Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.
ELECTRONIC MONITORING SYSTEM MEMS 3000 HOMESTATION & TRANSMITTER INSTALLATION GUIDE September 2005 Forward MEMS 3000 HomeStation & Transmitter Installation Guide F-3 Information in this documentation is subject to change without notice and does not represent a commitment on part of ElmoTech Ltd. The software described in this document is subject to the license agreement that is included with the product, which specifies the permitted and prohibited uses of the product. Any unauthorized duplication or use of this documentation, in whole or in part, in print, or in any other storage or retrieval system is prohibited. No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language in any form by any means for any purpose other than the purchaser’s personal use without the permission of ElmoTech Ltd. © 2002-05 ElmoTech Ltd. All rights reserved. Unless otherwise noted, all names of companies, products, street addresses, and persons contained herein are part of a completely fictitious scenario and are designed solely to document the use of an ElmoTech product. Contact Us Corporate Headquarters ElmoTech Ltd. 2 Ha-Barzel St., P.O. Box 13236, 61132 Tel Aviv, Israel Tel: 972-3-7671800 Fax: 972-3-7671801 U.S.A Customers, call 1-800-313-1483 E-mail : [email protected] Visit us at: www.elmotech.com Table of Contents MEMS 3000 HomeStation & Transmitter Installation Guide TC-1 TABLE OF CONTENTS Section Page CHAPTER 1 INTRODUCTION .........................................................................1-1 CHAPTER 2 THE MONITORING OFFICE ....................................................2-1 INSTALLATION KIT................................................................................. 2-1 INSTALLATION TOOLS............................................................................ 2-1 OFFENDER INFORMATION IN THE MWS................................................. 2-2 CHAPTER 3 THE OFFENDER’S CURFEW LOCATION .............................3-1 LOCATING THE MEMS 3000 HOMESTATION........................................ 3-1 POSITIONING THE MEMS 3000 HOMESTATION.................................... 3-2 INSTALLING AND ACTIVATING THE MEMS 3000 HOMESTATION........ 3-3 CHAPTER 4 TRANSMITTING TAG (TX) CALIBRATION AND INSTALLATION ..................................................................................................4-1 CALIBRATING THE TRANSMITTING TAG................................................ 4-1 ATTACHING THE TRANSMITTING TAG................................................... 4-2 CHAPTER 5 ACTIVATING THE OFFENDER’S MONITORING PROGRAM............................................................................................................5-1 DOWNLOADING THE PROGRAM CONFIGURATION................................. 5-1 PERFORMING A RANGE TEST................................................................. 5-2 ENROLLING THE OFFENDER................................................................... 5-4 CHAPTER 6 DAILY OPERATING INSTRUCTIONS ....................................6-1 INCOMING / OUTGOING CALLS.............................................................. 6-1 ON-DEMAND TEST REQUESTS................................................................ 6-2 GENERAL RULES FOR THE OFFENDER.................................................... 6-3 Table of Contents MEMS 3000 HomeStation & Transmitter Installation Guide TC-2 CHAPTER 7 REMOVING THE MONITORING SYSTEM ...........................7-1 PERFORMING AN END OF SERVICE......................................................... 7-1 DISCONNECTING AND PACKING THE MEMS 3000 HOMESTATION....... 7-2 REMOVING THE TRANSMITTING TAG..................................................... 7-2 DEACTIVATING THE TRANSMITTING TAG.............................................. 7-3 CHAPTER 8 MONITORING SYSTEM MAINTENANCE .............................8-1 CLEANING THE MEMS 3000 HOMESTATION........................................ 8-1 CLEANING THE TRANSMITTER............................................................... 8-2 REPLACING THE TRANSMITTER STRAPS................................................ 8-3 FCC NOTICES .....................................................................................................9-1 List of Figures MEMS 3000 HomeStation & Transmitter Installation Guide TF-1 LIST OF FIGURES Section Page Figure 3-1 Locating the MEMS 3000 HomeStation .............................. 3-2 Figure 3-2 Positioning the MEMS 3000 HomeStation .......................... 3-3 Figure 3-3 Installing the MEMS 3000 HomeStation.............................. 3-4 Figure 5-1 Enrolling the Offender .......................................................... 5-5 Introduction MEMS 3000 HomeStation & Transmitter Installation Guide 1-1 Chapter 1 Introduction Welcome to the Electronic Monitoring System and correctional tool, created by ElmoTech Ltd., that has the ability to collect, analyze and intelligently act on information from multiple sources. An inconspicuous transmitting Tag (TX) is attached to the client's ankle or wrist by means of a tamper-detecting strap. The client's presence (or absence) is tracked constantly by radio transmissions between the Tag and the MEMS 3000 HomeStation (RF Model). When the client enters or leaves the defined home environment, the MEMS 3000 HomeStation records the event. The MEMS 3000 HomeStation then checks the client’s stored curfew schedule to determine if the event is in violation of his or her curfew order. The MEMS 3000 HomeStation is a highly efficient monitoring unit, integrating alcohol testing (BAT), video identity verification and radio frequency (RF Model) presence monitoring into a single unit. The MEMS 3000 HomeStation transfers the breath alcohol test results and user’s image to the monitoring center at a push of a button. The MEMS 3000 HomeStation reports certain violations to the monitoring center as soon as they occur. All violation, non-violation eve…
Text truncated - open the document above for the full version.
Hardware Requirements The MEMS 3000 shall include 5 printed circuit boards: • Converted DCU PCB • User Interface (UI) PCB • BAT PCB • Camera PCB • Lights PCB The following diagram illustrates the connectivity of the various MEMS 3000 PCBs. The following paragraphs define the hardware requirements for the various MEMS 3000 PCBs.
TCB Confidentiality Form 30/1/2006 EMCCert DR. RAŠEK Boelwiese 5 91320 Ebermannstadt Germany Tel.: +49-9194-9331 Fax: +49-9194-7964-84 E-mail: [email protected] URL: http://www.emcc.de Gentlemen: This letter is to comply with Section 0.457(d)(2)(i) pertaining to confidential material. Elmo Tech would like the following document regarding this submission for FCC ID: LSQ MEMS- 3000 to be kept confidential. Schematics: 1 Page. The above material contains trade secrets or technical data, which would customarily be guarded from competitors. We do not want this document to be accessible to the general public. Sincerely, Gil Gemer VP R&D
ACS Sep-29-2004 BTI2 Electrical Specifications Absolute Maximum Ratings Ambient temperature range: +5º ~ +50º C Storage temperature range: -5º ~ +55º C Voltage on Vcc with respect to GND: -0.3 ~ +6.5V Voltage on Reset, Tx, Rx with respect to GND: -0.3 ~ (Vcc+0.3) Voltage on Vpmp with respect to GND: +7.2V Serial Communication TTL level, 9600, N, 8, 1 Alcohol Measurement Fuel cell: Operating life: 1 year (minimum) Specificity: specific for alcohol, no cross Sensitivity to ketones or hydrocarbons Range: 0~255 mg% BAC Resolution: 1mg% BAC Accuracy: +/-5 mg% BAC for solution < 50 mg% BAC +/-10% for solution >= 50 mg% BAC Analyzing time: < 6 seconds at 100 mg% BAC Purging time: < 60 seconds at 100 mg% BAC Warm-up time: 2 minutes (maximum) Alcohol Calibration Solution: 50 mg% BAC Power Supply Total power dissipation: Vcc -- 400mW (maximum) Vpmp -- 20W (maximum) Maximum current Icc: 100mA Maximum current Ipmp: 3A Nominal Vcc: +5V/100mA with 750mA fuse Nominal Vpmp: +5V/3A (recommended) with 5A fuse
Introduction MEMS 3000 HomeStation & Transmitter Installation Guide 1-1 Chapter 1 Introduction Welcome to the Electronic Monitoring System and correctional tool, created by ElmoTech Ltd., that has the ability to collect, analyze and intelligently act on information from multiple sources. An inconspicuous transmitting Tag (TX) is attached to the client's ankle or wrist by means of a tamper-detecting strap. The client's presence (or absence) is tracked constantly by radio transmissions between the Tag and the MEMS 3000 HomeStation (RF Model). When the client enters or leaves the defined home environment, the MEMS 3000 HomeStation records the event. The MEMS 3000 HomeStation then checks the client’s stored curfew schedule to determine if the event is in violation of his or her curfew order. The MEMS 3000 HomeStation is a highly efficient monitoring unit, integrating alcohol testing (BAT), video identity verification and radio frequency (RF Model) presence monitoring into a single unit. The MEMS 3000 HomeStation transfers the breath alcohol test results and user’s image to the monitoring center at a push of a button. The MEMS 3000 HomeStation reports certain violations to the monitoring center as soon as they occur. All violation, non-violation events that are not defined as immediate are stored in the MEMS 3000 HomeStation for the next upload. The MEMS 3000 HomeStation initiates a pre-defined routine sanity call to the monitoring center in order to report the status of the equipment and upload stored events. This event information completes the audit trail of the client’s behavior. The MEMS 3000 HomeStation detects and reports tilting, loss of power, loss of telephone line, low battery, and other alarm conditions. The MEMS 3000 HomeStation also detects transmitter tag tampering, tag removal and low battery.
REV Δ Description Sheet Effected Date Drawn Checked A 02.02.06 D.Lanuel S.Cohen EMC Laboratory MEMS-3000 FCCID: LSQ-MEMS-3000 Manufactured by EMC Test Report According FCC Part 15 Requirements June 2006 Function/Title Name Signature Date Prepared by Test Engineer D.Lanuel 02.02.06 Checked by Test Engineer D.Lanuel 02.02.06 Approved by EMC Lab. Manager S.Cohen 02.02.06 Mems3000 FCC Test Report EMC/30020FC06040 2/2 Table of Contents Para Page 1 ADMINISTRATIVE DATA...................................................................................................................3 2 GENERAL INFORMATION..................................................................................................................3 3 TEST SUMMARY AND SIGNATURES...................................................................................................4 4 E.U.T INFORMATION........................................................................................................................5 5 RADIATED EMISSION PART 15.109- (FOR RX MODE)..........................................................................6 6 CONDUCTED EMISSION, AC POWER LEADS ACCORDING TO FCC 15.107.............................................9 7 PHOTOGRAPHS.............................................................................................................................. 16 8 CORRECTION FACTORS.................................................................................................................. 17 9 ABBREVIATIONS AND ACRONYMS................................................................................................... 19 Mems3000 FCC Test Report EMC/30020FC06040 3/3 1 Administrative Data 1.1. Scope This document describes the measurement procedures and tests for Radiated and conducted emission testing of the MEMS3000 Manufactured by 2 General Information 2.1. Description of equipment Under Test Equipment Under Test: MEMS3000 FCCID LSQ-MEMS-3000 Manufacturer: Elmotech Ltd. Serial Numbers: 001 Mode of Operation: RX MODE Receiver operating frequency: 318MHZ Year of Manufacture: 2006 2.2. Applicant Information: Applicant: Elmotech Ltd. Applicant Address 2, Habarzel Street Tel-Aviv Telephone: +972-3-6478871 FAX: +972-3-6478872 The testing was observed by: YARIV OREN Following applicant's personnel: 2.3. Test Performance: Date of reception for testing: 01.02.06 Dates of testing; 01.02.06 Test Laboratory Name: Tadiran EMC Laboratory Address: Hashoftim 26 Holon Zip Code: 267,5812 City: Holon Country: Israel Telephone: 03-5574476 Fax: 03-5575320 Email: [email protected] Applicable EMC Specification: Federal Communication Commission (FCC), Code of Federal Regulations 47, FCC Docket 89-103, Part 15: Radio Frequency Devices, Sections 15.109, 15,107 Mems3000 FCC Test Report EMC/30020FC06040 4/4 3 Test Summary and Signatures. TADIRAN EMC Laboratory has completed testing of E.U.T in accordance with the requirements of the FCC Part 15 Regulations for Class B equipment. The E.U.T was found to comply with the requirements of the FCC Part 15 Regulations given below Test Test Description Section PASS/FAIL 1 Radiation emission 15.109 PASS 2 Conducted emission 15.107 PASS 3.1. Test performed by: Mr. D. Lanuel Test Engineer 3.2. Test Report prepared by: Mr. D. Lanuel Test Engineer 3.3. Test Report Approved by: Mr. Samuel Cohen EMC Lab. Manager Mems3000 FCC Test Report EMC/30020FC06040 5/5 4 E.U.T information 4.1. E.U.T description The E.UT, MEMS 3000 is a home unit, which receives data from 318MHz alarm transmitters; it provides communication with monitoring center through modem POTS lines and infrared communication with a computer. The device is powered via external AC/DC adaptor 12v/4a, the device complies with Part 68 FCC Rules, US:LSQALBDCU2010, the EUT provides the following monitoring technologies: • Randomly schedule video telephone calls to the client. • Remote breath alcohol testing with a visual confirmation. • Receiver under 318MHz 4.2. E.U.T Test Configuration E.UT. Test configuration is shown in figure bellow Internal Battery Integral Antenna E.U.T AC/DC Converter AC Input 4.3. E.U.T Mode of Operation description 4.3.1 318MHz RX Mode operated by AC/DC Converter Mems3000 FCC Test Report EMC/30020FC06040 6/6 5 Radiated emission part 15.109- (for RX mode) 5.1. Preliminary Radiated emission Test Result According Part 15.109 E.U.T: MEMS3000 001 Test Method: ANSI 63.4 Date: 01.02.06 Relative Humidity: 41% Ambient Temperature: 19c Air Pressure: 1038hpa Test Setup: figure 1, 2 Testing Engineer: D.Lanuel Date 02.02.06 5.2. Test Results Summary & Conclusions The E.U.T was found in compliance with 15.109 radiated emission requirements 5.3. Limits of Radiated Interference Field Strength according 15.109 The test unit shall meet the limits of Table-1 for Class B equipment. Table- 1 Limits For 15.109 Class B equipment Frequency Range (MHz) Limits (dBμV/m) Detector 30 - 88 40 88 - 216 43.5 216 - 960 46 960 - 1000 46 Quasi Peak 1000 - 2000 53.9 Average Mems3000 FCC Test Report EMC/30020FC06040 7/7 5.4. Test Instrumentation and Equipment Table- 2 Test Instrumentation and Equipment Item Model Manufacturer Next Date Calibration Spectrum Analyzer 8593E HP 31.01.06 Double Ridge Guide Antenna(1- 18GHz) 3105 EMCO 24.04.06 Broadband Antenna BTA-L FRANKONIA 10.04.06 Low Noise Amplifier (0-1GHz) AM-1300-N MITEQ 14.01.06 Low Noise Amplifier (1-4GHz) AMM-003M Avantek 14.01.06 5.5. Test Results Table- 3 Test Results for Unintentional Emissions in RX Mode 15.109 Antenna Polarization Freq. Range MHz Res. BW (kHz) Plot Ref. PASS/FAIL 30-1000 120 1 PASS Both 1000-2000 1000 2 PASS Mems3000 FCC Test Report EMC/30020FC06040 8/8 5.6. Test Procedure 5.6.1 Preliminary Test Procedure 5.6.1.1 The EUT was placed on the top of a rotating table 0.8 meters above the ground at a chamber shielded 5.6.1.2 The E.U.T was set 3 meters away from the receiving antenna, which was mounted on the top of a variable-height antenna tower. 5.6.1.3 The Antenna height…
Text truncated - open the document above for the full version.
Mems3000 FCC Test Report EMC/30020FC06040 16/16 7 Photographs Photograph/ 1 Radiated Emission 30-1000MhZ test setup Photograph/ 2 Radiated Emission 1-2GHz test setup
| # | Rule Parts | Frequency Range | Power Output |
|---|---|---|---|
| 1 | 15B | 318 MHz - 318 MHz | - |

Dual Comm RF Monitoring System
Equipment Class
DSR - Part 15 Remote Control/Security Device Transceiver
Wrist Tag
Equipment Class
DSR - Part 15 Remote Control/Security Device Transceiver
Wrist Tag
Equipment Class
DSR - Part 15 Remote Control/Security Device Transceiver
Part 15 - Remote Control / Security Device Transceiver
Equipment Class
DSR - Part 15 Remote Control/Security Device Transceiver
2TRACK BASE UNIT 318 MHz
Equipment Class
DSR - Part 15 Remote Control/Security Device Transceiver
