KVW61020307M3SR Series 4400 VHF/Transmitter

M3SRTRANSCEIVER•X.4410A/X.4460A Operator’sManual 6076.0822.12– W.1 / W.2 – In order to comply with the FCC radiofrequency exposure limits of 1.1310, this equipment must be installed in such a way as to provide a minimum separation distance of 2 m from the transmitting antenna to persons nearby. WARNING

Digital Reprogrammable Software Radios M3SR Your key to interoperability
High operational flexibility while on mission
Interoperability with existing radios according to international standards
Easy system integration
Low life cycle costs
Software download of new waveforms
High growth potential through P 3 I (preplanned product improvement) 2 Digital Reprogrammable Software Radios M3SR M3SR (multiband, multimode and multi- role surface radio) represents an innova- tive and versatile generation of software radios for use in the navy, in civil and mil- itary air traffic control, air defence, and in stationary applications. In addition to M3TR (multiband, multi- mode and multirole tactical radio) and M3AR (multiband, multimode and multi- role airborne radio), the M3SR series is the third element of a new radio equip- ment generation. All three types feature a functionality that can be varied by means of software. For the commercial user, the basic units come standard with the waveform for air traffic control (ATC) in line with EN 300676. M3SR can be used both in normal ATC operation and as an emer- gency backup radio. The M3SR series is interoperable with many types of existing radio equipment and standards. For military customers, this means seamless communication with their own and allied troops. To com- municate with neighbouring troops, the radio is switched to the waveform or com- munication protocol used there. This switchover can be made online even during a mission. The operational functions and the avail- able waveforms are determined by the loaded application software. Additional functions can be implemented, as required, by downloading the appropriate software and/or using plug-in hardware modules. Modular design The M3SR features highly modular hard- ware and software architecture. All M3SR units are based on the uniform Radio Basis KR 4400. The versatile upgrade concept (P 3 I) of the basic version helps to avoid unnecessarily high initial investment costs. The M3SR is available as a receiver, multireceiver, transmitter or transceiver, according to the customer’s require- ments. Radio Basis KR4400 The various models are set up on the hardware and software of the Radio Basis KR 4400, which forms the central and common part of all M3SR radios. The radio basis is independent of the RF- specific modules. Additional radio- specific hardware and software modules define the performance features of the radio. The KR 4400 consists of the mechanical frame, the radio platform (motherboard), and a front panel with audio interface, loudspeaker and status displays. The plat- form is the control center of the radio. The embedded realtime operating system controls and monitors all the functions in the radio. A control panel (GB 4000C) can be integrated for local control of the radios. The main tasks of the radio basis include:
Monitoring and control of the com- plete radio unit
Mechanical and electrical accommo- dation of modules and control panel
Digital voice and data processing
Internal routing of information data to the interfaces
Standard interfaces to peripherals
Audio interface, loading of encryp- tion keys and display of status infor- mation An oven-controlled crystal oscillator (OCXO) is integrated as standard to meet the stringent requirements regarding time stability. For the configuration of the various radio models, the radio basis is equipped with slots for the radio modules, and a mechanical fixture on the side to accom- modate the transmitter module. Digital Reprogrammable Software Radios M3SR 3 Key features of the modules The modules have the following out- standing features:
Independent use of all modules (no alignment or manual adjustment when modules are replaced)
Central download of software and firmware, either locally or remotely (no need to open the radio unit)
Data exchange via radio module bus
Type label with bar code identification down to PCB level (fast automated detection and identification)
All modules with electromagnetic shielding (maximum EMC/EMI immu- nity)
All settings made via software (reduced maintenance)
Fast and easy replacement of mod- ules (short MTTR) Modules for radio module slots VHF/UHF Synthesizer Module GF 4400T The synthesizer module is the core of the high-frequency structure of the radio unit. It covers the frequency range from 100 MHz to 512 MHz, generates the RF signal for driving the transmitter, and supplies the local oscillator (LO) signal for the receiver module. Direct digital synthe- sis (DDS) technology ensures fine fre- quency tuning with high accuracy and high speed. The extremely low-noise signal generation allows the radio to be used at sites with stringent requirements regarding large-signal immunity (colloca- tion). VHF/UHF Receiver Module ET 4400 The Main Receiver Module ET 4400 can be universally used for all operational modes in the VHF/UHF range. The use of programmable VLSI components makes for the extremely compact size of the module which occupies only one slot. The flexible digital demodulator allows processing of complex digital waveforms. VHF/UHF Guard Receiver ET 4400G The ET 4400G simultaneously monitors the emergency frequencies in the VHF (121.5 MHz) and UHF (243 MHz) ranges and can be installed in any M3SR model, irrespective of the other modules. The AF of the guard receiver can either be routed to one of the audio interfaces, or mixed with the AF of the main receiver. The soft- ware for the use of a guard receiver is supplied with the basic unit. Electronic Protective Measures (EPM) Processor Module GP 4400 The EPM Processor Module GP 4400 is a powerful processor module that performs the data processing for special waveforms. It occupies one radio module slot. The module can host EPM waveforms such as SATURN, SECOS or HAVE QUICK I/II on its memory devices. The functionality of the module is determined by the loaded soft- ware. Even switching between different preloaded waveforms is possible. …

Text truncated - open the document above for the full version.

Radio Communication Systems Division 6076.0822.12.02 – 1 Pƒr…h‡‚…†Hhˆhy H"TS WCAVCAhqWCAVCAUS6IT8@DW@ST (valid for models ≥ 02) M3SR Software Release:8.00 XT 4410A XU 4410A XD 4410A XD 4460A XU 4410A XT 4460A © Copying of this document as well as any other utilization and communication of its content are only admissible with the permission of the originator or other authorized persons. Any disregard will be prosecuted and is subject to restitution (UrhG, UWG, BGB). For the case a patent is is- sued or the design is officially registered all rights are reserved. SPC9@ T8CX6SaB€iC 8‚FB(9' %& H.pur(H.uyq‚…s†‡… $(Ury'(# !(D‡#('(# !( Uryrsh‘'(# !( ! %#D‡#('(# !( ! %# Q…v‡rqv‡urArqr…hySrƒˆiyvp‚sBr…€h’(Tˆiwrp‡‡‚puhtr(9h‡hv‡u‚ˆ‡‡‚yr…hpr†)‚…qr…‚s€htv‡ˆqr‚y’ '" 6076.0822.12.02 – 2 Adressen/Addresses FIRMENSITZ/HEADQUARTERSPhone Fax E-mail Rohde & Schwarz GmbH & Co. KG Mühldorfstraße 15 · D-81671 München Postfach 80 14 69 · D-81614 München +49 (89) 41 29-0 +49 89 4129-121 64 - WERKE/PLANTS Rohde & Schwarz Messgerätebau GmbH Riedbachstraße 58 · D-87700 Memmingen Postfach 1652 · D-87686 Memmingen +49 (8331) 108-0 +49 (8331) 108-11 24 - Rohde & Schwarz GmbH & Co. KG Werk Teisnach Kaikenrieder Straße 27 · D-94244 Teisnach Postfach 1149 · D-94240 Teisnach +49 (9923) 857-0 +49 (9923) 857-11 74 - Rohde & Schwarz GmbH & Co. KG Dienstleistungszentrum Köln Graf-Zeppelin-Straße 18 · D-51147 Köln Postfach 98 02 60 · D-51130 Köln +49 (2203) 49-0 +49 (2203) 49 51-308 [email protected] [email protected] TOCHTERUNTERNEHMEN/SUBSIDIARIES Rohde & Schwarz Vertriebs-GmbH Mühldorfstraße 15 · D-81671 München Postfach 80 14 69 · D-81614 München +49 (89) 41 29-137 74 +49 (89) 41 29-137 77 - Rohde & Schwarz International GmbH Mühldorfstraße 15 · D-81671 München Postfach 80 14 60 · D-81614 München +49 (89) 41 29-129 84 +49 (89) 41 29-120 50 - Rohde & Schwarz Engineering and Sales GmbH Mühldorfstraße 15 · D-81671 München Postfach 80 14 29 · D-81614 München +49 (89) 41 29-137 11 +49 (89) 41 29-137 23 - R&S BICK Mobilfunk GmbH Fritz-Hahne-Str. 7 · D-31848 Bad Münder Postfach 2062 · D-31844 Bad Münder +49 (5042) 998-0 +49 (5042) 998-105 - Rohde & Schwarz FTK GmbH Wendenschlossstraße 168, Haus 28 D-12557 Berlin +49 (30) 658 91-122 +49 (30) 655 50-221 - Rohde & Schwarz SIT GmbH Agastraße 3 D-12489 Berlin +49 (30) 658 84-0 +49 (30) 658 84-183 ADRESSEN DEUTSCHLAND/ADDRESSES GERMANY Rohde & Schwarz Vertriebs-GmbH Mühldorfstraße 15 · D-81671 München Postfach 80 14 69 · D-81614 München +49 89 4129-133 74 +4989 4129-133 77 - Zweigniederlassungen der Rohde & Schwarz Vertriebs-GmbH/Branch offices of Rohde & Schwarz Vertriebs-GmbH Zweigniederlassung Nord, Geschäftsstelle Berlin Ernst-Reuter-Platz 10 · D-10587 Berlin Postfach 100620 · D-10566 Berlin +49 (30) 34 79 48-0 +49 (30) 34 79 48 48 - Zweigniederlassung Büro Bonn Josef-Wirmer-Straße 1-3 · D-53123 Bonn Postfach 140264 · D-53057 Bonn +49 (228) 918 90-0 +49 (228) 25 50 87 - Zweigniederlassung Nord, Geschäftsstelle Hamburg Steilshooper Alle 47 · D-22309 Hamburg Postfach 60 22 40 · D-22232 Hamburg +49 (40) 63 29 00-0 +49 (40) 630 78 70 - Zweigniederlassung Mitte, Geschäftsstelle Köln Niederkasseler Straße 33 · D-51147 Köln Postfach 900 149 · D-51111 Köln +49 (2203) 807-0 +49 (2203) 807-650 - Zweigniederlassung Süd, Geschäftsstelle München Mühldorfstraße 15 · D-81671 München Postfach 80 14 69 · D-81614 München +49 (89) 41 86 95-0 +49 (89) 40 47 64 - Zweigniederlassung Süd, Geschäftsstelle Nürnberg Donaustraße 36 D-90451 Nürnberg +49 (911) 642 03-0 +49 (911) 642 03-33 - Zweigniederlassung Mitte, Geschäftsstelle Neu-Isenburg Siemensstraße 20 D-63263 Neu-Isenburg +49 (6102) 20 07-0 +49 (6102) 20 07 12 - ADRESSEN WELTWEIT/ADDRESSES WORLDWIDE siehe / see AustriaAlbania ROHDE & SCHWARZ Bureau d'Alger 5B Place de Laperrine 16035 Hydra-Alger +213 (21) 48 20 18 +213 (21) 69 46 08 Algeria PRECISION ELECTRONICA S.R.L. Av. Pde Julio A. Roca 710 - 6° Piso (C1067ABP) Buenos Aires +541 (14) 331 41 99 +541 (14) 334 51 11 [email protected] Argentina ROHDE & SCHWARZ (AUSTRALIA) Pty. Ltd. Sales Support Unit 6 2-8 South Street Rydalmere, N.S.W. 2116 +61 (2) 88 45 41 00 +61 (2) 96 38 39 88 [email protected] schwarz.com Australia ROHDE & SCHWARZ-ÖSTERREICH Ges.m.b.H. Am Euro Platz 3 Gebäude B 1120 Wien +43 (1) 602 61 41-0 +43 (1) 602 61 41-14 [email protected] Austria ROHDE & SCHWARZ Azerbaijan Liaison Office Baku ISR Plaza 340 Nizami Str. 370000 Baku +994 (12) 93 31 38 +994 (12) 93 03 14 [email protected] Schwarz.com Azerbaijan siehe / see DenmarkBaltic Countries BIL Consortium Ltd. Corporation Office House No: 95/A, Block - 'F' Road No. 4, Banani Dhaka-1213 +880 (2) 881 06 53 +880 (2) 882 82 91 Bangladesh ROHDE & SCHWARZ BELGIUM N.V. Excelsiorlaan 31 Bus 1 1930 Zaventem +32 (2) 721 50 02 +32 (2) 725 09 36 [email protected] Belgium ROHDE & SCHWARZ DO BRASIL LTDA. Av. Alfredo Egidio de Souza Aranha n° 177, 1° andar - Santo Amaro 04726-170 Sao Paulo - SP +55 (11) 56 44 86 11 (general) +55 (11) 56 44 86 25 (sales) +55 (11) 56 44 86 36 [email protected] schwarz.com Brasil GKL Equipment PTE. Ltd. Jurong Point Post Office P.O.Box 141 Singapore 916405 +65 (6) 276 06 26 +65 (6) 276 06 29 [email protected] Brunei ROHDE & SCHWARZ ÖSTERREICH Representation Office Bulgaria 39, Fridtjof Nansen Blvd. 1000 Sofia +359 (2) 963 43 34 +359 (2) 963 21 97 [email protected] Bulgaria siehe / see SloveniaBosnia- Herzegovina Adressen/Addresses ROHDE & SCHWARZ CANADA Inc. 555 March Rd. Kanata, Ontario K2K 2M5 +1 (613) 592 80 00 +1 (613) 592 80 09 [email protected] Canada TEKTRONIX CANADA Inc. Test and Measurement 4929 Place Olivia Saint-Laurent, Pq Montreal H4R 2V6 +1 (514) 331 43 34 +1 (514) 331 59 91 Canada DYMEQ Ltda. Av. Larrain 6666 Santiago +56 (2) 339 20 00 +56 (2) 339 20 10 [email protected] Chile ROHDE & SCHWARZ China Ltd. Representati…

Text truncated - open the document above for the full version.

Response to TCB Findings Q: Please provide a tune-up procedure for the transmitter. Response: There is no tuning other than selecting the frequency via the control unit according to the User manual once the appropriate input has been selected (mapped). Q: We need a statement addressed to FCC assuring that the operation on 8.33kHz channel spacing will not be used in US. A channel spacing of 25kHz is allowed only. Response: Statement provided.

Bureau Veritas Consumer Product Services, Inc. Curtis-Straus, LLC Division 527 Great Road Littleton, MA 01460 US Tel: 978.486.8880 Fax: 978.486.8828 www.curtis-straus.com October 3, 2008 To Whom It May Concert: Please supersede the following exhibit Internal Photos 2 of 2 for Rohde & Schwarz GmbH & Co KG FCC ID: KVW61020307. The reason for this request is that the exhibit was uploaded incorrectly. If you have any questions please contact me at anytime. Sincerely, Kathlene McQuaid Administrative Assistant Tel: 978-486-8880 ext. 278 Fax: 978-486-4926 Email: [email protected]

Bureau Veritas Consumer Product Services, Inc. Curtis-Straus, LLC Division 527 Great Road Littleton, MA 01460 US Tel: 978.486.8880 Fax: 978.486.8828 www.curtis-straus.com October 9, 2008 To Whom It May Concern: We request that file X.44x0A_6076.0822.12.02-mod.03 rev to take the place of the following files Operational Manual 1 of 3, Operational Manual 2 of 3 and Operational Manual 3 of 3. Thiswas requested by the applicant Rohde & Schwarz GmbH & Co KG for FCC ID: KVW61020307. If you have any questions please contact me at anytime. Sincerely, Kathlene McQuaid Administrative Assistant Tel: 978-486-8880 ext. 278 Fax: 978-486-4926 [email protected]

Prediction of MPE limit at a given distance Equation from page 18 of OET Bulletin 65, Edition 97-01 where:S = power density P = power input to the antenna G = power gain of the antenna in the direction of interest relative to an isotropic radia R = distance to the center of radiation of the antenna Maximum Power = 1.405X30 Watts=42.150 Watts for 90% amplitude modulation Maximum peak output power at antenna input terminal:46.25(dBm) Maximum peak output power at antenna input terminal:42150(mW) Antenna gain(typical):2(dBi) Maximum antenna gain:1.584893192(numeric) Prediction distance:200(cm) Prediction frequency:118-136(MHz) PE limit for uncontrolled exposure at prediction frequenc y:0.2(mW/cm^2) Power density at prediction frequency:0.132901(mW/cm^2) Maximum allowable antenna gain:3.775022721(dBi) Margin1.775022721 2 4 R PG S π = ator

Master: PT87-D Date: February 25, 2001 Test Report: 3W06782 Applicant: Rohde & Schwarz 555 March Road, Kanata Ontario K2K 2M5 Equipment Under Test: XT4410A VHF Transceiver (EUT) FCC ID: KVW61020307 In Accordance With: FCC Part 87, Subpart D Tested By: Nemko Canada Inc. 303 River Road, R.R. 5 Ottawa, Ontario K1V 1H2 Authorized By: Glen Westwell, Wireless Technologist Date: 23 May 2003 Total Number of Pages: 23 Nemko Canada Inc. FCC PART 87, SUBPART D PROJECT NO.: 3W06782 EQUIPMENT: VHF Transceiver Page 2 of 23 Table of Contents Section 1. Summary Of Test Results ..................................................................................... 3 Section 2. General Equipment Specification......................................................................... 5 Section 3. RF Power Output ................................................................................................... 6 Section 4. Audio Frequency Response ................................................................................... 7 Section 5. Audio Low-Pass Filter Response .......................................................................... 8 Section 6. Modulation Limiting.............................................................................................. 9 Section 7. Occupied Bandwidth ........................................................................................... 10 Section 8. Spurious Emissions at Antenna Terminals ....................................................... 13 Section 9. Field Strength of Spurious Emissions ................................................................ 16 Section 10. Frequency Stability.............................................................................................. 18 Section 11. Block Diagrams ....................................................................................................19 Section 12. Test Equipment List ............................................................................................ 23 Nemko Canada Inc. FCC PART 87, SUBPART D PROJECT NO.: 3W06782 EQUIPMENT: VHF Transceiver Page 3 of 23 Section 1. Summary Of Test Results General All measurements are traceable to national standards. These tests were conducted on a sample of the equipment for the purpose of demonstrating compliance with FCC Part 87, Subpart D. Equipment Type: TNB Production Unit THIS TEST REPORT RELATES ONLY TO THE ITEM(S) TESTED. THE FOLLOWING DEVIATIONS FROM, ADDITIONS TO, OR EXCLUSIONS FROM THE TEST SPECIFICATIONS HAVE BEEN MADE. See “ Summary of Test Data”. TESTED BY: ______________________________ DATE: 23 May 2003 Russell Grant, Nemko Canada Inc. FCC PART 87, SUBPART D PROJECT NO.: 3W06782 EQUIPMENT: VHF Transceiver Page 4 of 23 Summary Of Test Data Name Of Test Para. No. Result RF Power Output 2.1046 Complies Audio Frequency Response 2.1047 Complies Audio Low-Pass Filter Response 2.1047 N/A (1) Modulation Limiting 2.1047 Complies Occupied Bandwidth 2.1049 Complies Spurious Emissions at Antenna Terminals 2.1051 Complies Field Strength of Spurious Emissions 2.1053 Complies Frequency Stability 2.1055 Complies (1) This equipment does not use frequency modulation. Therefore there is no requirement for an audio low pass filter. . Nemko Canada Inc. FCC PART 87, SUBPART D PROJECT NO.: 3W06782 EQUIPMENT: VHF Transceiver Page 5 of 23 Section 2. General Equipment Specification Manufacturer: Rohde & Schwarz Model No.: XT4410A Serial No.: 100013 Date Received In Laboratory: April 17, 2003 Nemko Identification No.: 1 TX/RX 118 – 136.975 MHz RF Power Output 3 – 30 W Modulation Double Sideband AM Voice Modulation Limit 90% AM Emission Designator 6K00A3E Equipment Under Test ROHDE & SCHWARZ M3SR XT4410A TRANSCEIVER P/N 6102.0307.91 S/N 100013 ROHDE & SCHWARZ AC POWER SUPPLY M/N IN 4000A P/N 6105.5500.03 S/N 100166 / 2003988 Nemko Canada Inc. FCC PART 87, SUBPART D PROJECT NO.: 3W06782 EQUIPMENT: VHF Transceiver Page 6 of 23 Section 3. RF Power Output Para. No.: 2.1046 Test Performed By: Russell Grant Date of Test: April 29, 2003 Minimum Standard: 87.131, 50W Test Conditions: 120VAC 27°C, 16%RH Test Results: Complies. The maximum RF output power is 41.3 W with 90% AM modulation. The carrier power is within –0.3 dB of the manufacturer’s rating of RF power output. Measurement Data: TX 128 MHz Modulated 2500 Hz, 16 dB overdrive, ref: 50% AM, 1000 Hz Carrier Power Mean Power Rated Measured(Measured/Rated) dB Rated Measured (Measured/Rated) dB 30.0 29.2 -0.1 42.2 41.3 -0.1 3.0 2.8 -0.3 4.2 4.0 -0.2 Note: Mean power rating is based on the limit of 90% AM. This is equivalent to 1.405 x carrier power. Carrier power is the average power supplied to the antenna transmission line by a transmitter during one radio frequency cycle taken under the condition of no modulation. Mean power is the average power supplied to the antenna transmission line by a transmitter during an interval of time sufficiently long compared with the lowest frequency encountered in the modulation taken under normal operating conditions. Nemko Canada Inc. FCC PART 87, SUBPART D PROJECT NO.: 3W06782 EQUIPMENT: VHF Transceiver Page 7 of 23 Section 4. Audio Frequency Response Para. No.: 2.1047 Test Performed By: Russell Grant Date of Test: April 30, 2003 Minimum Standard: N/A Test Conditions: 120VAC 22°C, 16%RH Test Results: See attached graph. Measurement Data: Audio Frequency Response -90 -80 -70 -60 -50 -40 -30 -20 -10 0 10 100100010000 Frequency (Hz) Response (dB) Nemko Canada Inc. FCC PART 87, SUBPART D PROJECT NO.: 3W06782 EQUIPMENT: VHF Transceiver Page 8 of 23 Section 5. Audio Low-Pass Filter Response Para. No.: 2.1047 Test Performed By: Date of Test: Minimum Standard: Test Conditions: Test Results: N/A Measurement Data: Nemko Canada Inc. FCC PART 87, SUBPART D PROJECT NO.: 3W06782 EQUIPMENT: VHF Transceiver Page 9 of 23 Section 6. Modulation Limiting Para. No.: 2.1047 Test Performed By: Russell Grant Date of Test: April 30, 2003 Minimum Standard: 87.141(b) 100% Test Conditions: 1…

Text truncated - open the document above for the full version.

Nemko Canada Inc. FCC PART 87, SUBPART D PROJECT NO.: 3W06782 EQUIPMENT: VHF Transceiver Page 17 of 23 TX 128 MHz, 30 Watts Modulated 2500 Hz, 16 dB overdrive (ref: 50% modulation, 1000 Hz)
