VRX1000 VEHICLE RADIO EXTENDER User’s Guide 8A087X02 Draft 0.11 APRIL 2015 8A087X02 DRAFT 0.11 VRX1000 User’s Guide April 2015 Page 2 of 20 NOTES 8A087X02 DRAFT 0.11 VRX1000 User’s Guide April 2015 Page 3 of 20 Contents Contents........................................................................................................................... 3 Manual Revisions.......................................................................................................... 4 Computer Software Copyrights ..................................................................................... 5 Document Copyrights.................................................................................................... 5 Disclaimer .....................................................................................................................5 Trademarks ................................................................................................................... 5 Commercial Warranty and Service................................................................................ 6 Notations Used in This Manual...................................................................................... 7 RF Energy Exposure Compliance, Awareness and Control Information and Operational Instructions................................................................................................. 9 RF Exposure Label ..................................................................................................... 10 FCC Label ................................................................................................................... 10 Installation Requirements for Compliance with Radio Frequency (RF) Energy Exposure Safety Standards ......................................................................................... 11 Introduction ...................................................................................................................12 Identifying Your VRX1000 Model ................................................................................ 13 Frequency Band of Operation............................................................................................... 13 Cross-Band ........................................................................................................................... 13 VRX1000 Operation Basics .................................................................................................. 14 Powering up the VRX1000.......................................................................................... 15 Turning ON the VRX1000 ........................................................................................... 15 Activating the VRX1000 via the Control Head ...................................................................... 15 Turning OFF the VRX1000 ......................................................................................... 16 Deactivating the VRX1000 via the MSU Control Head......................................................... 16 Selecting VRX1000 Channel....................................................................................... 17 Independent VRX1000 Channel Change ............................................................................. 17 Strapped VRX1000 Channel Change................................................................................... 17 Local Mode Indication ................................................................................................. 17 Appendix 1 – VRX1000 Specifications - Preliminary ................................................. 18 Contact Information ...................................................................................................... 20 8A087X02 DRAFT 0.11 VRX1000 User’s Guide April 2015 Page 4 of 20 Manual Revisions Rev # Date ECN Notes & References DRAFT 0.1 Oct 28, 2014 na DRAFT 0.1 DRAFT 0.11 Apr 30, 2015 na DRAFT 0.11 8A087X02 DRAFT 0.11 VRX1000 User’s Guide April 2015 Page 5 of 20 Computer Software Copyrights The products described in this manual include copyrighted Futurecom computer programs stored in semiconductor memories or other media. Laws in the United States, Canada and other countries preserve for Futurecom certain exclusive rights for copyrighted computer programs, including but not limited to, the exclusive right to copy or reproduce in any form the copyrighted computer programs. Any copyrighted computer program contained in the Futurecom products described in this manual may not be copied, reproduced, modified, reverse-engineered, or distributed in any manner without the express written permission of Futurecom. The purchase of Futurecom products shall not be deemed to grant either directly or by implication, estoppels, or otherwise, any license under the copyrights, patents or patent applications of Futurecom, except for the normal non-exclusive license to use that arises by operation of law in the sale of a product. Document Copyrights No part of this manual may be reproduced, distributed or transmitted in any form or by any means, for any purpose without written permission of Futurecom. Disclaimer The information in this document is carefully examined and is believed to be entirely reliable. However, no responsibility is assumed for inaccuracies. Futurecom Systems Group, ULC. reserves the right to make changes to any products herein to improve reliability, function or design. Futurecom does not assume any liability arising out of the application or use of any product or circuit described herein. Trademarks MOTOROLA, ASTRO, XTL TM 2500, XTL TM 5000, XTS TM 1500, XTS TM 2500, XTS TM 5000, APX TM 4000, APX TM 4500, APX TM 6000, APX TM 7000, APX TM 6500, APX TM 7500, MDC1200 are trademarks of Motorola Solutions Inc. 8A087X02 DRAFT 0.11 VRX1000 User’s Guide April 2015 Page 6 of 20 Commercial Warranty and Service Futurecom Systems Group, ULC. warrants to the original purchaser all standard products sold by Future…

Text truncated - open the document above for the full version.

Date: June 25, 2015 To Whom It May Concern Subject: VRX1000 UHF Justification Letter Applicant: Futurecom Systems Group, ULC FCC ID: LO6-VRX1000UHF The Mobexcom VRX1000 UHF: 1. Is able to operate in the frequency range 380.0 – 512.0MHz. 2. Meets the requirements of FCC Rules, Parts 90.203(e). The operator cannot program and transmit on frequencies other than those programmed by the manufacturer or service personnel. Normally accessible external controls cannot be used to program frequencies; they are only used to select preprogrammed frequencies. 3. Should not be programmed in the frequency band 406.0MHz – 406.1MHz. The following statement is included in the Users Manual: “Do not use the VRX1000 in the frequency band 406.0 – 406.1MHz. This frequency band is reserved for distress beacons.” The VRX1000 UHF is used in the following Part 90 Mobile and Land Mobile frequency bands: • 406.1 - 410.0MHz • 410.0 - 420.0MHz • 420 - 450MHz • 450.0 - 454.0MHz • 456.0 - 460.0MHz • 460.0 - 462.5375MHz • 462.7375 - 467.5375MHz • 467.7375 - 470.0MHz • 470.0 - 512MHz In addition, the VRX1000 UHF is used by Federal and Public Safety agencies and the Military operating in spectrum covered by NTIA under Federal Table G27 instead of Part 90. Having the whole 380.0 - 512.0MHz listed on the FCC Grant allows these agencies and the Military to purchase VRX1000 UHF. 3277 LANGSTAFF ROAD, Concord, Ontario L4K 5P8, Canada, Tel: (905)660-5548 Fax: (905)660-1380 2 Regards, Tony Bombera (Signature) (Print Name) Title: Senior Staff Engineer On behalf of : Futurecom Systems Group ULC. Phone No.: 905 660 5548 Fax No.: 905 660 6858 Email : [email protected]

Federal Communications Commission Authorization and Evaluation Division 1435 Oakland Mills Road Columbia, MD 21046 Date: April 30, 2015 SUBJECT: FCC Application for LO6-VRX1000UHF To Whom It May Concern: We, the undersigned, hereby attest to the fact that we will apply the FCC Verification authorization procedure to the Part 15B - Unintentional Radiator portion of this composite filing. Regards, Tony Bombera (Signature) (Print Name) Title: Senior Staff Engineer On behalf of : Futurecom Systems Group ULC. Phone No.: 905 660 5548 Fax No.: 905 660 6858 Email : [email protected] 3277 LANGSTAFF ROAD, Concord, Ontario L4K 5P8, Canada, Tel: (905)660-5548 Fax: (905)660-1380

FEDERAL COMMUNICATIONS COMMISSION 7435 Oakland Mills Road Columbia, MD 21046 USA Date: April 30, 2015 Subject: Part 90.203(e) Compliance Attestation Applicant: Futurecom Systems Group, ULC Model: VRX1000 UHF FCC ID: LO6-VRX1000UHF Dear Sir or Madam: This equipment meets the requirements of the FCC Rules, Parts 90.203(e). The operator cannot program and transmit on frequencies other than those programmed by the manufacturer, service or maintenance personnel, using the equipment’s external operational controls. Regards, Tony Bombera (Signature) (Print Name) Title: Senior Staff Engineer On behalf of : Futurecom Systems Group ULC. Phone No.: 905 660 5548 Fax No.: 905 660 6858 Email : [email protected] 3277 LANGSTAFF ROAD, Concord, Ontario L4K 5P8, Canada, Tel: (905)660-5548 Fax: (905)660-1380

Date: April 30, 2015 To Whom It May Concern Subject: Authority to Act as an Agent Applicant: Futurecom Systems Group, ULC FCC ID: LO6-VRX1000UHF Dear Sir/Madam, I hereby appoint UltraTech Engineering Labs Inc. (UltraTech) to act as my agent in preparation of this application for authorization of above equipment under F.C.C. Rules. The applicant hereby certify that neither the applicant nor any party to the application is subject to a denial of Federal benefits, that include FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. §862 because of a conviction for possession or distribution of a controlled substance. See 47 CFR 1.2002(b) for the definition of a “party” for these purposes. I also certify that the information provided, properly describe the device or system for which authorization is required. Regards, Tony Bombera (Signature) (Print Name) Title: Senior Staff Engineer On behalf of : Futurecom Systems Group ULC. Phone No.: 905 660 5548 Fax No.: 905 660 6858 Email : [email protected] 3277 LANGSTAFF ROAD, Concord, Ontario L4K 5P8, Canada, Tel: (905)660-5548 Fax: (905)660-1380

Date: April 30, 2015 To Whom It May Concern Subject: Confidentiality Letter Applicant: Futurecom Systems Group, ULC FCC ID: LO6-VRX1000UHF Dear Sir/Madam: The applicant would like to request the following documents submitted with this application for certification be withheld from public disclosure as per Section 0.457 & 0.459 of FCC Rules. 1. Technical/Operational Description/Tuning Procedure 2. Block Diagram 8H087A500 3. Schematics 8D087B03 4. Parts List 7L087X05 5. Tuning Info The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. Regards Tony Bombera (Signature) (Print Name) Title: Senior Staff Engineer On behalf of : Futurecom Systems Group ULC. Phone No.: 905 660 5548 Fax No.: 905 660 6858 Email : [email protected] 3277 LANGSTAFF ROAD, Concord, Ontario L4K 5P8, Canada, Tel: (905)660-5548 Fax: (905)660-1380

July 8, 2015 Ultratech Engineering Labs, Inc. 3000 Bristol Circle Oakville, Ontario L6H 6G4 Subject: Equipment Certification under FCC 47 CFR, Parts 2 and 90 Applicant: Futurecom Systems Group, ULC Product: Vehicle Radio Extender Model: VRX1000 UHF FCC ID: LO6-VRX1000UHF Dear Sir/Madam: As appointed agent for Futurecom Systems Group, ULC, we submit the application for FCC certification of the above product. Kindly review all required documents uploaded to your E- Filing Site. If you have any queries, please do not hesitate to contact us. Yours truly, Dan Huynh Dan Huynh Authorized Agent UltraTech Group of Labs FCC TCB & IC CB Ultratech’s Accreditations: 0685 91038 1309 46390-2049 NVLAP LAB CODE 200093-0 SL2-IN-E-1119R Korea KCC-RRA CA2049 TL363_B TPTDP DA1300 3000 Bristol Circle, Oakville, Ontario, Canada L6H 6G4 Tel.: (905) 829-1570 Fax.: (905) 829-8050 Website: www.ultratech-labs.com Email: [email protected]

FCC Parts 2 and 90 Page 139 of 148 Vehicle Radio Extender, Model: VRX1000 UHF FCC ID: LO6-VRX1000UHF ULTRATECH GROUP OF LABS File #: 15FSG142_FCC90 3000 Bristol Circle, Oakville, Ontario, Canada L6H 6G4 July 8, 2015 Tel. #: 905-829-1570, Fax. #: 905-829-8050, Email: [email protected] , Website: http://www.ultratech-labs.com All test results contained in this engineering test report are traceable to National Institute of Standards and Technology (NIST) 5.9. EXPOSURE OF HUMANS TO RF FIELD [[§§ 1.1310 & 2.1091] § 1.1310: The criteria listed in the following table shall be used to evaluate the environmental impact of human exposure to radio-frequency (RF) radiation as specified in 1.1307(b). Limits for Maximum Permissible Exposure (MPE) Frequency range (MHz) Electric field strength (V/m) Magnetic field strength (A/m) Power density (mW/cm 2 ) Averaging time (minutes) (A) Limits for Occupational/Controlled Exposures 0.3-3.0 6141.63*(100) 6 3.0-30 1842/f4.89/f*(900/f 2 ) 6 30-300 61.40.1631.0 6 300-1500 f/300 6 1500-100,000 5 6 (B) Limits for General Population/Uncontrolled Exposure 0.3-1.34 6141.63*(100) 30 1.34-30 824/f2.19/f*(180/f 2 ) 30 30-300 27.50.0730.2 30 300-1500 f/1500 30 1500-100,000 1.0 30 f = frequency in MHz * = Plane-wave equivalent power density Note 1: Occupational/controlled limits apply in situations in which persons are exposed as a consequence of their employment provided those persons are fully aware of the potential for exposure and can exercise control over their exposure. Limits for occupational/controlled exposure also apply in situations when an individual is transient through a location where occupational/controlled limits apply provided he or she is made aware of the potential for exposure. Note 2: General population/uncontrolled exposures apply in situations in which the general public may be exposed, or in which persons that are exposed as a consequence of their employment may not be fully aware of the potential for exposure or can not exercise control over their exposure. FCC Parts 2 and 90 Page 140 of 148 Vehicle Radio Extender, Model: VRX1000 UHF FCC ID: LO6-VRX1000UHF ULTRATECH GROUP OF LABS File #: 15FSG142_FCC90 3000 Bristol Circle, Oakville, Ontario, Canada L6H 6G4 July 8, 2015 Tel. #: 905-829-1570, Fax. #: 905-829-8050, Email: [email protected] , Website: http://www.ultratech-labs.com All test results contained in this engineering test report are traceable to National Institute of Standards and Technology (NIST) 5.9.1. Method of Measurements Calculation Method of RF Safety Distance : 22 44r EIRP r PG S      Where, P: power input to the antenna in mW EIRP: Equivalent (effective) isotropic radiated power. S: power density mW/cm 2 G: numeric gain of antenna relative to isotropic radiator r: distance to centre of radiation in cm S EIRP S PG r     44 5.9.2. Evaluation of RF Exposure Compliance Requirements Maximum RF Power conducted, P conducted [dBm]: 34.90 Maximum Antenna Gain, G[dBi]: 2.15 Maximum EIRP, P EIRP [dBm]: 37.05 MPE Limit for Occupational/Controlled Exposure, S controlled [mW/cm 2 ]: = 380/300 = 1.267 MPE Limit for General Population/Uncontrolled Exposure, S uncontrolled [mW/cm 2 ] = 380/1500 = 0.253 Calculated RF Safety Distance for Occupational/Controlled Exposure, r safety_controlled [cm]: 17.8 Calculated RF Safety Distance for General Population/Uncontrolled Exposure, r safety_uncontrolled [cm] 39.9
