LBBFF2115HT900MHz 40 Channel Analog Modulation Cordless Phone

Continental Conair Limited

Click to zoom

Application Details

Equipment Class: DXT - Part 15 Low Power Transceiver, Rx Verified
Date of Grant: Oct 17, 2002
Application Purpose: Original Equipment
Date of Application: Oct 17, 2002
Equipment Note: 900MHz 40 Channel Analog Modulation Cordless Phone
Frequency Range: 926.11700000 - 927.28800000
Company: Continental Conair Limited
Country: Hong Kong

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

FCC WANTS YOU TO KNOW This equipment complies with Part 68 of the FCC rules. On the bottom of the base ofthis equipment is a label that contains, among other information, the FCC RegistrationNumber and Ringer Equivalence Number (REN) for this equipment. You must, uponrequest, provide this information to your telephone company.An FCC compliant telephone cord and modular plug is provided with this equipment.This equipment is designed to be connected to the telephone network or premises wiringusing a compatible modular jack which is Part 68 compliant. See Installation Instructionsfor details.The REN is useful to determine the quantity of devices you may connect to yourtelephone line and still have all of those devices ring when your telephone number iscalled. In most, but not all areas, the sum of the REN’s of all devices connected to oneline should not exceed five (5.0). To be certain of the number of devices you mayconnect to your line, as determined by the REN, you should contact your localtelephone company to determine the maximum REN for your calling area.If your telephone equipment causes harm to the telephone network, the telephonecompany may discontinue your service temporarily. If possible, they will notify you inadvance. But if advance notice isn’t practical, you will be notified as soon as possible.You will be informed of your right to file a complaint with the FCC.Your telephone company may make changes in its facilities, equipment, operations, orprocedures that could affect the proper functioning of your equipment. If they do, youwill be notified in advance to give you an opportunity to maintain uninterruptedtelephone service. If you experience trouble with this telephone equipment, disconnectfrom the network until the problem has been corrected or until you are sure that theequipment is not malfunctioning.This equipment may not be used on coin service provided by the telephone company.Connection to party lines is subject to state tariffs.This equipment is hearing aid compatible.Warning: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed toprovide reasonable protection against harmful interference in a residential installation.Some cordless telephones operate at frequencies that may cause interference tonearby TV’s and VCR’s. To minimize or prevent such interference, the base of thecordless telephone should not be placed near or on top of a TV or VCR. If interferenceis experienced, moving the cordless telephone farther away from the TV or VCR willoften reduce or eliminate the interference. However, there is no guarantee thatinterference will not occur in a particular installation. If this equipment does causeharmful interference to radio or television reception, which can be determined byturning the equipment off and on, the user is encouraged to try to correct theinterference by one or more of the following measures: • Reorient or relocate the receiving antenna.• Increase the separation between the equipment and receiver.• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio TV technician for help. 9 INTRODUCTION ABOUT THE FF2115The FF2115 is a 900 MHz Cordless Phone with Caller Identifier. It isdesigned and engineered to exacting standards for reliability, long life,and outstanding performance.FEATURES• Caller ID (64 call data memory locations) with call waiting• 40 Channels (auto or manual selection)• LCD on the handset with three-language selection• 10-Number Two-touch Dial Memory• Direct dialing from caller list• Extended battery life• Digital security codingThe FF2115 features include AutoTalk™ and AutoStandby™.AutoTalk™ allows you to answer a call by just removing the Handsetfrom the Base so you don’t have to waste time pushing buttons orflipping switches. AutoStandby™ allows you to hang up by simplyreturning the handset to the Base.The UltraClear Plus™ true compander circuitry virtually eliminatesbackground noise. This innovative technology, together with 40different channels, provides you with the best possible receptionduring all your conversations.TO PROTECT YOU AGAINST MISBILLED CALLS, THE FF2115 HASRANDOM CODE™ DIGITAL SECURITY WHICH AUTOMATICALLYSELECTS ONE OF OVER 65,000 DIGITAL SECURITY CODES FORTHE HANDSET AND BASE UNIT. ALSO, THE AUTOSECURER™FEATURE ELECTRONICALLY LOCKS YOUR PHONE WHEN THEHANDSET IS IN THE BASE. TO GET THE MOST FROM YOUR FF2115,PLEASE READ THIS OPERATING GUIDE THOROUGHLY. 8

Users Manual

STOP ...DON’T TAKE ME BACK TO THE STORE. LOOK ...FOR THE TOLL-FREE “HELP” TELEPHONE NUMBER. LISTEN ...AS THE EXPERTS TALK YOU THROUGH THE PROBLEM. For immediate answers to your questions regarding operation, missing parts or installation, call the SOUTHWESTERN BELL FREEDOM PHONE® RETAIL SALES HELP LINE AT: 1-800-366-0937 Monday - Friday 8:30a.m. - 9:00p.m. EST Saturday 8:30a.m. - 12:30p.m. EST http://www.swbfreedomphone.com SOUTHWESTERN BELL FREEDOM PHONE® 7475 N. Glen Harbor Blvd., Glendale, AZ 85307 FF2115 H T Printed in China Southwestern BellFreedom Phone ® 900MHz Cordless Telephone with Call Waiting Caller IDFF2115 H T Owner’s Manual Toll Free Helpline 1-800-366-0937http://www.swbfreedomphone.com IB- 4 3 7 8 CONTENTS IMPORTANT SAFETY INSTRUCTIONSSAFETY INSTRUCTIONS FOR BATTERIESNAME OF CONTROLS AND INDICATIONSFCC WANTS YOU TO KNOWINTRODUCTIONFEATURESBOX CONTENTSPREPARATIONOPERA TING INSTRUCTIONS INSTALLATIONHANDSET BATTERY CHARGINGCALLER ID SETUPTELEPHONE OPERATIONCALLER ID OPERATIONTROUBLESHOOTINGPRODUCT CARESERVICELIMITED WARRANTY 2 34589 1010111314151922242526 IMPORTANT SAFETY INSTRUCTIONS BEFORE USING YOUR TELEPHONE EQUIPMENT, BASIC SAFETY PRECAUTIONSSHOULD ALWAYS BE FOLLOWED TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCKAND INJURY TO PERSONS, INCLUDING THE FOLLOWING:1. Read and understand all instructions.2. Follow all warnings and instructions marked on the product.3. Unplug this product from the wall telephone jack and power outlet before cleaning. Donot use liquid cleaners or aerosol cleaners. Use a damp cloth for cleaning.4. Do not use this product near water, for example, near a bath tub, wash bowl, kitchensink, laundry tub, swimming pool, or in a wet basement.5. Do not place this product on an unstable cart, stand or table. The product may fall,causing serious damage.6. Slots or openings in the cabinet and the back and bottom are provided for ventilation, toprotect it from overheating. These openings must not be blocked or covered. The openingsshould never be blocked by placing the product on a bed, or other similar surface. This productshould never be placed near or over a radiator or heat register.7. This product should be operated only from the type of power source indicated on themarking label. If you are not sure of the type of power supply to your home, consult yourdealer or local power company.8. Do not allow anything to rest on the power cord. Do not place this product where thecord will be damaged by persons stepping on it. 9. Do not overload wall outlets and extension cords, as this can result in fire or electric shock. 10. Never push objects of any kind into this product through cabinet slots, as they maytouch dangerous voltage points or short out parts. This could result in fire or electric shock.Never spill liquid of any kind on the product.11. To reduce the risk of electric shock, do not disassemble this product. Instead, when serviceor repair work is required, take it to a qualified service technician. Opening or removing coversmay expose you to dangerous voltages or other risks. Incorrect reassembly can cause electricshock when the appliance is subsequently used.12. Unplug this product from the wall outlet and refer servicing to qualified service personnelunder the following conditions: a. When the power supply cord or plug is damaged or frayed.b. If liquid has been spilled into the product.c. If the product has been exposed to rain or water.d. If the product does not operate normally, and proper operating instructions have been followed, adjust only those controls that are covered by the operating instructions. Improperadjustment of other controls may result in damage and will often require extensive work by aqualified technician to restore the product to normal operation. e. If the product has been dropped or the cabinet has been damaged.f. If the product exhibits a distinct change in performance. 13. Avoid using a telephone (other than a cordless type) during an electrical storm. Theremay be a remote risk of electric shock from lightning.14. Do not use the telephone to report a gas leak in the vicinity of the leak.15. Use only the power cord and batteries indicated in this manual. Do not dispose of batteriesin a fire. They may explode. Check with local codes for possible special disposal instructions. CAUTIONDanger of explosion if battery is incorrectly replaced.Replace only with the same or equivalent type recommended by the manufacturer.Dispose of used batteries according to the manufacturer’s instructions. 3 4 SAFETY INSTRUCTIONS FOR BATTERIES Safety Instructions for BatteriesHandset Battery PackCAUTION:Use only a Southwestern Bell Freedom Phone® approved battery pack in the handsetof your FF2115 Cordless Telephone. To reduce the risk of fire or injury, always do thefollowing when replacing, discarding or charging batteries. When handling the batteries,be careful not to short the battery with conducting materials such as rings, bracelets,and keys. The battery or conducting material may overheat and cause burns.Use only the following type and size of battery pack:FOR HANDSET UNIT : BYD D-AA 6 00x3 3.6V 6 00mAH r , BYD Battery Co.,Ltd a. Do not dispose of the battery pack in a fire. The cell may explode. Check with local codes for possible special disposal instructions. b. Do not attempt to open or mutilate the battery pack. The chemicals are dangerous and may cause damage to the eyes or skin, and may be toxic if swallowed. c. Follow the charge instructions outlined in this manual. (See page 13) The EPA certified RBRC®* Battery Recycling Seal on the nickel-cadmium (Ni-Cd)battery indicates that Southwestern Bell Freedom Phone® Retail Sales is voluntarilyparticipating in an industry program to collect and recycle these batteries at the end oftheir useful life, when taken out of service in the United States or Canada. The RBRC®program provides a convenient alternative to placing used Ni-Cd batteries into thetrash or the municipal waste stream, which may be il…

Text truncated - open the document above for the full version.

Block Diagram

FF2115bbd.sch-1 - Tue Aug 20 10:52:53 2002 2115hbd.sch-1 - Tue Aug 20 10:48:42 2002

External Photos

External photos FCC ID: LBBFF2115HT External photos FCC ID: LBBFF2115HT

ID Label/Location Info

LINE DRAWING LIONDA TECHNOLOGY COMPANY LIMITED ENGINEERING DEPARTMENT TITLE DRAWN BY DATE : : : CHECKED BY DATE APPROVED BY DATE REVISION : : : : : August 9, 2002 FF2115 Base ( back & rear view) US 9901009 L I S T E D R Freedom Phone ® Southwestern Bell Complies with 47 CFR Part 68 Requirements FCC REGISTRATION No: US: SBFW901BFF2115HT USOC JACK: RJ11C REN: 0.1BHAC MADE IN CHINA MANUFACTURED TO BELL SPECIFICATIONS FCC ID : LBBFF2115HT THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT TO THE FOLLOWING TWO CONDITIONS: (1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE, AND (2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION. PRIVACY OF COMMUNICATION MAY NOT BE ENSURED WHEN USING THIS PHONE. MODEL NO. FF2115HT CONFORMS TO ANSI/UL STD. 1950 US 9901009 L I S T E D R Freedom Phone ® Southwestern Bell Complies with 47 CFR Part 68 Requirements FCC REGISTRATION No: US: SBFW901BFF2115HT USOC JACK: RJ11C REN: 0.1BHAC MADE IN CHINA MANUFACTURED TO BELL SPECIFICATIONS FCC ID : LBBFF2115HT THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT TO THE FOLLOWING TWO CONDITIONS: (1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE, AND (2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION. PRIVACY OF COMMUNICATION MAY NOT BE ENSURED WHEN USING THIS PHONE. MODEL NO. FF2115HT CONFORMS TO ANSI/UL STD. 1950 LINE DRAWING LIONDA TECHNOLOGY COMPANY LIMITED ENGINEERING DEPARTMENT TITLE DRAWN BY DATE : : : CHECKED BY DATE APPROVED BY DATE REVISION : : : : : SEPT. 5, 2002 FF2115 handset front and side view 0 7 8 4 5 12 9 6 3 DIR DEL CHAN MENU VOICE MAIL EDIT FLASH SAVE REDIAL OPTION TALK ABC DEF GHI JKL MNO PQRS TUV WXYZ OPER NEW CALL MSG WTG HEADSET LOW MID HI FCC ID: LBBFF2115HT Model No.: FF2115HT FCC ID: LBBFF2115HT Model No.: FF2115HT

Internal Photos

Internal photos FCC ID: LBBFF2115HT Base assembly (View 1) Base assembly (View 2) Internal photos FCC ID: LBBFF2115HT Base Main PCB comp side (View 1) Base Main PCB comp side (View 2) Internal photos FCC ID: LBBFF2115HT Base Main PCB solder side Base Oscillator PCB comp side Internal photos FCC ID: LBBFF2115HT Base Oscillator PCB solder side Internal photos FCC ID: LBBFF2115HT Handset assembly Handset Main PCB comp side (View 1) Internal photos FCC ID: LBBFF2115HT Handset Main PCB comp side (View 2) Handset Main PCB display side Internal photos FCC ID: LBBFF2115HT Handset Oscillator PCB comp side Handset Oscillator PCB solder side

Operational Description

LIONDA TECHNOLOGY COMPANY LIMITED ENGINEERING DEPARTMENT FF2115desc.doc Page 1 9/27/2002 CIRCUIT DESCRIPTION Model: FF2115 Base a. RF Transmitter Section – RF Board Compressed audio signal is frequency modulated through the varactor diode D3, D4. Diode D3, D4, L4 and Q5 the external components formed the voltage controlled oscillator circuit for the transmitter part. This circuit generates the TX VCO frequency. A portion of this signal is fed back to the PLL IC’s pin1 (FIN1) for phase comparison. Once the phase of oscillation stabilized, the PLL circuit generates the error voltage necessary for the VCO to oscillate at the desired transmitter’s RF frequency. The VCO circuit impedance is matched with the succeeding circuit through the transistor Q2 that also acts as the buffer amplifier. RF amplifier Q7 boosts the signal for transmission. This amplified RF signal is trimmed to the desired frequency band by BPF903 so as not to interfere with the receiver circuit. The transmitter RF signal is then propagated through the antenna. b. RF Receiver Section - RF Board The Base Unit antenna receives RF signal. Band Pass Filter BPF903 trims the signal to the desirable frequency band. Transistor Q6 & Q3 is a low noise amplifier that boosts the RF signal to a specific level for mixing. PLL IC1 (KB8825B) is used as a Universal Phase Lock Loop circuit. The frequency from the Voltage Controlled Oscillator (VCO) D1, L5 and Q4, is fed back to the PLL IC through pin 16 (FIN2) for phase comparison. During channel scanning or turning the unit on, once the phase of oscillation stabilized (locked), the PLL circuit generates the first local oscillator frequency for down-converting the received RF signal into the first IF frequency 10.7MHz. This process is accomplished through the IF mixer circuit Q1. Q1 is used for matching the impedance of the mixer circuit with the succeeding circuits. The resulting IF signal is kept constant by the IF Filter FL1 to 10.7MHz which is then mixed with the second local oscillator frequency 11.150MHz (derived from X1 & C47) to produced a much lower IF frequency. This lower IF frequency if further filtered by IF Filter FL4 to produce a more stable signal of 450AKHz. Quadrature signal detection is accomplished internally by the Narrow-band Detector IC2 (KA3361) with the IF coil L7. The recovered audio frequency can be taken from IC2 audio output pin9. Double conversion of received signal is utilized to improve the image frequency rejection of the unit. c. Transmitter Audio Section – Main Board Audio Frequency signal from the telephone line is compressed through the compressor part of IC4 to minimize the transmission noise. The degree of compression depends on the external RC combinations. AGC is also utilized by IC4 to avoid shock noise caused by abrupt change of audio levels. The compressed audio is filtered and amplified for better acoustical performance. d. Receiver Audio Section – Main Board The compressed Audio Frequency signal is passed through passive RC filters for acoustic compliance. The filtered audio is then fed to the Compander IC4 for expansion thus retrieving the original Audio signal with noise filtered out. Q5 is used as buffer circuit. Bridge rectifier D12-D15 isolates the high-voltage telephone line to the rest of the circuit. D12-D15 is 1 LIONDA TECHNOLOGY COMPANY LIMITED ENGINEERING DEPARTMENT FF2115desc.doc Page 2 9/27/2002 also act as a hybrid transformer to create a two-way path for audio transmission to and reception from the telephone line. Handset a. RF Transmitter Section – RF Board Refer to portion 1.b for this section. All circuit performance is the same except that Band Pass Filter BPF927 is changed to BPF903 for the handset transmission. b. RF Receiver Section – RF Board Refer to portion 1.b for this section. All circuit performance is the same except that Band Pass Filter BPF903 is changed to BPF927 for the handset reception. c. Transmitter Audio Section – Main Board Audio Frequency signal from the handset or from the headset microphone is compressed through the compressor part of IC1 to minimize the transmission noise. The degree of compression depends on the external RC combinations. AGC is also utilized by IC1 to avoid shock noise caused by abrupt change of audio levels. The compressed audio is filtered and amplified for better acoustical performance. Q3 is a switching transistor that controls the power supply for the TX RF part. d. Receiver Audio Section – Main Board The compressed Audio Frequency signal is passed through passive RC filters for acoustic compliance. The filtered audio is then fed to the Compander IC1 for expansion thus retrieving the original audio signal with noise filtered out. Q2 & Q10 act as audio amplifier to sufficiently drive the handset speaker. Q7 and Q8 are switching transistors that control the power supply for the RF part, the Compander part and the AF amplifier respectively. An earphone jack is provided for an optional headset unit for handsfree conversation on the handset. OTHERS (Handset): a. Charging and Reset Controls Recharging the handset battery is accomplished by putting the handset on the cradle. IC5 detects this action and sends a command to the CPU for proper exchange of security code. b. Ring Detection When the handset receives the ring command from the base unit, the CPU will send buzzer signal to the ringer amplifier Q5 and Q6 that drives the Buzzer. c. Antenna Antenna is permanently attached to the RF module, and it is integral type. Sequence mode is as indicated in the block diagram. 3 2 LIONDA TECHNOLOGY COMPANY LIMITED ENGINEERING DEPARTMENT FF2115desc.doc Page 3 9/27/2002 OTHERS (Base): a. Hook Switching and Dialing Hook switching and the transistor Q6 that is controlled by the CPU accomplishes pulse dialing. DTMF signal from the ladder circuit internal to the CPU is filtered and amplified by Q5. b. Over-voltage Protection Fuse1 and varistor Z1 act as high current and high voltage protectors for the …

Text truncated - open the document above for the full version.

Schematics

FF2115rfb.sch-1 - Thu Sep 05 12:40:03 2002 2115hm.sch-1 - Thu Sep 05 12:36:13 2002 FF2115rfh.sch-1 - Thu Sep 05 12:41:04 2002

Test Report

• The test results reported in this report shall refer only to the sample actually tested and shall not refer or be deemed to refer to bulk from which such a sample may be said to have been obtained. • This report shall not be reproduced except in full without prior authorization form Intertek Testing Services Limited FCC ID: PEG39281-5 Intertek Testing Services Hong Kong Ltd. 2/F., Garment Centre, 576 Castle Peak Road, Kowloon, Hong Kong. Tel: (852) 2173 8888 Fax: (852) 2741 1693 Senton Enterprises Limited Application For Permissive Change 900MHz 40 Channel Analog Modulation Cordless Phone with Alarm Clock Radio (FCC ID: PEG39281-5) WO# 0210549 TL/Ann Choy October 8, 2002 INTERTEK TESTING SERVICES FCC ID: PEG39281-5 i LIST OF EXHIBITS INTRODUCTION EXHIBIT 1: General Description EXHIBIT 2: System Test Configuration EXHIBIT 3: Emission Results EXHIBIT 4: Equipment Photographs EXHIBIT 5: Product Labelling EXHIBIT 6: Technical Specifications EXHIBIT 7: Instruction Manual EXHIBIT 8: Security Code Information INTERTEK TESTING SERVICES FCC ID: PEG39281-5 ii MEASUREMENT/TECHNICAL REPORT Senton Enterprises Limited - MODEL: 39281 FCC ID: PEG39281-5 This report concerns (check one:) Original Grant Class II Change X Equipment Type : Cordless Telephone (example : computer, modem, transmitter, etc.) Deferred grant requested per 47 CFR 0.457(d)(1)(ii)? Yes No X If yes, defer until : date Company Name agrees to notify the Commission by: date of the intended date of announcement of the product so that the grant can be issued on that date. Transition Rules Request per 15.37 ? Yes No X If no, assumed Part 15, Subpart C for intentional radiator - the new 47 CFR [12-18-01 Edition] Provision. Report prepared by: Tommy Leung Intertek Testing Services. 2/F., Garment Centre, 576 Castle Peak Road, Kowloon, Hong Kong. Phone : 852-2173-8538 Fax: 852-2741-1693 INTERTEK TESTING SERVICES FCC ID: PEG39281-5 iii Table of Contents 1.0 General Description.........................................................................................................2 1.1 Product Description.........................................................................................................2 1.2 Purpose of Application ....................................................................................................2 1.3 Test Methodology ............................................................................................................3 1.4 Test Facility .....................................................................................................................3 2.0 System Test Configuration .................................................................................................5 2.1 Justification ......................................................................................................................5 2.2 EUT Exercising Software................................................................................................5 2.3 Support Equipment List and Description........................................................................6 2.4 Measurement Uncertainty ...............................................................................................7 2.5 Equipment Modification..................................................................................................7 3.0 Emission Results ...................................................................................................................9 3.1 Field Strength Calculation .............................................................................................10 3.2 Radiated Emission Configuration Photograph - Base Unit ..........................................11 3.3 Radiated Emission Data - Base Unit .............................................................................12 3.4 Radiated Emission Configuration Photograph - Handset .............................................15 3.5 Radiated Emission Data - Handset................................................................................16 3.6 Radiated Emission on the bandedge..............................................................................19 3.7 Line Conducted Configuration Photograph - Base Unit...............................................21 3.8 Line Conducted Emission Data - Base Unit .................................................................22 4.0 Equipment Photographs ...................................................................................................25 5.0 Product Labelling ...............................................................................................................27 6.0 Technical Specifications ....................................................................................................29 7.0 Instruction Manual ............................................................................................................31 8.0 Security Code Information ...............................................................................................33 INTERTEK TESTING SERVICES FCC ID: PEG39281-5 iv List of attached file Exhibit type File Description filename Test Report Test Report report.doc Operation Description Technical Description descri.pdf Cover Page Purpose of Application product change.pdf Test Setup Photo Radiated Emission for Base config photos.doc Test Setup Photo Radiated Emission for Handset config photos.doc Test Report Emission Plot emission.pdf Test Setup Photo Conducted Emission config photos.doc Test Report Conducted Emission Test Result conduct.pdf External Photo External Photo external photos.doc Internal Photo Internal Photo internal photos.doc Block Diagram Block Diagram block.pdf Schematics Circuit Diagram circuit.pdf ID Label/Location Label Artwork and Location label.pdf User Manual User Manual manual.pdf User Manual FCC Information fcc information.pdf INTERTEK TESTING SERVICES FCC ID: PEG39281-5 1 EXHIBIT 1 GENERAL DESCRIPTION INTERTEK TESTING SERVICES F…

Text truncated - open the document above for the full version.

Test Setup Photos

The Worst Case Configuration Photographs FCC ID: LBBFF2115HT Radiated Emission – Base Front View Rear View The Worst Case Configuration Photographs FCC ID: LBBFF2115HT Radiated Emission – Handset Front View Rear View The Worst Case Configuration Photographs FCC ID: LBBFF2115HT Conducted Emission Front View Rear View The Worst Case Configuration Photographs FCC ID: LBBFF2115HT Conducted Emission Side View

Test Setup Photos
