Page 1 of 3 FEDERAL COMMUNICATIONS COMMISSION INTERFERENCE STATEMENT This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -- Reorient or relocate the receiving antenna. -- Increase the separation between the equipment and receiver. -- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -- Consult the dealer or an experienced radio/TV technician for help. CAUTION: To assure continued FCC compliance: Any changes or modifications not expressly approved by the grantee of this device could void the user's authority to operate the equipment. Page 1 of 2
Page 12 Chungear Industrial Co., Ltd. Fan-Light Remote Controller (Transmitter) FCC ID. : KUJCE9201 Schematics Diagram
Page 6 Chungear Industrial Co., Ltd. Fan-Light Remote Controller (Transmitter) FCC ID. : KUJCE9201 Photographs Photo 1 General Appearance (Front & Upper View) Photo 2 General Appearance (Rear & Bottom View) Page 7 Chungear Industrial Co., Ltd. Fan-Light Remote Controller (Transmitter) FCC ID. : KUJCE9201 Photo 3 Internal View (Remove Stand) Photo 4 Internal View (Remove Covers)
Page 4 Chungear Industrial Co., Ltd. Fan-Light Remote Controller (Transmitter) FCC ID. : KUJCE9201 Label Drawing l Label Placement Location (Back Side of EUT) FCC LABEL FCC ID.: KUJCE9201 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may
Page 8 Chungear Industrial Co., Ltd. Fan-Light Remote Controller (Transmitter) FCC ID. : KUJCE9201 Photo 5 PCB View (Component Side) Photo 6 PCB View (Solder Side)
Page 1 of 3
Page 11 Chungear Industrial Co., Ltd. Fan-Light Remote Controller (Transmitter) FCC ID. : KUJCE9201 Block Diagram [NOTE]: (1). These buttons are normally open ( i.e. spring loaded to remain open and only close when pushing) (2). There is no latching circuit to lock on transmitter after initial button is pushed.
FCC ID.KUJCE9201 Page 1 of 24 Audix Corporation Report No. TTEMC-KUJCE9201 APPLICATION FOR CERTIFICATION On Behalf of Chungear Industrial Co., Ltd. Fan-Light Remote Controller (Transmitter) Model : JY610 FCC IDKUJCE9201 Prepared for : Chungear Industrial Co., Ltd. 106 Kanho Rd., Taichung, Taiwan, R.O.C. Prepared By : Audix Corporation Technical Division EMC Department No. 53-11, Tin-Fu Tsun, Lin-Kou, Taipei Hsien, Taiwan, R.O.C. Tel : (02) 2609-9301, 2609-2133 Fax : (02) 2609-9303 File Number EM-G920532 Report Number TTEMC-F92098 Date of Test May 19 ~ 20, 2003 Date of Report May 27, 2003 FCC ID.KUJCE9201 Page 2 of 24 Audix Corporation Report No. TTEMC-KUJCE9201 TABLE OF CONTENTS Description Page TEST REPORT CERTIFICATION .......................................................................................................3 1. GENERAL INFORMATION..........................................................................................................4 1.1. Description of Device (EUT) ............................................................................................................. 4 1.2. Description of Test Facility ................................................................................................................ 5 1.3. Measurement Uncertainty .................................................................................................................. 5 2. POWERLINE CONDUCTED TEST ..............................................................................................6 3. RADIATED EMISSION TEST.......................................................................................................7 3.1. Test Equipment................................................................................................................................... 7 3.2. Test Setup ........................................................................................................................................... 7 3.3. Radiation Limit (§15.231) .................................................................................................................. 8 3.4. EUT’s Configuration during Compliance Measurement.................................................................... 8 3.5. Operating Condition of EUT .............................................................................................................. 8 3.6. Test Procedure .................................................................................................................................... 9 3.7. Radiated Emission Noise Measurement Results .............................................................................. 10 4. EMISSION BANDWIDTH TEST ................................................................................................16 4.1. Test Equipment................................................................................................................................. 16 4.2. Block Diagram of Test Setup ........................................................................................................... 16 4.3. Specification Limits (§15.231-(c)) ................................................................................................... 16 4.4. EUT’s Configuration during Compliance Measurement.................................................................. 16 4.5. Emission Bandwidth Measurement Results ..................................................................................... 16 5. PERIODIC OPERATED TEST.....................................................................................................18 5.1. Test Equipment................................................................................................................................. 18 5.2. Block Diagram of Test Setup ........................................................................................................... 18 5.3. Specification Limits [§15.231-(a)-(1)] ............................................................................................. 18 5.4. EUT’s Configuration during Compliance Measurement.................................................................. 18 5.5. Periodic Operated Measurement Results..........................................................................................18 5.6. Periodic Operated Measurement Results..........................................................................................18 6. DEVIATION TO TEST SPECIFICATIONS................................................................................20 7. PHOTOGRAPHS ..........................................................................................................................21 7.1. Photos of Radiated Measurement at Semi-Anechoic Chamber (30~1000MHz) ............................ 21 7.2. Photos of Radiated Measurement at Semi-Anechoic Chamber (Above 1GHz) ............................. 22 7.3. Photo of Emission Bandwidth Measurement ................................................................................... 24 7.4. Photo of Periodic Operated Measurement........................................................................................ 24 FCC ID.KUJCE9201 Page 3 of 24 Audix Corporation Report No. TTEMC-KUJCE9201 TEST REPORT CERTIFICATION Applicant Chungear Industrial Co., Ltd. Manufacturer #1 Chungear Industrial Co., Ltd. Manufacturer #2 Satellite Electronic (Zhongshan) Ltd. EUT Description Fan-Light Remote Controller (Transmitter) FCC ID KUJCE9201 (A) MODEL NO. JY610 (B) SERIAL NO. N/A (C) POWER SUPPLYDC 9V Measurement Procedure Used: FCC RULES AND REGULATIONS PART 15 SUBPART C, MAY 2002 AND ANSI C63.4/1992 The device described above was tested by Audix Corporation to determine the maximum emission levels emanating from the device. The maximum emission levels were compared to the FCC Part 15 subpart C limits both radiated and conducted emissions. The measurement results are contained in this test report and Audix Corporation is…
