LHJ012Automotive Security Receiver

Re: Certification for Motorola LHJ012 Receiver Model: LHJ012 FCC ID: LHJ012 CANADA: to be provided by IC USER'S MANUAL INFORMATION (PRELIMINARY) The User's Manual is in preparation. The following material will be contained in the manual: FCC ID: LHJ012 CANADA: to be provided by IC This device complies with Part 15 of the FCC Rules and with RSS-210 of Industry Canada. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. WARNING: Changes or modifications not expressively approved by the party responsible for compliance could void the user's authority to operate the equipment.

Re: Certification for Motorola LHJ012 Receiver Model: LHJ012 FCC ID: LHJ012 CANADA: to be provided by IC POWER OF ATTORNEY A letter granting Valdis V. Liepa the Power of Attorney is on file and can be provided when so requested. Re: Certification for Motorola LHJ012 Receiver Model: LHJ012 FCC ID: LHJ012 CANADA: to be provided by IC REQUEST FOR CONFIDENTIALITY Pursuant to 47 CRF 0.459, Motorola requests that a part of the subject application be held confidential. This comprises Exhibits (5) Schematics (10) Parts List (Part of Exhibit only) Motorola has spent substantial effort in developing this product and it is one of the first of its kind in industry. Having the subject information easily available to "competition" would negate the advantage they have achieved by developing this product. Not protecting the details of the design will definitely result in a financial hardship. If there are any questions regarding this request, please contact me at the above address or call 734-483-4211, fax 734-647-2106 or e-mail [email protected]. Sincerely, Valdis V. Liepa Research Scientist University of Michigan January 17, 2002 Re: Certification for Motorola LHJ012 Receiver Model: LHJ012 FCC ID: LHJ012 CANADA: to be provided by IC STATEMENT OF MODIFICATIONS There were no modifications made to the DUT by this test laboratory. (Also see Section 3.1 of the attached Test Report). _____________________ Valdis V. Liepa Research Scientist Re: Certification for Motorola LHJ012 Receiver Model: LHJ012 FCC ID: LHJ012 CANADA: to be provided by IC GENERAL PRODUCT INFORMATION The device, for which certification is pursued, has been designed by: Motorola AIEG 4000 Commercial Avenue Northbrook, IL 60062-1840 Steven Flatt Tel: 847-480-4137 Fax: 847-205-2503 It will be manufactured by: Motorola AIEG 4000 Commercial Avenue Northbrook, IL 60062-1840 Steven Flatt Tel: 847-480-4137 Fax: 847-205-2503 It will be marketed and serviced by: GM Dealers of North America

January 17, 2002 American Telecommunications Certification Body, Inc. 6731 Whittier Avenue Suite C110 McLean, VA 22101 RE: Certification Application FCC ID: LHJ012 Please find enclosed application materials for certification of Motorola LHJ012 Receiver. Portions of this submittal are filed Confidential. Please note that we have enclosed the Letter of Agency, the Modifications Letter, and the Request for Confidentiality in Exhibit 2 (Attestations). If there are any questions regarding the application or testing performed, please contact me at the above address or call 734-483-4211, fax 734-647-2106, or e-mail [email protected]. Sincerely, Valdis V. Liepa Research Scientist

January 17, 2002 Federal Communications Commission Equipment Approval Services P.O. Box 358315 Pittsburgh, PA 15251-5315 Re: Certification for Motorola LHJ012 Receiver Model: LHJ012 FCC ID: LHJ012 CANADA: to be provided by IC Please find enclosed application materials for certification of Motorola LHJ012 Receiver. We tested it and found it to comply with Part 15. If there are any questions regarding the application or testing performed, please contact me at the above address or call 734-483-4211, fax 734-647-2106, or e-mail [email protected]. Sincerely, Valdis V. Liepa Research Scientist Enclosures: Industry Canada Cover Letter Table of Contents for Exhibits January 17, 2002 Certification and Engineering Bureau Industry Canada 3701 Carling Avenue, Bldg. 94 Ottawa, Ontario K2H 8S2 Re: Certification for Motorola LHJ012 Receiver Model: LHJ012 FCC ID: LHJ012 CANADA: to be provided by IC Please find enclosed application materials for certification of Motorola LHJ012 Receiver. We tested the device and found it to comply with RSS-210. The product is identified by: Model: LHJ012 If there are any questions, suggestions, etc., regarding the application or testing performed, please contact me at the above address or call 734-483-4211, fax 734-647- 2106; e-mail: [email protected]. Sincerely, Valdis V. Liepa Research Scientist Enclosures: Application Form with payment (This) Letter of Transmittal Summary of Test Results Table of Contents for Exhibits Application Forms and Exhibits (on CD ROM) January 20, 2002 Re: Certification for Motorola LHJ012 Receiver Model: LHJ012 FCC ID: LHJ012 CANADA: to be provided by IC TABLE OF CONTENTS FOR EXHIBITS Total Pages (1) ID Label/Location Information 2 (2) Attestation Statements 7 (3) External Photos 2 (4) Block Diagrams 1 (5) Schematics 1 (6) Test Report 10 (7) Test Setup Photos 1 (8) User’s Manual 4 (9) Internal Photos 3 (10) Parts List/Parts Placement 8 (11) RF Exposure Information 0 (12) Operational Description 1 (13) Cover Letter(s) 3

LHJ012 Receiver with Harness LHJ012 Receiver Front LHJ012 Receiver Back

LHJ012 Receiver Open - Top LHJ012 Receiver Open - Bottom LHJ012 Receiver PCB - Top LHJ012 Receiver PCB - Bottom LHJ012 Receiver PCB RF Section Close-up Top LHJ012 Receiver PCB RF Section Close-up Bottom

Receiver Description of Operation The receiver is used in an automotive remote function actuation system, powered by the vehicle 12 Volt source. It is contained in the Passenger Side Door Module (PDM), located in the passenger compartment. The PDM also has switches that control various interior functions and communicates with the rest of the vehicle over a communications bus. The PDM is designed to receive a 315 MHz signal that has on off keyed modulation at a digital data rate of 2 kHz. It is a superheterodyne type using a Surface Acoustic Wave (SAW) resonator controlled 304.3 MHz local oscillator. The resulting received digital data is decoded by a microcontroller on the PDM. The internal antenna is impedance matched to the input of the 315 MHz Surface Acoustic Wave (SAW) band pass filter. The output of the SAW filter is impedance matched to the input of the single transistor Low Noise Amplifier (LNA). The output of the LNA drives the RF input of a superheterodyne receiver integrated circuit (IC). The receiver IC has the active circuitry to perform the mixer, local oscillator, intermediate frequency (IF) amplifier, limiter amplifier and demodulator functions. The RF output from the LNA is combined with the local oscillator in the mixer. The 10.7 MHz IF output of the mixer drives a discrete inductor and capacitor band pass filter. The output of the discrete filter drives the input of the IF amplifier. The output of the IF amplifier is connected to the input of the ceramic band pass filter. The output of the ceramic filter is connected to the input of the limiter amplifier. The output of the limiter is internally connected to the demodulator. The demodulator output is connected to the input of the data slicer. The digital data output of the data slicer is connected to the data input of the microcontroller. The microcontroller decodes the received digital data and then issues the appropriate actuation instructions.

LHJ012 Receiver Close-up on OATS LHJ012 Receiver on OATS

LHJ012 Receiver Close-up on OATS LHJ012 Receiver on OATS
