LWN9701F25F25 Series Industrial Radio Remote Controller

Installation & Operation Manual F25 Industrial Radio Remote Controller Lee’s Hi-tech Enterprise. Co., Ltd. 1 Table Of Contents Safety Considerations ------------------------------------------------------------2 Part. 1 Operator’s Manual Chapter 1 Warranty -----------------------------------------------------3 Chapter 2 Precautions Of Operation --------------------------------- 4 Chapter 3 Standard Accessories ---------------------------------------6 Chapter 4 Operation -----------------------------------------------------7 Chapter 5 Inspection and Fault Detection ---------------------------10 Part. 2 Technician’s Manual Chapter 1 General Characteristics -------------------------------------11 Chapter 2 System Configuration ---------------------------------------12 Chapter 3 Installation ----------------------------------------------------14 2 Safety Considerations This product and related documentation must be reviewed for familiarization with safety markings and instructions before operation. Safety Symbols The following symbols may be found on the remote control or throughout the remote control’s documentation. Refer to Manual When product is marked with this symbol refer to instruction manual for additional information. High Voltage Indicates presence of hazardous voltage. Unsafe practice could result in severe personal injury. Warning Denotes a hazard. Included text gives proper procedures. Failure to follow instructions could result in severe personal injury and/or property damage. Caution Denotes a hazard. Included text gives proper procedures. Failure to follow instructions could result in minor personal injury and/or properly damage. 3 Part 1. Operator’s Manual Chapter 1 Warranty 1-1 Warranty Lee’s Hi-Tech Enterprises Co., Ltd. guarantees that this product meets its published specifications at the time of shipment from the factory. Under proper installation it should work as expected. 1-2 Warranty Period This equipment is warranted against defects in material and manufacturing for a period of one year from the date of shipment. During the warranty period, TELECRANE is responsible for necessary repairs as long as the product can be proved to be defective. For warranty service or repair this product must be returned to a service facility designated by TELECRANE. Buyer will pay shipping charges to TELECRANE while TELECRANE will pay return shipping charges. 1-3 Excluded Items This warranty does not include consumptive parts such as batteries, fuses, buttons, and relays. Also this warranty does not cover defects caused by improper installation, improper or insufficient maintenance, unauthorized modification, improper operation, ignorance of environmental specifications, or improper software or interfacing. 1-4 Remarks ◎ No other warranty is expressed or implied, except for the above mentioned. ◎ The remedies provided herein are the buyer’s sole and exclusive remedies. TELECRANE shall not be liable for any direct, indirect, special, incidental or consequential damages. 4 Chapter 2 Precautions of Operation 2-1 Attention ◎ Please carefully read the manual before installing and operating this device. ◎ Due to the complex nature of this equipment it is necessary to read the entire manual before installation. ◎ Never dismantle the equipment by any unauthorized personnel, or equipment may be damaged. ◎ This manual is for reference only. Pleases consult your distributor for further assistance. ◎ The equipment has been strictly tested for quality before delivery from our plant. However, this equipment must not be used in dangerous situations or where damage may result. ◎ After operation, shut off main power to the crane, power to receiver, and remove transmitter key. ◎ Transmitter should be placed in a safe area when not in use to avoid accidental pressing of buttons. ◎ The crane should be equipped with main power relay, limit switch and other safety devices. ◎ Don’t use equipment during lightening or high electrical interference conditions. ◎ Make sure that the batteries are in good condition and power for receiver is correct. ◎ Maintenance should only be done while the crane’s main power is off to prevent electrical shock. ◎ The contents of this manual may be amended by the manufacturer without notice. ◎ The manufacturer may introduce new functions to the equipment as necessary, therefore, the descriptions may change. 5 2-2 Precautions ☆ Operating in an industrial facility is relatively dangerous; therefore, operator must have taken the adequate trainings in using F25 system. ☆ Those who operate the machine should be healthy and have good judgment in regard to safety. ☆ Although the F25 transmitter is so durable and resistant for the fluctuating temperature, care still need be taken to prevent it from the severe impact or pressure. ☆ During operation, if the power supply of the transmitter’s batteries is insufficient, the transmitter will send out EMS signal first to de-energize all of motion relays inside the receiver to stop crane’s moving, and then the LED indicator on transmitter will flash in red constantly. At this moment, the batteries need to be replaced and all of four batteries should be replaced at the same time. ☆ If the severe interference occurred the equipment should be stopped at once. ☆ Please take the batteries out when the equipment will not be used for a long time. ☆ Be sure to know the “Procedures of Emergency “ as follows. 2-3 Procedures of emergency In case of an Emergency, please follow the steps below and ask the distributor for service immediately. 1. Press "EMS" button. 2. Turn the key to "OFF" position and remove it. 3. Switch off the main power of crane. 4. Advise the distributor to find out the reason. 6 Chapter 3 F25 Standard Accessories When you acquire a standard and full set of F25 system, it includes the following items. (1)Transmitter, one unit. (2)Receiver, one unit. 7 Chapter 4 Operation 4-1 F25 Transmitter’s parts Antenna Rotary Key EMS Button LED Indic…

Text truncated - open the document above for the full version.

Federal Communications Commission 7435 Oakland Mills Road Columbia, MD,21046 Re: Certification for Gain Electronic Co., Ltd. Model(s): F25-12S/F25-12D/F25-10S/F25-10D/F25-8S/F25-8D/F25-6S/F25-6D FCC ID:LWN-9701F25 IC:2384A-9701F25 REQUEST FOR CONFIDENTIALITY To whom it may concern, On behalf of Lee Hi-tech Enterprise Co., Ltd, (pursuant to 47 CRF 0.459) I request that the following documents contained in this certification application be permanently withheld from public disclosure. All schematic diagrams All Block diagrams Operation Description Disclosure of the above information to the public, including Lee Hi-tech Enterprise Co., Ltd. competitors, would result in a severe business hardship for Gain Electronic Co., Ltd and its partners and may impair their collective ability to bring this product to market Additionally, Lee Hi-tech Enterprise Co., Ltd. also certifies that no party to this application is subject to denial of benefits, including FCC benefits, pursuant to section 5301 of the anti-drug abuse act of 1988, 21 U.S.C 853(a) On Behalf of Lee Hi-tech Enterprise Co., Ltd, sincerely Paul Chen ECMG Worldwide Certification Solutions (Taiwan)

American Telecommunications Certification Body Inc. 6731 Whittier Ave, McLean, VA 22101 February 20, 2008 RE: FCC ID: LWN9701F25_ATCB005935 Attention: I have a few comments on this Application. Please note that further comments may arise in response to answers provided to the questions below. 1. Please provide the required Block diagram exhibit for this application as a separate exhibit. Dennis Ward mailto:[email protected] The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information may result in application termination. Correspondence should be considered part of the permanent submission and may be viewed from the Internet after a Grant of Equipment Authorization is issued. Please do not respond to this correspondence using the email reply button. In order for your response to be processed expeditiously, you must submit your documents through the AmericanTCB.com website. Also, please note that partial responses increase processing time and should not be submitted. Any questions about the content of this correspondence should be directed to the sender.

684 West Maude Avenue, Sunnyvale, CA 94085. Tel. (650) 988-0900 Fax (650) 988-6647 www.ecmg-global.com FCC CERTIFICATION RADIO MEASUREMENT TECHNICAL REPORT On Model Name: F25 Industrial Radio Remote Controller Model Number : F25-12S/F25-12D/F25-10S/F25-10D F25-8S/F25-8D/F25-6S/F25-6D Trademark : FCC ID : LWN9701F25 Prepared for L e e H i - t e c h E n t e r p r i s e . C o . , L t d. According to FCC Part 15 (2006), Subpart C According to IC RSS-210 Test Report #: LEE-0801-6785-FCC Prepared by: Cherry Chang Reviewed by: Harry Zhao QC Manager: Paul Chen Test Report Released by: 2008 February 1 ⎯⎯⎯⎯⎯⎯⎯⎯⎯ ⎯⎯⎯⎯⎯⎯ Paul Chen Date Test Location Tests performed at Training Research Co., Ltd. in a Certified ANSI Semi-Anechoic Chamber and Shielded Room performed testing. Test Site Location: Training Research Co., Ltd. No.255,Nanyang St., Shijr City, Taipei Hsien 221,Taiwan Tel: 886-2-2693-5155 Fax: 886-2-2693-4440 Registration Number: 93906 Accreditation Bodies Training Research Co., Ltd. is a fully accredited Test Laboratory for ITE, ISM, MIL-STD and Telecommunications Products. Accredited by the National Voluntary Laboratory Accreditation Program for the specific scope of accreditation under Lab Code # 200174-0. TRC is ECMG’s subcontract Lab. TRC conduct the related EMC/RF test. ECMG collect and generate the report. Table of Contents DISCLAIMER NOTICE _________________________________________ 1 REPRODUCTION CLAUSE_____________________________________ 1 OPINIONS AND INTERPRETATIONS ___________________________ 1 STATEMENT OF MEASUREMENT UNCERTAINTY ______________ 1 ADMINISTRATIVE DATA _____________________________________ 2 EUT DESCRIPTION ___________________________________________ 2 TEST SUMMARY _____________________________________________ 4 TEST MODE JUSTIFICATION _________________________________ 5 EUT EXERCISE SOFTWARE ___________________________________ 5 EQUIPMENT MODIFICATION _________________________________ 5 TEST SYSTEM DETAILS ______________________________________ 6 CONFIGURATION OF TESTED SYSTEM________________________ 7 EUT SAMPLE PHOTOS _______________________________________ 8 ATTACHMENT 1 – ANTENNA REQUIREMENT_________________ 19 ATTACHMENT 2 – RESTRICTED BAND OF OPERATION_______ 22 ATTACHMENT 3 – OPERATION MODE _______________________ 27 ATTACHMENT 4 –FIELD STRENGTH OF FUNDAMENTAL AND SPURIOUS EMISSIONS__________________________________________________ 32 ATTACHMENT 5 – 20dB BANDWIDTH TEST FOR FCC _______ 41 ATTACHMENT 6 – 99% BANDWIDTH TEST FOR IC _________ 46 EMC Test Report #: LEE-0801-6785-FCC Prepared for Lee Hi-tech Enterprise. Co., Ltd. Prepared by EMC Compliance Management Group Page 1 of 37 Disclaimer Notice When government drawing, specification, or other data are used for any purpose other than in connection with a definitely related government procurement operation, the United States Government thereby incurs no responsibility nor any obligation whatsoever; and the fact that the Government may have formulated, furnished, or in any way supplied the said drawing, specifications, or other data, is not to be regarded by implication or otherwise in any manner licensing the holder or any other person or corporation, or conveying any rights or permission to manufacture, use, or sell patented invention that may in any way be related thereto. This report must not be used to claim product endorsement by NVLAP or any agency of the U.S. Government. Reproduction Clause Any reproduction of this document must be done in full. No single part of this document may be reproduced without permission from EMC Compliance Management Group, 684 West Maude Avenue, Sunnyvale, CA 94085. Opinions and Interpretations This test report relates to the abovementioned equipment under test (EUT). Without the permission of EMC Compliance Management Group Test Lab this test report is not permitted to be duplicated in extracts. This test report does not entitle to carry any test mark on this or similar products. The manufacturer has sole responsibility of continued compliance of the device. Statement of Measurement Uncertainty The data and results referenced in the document are true and accurate. The reader is cautioned that there may be errors within the calibration limits of the equipment and facilities that can account for a nominal measurement error. Furthermore, component and process variability of devices similar to that tested may result in additional deviation. EMC Test Report #: LEE-0801-6785-FCC Prepared for Lee Hi-tech Enterprise. Co., Ltd. Prepared by EMC Compliance Management Group Page 2 of 50 Administrative Data Test Sample : F25 Industrial Radio Remote Controller Model Number : F25-12S/F25-12D/F25-10S/F25-10D F25-8S/F25-8D/F25-6S/F25-6D Trade Mark : Date Tested : 2008 January 31 Applicant : Lee Hi-tech Enterprise. Co., Ltd. 8F-1 No.288-2, Hsin-Ya Road Chien-Chen Dist, Kaohsiung, Taiwan, R.O.C Telephone : +886-7-812-5652 Fax : +886-7-812-5704 Manufacturer : Lee Hi-tech Enterprise. Co., Ltd. 8F-1 No.288-2, Hsin-Ya Road Chien-Chen Dist, Kaohsiung, Taiwan, R.O.C EUT Description Lee’s Hi-Tech Net Co., Ltd. Model number F25-12S F25-12D/F25-10S/F25-10D/ F25-8S/F25-8D/F25-6S/F25-6D (referred to as the EUT in this test report) is a Industrial Radio Remote Controller.. The F25-12S/F25-12D/F25-10S/F25-10D/ F25-8S/F25-8D F25-6S/F25-6Dare having the same design structure and the in differences between F25-12S/F25-12D/F25-10S F2-10D/F25-8S/F25-8D/F25-6S/F25-6D are just number of pushbuttons & relays. EMC Test Report #: LEE-0801-6785-FCC Prepared for Lee Hi-tech Enterprise. Co., Ltd. Prepared by EMC Compliance Management Group Page 3 of 50 EMC Test Report #: LEE-0801-6785-FCC Prepared for Lee Hi-tech Enterprise. Co., Ltd. Prepared by EMC Compliance Management Group Page 4 of 50 Test Summary The Electromagnetic Compatibility requirements on F25-10D for this test are stated below. All results listed in this report relate exclusively to this above-mentioned model as the Equipment Under Test. This report co…

Text truncated - open the document above for the full version.
