KUJCE9202Fan-Light Remote Control Transmitter

FCC ID. KUJCE9202 Page 1 of 3 FCC ID. KUJCE9202 Page 2of 3 FCC ID. KUJCE9202 FEDERAL COMMUNICATIONS COMMISSION INTERFERENCE STATEMENT This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -- Reorient or relocate the receiving antenna. -- Increase the separation between the equipment and receiver. -- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -- Consult the dealer or an experienced radio/TV technician for help. FCC Label Compliance Statement: This device complies with Part 15 of the FCC Rules. Operation is subject to he following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Page 3of 3

Page 11 Chungear Industrial Co., Ltd. Fan-Light Remote Controller (Transmitter) FCC ID. : KUJCE9202 Block Diagram [NOTE]: (1). These buttons are normally open (i.e. spring loaded to remain open and only close when pushing) (2). There is no latching circuit to lock on transmitter after initial button is pushed.

Page 6 Chungear Industrial Co., Ltd. Fan-Light Remote Controller (Transmitter) FCC ID. : KUJCE9202 Photographs Photos 1 General Appearance (Front View) Photos 2 General Appearance (Back View)

Page 4 Chungear Industrial Co., Ltd. Fan-Light Remote Controller (Transmitter) FCC ID. : KUJCE9202 Label Drawing l Label Placement Location (Back Side of EUT) FCC IDKUJCE9202 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC LABEL

Page 7 Chungear Industrial Co., Ltd. Fan-Light Remote Controller (Transmitter) FCC ID. : KUJCE9202 Photos 3 Internal View (Removed Case Covers) Photos 4 PCB View (Component Side) Page 8 Chungear Industrial Co., Ltd. Fan-Light Remote Controller (Transmitter) FCC ID. : KUJCE9202 Photos 5 PCB View (Solder Side)

Page 12 Chungear Industrial Co., Ltd. Fan-Light Remote Controller (Transmitter) FCC ID. : KUJCE9202 Schematics Diagram

FCC ID.KUJCE9202 Page 1 of 27 Audix Corporation Report No.: TTEMC-F92135 APPLICATION FOR CERTIFICATION On Behalf of Chungear Industrial Co., Ltd. Fan-Light Remote Controller (Transmitter) Model : JY121-5 FCC IDKUJCE9202 Prepared for : Chungear Industrial Co., Ltd. 106 Kanho Rd., Taichung, Taiwan, R.O.C. Prepared by : Audix Corporation Technical Division EMC Department No. 53-11, Tin-Fu Tsun, Lin-Kou Hsiang, Taipei Hsien 24443, Taiwan, R.O.C. Tel : (02) 2609-9301, 2609-2133 Fax : (02) 2609-9303 File Number ATM-G92610 Report Number TTEMC-F92135 Date of Test Jul. 02, 2003 Date of Report Jul. 09, 2003 FCC ID.KUJCE9202 Page 2 of 27 Audix Corporation Report No.: TTEMC-F92135 TABLE OF CONTENTS Description Page TEST REPORT CERTIFICATION.........................................................................................................3 1. GENERAL INFORMATION.............................................................................................................4 1.1. Description of Device (EUT).........................................................................................................4 1.2. Description of Test Facility............................................................................................................5 1.3. Measurement Uncertainty..............................................................................................................5 2. POWERLINE CONDUCTED MEASUREMENT.............................................................................6 3. RADIATED EMISSION MEASUREMENT.....................................................................................7 3.1. Test Equipment.............................................................................................................................7 3.2. Test Setup.....................................................................................................................................7 3.3. Radiation Limit (§15.231)..............................................................................................................8 3.4. EUT’s Configuration during Compliance Measurement...................................................................8 3.5. Operating Condition of EUT..........................................................................................................8 3.6. Test Procedure..............................................................................................................................9 3.7. Radiated Emission Noise Measurement Results.............................................................................10 4. EMISSION BANDWIDTH MEASUREMENT...............................................................................19 4.1. Test Equipment...........................................................................................................................19 4.2. Block Diagram of Test Setup.......................................................................................................19 4.3. Specification Limits (§15.231-(c))................................................................................................19 4.4. EUT’s Configuration during Compliance Measurement.................................................................19 4.5. Emission Bandwidth Measurement Results...................................................................................19 5. PERIODIC OPERATED MEASUREMENT...................................................................................21 5.1. Test Equipment...........................................................................................................................21 5.2. Block Diagram of Test Setup.......................................................................................................21 5.3. Specification Limits [§15.231-(a)-(1)]..........................................................................................21 5.4. EUT’s Configuration during Compliance Measurement.................................................................21 5.5. Periodic Operated Measurement Results.......................................................................................21 6. DEVIATION TO TEST SPECIFICATIONS...................................................................................23 7. PHOTOGRAPHS..............................................................................................................................24 7.1. Photos of Radiated Measurement at Semi-Anechoic Chamber (30~1000MHz).......................................24 7.2. Photos of Radiated Measurement at Semi-Anechoic Chamber (1~4GHz)........................................25 7.3. Photos of Emission Bandwidth Measurement................................................................................27 7.4. Photos of Periodic Operated Measurement....................................................................................27 FCC ID.KUJCE9202 Page 3 of 27 Audix Corporation Report No.: TTEMC-F92135 TEST REPORT CERTIFICATION Applicant Chungear Industrial Co., Ltd. Manufacturer Chungear Industrial Co., Ltd. EUT Description Fan-Light Remote Controller (Transmitter) FCC ID KUJCE9202 (A) MODEL NO. JY121-5 (B) SERIAL NO. N/A (C) POWER SUPPLYDC 9V Measurement Procedure Used: FCC RULES AND REGULATIONS PART 15 SUBPART C, MAY 2002 AND ANSI C63.4/1992 The device described above was tested by AUDIX CORPORATION to determine the maximum emission levels emanating from the device. The maximum emission levels were compared to the FCC Part 15 subpart C limits both radiated and conducted emissions and output signal levels. The measurement results are contained in this test report and AUDIX CORPORATION is assumed full responsibility for the accuracy and completeness of these measurements. Also, this report shows that the EUT to be technically compliant with the FCC official limits. This report applies to above tested sample only. This report shall not be reproduced in part without written ap…

Text truncated - open the document above for the full version.

FCC ID.KUJCE9202 Page 24 of 27 Audix Corporation Report No.: TTEMC-F92135 7. PHOTOGRAPHS 7.1. Photos of Radiated Measurement at Semi-Anechoic Chamber (30~1000MHz) EUT on Stand EUT on Side FCC ID.KUJCE9202 Page 25 of 27 Audix Corporation Report No.: TTEMC-F92135 EUT on Lie 7.2. Photos of Radiated Measurement at Semi-Anechoic Chamber (1~4GHz) EUT on Stand FCC ID.KUJCE9202 Page 26 of 27 Audix Corporation Report No.: TTEMC-F92135 EUT on Side EUT on Lie FCC ID.KUJCE9202 Page 27 of 27 Audix Corporation Report No.: TTEMC-F92135 7.3. Photos of Emission Bandwidth Measurement 7.4. Photos of Periodic Operated Measurement
