Inprocess Messtechnik GmbH Federal Communications Commission Authorization and Evaluation Division January 19, 2010 Confidentiality Request regarding application for certification of FCC ID: MFFRWP38XX Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Exhibit Type File Name Block diagrams 38_00 (TX) BlkDia Exhibit C(1).pdf Circuit Description 38_00 (TX) OpDes Exhibit C(3).pdf Schematic 38_00 (TX) Schem Exhibit C(2)-1 to -2.pdf The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Pursuant to DA04-1705 June 15, 2004 of the Commission’s public notice, we also request temporary confidential treatment of information accompanying this application as outlined below: Exhibit Type File Name External Photos 38.00 (TX) ExtPho Exhibit (6)C.pdf Internal Photos 38.00 (TX) IntPho Exhibit C(6).pdf Users’ Manual 38_00 (TX) UserMan (Draft) Exhibit C(5).pdf Sincerely, Wilfried Veil

1 1 2 2 3 3 4 4 AA BB CC DD Status Änderungen DatumName DatumName Bearbeitet Geprüft Blatt Nr. Format Werkstoff Maßstabm&h Teilenr. Alle Rechte nach DIN 34 vorbe- halten. Unzulässige Weitergabe an Dritte verboten. Copyright m&h c m&h Inprocess Messtechnik GmbH Am Langholz 11 88289 Waldburg Germany www.mh-inprocess.com Toleranzen ISO 2768 fein Ra 6,3 = = gedreht/gefräst/gebohrt Ra 3,2 = = feingedreht/feingefräst Ra 0,8 = = geschliffen/feinstgedreht Bezeichnung Zeichnungsnummer 38.00-10.037 Position of FCC ID Label 1 A4 MFFRWP38 Pfadenhauer 25.11.09 a neues Original 25.01.10 Veil G:\Entwicklung\38.00 Messtaster\2D-Zeichnungen.idw\38.00-10.037.idw

FCC PART 15.231 TEST REPORT LOW POWER UNLICENSED TRANSMITTER Applicant M+H MESSTECHNIK GMBH GERMANY Address AM LANGHOLZ 11 D-88289 WALDBURG GERMANY Product Description Radio Wave Probe 38.xx FCC ID FCC ID: MFFRWP38XX Model Number 38.xx Date Sample Received 11/30/2009 Date Tested 12/17/2009 Report No. 2916GT9TestReport.pdf Tested By Nam Nguyen Approved By Mario de Aranzeta Test Results Pass Fail THE ATTACHED REPORT SHALL NOT BE REPRODUCED EXCEPT IN FULL WITHOUT THE WRITTEN APPROVAL OF TIMCO ENGINEERING, INC. 849 NW STATE ROAD 45 NEWBERRY, FL 32669 USA PH: 888.472.2424 OR 352.472.5500 FAX: 352.472.2030 EMAIL: [email protected] HTTP: //WWW.TIMCOENGR.COM Certificate # 0955-01 APPLICANT: M+H MESSTECHNIK GMBH GERMANY FCC ID: MFFRWP38XX REPORT: M\M+H\2916GT9\2916GT9TestReport.doc Page 2 of 12 TABLE OF CONTENTS ATTESTATIONS.............................................................................................................3 REPORT SUMMARY ......................................................................................................4 TEST ENVIRONMENT....................................................................................................4 TEST SETUP .................................................................................................................4 DUT SPECIFICATION ....................................................................................................5 MANUFACTURE DECLARATION OF COMPLIANCE WITH PART 15.231(A)......................6 TEST EQUIPMENT LIST ................................................................................................7 TEST PROCEDURES .....................................................................................................8 RADIATION INTERFERENCE .........................................................................................9 OCCUPIED BANDWIDTH.............................................................................................11 POWER LINE CONDUCTED INTERFERENCE ..............................................................12 APPLICANT: M+H MESSTECHNIK GMBH GERMANY FCC ID: MFFRWP38XX REPORT: M\M+H\2916GT9\2916GT9TestReport.doc Page 3 of 12 ATTESTATIONS This equipment has been tested in accordance with the standards identified in this test report. To the best of my knowledge and belief, these tests were performed using the measurement procedures described in this report. All instrumentation and accessories used to test products for compliance to the indicated standards are calibrated regularly in accordance with ISO 17025 requirements. Certificate # 0955-01 I attest that the necessary measurements were made, under my supervision, at: Timco Engineering Inc. 849 NW State Road 45 Newberry, Fl 32669 Authorized Signatory Name: Mario de Aranzeta Mario de Aranzeta C.E.T. Compliance Engineer/ Lab. Supervisor Date: December 31, 2009 APPLICANT: M+H MESSTECHNIK GMBH GERMANY FCC ID: MFFRWP38XX REPORT: M\M+H\2916GT9\2916GT9TestReport.doc Page 4 of 12 REPORT SUMMARY Disclaimer The test results only relate to the item tested. Applicable Rule(s) FCC Pt 15.231, Pt 15.209, Pt 15.207, ANSI C63.4: 2003 Related Report(s) or Approval(s) No related report TEST ENVIRONMENT Test Facility The test sites are located at 849 NW State Road 45 Newberry, FL 32669 USA. Test Condition: Temperature: 26ºC Relative humidity: 50% TEST SETUP Test Exercise (e.g software description, test signal, etc.): The DUT was placed in continuous transmit mode of operation. Deviation from the standard(s) No deviation from the standard(s) Modification to the DUT: No modification was made to the DUT. Supporting Peripheral Equipment Not applicable. The device is a stand-alone remote control radio. APPLICANT: M+H MESSTECHNIK GMBH GERMANY FCC ID: MFFRWP38XX REPORT: M\M+H\2916GT9\2916GT9TestReport.doc Page 5 of 12 DUT SPECIFICATION Applicant M+H MESSTECHNIK GMBH GERMANY Description Radio Wave Probe 38XX FCC ID MFFRWP38XX Model Number 38.xx Frequency Range (433.075 – 434.650) MHz 110–120Vac/50– 60Hz DC Power DUT Power Source Battery Operated Exclusively Test Item Prototype Pre-Production Production Type of Equipment Fixed Mobile Portable APPLICANT: M+H MESSTECHNIK GMBH GERMANY FCC ID: MFFRWP38XX REPORT: M\M+H\2916GT9\2916GT9TestReport.doc Page 6 of 12 MANUFACTURE DECLARATION OF COMPLIANCE WITH PART 15.231(A) Item Description Yes No 1 Does this device transmit a signal that is only used to control another device? X 2 Does this device send data with this control signal? X 3 Does this device send data? Data is, things like: temperature, wind direction, fluid amount, rate of flow, etc. X 4 Does this device transmit continuously or automatically? 5 If manually operated does this device stop transmitting within 5 seconds of releasing the button? 6 If automatically operated does it deactivate 5 seconds after activation? 7 Does it transmit at regular predetermined intervals? Does it poll or send supervisory information? 8 If yes does it do a system integrity check? How often? Is this a fire, security or safety of life device? 9 If YES does the device stop transmitting after the alarm condition is satisfied? Duty cycle: Maximum on-time? If YES, on-time in 100 ms? If Other, please specify here 10 On time in 11 Modulation technique: Please specify the modulation of the test sample, FM, or AFSK, or FSK, or on-off keying, or others? This device falls under 15.231 (e) APPLICANT: M+H MESSTECHNIK GMBH GERMANY FCC ID: MFFRWP38XX REPORT: M\M+H\2916GT9\2916GT9TestReport.doc Page 7 of 12 TEST EQUIPMENT LIST Device Manufacturer Model Serial Number Cal/Char Date Due Date 3/10-Meter OATS TEI N/A N/A Listed 3/20/07 3/19/10 3-Meter OATS TEI N/A N/A Listed 1/11/09 1/10/12 3-Meter Semi- Anechoic Chamber Panashield N/A N/A Listed 5/11/07 5/10/10 Analyzer Silver Tower Quasi-Peak Adapter HP 85650A 3303A01844 CAL 10/30/08 10/30/10 Analyzer Silver Tower RF Preselector HP 85685A 2620A00294 CAL 3/6/09 3/6/11 Analyzer Silver Tower Spectrum Analyzer HP 8566B Opt 462 3552A22064…
