L2V-TRACE2Satellite Asset Tracker

1 SPOT TRACE USER GUIDE THEFT-ALERT TRACKING DEVICE 100% SATELLITE TECHNOLOGY 32 To begin using SPOT TRACE, we recommend you spend a few minutes reading through this User Guide, then visit FindMeSPOT.com to select a service plan and activate your SPOT device. Mount the unit with logo pointed toward the sky. It can be mounted beneath fiberglass, fabric, or glass, but metal obstructions should be avoided. Keep SPOT TRACE at least 12 inches away from GPS devices, as it can interfere with the signal reception of your GPS device. Activate your SPOT TRACE before mounting or placing on an asset by visiting FindMeSPOT.com/Activate. HERE ARE A FEW IMPORTANT THINGS TO REMEMBER ABOUT YOUR SPOT TRACE SECTION 1: WELCOME Welcome to the SPOT Family! SPOT TRACE provides satellite-based messaging capabilities so you can track anything, anytime, anywhere. WHAT YOU NEED • Personal contact information, including a valid email address for yourself and other people you would like to receive notifications • SPOT TRACE electronic serial number (ESN) and authorization code located at the bottom of the Quick Start Guide and inside the SPOT Trace battery compartment (keep in a safe place as a reference tool) • Credit card information ACCOUNT SETUP AND ACTIVATION 1. Go to FindMeSPOT.com/Activate. 2. Existing SPOT customers should login to their current SPOT account to add their new device. 3. New customers will need to select: Begin Activation, then Set Up New Account. 4. Follow the instructions provided within the activation portal. Do not skip forms or pages. 5. Choose the services you wish to add to your SPOT TRACE device and confirm your order. 6. Edit your device features, message alerts, and contact information for the necessary message alerts. For more details on SPOT TRACE features, view page 7. IMPORTANT NOTE: An update of SPOT TRACE is required after certain features are edited. SPOT TRACE must be plugged into your computer with the included USB cable to successfully complete an update. Your SPOT TRACE requires an active SPOT subscription to communicate. To do this, simply activate your device using the instructions outlined below. SECTION 2: GETTING STARTED These codes are located on the Quick Start Guide included in your SPOT TRACE box as well as inside the battery compartment of your SPOT TRACE. You will need these codes when setting up your account on FindMeSPOT.com/Activate. ELECTRONIC SERIAL NUMBER (ESN) AND AUTHORIZATION CODE 45 POWER One of these power sources: • (4) AAA Energizer ® Ultimate Lithium 8x batteries (L92) – installed • (4) AAA Energizer ® NiMH rechargeable batteries (NH12) – sold separately • Waterproof – DC Power Cable sold separately REPLACING BATTERIES 1. Loosen the screws to open the back cover. 2. Install 4 AAA Energizer ® Ultimate Lithium 8x batteries or NiMH rechargeable batteries. 3. Replace cover ensuring that the gasket is lined up and free of debris. Tighten screws with a small screwdriver. It is important that you fully tighten the back cover to maintain SPOT TRACE's waterproof seal. 4. Keep your batteries installed, even when using an external DC source to ensure proper system performance in the event that the external DC source is cut or should fail PLEASE NOTE: NiMH batteries cannot be charged within the SPOT TRACE unit. If using an External DC source, SPOT Trace will NOT be waterproof unless using the Waterproof – DC Power Cable (sold separately). REPLACEABLE BATTERIES - CAUTION: Risk of explosion if battery is replaced by an incorrect type. Dispose of used batteries according to the instructions. TO TURN SPOT TRACE ON: Simply locate the Power button on the top of the device, press and hold the button; lights will illuminate. SPOT TRACE will perform a self-test and then enter Track mode automatically. Warning – Blasting Area: To avoid interference with blasting operations, turn your SPOT Trace off when in a “Blasting Area” or in areas posted “Turn off two-way radio.” Obey all signs and instructions. Warning – Potential Explosive Atmosphere: Turn off the SPOT Trace when in any area with a potentially explosive atmosphere and obey all signs and instructions. SECTION 3: USING SPOT TRACE SPOT TRACE SELF-TEST: SPOT TRACE performs a self-test when you initially turn on your device. During self-test, all lights will blink green in an alternating manner to indicate self-test is in progress. If all visible lights flash red, the SPOT TRACE self-test has found a failure, please call SPOT Customer Relations. TO TURN SPOT TRACE OFF: Press the power button for 3 seconds. When the device leaves Track Mode and enters Off Mode from the Power button being pressed, SPOT TRACE will send out a message indicating the power has been turned off. This is to let you know someone has powered off the device. Your SPOT TRACE is always in track mode when powered on. The lights will stop blinking after 20 minutes in order to be unnoticeable. A quick press of the power button will resume blinking for another 20 minutes. SPOT TRACE mounted inside a fiberglass compartment of a boat using the included Velcro strip and mounting bracket. Notice the unit is angled toward the sky for optimal performance. 67 MOUNTING SPOT TRACE • Use the reversible mounting bracket, double sided industrial strength tape, adhesive grip pad or adhesive velcro strips (all included) to affix the SPOT TRACE to your asset • Ensure the SPOT logo is pointed toward the sky • The unit can be mounted beneath fiberglass, fabric or glass, but metal obstructions should be avoided (see examples on page 5 & 6) • If using an External DC source, ensure that the unit will be mounted close enough to the power source • If using an External DC source, SPOT TRACE will NOT be waterproof unless using the Waterproof – DC Power Cable (sold separately) • Experiment with mounting options to determine what works best for your asset and your needs NOTE: Before permanently affixing SPOT TRACE to your asset, verify that the track point/location was received…

Text truncated - open the document above for the full version.

Date: November 7, 2022 Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 Confidentiality Request FCC ID: L2V-TRACE2 Pursuant to Sections 0.457(d)(1)(ii) and 0.459 of the Commission’s Rules, SPOT LLC hereby requests permanent confidential treatment of information accompanying this application as outlined below: Schematics Bill of Materials/Parts List Block Diagrams Theory of Operation Tune-Up Procedure SPOT LLC also hereby requests short-term confidential treatment of information accompanying this application as outlined below for a period of period of 30 days: Internal Photos External Photos User Manual Test Set-up Photographs The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457(d)(1)(ii), disclosure of this Application and all accompanying materials will not be made before the date of the Grant for this Application. Yours sincerely, Name: Matthew Kapral Title: Senior QA & Compliance Engineer

Date: November 7, 2022 TUV SUD America Inc. 10 Centennial Drive Peabody, MA 01960, USA Dear Sir or Madam, We, SPOT LLC, 1351 Holiday Square Blvd, Covington, Louisiana 70433 USA hereby authorize Marlene Sealey of TUV SUD America, 10040 Mesa Rim Road, San Diego, CA, 92121 and Hoosamuddin S. Bandukwala of HB Compliance Solutions to act as our agent in all matters relating to applications for equipment authorization, including the signing of all documents relating to these matters. Yours sincerely, Name: Matthew Kapral Title: Senior QA & Compliance Engineer

Trace Battery Housing (Bottom Enclosure) Trace PCBA Housing (Top Enclosure) Trace Plastics (Button Side) Trace Plastics (Left/Right Side) Trace Plastic (USB Side)

2X 36 2X 44 41.10 1.05 2X 2.32 2.35 2X 4.87 4X 2.30 4X 4.50 4X 6.60 3X 1 2X 9.50 A A 4±0.10 TYP 1±0.10 91° TYP 10.3 13.1 11.8 21.7 1.4 2X 1.50 10X 2 1.20TYP 1TYP 1 3 SECTION A-A REFERENCE THE CORRESPONDING 3D CAD FILE FOR ALL 1. UNDEFINED DIMENSIONS. MOLDING NOTES:2. ALL SURFACES NOT SPECIFICALLY CALLED OUT ON DRAWING a. SHOULD BE FINISHED FOR OPTIMAL MOLD RELEASE AND/OR OVERMOLD ADHESION. REMOVE MATERIAL FLASHING AT ALL THRU HOLES.b. DEGATE MATERIAL FLUSH TO MINUS .010"c. PLASTIC TO BE ROHS2 COMPLIANT.3. REV:DESCRIPTION / ECN#:ENGR 1:ENGR 2:DOC REL:DATE: X1 INITIAL VERSION WAS 7200-0169-01 REV X7 4/9/2014 X2CE MARK CHANGED4/11/2017 AADDED FCC ID3/31/2022 B UPDATED REGULATORY INFO TO INCLUDE UKCA AND ANATEL MARKINGS 8/9/2022 CUPDATED FCC ID11/17/2022 D UPDATED FCC ID ONTO A SINGLE LINE AND REMOVED ANATEL MARKING 01/09/2023 D C B A A B C D 1 2 3 4 5 6 7 8 8 7 6 5 4 3 2 1 THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE PROPERTY OF GLOBALSTAR. ANY REPRODUCTION IN PART OR AS A WHOLE WITHOUT THE WRITTEN PERMISSION OF GLOBALSTAR IS PROHIBITED. CONFIDENTIAL: 2-D DRAWINGS ARE FOR REFERENCE ONLY. USE 3-D CAD DATA FOR PRODUCTION. DIMENSIONS ARE IN MM. EXCEPT WHERE STATED, TOLERANCES ARE AS FOLLOWS: ANGULAR: 1/2° LINEAR: 0.25 MM SURFACE RELATIVE TO 3D: 0.25 MM MATERIAL FINISH Drawn By: Proj Engr: Date: TITLE: SIZE B DWG. NO. REV D H.WEN BLANK BLANK XXXXXXXX XXXXXXXX PLSTC SPOT TRACE BATTERY SUPPORT 1 Sheet of 300 HOLIDAY SQUARE BLVD COVINGTON, LA 70433 985-355-1514 1 Prod Ctrl: Engr 2: Engr 1: Doc Ctrl: Date: Date: Date: Date: Date: 01/09/2023 7200-0178-01 XXXXXXXX BLANK XXXXXXXXBLANK XXXXXXXX BLANK SABIC EXL 1414 PC, COLOR BLACK SPI-B2 EXCEPT WHERE NOTED SCALE 1:1

Trace PCBA – Antenna side (Left) Trace PCBA Top Plastic Housing (Right) Trace PCBA – Antenna Side Trace PCBA – Component Side Trace PCBA – In Top Plastic Housing Trace PCBA – In Top Plastic Housing (Left) Trace PCBA / Battery Separator (Right) Trace PCBA / Battery Separator Installed Over PCBA in Top Enclosure (Left) Trace Battery Housing (Bottom Enclosure) w/ Batteries Installed (Right)

Certificates and reports shall not be reproduced except in full, without the written permission of H.B Compliance Solutions, LLC. Maximum Permissible Exposure Statement For the Globalstar, Inc. Spot Trace December 20, 2022 Prepared for: Globalstar, Inc. 1351 Holiday Square Blvd. Covington, LA 70433 Prepared By: H.B. Compliance Solutions 5005 S. Ash Avenue, Suite # A-10 Tempe, Arizona 85282 Reviewed By: Hoosamuddin Bandukwala Cert # ATL-0062-E HBCS MPE Report # EMC_22042_4 Page 2 of 2 Prediction of MPE limit at a given distance Equation from page 18 of OET Bulletin 65, Edition 97-01 S = PG/4πR2 Where, S = power density (mW/cm2) P = output power at the antenna terminal (mW) G = gain of transmit antenna (numeric) R = distance from transmitting antenna (cm) Maximum peak output power at antenna input terminal = 24.39 (dBm) * Maximum peak output power at antenna input terminal = 274.78 (mW) Antenna gain (typical) = -0.4 (dBi) Maximum antenna gain = 0.9 (numeric) Prediction distance = 20 (cm) Prediction frequency = 1618.75 (MHz) MPE limit for uncontrolled exposure at prediction frequency = 1.0 (mW/cm^2) Power density at prediction frequency = 0.04920 (mW/cm^2) *Includes 1dB of manufacturer output power tolerance. To solve for the minimum mounting distance required; R = √ (PG/4πS) R = √ (274.782 x 0.9 / 4π x 0.04920) = 20 cm (Based on continuous transmission) END OF TEST REPORT

Certificates and reports shall not be reproduced except in full, without the written permission of H.B Compliance Solutions, LLC. Intentional Radiator Test Report For the Globalstar, Inc. Spot Trace Tested under The FCC Rules contained in Title 47 of the CFR, Part 25 and ISED RSS-170 Issue 3 for Satellite Communications December 20, 2022 Prepared for: Globalstar, Inc. 1351 Holiday Square Blvd. Covington, LA 70433 Prepared By: H.B. Compliance Solutions 5005 S. Ash Avenue, Suite # A-10 Tempe, Arizona 85282 Reviewed By: Hoosamuddin Bandukwala Cert # ATL-0062-E Engineering Statement: The measurements shown in this report were made in accordance with the procedure indicated, and the emissions from this equipment were found to be within the limits applicable. I assume full responsibility for the accuracy and completeness of these measurements, and for the qualifications of all persons taking them. It is further stated that upon the basis of the measurement made, the equipment tested is capable of operation in accordance with the requirements of Part 25 of the FCC Rules under normal use and maintenance. All results contained herein relate only to the sample tested. HBCS Report # EMC_22042 Page 2 of 35 Report Status Sheet Revision # Report Date Reason for Revision Ø December 20, 2022 Initial Issue HBCS Report # EMC_22042 Page 3 of 35 Table of Contents EXECUTIVE SUMMARY ............................................................................................ 4 1. Testing Summary ........................................................................................ 4 EQUIPMENT CONFIGURATION ................................................................................ 5 1. Overview .................................................................................................... 5 2. Test Facility ................................................................................................. 6 3. Description of Test Sample ......................................................................... 7 4. Equipment Configuration ........................................................................... 7 5. Support Equipment .................................................................................... 7 6. Ports and Cabling Information .................................................................... 7 7. Method of Monitoring EUT Operation ........................................................ 7 8. Mode of Operation ..................................................................................... 8 9. Modifications ............................................................................................. 8 10. Disposition of EUT ...................................................................................... 8 Criteria for Intentional Radiators ............................................................................ 9 1. RF Power Output ........................................................................................ 9 2. Occupied Bandwidth ................................................................................ 11 3. Unwanted Emissions at Antenna Terminals .............................................. 13 4. Radiated Spurious Emissions .................................................................... 21 5. Protection of Aeronautical Radio Navigation Satellite Service .................. 24 6. Frequency Stability vs Temperature ......................................................... 30 7. Frequency Stability vs Voltage .................................................................. 32 Test Equipment ..................................................................................................... 34 8. Measurement Uncertainty ....................................................................... 35 HBCS Report # EMC_22042 Page 4 of 35 EXECUTIVE SUMMARY 1. Testing Summary These tests were conducted on a sample of the equipment for the purpose of demonstrating compliance with Part 25. All tests were conducted using measurement procedure from ANSI C63.26-2015 RSS-GEN Issue 5 and RSS-170 Issue 3 as appropriate. Test Name Test Method / FCC Standard ISED Standard Result Comments RF Output Power §2.1046; §25.204 RSS-170 (5.3) Pass Occupied Bandwidth §2.1049 RSS-Gen (6.7) Pass Unwanted Emissions at Antenna Terminals §2.1051; §25.202(f) RSS-170 (5.4.3.1) Pass Radiated Spurious Emissions §2.1053; §25.202(f) RSS-170 (5.4.3.1) Pass Protection of Aeronautical Radio Navigation Satellite Service §25.216(c)(f)(g)(i)(j) RSS-170 (5.4.3) Pass Frequency Stability over Temperature Variations §2.1055(a)(1); §25.202(d) RSS-170 (5.2) Pass Frequency Stability over Voltage Variations §2.1055(d); §25.202(d) RSS-170 (5.2) Pass HBCS Report # EMC_22042 Page 5 of 35 EQUIPMENT CONFIGURATION 1. Overview H.B Compliance Solutions was contracted by Globalstar to perform testing on the Spot Trace under the purchase number 103975. This document describes the test setups, test methods, required test equipment, and the test limit criteria used to perform compliance testing of the Globalstar, Spot Trace. The tests were based on FCC Part 25 Rules. The tests described in this document were formal tests as described with the objective of the testing was to evaluate compliance of the Equipment Under Test (EUT) to the requirements of the aforementioned specifications. Globalstar should retain a copy of this document and it should be kept on file for at least five years after the manufacturing of the EUT has been permanently discontinued. The results obtained relate only to the item(s) tested. Product Name: Spot Trace Model(s) Tested: Spot Trace FCC ID: L2V-TRACE2 IC ID: 3989A-TRACE Supply Voltage Input: Primary Power: 6 VDC Frequency Range: 1611.25MHz to 1618.75MHz No. of Channels: Four Channel Necessary Bandwidth N/A Type(s) of Modulation: BPSK Range of Operation Power: 0.275W Voltage into final Transistor 3.3V Current into final Transistor 475mA Emission Designator: 2M50G1D Chann…

Text truncated - open the document above for the full version.

1 | Page Test Setup Photos Globalstar – Project 22042 Test Setup Photo # 1 Test Setup Photo # 2 2 | Page Test Setup Photo # 3 Test Setup Photo # 4 3 | Page Test Setup Photo # 5
