L2C0022RRKE/TPM Receiver

Re: Certification for Delphi Delco 15270437 Receiver Model: 15270437 FCC ID: L2C0022R IC: 3432A-0022R USER'S MANUAL INFORMATION (PRELIMINARY) The User's Manual is in preparation. The following material will be contained in the manual: FCC ID: L2C0022R IC: 3432A-0022R This device complies with Part 15 of the FCC Rules and with RSS-210 of Industry Canada. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. WARNING: Changes or modifications not expressively approved by the party responsible for compliance could void the user's authority to operate the equipment. The term “IC:” before the radio certification number only signifies that Industry Canada technical specifications were met.

Re: Certification for Delphi Delco 15270437 Receiver Model: 15270437 FCC ID: L2C0022R IC: 3432A-0022R POWER OF ATTORNEY A letter granting Valdis V. Liepa the Power of Attorney is on file and can be provided when so requested. Re: Certification for Delphi Delco 15270437 Receiver Model: 15270437 FCC ID: L2C0022R IC: 3432A-0022R REQUEST FOR CONFIDENTIALITY Pursuant to 47 CRF 0.459, Delphi Delco requests that a part of the subject application be held confidential. This comprises Exhibits (5) Schematics (10) Parts List (Part of Exhibit only) Delphi Delco has spent substantial effort in developing this product and it is one of the first of its kind in industry. Having the subject information easily available to "competition" would negate the advantage they have achieved by developing this product. Not protecting the details of the design will result in financial hardship. If there are any questions regarding this request, please contact me at the above address or call 734-483-4211, fax 734-647-2106 or e-mail [email protected]. Sincerely, Valdis V. Liepa Research Scientist University of Michigan December 16, 2004 Re: Certification for Delphi Delco 15270437 Receiver Model: 15270437 FCC ID: L2C0022R IC: 3432A-0022R STATEMENT OF MODIFICATIONS There were no modifications made to the DUT by this test laboratory. (Also see Section 3.1 of the attached Test Report). _____________________ Valdis V. Liepa Research Scientist Re: Certification for Delphi Delco 15270437 Receiver Model: 15270437 FCC ID: L2C0022R IC: 3432A-0022R GENERAL PRODUCT INFORMATION The device, for which certification is pursued, has been designed by: Delphi Automotive Systems One Corporate Center Kokomo, IN 46904-9005 Ramon Morales Rueda Tel: (915) 782-8296 Fax: (915) 783-7934 It will be manufactured by: Mexico Technical Center Ave. Hermanos Escobar # 5756 Cd. Juarez. Chih. Mex. CP 32310 Ramon Morales Rueda Tel: (915) 782-8296 Fax: (915) 783-7934 Canadian Contact: Richard Wilkins c/o Delphi Energy and Chassis Systems Oshawa, Ontario L1N 7S6 [email protected] Ph. (905)644-5216

December 16, 2004 American Telecommunications Certification Body, Inc. 6731 Whittier Avenue Suite C110 McLean, VA 22101 RE: Certification Application FCC ID: L2C0022R IC : 3432A-0022R Please find enclosed application materials for certification of Delphi Delco 15270437 Receiver. Note: 1) portions of this submittal are filed Confidential 2) a list of the modifications made is provided in Attestations. If there are any questions regarding the application or testing performed, please contact me at the above address or call 734-483-4211, fax 734-647-2106, or e-mail [email protected]. Sincerely, Valdis V. Liepa Research Scientist

December 16, 2004 Federal Communications Commission Equipment Approval Services P.O. Box 358315 Pittsburgh, PA 15251-5315 Re: Certification for Delphi Delco 15270437 Receiver Model: 15270437 FCC ID: L2C0022R IC: 3432A-0022R Please find enclosed application materials for certification of Delphi Delco 15270437 Receiver. We tested it and found it to comply with FCC Part 15. If there are any questions regarding the application or testing performed, please contact me at the above address or call 734-483-4211, fax 734-647-2106, or e-mail [email protected]. Sincerely, Valdis V. Liepa Research Scientist December 16, 2004 Certification and Engineering Bureau Industry Canada 3701 Carling Avenue, Bldg. 94 Ottawa, Ontario K2H 8S2 Re: Certification for Delphi Delco 15270437 Receiver Model: 15270437 FCC ID: L2C0022R IC: 3432A-0022R Please find enclosed application materials for certification of Delphi Delco 15270437 Receiver. We tested the device and found it to comply with RSS-210. The product is identified by: IC: 3432A-0022R If there are any questions, suggestions, etc., regarding the application or testing performed, please contact me at the above address or call 734-483-4211, fax 734-647- 2106; e-mail: [email protected]. Sincerely, Valdis V. Liepa Research Scientist

RF signal is received by an external antenna and then goes to the circuit thru a mounted coax connector. The signal goes to a 315 MHz SAW filter a LNA preamplifier and finally applied to Infineon Receiver IC TDA5211. This receiver IC has a LNA Stage one mixer, one IF filter at 10.7 MHZ a ASK detector, a low pass data filter of 5 KHz and a data slicer circuit. Received digital Data is further processed by the master micro- controller IC. The LO signal which is also applied to the mixer stage is generated by a Frequency synthesizer, which consist of a crystal controlled Reference oscillator running at 10.178 MHz. a VCO running at 651.4 MHz which is divided by 2 and applied to the mixer to get the 10.7 MHz IF frequency. The VCO (651.4 MHz) is also divided by 64 in this process.
