M65TR5C2-way system of car alarm system

The button ➄ of TR5C Transceiver functions description: For LCD panel light out : press once for LCD panel light out, wait for 3 seconds will turn off the light and back to normal status automatically. Known the latest status: Press twice for known the latest status (LCD panel keep lighten), wait for 3 seconds will turn off the light and back to normal status automatically. For example: If latest status was Door open trigger form Car2, when normal status and press twice LCD panel will show the match picture like the right of picture to prompt user. Note: -1 or -2 prompt meaning the latest status of Car1 or Car2. If no single back from Car1 or Car2, the -1 or -2 will not bee shown. Car1 or Car2 Control Selection: Keep press 2” to change Car1 or Car2 control for transceiver and LCD panel will show the match number (Hour Number) to prompt. (LCD panel keep lighten), wait for 3 seconds will turn off the light and back to normal status automatically. For example: If the transceiver latest control was for Car1, when keep press 2” that will change to control Car2 and LCD show number “2” that meaning the all controls of transceiver was for Car2, when keep press 2” again turn to control Car1 and LCD shown number “1”. When Car1 or Car2 been Selected and wait for 3 seconds will turn off the light and back to normal status automatically. For Time and Beep Setup: Press 5 times go into the Time and Beep Setup mode (LCD panel keep lighten and “AM” or “PM” will flashing that is meaning in setup mode). When in setup mode, you can refer the key function of following chart to operation. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC Statement This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. End users must follow the specific operating instructions for satisfying RF exposure compliance. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. Notice: Any changes or modification not expressly approved by the party responsible could void the user's authority to operate the device. Button Description Button ➀ turn “AM/PM” (when “AM” or “PM” flashing) or increase(+) for time number adjusting Button ➁ turn “AM/PM” (when “AM” or “PM” flashing) or decrease(-) for time number adjusting Button ➂ Go to the next item operation. (cycled and the match item will flashing for indication) “AM/PM”ΔHour”ΔMinutes higher number”ΔMinutes lower number” ΔAM/PM”ΔHour”Î... Button ➃ Beep disable(shock once and show match item) or Beep enable(beep once and show match item) Button ➄ press once for exit setup mode directly or do nothing wait for seven seconds to exit setup mode automatically, when exit setup mode will turn off the LCD panel light.

2 Way RF Circuit Low- V oltage technology Step-up circuit +3V +1.5V SW2 SW2 SW2 SW2 Buzzer TR5C Chart CPU Battery LCD

Report No: ER/2005/40006 ID: M65TR5C Issue Date: May 06, 2005 The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without prior written permission of the Company. SGS Taiwan Ltd. No. 134, Wu Kung Rd., Wuku Industrial Zone, Taipei Country, Taiwan. / 台北縣五股工業區五工路134號 台灣檢驗科技股份有限公司 t (886-2) 2299-3939 f (886-2) 2298-2698 www.sgs.com.tw 0513 ILAC MRA APPENDIX 2 PHOTOGRPHS OF EUT Report No: ER/2005/40006 ID: M65TR5C Issue Date: May 06, 2005 The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without prior written permission of the Company. SGS Taiwan Ltd. No. 134, Wu Kung Rd., Wuku Industrial Zone, Taipei Country, Taiwan. / 台北縣五股工業區五工路134號 台灣檢驗科技股份有限公司 t (886-2) 2299-3939 f (886-2) 2298-2698 www.sgs.com.tw 0513 ILAC MRA Front View of EUT Back View of EUT Report No: ER/2005/40006 ID: M65TR5C Issue Date: May 06, 2005 The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without prior written permission of the Company. SGS Taiwan Ltd. No. 134, Wu Kung Rd., Wuku Industrial Zone, Taipei Country, Taiwan. / 台北縣五股工業區五工路134號 台灣檢驗科技股份有限公司 t (886-2) 2299-3939 f (886-2) 2298-2698 www.sgs.com.tw 0513 ILAC MRA Side View of EUT

FCC ID LABEL FORMAT AND LOCATION Applicant: SuperNova Corp. FCC ID: M65TR5C FCC ID: M65TR5C This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC ID LABEL AREA

Report No: ER/2005/40006 ID: M65TR5C Issue Date: May 06, 2005 The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without prior written permission of the Company. SGS Taiwan Ltd. No. 134, Wu Kung Rd., Wuku Industrial Zone, Taipei Country, Taiwan. / 台北縣五股工業區五工路134號 台灣檢驗科技股份有限公司 t (886-2) 2299-3939 f (886-2) 2298-2698 www.sgs.com.tw 0513 ILAC MRA APPENDIX 3 PHOTOGRPHS OF EUT Report No: ER/2005/40006 ID: M65TR5C Issue Date: May 06, 2005 The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without prior written permission of the Company. SGS Taiwan Ltd. No. 134, Wu Kung Rd., Wuku Industrial Zone, Taipei Country, Taiwan. / 台北縣五股工業區五工路134號 台灣檢驗科技股份有限公司 t (886-2) 2299-3939 f (886-2) 2298-2698 www.sgs.com.tw 0513 ILAC MRA Internal of EUT – Open Report No: ER/2005/40006 ID: M65TR5C Issue Date: May 06, 2005 The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without prior written permission of the Company. SGS Taiwan Ltd. No. 134, Wu Kung Rd., Wuku Industrial Zone, Taipei Country, Taiwan. / 台北縣五股工業區五工路134號 台灣檢驗科技股份有限公司 t (886-2) 2299-3939 f (886-2) 2298-2698 www.sgs.com.tw 0513 ILAC MRA Internal of EUT – 1 Internal of EUT – 2 Report No: ER/2005/40006 ID: M65TR5C Issue Date: May 06, 2005 The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without prior written permission of the Company. SGS Taiwan Ltd. No. 134, Wu Kung Rd., Wuku Industrial Zone, Taipei Country, Taiwan. / 台北縣五股工業區五工路134號 台灣檢驗科技股份有限公司 t (886-2) 2299-3939 f (886-2) 2298-2698 www.sgs.com.tw 0513 ILAC MRA Internal of EUT – 3 Internal of EUT – 4

Operating Description This device is a transceiver. it is powered by 1.5Vdc battery and operating at 433.92 MHz frequency range for both RX and TX. The pulse modulation technologic was used and RF signal was transmitted when any button was pressed. The pulse repetition rate is 74.25ms, the duty cycle is about 0.3. The CPU U1 of transmitter will encode the pulse code for each key and modulated RF signal when any key was pressed. After key release the CPU U1 will stop encode and stop transmit signal at once. When the car station receive the signal from the remote the car station will return a RF signal to indicate the status.

Fi rr i .J! .I i Fi ni do .^ + r t lr |+tt. I It' -r t,. tE F{ 8i E EBf i? TEE 1 .= = - ?g"IF3 = ! ai:E irra=g rf xi .j Fi'J' 3.f: ,fr ,'-. cl c: Fl a.i rl rr ,:- U 7 :r ti) = r4 I it. -ir' € f\' (t- <- F-, '{ ,7 ; +.r l- * rr ^' !a ri € u) 7 !; ':- Fi f"l q? '.l d ct U "7 i< F1 _':.1 i i= I i-i i: a l= i- iJ i>< !\ / ti i=i i'l li t\ Vt = (D - 7 J t. IJ I Lt tJ l.z iJ :.- (t E rYl lsi I :-l :-l :1 !, :< l-' i rv i i>: i- !i-: 'r- l*r F t-, ; -\ i-. i> t=i : < l:'rl i- i=: 'l iet i, r-- )= I:' :: :-\ a : = i-j: r,-. t<: t: t.'.. ta, a: - i J i.-, l. i3:'::ifqqii{EfiFFrs=i ; F;iis=; F t.,-jiaa;_\ = :"Z7aeZZ Z? 'Z '=Z A = ii ='==33 7 ^a,a'24 -. gtrFE iF E rs- F FE =FF E C F Fr:9 j: - ., r,"z r- + - ir - c, .! ? !i,j...- +.- r, - c, I r I -l : z, \f I 9- te I l. I I i' I I t- IR t:: ---F --i:--i-:'i LCT) I

Report No: ER/2005/40006 ID: M65TR5C Issue Date: May. 06, 2005 Page: 1 of 25 The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without prior written permission of the Company. SGS Taiwan Ltd. No. 134, Wu Kung Rd., Wuku Industrial Zone, Taipei Country, Taiwan. / 台北縣五股工業區五工路134號 台灣檢驗科技股份有限公司 t (886-2) 2299-3939 f (886-2) 2298-2698 www.sgs.com.tw 0513 ILAC MRA ELECTROMAGNETIC EMISSIONS COMPLIANCE REPORT INTENTIONAL RADIATOR CERTIFICATION TO FCC PART 15 SUBPART C REQUIREMENT OF Product Name: 2-way system of car alarm system Brand Name: N/A Model Name: TR5C Model Differences: N/A FCC ID: M65TR5C Report No.: ER/2005/40006 Issue Date: May. 06, 2005 FCC Rule Part: §15.231 Prepared for SuperNova Corp. No. 34, Wu-Chuan 6 Rd.,Wu-Ku Industrial Zone, Wu-Ku Hsiang Taipei Taiwan R.O.C. Prepared by SGS Taiwan Ltd. No. 134, Wu Kung Rd., Wuku Industrial Zone, Taipei County, Taiwan. Note: This report shall not be reproduced except in full, without the written approval of SGS Taiwan Ltd. This document may be altered or revised by SGS Taiwan Ltd. personnel only, and shall be noted in the revision section of the document. Report No: ER/2005/40006 ID: M65TR5C Issue Date: May 06, 2005 Page: 2 The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without prior written permission of the Company. SGS Taiwan Ltd. No. 134, Wu Kung Rd., Wuku Industrial Zone, Taipei Country, Taiwan. / 台北縣五股工業區五工路134號 台灣檢驗科技股份有限公司 t (886-2) 2299-3939 f (886-2) 2298-2698 www.sgs.com.tw 0513 ILAC MRA VERIFICATION OF COMPLIANCE Applicant: SuperNova Corp. No. 34, Wu-Chuan 6 Rd.,Wu-Ku Industrial Zone, Wu-Ku Hsiang Taipei Taiwan R.O.C. Product Description: 2-way system of car alarm system FCC ID Number: M65TR5C Brand Name: N/A Model No.: TR5C Model Difference: N/A File Number: ER/2005/40006 Date of test: Apr. 23, 2005 ~ May. 03, 2005 Date of EUT received: Apr. 23, 2005 We hereby certify that: The above equipment was tested by SGS Taiwan Ltd. The test data, data evaluation, test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.4 (2003) and the energy emitted by the sample EUT tested as described in this report is in compliance with conducted and radiated emission limits of FCC Rules Part 15.231. The test results of this report relate only to the tested sample identified in this report. Test By: Date May 06, 2005 Sky Wang Prepared By: Date May 06, 2005 Elisa Chen Approved By Date May 06, 2005 Vincent Su Report No: ER/2005/40006 ID: M65TR5C Issue Date: May 06, 2005 Page: 3 The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without prior written permission of the Company. SGS Taiwan Ltd. No. 134, Wu Kung Rd., Wuku Industrial Zone, Taipei Country, Taiwan. / 台北縣五股工業區五工路134號 台灣檢驗科技股份有限公司 t (886-2) 2299-3939 f (886-2) 2298-2698 www.sgs.com.tw 0513 ILAC MRA Version Version No. Date 00 May 06, 2005 01 May 24, 2005 Report No: ER/2005/40006 ID: M65TR5C Issue Date: May 06, 2005 Page: 4 The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without prior written permission of the Company. SGS Taiwan Ltd. No. 134, Wu Kung Rd., Wuku Industrial Zone, Taipei Country, Taiwan. / 台北縣五股工業區五工路134號 台灣檢驗科技股份有限公司 t (886-2) 2299-3939 f (886-2) 2298-2698 www.sgs.com.tw 0513 ILAC MRA Table of Contents 1. GENERAL INFORMATION ........................................................................................... 6 1.1 PRODUCT DESCRIPTION................................................................................................................... 6 1.2 RELATED SUBMITTAL(S) / GRANT (S) .............................................................................................. 6 1.3 TEST METHODOLOGY....................................................................................................................... 6 1.4 TEST FACILITY................................................................................................................................. 6 2. SYSTEM TEST CONFIGURATION .............................................................................. 7 2.1 EUT CONFIGURATION...................................................................................................................... 7 2.2 EUT EXERCISE................................................................................................................................. 7 2.3 TEST PROCEDURE............................................................................................................................. 7 2.4 LIMITATION...................................................................................................................................... 8 2.5 CONFIGURATION OF TESTED SYSTEM............................................................................................ 10 3. SUMMARY OF TEST RESULTS ................................................................................. 11 4. DESCRIPTION OF TEST MODES .............................................................................. 11 5. CONDUCTED EMISSIONS TEST (NOT APPLY IN THE REPORT) .................... 12 5.1 MEASUREMENT PROCEDURE: ........................................................................................................ 12 5.2 TEST SET-UP (BLOCK DIAGRAM OF CONFIGURATION) ................................................................ 12 5.3 MEASUREMENT EQUIPMENT USED: ............................................................................................... 12 5.4 MEASUREMENT RESULT: ............................................................................................................... 12 6. RADIATED E…

Text truncated - open the document above for the full version.

Report No: ER/2005/40006 ID: M65TR5C Issue Date: May 06, 2005 The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without prior written permission of the Company. SGS Taiwan Ltd. No. 134, Wu Kung Rd., Wuku Industrial Zone, Taipei Country, Taiwan. / 台北縣五股工業區五工路134號 台灣檢驗科技股份有限公司 t (886-2) 2299-3939 f (886-2) 2298-2698 www.sgs.com.tw 0513 ILAC MRA APPENDIX 1 PHOTOGRPHS OF SET UP Report No: ER/2005/40006 ID: M65TR5C Issue Date: May 06, 2005 The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without prior written permission of the Company. SGS Taiwan Ltd. No. 134, Wu Kung Rd., Wuku Industrial Zone, Taipei Country, Taiwan. / 台北縣五股工業區五工路134號 台灣檢驗科技股份有限公司 t (886-2) 2299-3939 f (886-2) 2298-2698 www.sgs.com.tw 0513 ILAC MRA Radiated Emission Setup Photos
