USER MANUAL FCA WL/WS PASE System MY2021 Model:WXRFHM1 Model: WXRFHM1 The WXRFHM1 (Radio Frequency Hub Module) is an electronic body controller that provides Passive and Active entry and start to the vehicle. The module communicates with the other vehicle electronic devices via CAN FD. The communication of the RFHM module and the KeyFOB is done via LF antenna coils mounted inside and outside the vehicle (If equipped). The device is available in the 433.92 MHz internal antenna (92 mm) and 433.92 MHz external antenna (Fakra Connector) version. The RFHUB system is a Passive Start and Entry (PASE) system that provides enhanced customer convenience and security via a customer carried, passively or actively enabled FOBIK communicating with the vehicle control module RFHUB. A valid KeyFOB allows access to the vehicle's passenger compartment, access to the trunk, and use of the vehicle's ignition controls. The RFHUB System includes an RFHUB Module, an Ignition Module (KIN) containing the Base station and Transponder coil, and a KeyFOB. Use of the ignition controls is provided through a Keyless Ignition Node module (KIN) located in the vehicle. The LF antenna coils are driven by an LF Driver. The antenna components form a series resonance circuit with a low Q factor. The purpose of the antenna is to generate magnetic fields which are high enough to transmit data to the KeyFOB and accurate enough for location recognition of the KeyFOB (outside/inside the vehicle). The KeyFOB receives and processes this transmitted data. The KeyFOB then sends its ID confirmation and data to the RFHM module via a 433.92MHz RF signal. The RFHM also receives RKE information from the KeyFOB for Keyless Access to commands such as "Lock", "Unlock" and "Remote Start" and receives TPMS RF Telegrams from TPMS sensors embedded in the tires. The RFHM is designed to withstand and operate properly at the environmental extremes typically encountered in a vehicle’s passenger compartment. Model: WXRFHM1 The FCA RFHM WL requires 2 different connectors to interface with the user and other modules Model: WXRFHM1 Components on board Microprocessor Internal Clock 120MHz Crystal Oscillator 40 MHz RF Receiver 433.92 MHz LF Transmitter 125 kHz CAN Transceiver 2 Mbps LIN Transceiver 19.2 Kbps Technical data Operating Voltage 6V to 16V Max Current Consumption 250 mA Operating Temp range (°C) -40 to 85°C Measurements (LxWxH) 153.5X101.7X29mm weight (g) 130.4g (internal antenna) / 134.7g (external antenna) Carrier Frequency 433.92 MHz Bandwidth 240 kHz Number of Channels 1 Channel Type of Modulation ASK and FSK Antenna Type Internal antenna: 92 mm Loop antenna / External antenna: Fakra connection Antenna Gain Internal Antenna: -6 dB / External Antenna: NA Manufacturer Continental Automotive GmbH Siemensstr. 12, 93055 Regensburg, Germany Model: WXRFHM1 Regulatory information - FCC/ISED Owner Manual statement of compliance NOTE: If the device itself is smaller than 8 cm x 10 cm, the statements of compliance may be included in the device or vehicle owner/operator manual. However, if the device itself is larger than 8 cm x 10 cm, then it is required to have at least the first paragraphbelow placed on the device label or housing. This device complies with Part 15 of the FCC Rules and with Industry Canada’s licence-exempt RSSs. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. Cet appareil est conforme aux CNR d’Industrie Canada a applicables aux appareils radio exempts de licence. L’exploitation est autorisée à condition que l'appareil ne produise pas de brouillage préjudiciable et qu'il accepte tout brouillage, même celui susceptible d'en compromettre le fonctionnement. Note: Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: —Reorient or relocate the receiving antenna. —Increase the separation between the equipment and receiver. —Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. —Consult the dealer or an experienced radio/TV technician for help. - Taiwan 取得審驗證明之低功率射頻器材，非經核准，公司、商號或使 用者均不得擅自變更頻率 、加大功率或變更原設計之特性及功能。 低功 率射 頻器材之使用不得影響飛航安全及干擾合法通信；經發現有干擾現象時，應 立 即停用，並改善至無干擾時方得繼續使用。 前述 合法通信，指依電信管理 法規定作業之無線電通信。 低功率射頻器材須忍受合法通信或工業、科學及 醫療用電波輻射性電機設備之 干擾。 -

C5266091_X8_Ed.1 1/1 Letter of Authorization Company: Continental Automotive GmbH Address: 4685 lnvestment Drive, Troy, Michigan, United States Product Name: FCA WL/WS PASE System MY 2021 Model Number: WXRFHM1 FCC Identifier: M3NWXRFHM1 We authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, to act on our behalf on all matters concerning the above named equipment. Any individual within LGAI Technological Center S.A. is authorized to act on our behalf and take action on the application. We declare that authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, is allowed to forward all information related to the approval project to the Federal Communication Commission and to discuss any issues concerning the approval application. Any and all acts carried out by LGAI Technological Center S.A. on our behalf shall have the same effect as acts of our own. Name: Mark Kenney Date: 2021/01/25 Title: Type approval employee Signature of applicant:

C5266091_X10_Ed.1 1/1 Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Date: 2021/01/25 Subject: Request for Confidentiality FCC ID: M3NWXRFHM1 To Whom It May Concern, Pursuant to the provisions of Sections 0.457 and 0.459 of Commission's rules (47CFR0.457, 0.459), we are requesting the Commission to withhold the following attachment(s) as confidential document from public disclosure. Exhibits Long-Term Confidentiality Short-Term Confidentiality ID Label/Location No No Attestation Statement No No External Photos No Block Diagram Schematics Test Report No No Test Setup Photos No User’s Manual Internal Photos Parts List / Tune Up RF Exposure Info Operational Description Cover Letter(s) No No SDR Software / Security Info No Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. Sincerely, Name: Mark Kenney Title: Type approval employee

External antenna: 433MHz External RX Antenna 125kHz TX Antenna Internal antenna: 125kHz TX Antenna

Label location 03A2.C773.7340.0_DRW_000_ACJBA-20300149/11143376K14; Content Table Updated2020-07-20RS 02A2.C773.7340.0_DRW_000_ABJBA-19300260/9934878 G13; Homologation symbols moved and arrow added. 2019-11-01AN 01A2.C773.7340.0_DRW_000_AAJBA-19300069/8773135Initial Release2019-03-14RS No. Continental Drawing Version Change Nr./e-sign Nr.Modification DescriptionDateName All versions Blank Label Part No : A2C69035000 Size and scale of the HOMOLOGATION SYMBOLS are not to specification. For label printing use manufacturing data base. 181716151413121110987654321 R Q P N M L K J I H G F E D C B 82.9105-0208.0 / 000 / 00 192021222324 123456789101112131415161718192021222324 A S A B C D E F G H I J K L M N P Q R S BEMERKUNGEN NOTES DRAWING CAD SYSTEM MATERIAL GENERAL TOLERANCESTOLERANCE PRINCIPLE RELEASED BYDEPARTMENT TITLE SURFACE (C) Continental AG PAGE of SCALE DEPARTMENT REVIEWED BYDEPARTMENT CALCULATED WEIGHT MATERIAL NO. DOC. VERS.DOC. PART DOC. TYPE DOCUMENT NO. 3D MODEL DOC. VERS. CHANGED ITEMS ZONE IN GRID CHANGE DESCRIPTION CREATED BYDATE DATE DATE DIMENSIONS IN MILLIMETERS Label Printed -- 2020 WL Printed Homologaion Label A2C77373400_CAD_000.CATPart Ramki.Srinivasan2020-08-20VNI CE HW AM TRO XFC ME 1 A2C77373400DRW000 - --Size ISO 14405 - JBA-20300149 AC - 11N/A g +/--% ECM NO. FORMAT A0 THE REPRODUCTION, DISTRIBUTION AND UTILIZATION OF THIS DOCUMENT AS WELL AS THE COMMUNICATION OF ITS CONTENTS TO OTHERS WITHOUT EXPRESS AUTHORIZATION IS PROHIBITED. OFFENDERS WILL BE HELD LIABLE FOR THE PAYMENT OF DAMAGES. ALL RIGHTS RESERVED IN THE EVENT OF THE GRANT OF A PATENT, UTILITY MODEL OR DESIGN. NO GUARANTEE CAN BE GIVEN IN RESPECT OF THE TRANSLATION. IN ALL CASES THE LATEST ENGLISH LANGUAGE VERSION OF THIS DOCUMENT SHALL BE TAKEN AS AUTHORITATIVE A2C77373400_DRW_000.CATDrawing Submitted5AC.. LABEL 1 COUNTRYLABEL INFO DEVICEDRAWING DEVICE ALGERIA, AZERBAIJANI REPUBLIC (CIS), ARMENIA (CIS), BAHRAIN (AGCC), BARBADOS, BELARUS (CIS), BOLIVIA, BRUNEI DARUSSALAM, CAMEROON, CHILE, CHINA, COLOMBIA, COSTA RICA, ECUADOR, EGYPT, EL SALVADOR GUATEMALA, HONDURAS, HONGKONG, INDIA, IRAQ, ISRAEL, IVORY COAST, KAZAKSTAN (CIS), KENYA, KUWAIT (AGCC), LEBANON, MACEDONIA, MALAWI, MAURITIUS, MONGOLIA, MOZAMBIQUE, NAMIBIA, NICARAGUA, NIGER, OMAN (AGCC), PANAMA, SAUDI ARABIA (AGCC), SENEGAL, SRI LANKA, TANZANIA, THAILAND, TOGO, TUNISIA, UGANDA, URUGUAY , VENEZUELA, YEMEN, ZAMBIA, ZIMBABWE CONTINENTAL ARGENTINE REPUBLIC (LOGO ONLY) CNC ID : DI-20XX-XXX AUSTRALIA, NEW ZEELAND (LOGO ONLY) BRAZIL Anatel - XXXXX-XX-XXXXX REFER TO CHART FOR 'N' VALUE CANADA IC:7812D-XXXXXXXX MN:XXXXXXXX NN REFER TO CHART FOR "X N" VALUES CHRYSLER PART NUMBER ASSY EUROPEAN COMMUNITY: AUSTRIA, BELGIUM,BULGARIA, CROATIA, CYPRUS, CZECH REPUBLIC, DENMARK, ESTONIA, FINLAND, FRANCE, GERMANY,GREECE, HUNGARY, IRELAND, ITALY, LATVIA, LITHUANIA, LUXEMBOURG, MALTA, NETHERLANDS, POLAND, PORTUGAL, ROMANIA, SLOVAK REPUBLIC, SLOVENIA, SPAIN, SWEDEN, SWITZERLAND, UK NON EUROPEAN COMMUNITY: ALBANIA, ANGOLA, FRENCH GUYANA (FRANCE), GUADELOUPE (FRANCE), FRENCH POLYNESIA (FRANCE), GEORGIA, GIBRALTAR, ICELAND, LIBYA, LIECHTENSTEIN, MALI, MARTINIQUE (FRANCE), MONTENEGRO, NEW CALEDONIA (FRANCE), NORWAY, REUNION (FRANCE), TURKEY, QATAR (AGCC), (LOGO ONLY) GHANA NCA APPROVED: XXX-XX-XXX-XXX INDONESIA (REPUBLIC OF) XXXXX/XXXXX/XXXX (Cert #) XXXX (PLG ID #) JORDAN (HASHEMITE KINGDOM OF) TRC/LPD/20XX/XXX MALAYSIA (LOGO ONLY) HIDF1500XXXX MEXICO IFETEL: RXXXXXXXX-XXXX MOLDOVA (REPUBLIC OF) (CIS) (LOGO ONLY) XXX MOROCCO (KINGDOM OF) (LOGO ONLY) AGREE PAR L`ANRT MAROC Numero d`agrement :MR XXXXX ANRT XXXX Date d`agrement :XX/XX/XXXX NIGERIA (FEDERAL REPUBLIC OF) (LOGO ONLY) PARAGUAY (REPUBLIC OF) (LOGO) xxxx-xx-x-xxxx PHILIPPINES (REPUBLIC OF THE) (LOGO ONLY) ESD-CPE-XXXXXXXX RUSSIAN FEDERATION (CIS) (LOGO ONLY) SERBIA (REPUBLIC OF) (LOGO ONLY) P1617131700 17 SINGAPORE (REPUBLIC OF) (LOGO ONLY) Complies with IMDA Standards DAXXXXXX SOUTH AFRICA (REPUBLIC OF) (LOGO ONLY) TA-20XX/XXXX APPROVED TAIWAN (LOGO) ETCXXXLPDXXXX UKRAINE (CIS) (LOGO ONLY) UA.TR.XXX UNITED ARABIAN EMIRATES (AGCC) ABU DHABI, DUBAI, SHARJAH, RAS AL-KHAIMAH, UMM AL-QAWAIN, AJMAN, FUJAIRAH TRA REGISTERED No: ERXXXXX/XX DEALER No: DAXXXXX/XX USA, DOMINICAN REPUBLIC, GUAM, PUERTO RICO, PERU, VIRGIN ISLANDS FCC ID: XXX-XXXXXXXX VIETNAM(LOGO ONLY) KOREA (REPUBLIC OF)MISP-XXX-TAL-XXXXXX CONTENT OF THE LABEL RF HUB WL/WS, HOUSING FIELDDESCRIPTIONCONTENTEXECUTIONTEXT HEIGHT ACHRYSLER DEVICE TYPERFHM WL/WSPS-44806.35 mm BCHRYSLER LOGOPS-44806.35 mm CCHRYSLER SUPPLIER CODE64469PS-44802.36 mm DMANUFACTURING DATEYDDD (YEAR AND CURRENT DAY OF THE YEAR)PS-44802.36 mm ECHRYSLER PART NUMBER ASSY (P):XXXXXXXXNN REFER TO CHART FOR "X N" VALUES PS-44802.36 mm FCHRYSLER PART NUMBER ECU (P):XXXXXXXXNN REFER TO CHART FOR "X N" VALUES PS-44802.36 mm GCHRYSLER BAR CODE ASSY (P)XXXXXXXXNN REFER TO CHART FOR "X N" VALUES code 39; 11 digits 6.4 mm HCURRENT HARDWARE PN.SEE ECU ASSEMBLY DRAWINGPS-88002.36 mm JCURRENT SOFTWARE REV.SEE ECU ASSEMBLY DRAWINGPS- 88002.36 mm KCONTINENTAL PART NUMBERA2CXXXXX REFER TO CHART FOR "X N" VALUES PS-88002.36 mm LCONTINENTAL BARCODE REAL TEXT (T)00 = RI(NOG), (T) = PROD LINE A (COMPONENT CODE FOR RFHUB) DDD [DAY OF THE YEAR (031=31JAN)] Y [YEAR (7=2007), VVVVVV=SERIAL NUMBER] PS-88002.36 mm MCONTINENTAL BARCODESAME AS FIELD "L"code 39; 15 digits 6.4 mm NCOUNTRY OF ORIGIN (EN)Made in MexicoPS-44801.57 mm PCOUNTRY OF ORIGIN (FR)Fabrique au MexiquePS-44801.57 mm QCONTINENTAL LOGOATE N 101 55.50 6 mm RHOMOLOGATIONFCC ID : / IC : / CE, (SEE LABEL) AND ASIDE TABLE 2.36 mm SCONTINENTAL INTERNAL SR. NO. MATRIX TO SCAN: PPP I E Y DDD SSSSSS PCB DATA MATRIX 5 x 5 mm TCONTINENTAL SR. NO. READABLE PPP I E Y DDD SSSSSS PPP (SUB-ASSY) I (MFG INDEX) E (LASER POINT EQ ID) Y (YEAR) DDD (JULIAN DATE) SSSSSS (SERIAL NUMBER) 2.36mm U*S CODE ONLY FOR SERVICE PARTS S2.36 VFREQUENCY433 MHz (ALL COUNTRIES BUT JAPAN) 315 MHz (JAPAN ONLY) 2.36 mm - FOR 'X' VALUES REFER TO TRANCEIVER ASSY DRAWING A2C77173200_DRW_001 LAT…
