MFFLSR100Laser Scanner

Hexagon Metrology GmbH
Laser Scanner - FCC ID MFFLSR100 - Hexagon Metrology GmbH
Click to zoom

Application Details

Equipment Class
DTS - Digital Transmission System
Date of Grant
Jul 31, 2026
Application Purpose
Original Equipment
Equipment Note
Laser Scanner
Frequency Range
2402.00000000 - 2480.00000000
Company
Hexagon Metrology GmbH
Country
Germany

Documents & Files

Select a file to view

Attestation Statements

↗
↗

Cover Letter(s)

↗
↗

External Photos

↗

ID Label/Location Info

↗

Internal Photos

↗

RF Exposure Info

↗

Test Report

↗
↗
↗

Test Setup Photos

↗
↗

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Cover Letter(s)

Long/Short-term Confidentiality Request NMi TESTLAB GmbHDate: 30 July 2026 Product Certification Königswinkel 10 D 32825 Blomberg FCC ID:MFFLSR100 To Whom It May Concerns, Pursuant to sections 0.457(d) and 0.459 of CFR 47 and to avoid premature release of sensitive information prior to marketing or release of the product to the public, we hereby request long-term confidential treatment of information accompanying this application as outlined below: ☒ Schematics☐ Parts List ☒ Block Diagram☐ Tune-Up Info ☒ Operational Description In addition we hereby request the following exhibits contained in this application to be temporarily (short-term confidentiality) withheld from the public disclosure ☒ for an initial period of 180 days☐ until:☐ not applicable ☐ External Photos☐ Test Setup Photos ☐ Internal Photos☒ Users Manual The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to rule 0.457(d), disclosure of this application and all accompanying documentation will not be made before the date of the GRANT for this application. If you have any questions, please feel free to contact me. Yours sincerely, Signatory Kai Heinrichs Graduated Approval Engineer

External Photos

External EUT photos Examiner:Bernward ROHDERevision:00 Date of issue: 15.07.2026Order Number: 25-111949page 1 of 7 EUT – 3d top view External EUT photos Examiner:Bernward ROHDERevision:00 Date of issue: 15.07.2026Order Number: 25-111949page 2 of 7 EUT – bottom view External EUT photos Examiner:Bernward ROHDERevision:00 Date of issue: 15.07.2026Order Number: 25-111949page 3 of 7 EUT – top view External EUT photos Examiner:Bernward ROHDERevision:00 Date of issue: 15.07.2026Order Number: 25-111949page 4 of 7 Side view 1 External EUT photos Examiner:Bernward ROHDERevision:00 Date of issue: 15.07.2026Order Number: 25-111949page 5 of 7 Side view 2 External EUT photos Examiner:Bernward ROHDERevision:00 Date of issue: 15.07.2026Order Number: 25-111949page 6 of 7 Side view 3 External EUT photos Examiner:Bernward ROHDERevision:00 Date of issue: 15.07.2026Order Number: 25-111949page 7 of 7 Side view 4

ID Label/Location Info

Description LS-R-100 12 1.7 Markings Markings

Internal Photos

Examiner:Bernward ROHDERevision:00 Date of issue: 15.07.2026Order Number: 25-111949page 1 of 7 EUT – opened – top view Examiner:Bernward ROHDERevision:00 Date of issue: 15.07.2026Order Number: 25-111949page 2 of 7 EUT PCB – top view Examiner:Bernward ROHDERevision:00 Date of issue: 15.07.2026Order Number: 25-111949page 3 of 7 EUT PCB – top view Examiner:Bernward ROHDERevision:00 Date of issue: 15.07.2026Order Number: 25-111949page 4 of 7 Radio part – detail view Examiner:Bernward ROHDERevision:00 Date of issue: 15.07.2026Order Number: 25-111949page 5 of 7 Integrated radio module – detail view Examiner:Bernward ROHDERevision:00 Date of issue: 15.07.2026Order Number: 25-111949page 6 of 7 Radio part – detail view Ant 1 Ant 2 Examiner:Bernward ROHDERevision:00 Date of issue: 15.07.2026Order Number: 25-111949page 7 of 7 2.4 GHz PCB antenna – detail view Feed Ant 1 Feed Ant 2

RF Exposure Info

FCC RF Exposure Evaluation Report Number: F251949E11 Equipment under Test (EUT): Laser Scanner LS-R-100 Applicant: Hexagon Metrology GmbH Manufacturer: Hexagon Metrology GmbH Königswinkel 10 32825 Blomberg, Germany +49 5235 / 9500-0 [email protected] www.nmi-testlab.de Examiner:Martin EPPINGERReport Number: F251949E11 Date of Issue: 30.07.2026Order Number: 25-111949Page 2 of 15 References [1]CFR 47 Rule part 1Practice and Procedure [2] CFR 47 Rule part 2Frequency Allocations and Radio Treaty Matters; General Rules and Regulations [3] KDB 447498 D04 Interim General RF Exposure Guidance v01 This test report is only valid in its original form. Any reproduction of its contents in extracts without written permission of the accredited test laboratory NMi TESTLAB GmbH is prohibited. The test results herein refer only to the tested sample. NMi TESTLAB GmbH is not responsible for any generalizations or conclusions drawn from these test results concerning further samples. Any modification of the tested samples is prohibited and leads to the invalidity of this test report. Each page necessarily contains the NMi TESTLAB Logo and the TEST REPORT NUMBER. Assessed and written by: Signature Reviewed and approved by: Signature Examiner:Martin EPPINGERReport Number: F251949E11 Date of Issue: 30.07.2026Order Number: 25-111949Page 3 of 15 Contents:Page Identification ........................................................................................................................... 4 1.1Applicant ............................................................................................................................................ 4 1.2Manufacturer ..................................................................................................................................... 4 1.3Test Laboratory ................................................................................................................................. 4 1.4EUT (Equipment under Test) ............................................................................................................. 5 1.5Technical Data of Equipment ............................................................................................................ 6 Evaluation Method .................................................................................................................. 8 2.1RF exposure test exemptions for single sources ............................................................................. 8 2.1.1General Exemption CFR 47 §1.1307(b)(3)(i)(A) ........................................................................ 8 2.1.2SAR Based Exemption CFR 47 §1.1307(b)(3)(i)(B) ................................................................... 8 2.1.3MPE Based Exemption CFR 47 §1.1307(b)(3)(i)(C) .................................................................. 8 2.1.4Stand-alone MPE evaluation limits ........................................................................................... 9 2.2RF exposure test exemptions for simultaneous transmission sources ......................................... 10 2.2.11 mW Test Exemption for simultaneous transmission sources ............................................. 10 2.2.2Simultaneous transmission SAR based and MPE based test exemptions ............................ 10 2.2.3Test exemption based on the SAR to Peak Location Separation Ratio .................................. 11 Results of evaluation ............................................................................................................. 12 3.1Used evaluation methods................................................................................................................ 12 3.2Evaluation Distance ......................................................................................................................... 12 3.3BLE 2.4 GHz emissions ................................................................................................................... 13 3.4Proprietary emissions ...................................................................................................................... 14 3.5UNII-I band emissions ..................................................................................................................... 14 3.6Simultaneous emissions .................................................................................................................. 15 Conclusion ............................................................................................................................ 15 Report History ....................................................................................................................... 15 Examiner:Martin EPPINGERReport Number: F251949E11 Date of Issue: 30.07.2026Order Number: 25-111949Page 4 of 15 Identification 1.1Applicant Name:Hexagon Metrology GmbH Address:Am Langholz 11, 88289 Waldburg Country:Germany Name for contact purposes:Mr. Christoph WIEST Phone:+49 7529 9733838 eMail address:[email protected] Applicant represented during the test by the following person: --- 1.2Manufacturer Name:Hexagon Metrology GmbH Address:Am Langholz 11, 88289 Waldburg Country:Germany Name for contact purposes:Mr. Christoph WIEST Phone:+49 7529 9733838 eMail address:[email protected] Manufacturer represented during the test by the following person: --- 1.3Test Laboratory The tests were carried out by:NMi TESTLAB GmbH formerly PHOENIX TESTLAB GmbH Königswinkel 10 32825 Blomberg Germany accredited byDeutsche Akkreditierungsstelle GmbH (DAkkS) according to DIN EN ISO/IEC 17025:2018. The accreditation is only valid for the scope of accreditation listed in the annex of the certificate D-PL-17186-01-00. FCC Test Firm Designation Number DE0004, FCC Test Firm Registration Number 469623, CAB Identifier DE0003 and ISED# 3469A. Examiner:Martin EPPINGERReport Number: F251949E11 Date of Issue: 30.07.2026Order Number: 25-111949Page 5 of 15 1.4EUT …

Text truncated - open the document above for the full version.

Test Report

Antenna Report Report Number: F251949E14 Antenna under Test (AUT): Antenna(s) of: Laser Scanner LS-R-100 Applicant: Hexagon Metrology GmbH Manufacturer: Hexagon Metrology GmbH Königswinkel 10 32825 Blomberg, Germany +49 5235 / 9500-0 [email protected] www.nmi-testlab.de Examiner:Bernward ROHDEReport Number: F251769E8 Date of issue: 16.07.2026Order Number: 25-111769page 2 of 17 References [1] None (According customer requirements) This test report is only valid in its original form. Any reproduction of its contents in extracts without written permission of the accredited test laboratory NMi TESTLAB GmbH is prohibited. The test results herein refer only to the tested sample. NMi TESTLAB GmbH is not responsible for any generalisations or conclusions drawn from these test results concerning further samples. Any modification of the tested samples is prohibited and leads to the invalidity of this test report. Each page necessarily contains the NMi TESTLAB Logo and the TEST REPORT NUMBER. Tested and written by Signature Reviewed and approved by: Signature Examiner:Bernward ROHDEReport Number: F251769E8 Date of issue: 16.07.2026Order Number: 25-111769page 3 of 17 Contents:Page 1Identification ........................................................................................................................... 4 1.1Applicant .............................................................................................................................................. 4 1.2Manufacturer ....................................................................................................................................... 4 1.3Test Laboratory ................................................................................................................................... 4 1.4AUT (Antenna under test) ................................................................................................................... 5 1.5EUT (Equipment under test) ............................................................................................................... 5 1.6Technical Data of Equipment .............................................................................................................. 6 1.7Dates .................................................................................................................................................... 6 2Operational States ................................................................................................................... 6 3Additional Information ............................................................................................................. 7 4Photographs ............................................................................................................................ 8 4.1Antenna ............................................................................................................................................... 8 5Antenna Charts ....................................................................................................................... 9 5.1Reference ............................................................................................................................................ 9 5.2Results (Max. Gain) ............................................................................................................................. 9 5.3Antenna Diagrams EUT Position ....................................................................................................... 10 5.3.1Test Setup Photos ................................................................................................................... 10 5.3.2Azimuth charts of transmitter ANT 1 ....................................................................................... 11 5.3.2.12405 MHz ........................................................................................................................ 11 5.3.2.22440 MHz ....................................................................................................................... 12 5.3.2.32480 MHz ....................................................................................................................... 13 5.3.3Azimuth charts of transmitter ANT 2 ...................................................................................... 14 5.3.3.12405 MHz ....................................................................................................................... 14 5.3.3.22440 MHz ....................................................................................................................... 15 5.3.3.32480 MHz ....................................................................................................................... 16 6Test Equipment used for Tests ............................................................................................. 17 7Report History ....................................................................................................................... 17 Examiner:Bernward ROHDEReport Number: F251769E8 Date of issue: 16.07.2026Order Number: 25-111769page 4 of 17 1Identification 1.1Applicant Name:Hexagon Metrology GmbH Address:Am Langholz 11, 88289 Waldburg Country:Germany Name for contact purposes:Mr. Christoph WIEST Phone:+49 7529 9733838 eMail address:[email protected] Applicant represented during the test by the following person: --- 1.2Manufacturer Name:Hexagon Metrology GmbH Address:Am Langholz 11, 88289 Waldburg Country:Germany Name for contact purposes:Mr. Christoph WIEST Phone:+49 7529 9733838 eMail address:[email protected] Manufacturer represented during the test by the following person: --- 1.3Test Laboratory The tests were carried out by:NMi TESTLAB GmbH formerly PHOENIX TESTLAB GmbH Königswinkel 10 32825 Blomberg Germany Examiner:Bernward ROHDEReport Number: F251769E8 Date of issue: 16.07.2026Order Number: 25-111769page 5 of 17 1.4AUT (Antenna under t…

Text truncated - open the document above for the full version.

Test Report

Test Report Report Number: F251949E9 Equipment under Test (EUT): Laser Scanner LS-R-100 Applicant: Hexagon Metrology GmbH Manufacturer: Hexagon Metrology GmbH Königswinkel 10 32825 Blomberg, Germany +49 5235 / 9500-0 [email protected] www.nmi-testlab.de Examiner:Martin EPPINGERReport Number: F251949E9 Date of Issue: 22.07.2026Order Number: 25-111949Page 2 of 46 References [1] ANSI C63.10-2020 + Cor. 1-2023 + C63.10a-2024 + Errata to C63.10a-2024*, American National Standard of Procedures for Compliance Testing of Unlicensed Wireless Devices *Remark: This standard is not in the annex of the laboratory yet [2] FCC CFR 47 Part 15, Radio Frequency Devices [3] 558074 D01 15.247 Meas Guidance v05r02 (April 2019), GUIDANCE FOR COMPLIANCE MEASUREMENTS ON DIGITAL TRANSMISSION SYSTEM, FREQUENCY HOPPING SPREAD SPECTRUM SYSTEM, AND HYBRID SYSTEM DEVICES OPERATING UNDER SECTION 15.247 OF THE FCC RULES [4] RSS-247, Issue 4 (2025-07)Digital Transmission Systems, Frequency Hopping Systems and Licence-Exempt Local Area Network Devices in 902-928 MHz, 2400-2483.5 MHz, 5150-5350 MHz, and 5470-5895 MHz bands [5] RSS-Gen, Issue 5 (2018-04) + Amendment 1 (2019-03) + Amendment 2 (2021-02) General Requirements for Compliance of Radio Apparatus Examiner:Martin EPPINGERReport Number: F251949E9 Date of Issue: 22.07.2026Order Number: 25-111949Page 3 of 46 Test Result The requirements of the tests performed as shown in the overview (clause 4) were fulfilled by the equipment under test. The complete test results are presented in the following. “Passed” indicates that the equipment under test conforms with the relevant limits of the testing standard without taking any measurement uncertainty into account as stated in [1]. However, the measurement uncertainty is calculated and shown in this test report. This test report is only valid in its original form. Any reproduction of its contents in extracts without written permission of the accredited test laboratory NMi TESTLAB GmbH is prohibited. The test results herein refer only to the tested sample. NMi TESTLAB GmbH is not responsible for any generalisations or conclusions drawn from these test results concerning further samples. Any modification of the tested samples is prohibited and leads to the invalidity of this test report. Each page necessarily contains the NMi TESTLAB Logo and the TEST REPORT NUMBER. Tested by: Signature Written by: Signature Reviewed and approved by: Signature Examiner:Martin EPPINGERReport Number: F251949E9 Date of Issue: 22.07.2026Order Number: 25-111949Page 4 of 46 Contents:Page Identification ........................................................................................................................... 5 1.1Applicant ............................................................................................................................................ 5 1.2Manufacturer ..................................................................................................................................... 5 1.3Test Laboratory ................................................................................................................................. 5 1.4EUT (Equipment under Test) ............................................................................................................. 6 1.5Technical Data of Equipment ............................................................................................................ 7 1.6Dates .................................................................................................................................................. 8 Operational States ................................................................................................................... 9 2.1Description of function of the EUT ................................................................................................... 9 Additional Information ........................................................................................................... 10 Overview ................................................................................................................................ 11 Results ................................................................................................................................... 12 5.1Test setups ...................................................................................................................................... 12 5.2Duty cycle ........................................................................................................................................ 18 5.3DTS bandwidth ................................................................................................................................ 19 5.4Occupied bandwidth – power bandwidth (99%) ............................................................................ 21 5.5DTS fundamental emission output power ...................................................................................... 23 5.6DTS maximum power spectral density ........................................................................................... 26 5.7DTS band-edge emission measurements ...................................................................................... 29 5.8Maximum unwanted emissions ....................................................................................................... 33 Measurement Uncertainties ................................................................................................. 44 Test Equipment used for Tests .............................................................................................45 Test site Verification ............................................................................................................ 46 Report History ...................................................................................................................... 46 List of Annexes .......................................…

Text truncated - open the document above for the full version.

Test Report

Test Report Report Number: F251949E8 Equipment under Test (EUT): Laser Scanner LS-R-100 Applicant: Hexagon Metrology GmbH Manufacturer: Hexagon Metrology GmbH Königswinkel 10 32825 Blomberg, Germany +49 5235 / 9500-0 [email protected] www.nmi-testlab.de Examiner:Martin EPPINGERReport Number: F251949E8 Date of Issue: 30.07.2026Order Number: 25-111949Page 2 of 47 References [1] ANSI C63.10-2020 + Cor. 1-2023 + C63.10a-2024 + Errata to C63.10a-2024*, American National Standard of Procedures for Compliance Testing of Unlicensed Wireless Devices *Remark: This standard is not in the annex of the laboratory yet [2] FCC CFR 47 Part 15, Radio Frequency Devices [3] 558074 D01 15.247 Meas Guidance v05r02 (April 2019), GUIDANCE FOR COMPLIANCE MEASUREMENTS ON DIGITAL TRANSMISSION SYSTEM, FREQUENCY HOPPING SPREAD SPECTRUM SYSTEM, AND HYBRID SYSTEM DEVICES OPERATING UNDER SECTION 15.247 OF THE FCC RULES [4] RSS-247, Issue 4 (2025-07)Digital Transmission Systems, Frequency Hopping Systems and Licence-Exempt Local Area Network Devices in 902-928 MHz, 2400-2483.5 MHz, 5150-5350 MHz, and 5470-5895 MHz bands [5] RSS-Gen, Issue 5 (2018-04) + Amendment 1 (2019-03) + Amendment 2 (2021-02) General Requirements for Compliance of Radio Apparatus Examiner:Martin EPPINGERReport Number: F251949E8 Date of Issue: 30.07.2026Order Number: 25-111949Page 3 of 47 Test Result The requirements of the tests performed as shown in the overview (clause 4) were fulfilled by the equipment under test. The complete test results are presented in the following. “Passed” indicates that the equipment under test conforms with the relevant limits of the testing standard without taking any measurement uncertainty into account as stated in [1]. However, the measurement uncertainty is calculated and shown in this test report. This test report is only valid in its original form. Any reproduction of its contents in extracts without written permission of the accredited test laboratory NMi TESTLAB GmbH is prohibited. The test results herein refer only to the tested sample. NMi TESTLAB GmbH is not responsible for any generalisations or conclusions drawn from these test results concerning further samples. Any modification of the tested samples is prohibited and leads to the invalidity of this test report. Each page necessarily contains the NMi TESTLAB Logo and the TEST REPORT NUMBER. Tested by: Signature Written by: Signature Reviewed and approved by: Signature Examiner:Martin EPPINGERReport Number: F251949E8 Date of Issue: 30.07.2026Order Number: 25-111949Page 4 of 47 Contents:Page Identification ........................................................................................................................... 5 1.1Applicant ............................................................................................................................................ 5 1.2Manufacturer ..................................................................................................................................... 5 1.3Test Laboratory ................................................................................................................................. 5 1.4EUT (Equipment under Test) ............................................................................................................. 6 1.5Technical Data of Equipment ............................................................................................................ 7 1.6Dates .................................................................................................................................................. 8 Operational States ................................................................................................................... 9 2.1Description of function of the EUT ................................................................................................... 9 Additional Information ........................................................................................................... 10 Overview ................................................................................................................................ 11 Results ................................................................................................................................... 12 5.1Test setups ...................................................................................................................................... 12 5.2Duty cycle ........................................................................................................................................ 18 5.3DTS bandwidth ................................................................................................................................ 20 5.4Occupied bandwidth – power bandwidth (99%) ............................................................................ 22 5.5DTS fundamental emission output power ...................................................................................... 24 5.6DTS maximum power spectral density ........................................................................................... 27 5.7DTS band-edge emission measurements ...................................................................................... 30 5.8Radiated emissions ......................................................................................................................... 34 Measurement Uncertainties ..................................................................................................45 Test Equipment used for Tests ............................................................................................ 46 Test site Verification ............................................................................................................ 46 Report History ...................................................................................................................... 46 List of Annexes .............................…

Text truncated - open the document above for the full version.

Test Setup Photos

Annex A Test setup photos Examiner:Martin EPPINGERReport Number: F251949E9 Date of issue: 22.07.2026Order Number: 25-111949page 1 of 11 Test setups radiated emissions EUT Position 1 below 1GHz Annex A Test setup photos Examiner:Martin EPPINGERReport Number: F251949E9 Date of issue: 22.07.2026Order Number: 25-111949page 2 of 11 EUT Position 2 below 1GHz Annex A Test setup photos Examiner:Martin EPPINGERReport Number: F251949E9 Date of issue: 22.07.2026Order Number: 25-111949page 3 of 11 EUT Position 3 below 1GHz Annex A Test setup photos Examiner:Martin EPPINGERReport Number: F251949E9 Date of issue: 22.07.2026Order Number: 25-111949page 4 of 11 30 MHz – 1 GHz Annex A Test setup photos Examiner:Martin EPPINGERReport Number: F251949E9 Date of issue: 22.07.2026Order Number: 25-111949page 5 of 11 9 kHz – 30 MHz – Antenna Position 1 Annex A Test setup photos Examiner:Martin EPPINGERReport Number: F251949E9 Date of issue: 22.07.2026Order Number: 25-111949page 6 of 11 9 kHz – 30 MHz – Antenna Position 2 Annex A Test setup photos Examiner:Martin EPPINGERReport Number: F251949E9 Date of issue: 22.07.2026Order Number: 25-111949page 7 of 11 9 kHz – 30 MHz – Antenna Position 3 Annex A Test setup photos Examiner:Martin EPPINGERReport Number: F251949E9 Date of issue: 22.07.2026Order Number: 25-111949page 8 of 11 1 GHz – 12 GHz Annex A Test setup photos Examiner:Martin EPPINGERReport Number: F251949E9 Date of issue: 22.07.2026Order Number: 25-111949page 9 of 11 12 GHz – 18 GHz Annex A Test setup photos Examiner:Martin EPPINGERReport Number: F251949E9 Date of issue: 22.07.2026Order Number: 25-111949page 10 of 11 18 GHz – 26.5 GHz Annex A Test setup photos Examiner:Martin EPPINGERReport Number: F251949E9 Date of issue: 22.07.2026Order Number: 25-111949page 11 of 11 Conducted measurements

Test Setup Photos

Annex A Test setup photos Examiner:Martin EPPINGERReport Number: F251949E8 Date of issue: 24.07.2026Order Number: 25-111949page 1 of 10 Test setups radiated emissions EUT Position 1 below 1GHz Annex A Test setup photos Examiner:Martin EPPINGERReport Number: F251949E8 Date of issue: 24.07.2026Order Number: 25-111949page 2 of 10 EUT Position 2 below 1GHz Annex A Test setup photos Examiner:Martin EPPINGERReport Number: F251949E8 Date of issue: 24.07.2026Order Number: 25-111949page 3 of 10 EUT Position 3 below 1GHz Annex A Test setup photos Examiner:Martin EPPINGERReport Number: F251949E8 Date of issue: 24.07.2026Order Number: 25-111949page 4 of 10 30 MHz – 1 GHz Annex A Test setup photos Examiner:Martin EPPINGERReport Number: F251949E8 Date of issue: 24.07.2026Order Number: 25-111949page 5 of 10 9 kHz – 30 MHz – Antenna Position 1 Annex A Test setup photos Examiner:Martin EPPINGERReport Number: F251949E8 Date of issue: 24.07.2026Order Number: 25-111949page 6 of 10 9 kHz – 3…

Text truncated - open the document above for the full version.

Contact Information

Applicant

Christoph Wiest
[email protected]Fax: +497529973359

Test Firm

PHOENIX TESTLAB GmbHHolger Bentje
[email protected]Fax: 49-5235-9500-28

Technical Specifications

#Rule PartsFrequency RangePower Output
115C2.40 GHz - 2.48 GHz2.20 mW
215C2.40 GHz - 2.48 GHz3.40 mW
Confidentiality
Long Term
Grant Notes
Output power listed is max peak conducted. RF Exposure compliance is addressed for 1.1310 and 2.1091 MPE limits.
