M6JN0902Color Monitor

HR17 MultiSync HR19 MultiSync User‘s Manual HR17/HR19 MultiSync Printed in China 15500921 FCC GUIDELINES This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: ♦ Reorient or relocate the receiving antenna ♦ Increase the separation between the equipment and receiver ♦ Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. ♦ Consult the dealer or an experienced radio/TV technician for help. ♦ Use only shielded cables to connect I/O devices to this equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference. (2) This device must accept any interference received, including interference that may cause undesired operation. Information to User: F Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate this equipment. Shielded interface cable, if any, must be used in order to comply with emission limits. T T-1 TCO‘99 Congratulation! You have just purchased a TCO‘99 approved and labeled product! Your choice has provided you with a pro d u c t developed for professional use. Your purchase has also contributed to reducing the burden on the environment and also to the further development of environmentally adapted electronics products. Why do we have environmentally labelled computers? In many countries, environmental labelling has become an established method for encouraging the adaptation of goods and services to the environment. The main problem, as far as computers and other electronics equipment are concerned, is that environmentally harmful substances are used both in the products and during the manufacturing. Since it has not been possible for the majority of electronics equipment to be recycled in a satisfactory way, most of these potentially damaging substances sooner or later enter Nature. There are also other characteristics of a computer, such as energy consumption levels, that are important from the viewpoints of both the work (Internal) and natural (external) environments. Since all methods of conventional electricity generation have a negative effect on the environment (acidic and climate- influencing emissions, radioactive waste, etc.), it is vital to conserve energ y. E l e c t ronics equipment in offices consume an enormous amount of energy since they are often left running continuously. What does labelling involve? This product meets the requirements for the TCO‘99 scheme which provides for i n t e rnational and environmental labelling of personal computers. The labelling scheme was developed as a joint effort by the TCO (The Swedish Confederation of Professional Employees), Svenska Naturskyddsforeningen (The Swedish Society for Nature Conservation) and statens Energimyndighet (The Swedish National Energy Administration). The re q u i rements cover a wide range of issues: environment, erg o n o m i c s , u s a b i l i t y, emission of electrical and magnetic fields, energy consumption and electrical and fire safety. The environmental demands concern restrictions on the presence and use of heavy metals, brominated and chlorinated flame re t a rdants, CFCs (freons) and chlorinated solvents, among other things. The product must be pre p a red for recycling and the manufacturer is obliged to have an environmental plan which must be adhered to in each countr y where the company implements its operational policy. The energy requirements include a demand that the computer and/or display, after a certain period of inactivity, shall reduce its power consumption to a lower level in one or more stages. The length of time to reactivate the computer shall be reasonable for the user. Labelled products must meet strict environmental demands, for example, in respect of the reduction of electric and magnetic fields, physical and visual ergonomics and good usability. Environmental Requirements Flame retardants Flame retardants are present in printed circuit boards, cables, wires, casings and housings. In turn, they delay the spread of fire. Up to thirty percent of the plastic in a computer casing can consist of flame retar ant substances. Most flame retardants contain bromine or chloride and these are related to another group of e n v i ronmental toxins, PCB‘s, which are suspected to give rise to severe health Microsoft and Windows are registered trademarks of the Microsoft Corporation. ENERGY STAR is a U.S. registered mark. All other trademarks or registered trademarks are property of their respective owners. ENERGYSTAR ® Product This product meets the Energy Star guidelines for energy efficiency. The Energy Star emblem does not represent EPA endorsement of any product or service. CSA This Class B digital apparatus meets all requirements of the Canadian Interference-Causing Equipment Regulation. Cet appareil numerique de la class B respecte toutes les exigences du Reglement sur le materiel brouilleur du Canada. English Deutsch Français Español Italiano Dutch T-2 effects, including reproductive damage in fisheating birds and mammals, due to the bio-accumulative* processes. Flame re t a rdants have been found in human blood and researchers fear that…

Text truncated - open the document above for the full version.

N0902 BLOCK DIAGRAM Video Pre-AMP U201 Video Output AMP U203 OSD Process U202 Micro-Processor U701 Horizontal & Vertical Process U301 Vertical AMP Output U401 Horizontal Driver & Output T301, Q315, Q316 High Voltage Generator U302, U303, T302, Q306 Dynamic Focus Q305,t303 Voltage Regulator U102, Q113 Switch Power Supply U101, T101 R, G, B Input H/H+V V PS1 PS2 AC Input 80V 47V 15V 7V -12V 12V 5V G4 G2 H-DY V-DY R-OUT G-OUT B-OUT HV 2 EEPROM U702 BRIGHTNESS CONTROL Q329,Q323,VR304

(Photo 1) FCC ID: M6JN0902 (Photo 2) FCC ID: M6JN0902 1

REVISIONS ECN REV DESCRIPTIONDATE APPROVED HIGH VISCOSITY AND PERMANENT TYPE ADHESIVE ITEM MATERIAL THICKNESS THE KIND OF ADHESIVE ART WORK NUMBER THE MATERIAL TO BE ADHERED THE SURFACE CONDITION OF THE MATERIAL TO BE ADHERED ABS/PC+ABS FLAT t=0.1 POLYESTER FILM DESCRIPTION MATERIAL : 2F, NO.8, TUN HWA N. RD., TAIPEI, TAIWAN. R.O.C. TEL : (02)8733-5516 FAX : (02)2772-0502 DISPLAY LIMITED UNIT : mm. DATE : 90.05.21 P / No. : 1 PAST No. : PROJECT :(N0902) FILE NAME : PAST NAME : NAME PLATE INSTRUCTION SHEET : 1 / 1 SCALE : 1 / 1 DRAWN :CHECKED : =1Feb 20.2001 R2-4 SOPHIA 45 125 (NOTE) 1.) VENDOR MUST SUBMIT SAMPLE AND GAIN THE APPROVAL OF NPG ENGINEER BEFORE M.P. 2.) TO BE PRINTED MARK OF PROOF OF MANUFACTURED BY A FACTORY APPROVED BY C.S.A. 3.) REGARDING COMBINED CONDITION WHICH ARE ADHEREND(POLYSTYRENE)& LABEL  MATERIAL (POLYESTER FILM) TO BE PRINTED THE APPROVED TYPE NAME OF UL. 4.) COLOR OF LETTER AND FRAME: SILVER (PRINTABLE SURFACE) 5.) BASE COLOR AND INSIDE FRAME: BLACK CSA/UL MARK FOR VENDOR U L ® C US LISTED I.T.E. 92UJ E173835 100-240V~ 50-60Hz 2.2A N0902 CAUTION:TO Prevent electric shock, do not remove back cover. No user serviceable parts inside. Refer servicing to qualified service personnel. This device complies with part 15 of the FCC Rules. Operation is subject to the following conditions:(1) this device may not cause harmful interference. and (2) this device must accept any interference received, including interference that may cause undesired operation. This product complies with DHHS Rules 21CFR ,Subchapter J applicable at date of manufacture. Die erzeugten Röntgenstrahlen Werden durch die eigensichere Kathodenstrahlröhre ausreichend abgeschirmt. Nach Röv vom 08.01.1987 Anlage lll. Anodenspannung:max 29KV Apparatet må kun tilkoples jordet stikkontakt. Apparaten skall anslutas till jordat uttag när den ansluts till ett nätverk. Complies with Canadian ICES-003 Class B Conforme a la NMB-003 Class B NPG DISPLAY LTD.TAIWAN BRANCH 2F,NO.8,TUN HWA N.RD.,TAIPEI,TAIWAN.R.O.C. 720NP Made in China FCC ID : M6JN0902

(Fig. 1) FCC ID: M6JN0902 FCC LABEL LOCATION The label will be permanently affixed at a conspicuous location on the device. Label

(Photo 3) FCC ID: M6JN0902 (Photo 4) FCC ID: M6JN0902 (Photo 5) FCC ID: M6JN0902 2 (Photo 6) FCC ID: M6JN0902 2 (Photo 7) FCC ID: M6JN0902 3 (Photo 8) FCC ID: M6JN0902 6 1 7 5 8 9 3 4

(Photo 9) FCC ID: M6JN0902 (Photo 10) FCC ID: M6JN0902 (Photo 11) FCC ID: M6JN0902 (Photo 12) FCC ID: M6JN0902 (Photo 13) FCC ID: M6JN0902 10

(Photo 14) FCC ID: M6JN0902 (Photo 15) FCC ID: M6JN0902 (Photo 16) FCC ID: M6JN0902 (Photo 17) FCC ID: M6JN0902 (Photo 18) FCC ID: M6JN0902 11

(Photo 19) FCC ID: M6JN0902 (Photo 20) FCC ID: M6JN0902 (Photo 21) FCC ID: M6JN0902 12 (Photo 22) FCC ID: M6JN0902 12 (Photo 23) FCC ID: M6JN0902 13

(Photo 29) FCC ID: M6JN0902 (Photo 30) FCC ID: M6JN0902 23 23 (Photo 31) FCC ID: M6JN0902 (Photo 32) FCC ID: M6JN0902 (Photo 33) FCC ID: M6JN0902

FCC ID: M6JN0902 Report No.: F900425011Issued: May 17, 2001 FCC TEST REPORT REPORT NO.: F90042501 MODEL NO.: N0902 RECEIVED: April 25, 2001 TESTED: May 5, 2001 APPLICANT:NPG Display LTD., Taiwan Branch ADDRESS:2FL-1, No. 8, Tunhua N. Rd., Taipei, Taiwan, R.O.C. ISSUED BY:Advance Data Technology Corporation LAB LOCATION:47 14th Lin, Chiapau Tsun, Linko, Taipei, Taiwan, R.O.C. This test report consists of 23 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by NVLAP or any U.S. government agencies. The test results in the report only apply to the tested sample. The test results in this report are traceable to the national or international standards. 0528 Lab Code: 200102-0 FCC ID: M6JN0902 Report No.: F900425012Issued: May 17, 2001 Table of Contents 1CERTIFICATION............................................................................................. 3 2SUMMARY OF TEST RESULTS..................................................................... 4 3GENERAL INFORMATION ............................................................................. 5 3.1GENERAL DESCRIPTION OF EUT ............................................................... 5 3.2DESCRIPTION OF TEST MODES ................................................................. 5 3.3DESCRIPTION OF SUPPORT UNITS............................................................ 6 4EMISSION TEST ............................................................................................ 7 4.1CONDUCTED EMISSION MEASUREMENT .................................................. 7 4.1.1 LIMITS OF CONDUCTED EMISSION MEASUREMENT ............................... 7 4.1.2 TEST INSTRUMENTS .................................................................................... 7 4.1.3 TEST PROCEDURE ....................................................................................... 8 4.1.4 DEVIATION FROM TEST STANDARD ........................................................... 8 4.1.5 TEST SETUP .................................................................................................. 8 4.1.6 EUT OPERATING CONDITIONS.................................................................... 9 4.1.7 TEST RESULTS (A) ...................................................................................... 10 4.1.8 TEST RESULTS (B) ...................................................................................... 12 4.2RADIATED EMISSION MEASUREMENT ..................................................... 14 4.2.1 LIMITS OF RADIATED EMISSION MEASUREMENT .................................. 14 4.2.2 TEST INSTRUMENTS .................................................................................. 15 4.2.3 TEST PROCEDURE ..................................................................................... 15 4.2.4 DEVIATION FROM TEST STANDARD ......................................................... 16 4.2.5 TEST SETUP ................................................................................................ 16 4.2.6 EUT OPERATING CONDITIONS.................................................................. 16 4.2.7 TEST RESULTS (A) ...................................................................................... 17 4.2.8 TEST RESULTS (B) ...................................................................................... 19 5PHOTOGRAPHS OF THE TEST CONFIGURATION ................................... 21 6APPENDIX - INFORMATION ON THE TESTING LABORATORIES............. 23 FCC ID: M6JN0902 Report No.: F900425013Issued: May 17, 2001 1 CERTIFICATION PRODUCT:19” CRT COLOR MONITOR BRAND NAME:NEC MODEL NO:N0902 TEST ITEM:ENGINEERING SAMPLE APPLICANT:NPG Display LTD., Taiwan Branch STANDARDS:FCC Part 15, Subpart B, Class B CISPR 22: 1997, Class B ANSI C63.4-1992 We, Advance Data Technology Corporation, hereby certify that one sample of the designation has been tested in our facility on May 5, 2001. The test record, data evaluation and Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample's EMC characteristics under the conditions herein specified. FCC ID: M6JN0902 Report No.: F900425014Issued: May 17, 2001 2 SUMMARY OF TEST RESULTS The EUT has been tested according to the following specifications: StandardTest TypeResultRemarks Conducted TestPASS Meets Class B Limit Minimum passing margin is –2.9 dB at 22.800 MHz FCC Part 15, Subpart B, CISPR 22: 1997, Class B Radiated TestPASS Meets Class B Limit Minimum passing margin is –3.1 dB at 57.29 MHz NOTE: For conducted emission test, the test limit used is according to FCC Part 15.107. In this part, conducted emission test for telecom port is not mentioned and therefore this item is not tested. FCC ID: M6JN0902 Report No.: F900425015Issued: May 17, 2001 3 GENERAL INFORMATION 3.1 GENERAL DESCRIPTION OF EUT PRODUCT19” CRT COLOR MONITOR MODEL NO.N0902 POWER SUPPLY Switching Power Cord: Non-shielded, 3 pin, AC (1.8m) DATA CABLEShielded (1.8m) with a ferrite core NOTE: The EUT is a 19” CRT color monitor with resolution up to 1600x1200. The EUT has two types of CRT: SAMSUNG and MITSUBISHI. Both were tested separately and their data are recorded in this report. For a more detailed features description, please refer to the manufacturer's specifications or the User's Manual. 3.2 DESCRIPTION OF TEST MODES The EUT was pre-tested under the following resolution & horizontal synchronization speed mode: - 1600x1200 mode (85Hz/106kHz), - 1280x1024 mode (85Hz/91kHz), - 640x480 mode (60Hz/31kHz) The worst emission levels were found under 1600x1200 (85Hz/106kHz). Therefore for the final test, the EUT was tested with the following modes: MODE 1 – SAMSUNG CRT MODE 2 – MITSUBISHI CRT FCC ID: M6JN0902 Report No.: F900425016Issued: May 17, 2001 3.3 DESCRIPTION OF SUPPORT UN…

Text truncated - open the document above for the full version.

FCC ID: M6JN0902 Report No.: F9004250121Issued: May 17, 2001 5 PHOTOGRAPHS OF THE TEST CONFIGURATION CONDUCTED EMISSION TEST FCC ID: M6JN0902 Report No.: F9004250122Issued: May 17, 2001 RADIATED EMISSION TEST
