TEST ................................................................................................13 4.1. Test Equipment................................................................................................................................. 13 4.2. Block Diagram of Test Setup ........................................................................................................... 13 4.3. Specification Limits (§15.231-(c)) ................................................................................................... 13 4.4. EUT’s Configuration during Compliance Measurement.................................................................. 13 4.5. Emission Bandwidth Measurement Results ..................................................................................... 13 5. PERIODIC OPERATED TEST.....................................................................................................15 5.1. Test Equipment................................................................................................................................. 15 5.2. Block Diagram of Test Setup ........................................................................................................... 15 5.3. Specification Limits [§15.231-(a)-(1)] ............................................................................................. 15 5.4. EUT’s Configuration during Compliance Measurement.................................................................. 15 5.5. Periodic Operated Measurement Results..........................................................................................15 6. DEVIATION TO TEST SPECIFICATIONS................................................................................17 7. PHOTOGRAPHS ..........................................................................................................................18 7.1. Photos of Radiated Measurement at Semi-Anechoic Chamber (30~1000MHz) ............................ 18 7.2. Photos of Radiated Measurement at Semi-Anechoic Chamber (1~4GHz) ..................................... 19 7.3. Photos of Emission Bandwidth Measurement.................................................................................. 21 7.4. Photos of Periodic Operated Measurement ...................................................................................... 21 Taiwan Tokin EMC Eng. Corp. Report No.: TTEMC-F91174 FCC ID.KUJCE9103 Page 3 of 21 TEST REPORT CERTIFICATION Applicant ： Chungear Industrial Co., Ltd. Manufacturer ： Chungear Industrial Co., Ltd. EUT Description ： Fan/Light Remote Control (Transmitter) FCC ID ： KUJCE9103 (A) MODEL NO. ： E08BT (B) SERIAL NO. ： N/A (C) POWER SUPPLY：DC 9V Measurement Procedure Used: FCC RULES AND REGULATIONS PART 15 SUBPART C, MAY 2002 AND ANSI C63.4/1992 The device described above was tested by TAIWAN TOKIN EMC ENG. CORP. to determine the maximum emission levels emanating from the device. The maximum emission levels were compared to the FCC Part 15 subpart C limits both radiated and conducted emissions. The measurement results are contained in this test report and TAIWAN TOKIN EMC ENG. CORP. is assumed full responsibility for the accuracy and completeness of these measurements. Also, this report shows that the EUT to be technically compliant with the FCC official limits. This report applies to above …

Text truncated - open the document above for the full version.

FCC ID.KUJCE9103 Page 1 of 3 Supplement Data for Radiated Emission above 1GHz with Peak reading Date of Test： Dec. 03, 2002 Temperature： 22°C EUT： Fan/Light Remote Control (Transmitter) Humidity： 63％ Test Position： EUT on Stand Emission Antenna Cable Meter Reading Emission Level Frequency Factor Loss Horizontal Horizontal Limits Margin MHz dB/m dB dBμV dBμV/m dBμV/m dB ------------------------------------------------------------------------------------------------------------------ Spurious / Harmonic Freq. (Above 1GHz, Peak Value) 1216.051 25.30 4.61 2.44 32.35 74.93 42.58 1520.083 25.52 5.56 0.84 31.92 74.93 43.01 1824.166 27.04 6.77 -2.58 31.23 74.93 43.70 2128.166 28.08 6.02 -1.38 32.72 74.93 42.21 2432.224 28.68 6.39 -0.21 34.86 74.93 40.07 2736.336 29.81 6.84 -0.30 36.35 74.93 38.58 3040.572 30.88 7.26 -2.21 35.93 74.93 39.00 ------------------------------------------------------------------------------------------------------------------ Emission Antenna Cable Meter Reading Emission Level Frequency Factor Loss Vertical Vertical Limits Margin MHz dB/m dB dBμV dBμV/m dBμV/m dB ------------------------------------------------------------------------------------------------------------------ Spurious / Harmonic Freq. (Above 1GHz, Peak Value) 1216.051 25.30 4.61 0.85 30.76 74.93 44.17 1520.083 25.52 5.56 0.49 31.57 74.93 43.36 1824.166 27.04 6.77 -3.24 30.57 74.93 44.36 2128.166 28.08 6.02 -1.41 32.69 74.93 42.24 2432.224 28.68 6.39 -0.37 34.70 74.93 40.23 2736.336 29.81 6.84 0.11 36.76 74.93 38.17 3040.572 30.88 7.26 -0.83 37.31 74.93 37.62 ------------------------------------------------------------------------------------------------------------------ Remark ： 1. Emission Level = Antenna Factor + Cable Loss + Meter Reading. 2. Measurement was up to 10th harmonic (~4GHz), but the emissions level were too low against the official limit and not report. Taiwan Tokin EMC Eng. Corp. Report No.: TTEMC-F91174 FCC ID.KUJCE9103 Page 2 of 3 Date of Test： Dec. 03, 2002 Temperature： 22°C EUT： Fan/Light Remote Control (Transmitter) Humidity： 63％ Test Position： EUT on Side Emission Antenna Cable Meter Reading Emission Level Frequency Factor Loss Horizontal Horizontal Limits Margin MHz dB/m dB dBμV dBμV/m dBμV/m dB ------------------------------------------------------------------------------------------------------------------ Spurious / Harmonic Freq. (Above 1GHz, Peak Value) 0 25.30 4.61 2.05 31.96 74.93 42.97 1520.083 25.52 5.56 0.33 31.41 74.93 43.52 1824.166 27.04 6.77 -2.78 31.03 74.93 43.90 2128.166 28.08 6.02 -1.11 32.99 74.93 41.94 2432.224 28.68 6.39 -0.79 34.28 74.93 40.65 2736.336 29.81 6.84 -0.22 36.43 74.93 38.50 3040.572 30.88 7.26 -0.69 37.45 74.93 37.48 ------------------------------------------------------------------------------------------------------------------ Emission Antenna Cable Meter Reading Emission Level Frequency Factor Loss Vertical Vertical Limits Margin MHz dB/m dB dBμV dBμV/m dBμV/m dB ------------------------------------------------------------------------------------------------------------------ Spurious / Harmonic Freq. (Above 1GHz, Peak Value) 1216.051 25.30 4.61 6.78 36.69 74.93 38.24 1520.083 25.52 5.56 0.09 31.17 74.93 43.76 1824.166 27.04 6.77 -2.76 31.05 74.93 43.88 2128.166 28.08 6.02 -1.24 32.86 74.93 42.07 2432.224 28.68 6.39 -0.79 34.28 74.93 40.65 2736.336 29.81 6.84 -0.46 36.19 74.93 38.74 3040.572 30.88 7.26 -0.93 37.21 74.93 37.72 ------------------------------------------------------------------------------------------------------------------ Remark ： 1. Emission Level = Antenna Factor + Cable Loss + Meter Reading. 2. Measurement was up to 10th harmonic (~4GHz), but the emissions level were too low against the official limit and not report. Taiwan Tokin EMC Eng. Corp. Report No.: TTEMC-F91174 FCC ID.KUJCE9103 Page 3 of 3 Date of Test： Dec. 03, 2002 Temperature： 22°C EUT： Fan/Light Remote Control (Transmitter) Humidity： 63％ Test Position： EUT on Lie Emission Antenna Cable Meter Reading Emission Level Frequency Factor Loss Horizontal Horizontal Limits Margin MHz dB/m dB dBμV dBμV/m dBμV/m dB ------------------------------------------------------------------------------------------------------------------ Spurious / Harmonic Freq. (Above 1GHz, Peak Value) 1216.051 25.30 4.61 1.32 31.23 74.93 43.70 1520.083 25.52 5.56 -0.25 30.83 74.93 44.10 1824.166 27.04 6.77 -0.95 32.86 74.93 42.07 2128.166 28.08 6.02 -0.87 33.23 74.93 41.70 2432.224 28.68 6.39 -1.56 33.51 74.93 41.42 2736.336 29.81 6.84 -0.97 35.68 74.93 39.25 3040.572 30.88 7.26 -1.89 36.25 74.93 38.68 ------------------------------------------------------------------------------------------------------------------ Emission Antenna Cable Meter Reading Emission Level Frequency Factor Loss Vertical Vertical Limits Margin MHz dB/m dB dBμV dBμV/m dBμV/m dB ------------------------------------------------------------------------------------------------------------------ Spurious / Harmonic Freq. (Above 1GHz, Peak Value) 1216.051 25.30 4.61 7.28 37.19 74.93 37.74 1520.083 25.52 5.56 -0.31 30.77 74.93 44.16 1824.166 27.04 6.77 -0.60 33.21 74.93 41.72 2128.166 28.08 6.02 -1.15 32.95 74.93 41.98 2432.224 28.68 6.39 -0.25 34.82 74.93 40.11 2736.336 29.81 6.84 -0.55 36.10 74.93 38.83 3040.572 30.88 7.26 -0.99 37.15 74.93 37.78 ------------------------------------------------------------------------------------------------------------------ Remark ： 1. Emission Level = Antenna Factor + Cable Loss + Meter Reading. 2. Measurement was up to 10th harmonic (~4GHz), but the emissions level were too low against the official limit and not report. Taiwan Tokin EMC Eng. Corp. Report No.: TTEMC-F91174

FCC ID.KUJCE9103 Page 18 of 21 7. PHOTOGRAPHS 7.1. Photos of Radiated Measurement at Semi-Anechoic Chamber(30~1000MHz) EUT on Stand EUT on Side Taiwan Tokin EMC Eng. Corp. Report No.: TTEMC-F91174 FCC ID.KUJCE9103 Page 19 of 21 EUT on Lie 7.2. Photos of Radiated Measurement at Semi-Anechoic Chamber (1~4GHz) EUT on Stand Taiwan Tokin EMC Eng. Corp. Report No.: TTEMC-F91174 FCC ID.KUJCE9103 Page 20 of 21 EUT on Side EUT on Lie Taiwan Tokin EMC Eng. Corp. Report No.: TTEMC-F91174 FCC ID.KUJCE9103 Page 21 of 21 7.3. Photos of Emission Bandwidth Measurement 7.4. Photos of Periodic Operated Measurement Taiwan Tokin EMC Eng. Corp. Report No.: TTEMC-F91174
