LIST OF GENERATED FREQUENCIES Frequencies of the oscillators shown in the block diagrams hereafter: (1)SAW-Resonator Oscillator in the transmitters f =433.92 MHz. (2)SAW-Local Oscillator in the receiversf LO = 433.42 MHz. (3)Processor Oscillator in the MINI Receiverf =5 MHz. (4)Processor Oscillator in the radio programmer f =10 MHz. P. 1 of 4 CARDIN ELETTRONICA S.p.A. R.& D. Dept. P. 2 of 4 SERIES S435 - 2 CH TRANSMITTER SCHEMATIC BLOCK SECURITY CODE EEPROM uPROCESSOR SAW-RESONATOR OSCILLATOR (1) ANTENNA+ RF FILTER BATTERY 2 CHANNEL BUTTONS CODE GENERATION BUTTON SERIES S435 - 4 CH TRANSMITTER SCHEMATIC BLOCK SECURITY CODE EEPROM uPROCESSOR SAW-RESONATOR OSCILLATOR (1) ANTENNA+ RF FILTER BATTERY 4 CHANNEL BUTTONS CODE GENERATION BUTTON SERIES S435 - 12 CH TRANSMITTER SCHEMATIC BLOCK SECURITY CODE EEPROM uPROCESSOR SAW-RESONATOR OSCILLATOR (1) ANTENNA+ RF FILTER BATTERY 4 CHANNEL BUTTONS 1ST, 2ND, 3RD CHANNEL BANK SELECTOR CODE GENERATION BUTTON CARDIN ELETTRONICA S.p.A. R.& D. Dept. P. 3 of 4 SERIES S435 - MINI RECEIVER SCHEMATIC BLOCK POWER SUPPLY ANTENNA+ RF FILTER RF INPUT AMPLIFIER DEMODULATORuPROCESSOR uP OSCILLATOR (3) SECURIY CODE EEPROM CARD POWER ON RESET CIRCUIT 2 RELAYS SAW LOCAL OSCILLATOR (2) TERMINAL BOARDS MEMO BUTTON DELETE BUTTON JUMPERS FOR CHANNEL SELECTION CARDIN ELETTRONICA S.p.A. R.& D. Dept. P. 4 of 4 SERIES S435 -RADIOPROGRAMMER SCHEMATIC BLOCK POWER SUPPLY ANTENNARF MODULE (2)uPROCESSOR uP OSCILLATOR (4) SECURIY CODE EEPROM CARD POWER ON RESET CIRCUIT 3 RELAYS FOR MOTOR CONTROL I/O CONNECTOR MEMO & DELETE BUTTONS WORK CYCLE SETTING DIP-SWITCH FOR CHANNEL SELECTION DYNAMIC BUTTON open-stop-close-stop

ESR-BriefCert-00-06-04 E LECTRO M AGNETIC C OMPATIBILITY C ERTIFICATION EMCCert DR. RAŠEK · Boelwiese 5 · 91320 Ebermannstadt · Germany Zertifizierungsinstitut · Certification Institute Sachverständigenbüro · Technical Experts Von der Industrie- und Handelskammer für Ober- franken Bayreuth 1977 öffentlich bestellter und ver- eidigter Sachverständiger für elektrische Störungen und elektromagnetische Verträglichkeit BENANNTE STELLE / NOTIFIED BODY 89/336, 91/263, 93/97, 98/13, 99/5/EC BRD/RegTP EU # 0678 ZUSTÄNDIGE STELLE / COMPETENT BODY 89/336/EEC BAPT # BPT-ZE-009/94 Telefon:0 91 94 - 93 31 International:+ 49 - 91 94 - 93 31 Telefax:0 91 94 - 79 64 - 84 International:+ 49 - 91 94 - 79 64 - 84 Mail:[email protected] Web:http : //www . emcc . de Ihr ZeichenUnser ZeichenDatum Your ReferenceOur ReferenceDate V.A.T. Id. Nr.: DE 1326 389 00 Bank: HypoVereinsbank Forchheim, Germany # 1040293139 (BLZ 760 202 14), S.W .I.F.T.-Code HYVE DE MM 222 Sparkasse Forchheim, Germany # 74468 (BLZ 763 510 40), S.W .I.F.T.-Code BYLA DE MM Citibank New York, USA # 50273189, S.W .I.F.T.-Code 021000089 S INCE 1977 Application for Certification on behalf of Cardin Elettronica S.p.A. Confidentiality / FCC ID: LH8T-S435 Dear Sir/Madam Pursuant to Section 0.459 of the Commission's rules (CFR 47), we request confidentiality for portions of the material contained in the application for FCC ID: LH8T-S435 and that the identified material be withheld from public inspection following the grant of this authorization. This material contains Cardin's trade secrets and confidential information that Cardin Elettronica S.p.A. does not customarily release to the public and which is otherwise not generally available to the public. Confidentiality is requested for the following exhibits: 1. WIRING DIAGRAM 2. PARTS LIST Yours sincerely, EMCCert DR. RAŠEK Klaus Knoerig Agent for Cardin Elettronica S.p.A. EMCC Dr. Rasek Boelwiese 5 Ebermannstadt, Germany 91320 Federal Communications Commission Authorizations and Evaluation Division 7435 Oakland Mills Road Columbia Maryland 21046 USA Kn/-950295AOC/nb2000-11-27

FCC ID: LH8T-S435 RADIO LABORATORIES EMC LABORATORIES TTI-P-G 094/94 TTI-P-G 074/95 EMCC DR. RAäEK Moggast 72-74 91320 Ebermannstadt Germany FCC Registration # 90566 TX_Annex2e.doc Telephone: +49-9194-9016 Telefax:+49-9194-8125 Mail:[email protected] Web:http://www.emcc.de Page 1 of 6 ANNEX 2 TO TEST REPORT # EMCC-950295AOC, 2000-NOV-21 PHOTOGRAPHS OF EQUIPMENT UNDER TEST (EUT) EXTERNAL VIEWS EQUIPMENT UNDER TEST: Trade Name:S435 Model:TRS43540M.0US and TRS435120.0US Serial No:None Equipment Category:Transmitter Manufacturer:CARDIN ELETTRONICA SPA Address:Via Raffaello 36 31020 S. Vendemiano (TV) Italy Phone:+39-0438-401818 Fax:+39-0438-401831 RELEVANT STANDARD:47 CFR Part 15C - Intentional Radiators CONTENTS Page 1 MODEL TRS43540M.0US........................................................................................................................................ 2 1.1 Front view of EUT............................................................................................................................................ 2 1.2 Rear view of EUT ............................................................................................................................................ 3 2 MODEL TRS435120.0US......................................................................................................................................... 4 2.1 Front view of EUT............................................................................................................................................ 4 2.2 Rear view of EUT ............................................................................................................................................ 5 3 MODEL TRS435200.0US (VARIANT OF MODEL TRS435120.0US) ..................................................................... 6 3.1 Front view of EUT............................................................................................................................................ 6 FCC ID: LH8T-S435 Annex 2 to Test Report #EMCC-950295AOC Page 2 of 6 Issue Date: 2000-NOV-21 TEST OF S435 MODEL TRS43540M.0US AND TRS435120.0US TO 47 CFR PART 15C - INTENTIONAL RADIATORS TX_ANNEX2E.DOC 1 MODEL TRS43540M.0US 1.1 Front view of EUT FCC ID: LH8T-S435 Annex 2 to Test Report #EMCC-950295AOC Page 3 of 6 Issue Date: 2000-NOV-21 TEST OF S435 MODEL TRS43540M.0US AND TRS435120.0US TO 47 CFR PART 15C - INTENTIONAL RADIATORS TX_ANNEX2E.DOC 1.2 Rear view of EUT FCC ID: LH8T-S435 Annex 2 to Test Report #EMCC-950295AOC Page 4 of 6 Issue Date: 2000-NOV-21 TEST OF S435 MODEL TRS43540M.0US AND TRS435120.0US TO 47 CFR PART 15C - INTENTIONAL RADIATORS TX_ANNEX2E.DOC 2 MODEL TRS435120.0US 2.1 Front view of EUT FCC ID: LH8T-S435 Annex 2 to Test Report #EMCC-950295AOC Page 5 of 6 Issue Date: 2000-NOV-21 TEST OF S435 MODEL TRS43540M.0US AND TRS435120.0US TO 47 CFR PART 15C - INTENTIONAL RADIATORS TX_ANNEX2E.DOC 2.2 Rear view of EUT FCC ID: LH8T-S435 Annex 2 to Test Report #EMCC-950295AOC Page 6 of 6 Issue Date: 2000-NOV-21 TEST OF S435 MODEL TRS43540M.0US AND TRS435120.0US TO 47 CFR PART 15C - INTENTIONAL RADIATORS TX_ANNEX2E.DOC 3 MODEL TRS435200.0US (VARIANT OF MODEL TRS435120.0US) 3.1 Front view of EUT

FCC ID: LH8T-S435 This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: 1) This device may not cause harmful interference and 2) This device must accept any interference received including interference that may cause undesired operations ETICHETTE conformità LH8T-S435 S435 20-11-2000 ZVE392 S435 CONFORMITÀ USA (TRS435200-TRS435400 -TRS435120-TRS43540M) SCALA: 1:1 Description : Product Code : Date : Drawing number : P.J.Heath CARDIN ELETTRONICA S.p.A - 31020 San Vendemiano (TV) Italy - via Raffaello, 36 Tel: 0438/401818 Fax: 0438/401831 Draft : All rights reserved. Unauthorised copying or use of the information contained in this document is punishable by law Materiale: PVC Grey Fondo/Scrittura: Nero Bordo: Nessuno

FCC ID: LH8T-S435 RADIO LABORATORIES EMC LABORATORIES TTI-P-G 094/94 TTI-P-G 074/95 EMCC DR. RAäEK Moggast 72-74 91320 Ebermannstadt Germany FCC Registration # 90566 TX_Annex2i.doc Telephone: +49-9194-9016 Telefax:+49-9194-8125 Mail:[email protected] Web:http://www.emcc.de Page 1 of 9 ANNEX 2 TO TEST REPORT # EMCC-950295AOC, 2000-NOV-21 PHOTOGRAPHS OF EQUIPMENT UNDER TEST (EUT) INTERNAL VIEWS EQUIPMENT UNDER TEST: Trade Name:S435 Model:TRS43540M.0US and TRS435120.0US Serial No:None Equipment Category:Transmitter Manufacturer:CARDIN ELETTRONICA SPA Address:Via Raffaello 36 31020 S. Vendemiano (TV) Italy Phone:+39-0438-401818 Fax:+39-0438-401831 RELEVANT STANDARD:47 CFR Part 15C - Intentional Radiators CONTENTS Page 1 MODEL TRS43540M.0US........................................................................................................................................ 2 1.1 Housing opened .............................................................................................................................................. 2 1.2 Print circuit board, side 1 ................................................................................................................................. 3 1.3 Print circuit board, side 2 ................................................................................................................................. 4 2 MODEL TRS435120.0US......................................................................................................................................... 5 2.1 Housing opened, print circuit board removed ................................................................................................. 5 2.2 Print circuit board, side 1 ................................................................................................................................. 6 2.3 Print circuit board, side 2 ................................................................................................................................. 7 3 MODEL TRS435200.0US (VARIANT OF MODEL TRS435120.0US) ..................................................................... 8 3.1 Print circuit board, side 1 ................................................................................................................................. 8 3.2 Print circuit board, side 2 ................................................................................................................................. 9 FCC ID: LH8T-S435 Annex 2 to Test Report #EMCC-950295AOC Page 2 of 9 Issue Date: 2000-NOV-21 TEST OF S435 MODEL TRS43540M.0US AND TRS435120.0US TO 47 CFR PART 15C - INTENTIONAL RADIATORS TX_ANNEX2I.DOC 1 MODEL TRS43540M.0US 1.1 Housing opened FCC ID: LH8T-S435 Annex 2 to Test Report #EMCC-950295AOC Page 3 of 9 Issue Date: 2000-NOV-21 TEST OF S435 MODEL TRS43540M.0US AND TRS435120.0US TO 47 CFR PART 15C - INTENTIONAL RADIATORS TX_ANNEX2I.DOC 1.2 Print circuit board, side 1 FCC ID: LH8T-S435 Annex 2 to Test Report #EMCC-950295AOC Page 4 of 9 Issue Date: 2000-NOV-21 TEST OF S435 MODEL TRS43540M.0US AND TRS435120.0US TO 47 CFR PART 15C - INTENTIONAL RADIATORS TX_ANNEX2I.DOC 1.3 Print circuit board, side 2 FCC ID: LH8T-S435 Annex 2 to Test Report #EMCC-950295AOC Page 5 of 9 Issue Date: 2000-NOV-21 TEST OF S435 MODEL TRS43540M.0US AND TRS435120.0US TO 47 CFR PART 15C - INTENTIONAL RADIATORS TX_ANNEX2I.DOC 2 MODEL TRS435120.0US 2.1 Housing opened, print circuit board removed FCC ID: LH8T-S435 Annex 2 to Test Report #EMCC-950295AOC Page 6 of 9 Issue Date: 2000-NOV-21 TEST OF S435 MODEL TRS43540M.0US AND TRS435120.0US TO 47 CFR PART 15C - INTENTIONAL RADIATORS TX_ANNEX2I.DOC 2.2 Print circuit board, side 1 FCC ID: LH8T-S435 Annex 2 to Test Report #EMCC-950295AOC Page 7 of 9 Issue Date: 2000-NOV-21 TEST OF S435 MODEL TRS43540M.0US AND TRS435120.0US TO 47 CFR PART 15C - INTENTIONAL RADIATORS TX_ANNEX2I.DOC 2.3 Print circuit board, side 2 FCC ID: LH8T-S435 Annex 2 to Test Report #EMCC-950295AOC Page 8 of 9 Issue Date: 2000-NOV-21 TEST OF S435 MODEL TRS43540M.0US AND TRS435120.0US TO 47 CFR PART 15C - INTENTIONAL RADIATORS TX_ANNEX2I.DOC 3 MODEL TRS435200.0US (VARIANT OF MODEL TRS435120.0US) 3.1 Print circuit board, side 1 FCC ID: LH8T-S435 Annex 2 to Test Report #EMCC-950295AOC Page 9 of 9 Issue Date: 2000-NOV-21 TEST OF S435 MODEL TRS43540M.0US AND TRS435120.0US TO 47 CFR PART 15C - INTENTIONAL RADIATORS TX_ANNEX2I.DOC 3.2 Print circuit board, side 2

CARDIN ELETTRONICA S.p.A. R.& D. Dept. P. 1 of 4 1.0 INTRODUCTION Manufacturer’s data CARDIN ELETTRONICA SPA VIA RAFFAELLO 36 Tel. +39-0438-401818 31020 S. VENDEMIANO (TV) Fax.+39-0438-401831 ITALY Product marketing and commercial name S435 RADIO CONTROL (operating frequency: 433.92 MHz) consists of the following equipments: - miniaturized transmitter 2 channels (TX2) TRS435 200.0US - miniaturized transmitter 4 channels (TX4) TRS435 400.0US - wall mounted transmitter 4 channels (TX4M) TRS435 40M.0US - miniaturized transmitter 12 channels (TX12) TRS435 120.0US Note: the transmitter versions only differ from one and other by the number of functions (channels) which they are able to activate from a distance. The various containers differ from one and other by the number of buttons which depend on the model; it’s necessary remember that the four and twelve-channel transmitters use the same box but the twelve-channel transmitters has a selector to address the first, the second and the third channel bank. By looking at the wiring diagram it can be seen that all the transmitters feature the same radio frequency section and that only the encode section differs, due to the number of channel functions. - two-channel mini receiver (RXM2CH) RMS435 200.0US - one-channel mini receiver (RXM1CH) RMS435 100.0US - 120V radio programmer (RXPR) RPS435 000.0US Note1: the RF part in the 120V radio programmer is represented by the YRFIBR-433 module. Technical report drawn up by: Ing. M. Terruso Resp. Certif. & Omologhe – Cardin Elettronica S.p.A. CARDIN ELETTRONICA S.p.A. R.& D. Dept. P. 2 of 4 2.0 GENERAL DESCRIPTION - Radio control system model S435 consisting of one or more transmitters and one or more receivers; - Carrier frequency in the UHF waveband controlled by a SAW RESONATOR; - PCM type encoding signal transmitted in modulation bandwidth ASK; - Superetherodyne receiver, single conversion with local oscillator SAW, low rumor RF preamplifier and integrated RF-IF section; - Encoding and decoding device using a highly reliable 49 bit custom LSI, code transmission with complementary parity, automatic pre-chosen channel selection; - Highly reliable encoding system guaranteed by the use of dynamic codes. The code is changed for each encoding transmission through the use of an encoding algorithm which only the receiver is able to recognize and therefore decide whether or not the code transmitted corresponds to the original code. The code is generated for each channel in the transmitter using the random arbitrary method with 2 36 combinations. The generated code is memorized in the receiver via radio. The receiver is able to memorize 32 or 128 or 512 different codes. 2.1 USE AND APPLICATIONS The Radio control model S435 permits the remote activation of electrical and electronic appliances and has its best use in the following areas: • Automatic opening systems • Alarm systems and in all systems which require remote activation (without wires) using secret user codes in compliance with the local safety standards in force. CARDIN ELETTRONICA S.p.A. R.& D. Dept. P. 3 of 4 3.0 PRODUCT DESCRIPTION • 120V radioprogrammer (with container) - External casing in ABS (overall dimensions 115 x 139 x 44mm) - Electronic circuit with the slot-in receiver card YRFIBR-433 and motor control in output - Power supply: 110-120 V ac PRODUCT DESCRIPTION CODE Radioprogrammer RPS435 000.0US • RF module YRFIBR_433 - Only radio frequency part - Band width in Low frequency 2400 Hz. - Slot-in receiver decoded outputs with logical level 5V. CMOS - Circuit board dimensions 50 x 20 mm - Electronic p.c.b. card with an 8-way pin connector to be inserted in to devices suited to its application - Power supply: 5 V. dc PRODUCT DESCRIPTION CODE RF module YRFIBR-433 YRF433IBR0CE • Mini receiver (with container) - One and two channel mini receivers (external dimensions 20x60x90 mm.) - For internal use the device features an easily accessible terminal block and - channel selection on the card - Power supply: 12-24V ac/dc - Up to 32 codes PRODUCT DESCRIPTION CODE 2 channel mini receiver RMS435 200.0US 1 channel mini receiver RMS435 100.0US CARDIN ELETTRONICA S.p.A. R.& D. Dept. P. 4 of 4 • Miniaturized transmitters - Shock-proof container - Overall dimensions 80 x 39 x 12 mm - Led indicating signal emission - Access door permitting battery replacement and user code programming - Power supply: pencil battery 12V (model GP23A) - Versions with up to 12 channels - 2 36 random code combinations with dynamic code transmission PRODUCT DESCRIPTION CODE Miniaturized 2-channel transmitter TRS435 200.0US Miniaturized 4-channel transmitter TRS435 400.0US Wall mounted transmitter 4-channel TRS435 40M.0US Miniaturized 12-channel transmitter TRS435 120.0US

FCC ID: LH8T-S435 Test Report #EMCC-950295AOC Page 2 of 18 Issue Date: 2000-NOV-21 TEST OF S435 MODEL TRS43540M.0US AND TRS435120.0US TO 47 CFR PART 15C - INTENTIONAL RADIATORS FCC_TX435.DOC CONTENTSPage 1 GENERAL INFORMATION ..................................................................................................................................................................... 3 1.1 Purpose........................................................................................................................................................................................ 3 1.2 Limits and Reservations............................................................................................................................................................. 3 1.3 Test Location ............................................................................................................................................................................... 3 1.4 Manufacturer ......................................................................…
