MIVWLN802BWireless LAN Portfolio

1 Enfora Wireless Portfolio User Manual 2 This manual is copyrighted. All rights reserved. No portion of this document may be copied, photocopied, reproduced, translated, or reduced to any electronic medium or machine form without prior consent in writing from Enfora, Inc. © 2003 Enfora, Inc. All rights reserved. The information in this document is subject to change without notice and does not represent a commitment on the part of Enfora, Inc. Adobe® Acrobat Reader, © 1987-1999 Adobe Systems Inc. All rights reserved. Adobe and Acrobat are trademarks of Adobe Systems Inc. Enfora, Inc. 661 East 18 th Street Plano, TX 75074 USA www.enfora.com Enfora, Inc. Proprietary Information WP802b001MAN The products and specifications, configurations, and other technical information regarding the services described or referred in this guide are subject to change without notice. All statements, technical information, and recommendations contained in this guide are believed to be accurate and reliable, but are presented “as is”, without warranty of any kind, expressed or implied. Users must take full responsibility for their application of any products specified in this document. Enfora, Inc. makes no implied warranties of merchantability or fitness for a purpose as a result of this guide or the information described within, all other warranties, express or implied, are excluded. 3 Contents Regulatory Information 4 Device Compatibility 5 Getting Started 5 Software Installation 5 Placing the Palm® handheld into the Wireless Portfolio 5 Configuring the Enfora WP802b 5 Entering the Network ID 7 Setting Encryption 8 Selecting the Key Index 9 Selecting the Key Length 10 Saving Settings 11 Connecting 12 Wireless Portfolio LED’s 12 Battery Charging 12 Device Compatibility List 13 4 Regulatory Information The equipment certifications appropriate to your device are marked on the device and product specific information. The use of the equipment is subject to the following conditions: FCC COMPLIANCE STATEMENT This device complies with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. CAUTION Changes or modifications without the express consent of Enfora, Inc. void the user’s authority to use the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in an appropriate installation. This equipment generates, uses, and can radiate radio frequency energy and, if not used in accordance with instructions, can cause harmful radiation to radio communication. However, there is no guarantee that interference will not occur in a particular installation. If the equipment does cause harmful interference in radio and television reception, which can be determined by turning the equipment on and off, the user is encouraged to try to correct the interference by one or more of the following measures: Reorient or relocate the receiving antenna. Increase the separation distance between the equipment and the receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Contact Enfora, Inc. Technical Support for assistance. FCC Radiation Exposure Statement 1. CAUTION: This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. 2. This Transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. The Federal Communications Commission (FCC) with its action in ET Docket 96-8 has adopted a safety standard for human exposure to radio frequency (RF) electromagnetic energy emitted by FCC certified equipment. Enfora products meet the uncontrolled environmental limits found in OET-65 and ANSI C95.1, 1991.Proper operation of this radio according to the instructions found in this manual and the hardware and software guides on the CD will result in user exposure that is substantially below the FCC recommended limits. 5 Getting Started This section explains how to setup the Enfora WP802b for use with a Palm® handheld device with OS 3.51 – 5.2.1. Software Installation 1. Run the Enfora program 802Mgr.exe and follow the install wizard. The Enfora program is located on the 802.11b beta version CD. 2. After completing the installation you will be prompted to perform a Hotsync. 3. Dock you Palm® device and then perform a HotSync. Placing the Palm® handheld into the Wireless Portfolio ß Adhere the provided female Velcro strip to the back of your Palm® handheld and the male Velcro strip on the inner right side of the Wireless Portfolio. ß Attach the Palm® Universal Adaptor on the Wireless portfolio to your Palm® handheld. ß Place your Palm® handheld on the inner right side of the Wireless Portfolio. Configuring Enfora 802.11b Wireless Portfolio 1. First power on the Wireless Portfolio. The power button is located on the left-hand side of the Wireless Portfolio just above the 2 LED’s. It is placed on the inner edge of the Wireless Portfolio. Next select the Wi-Fi icon from the home screen of your Palm® handheld. 6 2. The Wi-Fi Manager screen will appear. Select the preference icon on you Palm® handheld. 3. Select Network from the Options menu. 7 4. Enter Network ID. The Network ID is also referred to as the SSID. To enter your Network ID Tap on ANY. If your wireless network does not require a Network ID (SSID) you can leave the Network ID as ANY. 5. Entering a new Network ID (SSID). In the Network ID field highlight ANY and then enter your Network ID (SSID) of your access point. 8 6. Encryption level. By default Data Encryption is disabled. To enabled encryption select Data Encryption (WEP enabled…

Text truncated - open the document above for the full version.

Battery Charger BQ24012 Battery LED Charging LED State ARM Processor PN: AT91R40807 8 KB RAM 0 KB Flash JTAG conn PDA 232 level shift MAX3243CDBR Addr/Data FLASH mem 4Mb 120ns Power Distribution Switch PN:TPS2041A 6MHz XTAL Header/ connector USB UHC124 PLL Memory/MCU Interface Port 1 Port 2 Port 3 Port 4 Palm wall plug 5V Power Condition VBAT 802.11b Samsung USB module SRAM 1Mb OSC/ XTAL 7.3728 MHz Serial Debug USART Power On/Off Control Status LED GPIO Memory Control 3.3V RESET Low Bat LED

The Nation's First Licensed Nationally Recognized Testing Laboratory Conceil canadien des nomes Organisme de certification accedite Standards Council of Canada Accredited Certification Organization TM MET Laboratories, Inc. Safety Certification - EMI - Telecom Environmental Simulation 914 WEST PATAPSCO AVENUE !! BALTIMORE, MARYLAND 21230-3432 !! PHONE (410) 354-3300 !! FAX (410) 354-3313 October 2, 2003 Enfora Inc. 661 East 18th Street Plano, Texas 75074 Reference: Wireless Portfolio WP802b FCC ID: MIVWLN0101 Dear Mr. Phillip Raymond: Enclosed is the EMC Test Report for the Enfora Inc.. The Enfora Inc Wireless Portfolio WP802b was tested to the requirements of the FCC Rules and Regulations, Section 15.247, of Title 47 of the CFR, for a Part 15 Transmitter. Thank you for using the testing services of MET Laboratories. If you have any questions regarding these results or if MET can be of further assistance to you, please feel free to contact me. We appreciate your business and look forward to working with you again soon. Kindest Regards, MET LABORATORIES, INC. Marianne T. Bosley Documentation Department Enclosures: (\Enfora Inc.\EMC14139-FCC247.rpt) DOCTEM-23 Jan 02 Certificates and reports shall not be reproduced except in full, without the written permission of MET Laboratories, Inc. While use of the National Voluntary Laboratory Accreditation Program (NVLAP) letters or the NVLAP Logo in this report reflects the MET Accreditation under the NVLAP Program, these letters, logo, or Statements do not claim product endorsement by NVLAP or any Agency of the U.S. Government. Enfora Inc. Wireless Portfolio WP802b FCC ID: MIVWLN0101September 20, 2003 Electro-Magnetic Compatibility Test Report for the Enfora Inc. Wireless Portfolio WP802b Tested Under FCC Part 15 Subpart C Section 15.247 Title 47 of the CFR for Intentional Radiators MET REPORT: EMC14139-FCC247 September 20, 2003 PREPARED FOR: Enfora Inc. 661 East 18th Street Plano, Texas 75074 PREPARED BY: MET Laboratories, Inc. 914 West Patapsco Avenue Baltimore, Maryland 21230-3432 Copyright 2003, MET Laboratories, Inc. This report shall not be reproduced except in full, without the express written consent of MET Laboratories, Inc., nor shall this report, or any copy thereof be provided to a competitor of MET Laboratories, Inc. Enfora Inc. Wireless Portfolio WP802b FCC ID: MIVWLN0101September 20, 2003 MET Report: EMC14139-FCC247Copyright 2003, MET Laboratories, Inc.Page ii of v Electro-Magnetic Compatibility Test Report for the Enfora Inc. Wireless Portfolio WP802b Tested Under FCC Part 15 Subpart C Section 15.247 Title 47 of the CFR for Intentional Radiators MET REPORT: EMC14139-FCC247 September 20, 2003 PREPARED FOR: Enfora Inc. 661 East 18th Street Plano, Texas 75074 ______________________________________________________________ Christopher R. Harvey, DirectorMarianne T. Bosley Electromagnetic Compatibility TestingReport Writer Engineering Statement: The measurements shown in this report were made in accordance with the procedures indicated, and the emissions from this equipment were found to be within the limits applicable. I assume full responsibility for the accuracy and completeness of these measurements, and for the qualifications of all persons taking them. It is further stated that upon the basis of the measurements made, the equipment tested is capable of operation in accordance with the requirements of Part 15, Section 15.247, of the FCC Rules under normal use and maintenance. ________________________________ Liming Xu Project Engineer Enfora Inc. Wireless Portfolio WP802b FCC ID: MIVWLN0101September 20, 2003 MET Report: EMC14139-FCC247Copyright 2003, MET Laboratories, Inc.Page iii of v Table of Contents I. Executive Summary...........................................................................1 A.Purpose of Test.......................................................................2 B.Executive Summary....................................................................2 II. General.....................................................................................3 A.Test Site.............................................................................4 B.Description of Test Sample..............................................................4 C.General Test Setup....................................................................4 D.Mode of Operation....................................................................4 E.Modifications.........................................................................7 F.Disposition of Test Sample..............................................................7 III. Antenna Requirements.........................................................................8 IV. Emissions Requirements......................................................................10 A.Conducted Emissions.................................................................11 B.Radiated Emissions - General...........................................................17 V.Bandwidth & Bandedge Requirements...........................................................20 VI. Peak Output Power Requirements...............................................................26 A.Peak Output Power (Conducted).........................................................27 B.RF Exposure Requirements.............................................................29 VII. Spurious Emissions - Radiated & RF Conducted - Requirements.......................................30 VIII. Power Spectral Density Requirements............................................................37 IX.Test Equipment.............................................................................41 X.Certification Label & User's Manual Information...................................................43 A.Certification Information...............................................................44 B.Label and User's Manual Information.....................................................47 Enf…
