M4Y-AS240802.11ax Access Point

1 AS240 DFDSFD 2x2 Dual Band 802.11ax Access Point DFDSFD Package Contents One Indoor access pointScrews for hard ceilingScrews for suspendedceiling Mounting Bracket Installation Requirements TERMS OF USE: All Ethernet cabling runs suggestusingCAT.6, 24AWG (or above) Shielded Twisted Pair (STP) cabling. In addition, please cut the cable into a proper length, strip the cables on both ends, and crimp the wires into RJ45 connectors.It is the professional installer’s responsibility to follow local country regulations, including operation within legal frequency channels, output power, indoor cabling requirements, and Dynamic Frequency Selection (DFS) requirements. Mounting Below a Suspended Ceiling Identify the location where you intend to mount the access point. Raise the selected ceiling tile on both sides of the channel to remove the tile. Use the mounting bracket as a template to mark the locations of the mounting holes on the tile. Use a drill to drill a pilot hole at the mounting hole locations you marked. Position the mounting bracket holes (with indents up) over the pilot holes. Insert a fastener into each mounting hole and use a washer together with wing nut to tighten. If necessary, drill or cut a cable access hole in the ceiling tile large enough for the Ethernet cables. Pull the cable through the access hole until you have about 1 foot of cable protruding from the hole. Connect the Ethernet cable to the access point. Align the access point hook over the keyhole mounting slots on the mounting bracket. If you created a hole for the cable,make sure the access point is positioned so that the cable reach their respective port. Gently slide the access point onto the mounting bracket until it clicks into place. ○ 11 Reinstall the ceiling tile. Mounting On a Hard Ceiling This procedure describes the steps required to mount the access point on a hard ceiling using the mounting bracket. ○ 1 Use the mounting bracket as a template to mark the locations of the mounting holes on the ceiling. ○ 2 Use a drill to drill a pilot hole atthe mounting hole locations you marked and insert the plastic anchors. ○ 3 Position the mounting bracket mounting holes (with indents up) over the pilot holes. ○ 4 Insert a fastener into each mounting hole and tighten. ○ 5 Connect the Ethernet and power cables to the access point. ○ 6 Align the access point hook over the keyhole mounting slots on the mounting bracket. If you created a hole for the cable, make sure the access point is positioned so that the cable reach their respective port. ○ 7 Gently slide the access point onto the mounting bracket until it clicks into place. Powering the Access Point Connect the PoE cable into the WAN/PoE IN port of the device. LED Indicator ColorIndicatorBehaviorDescription Green PWR OnPower on OffPower off WLAN On WLAN connection detected Off No WLAN connection detected Blinking Sending / receiving data WAN On Ethernet connection detected Off No Ethernet connection detected Blinking Sending / receiving data Note:Please wait for 5-10 seconds while powering on. Access Point Configuration In a default access point configuration, the access point default AP mode is TAP mode, and obtains IP addressesfrom DHCP Option43protocol. Note: In TAP mode,the AP must be able to go with Wireless LAN Controllers (WLCs)for bulk configuration and performing other commandsof access points. Please refer to WLC QSG for settings first, then go back to finish the AP configuration. https://www.zcom.com.tw/index/downloads?keyword=&meterial_type=49 Step 1.Power on the access point. As the status of LED indicator from flashing change to steady red, the connection is successful. Note: Please make sure DHCP server is enabled on the network once accomplished WLC settings. The access point must receive its IP address through DHCP server. Note: Switching from DHCP to assign a static IP address or DNS and L2 discovery mode to the access point, please refer to the user manual formore information. https://www.zcom.com.tw/index/downloads?keyword=&meterial_type=25 If the access point cannot connect to the WLC by DHCP broadcast, please refer to the following optional settings. Optional: Set up a static IP address Note:The following procedure assumes that Windows 10 is the operating system. Procedures for other operating systems are similar. Step 1.On your computer, configure your network adapter from the “Local Area Connection “settings as follows: ̇StartControl PanelNetwork & InternetChange Adapter OptionsEthernet Step 2.Edit the TCP/IPv4 address setting as follows: ̇PropertiesInternet Protocol Version4(TCP/IPv4) Step 3.Select “Use the following IP address”and make the following entries: ̇IP address: 192.168.1.168(or any available address in the 192.168.1.x network, except 192.168.1.1) ̇Subnet mask: 255.255.255.0 Leave the “Default gateway”and “DNS server”fields empty. Step 4.Click “OK”to save your changes. Login into the access point Step 5.Launch a Web browser; type default URL https://192.168.1.1to connect to the access point. When a security alert dialog box appears, click OK/Yes to proceed. Step 6.When login page appears, enter the following: Username: root/Password: password Step 7.Click login. Customizing the Wireless Settings On the Web interface menu, Select StatusGeneralin the menu bar. Check your switchmod item to select “Connect with via IP”, and setup your WLC IP address on “Wireless Switch Address 1”. Note: IP address of WLC needsto be assigned (ex. 192.168.1.228) while on operation. Note: If you need a standalone access point, please change to FAP mode. FAP Mode The default AP mode is TAP mode, before FAP configurations please change AP mode. Step 1.If currently in TAP Mode: On the Web interface menu, click SystemAP mode. Step 2.Select Fat AP from the drop-down list. Step 3.Click save & apply to take effect. Note: For FAP mode, please refer to the user manual for more information. https://www.zcom.com.tw/index/downloads?keyword=&meterial…
