L82-GIG-B427-DATAUSB Bluetooth Transceiver for Personal Computer

F:\DATEN\ZULASSG\PROJEKTE\Bluetooth\Gigaset B427 data\USA\User Manual\Vorschlag für USA Zulassung 31.01.01.doc i Important Safety Instructions BEFORE USING YOUR GIGASET B427 DATA EQUIPMENT, BASIC SAFETY INSTRUCTIONS SHOULD ALWAYS BE FOLLOWED TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK AND INJURY TO PERSONS. 1. Read and understand all instructions. 2. Follow all warnings and instructions marked on the product. 3. Unplug this product from the PC before cleaning. Do not use liquid cleaners or aerosol cleaners. Use damp cloth for cleaning. 4. Do not use this product near water, for example, near a bathtub, wash bowl, kitchen sink, or laundry tub, in a wet basement or near a swimming pool. 5. Fix this product securely on a stable surface by using the strip. Serious damage and/or injury may result if the unit falls. 6. Do not place objects on the usb cord. Install the unit where no one can step or trip on the cord. 7. Never spill liquid of any kind on this product. 8. To reduce the risk of electric shock or burns, do not disassemble this product. Take it to a qualified service center when service is required. Opening or removing covers may expose you to dangerous voltages, dangerous electri- cal current or other risks. Incorrect reassembly can cause electric shock when the appliance is subsequently used. 9. Unplug the product from the PC and refer servicing to qualified service personnel under the following conditions: a. If liquid has been spilled into the product. b. If the product has been exposed to rain or water. c. If the product does not operate normally by following the operating instructions. Adjust only those controls that are covered by the operating instructions because improper adjustment of other controls may result in damage and may require extensive work by a qualified technician to restore the product to normal operation. d. If the product has been dropped or physically has been damaged. e. If the product exhibits a distinct change in performance. F:\DATEN\ZULASSG\PROJEKTE\Bluetooth\Gigaset B427 data\USA\User Manual\Vorschlag für USA Zulassung 31.01.01.doc ii FCC Comment This device complies with Part 15 of the FCC Rules. Operation is Subject to the following two conditions. (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation

F:\DATEN\ZULASSG\ARCHIV\Zulassungsdokumentation\Länder\USA\Gigaset B427 data ( USB Dongle )\CETECOM_Vollmacht.doc Information and Communication Mobile Authorisation (Power of attorney) We, Siemens AG Frankenstrasse 2 Information and Communication Mobile46395 Bocholt Cordless Products Germany ICM CP authorise CETECOM ICT Services GmbH Untertürkheimer Strasse 6 - 10 D-66117 Saarbrücken Germany to act as our agent and to process and sign on our behalf for all approval activities in all countries. This authorisation is applicable for the product: Gigaset B427 data Bocholt, 24 January 2001 ...................................................................................... Place and DateMr. Leiblich Senior Approvals Manager Tel.: +49-2871-91-2285 Fax: +49-2871-91-2495

F:\DATEN\ZULASSG\ARCHIV\Zulassungsdokumentation\Länder\USA\Gigaset B427 data ( USB Dongle )\Decl_Sim_signed.doc Information and Communucation Mobile Declaration of Identity We, Siemens AG – ICM CP, declare that the “Gigaset B427 data” is identical to “Gigaset B420 data” We declare that: These two versions are identical in all Type Approval aspects and performance. Siemens AG Information and Communication Mobile Cordless Products ICM CP Frankenstrasse 2 46395 Bocholt Germany Bocholt, 25. January 2001 ...................................................................................... Place and DateMr. Siemens Development Project Leader Tel.: +49-2871-91-3556 Fax: +49-2871-91-3558

address bus (A0..A18) RF control bus Rx / Tx ON PA cont ro l 13 MHz Crystal USB +5V USB- Connector Typ A, high-speed USB-Cable, Connector Voltage Regulation 3,5V (PA) 3,3V 2,8V 2,2V (BB) 2,8V (RF) GND DATA+DATA- D/A Power- Control BP Filter 20dBm RF Part (MCM) PA 20dB RF switch 0dBm RF switch Bluetooth Baseband Controller VWS26002/3 Flash Memory 28F800B3 512x16bit (8Mbit) t =90ns access 13MHz, 1MHz and 3,2kHz clock signals data bus (D0..A15) control bus (CS, RD, WR)

February 1, 2001 CONFIDENTIALITY REQUEST Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Re:Siemens, application for Spread Spectrum Transmitter FCC ID: L82-GIGASET-B482 Gentlemen: Siemens herein submits an Application for Equipment Authorization and submission of the FCC fee in the amount of $1130.00 along with Form 159 for certification of a spread spectrum transmitter under FCC Rules Part 15 as required by the FCC Rules. Siemens requests, pursuant to 47CFR 0.459, post grant confidentiality for portions of the material contained in this application such that the identified material will be withheld from public inspection following the grant of this authorization. This material, as indicated by request for confidentiality of the item during the electronic submission process and further identified below, includes: 1. Circuit diagrams submitted as Equipment Authorization Electronic Filing attachment: "schematics". Specifically, this exhibit contains information relating to circuit function and complexity that could be of benefit to competitors. The material contains trade secrets and confidential information that Siemens does not customarily release to the public and which is otherwise not generally available to the public. Please contact the undersigned by phone at 410-531-3439, by fax at 410-531-0807, by email at [email protected], or by correspondence at the address below if there are any further questions or additional information needed concerning this filing. Rega rds, (signed) Phillip Inglis, TRP/Cetecom bvba 14085 Howard Rd. Dayton, MD. 21036

February 1, 2001 CONFIDENTIALITY REQUEST Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Re:Siemens, application for Spread Spectrum Transmitter FCC ID: L82-GIG-B427-DATA Gentlemen: Siemens herein submits an Application for Equipment Authorization and submission of the FCC fee in the amount of $1130.00 along with Form 159 for certification of a spread spectrum transmitter under FCC Rules Part 15 as required by the FCC Rules. Siemens requests, pursuant to 47CFR 0.459, post grant confidentiality for portions of the material contained in this application such that the identified material will be withheld from public inspection following the grant of this authorization. This material, as indicated by request for confidentiality of the item during the electronic submission process and further identified below, includes: 1. Circuit diagrams submitted as Equipment Authorization Electronic Filing attachment: "schematics". Specifically, this exhibit contains information relating to circuit function and complexity that could be of benefit to competitors. The material contains trade secrets and confidential information that Siemens does not customarily release to the public and which is otherwise not generally available to the public. Please contact the undersigned by phone at 410-531-3439, by fax at 410-531-0807, by email at [email protected], or by correspondence at the address below if there are any further questions or additional information needed concerning this filing. Rega rds, (signed) Phillip Inglis, TRP/Cetecom bvba 14085 Howard Rd. Dayton, MD. 21036

Transmitter, USA FCC ID:L82-GIGASET-B427 This device complies with Part 15 of the FCC Rules. Operation is Subject to the following two conditions. (1) this device my not cause Harmful interference, and (2) this device must accept any interference Received, including interference that may cause undesired operation. THIS LABEL WILL BE PLACED ON THE BOTTOM OF THE UNIT The FCC ID is mandatory and must be placed on the cover of device. The statement is mandatory for the manual but voluntary for marking of the device.

Revised Label for Seimens Application: Attached is the identification label showing all caps for the FCC identifier for the application pending under EA 99928, FCC ID:L82-GIG-B427-DATA. This marking will all capital letters will replace the current marking and will be located on the bottom of the unit. Do to the extremely small size of the product, the FCC compliance statement will be placed in the user’s manual. Phillip Inglis/TRP Cetecom bvba L82-GIG-B427-DATA

Revised Label for Seimens Application: Attached is the identification label showing all caps for the FCC identifier for the application pending under EA 99928, FCC ID:L82-GIG-B427-DATA. This marking with all capital letters will replace the current marking and will be located on the bottom of the unit. Due to the extremely small size of the product, the FCC compliance statement will be placed in the user’s manual. Phillip Inglis/TRP Cetecom bvba L82-GIG-B427-DATA

CETECOM ICT Services GmbH Test report nr..: 4-0304-A/00Issue Date: 29.01.2001Page 66 (71) Photographs of the equipment Photograph no.: 1 CETECOM ICT Services GmbH Test report nr..: 4-0304-A/00Issue Date: 29.01.2001Page 67 (71) Photographs of the equipment Photograph no.: 2 CETECOM ICT Services GmbH Test report nr..: 4-0304-A/00Issue Date: 29.01.2001Page 68 (71) Photographs of the equipment Photograph no.: 3 CETECOM ICT Services GmbH Test report nr..: 4-0304-A/00Issue Date: 29.01.2001Page 69 (71) Photographs of the equipment Photograph no.: 4 CETECOM ICT Services GmbH Test report nr..: 4-0304-A/00Issue Date: 29.01.2001Page 70 (71) Photographs of the equipment Photograph no.: 5 CETECOM ICT Services GmbH Test report nr..: 4-0304-A/00Issue Date: 29.01.2001Page 71 (71) Photographs of the equipment Photograph no.: 6

sProduct description „Gigaset B427 data“ ConfidentialSeite 1ICP CD DP D4 F:\DATEN\ZULASSG\PROJEKTE\Bluetooth\Gigaset B427 data\Product description.doc 22.01.01 Product description Bluetooth „Gigaset B427 data“ This product consists of two parts. The one is the „Gigaset B427 data“ itself, the other is the upper layer Bluetooth software for Microsoft Windows 98 / 2000 based personal computers. The „Gigaset B427 data“ contains a small printed circuit board, the Bluetooth baseband hardware including firmware and the RF-part. The housing is made of PC- ABS plastic with rubber feets for desktop use and a self adhesive strip for mounting at a laptop computer. The „Gigaset B427 data“ has to be connected to the computer with a type A USB connector. The cable is directly mounted to the „Gigaset B427 data“, so that there is no type B connector. The main units of the „Gigaset B427 data“ are the following: 1. RF-part for transmitting and receiving data in the 2,4 GHz ISM band. The RF-part is in compliance with the Bluetooth Requirements in Spec 1.0b. The transmitter is capable of +20 dBm (100 mW) transmit power. It has a built in power control according to the Bluetooth Spec. 2. Bluetooth baseband chip and FLASH memory for data preparation. 3. Firmware for the baseband controller, stored in the FLASH. This firmware covers all layers up to the HCI interface. It also has the algorithm for the built in power control for the transmit amplifier. 4. USB interface, electrical as well as mechanical (type A connector). The upper layer software for the PC has to be installed from a compact disk by the user. The operating system on the PC has to be Microsoft Windows 98 or Microsoft Windows 2000. Beside the Bluetooth protocol stack, the software contains a small configuration utility to enable the user to connect his own Applications to the virtual COM-port given by the stack. There is no application delivered with the „Gigaset B427 data“. The „Gigaset B427 data“ can only be used for data applications. Voice transmissions are not supported by the Bluetooth stack implemented, allthough the hardware is able to transmit and receive SCO type packages, which would be necessary for voice. The table shows an overview to the features: Air InterfaceBluetooth air interface according Spec. 1.0b or higher; point to point connection Rangeca. 100 m (20 dBm max. transmit power, power control) Power supplyExternal from Host, 4,7... 5,5 V according USB- Spec. Power-Management, to reduce power consumption Supported Applications (not included in the product) - Conntection to networks for data transmissions or internet services - Synchronisation, Objekt Exchange, File Transfer (local) - Communication with peripherals (proprietary solution, planned as simple cable replacement, sProduct description „Gigaset B427 data“ ConfidentialSeite 2ICP CD DP D4 F:\DATEN\ZULASSG\PROJEKTE\Bluetooth\Gigaset B427 data\Product description.doc 22.01.01 no guarantee for functionality, has to be checked for every application) Supported protocolsPhysical Layer, Link Manager and HCI in firmware HCI, L2CAP, RFCOMM, SDP, Bluetooth advisor in PC software on compact disc. Supported profilesGeneric Access Profile, Service Discovery Profile, Serial Port Profile, Generic Object Exchange, File Transfer, Object Push, Synchronization Profile, Dial up Networking und FAX LAN-Access Not supported profilesHeadset, TCS Firmware variantsNo Firmware variants planned Software updates / upgrades on CD have to be discussed Interfaces hardwareUSB Interface Interfaces softwareHCI interface, in the „Gigaset B427 data“ as well as in the protocol stack on the PC. Interface for applications: VCOMM LEDA LED for showing activities on air is not planned for the first version of the „Gigaset B427 data“ AntennaInternal Environmental conditionsIndoor use only Temperature:+5°C...+40°C Humidity:20%...85%rel. According to IEC 721 3K3 EMC:to be clearified Mechanical constructionDimensions ca. 85mm x 43mm x 10mm Cable directly connected to device, length 20 cm Type: double shielded USB cable for high speed devices Shieldings Three separate shieldings for baseband, RF-part and power amplifier Host systemsPCs, Laptops, etc. with USB interface. Operating systems Windows 98, Windows 2000

SIEMENS AG ... Vertraulich! - Alle Rechte vorbehalten ! ... 25.01.2001 PDM Kundenstückliste Seite 1 von 3 Sachnummer S30851-Q792-B101-6 Verantw. ELSHORST Status 1 Stand 24.01.2001 15:42:11 Text FBG - USB-Dongle (BLUETOOTH) Pos. Komponente Menge Benennung Bauteilnahme ---------------------------------------------------------------------------- 0005 A30148-N***-D1-*-7469 1.000 MITTEILUNG 0400 A30851-X792-B101-6-7411 1.000 STROMLAUFPLAN 0401 T30851-Q792-B101-6-7402 1.000 BAUSCHALTPLAN 0450 S30851-Q792-B101-6-BP71 1.000 VISION-DATEN 0451 S30851-Q792-B101-6-BP83 1.000 SMD-BESTUECKDATEN 0452 W30851-Q792-B101-2-PP10 1.000 Pruefpunktebauschaltplan 1010 W30851-Q792-B101-2 1.000 LEITERPLATTEN - BV 1020 V24852-C821-F2 1.000 WID 820R R803 1030 V39253-F4104-J4 1.000 WID-ARRAY 100K R18 1040 V24852-C-X 4.000 WID 0R R802 R811 R825 R849 1050 V24852-C100-J2 1.000 WID 10R R905 1060 V24852-C330-J2 2.000 WID 33R R15 R16 1070 V24852-C101-F2 1.000 WID 100R R831 1080 V24852-C131-F2 1.000 WID 130R R800 1090 V24852-C221-J2 3.000 WID 220R R804 R805 R845 1100 V24852-C391-J2 1.000 WID 390R R806 1110 V24852-C102-J2 2.000 WID 1K R823 R830 1120 V24852-C122-J2 1.000 WID 1K2 R807 1130 V24852-C152-J2 1.000 WID 1K5 R2 1140 V24852-C182-F2 1.000 WID 1K8 R801 1150 V24852-C222-F2 1.000 WID 2K2 R847 1160 V24852-C332-J2 1.000 WID 3K3 R841 1170 V24852-C472-F2 1.000 WID 4K7 R808 1180 V24852-C103-J2 1.000 WID 10K R850 1190 V24852-C104-J2 8.000 WID 100K R11 R21 R25 R3 R30 R31 R4 R809 1200 V24852-C124-J2 1.000 WID 120K R851 1210 V24852-C224-J2 1.000 WID 220K R904 1220 V24852-C274-J2 1.000 WID 270K R12 1230 V24852-C474-J2 1.000 WID 470K R840 1240 V24853-C104-Z8 11.000 KON 100n C10 C11 C12 C13 C14 C15 C205 C6 C7 C8 C9 1250 V24853-C9010-B208 2.000 KON 1p2 SIEMENS AG ... Vertraulich! - Alle Rechte vorbehalten ! ... 25.01.2001 PDM Kundenstückliste Seite 2 von 3 Sachnummer S30851-Q792-B101-6 Verantw. ELSHORST Status 1 Stand 24.01.2001 15:42:11 Text FBG - USB-Dongle (BLUETOOTH) Pos. Komponente Menge Benennung Bauteilnahme ---------------------------------------------------------------------------- C831 C832 1260 V24853-C9010-B808 1.000 KON 1p8 C823 1270 V24853-C9020-B208 1.000 KON 2p2 C800 1280 V24853-C9020-B708 1.000 KON 2p7 C899 1290 V24853-C9040-C708 13.000 KON 4p7 C211 C801 C817 C833 C834 C840 C842 C843 C847 C848 C849 C909 C910 1300 V24853-C9100-J8 5.000 KON 10p C24 C4 C810 C813 C845 1310 V24853-C9120-J8 3.000 KON 12p C806 C901 C903 1320 V24853-C9150-J8 1.000 KON 15p C850 1330 V24853-C9270-J8 1.000 KON 27p C851 1340 V24853-C9560-J5 1.000 KON 56p C846 1350 V24853-C9102-K6 3.000 KON 1n C803 C816 C844 1360 V24853-C9103-K6 5.000 KON 10n C207 C210 C212 C3 C906 1370 V39377-F6224-K 1.000 KON 220n C907 1380 V39369-F8105-Z 1.000 KON 1u C905 1390 V39375-F3105-K 4.000 KON GRM 1u C203 C208 C213 C23 1400 V39375-F3225-K 4.000 KON 2u2 C202 C206 C209 C808 1410 V39373-F6106-K 1.000 KON 10u C908 1420 V20810-U6096-D670 1.000 IC W7020 D900 1430 V20830-C1093-D670 1.000 TRANS BSS83P V820 1440 V20840-C4009-D670 4.000 DOPPELTRANS BCR35PN V800 V801 V802 V806 1450 V20840-C4035-D670 1.000 TRANS BCR198S V804 1460 V20840-D24-D670 2.000 DOPPELDIODE BAR64-05 V803 V805 1470 V20840-D5047-D670 1.000 DIODE 40V V807 1480 V20840-D5048-D670 1.000 DOPPELDIODE BAT64-04W V200 1490 V20810-C6082-D670 1.000 IC OPA337NA N800 1500 V20810-C6083-D670 1.000 IC PA2423MB REV.3 N1 1510 V20810-E6043-D670 1.000 IC GT28F800B3 D2 1520 V20810-G6160-D670 1.000 IC VWS26002D SIEMENS AG ... Vertraulich! - Alle Rechte vorbehalten ! ... 25.01.2001 PDM Kundenstückliste Seite 3 von 3 Sachnummer S30851-Q792-B101-6 Verantw. ELSHORST Status 1 Stand 24.01.2001 15:42:11 Text FBG - USB-Dongle (BLUETOOTH) Pos. Komponente Menge Benennung Bauteilnahme ---------------------------------------------------------------------------- D1 1530 V20820-C6070-D670 1.000 SPANNUNGSREGLER LP2985IM5 N201 1540 V20820-C6097-D670 1.000 SPANNUNGSREGLER LP2985IM5 L200 1550 V20820-C6104-D670 1.000 SPANNUNGSREGLER LP2985AIM5X N202 1560 V30145-A820-Y7 1.000 SICHERUNG 1A F1 1570 V32906-A3-X9-2 1.000 SCHILD DATA-MATRIX-CODE A1 1580 C39334-Z97-C179 1.000 STECKER YY-0800-SMT05RT X2 1590 C39363-A309-C120 3.000 ABSCHIRMTOPF C39363-A309-C120 X10 X11 X12 1600 C39363-A309-C660 1.000 ANTENNE C39363-A309-C660 X800 1610 V30145-F220-Y4 1.000 QUARZ 13MHz G900 1620 V39153-F180-G 1.000 SPULE 18n L803 1630 V39154-F80-D202 1.000 SPULE 8n2 L805 1640 V39154-F20-S702 1.000 SPULE 2n7 L804 1650 V39150-F40-J700 1.000 SPULE 4n7 L800 1660 V39154-F120-J2 2.000 SPULE 12n

DASY Test-Report, Siemens 6575 115a Page 15 of 22 Schmid & Partner Engineering AG stii‘t~lsrr;lrr+II.A045 zurirl?. Swi~zt.,,.lnd. Tele‘an+9, , 1RO0800Es” +411180“8 64 SItl332 Manufactured: Last calibration: Recalibrated: December 20, 1997 January 12,1999 December l&l999 Calibrated for System DASY3

DASY Test-Report, Siemens 6575 115a Page 18 of 22 ET3DV5 SN:l332 f = 1800 MHz, WG R22 f = 2500 MHz. WG R26 Isotropy Error (b), 0 = 0” Page 4 Of 7 DASY Test-Report, Siemens 6575 115a Page 22 of 22 8 References [ANSI 19921 [DASY 19951 [FCC 19961 [FCC 19971 , [Kuster 19971 ANSI C95.1: IEEE Standard for Safety Levels with Respect to Human Exposure to Radio Frequency Electromagnetic Fields, 3 kHz to 300 GHz, Inst. of Electrical and Electronics Engineers, Inc., 1992. Referenzliste des Herstellers, der Fa. Schmid & Partner Engineering AG, i&r installierte DASY-Systeme mit RX90 Robotem: Deutsche Telekom, Forschungs- und Technologiezentrum; Motorola Cellular - MRO; Motorola; Ericsson Mobile Communications AB; Nokia Mobile Phones LTD; IMST GmbH, 1995. Federal Communications Commission: Report and order: Guidelines for evaluating the environmental effects of radiofrequency radiation, Tech. Rep. FCC 96-326, FCC, 1996. Federal Communications Commission: Evaluating Compliance with FCC Guidelines for Human Exposure to Radiofiequency Electromagnetic Fields, Supplement C to OET Bulletin 65, FCC, 1997. N. Kuster, R. Kzistle and T. S&mid: Dosimetric evaluation of handheld mobile communications equipment with known precision, In: IEICE Trans. Commun., Vol. E80-B, No. 5,645-652, 1997.

CETECOM ICT Services GmbH Radio Satelite Communication Untertürkheimer Straße 6-10 . D-66117 SaarbrückenTelefon: +49 (0)681 598-9100Telefax: -9075 RSC14issue test report consist of 71 PagesPage 1 (71) Test report no.: 4-0304-A/00 FCC Part 15.247 Siemens Gigaset B420data Accredited Testing Laboratory DAR-Registration number: TTI-P-G 166/98-00 CETECOM ICT Services GmbH Test report nr.:4-0304-A/00Issue date:29.01.2001Page 2 (71) Table of Contents 1 General information 1.1 Notes 1.2 Testing laboratory 1.3 Details of applicant 1.4 Application details 1.5 Test item 1.6 Test standards 2 Technical test 2.1 Summary of test results 2.2 Test report 1 General information 1.1 Notes The test results of this test report relate exclusively to the test item specified in 1.5. The CETECOM ICT Services GmbH does not assume responsibility for any conclusions and generalisations drawn from the test results with regard to other specimens or samples of the type of the equipment represented by the test item. The test report may only be reproduced or published in full. Reproduction or publication of extracts from the report requires the prior written approval of the CETECOM ICT Services GmbH. 1.2Testing laboratory CETECOM ICT Services GmbH Untertürkheimer Straße 6 - 10 66117 Saarbrücken Germany Telefone: + 49 681 598 - 9100 Telefax : + 49 681 598 - 9075 E-mail: [email protected] Internet: www.cetecom.de Accredited testing laboratory DAR-registration number : TTI-P-G 166/98-00 CETECOM ICT Services GmbH Test report nr.:4-0304-A/00Issue date:29.01.2001Page 3 (71) 1.3Details of applicant Name :Siemens AG / ICP CD DP PSI Street :Frankenstrasse 2 City :D-46395 Bocholt Country :Germany Telephone:+49-2871 91 28 57 Telefax :+49-2871 91 24 95 Contact :Mr. Uwe Alt Telephone:+49-2871 91 28 57 1.4Application details Date of receipt of application : 24.01.01 Date of receipt of test item : 24.01.01 Date of test : 24.01.01 1.5Test item Type of equipment : Bluetooth transceiver with USB Type designation: Gigaset B427data Manufacturer:applicant Street: City: Country: Serial number: Additional informations:: Frequency:2400 – 2483.5 MHz Type of modulation:1M00FXD / 79M8FXD (FHSS) Number of channels :79 Antenna:integral antenna Power supply:5 V DC according to USB convention Output power:100 mW EIRP Type of equipment:Temperature range : -20°C - +55°C 1.6Test standards: FCC Part 15 §15.247 CETECOM ICT Services GmbH Test report nr.:4-0304-A/00Issue date:29.01.2001Page 4 (71) 2 Technical test 2.1Summary of test results The radiated measurements were performed verticaly, horizontal results are about 2 dB lower over the whole frequency range. The antenna gain measurement was performed by the difference between conducted and radiated output measurement. All measurement settings are according to FCC 15.35, 15.205, 15.209, 15.247 and the „Measurement guidelines for FHSS systems“. No deviations from the technical specification(s) were ascertained in the course of the tests performed. Technical responsibility for area of testing : 30.01.01RSC 8414Ames H. DateSectionNameSignature Technical responsibility for area of testing : 30.01.01RSC8412Hausknecht D. DateSectionNameSignature CETECOM ICT Services GmbH Test report nr.:4-0304-A/00Issue date:29.01.2001Page 5 (71) 2.2Testreport TEST REPORT Testreport no. : 4-0304-A/00 CETECOM ICT Services GmbH Test report nr.:4-0304-A/00Issue date:29.01.2001Page 6 (71) TEST REPORT REFERENCE LIST OF MEASUREMENTS ParagraphPARAMETER TO BE MEASUREDPAGE Transmitter parameters § 15.204Antenna gain 7 § 15.247 (a) Carrier frequency separation8 § 15.247 (a)Number of hopping channels9 § 15.247 (a)Time of occupancy (dwell time)13 § 15.247 (a)(1)Spectrum bandwidth of a FHSS System16 § 15.247 (b)(2)Maximum peak output power20 §15.247Band edge compliance25 § 15.247 (c)(1)Emission limitations 29 § 15.107/207low frequency emissions54 Receiver parameters § 15.209Spurious radiations - Radiated55 Test equipment listing60 Photographs of the equipment62 CETECOM ICT Services GmbH Test report nr..: 4-0304-A/00Issue Date: 29.01.2001Page 7 (71) Equipment under test : Gigaset B427data Ambient temperature: 20°C Relative humidity : 31% REFERENCE NUMBER(S) OF TEST EQUIPMENT USED (for reference numbers see test equipment listing) - Antenna GainSUBCLAUSE § 15.204 The gain is +3.0 dBi (measured effectiv radiated power over dipol– measured conducted power with a temporary RF-connector) CETECOM ICT Services GmbH Test report nr..: 4-0304-A/00Issue Date: 29.01.2001Page 8 (71) Equipment under test : Gigaset B427data Ambient temperature: 20°C Relative humidity : 31% REFERENCE NUMBER(S) OF TEST EQUIPMENT USED (for reference numbers see test equipment listing) 64 Carrier frequency separation §15.247(a) A UnitdBm 1MAX1MA RF Att 40 dB Ref Lvl 30 dBm Ref Lvl 30 dBm 300 kHz/Center2.441 GHzSpan3 MHz RBW 30 kHz SWT 8.5 ms VBW 100 kHz -90 -80 -70 -60 -50 -40 -30 -20 -10 0 10 20 30 1 2 3 Marker 3 [T1] 16.79 dBm 2.44201303 GHz 3 [T1] 16.79 dBm 2.44201303 GHz 1 [T1] 16.81 dBm 2.44000501 GHz 2 [T1] 15.62 dBm 2.44101503 GHz Date: 24.JAN.2001 13:32:57 CETECOM ICT Services GmbH Test report nr..: 4-0304-A/00Issue Date: 29.01.2001Page 9 (71) Equipment under test : Gigaset B427data Ambient temperature: 20°C Relative humidity : 31% REFERENCE NUMBER(S) OF TEST EQUIPMENT USED (for reference numbers see test equipment listing) 64 Number of hopping channels§15.247(a) The number of hopping channels is 79. The next 4 plots shows the number. The right red line corresponds to the left red line from the next plot. Plot 1: A UnitdBm 1MAX1MA RF Att 40 dB Ref Lvl 30 dBm Ref Lvl 30 dBm 2.5 MHz/Start2.4 GHzStop2.425 GHz RBW 30 kHz VBW 100 kHz SWT 70 ms -90 -80 -70 -60 -50 -40 -30 -20 -10 0 10 20 30 1 2 Marker 2 [T1] 16.39 dBm 2.42004008 GHz F1 F2 Date: 24.JAN.2001 13:40:41 CETECOM ICT Services GmbH Test report nr..: 4-0304-A/00Issue Date: 29.01.2001Page 10 (71) Equipment under test : Gigaset B427data Ambient temperature: 20°C Relative humidity : 31% REFERENCE NUMBER(S) OF TE…
