Specifications Subject to Change without Notice Presenting the GSM/GPRS Wireless Portfolio! Enfora’s Patent Pending case design enhances your Pocket PC or Palm PDA by giving you access to worldwide GSM networks. Here are just a few of the benefits of using Enfora’s GSM/GPRS Wireless Portfolio with your Pocket PC or PalmOne PDA: • Browse the internet, send and receive emails, communicate by instant message or SMS! • Make and receive calls using your PDA, just as you would from your phone. • InfraRed connection allows the Wireless Portfolio to work with a wide variety of PDA’s. • BVRP pocket PhoneTools provides easy set up and configuration with the majority of worldwide carrier settings already preconfigured. • Integrated battery provides extended wireless data useage. • Handy carrying a case protects your PDA. Call your Enfora representative today or visit our website below. ENFORA L.P. 661 E 18 th STREET PLANO, TEXAS 75074 MAIN NUMBER: 972-633-4400 FAX: 972-633-4444 www.enfora.com GPRS Packet Data Environment Certifications Part Numbers Interface: InfraRed (IRDa) L x W x H: 6.0 x 4.0 x 1.75 in (Closed) Case: Durable Mesh/Leather Wireless: GSM/GPRS Operating System Support: PPC2000, PPC2002, PPC2003, Palm OS 4.0 Utilizes BVRP pocket PhoneTools PPC Software for access to: Dialer, Internet Explorer, SMS Manager, Instant Messenger and Phone Book. FCC: Part 15, 22 &24 GCF: Version 3.11.1 PTCRB: Version 2.9.1 Industry Canada - Power ON - Activity/Registration Operating: -10 °C to 55°C Storage -20°C to 70°C Humidity: Up to 90% non- condensing SIM Access: External GSM Antenna: Internal LED: 2 Status Indicators Audio: Headset Connector, 2.5mm GSM3208 Power Internal: 650 maH LiPolymer Battery, Rechargable: Typical Data Usage 24Hours Talk Time 3 Hours Standby 5 Days SIM Card/Interface/I/O Status Indicators System Information GSM/ GPRS W ireless Portfolio Application Interface RADIO PERFORMANCE Radio Frequency: 850/900/1800/1900 Sensitivity: -106 dB(Typical) Transmit Power: Class 4 (2W) Class 2 (1W) Multislot Class: MS-8 DATA TRANSFER Protocol: GPRS Release 99 & 97 Coding Scheme: CS1-CS4 Packet Channel: PBCCH/PCCCH GSM FUNCTIONALITY Voice: Full Rate, Enhanced full rate, and half rate CS Data: Asynchronous, trans- Parent, and non trans- Parent to 9.6 KB GSM/SMS: Text, PDU, MO/MT 7/8/04

C. Spillers Feb 5, 2004 Rev 1 Battery Charger BQ24001 Battery LED Power and Charging LED Registration State ASPEN Modem PDA IR Processor IR Connector Power Wall Plug Serial Debug USART Power On/Off Control GPIO Voice Band Codec 3.3V Aux 3.3V IR Encoder/ Decoder 22.1184 MHz XTAL 3.68 MHz XTAL Audio Headset Jack SIM card SIM Reader I R I R Chgr Status GSM3208 WIRELESS PORTFOLIO BLOCK DIAGRAM IR Cable

661 East 18 th Street Plano, Texas 75074-5601 972-633-4400 Tel 972-633-4444 Fax www.enfora.com February 9, 2004 Attn: Reviewing Engineer Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 SUBJECT: REQUEST FOR CONFIDENTIALITY FOR GSM3208, FCC ID MIVGSM3208 To whom it may concern: This letter serves as an official request for confidentiality under FCC Rule Section 0.459. We have requested that the schematic diagrams (PRT0301MG100) required to be submitted with this application be withheld from public review. This document is company proprietary information that should never get into the possession of our competition. Please contact me if there is any information you may need. Sincerely, Phillip Raymond Sr. Director, Product Development Enfora, Inc. 661 E. 18 th Street Plano, Texas 75074-5601

Enfora, L.P. 661 E. 18 th Street Plano, TX 75074-5601 (972) 633-4400 Fax (972) 633-4444 Authority to Act as Agent to the Federal Communications Commission On our behalf, I appoint MET Laboratories Inc. to act as agent in the preparation of this application for (Enfora model GSM3208) equipment authorization to the Federal Communications Commission. I certify that submitted Exhibits properly describe the device or system for which equipment authorization is sought. I also certify that each unit manufactured, imported or marketed, as defined in the Commission's regulations will have affixed to it a label identical to that submitted for approval with this application. Date: June 2, 2004 By: Scott Yarberry Title: Sr. Director, Product Development Telephone: 972-633-3560 Applicant: Enfora, L.P., 661 E. 18 th St., Plano, TX 75074

Close From: Marianne Bosley To: '[email protected]' Cc: Subject: FW: Enfora Dismissal issue TC 528357 FCC ID: MIVGSM3208 Sent: 7/12/2004 12:02 AM Importance: High AT_MSCLS.pdf GSM01xx[1].ComparisonOfProductVariants.7-7-04.pdf GSM3208 [1].LetterRegardingMS-8.7-8-04.pdf GSM3208MG000TRD_RevA[1].Pages1and6.pdf New GSM 3208 brochure.pdf -----Original Message----- From: Marianne Bosley To: '[email protected] ' Cc: Marianne Bosley; '[email protected] ' Sent: 7/11/2004 11:50 PM Subject: Enfora Dismissal issue TC 528357 FCC ID: MIVGSM3208 Importance: High Hello Steve, I am commenting on the situation with the Enfora Grant and Dismissal. These comments have been supplied by the customer, and by the testing engineer, Liming Xu. Item #1 - states apparent discrepancy between multislot mode capability. Customer confirmed that they unit operates in MS-8 (1 transmit slot) mode only. He also acknowledged the error on theire web site, and was in the process of correcting it. I have attached corrected brochure, and letter of explanation from the customer. Item #2 - Issue of whether PDA was attache when SAR testing done - Engineer writes: Because EUT must be in coninuous transmitting mode for SAR testing, and PDA can only work in normal operation mode (non-continuous transmitting), the unit had to be programmed by external PC to make the EUT continuous transmitting. During SAR testing PDA was inside portfolio, turned on, but not running the transmit program. PDA was not pictured on front page of SAR report because the portfolio was the actual EUT. Item #3 - Relationship between GSM0107 and GSM0108 modems - I have attached document explaining relationship. Being that it has been dismissed, I did not think I could upload exhibits to system. Once we have worked this issue through, and hopefully the Grant reinstated, I will upload all that is needed. If you have any questions, I will be in the office Mon - Wed. Thanks. Regards, marianne <<AT_MSCLS.pdf>> <<GSM01xx[1].ComparisonOfProductVariants.7-7-04.pdf>> <<GSM3208[1].LetterRegardingMS-8.7-8-04.pdf>> <<GSM3208MG000TRD_RevA[1].Pages1and6.pdf>> <<New GSM 3208 brochure.pdf>>

Enfora L.P. 661 E. 18 th Street Plano, TX 75074-5601 (972) 633-4400 Fax (972) 633-4444 July 8, 2004 RE: Enfora GSM3208, Question Regarding GPRS Operating Mode Reviewing FCC Engineer, We have reviewed our published data sheets for the GSM3208 regarding the Multi-Slot Class of operation and they are in error. The brochure states “Multislot Class: MS10”. This is incorrect and will be corrected next week. The brochure will be corrected to state “Multislot Class: MS-8”. We do not operate this device in MS-10 mode due to a significant decrease in battery life and the lack of need for the PDA to send large amounts of data. The software supplied with the GSM3208 does not have the capability to modify the Multi-Slot Class. I have reviewed our documentation regarding the testing of the GSM3208. The GSM3208 uses an Enfora GSM0108 Quad-Band Modem. During the final factory test of the GSM3208, the Multi-Slot class is verified as MS-8. I am attaching pages 1 & 6 of our confidential GSM3208MG000TRD (Test Requirements Document). On page 6, note the line that starts “$MSCLS: 8”. That confirms that the modem is set to MS-8 operation. I am also attaching the definition of that particular AT Command that sets/reads the MS Class. Sorry for the confusion. Let me know if you have any other questions. Regards, Scott Scott Yarberry Sr. Director, Product Development Enfora L.P. 661 E. 18 th St. Plano, TX 75074 972.633.3560 [email protected]

Enfora L.P. 661 E. 18 th Street Plano, TX 75074-5601 (972) 633-4400 Fax (972) 633-4444 July 7, 2004 Comparison of Product Variants in the Enabler II-G Family This document is designed to describe the following modules: • GSM0107 (Tri-Band module, remote SIM) • GSM0108 (Quad-Band module, remote SIM) • GSM0107-01 (Tri-Band module with on-board SIM) • GSM0108-01 (Quad-Band module with on-board SIM) • GSM0114 (US Tri-Band, remote SIM) The GSM0107 and GSM0114 versus the GSM0108: The GSM0108 Quad-Band GSM/GPRS module is based entirely on the GSM0107 Tri-Band GSM/GPRS module, the only difference being that in the GSM0108 the GSM850 band has been enabled and the RF calibration files have been populated for that band. The GSM0114 has the RF calibration tables disabled for the GSM900 band. The GSM010x versus the GSM010x-01: The GSM010x-01 versions of the module are the same as the GSM010x modules apart from the fact that the – 01 versions have been addition of the SIM connector fitted to the GSM module instead of using remote SIM. Summary: In all cases the modules run the same software and apart from the difference’s outlined above and are of the same hardware.

GSM3208 Operational Description Power Management The device uses a SPDT push button momentary switch to activate a D Flip-Flop circuit. This circuit controls the Power MOSFET that supplies battery power to the GSM/GPRS Wireless Modem (Host System). The digital circuitry is powered from a 3.3V linear regulator. It has extensive filtering at the regulator as well as the individual IC’s. A separate auxiliary.3.3V linear regulator supports the battery LED status. The device uses a single cell 650mA-hr internal non-removable battery with a built-in protection circuit. The charger is a linear charger with internal MOSFET control and external filtering. It is powered by a regulated external 5V wall mount supply. Filtering and circuit protection are accomplished with the use of a shunt capacitor, series coil, and a transorb device on the input power supply. LED status indicators Two LED’s are used to indicate battery status and registration status. Battery/Charger LED Registration LED Off State Off Off Charger Plugged in (Unit Off) Yellow Off Charger Plugged in (Unit On) Yellow X Charger Plugged in (Charge Complete) Green X On State (attempting to connected) Green Orange On State (connected to Network) Green Green Low Battery Orange X Ultra low Battery Flashing Orange X IrDA Compliant Protocol processor and IrDA Encoder/Decoder The ACT-IR8200L is a microprocessor with on-chip IrDA protocol stack. The interface to the host is via a traditional asynchronous serial data port. The ACT-IR8200L uses an external 22.1184MHz reference crystal. The host has full control of the communication sessions and data flow. The ACT-IR8200L communications to the ACT-IR220VACF (half-duplex Infrared processor) thru RS232 data lines. The ACT-IR220VACF encodes RS232 compatible data to IrDA compatible signal and decodes IrDA compatible signals to RS232 data at a baud rate up to 115.2kbps. A crystal of 3.6864MHz is used for pulse stretching and shortening, this allows for IrPHY modulation schemes. The IrDA Encoder/Decoder is connected to the transceiver thru an IR cable assembly. Audio Interface An onboard fully differential audio power amplifier is connected to the Host. A 2.5mm Audio plug is provided for user interface. Connector Interfaces 1. 60 pin connector for GSM/GPRS modem interface. 2. A SIM card reader connector 3. 6 pin De-Bug interface PCB Antenna The Enfora Wireless GSM/GPRS Portfolio is a device that incorporates an internal antenna for wireless communication. The antenna is a variation of a simple F-Type, made of copper etched on PCB, and is connected to the GSM/GPRS modem by a 45mm coaxial cable. To achieve the proper radiation pattern the field around the antenna must be free of any reference ground plane; therefore the antenna is placed in a region of the PCB void of any ground plane (approx. 1-inch wide area between the ground plane and edge of the PCB.) Normal operation of the antenna is achieved only when the portfolio is completely assembled. The dielectrics of the PCB (FR4 material, 62mil thick, 4-layer stack-up) and the plastic housing that fits over the PCB affect the tuning of the antenna. The combined dielectric of the PCB and the housing tunes the antenna to the quad band frequencies of 850,900,1800 and 1900 MHz.

LineQtyP/NTitleDetail 1GSM3208-01Wireless Portfolio, G Denim, Quad band, Aspen-based 21PRT0301MG019Leather Binder with PDA clip 31ADP-0000-0001 Adaptor, Power SuppUK adaptor for PSA-0001-0012 41ADP-0000-0002 Adaptor, Power SuppEU adaptor for PSA-0001-0012 51ADP-0000-0003 Adaptor, Power SuppUS adaptor for PSA-0001-0012 61PSA-0001-0012 Assembly, Power Su5Vdc, 5%, 2.0A, 2.35 x .7 x 7.5m 70GSM3208SW001Executable, UpgradeAspen upgrade utility for sm jalap 80GSM3208SW001DOC Document, SW upgraAspen upgrade to jalapeno instru 90GSM3200MG000TRD Test Requirements DJalapeno - G 101PRT0301MG000 Assembly, Jalapeno electronics pkg'd in hsg 111PRT0301MG000ASY Assembly document assembly instructions for sm jala 121BAT-0001-0620Battery, Li-Ion Poly m3.7 V, 650 mAh, 4.2 V Charge, 3 13.003PRT0000MG261 /4" x 36 Yd Roll, 3M cut to 6" 141CAB-1000-0040Cable Assembly, RF ultra Miniature Coaxial Cable, 4 0 15.001PRT0000MG262Tape, 1"x0.75"x36 yaCut to 1" per unit 161PRT0301MG250Assembly, IR Cable 176SCR-1000-0012Screw, Machine, Phi 0-48 x 0.1875 182LTP-0001-0007Light PipeVertical, 0.300, Round Face 191PRT0301MG200 Assembly, Top Main Hsg Plastic, mates to PRT0301M 201GSM0108MG001Assy, Quad-Band GSM/GPRS Modem 211GSM0108MG101PWB, Quad-Band G PGSM 220GSM0108MG001ASY Assembly Drawing, Quad-Band GSM/GPRS 230GSM0108MG001SCH Schematic 241GSM0107MG206Shield, Base 251GSM0107MG201Shield, Cover 261AMP-0001-3140IC, RF Amplifier, Po wQuad Band (GSM850/EGSM/DC 272ANS-0001-0002IC, Analog Switch, S RDSon=10ohm, 205MHz, MAC0 282ATT-0000-0003Attenuator, RF, SMT3 dB, 0404 292CAP-0011-0059Capacitor, SMC040 20.5 pF 302CAP-0011-0159Capacitor, SMC040 21.5 pF 312CAP-0021-0109Capacitor, SMC040 21.0 pF 322CAP-0021-0229Capacitor, SMC040 22.2 pF 332CAP-0061-0100Capacitor, SMC040 210 pF 344CAP-0061-0120Capacitor, SMC040 212 pF 352CAP-0061-0270Capacitor, SMC040 227 pF 362CAP-0061-0470Capacitor, SMC040 247 pF 371CAP-0171-0471Capacitor, SMC040 2470 pF 382CAP-0171-0102Capacitor, SMC040 21000 pF 391CAP-0171-0152Capacitor, SMC040 21500 pF 401CAP-0292-0105Capacitor, SMC060 31 uF 414CAP-0773-0475Capacitor, SMC080 54.7uF 423CAP-0783-0106Capacitor, SMC080 510 uF 4315CAP-1171-0104Capacitor, SMC040 20.1 uF 441CAP-1171-0223Capacitor, SMC040 2.022uF 451CAP-1291-0333Capacitor, SMC040 20.033 uF 462CAP-5172-0105Capacitor, SMC060 31 uF 471CON-0009-0002Connector, RF, Micr oSMT Receptacle 481CON-1050-0602Connector, Board-T o60 pin, 2x30 SMT, 2.0mm stack 490CON-1050-1201Connector, Board-T oSurface mount w/ alingment boss 500CON-4000-2002Connector, Memory SIMM, 6 pin, chip socket, hinged 511CPU-2000-0022IC, CPU, T.I. HerculeHercom G2, C035 w AMR, Digita 521FIL-0001-0030Filter, SAW, BP881.5 Mhz, 50 to 150 Ohm 531FIL-0001-0031Filter, SAW, BP942.5 Mhz, 50 to 150 Ohm 541FIL-0001-0032Filter, SAW, BP1842.5 Mhz, 50 to 150 Ohm 551FIL-0001-0033Filter, SAW, BP1960 Mhz, 50 to 150 Ohm 561FIL-0006-0002DiplexerRF, Chip multilayer, GSM850/9 0 571IND-0161-0100Inductor, SMC0402, 10 nH 581IND-0161-0220Inductor, SMC0402, 22 nH 590IND-0131-0220Inductor, SMC0402, 22 nH 601IND-0101-0629Inductor, SMC0402, 6.2nH 610IND-0121-0629Inductor, SMC0402, 6.2 nH 621IND-0161-0759Inductor, SMC0402, 7.5 nH 631IND-0101-0279Inductor, SMC0402, 2.7nH 641LDD-0001-1852IC, Linear Regulator 2.8 V, 150 mA, w/Shutdown, SO 651LGC-1000-1002IC, Logic, NAND Ga tSingle, MAC06A, Open drain 661LGC-1008-2023IC, Logic, AND Gate Dual 2-input, Nanostar8 671MEM-1100-0001IC, Memory, Flash + FLASH 32Mbit, SRAM 4Mbit, B o 681MRF-0000-4206IC, TransceiverQuad band, Integrated DCXO, 32 691MRF-1000-0002IC, DSP, CodecsCodec, Baseband + Pwr Cntrl 10 701RES-0041-1003Resistor, SMC0402, 100 k Ohms 711RES-0061-0100Resistor, SMC0402, 10 Ohms 721RES-0061-0101Resistor, SMC0402, 100 Ohms 731RES-0061-0102Resistor, SMC0402, 1.0 k Ohms 744RES-0061-0103Resistor, SMC0402, 10 k Ohms 752RES-0061-0104Resistor, SMC0402, 100 k Ohms 764RES-0061-0203Resistor, SMC0402, 20 k Ohms 771RES-0061-0472Resistor, SMC0402, 4.7 k Ohms 781RFS-0000-0010Module, RF Switch GSM850/EGSM/DCS/PCS 791TRS-0000-5006Overvoltage Transie nTVS, 6 Vbr, 5-Way Array, 100 W 801XTL-0001-1301Crystal13 MHz, 3x5mm SMT 811XTL-0001-3001Crystal32.768 kHz, 9 pF, leaded, SMT 821XTR-4000-0020Transistor, P-Chann eSingle, 2.5 V, 0.5 A, 1.25 W 831PRT0301MG101PCB, Jalapeno Sma lMain Board, 4 Layer 841PRT0301MG100PCB, MainJalapeno Small 851PRT0301MG101ASY Assembly Dwg, JalapMain Board Assy drawing 861PRT0301MG101SCH Schematic Dwg, Jal aMain Board Schematic drawing 871BMT-0001-0001IC, Battery Charger, Battery Charger Controller 883CAP-0061-0100Capacitor, SMC040 210 pF 892CAP-0061-0180Capacitor, SMC040 218 pF 902CAP-0061-0470Capacitor, SMC040 247 pF 914CAP-0161-0102Capacitor, SMC040 21000 pF 921CAP-0172-0224Capacitor, SMC060 30.22 uF 934CAP-0293-0225Capacitor, SMC080 52.2 uF 942CAP-0388-0470Capacitor, Tantalum ,470 uF, 20%, 6.3 V, 7.2 x 6.0 x 2 952CAP-0388-1063Capacitor, Tantalum,10 uf, 20%, 10V, SMC3216 9612CAP-1171-0104Capacitor, SMC040 20.1 uF 971CAP-1289-0475Capacitor, SMC121 04.7 uF 981COM-0002-0001IC, IrDADedicated Protocol Processor, 3 991COM-0002-0002IC, IrDAEncoder/Decoder, 3.3 V, 14 pin S 1001CON-1050-1602Connector, Board-To60 pin, 2x30 SMT, 2.0mm stack, 1011CON-2001-0003Connector, Board-T o7 Position, Right Angle 1021CON-2001-4002Connector, Board-T o2 Pin, Low Profile, 600V, 1A, 1m 1031CON-4000-5036Connector, Memory SIM, 8 pin, push/push 1041CON-5003-2523Connector, I/O, AudioJack, 2.5 mm Stereo, SMT 1051CON-6000-0023Connector, I/O, Pow e2.0 A, .65mm DC Power Jack/Sh 1062DIO-0001-0055Diode, ShottkyCommon Cathode, 200 mA, 30 V 1071FER-0001-1320Ferrite Bead, SMT1300 Ohms @100 MHz, High Fr 1082FER-0062-0102Ferrite Bead, SMT, S1k ohms @ 1GHz, EMI Suppress 1091FER-1000-0102Ferrite Bead, SMT, 21k ohms @ 100MHz, Filter, EMI 1102LDD-0001-3101IC, Linear Regulator 3.3 V, LDO, 150 mA max 1112LED-0001-0012LED2 Color, Yellow/Green, 1206 SM 1121LGC-1008-1020IC, Logic, AND Gate 2-Input AND Gate, SSOP5-P-0. 6 1132LGC-1014-1001IC, Logic, Inverter w/Single Gate Inverting Schmitt Tri 1141LGC-1074-1012IC, …

Text truncated - open the document above for the full version.

Enfora, L.P. 661 E. 18 th Street Plano, TX 75074-5601 (972) 633-4400 Fax (972) 633-4444 GSM3208 Tune-Up Procedure The Enfora GSM3208 contains an Enfora GSM0108 Modem. The GSM0108 Modem does not allow for any user adjustments to frequency or power output. In normal operation, the GSM network tunes the GSM0108’s radio and sets the power level. Date: June 2, 2004 By: Scott Yarberry Title: Sr. Director, Product Development Telephone: 972-633-3560 Applicant: Enfora, L.P., 661 E. 18 th St., Plano, TX 75074

SAR EVALUATION CERTIFICATE OF COMPLIANCE APPLICANT: Enfora Inc. EUT: GSM3208 Date of Receipt:January 1, 2004 Device Category:GSM MODEM RF exposure environment:Uncontrolled RF exposure category:Portable Power supply:Powered by Battery and AC/DC adaptor Antenna:Integrated Antenna Production/prototype:Identical Prototype Measured Standards:FCC OET 65 SUPPLEMENT C Modulation:GMSK Crest Factor:GMSK = 8 TX Range:1850.4 – 1909.8 MHz and 824.2 – 848.8 MHz RX Range:1930.2 – 1989.8 MHz and 869.2 – 893.8 MHz Used TX Channels: (PCS)Low: ch 1850.4 MHzCenter: ch 1880.2 MHzHigh: ch. 1909.8MHz Used TX Channels: (Cellula)Low: ch. 824.2 MHzCenter: ch 836.6 MHzHigh: ch. 848.8 MHz Maximum RF Power Output:PCS1900 band: 1.0 W Conducted and 850 band: 1.8 W Conducted Maximum SAR Measurement (averaged over: 1g) 0.82 W/kg Body (850 band ) and 1.121 W/kg Body (PCS 1900 ) Len Knight EMC Lab Manager APPLICANT NAME AND ADDRESS: DATE OF TEST:Januray 29, 2004 Enfora Inc.. TEST LOCATION:MET LABORATORIES INC. 661 East 18th Street 914 West Patapsco Ave. Plano, Texas 75074 Baltimore, Maryland 21230 This wireless portable device has been tested in accordance with the measurement procedures specified in CENELEC EN50360 and IEEE Std. 1528-200X (July 2001), and has been shown to be capable of compliance for localized specific absorption rate (SAR) for uncontrolled environment/general population exposure limits specified in ANSI/IEEE Std. C95.3 - 2002 I attest to the accuracy of this data. All reported measurements were performed by me, or were made under my supervision, and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. Enfora Inc. GSM3208 January 30, 2004 EMC14796-SAR-FCCCopyright 2003, MET Laboratories, Inc.Page 2 of 53 January 30, 2004 Enfora Inc. 661 East 18th Street Plano, Texas 75074 Reference: GSM3208 Dear Mr. Phillip Raymond: Enclosed is the EMC SAR Evaluation Report for the Enfora Inc. GSM3208. It was tested in accordance with the measurement procedures specified in FCC OET 65 SUPPLEMENT C shown to be capable to be in compliance for localized specific absorption rate (SAR) for uncontrolled environment/general population exposure limits specified in FCC OET 65 SUPPLEMENT C. Thank you for using the testing services of MET Laboratories. If you have any questions regarding these results or if MET can be of further assistance to you, please feel free to contact me. We appreciate your business and look forward to working with you again soon. Kindest Regards, MET LABORATORIES, INC. Marianne T. Bosley EMC Administrator Enclosures: DOCTEM-23 Jan 04 Certificates and reports shall not be reproduced except in full, without the written permission of MET Laboratories, Inc. The Nation’s First Licensed Nationally Recognized Testing Laboratory Enfora Inc. GSM3208 January 30, 2004 EMC14796-SAR-FCCCopyright 2003, MET Laboratories, Inc.Page 3 of 53 Dosimetric Assessment Test Report for the Enfora Inc. GSM3208 Tested and Evaluated In Accordance With FCC OET 65 SUPPLEMENT C MET REPORT: EMC14796-SAR-FCC January 30, 2004 PREPARED FOR: Enfora Inc. 661 East 18th Street Plano, Texas 75074 PREPARED BY: MET Laboratories, Inc. 914 West Patapsco Avenue Baltimore, Maryland 21230-3432 Enfora Inc. GSM3208 January 30, 2004 EMC14796-SAR-FCCCopyright 2003, MET Laboratories, Inc.Page 4 of 53 Dosimetric Assessment TEST REPORT for the Enfora Inc. GSM3208 In Accordance With FCC OET 65 SUPPLEMENT C Prepared for Enfora Inc. 661 East 18th Street Plano, Texas 75074 Report Prepared By Marianne T. Bosley EMC ADMINISTRATOR Report Reviewed By Liming Xu TEST ENGINEER Final Review By EMC LAB MANAGER Len Knight EMC LAB MANAGER Engineering Statement: The measurements shown in this report were made in accordance with the procedures specified in FCC OET 65 SUPPLEMENT C. I assume full responsibility for the accuracy and completeness of these measurements, and for the qualifications of all persons taking them. It is further stated that upon the basis of the measurements made, the equipment evaluated is capable of compliance for localized specific absorption rate (SAR) for uncontrolled environment/general population exposure limits specified in ANSI/IEEE Std. C95.3-2002.  Enfora Inc. GSM3208 January 30, 2004 EMC14796-SAR-FCCCopyright 2003, MET Laboratories, Inc.Page 5 of 53 Quick Links • Summary of test Report • EUT Description • Test Conditions • Host Laptops Used • System Validation • SAR results summary • SAR Area Scans • Setup Pictures • Measurement System  Enfora Inc. GSM3208 January 30, 2004 EMC14796-SAR-FCCCopyright 2003, MET Laboratories, Inc.Page 6 of 53 OBJECTIVE The objective of the procedure was to perform a dosimetric assessment one of the GSM3208 card. The measurements have been carried out with the dosimetric assessment system “SARA2", and were made according to the FCC OET 65 SUPPLEMENT C for evaluating compliance of mobile and portable devices with FCC OET 65 SUPPLEMENT C limits for human exposure in the general population to r…
