MIVLBH0107Portable PCS GSM Communicator

Tic TALK Copyright info 2 Contents Contents Welcome ................................................................................... 7 TicTALK Overview ..................................................................... 8 Registration ............................................................................. 12 Device basics .......................................................................... 13 Battery ......................................................................................................... 13 Control button operation .............................................................................. 14 Turn your phone ON/OFF ............................................................................ 15 Display screens............................................................................................ 16 Status bars, icons, and indicators ................................................................ 17 Backlight ...................................................................................................... 19 Device operations.................................................................... 20 Contents 3 Power-save mode ........................................................................................ 20 Auto-sleep mode.......................................................................................... 21 Menus .......................................................................................................... 21 Web configuration interface ..................................................... 24 Device management .................................................................................... 24 Log on to web site........................................................................................ 28 Numbers ......................................................................................... 29 Calendar Events............................................................................... 31 To Do List......................................................................................... 32 Settings ............................................................................................ 33 Fun Stuff........................................................................................... 38 4 Contents Notes .............................................................................................. 40 Home .............................................................................................. 41 Find Device.................................................................................... 41 Set date and time............................................................................ 42 Full update........................................................................................ 42 Using your TicTALK applications ............................................. 43 Features and applications............................................................................ 44 Make a Phone-ANYTIME call ...................................................................... 44 Make a Phone-RESTRICT call .................................................................... 45 Answer an incoming call .............................................................................. 45 Contents 5 End a call ..................................................................................................... 46 Make an EMERGENCY CALL ..................................................................... 46 Switch to handset mode during a call .......................................................... 47 Switch to headset mode............................................................................... 48 Adjust the volume during a call .................................................................... 48 View calendar events................................................................................... 49 Check your To Do list................................................................................... 50 Read and respond to a text message .......................................................... 51 View your missed calls................................................................................. 52 View photos ................................................................................................. 52 Use your stopwatch ..................................................................................... 52 Listen to a tune ............................................................................................ 53 Play Match It ................................................................................................ 53 Play Magic 8 ................................................................................................ 54 Play the Hangman game ............................................................................. 54 View countdown timers ................................................................................ 55 6 Contents Set your display contrast.............................................................................. 56 Select your watch face option ...................................................................... 56 Troubleshooting....................................................................... 57 Customer Care ........................................................................ 58 Battery Safety Precautions .......................................................................... 58 RF exposure ................................................................................................ 58 Legal Information..................................................................... 60 Limited Warranty ..................................................................... 61 Warranty Exclusive Remedy........................................................................ 61 Welcome 7 Welcome Thank you for buying the TicTALK phone.…

Text truncated - open the document above for the full version.

Enfora L.P. 661 E. 18 th Street Plano, TX 75074-5601 (972) 633-4400 Fax (972) 633-4444 Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Authority to Act as Agent to the Federal Communications Commission On our behalf, I appoint Nemko Dallas, Inc. to act as agent in the preparation of this application for (Enfora model LBH0107) equipment authorization to the Federal Communications Commission. I certify that submitted Exhibits properly describe the device or system for which equipment authorization is sought. I also certify that each unit manufactured, imported or marketed, as defined in the Commission's regulations will have affixed to it a label identical to that submitted for approval with this application. APPLICANT ANTI-DRUG ABUSE CERTIFICATION: In signing this letter, Applicant certifies that, in the case of an individual applicant, he or she is not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a), or, in the case of a non-individual applicant (e.g. corporation, partnership or other unincorporated association), no party to the application is subject to a denial of federal benefits, that includes FCC benefits, pursuant to that section. For the definition of a "party" for these purposes, see 47 CFR 1.2002(b). Date: February 11, 2005 Agency agreement expiration date: February 10, 2006 By: Bill Wrightson Title: Sr. Director, Product Development Telephone: 972-633-4430 Applicant: Enfora L.P., 661 E. 18 th St., Plano, TX 75074

Enfora L.P. 661 E. 18 th Street Plano, TX 75074-5601 (972) 633-4400 Fax (972) 633-4444 February 11, 2005 REQUEST FOR CONFIDENTIALITY Enfora L.P. requests confidentiality per CFR 47, paragraph 0.459 with regard to the following documents in the filing for equipment approval identified by FCC ID. No. MIVLBH0107. (1) Schematic diagrams contained in electronic file SDK0107MG001 & GSM0107MG001SCH6 (2) Block Diagram contained in electronic file PINEHURST_BLOCK2.PDF. It is the opinion of Enfora Inc. that disclosure of this information would result in significant loss of revenue. These documents are also covered under multiple non-disclosure agreements with other companies. This information should be kept confidential for 5 years. Bill Wrightson Sr. Director, Product Development Enfora L.P. 661 E. 18 th St Plano, TX 75074 972-633-4400

LBH0107 Circuit Description Enfora LP. 661 E. 18 th Street Plano, TX 75074-5601 (972) 633-4400 Fax (972) 633-4444 Operational Description The LBH0107 Tri-Band GSM Phone, utilizes a highly integrated transceiver that provides virtually all radio functions. Circuitry & Devices Provided for Determining & Stabilizing Frequency System Reference Clock: The transceiver uses a Digitally Controlled Crystal Oscillator (DCXO) to generate a precise system reference clock. Any initial offset error in the external crystal can be calibrated during factory test if needed. Frequency Synthesizer: The transceiver uses two complete PLL circuits, one for RF and one for the IF. The IF & RF output frequencies are controlled via software. The RF VCO is used for both transmit and receive modes. The IF VCO is only used for transmit mode. Transmitter: The transmit section uses an I/Q baseband upconverter and an offset phase-locked loop (OPPL). Circuitry & Devices Provided for Suppression of Spurious Radiation The output of the transmit VCO is a constant-envelope signal that reduces the problem of spectral spreading caused by any non-linearity in the RF Power Amplifier. Low-pass filters before the OPLL phase detector reduce the harmonic content of the Quadrature Modulator and feedback mixer outputs. A low-pass filter is also positioned in the 1900 MHz RF path between the RF PA and the RF switch to reduce spurious radiation. Circuitry & Devices Provided for Limiting Modulation All modulation waveforms are generated by the DSP in the Analog Baseband integrated circuit. Circuitry & Devices Provided for Limiting Power The RF Power Amplifier’s output level is controlled from an analog voltage generated by the Analog Baseband integrated circuit. The Power Amplifier provides an integrated power control loop that maintains the desired power output level. LBH0107 Circuit Description Enfora LP. 661 E. 18 th Street Plano, TX 75074-5601 (972) 633-4400 Fax (972) 633-4444 Circuitry & Devices Provided for USB communications The USB interface is accomplished by using an asynchronous 8-bit UART to USB controller. The controller utilizes an internal clock of 48MHz to meet the USB 2.0 specification data rate of up to 12Mbps. Data rates 115400kbps and 1Mbps are typical for this application.

Parental Control Communication Device TicTalkTM 850/1900 MHz (Dual Band) 900/1800/1900 MHz (Tri-Band) Voice Calls: Anytime Calling Restricted Calling Minutes/Numbers GSM SMS Incoming Text Message w/responses GPRS Data: Data updates Over the Air, Device Control TicTalk – Providing Peace of Mind for Parents. TicTalk provides Walkie-Talkie type communication with cellphone coverage Studies show that 9 out of 10 parents wished they had the ability to stay connected to their tweens, but they worry about huge monthly cellular bills and unwanted callers. At the same time, Tweens are frustrated when they can’t contact parents quickly to notify them of a change in plans or an unforeseen circumstance. TICTALK SOLVES ALL THIS AND MORE! TicTalk gives Tweens freedom and safety – in their coolest accessory yet. Parents appreciate control of the communication devices functions and features. Since they limit callers and specify when and how much the device is used, parents are assuredTicTalk positively enhances family communications. TicTalk is a must have for today’s Twees and parents alike – convenience, security and freedom – all in one! ENFORA, L.P 661 E 18 th STREET PLANO, TEXAS 75074 MAIN NUMBER: 972-633-4400 FAX: 972-633-4444 www.enfora.com GSM Functionality Phone Capabilities Environment Physical Information Interface: 1 Mini USB L x W x H: 84 x 54 x 22 mm Housing Polycarbonate LCD 128x128 Greyscale FSTN with backlight Buttons: Menu/ON-OFF/3-Way Rocker - Calendar - Notes - Enable “Menu Items” - Games - Control “Usage” - Priority Call - “To Do” Lists Override - Countdown Timers - “Sleep Mode” - Photo Viewer - Ring Tones - Stopwatch FCC: Part 15 and 24 GCF: Version 3.11.0 PTCRB: Version 2.9.1 Industry Canada CE Mark Ring of Lights (Optional) 3 Way Lighted Rocker Switch Battery Status, Signal Strength/Data Voice: AMR, EFR, FR, HR GSM SMS: Text Mode: Class B, Multislot 10 Protocol: GPRS Release 97 SMG 31 Operating: -20°C to 60°C Storage -20°C to 70°C Humidity: Up to 95% non- condensing SIM accessible via secure door latch Audio Speakerphone External headset Handset Mode (Tri-Band Only) LBH0104 (Dual Band Version) LBH0107 (TriBand Version) Dual or Tri Band Operation Power DC Voltage: 850mA LiIon Rechargeable Talk Time: 4 Hours Standby: 7 Days SIM Card/Audio Status Indicators Features Application Interface Web Based Over the Air or Via Local USB Certifications Part Numbers

Integration Guide Version 1.01 GSM0108PB001 Page 18 1.01 – 01/21/05 Electromagnetic Emissions Radiated spurious FCC Part 24 / Part 15 Class \ B GSM 11.10 Section 12.2 EN 55022 Class B Electromagnetic Immunity (per ETSI ETS 300 342-1) Radio Frequency (RF) Electromagnetic Field 3 V/m 800 – 1000 MHz; 1 kHz 80% EN 61000-4-3 Electrostatic discharge (ESD) Contact discharge to coupling planes: ±2 kV, ±4 kV Air discharge to coupling planes: ±2 kV, ±4 kV, ±8 kV RF common mode 3 V rms (Level 2) 150 kHz – 80 MHz EN 61000-4-6 5.3 Operating Power The Enfora Enabler II-G module requires an input voltage of 3.3 Vdc to 4.5 Vdc. 5.3.1 GSM Operating Power Enfora Enabler II-G (@ 3.76 Volts) Typical Current (mAmps ) Typical Peak Current (Amps) GSM 850 EGSM 900 GSM 1 TX 1 RX 1 RX Idle 254 mA 104 mA < 5 mA 1.6 A @ 32.5 dBm DCS 1800 GSM 1 TX 1 RX 1 RX Idle 212 mA 104 mA < 5 mA 1.2 A @ 29.5 dBm PCS 1900 GSM 1 TX 1 RX 1 RX Idle 200 mA 104 mA < 5 mA 1.4 A @ 29.5 dBm 5.3.2 GPRS Operating Power Enfora Enabler II-G (@ 3.76 Volts) Typical Current (mAmps) Typical Peak Current (Amps) GSM 850 EGSM 900 GPRS 1 TX /1RX 2 TX/ 2RX 1 TX/ 2RX 1 TX/ 3RX 1 TX/ 4RX 1 RX Idle 240 mA 422 mA 253 mA 270 mA 290 mA 104 mA < 5 mA 1.6 A @ 32.5 dBm DCS 1800 GPRS 1 TX /1RX 2 TX/ 2RX 1 TX/ 2RX 1 TX/ 3RX 1 TX/ 4RX 1 RX Idle 196 mA 350 mA 207 mA 224 mA 244 mA 104 mA < 5 mA 1.2 A @ 29.5 dBm PCS 1900 GPRS 1 TX /1RX 2 TX/ 2RX 1 TX/ 2RX 1 TX/ 3RX 1 TX/ 4RX 1 RX Idle 183 mA 325 mA 195 mA 212 mA 232 mA 104 mA < 5 mA 1.4 A @ 29.5 dBm

Enfora L.P. 661 E. 18 th Street Plano, TX 75074-5601 (972) 633-4400 Fax (972) 633-4444 February 11, 2005 Tuning Procedure Power Factory Set, No Tune up provisions needed for the LBH0107 product identified by FCC ID. No. MIVLBH0107. Bill Wrightson Sr. Director, Product Development Enfora L.P. 661 E. 18 th St Plano, TX 75074 972-633-4400

Test Report S/N: 020805MIV-T613-S24G Test Date(s): February 09, 2005 Test Type: FCC/IC SAR Evaluation Applicant: Enfora, L.P. Model:LBH0107FCC ID: MIVLBH0107IC ID: 4160A-LBH0107 Device Type: Portable Single-Band PCS GSM Communicator Frequency Range: 1850.2 - 1909.8 MHz 2005 Celltech Labs Inc. This document is not to be reproduced in whole or in part without the written permission of Celltech Labs Inc. 1 of 35 DECLARATION OF COMPLIANCE SAR RF EXPOSURE EVALUATION Test Lab CELLTECH LABS INC. Testing and Engineering Services 1955 Moss Court Kelowna, B.C. Canada V1Y 9L3 Phone: 250-448-7047 Fax: 250-448-7046 e-mail: [email protected] web site: www.celltechlabs.com Applicant Information Enfora, L.P. 661 E. 18 th St. Plano, TX 75074 United States FCC IDENTIFIER: MIVLBH0107 IC IDENTIFIER: 4160A-LBH0107 Model No.: LBH0107 Model Name: Pinehurst Rule Part(s): 47 CFR §2.1093; IC RSS-102 Issue 1 (Provisional) Test Procedure(s): FCC OET Bulletin 65, Supplement C (01-01) IEEE Standard 1528-2003 Device Description: Portable PCS GSM Communicator FCC Classification: PCS Licensed Transmitter Held to Face (PCF) Mode(s) of Operation: PCS GSM (Voice) Modulation Scheme: GMSK Tx Frequency Range(s): 1850.2 - 1909.8 MHz Max. RF Output Power: 29.9 dBm Peak Conducted (1880.2 MHz) Antenna Type(s) Tested: Internal Helical Coil Battery Type(s) Tested: Internal Lithium-ion 3.7 V, 870 mAh Body-Worn Accessories Tested: Generic Earbud with Lapel-Microphone NiteIze Small Clip Case Phone Holster with Plastic Belt-Clip Max. SAR Level(s) Evaluated: Face: 0.182 W/kg (1g average) Body: 0.418 W/kg (1g average) Celltech Labs Inc. declares under its sole responsibility that this wireless portable device has demonstrated compliance with the Specific Absorption Rate (SAR) RF exposure requirements specified in FCC 47 CFR §2.1093 and Health Canada’s Safety Code 6. The device was tested in accordance with the measurement standards and procedures specified in FCC OET Bulletin 65, Supplement C (Edition 01-01), Industry Canada RSS-102 Issue 1 (Provisional) and IEEE Standard 1528-2003 for the General Population / Uncontrolled Exposure environment. All measurements were performed in accordance with the SAR system manufacturer recommendations. I attest to the accuracy of data. All measurements were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. This test report shall not be reproduced partially, or in full, without the prior written approval of Celltech Labs Inc. The results and statements contained in this report pertain only to the device(s) evaluated. Performed By: Spencer Watson Compliance Technologist Celltech Labs Inc. Reviewed By: Russell W. Pipe Senior Compliance Technologist Celltech Labs Inc. Test Report S/N: 020805MIV-T613-S24G Test Date(s): February 09, 2005 Test Type: FCC/IC SAR Evaluation Applicant: Enfora, L.P. Model:LBH0107FCC ID: MIVLBH0107IC ID: 4160A-LBH0107 Device Type: Portable Single-Band PCS GSM Communicator Frequency Range: 1850.2 - 1909.8 MHz 2005 Celltech Labs Inc. This document is not to be reproduced in whole or in part without the written permission of Celltech Labs Inc. 2 of 35 TABLE OF CONTENTS 1.0 INTRODUCTION _____________________________________________ 3 2.0 DESCRIPTION OF DEVICE UNDER TEST (DUT) ___________________ 3 3.0 SAR MEASUREMENT SYSTEM _________________________________ 4 4.0 MEASUREMENT SUMMARY ___________________________________ 5 5.0 DETAILS OF SAR EVALUATION ________________________________ 6 6.0 EVALUATION PROCEDURES __________________________________ 6 7.0 SYSTEM PERFORMANCE CHECK ______________________________ 7 8.0 SIMULATED EQUIVALENT TISSUES ____________________________ 8 9.0 SAR SAFETY LIMITS _________________________________________ 8 10.0 ROBOT SYSTEM SPECIFICATIONS ____________________________ 9 11.0 PROBE SPECIFICATION (ET3DV6) ____________________________ 10 12.0 SAM PHANTOM V4.0C ______________________________________ 10 13.0 DEVICE HOLDER __________________________________________ 10 14.0 TEST EQUIPMENT LIST _____________________________________ 11 15.0 MEASUREMENT UNCERTAINTIES ____________________________ 12 MEASUREMENT UNCERTAINTIES (CONT.) _________________________ 13 16.0 REFERENCES _____________________________________________ 14 APPENDIX A - SAR MEASUREMENT DATA _________________________ 15 APPENDIX B - SYSTEM PERFORMANCE CHECK DATA_______________ 20 APPENDIX C - MEASURED FLUID DIELECTRIC PARAMETERS ________ 23 APPENDIX D - SAR TEST SETUP & DUT PHOTOGRAPHS _____________ 26 APPENDIX E - SYSTEM VALIDATION ______________________________ 33 APPENDIX F - PROBE CALIBRATION ______________________________ 34 APPENDIX G - SAM PHANTOM CERTIFICATE OF CONFORMITY _______ 35 Test Report S/N: 020805MIV-T613-S24G Test Date(s): February 09, 2005 Test Type: FCC/IC SAR Evaluation Applicant: Enfora, L.P. Model:LBH0107FCC ID: MIVLBH0107IC ID: 4160A-LBH0107 Device Type: Portable Single-Band PCS GSM Communicator Frequency Range: 1850.2 - 1909.8 MHz 2005 Celltech Labs Inc. This document is not to be reproduced in whole or in part without the written permission of Celltech Labs Inc. 3 of 35 1.0 INTRODUCTION This measurement report demonstrates that the Enfora, L.P. Model: LBH0107 Portable PCS GSM Communicator FCC ID: MIVLBH0107 complies with the SAR (Specific Absorption Rate) RF exposure requirements specified in FCC 47 CFR §2.1093 (see reference [1]) and Health Canada’s Safety Code 6 (see reference [2]) for the General Population / Uncontrolled Exposure environment. The test procedures described in FCC OET Bulletin 65, Supplement C, Edition 01- 01 (see reference [3]), IC RSS-102 Issue 1 (Provisional) (see reference [4]), and IEEE Standard 1528-2003 (see reference [5]) were employed. A description of the product and operating configuration, detailed summary of the test results, methodology and procedures use…

Text truncated - open the document above for the full version.

Nemko Test Report: 5L0053RUS1 Applicant: Enfora, Inc. Equipment Under Test: LBH0107 Tri-Band Phone (E.U.T.) In Accordance With: FCC Part 24, Subpart E Broadband PCS Subscriber Station Tested By: Nemko USA Inc. 802 N. Kealy Lewisville, TX 75057-3136 Authorized By: Tom Tidwell, Frontline Manager Date: 7 March 2005 Nemko USA, Dallas Facility FCC PART 24, SUBPART E BROADBAND PCS SUBSCRIBER STATION EQUIPMENT: LBH0107 Tri-Band Phone Test Report No.: 5L0053RUS1 Page 2 of 27 Table of Contents Section 1. Summary of Test Results ................................................................................... 3 Section 2. General Equipment Specification ..................................................................... 5 Section 3. RF Power Output ............................................................................................... 7 Section 4. Occupied Bandwidth.......................................................................................... 8 Section 5. Field Strength of Spurious............................................................................... 10 Section 7. Frequency Stability .......................................................................................... 15 Section 8. Test Equipment List......................................................................................... 17 ANNEX A - TEST METHODOLOGIES ............................................................................... 18 ANNEX B - TEST DIAGRAMS .............................................................................................. 24 Nemko USA, Dallas Facility FCC PART 24, SUBPART E BROADBAND PCS SUBSCRIBER STATION EQUIPMENT: LBH0107 Tri-Band Phone Test Report No.: 5L0053RUS1 Page 3 of 27 Section 1. Summary of Test Results Manufacturer: Enfora, Inc. Model No.: LBH0107 Serial No.: None General: All measurements are traceable to national standards. These tests were conducted on a sample of the equipment for the purpose of demonstrating compliance with FCC Part 24, Subpart E. New Submission Production Unit Class II Permissive Change Pre-Production Unit THIS TEST REPORT RELATES ONLY TO THE ITEM(S) TESTED. THE FOLLOWING DEVIATIONS FROM, ADDITIONS TO, OR EXCLUSIONS FROM THE TEST SPECIFICATIONS HAVE BEEN MADE. See “ Summary of Test Data”. Nemko USA Inc. authorizes the above named company to reproduce this report provided it is reproduced in its entirety and for use by the company’s employees only. Any use which a third party makes of this report, or any reliance on or decisions to be made based on it, are the responsibility of such third parties. Nemko USA Inc. accepts no responsibility for damages, if any, suffered by any third party as a result of decisions made or actions based on this report. This report applies only to the items tested. Nemko USA, Dallas Facility FCC PART 24, SUBPART E BROADBAND PCS SUBSCRIBER STATION EQUIPMENT: LBH0107 Tri-Band Phone Test Report No.: 5L0053RUS1 Page 4 of 27 Summary Of Test Data NAME OF TEST PARA. NO. RESULT RF Power Output 24.232 Complies Occupied Bandwidth 24.238 Complies Spurious Emissions at Antenna Terminals 24.238(a) NA Field Strength of Spurious Emissions 24.238(a) Complies Frequency Stability 24.235 Complies Footnotes: The phone has an integral antenna. Nemko USA, Dallas Facility FCC PART 24, SUBPART E BROADBAND PCS SUBSCRIBER STATION EQUIPMENT: LBH0107 Tri-Band Phone Test Report No.: 5L0053RUS1 Page 5 of 27 Section 2. General Equipment Specification Supply Voltage Input: 3.6 Vdc Battery Frequency Bands: Block A : 1850 – 1865 MHz Block B : 1865 – 1870 MHz Block C : 1870 – 1885 MHz Block D : 1885 – 1890 MHz Block E : 1890 – 1895 MHz Block F : 1895 – 1910 MHz CDMA GSM NADC (F9W) (GXW) (DXW) Type of Modulation and Designator: Emission Designator: 300KGXW Necessary Bandwidth: 300 kHz Output Impedance: 50 ohms RF Output (Rated): 0.5 W eirp Nemko USA, Dallas Facility FCC PART 24, SUBPART E BROADBAND PCS SUBSCRIBER STATION EQUIPMENT: LBH0107 Tri-Band Phone Test Report No.: 5L0053RUS1 Page 6 of 27 System Description The phone is a tri-band GSM phone operating in the 900 MHz GSM band, 1800 DCS band and 1900 PCS band. System Diagram Nemko USA, Dallas Facility FCC PART 24, SUBPART E BROADBAND PCS SUBSCRIBER STATION EQUIPMENT: LBH0107 Tri-Band Phone Test Report No.: 5L0053RUS1 Page 7 of 27 Section 3. RF Power Output NAME OF TEST: RF Power Output PARA. NO.: 2.1046 TESTED BY: David Light DATE: 3-3-05 Test Results: Complies. Measurement Data: Frequency (MHz) Output Power EIRP (Watts) Output Power EIRP (dBm) 1850.2 0.275 24.4 1880.2 0.363 25.6 1909.8 0.490 26.9 Note: Measurements were done radiated using the signal substitution method of measurement. Equipment Used: 1304-1036-1484-1485 Measurement Uncertainty: +/- 1.7 dB Temperature: 22 °C Relative Humidity: 45 % Nemko USA, Dallas Facility FCC PART 24, SUBPART E BROADBAND PCS SUBSCRIBER STATION EQUIPMENT: LBH0107 Tri-Band Phone Test Report No.: 5L0053RUS1 Page 8 of 27 Section 4. Occupied Bandwidth NAME OF TEST: Occupied Bandwidth PARA. NO.: 2.1047 TESTED BY: David Light DATE: 11/10/2004 Test Results: Complies. Test Data: See attached plots. Nemko USA, Dallas Facility FCC PART 24, SUBPART E BROADBAND PCS SUBSCRIBER STATION EQUIPMENT: LBH0107 Tri-Band Phone Test Report No.: 5L0053RUS1 Page 9 of 27 Test Data – Occupied Bandwidth Dallas Headquarters: 802 N. Kealy Lewisville, TX 75057 Tel: (972) 436-9600 Fax: (972) 436-2667 Nemko Dallas, Inc. Data Plot Page 1 of 1 Job No.:4L0655RDate: 11/11/2004 Specification: PT24 Temperature(°C): 19 Tested By: David Light Relative Humidity(%) 40 E.U.T.: Configuration: Notes: Occupied Bandwidth Dual Band Phone TX 20 dB Bandwidth = 300 kHz Nemko USA, Dallas Facility FCC PART 24, SUBPART E BROADBAND PCS SUBSCRIBER STATION EQUIPMENT: LBH0107 Tri-Band Phone Test Report No.: 5L0053RUS1 Page 10 of 27 Section 5. Field Strength of Spurious NAME OF TEST: Field Strength of Spurious PARA. NO.: 2.1053 TESTED BY: David Light DATE: 3/3/05 Test Results: Complies. Test Data: See attach…
