LO6-VRX1000VHFVRX1000

Futurecom Systems Group ULC.
VRX1000 - FCC ID LO6-VRX1000VHF - Futurecom Systems Group ULC.
Click to zoom

Application Details

Equipment Class
TNB - Licensed Non-Broadcast Station Transmitter
Date of Grant
Jul 16, 2015
Application Purpose
Original Equipment
Date of Application
Jul 16, 2015
Equipment Note
VRX1000
Frequency Range
136.00000000 - 174.00000000
Company
Futurecom Systems Group ULC.
Country
Canada

Documents & Files

Select a file to view

Users Manual

↗

Attestation Statements

↗
↗
↗

Cover Letter(s)

↗
↗
↗

External Photos

↗

ID Label/Location Info

↗

Internal Photos

↗

RF Exposure Info

↗

Test Report

↗

Test Setup Photos

↗

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

VRX1000 VEHICLE RADIO EXTENDER User’s Guide 8A087X02 Draft 0.2 JUNE 2015 8A087X02 DRAFT 0.2 VRX1000 User’s Guide June 2015 Page 2 of 20 NOTES 8A087X02 DRAFT 0.2 VRX1000 User’s Guide June 2015 Page 3 of 20 Contents Contents........................................................................................................................... 3 Manual Revisions.......................................................................................................... 4 Computer Software Copyrights ..................................................................................... 5 Document Copyrights.................................................................................................... 5 Disclaimer .....................................................................................................................5 Trademarks ................................................................................................................... 5 Commercial Warranty and Service................................................................................ 6 Notations Used in This Manual...................................................................................... 7 RF Energy Exposure Compliance, Awareness and Control Information and Operational Instructions................................................................................................. 9 RF Exposure Label ..................................................................................................... 10 FCC Label ................................................................................................................... 10 Installation Requirements for Compliance with Radio Frequency (RF) Energy Exposure Safety Standards ......................................................................................... 11 Introduction ...................................................................................................................12 Identifying Your VRX1000 Model ................................................................................ 13 Frequency Band of Operation............................................................................................... 13 Cross-Band ........................................................................................................................... 13 VRX1000 Operation Basics .................................................................................................. 14 Powering up the VRX1000.......................................................................................... 15 Turning ON the VRX1000 ........................................................................................... 15 Activating the VRX1000 via the Control Head ...................................................................... 15 Turning OFF the VRX1000 ......................................................................................... 16 Deactivating the VRX1000 via the MSU Control Head......................................................... 16 Selecting VRX1000 Channel....................................................................................... 17 Independent VRX1000 Channel Change ............................................................................. 17 Strapped VRX1000 Channel Change................................................................................... 17 Local Mode Indication ................................................................................................. 17 Appendix 1 – VRX1000 Specifications - Preliminary ................................................. 18 Contact Information ...................................................................................................... 20 8A087X02 DRAFT 0.2 VRX1000 User’s Guide June 2015 Page 4 of 20 Manual Revisions Rev # Date ECN Notes & References DRAFT 0.1 Oct 28, 2014 na DRAFT 0.1 DRAFT 0.11 Apr 30, 2015 na DRAFT 0.11 DRAFT 0.2 June 25, 2015 na DRAFT 0.2 8A087X02 DRAFT 0.2 VRX1000 User’s Guide June 2015 Page 5 of 20 Computer Software Copyrights The products described in this manual include copyrighted Futurecom computer programs stored in semiconductor memories or other media. Laws in the United States, Canada and other countries preserve for Futurecom certain exclusive rights for copyrighted computer programs, including but not limited to, the exclusive right to copy or reproduce in any form the copyrighted computer programs. Any copyrighted computer program contained in the Futurecom products described in this manual may not be copied, reproduced, modified, reverse-engineered, or distributed in any manner without the express written permission of Futurecom. The purchase of Futurecom products shall not be deemed to grant either directly or by implication, estoppels, or otherwise, any license under the copyrights, patents or patent applications of Futurecom, except for the normal non-exclusive license to use that arises by operation of law in the sale of a product. Document Copyrights No part of this manual may be reproduced, distributed or transmitted in any form or by any means, for any purpose without written permission of Futurecom. Disclaimer The information in this document is carefully examined and is believed to be entirely reliable. However, no responsibility is assumed for inaccuracies. Futurecom Systems Group, ULC. reserves the right to make changes to any products herein to improve reliability, function or design. Futurecom does not assume any liability arising out of the application or use of any product or circuit described herein. Trademarks MOTOROLA, ASTRO, XTL TM 2500, XTL TM 5000, XTS TM 1500, XTS TM 2500, XTS TM 5000, APX TM 4000, APX TM 4500, APX TM 6000, APX TM 7000, APX TM 6500, APX TM 7500, MDC1200 are trademarks of Motorola Solutions Inc. 8A087X02 DRAFT 0.2 VRX1000 User’s Guide June 2015 Page 6 of 20 Commercial Warranty and Service Futurecom Systems Group, ULC. warrants to the original purchaser all standar…

Text truncated - open the document above for the full version.

Attestation Statements

July 9, 2015 FEDERAL COMMUNICATIONS COMMISSIONS Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Subject: VRX1000 VHF Extended Frequencies Justification Letter Applicant: Futurecom Systems Group, ULC FCC ID: LO6-VRX1000VHF To whom it may concern: The VRX1000 VHF is able to operate in the frequency band 136 – 174MHz. To aid equipment authorization in other countries which accept the United States FCC Grant for Certification, Futurecom Systems Group, ULC., is requesting that the FCC lists the frequencies 136-174MHz on the FCC Grant. For the FCC’s Rule Parts 90 applications, this radio is used in systems by Federal and Public Safety agencies including Police, Fire, and Emergency Medical Services, etc. Equipment programming is the responsibility of Authorized Service Personnel. Also, the radio complies with 47 CFR Part 90.203(e), in that the operator cannot directly program the transmit frequencies using the normally accessible external controls. Per the FCC’s KDB 634817 guidance, as an alternative to listing the exact frequencies, we, Futurecom Systems Group, ULC., acknowledge that it is a violation of the FCC Rules if this device operates on unauthorized frequencies. Regards, Tony Bombera (Signature) (Print Name) Title: Senior Staff Engineer On behalf of : Futurecom Systems Group, ULC. Phone No.: 905 660 5548 Fax No.: 905 660 6858 Email : [email protected] 3277 LANGSTAFF ROAD, Concord, Ontario L4K 5P8, Canada, Tel: (905)660-5548 Fax: (905)660-1380

Attestation Statements

Federal Communications Commission Authorization and Evaluation Division 1435 Oakland Mills Road Columbia, MD 21046 Date: April 30, 2015 SUBJECT: FCC Application for LO6-VRX1000VHF To Whom It May Concern: We, the undersigned, hereby attest to the fact that we will apply the FCC Verification authorization procedure to the Part 15B - Unintentional Radiator portion of this composite filing. Regards, Tony Bombera (Signature) (Print Name) Title: Senior Staff Engineer On behalf of : Futurecom Systems Group ULC. Phone No.: 905 660 5548 Fax No.: 905 660 6858 Email : [email protected] 3277 LANGSTAFF ROAD, Concord, Ontario L4K 5P8, Canada, Tel: (905)660-5548 Fax: (905)660-1380

Attestation Statements

FEDERAL COMMUNICATIONS COMMISSION 7435 Oakland Mills Road Columbia, MD 21046 USA Date: April 30, 2015 Subject: Part 90.203(e) Compliance Attestation Applicant: Futurecom Systems Group, ULC Model: VRX1000 VHF FCC ID: LO6-VRX1000VHF Dear Sir or Madam: This equipment meets the requirements of the FCC Rules, Parts 90.203(e). The operator cannot program and transmit on frequencies other than those programmed by the manufacturer, service or maintenance personnel, using the equipment’s external operational controls. Regards, Tony Bombera (Signature) (Print Name) Title: Senior Staff Engineer On behalf of : Futurecom Systems Group ULC. Phone No.: 905 660 5548 Fax No.: 905 660 6858 Email : [email protected] 3277 LANGSTAFF ROAD, Concord, Ontario L4K 5P8, Canada, Tel: (905)660-5548 Fax: (905)660-1380

Cover Letter(s)

Date: April 30, 2015 To Whom It May Concern Subject: Authority to Act as an Agent Applicant: Futurecom Systems Group, ULC FCC ID: LO6-VRX1000VHF Dear Sir/Madam, I hereby appoint UltraTech Engineering Labs Inc. (UltraTech) to act as my agent in preparation of this application for authorization of above equipment under F.C.C. Rules. The applicant hereby certify that neither the applicant nor any party to the application is subject to a denial of Federal benefits, that include FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. §862 because of a conviction for possession or distribution of a controlled substance. See 47 CFR 1.2002(b) for the definition of a “party” for these purposes. I also certify that the information provided, properly describe the device or system for which authorization is required. Regards, Tony Bombera (Signature) (Print Name) Title: Senior Staff Engineer On behalf of : Futurecom Systems Group ULC. Phone No.: 905 660 5548 Fax No.: 905 660 6858 Email : [email protected] 3277 LANGSTAFF ROAD, Concord, Ontario L4K 5P8, Canada, Tel: (905)660-5548 Fax: (905)660-1380

Cover Letter(s)

Date: April 30, 2015 To Whom It May Concern Subject: Confidentiality Letter Applicant: Futurecom Systems Group, ULC FCC ID: LO6-VRX1000VHF Dear Sir/Madam: The applicant would like to request the following documents submitted with this application for certification be withheld from public disclosure as per Section 0.457 & 0.459 of FCC Rules. 1. Technical/Operational Description/Tuning Procedure 2. Block Diagram 8H087A501 3. Schematics 8D087B02 4. Parts List 7L087X03 5. Tuning Info The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. Regards Tony Bombera (Signature) (Print Name) Title: Senior Staff Engineer On behalf of : Futurecom Systems Group ULC. Phone No.: 905 660 5548 Fax No.: 905 660 6858 Email : [email protected] 3277 LANGSTAFF ROAD, Concord, Ontario L4K 5P8, Canada, Tel: (905)660-5548 Fax: (905)660-1380

Cover Letter(s)

July 13, 2015 Ultratech Engineering Labs, Inc. 3000 Bristol Circle Oakville, Ontario L6H 6G4 Subject: Equipment Certification under FCC 47 CFR, Parts 2 and 90 Applicant: Futurecom Systems Group, ULC Product: Vehicle Radio Extender Model: VRX1000 VHF FCC ID: LO6-VRX1000VHF Dear Sir/Madam: As appointed agent for Futurecom Systems Group, ULC, we submit the application for FCC certification of the above product. Kindly review all required documents uploaded to your E- Filing Site. If you have any queries, please do not hesitate to contact us. Yours truly, Dan Huynh Dan Huynh Authorized Agent UltraTech Group of Labs FCC TCB & IC CB Ultratech’s Accreditations: 0685 91038 1309 46390-2049 NVLAP LAB CODE 200093-0 SL2-IN-E-1119R Korea KCC-RRA CA2049 TL363_B TPTDP DA1300 3000 Bristol Circle, Oakville, Ontario, Canada L6H 6G4 Tel.: (905) 829-1570 Fax.: (905) 829-8050 Website: www.ultratech-labs.com Email: [email protected]

RF Exposure Info

FCC Parts 2 and 90 Page 82 of 91 Vehicle Radio Extender, Model: VRX1000 VHF FCC ID: LO6-VRX1000VHF ULTRATECH GROUP OF LABS File #: 15FSG140_FCC90 3000 Bristol Circle, Oakville, Ontario, Canada L6H 6G4 July 13, 2015 Tel. #: 905-829-1570, Fax. #: 905-829-8050, Email: [email protected] , Website: http://www.ultratech-labs.com All test results contained in this engineering test report are traceable to National Institute of Standards and Technology (NIST) 5.9. EXPOSURE OF HUMANS TO RF FIELD [[§§ 1.1310 & 2.1091] § 1.1310: The criteria listed in the following table shall be used to evaluate the environmental impact of human exposure to radio-frequency (RF) radiation as specified in 1.1307(b). Limits for Maximum Permissible Exposure (MPE) Frequency range (MHz) Electric field strength (V/m) Magnetic field strength (A/m) Power density (mW/cm 2 ) Averaging time (minutes) (A) Limits for Occupational/Controlled Exposures 0.3-3.0 6141.63*(100) 6 3.0-30 1842/f4.89/f*(900/f 2 ) 6 30-300 61.40.1631.0 6 300-1500 f/300 6 1500-100,000 5 6 (B) Limits for General Population/Uncontrolled Exposure 0.3-1.34 6141.63*(100) 30 1.34-30 824/f2.19/f*(180/f 2 ) 30 30-300 27.50.0730.2 30 300-1500 f/1500 30 1500-100,000 1.0 30 f = frequency in MHz * = Plane-wave equivalent power density Note 1: Occupational/controlled limits apply in situations in which persons are exposed as a consequence of their employment provided those persons are fully aware of the potential for exposure and can exercise control over their exposure. Limits for occupational/controlled exposure also apply in situations when an individual is transient through a location where occupational/controlled limits apply provided he or she is made aware of the potential for exposure. Note 2: General population/uncontrolled exposures apply in situations in which the general public may be exposed, or in which persons that are exposed as a consequence of their employment may not be fully aware of the potential for exposure or can not exercise control over their exposure. FCC Parts 2 and 90 Page 83 of 91 Vehicle Radio Extender, Model: VRX1000 VHF FCC ID: LO6-VRX1000VHF ULTRATECH GROUP OF LABS File #: 15FSG140_FCC90 3000 Bristol Circle, Oakville, Ontario, Canada L6H 6G4 July 13, 2015 Tel. #: 905-829-1570, Fax. #: 905-829-8050, Email: [email protected] , Website: http://www.ultratech-labs.com All test results contained in this engineering test report are traceable to National Institute of Standards and Technology (NIST) 5.9.1. Method of Measurements Calculation Method of RF Safety Distance : 22 44r EIRP r PG S      Where, P: power input to the antenna in mW EIRP: Equivalent (effective) isotropic radiated power. S: power density mW/cm 2 G: numeric gain of antenna relative to isotropic radiator r: distance to centre of radiation in cm S EIRP S PG r     44 5.9.2. Evaluation of RF Exposure Compliance Requirements Maximum RF Power conducted, P conducted [dBm]: 34.88 Maximum Antenna Gain, G[dBi]: 2.15 Maximum EIRP, P EIRP [dBm]: 37.03 MPE Limit for Occupational/Controlled Exposure, S controlled [mW/cm 2 ]: = 136/300 = 0.453 MPE Limit for General Population/Uncontrolled Exposure, S uncontrolled [mW/cm 2 ] = 136/1500 = 0.091 Calculated RF Safety Distance for Occupational/Controlled Exposure, r safety_controlled [cm]: 29.8 Calculated RF Safety Distance for General Population/Uncontrolled Exposure, r safety_uncontrolled [cm] 66.4

Test Report

Vehicle Radio Extender Model: VRX1000 VHF FCC ID: LO6-VRX1000VHF Applicant: Futurecom Systems Group, ULC 3277 Langstaff Road Concord, ON Canada L4K 5P8 Tested in Accordance With Federal Communications Commission (FCC) 47 CFR, Parts 2 and 90 UltraTech's File No.: 15FSG140_FCC90 This Test report is Issued under the Authority of Tri M. Luu Vice President of Engineering UltraTech Group of Labs Date: July 13, 2015 Report Prepared by: Dan Huynh Issued Date: July 13, 2015 Tested by: Hung Trinh Test Dates: May 29 - June 24, 2015  The results in this Test Report apply only to the sample(s) tested, and the sample tested is randomly selected.  This report must not be used by the client to claim product endorsement by NVLAP or any agency of the US Government. UltraTech 3000 Bristol Circle, Oakville, Ontario, Canada, L6H 6G4 Tel.: (905) 829-1570 Fax.: (905) 829-8050 Website: www.ultratech-labs.com , Email: [email protected], Email: [email protected] Korea KCC-RRA 91038 1309 46390-2049 NVLAP LAB CODE 200093-0 SL2-IN-E- 1119R CA2049 TL363_B TPTDP DA1300 FCC Parts 2 and 90 Contents i Vehicle Radio Extender, Model: VRX1000 VHF FCC ID: LO6-VRX1000VHF ULTRATECH GROUP OF LABS File #: 15FSG140_FCC90 3000 Bristol Circle, Oakville, Ontario, Canada L6H 6G4 July 13, 2015 Tel. #: 905-829-1570, Fax. #: 905-829-8050, Email: [email protected] , Website: http://www.ultratech-labs.com All test results contained in this engineering test report are traceable to National Institute of Standards and Technology (NIST) TABLE OF CONTENTS EXHIBIT 1. INTRODUCTION.............................................................................................................................................. 1 1.1. SCOPE ........................................................................................................................................................................ 1 1.2. RELATED SUBMITTAL(S)/GRANT(S) ........................................................................................................................ 1 1.3. NORMATIVE REFERENCES ...................................................................................................................................... 1 EXHIBIT 2. PERFORMANCE ASSESSMENT ................................................................................................................... 2 2.1. CLIENT INFORMATION .............................................................................................................................................. 2 2.2. EQUIPMENT UNDER TEST (EUT) INFORMATION ................................................................................................... 2 2.3. EUT’S TECHNICAL SPECIFICATIONS....................................................................................................................... 3 2.4. LIST OF EUT’S PORTS............................................................................................................................................... 4 EXHIBIT 3. EUT OPERATING CONDITIONS AND CONFIGURATIONS DURING TESTS .............................................. 5 3.1. CLIMATE TEST CONDITIONS .................................................................................................................................... 5 3.2. OPERATIONAL TEST CONDITIONS & ARRANGEMENT FOR TEST SIGNALS....................................................... 5 EXHIBIT 4. SUMMARY OF TEST RESULTS ..................................................................................................................... 6 4.1. LOCATION OF TESTS ................................................................................................................................................ 6 4.2. APPLICABILITY & SUMMARY OF EMC EMISSION TEST RESULTS .......................................................................6 4.3. MODIFICATIONS INCORPORATED IN THE EUT FOR COMPLIANCE PURPOSES ................................................ 6 4.4. DEVIATION OF STANDARD TEST PROCEDURES................................................................................................... 6 EXHIBIT 5. TEST DATA ..................................................................................................................................................... 7 5.1. RF POWER OUTPUT [§§ 2.1046 & 90.205] ................................................................................................................ 7 5.2. MODULATION CHARACTERISTICS - AUDIO FREQUENCY RESPONSE [§ 2.1047(a)] .......................................... 9 5.3. MODULATION CHARACTERISTICS - MODULATION LIMITING [§ 2.1047 (b)]....................................................... 16 5.4. OCCUPIED BANDWIDTH & EMISSION MASK [§§ 2.1049, 90.209 & 90.210]......................................................... 24 5.5. SPURIOUS EMISSIONS AT ANTENNA TERMINALS [§§ 2.1051, 2.1057, 90.210].................................................. 57 5.6. TRANSMITTER SPURIOUS/HARMONIC RADIATED EMISSIONS [§§ 2.1053, 2.1057 & 90.210].......................... 70 5.7. FREQUECNY STABILITY [§§ 2.1055 & 90.213] ....................................................................................................... 72 5.8. TRANSIENT FREQUENCY BEHAVIOR [§ 90.214] ................................................................................................... 74 5.9. EXPOSURE OF HUMANS TO RF FIELD [[§§ 1.1310 & 2.1091]............................................................................... 82 EXHIBIT 6. TEST EQUIPMENT LIST ............................................................................................................................... 84 EXHIBIT 7. MEASUREMENT UNCERTAINTY ................................................................................................................ 85 7.1. RADIATED EMISSION MEASUREMENT UNCERTAINTY ....................................................................................... 85 EXHIBIT 8. MEASUREMENT METHODS ........…

Text truncated - open the document above for the full version.

Test Setup Photos

ANNEX 1 - TEST SETUP PHOTOS Futurecom Systems Group, ULC Vehicle Radio Extender, Model: VRX1000 VHF FCC ID: LO6-VRX1000VHF A1 - 1 Radiated Emissions at 3 m, 30 - 1000 MHz ANNEX 1 - TEST SETUP PHOTOS Futurecom Systems Group, ULC Vehicle Radio Extender, Model: VRX1000 VHF FCC ID: LO6-VRX1000VHF A1 - 2 Radiated Emissions at 3 m, Above 1 GHz ANNEX 1 - TEST SETUP PHOTOS Futurecom Systems Group, ULC Vehicle Radio Extender, Model: VRX1000 VHF FCC ID: LO6-VRX1000VHF A1 - 3 Radiated Emissions at 3 m

Contact Information

Applicant

Tony Bombera(Sr Staff Engineer)
[email protected]905-532-1114Fax: 905-660-1380

Test Firm

UltraTech Engineering Labs Inc.Tri Luu
[email protected]905-829-1570Fax: 905-829-8050

Technical Specifications

#Rule PartsFrequency RangePower OutputEmissionTolerance
890,90.203(j)(5)136 MHz - 174 MHz3 W4K00F1D1 ppm
Confidentiality
Long Term
Grant Notes
Power output listed is at the antenna connector. The antenna used for this transmitter shall not exceed 2.15 dBi in gain, and shall be installed to provide at least 67 cm away from people for General Population/Uncontrolled Exposure environment or at least 30 cm away from people for Occupational/Controlled RF exposure environment. Users and installers must be provided with antenna installation instructions and transmitter operating conditions to satisfy RF exposure requirements in the applicable RF exposure compliance standards.
