MBH-CLT99XXN900 MHz Cordless Phone

I NTRODUCTION CAUTION: When using telephone equipment, there are basic safety instructions that shouldalways be followed. Refer to the IMPORTANTSAFETY INSTRUCTIONS provided with thisproduct and save them for future reference. Your Caller ID phone stores and displays specificinformation, provided by your local telephone company, tosubscribers of Caller ID or similar caller identificationservices.Your Caller ID phone enables you to:• Identify callers before you answer the phone.• View the time and date of each incoming call.• Record up to 40 Caller ID messages sequentially.• Know who called while you were away.To get the most from your new phone, we suggest thatyou take a few minutes right now to read through thisuser's guide. IMPORTANT: In order to use all of the features of this phone, you must subscribe to either the standardName/Number Caller ID Service or Call WaitingCaller ID Service. To know who is calling while you areon the phone, you must subscribe to Call WaitingCaller ID Service.IMPORTANT: Because cordless phones operate on electricity, you should have at least one phone in yourhome that isn’t cordless, in case the power in yourhome goes out. B EFORE Y OU B EGIN P ARTS C HECKLIST Make sure your package includes the items shown here. I NSTALLATION D ESKTOP I NSTALLATION NOTE : The handset can be charged facing up or down. 1. Set the RINGER switch (on the handset) to ON and place the handset in the cradle on the base. 2. Plug the power supply into the power jack on the bottom of the base and the other end into an electricaloutlet. The in use/charge indicator comes on, verifyingthe battery is charging.Allow the phone to charge for 12 hours prior to first use.If you don't properly charge the phone, batteryperformance will be compromised. NOTE: DO NOT connect the telephone line to the modular jack until the phone has charged for 12 hours. 3. Plug the telephone line cord into the PHONE LINE jack on the bottom of the base and into a modular jack. CAUTION: Use only the SANYO Canada Inc. power supply that came with this unit. Usingother power supplies may damage the unit. NOTE: The phone automatically defaults to touch- tone dialing. To change to pulse (rotary) dialing, see"TONE/PULSE DIALING." If you don't know whichtype of service you have, check with your localtelephone company. W ALL M OUNT I NSTALLATION Because it is necessary to charge the handset for 12 hoursprior to connecting the phone for use the first time, it isbetter to leave the unit on a flat surface during initialcharge before attempting to hang it on the wall.1. Set the RINGER switch (on the handset) to ON and place the handset in the cradle on the base. 2. Plug the power supply into the power jack on the bottom of the base and the other end into an electricaloutlet. The in use/charge indicator comes on, verifyingthe battery is charging.Allow the phone to charge for 12 hours prior to first use.If you don't properly charge the phone, batteryperformance will be compromised. NOTE: DO NOT connect the telephone line to the modular jack until the phone has charged for 12 hours. 3. Plug the telephone line cord into the PHONE LINE jack on the bottom of the base and the other end into a modular jack. 4. Slip the mounting holes on the bracket over the wall plate posts and firmly slide the unit down into place(wall plate not included). 5. Place the handset in the cradle. NOTE: If desired, gather the extra line cord together, and fasten with a wire tie. NOTE: The phone automatically defaults to touch- tone dialing. To change to pulse (rotary) dialing,see "TONE/PULSE DIALING." If you don't knowwhich type of service you have, check with thephone company. CAUTION: Use only the SANYO Canada Inc. power supply that came with this unit. Usingother power supplies may damage the unit. S ET U P There are three programmable menus available: Language,Tone/Pulse Dialing and Area Code.L ANGUAGE S ETTING 1. Make sure the phone is OFF (not in TALK mode). 2. Press the flash/program button until “ 1ENG 2FRA 3ESP” shows in the display. “1ENG” is the default setting. 3. Use the CID/VOL left (-) or right (+) arrow button to scroll to 1ENG 2FRA 3ESP, or use the touch tonepad on the handset to enter the desired setting. Forexample, to choose English, press the number 1 key.1ENG is the default setting. 4. Press flash/program to store selection. You will hear a confirmation tone. T ONE /P ULSE D IALING 1. Make sure the phone is OFF (not in TALK mode). 2. Press the flash/program button until “ 1TONE 2PULSE” shows in the display. “1TONE” is the default setting. 3. Use the CID/VOL left (-) or right (+) arrow button to scroll to 1TONE or 2PULSE, or use the touch tonepad on the handset to enter the desired setting. Forexample, to choose TONE dialing, press the number 1key. 1TONE is the default setting. 4. Press flash/program to store selection. You will hear a confirmation tone. A REA C ODE S ETTING 1. Make sure the phone is OFF (not in TALK mode). 2. Press the flash/program but ton until “- - - SET AREA CODE” shows in the display. “ - - -” is the default setting. 3. Use the handset number pad to enter your three digit area code. 4. Press flash/program to store selection. You will hear a confirmation tone. C ORDLESS P HONE B ASICS M AKING A C ALL To make a call, press the TALK button before you dial andpress it again to hang up.R EDIAL While the phone is on, press the redial button to redial thelast number you dialed (up to 32 digits). If you get a busysignal, and want to keep dialing the number, just press redialagain (you don't have to turn the phone off and back on).F LASH Use the flash/program button to activate custom callingservices such as call waiting or call transfer, whichare available through your local phone company. TIP: Don’t use the TALK button to activate custom calling services such as call waiting, or you’ll hang upthe phone. I N U SE I NDICATOR L IGHT The in use indicator is lit when the handset is charging inthe cradle on the base or when th…

Text truncated - open the document above for the full version.

August 14, 2002 FEDERAL COMMUNICATIONS COMMISSION 7435 Oakland Mills Road Columbia, MD 21046 U.S.A. Subject: Request for withholding from public disclosure the schematic diagrams and system block diagrams pursuant to an application for certification. Applicant:SANYO CANADA INC. Product:Cordless Telephone Model:CLT-9910, CLT-9915, CLT-9922, CLT-9925 and CLT-9935 FCC ID:MBH-CLT99XX Dear Sir/Madam, We, SANYO CANADA INC., would like to request that the schematic diagrams, system block diagrams, part lists and technical description, submitted with the application for certification be withheld from public disclosure as per Section 0.459 of FCC Rules. This request is made under the provisions of Section 0.457(d) of the Commission's Rules, and Section 552(b)(4) of the Freedom of Information Act. These sections authorize as a withholding from public inspection materials which would be privileged as a matter of law if retained by the person submitting them, and materials which would not customarily be released to the public by that person. If you have any queries, please do not hesitate to contact us by our telephone number: OUR TELEPHONE NO.:905-760-4051 Yours truly, Akio Ichimori Vice President, Engineering SANYO Canada Inc.

Feb. 10, 2003 TIMCO ENGINEERING INC. P O BOX 370 849 N.W. STATE ROAD 45 NEWBERRY, FLORIDA USA 32669 Subject:Certification Application under FCC Part 15, Subpart C, Para. 15.249, Low Power Transmitters Operating in the Frequency Band 902-928 MHz. Applicant:Sanyo Canada Inc. Product:SANYO CORDLESS TELEPHONE Model:CLT-9936, CLT-9936B, CLT-9935N, CLT-9935BN, CLT-9926, CLT-9926W, CLT- 9925N, CLT-9923, CLT-9922N, CLT-9916, CLT-9915N, CLT-9911, CLT-9910N FCC ID:MBH-CLT99XXN Dear Sir/Madam, As appointed agent for Sanyo Canada Inc., we would like to submit the application for FCC certification of the above product. Please review all necessary files uploaded to FCC OET site for detailed information. Please not that all Models are identical except for the electronic options and colors. The Model CLT-9935N which has the full options was tested to represent the worst case among all models. If you have any queries, please do not hesitate to contact us by our TOLL FREE numbers: OUR TELEPHONE NO.:1-877-765-4173 Yours truly, Tri Minh Luu, P. Eng., V.P., Engineering TML/AK Encl. UltraTech Group of Labs 31040/SIT C-1376 46390-2049 200093-0 2 00-034 3000 Bristol Circle, Oakville, Ontario, Canada L6H 6G4 Tel.: (905) 829-1570 Fax.: (905) 829-8050 Website: www.ultratech-labs.com Email: [email protected]

ANNEX 3 - EXTERNAL PHOTOGRAPHS OF EUTPHOTO # 1 SANYO CORDLESS TELEPHONES,MODELS: CLT-9936, CLT-9936B, CLT-9935N, CLT-9935BN, CLT-9926, LT-9926W, CLT-9925N, CLT-9923, CLT-9922N, CLT-9916, CLT-9915N, CLT-9911, CLT-9910N IC: 339A-CLT99XXNFCC ID: MBH-CLT99XXN ANNEX 3 - EXTERNAL PHOTOGRAPHS OF EUTPHOTO # 2 SANYO CORDLESS TELEPHONES,MODELS: CLT-9936, CLT-9936B, CLT-9935N, CLT-9935BN, CLT-9926, LT-9926W, CLT-9925N, CLT-9923, CLT-9922N, CLT-9916, CLT-9915N, CLT-9911, CLT-9910N IC: 339A-CLT99XXNFCC ID: MBH-CLT99XXN ANNEX 3 - EXTERNAL PHOTOGRAPHS OF EUTPHOTO # 3 SANYO CORDLESS TELEPHONES,MODELS: CLT-9936, CLT-9936B, CLT-9935N, CLT-9935BN, CLT-9926, LT-9926W, CLT-9925N, CLT-9923, CLT-9922N, CLT-9916, CLT-9915N, CLT-9911, CLT-9910N IC: 339A-CLT99XXNFCC ID: MBH-CLT99XXN ANNEX 3 - EXTERNAL PHOTOGRAPHS OF EUTPHOTO # 4 SANYO CORDLESS TELEPHONES,MODELS: CLT-9936, CLT-9936B, CLT-9935N, CLT-9935BN, CLT-9926, LT-9926W, CLT-9925N, CLT-9923, CLT-9922N, CLT-9916, CLT-9915N, CLT-9911, CLT-9910N IC: 339A-CLT99XXNFCC ID: MBH-CLT99XXN

FCC ID: MBH-CLT99XXN

ANNEX 4 - INTERNAL PHOTOGRAPHS OF BASE UNITPHOTO # 1 SANYO CORDLESS TELEPHONES,MODELS: CLT-9936, CLT-9936B, CLT-9935N, CLT-9935BN, CLT-9926, LT-9926W, CLT-9925N, CLT-9923, CLT-9922N, CLT-9916, CLT-9915N, CLT-9911, CLT-9910N IC: 339A-CLT99XXNFCC ID: MBH-CLT99XXN ANNEX 4 - INTERNAL PHOTOGRAPHS OF BASE UNITPHOTO # 2 SANYO CORDLESS TELEPHONES,MODELS: CLT-9936, CLT-9936B, CLT-9935N, CLT-9935BN, CLT-9926, LT-9926W, CLT-9925N, CLT-9923, CLT-9922N, CLT-9916, CLT-9915N, CLT-9911, CLT-9910N IC: 339A-CLT99XXNFCC ID: MBH-CLT99XXN ANNEX 4 - INTERNAL PHOTOGRAPHS OF BASE UNITPHOTO # 3 SANYO CORDLESS TELEPHONES,MODELS: CLT-9936, CLT-9936B, CLT-9935N, CLT-9935BN, CLT-9926, LT-9926W, CLT-9925N, CLT-9923, CLT-9922N, CLT-9916, CLT-9915N, CLT-9911, CLT-9910N IC: 339A-CLT99XXNFCC ID: MBH-CLT99XXN ANNEX 4 - INTERNAL PHOTOGRAPHS OF BASE UNITPHOTO # 4 SANYO CORDLESS TELEPHONES,MODELS: CLT-9936, CLT-9936B, CLT-9935N, CLT-9935BN, CLT-9926, LT-9926W, CLT-9925N, CLT-9923, CLT-9922N, CLT-9916, CLT-9915N, CLT-9911, CLT-9910N IC: 339A-CLT99XXNFCC ID: MBH-CLT99XXN

900M RF Module ALIGNMENT REPORTED BY : G.C.KO STEPACTIONADJUSTREADINGS 1BASE TX a) power on and set the test mode(21ch)1.4 V T2 ( TX VCO ) b) check the TX power. TX pwr : - 1 + 2 dBm c) if TX power spec in , it not be solder J1 d) if TX power is low , it must be solder J1solderJI e) check the TX freq.VR1 TX fre : 903.80 MZH + 1KHZ f) check the deviation on modulation, whether 12K + 1.0 KHZ or not Dev : 12 + 1.0 KHZ set 75 mV at pin number 1 of CON2 ( AF _ IN ) g) if Mod. Dev is spec in, it not be solder J2 h) if Mod. Dev is low, it must be solder J2solderJ2 i) check the data modulation. Dev : 15 + 1 KHZ 2BASE RX a) power on and set the test mode(21ch). 1.4 VT1 ( RX VCO ) b) check the RX sens(12dB SINAD). RX sens : < -108dBm condition : 1) RF input level -47dBm / Dev 12KHZ c) check the Audio output level. Audio out : 220 + 20 mV 3HANDSET TX a) power on and set the test mode(21ch) 1.4 V T2 ( TX VCO ) b) check the TX power. TX pwr : 0 + 2 dBm c) if TX power spec in , it not be solder J1 d) if TX power is low , it must be solder J1solderJI e) check the TX freq.VR1 TX fre : 926.30 MZH + 1KHZ f) check the deviation on modulation, whether 12.0 + 1.0 KHZ or not Dev : 12 + 1.0 KHZ set 75 mV at pin number 1 of CON2 ( AF _IN ) g) if Mod. Dev is spec in, it not be solder J2 h) if Mod. Dev is low, it must be solder J2solderJ2 i) check the data modulation. Dev : 15 + 1 KHZ 4HANDSET RX a) power on and set the test mode(21ch). 1.4 VT1 ( RX VCO ) b) check the RX sens(12dB SINAD). RX sens : < -108dBm condition : 1) RF input level -47dBm / Dev 12KHZ c) check the Audio output level. Audio out : 220 + 20mV

Jan. 24, 2003 Sanyo E.T. Canada Inc. 300 Applewood Cres. Concord, Ontario Canada, L4K 5C7 Attn.:Mr. Akio Ichimori Subject:Certification Testing in accordance with FCC CFR 47, Part 15, Subpart B - Class B Unintentional Radiators and Radio Receivers Operating in the frequency bands 902.8 - 927.25 MHz. Product:SANYO CORDLESS TELEPHONE Model:CLT-9936, CLT-9936B, CLT-9935N, CLT-9935BN, CLT-9926, CLT-9926W, CLT-9925N, CLT-9923, CLT-9922N, CLT-9916, CLT-9915N, CLT-9911, CLT-9910N Dear Mr. Ichimori, The product sample has been tested in accordance with FCC CFR 47, Part 15, Subpart B - Class B Unintentional Radiators and Radio Receivers Operating in the frequency bands 902.8 - 927.25 MHz, and the results and observation were recorded in the engineering report, Our File No.: SAN-078FCC15B Enclosed you will find copies of the engineering report. If you have any queries, please do not hesitate to contact us. Yours truly, Tri Minh Luu, P.Eng Vice President - Engineering Encl. UltraTech Group of Labs 31040/SIT C-1376 46390-2049 200093-0 2 00-034 3000 Bristol Circle, Oakville, Ontario, Canada L6H 6G4 Tel.: (905) 829-1570 Fax.: (905) 829-8050 Website: www.ultratech-labs.com Email: [email protected] SANYO CORDLESS TELEPHONE Model No.: CLT-9936, CLT-9936B, CLT-9935N, CLT-9935BN, CLT- 9926, CLT-9926W, CLT-9925N, CLT-9923, CLT-9922N, CLT-9916, CLT-9915N, CLT-9911, CLT-9910N Applicant: Sanyo E.T. Canada Inc. 300 Applewood Cres. Concord, Ontario Canada, L4K 5C7 Tested in Accordance With Federal Communications Commission (FCC) CFR 47, Part 15, Subpart B Class B Unintentional Radiators & Radio Receivers operating in the Frequency Band 902.8 - 927.25 MHz UltraTech's File No.: SAN-078FCC15B This Test report is Issued under the Authority of Tri M. Luu, Professional Engineer, Vice President of Engineering UltraTech Group of Labs Date: Jan. 24, 2003 Report Prepared by: Tri LuuTested by: Hung Trinh, EMI/RFI Technician Issued Date: Jan. 24, 2003Test Dates: Jan. 11, 2003 ß The results in this Test Report apply only to the sample(s) tested, and the sample tested is randomly selected. ß This report must not be used by the client to claim product endorsement by NVLAP or any agency of the US Government. UltraTech 3000 Bristol Circle, Oakville, Ontario, Canada, L6H 6G4 Tel.: (905) 829-1570 Fax.: (905) 829-8050 Website: www.ultratech-labs.com Email: [email protected], Email: [email protected] 2 31040/SITC-137646390-2049200093-000-034 FCC PART 15, SUBPART B, CLASS B UNINTENTIONAL RADIATORS AND RADIO RECEIVERS Page 1 SANYO CORDLESS TELEPHONESModel No.: CLT-9936, CLT-9936B, CLT-9935N, CLT-9935BN, CLT-9926, CLT-9926W, CLT-9925N, CLT-9923, CLT-9922N, CLT-9916, CLT-9915N, CLT-9911, CLT-9910N ULTRATECH GROUP OF LABSFile #: SAN-078FCC15B 3000 Bristol Circle, Oakville, Ontario, Canada L6H 6G4Jan. 24, 2003 Tel. #: 905-829-1570, Fax. #: 905-829-8050, Email: [email protected], Website: http://www.ultratech-labs.com ß All test results contained in this engineering test report are traceable to National Institute of Standards and Technology (NIST) TABLE OF CONTENTS EXHIBIT 1.INTRODUCTION.............................................................................................................................................................3 1.1.SCOPE..............................................................................................................................................................................................3 1.2.RELATED SUBMITAL(S)/GRANT(S)...............................................................................................................................................3 1.3.NORMATIVE REFERENCES........................................................................................................................................................3 EXHIBIT 2.PERFORMANCE ASSESSMENT.................................................................................................................................4 2.1.CLIENT INFORMATION...............................................................................................................................................................4 2.2.EQUIPMENT UNDER TEST (EUT) INFORMATION..................................................................................................................4 2.3.EUT’S TECHNICAL SPECIFICATIONS.....................................................................................................................................6 2.4.LIST OF EUT’S PORTS.....................................................................................................................................................................6 2.5.ANCILLARY EQUIPMENT..............................................................................................................................................................6 2.6.GENERAL TEST SETUP................................................................................................................................................................7 EXHIBIT 3.EUT OPERATING CONDITIONS AND CONFIGURATIONS DURING TESTS.................................................8 3.1.CLIMATE TEST CONDITIONS........................................................................................................................................................8 3.2.OPERATIONAL TEST CONDITIONS & ARRANGEMENT FOR TEST SIGNALS..........................................................................8 EXHIBIT 4.SUMMARY OF TEST RESULTS...................................................................................................................................9 4.1.LOCATION OF TESTS..................................................................................................................................................................9 4.2.APPLICABILITY & SUMMARY OF EMC EMISSION TEST RESULTS.......................................................................................9 4.3.MODIFICATI…

Text truncated - open the document above for the full version.

3000 Bristol Circle, Oakville, Ontario, Canada L6H 6G4 Tel.: (905) 829-1570 Fax.: (905) 829-8050 Website: www.ultratech-labs.com Email: [email protected] Jan. 24, 2003 Sanyo Canada Inc. 300 Applewood Cres. Concord, Ontario Canada, L4K 5C7 Attn.:Mr. Akio Ichimori Subject:Certification Application under FCC Part 15, Subpart C, Para. 15.249, Low Power Transmitters Operating in the Frequency Band 902-928 MHz. Product:SANYO CORDLESS TELEPHONE Model:CLT-9936, CLT-9936B, CLT-9935N, CLT-9935BN, CLT-9926, CLT-9926W, CLT-9925N, CLT-9923, CLT-9922N, CLT-9916, CLT-9915N, CLT-9911, CLT- 9910N FCC ID:MBH-CLT99XXN Dear Mr. Ichimori, The product sample, as provided by you, has been tested and found to comply with FCC Part 15, Subpart C, Para. 15.249, Low Power Transmitters operating in the Frequency Band 902-928 MHz. Please feel to contact us if you have any further questions. Best Regards, Tri M. Luu, P.Eng. V.P. Engineering UltraTech Group of Labs 31040/SIT C-1376 46390-2049 200093-0 2 00-034 ENGINEERING TEST REPORT SANYO CORDLESS TELEPHONE MODELS: CLT-9936, CLT-9936B, CLT-9935N, CLT-9935BN, CLT- 9926, CLT-9926W, CLT-9925N, CLT-9923, CLT-9922N, CLT-9916, CLT-9915N, CLT-9911, CLT-9910N FCC ID: MBH-CLT99XXN Applicant: Sanyo Canada Inc. 300 Applewood Cres. Concord, Ontario Canada, L4K 5C7 Tested in Accordance With FCC PART 15, SUBPART C, PARA. 15.249 LOW POWER TRANSMITTERS OPERATING IN THE FREQUENCY BAND FROM 902 - 928 MHz UltraTech's File No.: SAN-078FCC15C This Test report is Issued under the Authority of Tri M. Luu, Professional Engineer, Vice President of Engineering UltraTech Group of Labs Date: Jan. 24, 2003 Report Prepared by: Tri LuuTested by: Hung Trinh, EMI/RFI Technician Issued Date: Jan. 24, 2003Test Dates: Jan. 19-21, 2003 ß The results in this Test Report apply only to the sample(s) tested, and the sample tested is randomly selected. ß This report must not be used by the client to claim product endorsement by NVLAP or any agency of the US Government. UltraTech 3000 Bristol Circle, Oakville, Ontario, Canada, L6H 6G4 Tel.: (905) 829-1570 Fax.: (905) 829-8050 Website: www.ultratech-labs.com Email: [email protected], Email: [email protected] 2 31040/SITC-137646390-2049200093-000-034 FCC PART 15, SUBPART C, SECTION 15.249 - INTENTIONAL RADIATORSPage 2 SANYO CORDLESS TELEPHONES,MODELS: CLT-9936, CLT-9936B, CLT-9935N, CLT-9935BN, CLT-9926, CLT-9926W, CLT-9925N, CLT-9923, CLT-9922N, CLT-9916, CLT-9915N, CLT-9911, CLT-9910N FCC ID: MBH-CLT99XXN ULTRATECH GROUP OF LABSFile #: SAN-078FCC15C 3000 Bristol Circle, Oakville, Ontario, Canada L6H 6G4Jan. 24, 2003 Tel. : 905-829-1570, Fax. : 905-829-8050 All test results contained in this engineering test report are traceable to National Institute of Standards and Technology (NIST) TABLE OF CONTENTS EXHIBIT 1.SUBMITTAL CHECK LIST.................................................................................................................................4 EXHIBIT 2.INTRODUCTION....................................................................................................................................................5 2.1.SCOPE........................................................................................................................................................................................5 2.2.RELATED SUBMITTAL(S)/GRANT(S)........................................................................................................................................5 2.3.NORMATIVE REFERENCES..............................................................................................................................................5 EXHIBIT 3.PERFORMANCE ASSESSMENT.......................................................................................................................6 3.1.CLIENT INFORMATION.........................................................................................................................................................6 3.2.EQUIPMENT UNDER TEST (EUT) INFORMATION............................................................................................................6 3.3.EUT’S TECHNICAL SPECIFICATIONS..........................................................................................................................8 3.4.LIST OF EUT’S PORTS..............................................................................................................................................................8 3.5.ANCILLARY EQUIPMENT..........................................................................................................................................................8 3.6.GENERAL TEST SETUP......................................................................................................................................................9 EXHIBIT 4.EUT OPERATING CONDITIONS AND CONFIGURATIONS DURING TESTS............................10 4.1.CLIMATE TEST CONDITIONS...................................................................................................................................................10 4.2.OPERATIONAL TEST CONDITIONS & ARRANGEMENT FOR TESTS.....................................................................................10 EXHIBIT 5.SUMMARY OF TEST RESULTS.....................................................................................................................11 5.1.LOCATION OF TESTS........................................................................................................................................................11 5.2.APPLICABILITY & SUMMARY OF EMC EMISSION TEST RESULTS............................................................................11 5.3.MODIFICATIONS INCORPORATED IN THE EUT FOR COMPLIANCE PURPOSES....................................................................11 EXHIBIT 6.MEASUREMENTS, EXAMINATIONS & TEST DATA FOR EMC EMISSIONS...........................12 6.1.TEST PROCEDURES.................................…

Text truncated - open the document above for the full version.

ANNEX 1 - PLOTS OF MEASUREMENTSPHOTO # 1 SANYO CORDLESS TELEPHONES,MODELS: CLT-9936, CLT-9936B, CLT-9935N, CLT-9935BN, CLT-9926, LT-9926W, CLT-9925N, CLT-9923, CLT-9922N, CLT-9916, CLT-9915N, CLT-9911, CLT-9910N IC: 339A-CLT99XXNFCC ID: MBH-CLT99XXN ANNEX 1 - PLOTS OF MEASUREMENTSPHOTO # 2 SANYO CORDLESS TELEPHONES,MODELS: CLT-9936, CLT-9936B, CLT-9935N, CLT-9935BN, CLT-9926, LT-9926W, CLT-9925N, CLT-9923, CLT-9922N, CLT-9916, CLT-9915N, CLT-9911, CLT-9910N IC: 339A-CLT99XXNFCC ID: MBH-CLT99XXN

ANNEX 1 - PLOTS OF MEASUREMENTSPHOTO # 3 SANYO CORDLESS TELEPHONES,MODELS: CLT-9936, CLT-9936B, CLT-9935N, CLT-9935BN, CLT-9926, LT-9926W, CLT-9925N, CLT-9923, CLT-9922N, CLT-9916, CLT-9915N, CLT-9911, CLT-9910N IC: 339A-CLT99XXNFCC ID: MBH-CLT99XXN ANNEX 1 - PLOTS OF MEASUREMENTSPHOTO # 4 SANYO CORDLESS TELEPHONES,MODELS: CLT-9936, CLT-9936B, CLT-9935N, CLT-9935BN, CLT-9926, LT-9926W, CLT-9925N, CLT-9923, CLT-9922N, CLT-9916, CLT-9915N, CLT-9911, CLT-9910N IC: 339A-CLT99XXNFCC ID: MBH-CLT99XXN ANNEX 1 - PLOTS OF MEASUREMENTSPHOTO # 5 SANYO CORDLESS TELEPHONES,MODELS: CLT-9936, CLT-9936B, CLT-9935N, CLT-9935BN, CLT-9926, LT-9926W, CLT-9925N, CLT-9923, CLT-9922N, CLT-9916, CLT-9915N, CLT-9911, CLT-9910N IC: 339A-CLT99XXNFCC ID: MBH-CLT99XXN ANNEX 1 - PLOTS OF MEASUREMENTSPHOTO # 6 SANYO CORDLESS TELEPHONES,MODELS: CLT-9936, CLT-9936B, CLT-9935N, CLT-9935BN, CLT-9926, LT-9926W, CLT-9925N, CLT-9923, CLT-9922N, CLT-9916, CLT-9915N, CLT-9911, CLT-9910N IC: 339A-CLT99XXNFCC ID: MBH-CLT99XXN ANNEX 1 - PLOTS OF MEASUREMENTSPHOTO # 7 SANYO CORDLESS TELEPHONES,MODELS: CLT-9936, CLT-9936B, CLT-9935N, CLT-9935BN, CLT-9926, LT-9926W, CLT-9925N, CLT-9923, CLT-9922N, CLT-9916, CLT-9915N, CLT-9911, CLT-9910N IC: 339A-CLT99XXNFCC ID: MBH-CLT99XXN

ANNEX 1 - PLOTS OF MEASUREMENTSPHOTO # 7 SANYO CORDLESS TELEPHONES,MODELS: CLT-9936, CLT-9936B, CLT-9935N, CLT-9935BN, CLT-9926, LT-9926W, CLT-9925N, CLT-9923, CLT-9922N, CLT-9916, CLT-9915N, CLT-9911, CLT-9910N IC: 339A-CLT99XXNFCC ID: MBH-CLT99XXN Ambient ANNEX 1 - PLOTS OF MEASUREMENTSPHOTO # 8 SANYO CORDLESS TELEPHONES,MODELS: CLT-9936, CLT-9936B, CLT-9935N, CLT-9935BN, CLT-9926, LT-9926W, CLT-9925N, CLT-9923, CLT-9922N, CLT-9916, CLT-9915N, CLT-9911, CLT-9910N IC: 339A-CLT99XXNFCC ID: MBH-CLT99XXN ANNEX 1 - PLOTS OF MEASUREMENTSPHOTO # 9 SANYO CORDLESS TELEPHONES,MODELS: CLT-9936, CLT-9936B, CLT-9935N, CLT-9935BN, CLT-9926, LT-9926W, CLT-9925N, CLT-9923, CLT-9922N, CLT-9916, CLT-9915N, CLT-9911, CLT-9910N IC: 339A-CLT99XXNFCC ID: MBH-CLT99XXN ANNEX 1 - PLOTS OF MEASUREMENTSPHOTO # 10 SANYO CORDLESS TELEPHONES,MODELS: CLT-9936, CLT-9936B, CLT-9935N, CLT-9935BN, CLT-9926, LT-9926W, CLT-9925N, CLT-9923, CLT-9922N, CLT-9916, CLT-9915N, CLT-9911, CLT-9910N IC: 339A-CLT99XXNFCC ID: MBH-CLT99XXN ANNEX 1 - PLOTS OF MEASUREMENTSPHOTO # 11 SANYO CORDLESS TELEPHONES,MODELS: CLT-9936, CLT-9936B, CLT-9935N, CLT-9935BN, CLT-9926, LT-9926W, CLT-9925N, CLT-9923, CLT-9922N, CLT-9916, CLT-9915N, CLT-9911, CLT-9910N IC: 339A-CLT99XXNFCC ID: MBH-CLT99XXN ANNEX 1 - PLOTS OF MEASUREMENTSPHOTO # 12 SANYO CORDLESS TELEPHONES,MODELS: CLT-9936, CLT-9936B, CLT-9935N, CLT-9935BN, CLT-9926, LT-9926W, CLT-9925N, CLT-9923, CLT-9922N, CLT-9916, CLT-9915N, CLT-9911, CLT-9910N IC: 339A-CLT99XXNFCC ID: MBH-CLT99XXN ANNEX 1 - PLOTS OF MEASUREMENTSPHOTO # 13 SANYO CORDLESS TELEPHONES,MODELS: CLT-9936, CLT-9936B, CLT-9935N, CLT-9935BN, CLT-9926, LT-9926W, CLT-9925N, CLT-9923, CLT-9922N, CLT-9916, CLT-9915N, CLT-9911, CLT-9910N IC: 339A-CLT99XXNFCC ID: MBH-CLT99XXN ANNEX 1 - PLOTS OF MEASUREMENTSPHOTO # 14 SANYO CORDLESS TELEPHONES,MODELS: CLT-9936, CLT-9936B, CLT-9935N, CLT-9935BN, CLT-9926, LT-9926W, CLT-9925N, CLT-9923, CLT-9922N, CLT-9916, CLT-9915N, CLT-9911, CLT-9910N IC: 339A-CLT99XXNFCC ID: MBH-CLT99XXN

Jan. 24, 2003 INDUSTRY CANADA Head, Equipment Approval Unit 3701 Carling Avenue, Bdlg. # 94 P.O. Box 11490, Station “H” Ottawa, Ontario K2H 8S2 Subject:Certification Application under Industry Canada RSS-210, Issue 5, Sec. 6.2.2(m2), Low Power Licence-Exempt RadioCommunication Devices (902-928 MHz). Applicant:Sanyo Canada Inc. Product:SANYO CORDLESS TELEPHONE Model:CLT-9936, CLT-9936B, CLT-9935N, CLT-9935BN, CLT-9926, CLT-9926W, CLT- 9925N, CLT-9923, CLT-9922N, CLT-9916, CLT-9915N, CLT-9911, CLT-9910N IC:339A-CLT99XXN Dear Sir/Madam, As appointed agent for Sanyo Canada Inc., we would like to submit the application to INDUSTRY CANADA for certification of the above product. Attached please find the application form, test reports, annexes and a cheque in the amount of C$ 679.75 (including CDN $ 29.75 GST) for Canada assessment and certification fees. If you have any queries, please do not hesitate to contact us by our TOLL FREE numbers: OUR TELEPHONE NO.:1-877-765-4173 Yours truly, Tri Minh Luu, P. Eng., V.P., Engineering TML/AK Encl. UltraTech Group of Labs 31040/SIT C-1376 46390-2049 200093-0 2 00-034 3000 Bristol Circle, Oakville, Ontario, Canada L6H 6G4 Tel.: (905) 829-1570 Fax.: (905) 829-8050 Website: www.ultratech-labs.com Email: [email protected] Jan. 24, 2003 Sanyo Canada Inc. 300 Applewood Cres. Concord, Ontario Canada, L4K 5C7 Attn.:Mr. Akio Ichimori Subject:Certification Application under Industry Canada RSS-210, Issue 5, Sec. 6.2.2(m2), Low Power Licence-Exempt RadioCommunication Devices (902-928 MHz). Product:SANYO CORDLESS TELEPHONE Model:CLT-9936, CLT-9936B, CLT-9935N, CLT-9935BN, CLT-9926, CLT-9926W, CLT-9925N, CLT-9923, CLT-9922N, CLT-9916, CLT-9915N, CLT-9911, CLT- 9910N IC:339A-CLT99XXN Dear Mr. Ichimori, The product sample, as provided by you, has been tested and found to comply with Industry Canada RSS-210, Issue 5, Sec. 6.2.2(m2), Low Power Licence-Exempt RadioCommunication Devices (All Frequency Bands). Please feel to contact us if you …

Text truncated - open the document above for the full version.
