M8QS63227TXRC Toy Transmitter

PHOTOGRAPH OF THE PRODUCT FRONT VIEW OF THE PRODUCT REAR VIEW OF THE PRODUCT

LABEL LOCATION BOTTOM VIEW OF THE DEVICE WITH FCC ID LABEL FCC ID Label

PHOTOGRAPH OF THE PRODUCT INNER CIRCUIT TOP VIEW INNER CIRCUIT BOTTOM VIEW

FCC ID: M8QS63227TX Circuit Description The 27.145MHz crystal oscillator drives the base of Q3 the final/buffer amplifier. The modulation provided by Q1 and Q2. The output of Q3 has the matching network consisting of LX and CX that limit the harmonic content and effect the proper coupling of the antenna to the output stage. Antenna, Ground and Power Source The antenna consists of a 12.3cm long telescoping chrome over brass tubing. There is no external ground connection. The ground is only that of the printed circuit board. Electric current is supplied by a 9 Volt (“6F22” size battery x 1) primary battery

Date: 2004-06-19 TEST REPORT Page 1 of 18 No.: HM151299 This report shall not be reproduced unless with prior written approval from the Hong Kong Standards and Testing Centre. Applicant: Ngai Keung Metal & Plastic Manufactory Ltd. Description of Samples: Model name: 1:32 Radio Control Nintendo (Mario/Donkey Kong/Yoshi) (27MHz) Model no.: 63201 Brand name: Ngai Keung Metal & Plastic Manufactory Ltd. FCC ID: M8QS63227TX Date Samples Received: 2004-03-29 Date Tested: 2004-04-19 Investigation Requested: FCC Part 15 Subpart C Conclusions: The submitted product COMPLIED with the requirements of Federal Communications Commission [FCC] Rules and Regulations Part 15. The tests were performed in accordance with the standards described above and on Section 2.2 in this Test Report. Remarks: ---- K C Lee, EMC for Chief Executive Date: 2004-06-19 TEST REPORT Page 2 of 18 No.: HM151299 CONTENT: Cover Page 1 of 18 Content Page 2-3 of 18 1.0 General Details 1.1 Test Laboratory Page 4 of 18 1.2 Applicant Details Page 4 of 18 Applicant HKSTC Code Number for Applicant Manufacturer 1.3 Equipment Under Test [EUT] Page 5 of 18 Description of EUT operation 1.4 Date of Order Page 5 of 18 1.5 Submitted Samples Page 5 of 18 1.6 Test Duration Page 5 of 18 1.7 Country of Origin Page 5 of 18 1.8 Additional Information of EUT Page 6 of 18 2.0 Technical Details 2.1 Investigations Requested Page 7 of 18 2.2 Test Standards and Results Summary Page 7 of 18 3.0 Test Results 3.1 Emission Page 8-11 of 18 3.2 Bandwidth Measurement Page 12-13 of 18 Date: 2004-06-19 TEST REPORT Page 3 of 18 No.: HM151299 Appendix A List of Measurement Equipment Page 14 of 18 Appendix B Duty Cycle Correction During 100 msec Page 15-16 of 18 Appendix C Photographs Page 17-18 of 18 Date: 2004-06-19 TEST REPORT Page 4 of 18 No.: HM151299 1.0 General Details 1.1 Test Laboratory The Hong Kong Standards and Testing Centre Ltd. EMC Laboratory 10 Dai Wang Street, Taipo Industrial Estate New Territories, Hong Kong Telephone: 852 2666 1888 Fax: 852 2664 4353 1.2 Applicant Details Applicant Ngai Keung Metal & Plastic Manufactory Ltd. Room 1108-1112 Harbour Crystal Centre, 100 Granville Road, TST., East Kowloon HKSTC Code Number for Applicant NGK003 Manufacturer Ngai Keung Metal & Plastic Manufactory Ltd. Room 1108-1112 Harbour Crystal Centre, 100 Granville Road, TST., East Kowloon Date: 2004-06-19 TEST REPORT Page 5 of 18 No.: HM151299 1.3 Equipment Under Test [EUT] Description of Sample Model Name: 1:32 Radio Control Nintendo (Mario/Donkey Kong/Yoshi) (27MHz) Manufacturer: Ngai Keung Metal & Plastic Manufactory Ltd. Brand Name: Ngai Keung Metal & Plastic Manufactory Ltd. Model Number: 63201 Input Voltage: 9Vd.c (“6F22” size battery x 1) Additional Model Number: 63202/63203 1.3.1 Description of EUT Operation The Equipment Under Test (EUT) is a Ngai Keung Metal & Plastic Manufactory Ltd., 1:32 Radio Control Nintendo (Mario/Donkey Kong/Yoshi) (27MHz). The transmitter is a 2 button transmitter. The EUT continues to transmit while button is being pressed, Modulation by IC. and type is pulse modulation. 1.4 Date of Order 2004-03-29 1.5 Submitted Sample(s): 3 Samples per model 1.6 Test Duration 2004-04-19 1.7 Country of Origin China Date: 2004-06-19 TEST REPORT Page 6 of 18 No.: HM151299 1.8 Additional Information of EUT Submitted Not Available User Manual Part List Circuit Diagram Printed Circuit Board [PCB] Layout Block diagram FCC ID Label Date: 2004-06-19 TEST REPORT Page 7 of 18 No.: HM151299 2.0 Technical Details 2.1 Investigations Requested Perform ElectroMagnetic Interference measurement in accordance with FCC 47CFR [Codes of Federal Regulations] Part 15 and ANSI C63.4:2003 for FCC Certification. 2.2 Test Standards and Results Summary Tables EMISSION Results Summary Test Condition Test Requirement Test Method Class / Test Result Severity Pass Failed N/A Field Strength of Fundamental Emissions & Spurious Emissions FCC 47CFR 15.227 ANSI C63.4:2003 N/A Radiated Emissions, 30MHz to 1GHz FCC 47CFR 15.209 ANSI C63.4:2003 Class B Conducted Emissions on AC, 0.15MHz to 30MHz FCC 47CFR 15.207 ANSI C63.4:2003 Class B Note: N/A - Not Applicable Date: 2004-06-19 TEST REPORT Page 8 of 18 No.: HM151299 3.0 Test Results 3.1 Emission 3.1.1 Radiated Emissions (30 – 1000MHz) Test Requirement: FCC 47CFR 15.227 Test Method: ANSI C63.4:2003 Test Date: 2004-04-19 Mode of Operation: On mode Test Method: The sample was placed 0.8m above the ground plane on the OATS *. Measurements in both horizontal and vertical polarities were performed. During the test, each emission was maximized by: having the EUT continuously working, investigated all operating modes, rotated about all 3 axis (X, Y & Z) and considered typical configuration to obtain worst position, manipulating interconnecting cables, rotating turntable, varying antenna height from 1m to 4m in both horizontal and vertical polarizations. The emissions worst-case are shown in Test Results of the following pages. *: OATS [Open Area Test Site] located at HKSTC with a metal ground plane filed with the FCC pursuant to section 2.948 of the FCC rules, with Registration Number: 90657. Test Setup: EUT Pre-Amplifier Distance = 3m Receiver Turn Table Computer Ground Plane Date: 2004-06-19 TEST REPORT Page 9 of 18 No.: HM151299 Limits for Field Strength of Fundamental Emissions [FCC 47CFR 15.227]: Frequency Range of Fundamental Field Strength of Fundamental Emission [Peak] Field Strength of Fundamental Emission [Average] [MHz] [μV/m] [μV/m] 26.96-27.28 100,000 10,000 Results: FrequencyCorrectionLimit @3mE-Field FactorPolarity MHzdBμV/mμV/m 27.1529.3021.951.2363.1100,000Vertical μV/mdBμV/m Field Strength dBμV/m Field Strength of Fundamental Emissions Peak Value Measured Level @3m Field Strength FrequencyAdjusted byCorrectionLimit @3mE-Field Duty CycleFactorPolarity MHzdBdBμV/mμV/m 27.1525.0-4.321.946.9221.310,000Vertical Field Strength of Fundamental Emissions Average Measured Level @3m Field Strength μV/mdBμV/m Field Strength dBμV/m Acc…

Text truncated - open the document above for the full version.

TEST SET UP PHOTOGRAPH OF THE PRODUCT MEASUREMENT OF RADIATED EMISSION TEST SET UP
