LQN2961Volvo MMS Sensor

Connaught Electronics Ltd

Click to zoom

Application Details

Equipment Class: DXX - Part 15 Low Power Communication Device Transmitter
Date of Grant: Jul 05, 2007
Application Purpose: Original Equipment
Date of Application: Jul 04, 2007
Equipment Note: Volvo MMS Sensor
Frequency Range: 5725.00000000 - 5850.00000000
Company: Connaught Electronics Ltd
Country: Ireland

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

ITC Engineering Services Over 20 years experience in Compliance Testing and Engineering Consulting Services ———————————————————————————————————————————————————————— ————————————————ISO 17025, NVLAP and VCCI Accredited Laboratory———————————————— 9959 Calaveras Road, Box 543, Sunol, CA 94586-0543 Phone: (925) 862-2944 • (888) 336-7625 • Fax: (925) 862-9013 E-mail: [email protected] • Web: www.itcemc.com Date: Thursday, June 28, 2007. Timco Engineering Inc. 849 NW State Road 45 Newberry, Florida 32669 File Number: FCC ID: LNQ2910 (CEL Part Nos: 902960 and 902962) FCC ID: LQN2911 (CEL Part No: 902961) Subject: User Manual Statement. To Whom It May Concern, The warning statement submitted with this application is the only document that serves as a manual. Please note that the products with the above FCC ID is custom built for use by the intended manufacturer only. Hence all information regarding design and installation were mutually agreed upon between customer and manufacturer. Should you have any questions or comments regarding the above, please feel free to let me know immediately. Yours sincerely, Femi Ojo Compliance Engineer. ITC Engineering Services.

Users Manual

DIRECTORS: DR. JOE MCBREEN, FRANK CLANCY COMPANY REGISTRATION NO. 92489 User Manual Product Reference: Volvo MMS Sensor. CEL Part No: - 902960 (FCC ID: LQN2960) 902961 (FCC ID: LQN2961) 902962 (FCC ID: LQN2960) FCC WARNING STATEMENT Note: This equipment has been tested and found to comply with the limits for Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential/office installation. The equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna • Increase the separation between the equipment and receiver • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected • Consult the dealer or an experienced Radio/TV technician for help CAUTION: Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Connaught Electronics Ltd. IDA INDUSTRIAL ESTATE, DUNMORE ROAD, TUAM, CO. GALWAY, IRELAND. Telephone: +353 93 25128 Fax: +353 93 25133 [email protected] www.cel-europe.com

Block Diagram

Frame 1 of 1 SENSOR BLOCK DIAGRAM: TARGET +12 Gnd ST INRS Voltage Regulator Micro – Controller PRF Oscillator/ U8 4MHz RF Oscillator 5.8GHz Transmit Antenna Receive Antenna Target Envelope Detector Range Gate Generator Range Adjust IF FILTER IF AMPS Connaught Electronics Ltd. IDA INDUSTRIAL ESTATE, DUNMORE ROAD, TUAM, CO. GALWAY, IRELAND. Telephone: +353 93 25128 Fax: +353 93 25133 A/C Fax: +353 93 24047 [email protected] www.cel-europe.com FCC ID: -LQN2960 FCC ID: -LQN2961

Cover Letter(s)

ITC Engineering Services Over 20 years experience in Compliance Testing and Engineering Consulting Services ———————————————————————————————————————————————————————— ————————————————ISO 17025, NVLAP and VCCI Accredited Laboratory———————————————— 9959 Calaveras Road, Box 543, Sunol, CA 94586-0543 Phone: (925) 862-2944 • (888) 336-7625 • Fax: (925) 862-9013 E-mail: [email protected] • Web: www.itcemc.com Date: Thursday June 28, 2007 Timco Engineering Inc. 849 NW State Road 45 Newberry, Florida 32669 File Number: FCC ID: LQN2960 FCC ID: LQN2961 Subject: Request for Confidentiality To Whom It May Concern, Pursuant to 47CFR 0.575(d) of the commissions rules and section 552(b)(4) of the Freedom of Information Act (which authorizes the withholding from public inspection; materials which would be privileged as a matter of law, such as trade secrets), we are hereby requesting that the following documents are to be handled with confidentiality and removed from display on the FCC Status Query Form Display of Exhibits: • Schematics (all pages) If there are any questions or if further information is needed, please call me at (925) 862-2944. Thank you. Yours sincerely, Femi Ojo Compliance Engineer ITC Engineering Services Inc.

Cover Letter(s)

ITC Engineering Services Over 20 years experience in Compliance Testing and Engineering Consulting Services —————————————————————————————————————————————————————— ————————————————ISO 17025, NVLAP and VCCI Accredited Laboratory———————————————— 9959 Calaveras Road, Box 543, Sunol, CA 94586-0543 Phone: (925) 862-2944 • (888) 336-7625 • Fax: (925) 862-9013 E-mail: [email protected] • Web: www.itcemc.com Date: Thursday June 28, 2007 Timco Engineering Inc. 849 NW State Road 45, Newberry, Florida 32669. SUBJECT: FCC Part 15 Submittal for Equipment Authorization. To Whom It May Concern. The uploaded documents constitute a formal submittal and application for Grant of Equipment Authorization. The data in this report demonstrates that the equipment tested complies with FCC Part 15 Subpart C, section 209, test limit for devices operating under the provisions of this part. This application was prepared by ITC Engineering Services Inc.If there are any questions or further information is needed, please call us at (925) 862-2944 or fax (925) 862-9013. Yours sincerely, Femi Ojo Compliance Engineer. ITC Engineering Services.

External Photos

FCC Test External and Internal Photographs for 47CFR15, Subpart B for Unintentional Radiators, per Section 101 Equipment authorization of unintentional radiators, and 47CFR15, Subpart C per Section 209 General Limits for Operation of Intentional Radiators On Volvo MMS Sensor [MMS Sensor Front: FCC ID: LQN2960, Model No: 902960] [MMS Sensor Rear: FCC ID: LQN2961, Model No: 902961] [MMS Sensor Front Warranty: FCC ID: LQN2960, Model No: 902962] Part No(s): MMS Sensor Front Volvo Part No: 30797734 MMS Sensor Rear Volvo Part No: 30797735 MMS Sensor Front Warranty Volvo Part No: 30797800 Report No. 20070402-02-Fc15 Judgement Complies as Tested Provided for evaluation by Connaught Electronics, LTD IDA Industrial Estate Dunmore Road, Tuam Co. Galway, Ireland Tests and Report by ITC Engineering Services, Inc. 9959 Calaveras Road, Box 543 Sunol, California 94586-0543 Tel: (925) 862-2944 Fax: (925) 862-9013 Email: [email protected] Web Site: www.itcemc.com  ISO 17025 Accredited Compliance Laboratory Lab Code: 200172-0 Applicant: Connaught Electronics Ltd. Report No.: 20070402-02-FC15 Prepared By: ITC Engineering Services, Inc. 9959 Calaveras Road, PO Box 543 Sunol, California 94586-0543 Tel: [925] 862-2944 Fax: [925] 862-9013 Email: [email protected] Web: www.itcemc.com Product: Volvo MMS Sensor Model Number(s):902960, 902961 & 902962 FCC ID(s):LQN2960 & LQN2961 Page 2 of 8 Table of Contents PART 1 General........................................................................................................................................ 3 Test Information............................................................................................................................................. 3 Tests Performed: ............................................................................................................................................ 3 Declaration/Disclaimer .................................................................................................................................. 4 Test Methodology .......................................................................................................................................... 5 Test Facility ................................................................................................................................................... 5 PART 2 EXTENAL AND INTERNAL PHOTOGRAPHS.................................................................... 6 EUT Photographs........................................................................................................................................... 6 List of Tables Table 1 Radio Device Measurement Information...................................................................................... 5 Table 2 Measurement Uncertainty.............................................................................................................. 5 List of Figures Figure 1: EUT Front Unit (CEL Number 902960).................................................................................... 6 Figure 2: EUT Rear Unit (CEL Number 902961)..................................................................................... 6 Figure 3: EUT Front Warranty Unit (CEL Number 902962).................................................................... 7 Figure 4: EUTs Front View (902960 902961 & 902962).......................................................................... 7 Figure 5: EUT Internal View 1...................................................................................................................... 8 Figure 6: EUT Internal View 2..................................................................................................................... 8 Applicant: Connaught Electronics Ltd. Report No.: 20070402-02-FC15 Prepared By: ITC Engineering Services, Inc. 9959 Calaveras Road, PO Box 543 Sunol, California 94586-0543 Tel: [925] 862-2944 Fax: [925] 862-9013 Email: [email protected] Web: www.itcemc.com Product: Volvo MMS Sensor Model Number(s):902960, 902961 & 902962 FCC ID(s):LQN2960 & LQN2961 Page 3 of 8 PART 1 General Test Information Product: Model Number(s): Volvo MMS Sensor 902960, 902961 & 902962 Manufacturer’s Name Manufacturer’s Address Contact Connaught Electronics, LTD IDA Industrial Estate Dunmore Road, Tuam Co. Galway, Ireland Tel: + 011 353 (93) 25128 Mr. Patrick Denny Fax : +011 353 (93) 25133 Email [email protected] Test Laboratory ITC Engineering Services, Inc. 9959 Calaveras Road, PO Box 543 Sunol, CA 94586-0543 Email: [email protected] Web Site: http://www.itcemc.com Tel: +1(925) 862-2944 Fax: +1(925) 862-9013 Test Number Report Number 20070402-02 20070402-02-Fc15 Test Date(s) & Issue Date April 9 – April 13, 2007 June 4, 2007 Test Engineer(s) Femi Ojo Documentation Femi Ojo Test Results ; Complies as Tested Fail Total Number of Pages 8 The electromagnetic interference and RF tests, which this report describes, were performed by an independent engineering consultancy firm, ITC Engineering Services, Inc. (ITC), in accordance with the requirements specified in the FCC rules, 47CFR Part 15, Subparts B and C. It is the manufacturer's responsibility to assure that additional production units of this model are manufactured with identical electrical and mechanical characteristics. Any modifications specified in this report for compliance must be implemented in all production units for compliance to be maintained. Tests Performed: Emissions Requirements: • OPEN FIELD RADIATED EMISSIONS in accordance with the FCC PART 15 Sub-Part B. RF Requirements: • FIELD STRENGTH OF FUNDAMENTAL in accordance with the FCC 47 CFR 15.209. • HARMONIC EMISSIONS in accordance with the FCC 47 CFR 15.209. • SPURIOUS EMISSIONS in accordance with the FCC 47 CFR 15.209. Report generated by Report reviewed by Femi Ojo, Michael Gbadebo, P.E, Chief Engineer. Compliance Engineer (California License # 11303) Applicant: Connaught Electronics Ltd. Report No.: 20070402-02-FC15 Prepared …

Text truncated - open the document above for the full version.

Internal Photos

Text truncated - open the document above for the full version.

Operational Description

FCC ID: (LQN2960 & LQN2961) Frame 1 of 6 TECHNICAL FILE FOR VOLVO MMS SENSOR CEL P/N: 902960 902961 902962 Connaught Electronics Ltd. IDA INDUSTRIAL ESTATE, DUNMORE ROAD, TUAM, CO. GALWAY, IRELAND. Telephone: +353 93 25128 Fax: +353 93 25133 A/C Fax: +353 93 24047 [email protected] www.cel-europe.com FCC ID: (LQN2960 & LQN2961) Frame 2 of 6 1.0 Introduction This is a Technical File for VOLVO MMS sensor electronics supplied by CEL to VOLVO. 1.1 Theory of Operation The MDD microwave sensor works on the Doppler principle. The transmit antenna transmits an electromagnetic field into the vehicle. The receive antenna accepts reflections from moving targets and the resulting signals are filtered and amplified before being sent to the microcontroller for evaluation. The range is adjustable in software. Thus, the range can always be adjusted to fill the vehicle interior, in relation to the shortest distance between the MDD sensor and the windscreen or vehicle roof (the limits of the vehicle passenger compartment). In this way, a hemispherical field is generated within the vehicle as the area to be monitored. If a large enough change in analogue signal amplitude occurs, an analysis of the signal evaluation is started. The microcontroller contains a software algorithm that determines if the signal is a genuine movement or a spurious signal. If this analysis detects significant characteristics of a movement, an alarm is issued to the PJB via the BUS Interface. The VCC system uses a combination of sensors comprising a front and rear in order to provide greater cover within the vehicle. MICROWAVE BLOCK DIAGRAM: TARGET +12 Gnd ST INRS Voltage Regulator Micro – Controller PRF Oscillator RF Oscillator Transmi t Antenna Receive Antenna Target Envelope Detector Range Gate Generator Range Adjust IF FILTER IF AMPS FCC ID: (LQN2960 & LQN2961) Frame 3 of 6 1.2 Operating Modes and influencing factors In its non-sensitized condition, the microwave sensor module is set to Sleep-Mode. When sensitized, it is woken by an interrupt on the ST line. The sensitization period for the microwave sensor module, to full functionality, is 30 seconds. The complete alarm system is likewise ready for operation 30 seconds after sensitization of the DWA (anti-theft warning system). The microwave sensor module operates in impulse mode: that is, like a radar impulse system. An impulse is emitted for a brief period and the reflected signal received is amplified and evaluated. Because the module operates with a very low transmission output, more powerful external frequencies can connect with the receiver side of the device and cause false alarms. The reflected signal is checked in parallel with a suitable EMC protection switching unit and any foreign frequencies are filtered out. Any real movement in the detection area is recognized by a change in the reflection sample. The module emits a pulsed signal and delays this in accordance with the detection range required. This delayed impulse then controls the receiver section. Only after this delay time is the receiver section opened for a short period, when an associated signal pattern is stored. In reality, the detection range corresponds with a spherical "shell" having a width of ca. 5cm. The signal is stored in terms of amplitude and pattern and is compared with the next signal which is received. 1.3 Physical Construction Housing: LENGTH: 65mm, WIDTH: 60mm, HEIGHT: 25mm FCC ID: (LQN2960 & LQN2961) Frame 4 of 6 PCB: Two layer, Board material FR4 Layer 1: Components and signal tracks Layer 2: Ground plane Connector Detail: Front Connector Type : 5 Way JAE Part Number: IL-AG5-5PK-S3LG Rear Connector Type : 5 Way JAE Part Number: IL-AG5-5PK-S3LB Table 1 – Microwave Sensor ECU Connector Pin Detail Pin Name Function 1 Ubat Positive power supply 2 NC No connection 3 BUS BUS connection 4 NC No connection 5 GND Negative power supply 1.4 ESC Part Number(s) CEL Part No.: 902960, 902961 & 902962 1.5 ESC Manufacturers: CEL Dunmore Road, Tuam, Co. Galway, Ireland Tel: +353 93 25128 FCC ID: (LQN2960 & LQN2961) Frame 5 of 6 2.0 EMC Requirements Analysis 2.1 Potential Sources of Emissions Signal Source Description Voltage/Current Level Frequency % Duty Cycle (range) Other Resonator 3V 4MHz 50% FCC ID: (LQN2960 & LQN2961) Frame 6 of 6 3.0 Mode Descriptions Mode UBAT ST Input INRS (Output) Armed +12V 0V 12V (1 sec 0V on Alarm) Disarmed +12V 12V 12V Mode Armed: In this Mode the ST Input to the Microwave sensor is pulled to ground which ‘Arms’ the sensor i.e. if movement is detected then the INRS (alarm) output is activated (by pulling the INRS output to ground for 1 second). Mode Disarmed: In this Mode the ST Input to the Microwave sensor is pulled to UBat which ‘Disarms’ the sensor i.e. the sensor is turned OFF and so should not react to any movements.

Test Report

Report: RF Duty Cycle of CEL MMS Sensor Prepared For: ITC Prepared by: CEL Date: 03/05/07 Connaught Electronics Ltd. IDA INDUSTRIAL ESTATE, DUNMORE ROAD, TUAM, CO. GALWAY, IRELAND. Telephone: +353 93 25128 Fax: +353 93 25133 1 Scope This document details the RF duty cycle of CEL’s pulsed microwave sensor. 2 Duty Cycle Determination In order to determine the RF duty cycle, the PRF frequency and the oscillator on-time of the microwave sensor are measured and using these the duty cycle is calculated. 2.1 PRF Oscillator Period The pulsed microwave oscillator is turned on/off by the PRF (Pulse Repetition Frequency) oscillator. The pulse repetition frequency is 1.5MHz. (See fig.1 below). PRF = 1.46MHz Oscillator period = 682ns fig.1 2.2 RF pulse width determination: The range of the SDR is 85cm. Thus using the mathematical formula for RF waves the pulse width can be determined: Pulse width = (Range*2)/ (3x10 8 ) In the case of CEL’s SDR sensor: Pulse width = 1.7/ (3x10 8 ) = 5.66ns 2.3 Duty Cycle Calculation Duty Cycle (%) = RF Pulse Duration/PRF Oscillation Period = (5.66ns/682ns) * 100 = 0.83 %

Test Report

FCC Test Report for 47CFR15, Subpart B for Unintentional Radiators, per Section 101 Equipment authorization of unintentional radiators, and 47CFR15, Subpart C per Section 209 General Limits for Operation of Intentional Radiators On Volvo MMS Sensor [MMS Sensor Front: FCC ID: LQN2960, Model No: 902960] [MMS Sensor Rear: FCC ID: LQN2961, Model No: 902961] [MMS Sensor Front Warranty: FCC ID: LQN2960, Model No: 902962] Part No(s): MMS Sensor Front Volvo Part No: 30797734 MMS Sensor Rear Volvo Part No: 30797735 MMS Sensor Front Warranty Volvo Part No: 30797800 Report No. 20070402-02-Fc15 Judgement Complies as Tested Provided for evaluation by Connaught Electronics, LTD IDA Industrial Estate Dunmore Road, Tuam Co. Galway, Ireland Tests and Report by ITC Engineering Services, Inc. 9959 Calaveras Road, Box 543 Sunol, California 94586-0543 Tel: (925) 862-2944 Fax: (925) 862-9013 Email: [email protected] Web Site: www.itcemc.com  ISO 17025 Accredited Compliance Laboratory Lab Code: 200172-0 Applicant: Connaught Electronics Ltd. Report No.: 20070402-02-FC15 Prepared By: ITC Engineering Services, Inc. 9959 Calaveras Road, PO Box 543 Sunol, California 94586-0543 Tel: [925] 862-2944 Fax: [925] 862-9013 Email: [email protected] Web: www.itcemc.com Product: Volvo MMS Sensor Model Number(s):902960, 902961 & 902962 FCC ID(s):LQN2960 & LQN2961 Page 2 of 30 Table of Contents PART 1 General........................................................................................................................................ 5 Test Information............................................................................................................................................. 5 Tests Performed: ............................................................................................................................................ 5 Declaration/Disclaimer .................................................................................................................................. 6 Test Methodology .......................................................................................................................................... 7 Test Facility ................................................................................................................................................... 7 PART 2 RECEIVER MEASUREMENTS............................................................................................... 8 OPEN FIELD RADIATED EMISSIONS ..................................................................................................... 8 EUT Description / Test Specification: 47 CFR PART 15, Sub-Part B ........................................................ 8 Test Procedure – Radiated Emissions Tests .................................................................................................. 8 Site Used – Radiated Emissions Measurement............................................................................................ 10 Administrative & Environmental Details – Radiated Emissions Measurement .......................................... 10 Radiated Emissions Test Setup Photographs ............................................................................................... 11 Conclusion ............................................................................................................................... 12 PART 3 RF MEASUREMENTS............................................................................................................ 14 Test Specification: 47 CFR PART 15, Sub-Part C ..................................................................................... 14 EUT Description / Test Specification. ......................................................................................................... 14 General Test Procedure – RF Tests............................................................................................. 14 Spectrum Analyzer Configuration (during swept frequency scans) – Radiated Emissions ........................ 15 FIELD STRENGTH OF FUNDAMENTAL............................................................................................... 16 Field Strength Measurement ........................................................................................................................ 16 Site Used – Field Strength of Fundamental Measurements..................................................... 16 Administrative Details and Environmental Conditions – Field Strength of Fundamental Measurements.................................................................................................................................. 16 Test Data – Field Strength of Fundamental ................................................................................................. 16 Occupied Bandwidth Measurement ............................................................................................................. 18 Site Used – Occupied Bandwidth Measurements...................................................................... 18 Test Measurement: Occupied Bandwidth Measurements .................................................................... 18 Occupied Bandwidth Measurement Plot ..................................................................................................... 19 Spectrum Mask Measurement...................................................................................................................... 19 Occupied Bandwidth Data: .......................................................................................................................... 19 Measurement Photographs for Field Strength of Fundamental and Occupied Bandwidth ......................... 20 SPURIOUS EMISSIONS, HARMONICS, and Emissions in the RESTRICTED BANDS ....................... 21 Test Procedure – Spurious Emissions:......................................................................................................... 21 Site Used –…

Text truncated - open the document above for the full version.

Test Setup Photos

FCC Test Setup Photographs for 47CFR15, Subpart B for Unintentional Radiators, per Section 101 Equipment authorization of unintentional radiators, and 47CFR15, Subpart C per Section 209 General Limits for Operation of Intentional Radiators On Volvo MMS Sensor [MMS Sensor Front: FCC ID: LQN2960, Model No: 902960] [MMS Sensor Rear: FCC ID: LQN2961, Model No: 902961] [MMS Sensor Front Warranty: FCC ID: LQN2960, Model No: 902962] Part No(s): MMS S…

Text truncated - open the document above for the full version.

Contact Information

Applicant

Patrick Denny

[email protected]+353-93-23184Fax: +353-93-23110

Test Firm

ITC Engineering Services, Inc.Michael Gbadebo

[email protected]925-862-2944Fax: 925-862-9013

Technical Specifications

#	Rule Parts	Frequency Range	Power Output
1	15C	5.72 GHz - 5.85 GHz	-

Confidentiality

Long Term
