L2C0021RAutomotive Security/Convenience Receiver

Re: Certification for Delphi Delco 28015738 Receiver Model: 28015738 FCC ID: L2C0021R IC: 3432A-0021R USER'S MANUAL INFORMATION (PRELIMINARY) The User's Manual is in preparation. The following material will be contained in the manual: FCC ID: L2C0021R IC: 3432A-0021R This device complies with Part 15 of the FCC Rules and with RSS-210 of Industry Canada. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. WARNING: Changes or modifications not expressively approved by the party responsible for compliance could void the user's authority to operate the equipment. The term “IC:” before the radio certification number only signifies that Industry Canada technical specifications were met.

Re: Certification for Delphi Delco 28015738 Receiver PN: 28015738 FCC ID: L2C0021R IC: 3432A-0021R POWER OF ATTORNEY A letter granting Valdis V. Liepa the Power of Attorney is on file and can be provided when so requested. Re: Certification for Delphi Delco 28015738 Receiver PN: 28015738 FCC ID: L2C0021R IC: 3432A-0021R REQUEST FOR CONFIDENTIALITY Pursuant to 47 CRF 0.459, Delphi Delco requests that a part of the subject application be held confidential. This comprises Exhibits (5) Schematics (10) Parts List (Part of Exhibit only) Delphi Delco has spent substantial effort in developing this product and it is one of the first of its kind in industry. Having the subject information easily available to "competition" would negate the advantage they have achieved by developing this product. Not protecting the details of the design will result in financial hardship. If there are any questions regarding this request, please contact me at the above address or call 734-483-4211, fax 734-647-2106 or e-mail [email protected]. Sincerely, Valdis V. Liepa Research Scientist University of Michigan August 27, 2004 Re: Certification for Delphi Delco 28015738 Receiver PN: 28015738 FCC ID: L2C0021R IC: 3432A-0021R STATEMENT OF MODIFICATIONS There were no modifications made to the DUT by this test laboratory. (Also see Section 3.1 of the attached Test Report). _____________________ Valdis V. Liepa Research Scientist Re: Certification for Delphi Delco 28015738 Receiver PN: 28015738 FCC ID: L2C0021R IC: 3432A-0021R GENERAL PRODUCT INFORMATION The device, for which certification is pursued, has been designed by: Delphi Automotive Systems One Corporate Center Kokomo, IN 46904-9005 Ayax Mayagoitia Padilla Tel: (915) 612-8153 Fax: (915) 612-7934 It will be manufactured by: Delphi Automotive Systems Mexico Technical Center Ave. Hermanos Escobar # 5756 Cd. Juarez. Chih. Mex. CP 32310 Ayax Mayagoitia Padilla Tel: (915) 612-8153 Fax: (915) 612-7934 Canadian Contact: Richard Wilkins c/o Delphi Energy and Chassis Systems Oshawa, Ontario L1N 7S6 [email protected] Ph. (905)644-5216

315MHz ant. SAW filter LNA (low noise) , Crystal RF AMP LC (filter) 325.7MHz LO MIXER 10.7MHz IF filter Limiter LF filter Data Slicer Data output 6 3 3 9 13 13 1 14 14 8 17 8 10 5 5 23 26 4 4 7 7 2 2 Limiter Demodulator- Gain BW=200MHz VCO Divider 651.4 MHz Frequency VCO / 2 10.178125 MHz

August 27, 2004 American Telecommunications Certification Body, Inc. 6731 Whittier Avenue Suite C110 McLean, VA 22101 RE: Certification Application FCC ID: L2C0021R Please find enclosed application materials for certification of Delphi Delco 28015738 Receiver. Note: 1) portions of this submittal are filed Confidential 2) a list of the modifications made is provided in Attestations. If there are any questions regarding the application or testing performed, please contact me at the above address or call 734-483-4211, fax 734-647-2106, or e-mail [email protected]. Sincerely, Valdis V. Liepa Research Scientist

August 27, 2004 Federal Communications Commission Equipment Approval Services P.O. Box 358315 Pittsburgh, PA 15251-5315 Re: Certification for Delphi Delco 28015738 Receiver PN: 28015738 FCC ID: L2C0021R IC: 3432A-0021R Please find enclosed application materials for certification of Delphi Delco 28015738 Receiver. We tested it and found it to comply with FCC Part 15. If there are any questions regarding the application or testing performed, please contact me at the above address or call 734-483-4211, fax 734-647-2106, or e-mail [email protected]. Sincerely, Valdis V. Liepa Research Scientist August 27, 2004 Certification and Engineering Bureau Industry Canada 3701 Carling Avenue, Bldg. 94 Ottawa, Ontario K2H 8S2 Re: Certification for Delphi Delco 28015738 Receiver PN: 28015738 FCC ID: L2C0021R IC: 3432A-0021R Please find enclosed application materials for certification of Delphi Delco 28015738 Receiver. We tested the device and found it to comply with RSS-210. The product is identified by: IC: 3432A-0021R If there are any questions, suggestions, etc., regarding the application or testing performed, please contact me at the above address or call 734-483-4211, fax 734-647- 2106; e-mail: [email protected]. Sincerely, Valdis V. Liepa Research Scientist

1. Description of Operation. Super Heterodyne (315MHz) circuit : RF signal is received by helical antenna, the signal goes to a 315 MHz SAW filter a LNA pramplifier and finally applied to Infineon Receiver IC TDA5211. This receiver IC has a LNA Stage one mixer, one IF filter at 10.7 MHZ a ASK detector , a low pass data filter of 5KHz and a data slicer circuit. Received digital Data is further processed by the master microcontroller IC. The LO signal which is also applied to the mixer stage is generated By a Frequency syntheziser which consist of a crystal controlled Reference oscillator running at 10.178 MHz a VCO running at 651.4 MHz which is divided by 2 and applied to the mixer to get the 10.7 MHz IF frequency. The VCO (651.4 MHz) is also divided by 64 in this process. 2. Owner/Operator manual (if available) Not Available. 3. Product Information. a) Designed by : Delphi Delco Electronics b) Manufactured by : Delphi Delco Electronics c) Person responsible for the product : Ayax Mayagoitia Padilla Mexico Technical Center Ave. Hermanos Escobar # 5756 Cd. Juarez. Chih. Mex. CP 32310 MEX. Line: (656) 629-71-00 Ext. 5-8153 Fax MEX. Line: (656) 629-71-00 Ext. 5-8153 Phone U.S. Line: (915) 612-8153 Fax U.S. Line: (915) 612-7934 e-mail : [email protected]
