MMFS8486EX-BTBluetooth module

Bluetooth Module “BT 301(VRB4123-0102E) Bluetooth Module This module is limited to the use of bar code printer s-84/86 series. Dimensions 245 (W) X 408 (D) X 300 (H) mm (9.6” X 16.1” X 11.8”) except protruding parts Weight 16.0 kg (35.3 lbs) Power requirements (1) Input voltage: AC 100 - 240 V, ±10 % (2) Frequency: 50/60 Hz(3) Power consumption Input power voltage condition: AC 115 V / 50 HzAt peak: 180 VA / 180 W (at 30 % printing ratio)Standby: 30 VA / 25 W Environmental conditions (Temperature/Humidity) (1) Operating: -5 - 40 ºC (23 - 104 ºF), 15 - 80 % RH (non- condensing) (2) Storage: -20 - 60 ºC (-4 - 140 ºF), 15 - 90 % RH (non- condensing) PRINT SPECIFICATIONS Model namePrint method Direct thermal and Thermal transfer Head density(Resolution) 203 dpi (8 dots/mm) OPERATING CHARACTERISTICS Ɫ⚮ ᾒᡢὯⱢ⚮#ℓ⟇㫎ᧆ#⃪᢮偩㩞▫᢮偪 ᣃⱻ㭂ᆧ 609 dpi (24 dots/mm) ጚ⇢▖⩻ Basic Specifications Wesentliche technische Daten Especificaciones Básicas Especificações Básicas ESPECIFICACIONES DE LA IMPRESIÓN Nombre del modeloMétodo de impresiónDensidad de cabezales(Resolución) CARACTERÍSTICAS DE OPERACIÓN ESPECIFICAÇÕES DA IMPRESSÃO Nome do modeloMétodo de impressão Impressão térmica direta e Transferência térmica Densidade do cabeçote(Resolução) 203 ppp (8 pontos/ mm) CARACTERÍSTICAS OPERACIONAIS S84ex/S86ex 305 ppp (12 pontos/ mm) Spécifications de base S84ex/S86exQuick GuideKurzanleitungGuide RapideGuía RápidaGuia Rápido㔟#ცⱞᧆ First edition: Apr 2014 Q04522500©2014 SATO CORPORATION Q04522500 S84ex/S86ex 305 dpi (12 dots/mm) 609 ppp (24 pontos/ mm) Abmessungen 245 (B) X 408 (T) X 300 (H) mm, ausgenommen hervorstehe-nde Teile. Gewicht 16,0 kg Spannungsversorgung (1) Eingangsspannung: WS 100 - 240 V, ±10 % (2) Frequenz: 50/60 Hz(3) Leistungsaufnahme Eingangsspannungsbedingungen: WS 115 V / 50 HzBei Spitze: 180 VA / 180 W (bei 30 % Druckverhältnis)Im Bereitschaftszustand: 30 VA / 25 W Umgebungsbedingungen (Temperatur/ Luftfeuchtigkeit) (1) Bei Betrieb: -5 - 40 ºC, 15 - 80 % rel. F. (nicht kondensier- end) (2) Bei Lagerung: -20 - 60 ºC, 15 - 90 % rel. F. (nicht konden- sierend) DRUCKDATEN ModellnameDruckverfahren Thermodirekt oder Thermotransfer 203 dpi (8 Punkte/ mm) BETRIEBSDATEN 609 dpi (24 Punkte/ mm) S84ex/S86ex 305 dpi (12 Punkte/ mm) ಺⚞#Ჹ#⚞⢮⅖ 536#gsl +;#ᑮ10点2pp, 93<#gsl +57#ᑮ10点2pp, S84ex/S86ex 638#gsl +45#ᑮ10点2pp, ㍂✂ 578#+Z,#[#73;#+G,#[#633#+K,#pp##ᑶ⹆Ḫጾ#⣆✢ ⷻᲳ 4913#nj ⳮ⮺#▖⩻ 䰩4䰪⠯ᣏ⢮◿=#DF#433#0#573#Y/#䮃43#(䰩5䰪⦦㎶⋂=#83293#K}䰩6䰪∶Ữ⢮ᣏ ⠯ᣏ⢮◿#⤚ഞ=#DF#448#Y#2#83#K}㗦ㄖ#⎆=#4;3#YD#2#4;3#Z#+dw#63#(#⠢≮#Ữ⟒♺⇆,Ꭺ໚#⎆=#63#YD#2#58#Z 㭂ᆧ#ⵚᅞ#+⬒᢮2➟᢮, 䰩4䰪⤚⠻#㜂൧=#08#0#73#䮋F/#48#0#;3#(#UK#+᎒/#൚ᤆಪ#♰⟮# ഭ, 䰩5䰪ᶞඪ#㜂൧=#053#0#93#䮋F/#48#0#<3#(#UK#+᎒/#൚ᤆಪ# ♰⟮#ഭ, Térmica directa y de Transferencia térmica 203 ppp (8 puntos/ mm) 609 ppp (24 puntos/ mm) S84ex/S86ex 305 ppp (12 puntos/ mm) Dimensiones 245 (An) X 408 (P) X 300 (Al) mm excepto las partes salientes. Peso 16,0 kg Requisitos de alimentación de corriente (1) Voltaje de entrada: AC 100 - 240 V, ±10 %(2) Frecurencia: 50/60 Hz(3) Consumo de Energía Condiciones de voltaje de entrada de corriente: AC 115 V / 50 HzMáximo: 180 VA / 180 W (con 30% impreso)En standby: 30 VA / 25 W Condiciones ambientales (Temperatura/ Humedad) (1) En funcionamiento: -5 - 40 ºC, 15 - 80 % RH (sin conden- sación) (2) En almacenaje: -20 - 60 ºC, 15 - 90 % RH (sin conden- sación) Dimensões 245 (L) X 408 (P) X 300 (A) mm exceto as partes salientes. Peso 16,0 kg Requisitos de alimentação de energia (1) Voltagem: AC 100 - 240 V, ±10 %(2) Frequência: 50/60 Hz(3) Consumo de Energia Condições de voltagem de alimentação de energia: AC 115 V / 50 HzMáximo: 180 VA / 180 W (com 30% de impressão)Em standby: 30 VA / 25 W Condições ambientais (Temperatura/ Humidade)) (1) Funcionamento: -5 - 40 ºC, 15 - 80 % HR (sem conden- sação) (2) Armazenamento: -20 - 60 ºC, 15 - 90 % HR (sem conden- sação) Dimensions 245 (L) X 408 (P) X 300 (H) mm sans les parties saillantes Poids 16,0 kg Spécifications pour l’alimentation électrique (1) Tension d’entrée: CA 100 - 240 V, ±10 % (2) Fréquence: 50/60 Hz(3) Puissance consommée Specification sur la tension d’alimentation: CA 115 V / 50 HzTension électrique max: 180 VA / 180 W (à 30 % taux d'impression)Veille: 30 VA / 25 W Conditions d'utilisation (Température / Humidité) (1) En service: -5 - 40 ºC, hygrométrie 15 - 80 % (sans conden- sation) (2) En stockage: -20 - 60 ºC, hygrométrie 15 - 90 % (sans condensation) SPECIFICATIONS D’IMPRESSION Nom du modèle Direct thermique et Transfert thermique 203 dpi (8 points/mm) CARACTERISTIQUES DE FONCTIONNEMENT 609 dpi (24 points/mm) S84ex/S86ex 305 dpi (12 points/mm) Noise(EMC)standards / EMC-Normen, Geräuschnormen / Normes relatives aux interférences (EMC) / Estándares de ruido (EMC) / Padrões de emissão de ruído (EMC) / ᙢⱞ⹲#+HPF,#㥆ⷪ FCC15B Class A, ICES-003 Class AEN55022, EN55024, KN22, KN24GB9254, GB17625.1 Safety standards / Sicherheitsstandards / Normes de sécurité / Estándares de seguridad / Padrões de segurança / ⨲ⳮ㥆ⷪ UL 60950-1, CSA C22.2 No.60950-1EN60950-1, K60950-1GB4943.1 Lärm-Emmissionswert < 70 dB(A) RoHS-RichtlinieWir haben uns verpflichtet, nur Materialien zu verwenden, diekeine von der RoHS-Richtlinie betroffenen Substanzen enthalten.Von der RoHS-Richtlinie betroffene Substanzen (6 Stoffe) Sechswertiges Chrom .......................... 0,1 % oder wenigerBlei........................................................ 0,1 % oder wenigerQuecksilber........................................... 0,1 % oder weniger Cadmium ............................................ 0,01 % oder weniger Polybromierte Biphenyle(PBB) ............. 0,1 % oder weniger Polybromierte Diphenylether(PBDE) .... 0,1 % oder weniger Thermokopf-Druckdichte(Auflösung) Méthoded’impression Densité de la tête (Résolution) Open Source SoftwareThis printer product includes open source software applied to the open source software license. Please see our web site for more information.http://www.satoworldwide.com/licenses/OSS.aspx This product is also designed for IT power distribution system with phase-to…

Text truncated - open the document above for the full version.

(MUST BE ON COMPANY LETTERHEAD AND SIGNED BY OFFICIAL OF APPLICANT COMPANY) （ （（ （ここへ ここへここへ ここへ御社 御社御社 御社のカンパニーレターヘッドを のカンパニーレターヘッドをのカンパニーレターヘッドを のカンパニーレターヘッドを必 必必 必ず ずず ず貼付 貼付貼付 貼付してください してくださいしてください してください） ）） ） DATE : June 20, 2014 Equipment Autorisation Division Federal Communications Commission 74 35 Oakland Mills Road Columbia, MD 21046 FCC ID: MMFS8486ex-BT Product Name:_Bluetooth Module, Model BT301(VRB4123-0102E)_______ Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commissions rules, we hereby request that the following documents be held confidential: (List here the documents for which you are seeking confidentiality ± for example ...) • Block diagram • S chematics • Operational Description • Parts Lists Th ese materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. Dated this 20 Day of Ju ne 20 14 By: Mamoru Kido Signature Printed Title: Group Manager On behalf of : Sato Corporation Telephone: +81-3-5745-3450

DATE : July 22, 2014 Ne mk o Canada Inc 303 River Road Ottawa, Ontario, Canada K1V 1H2 Attn: Director of Certification Request for Limited Single Modular Approval for FCC ID: MMFS8486EX- BT Please accept our request for Limited Single Modular Approval in accordance with the requirements of 15.212 as described below. 15.212(a)(1) Single modular transmitters must meet the following requirements to obtain a modular transmitter approval for use in the grantee’s own Barcode Printer S-84 /86 series, Model BT301(VRB4123-0102E). (i) This module does not have its own shielding because this is a Limited Modular Approval for use in the grantee’s own Barcode Printer S-84 /86 series. (ii) This module has data buffer. Data input to Modular transmitter is controlled as not generating excessive data speed and abnormal modulation. (iii) This module is integrated with Power Supply regulator. (iv) This module has a dedicated antenna that is soldered to PCB. No other antenna except ones that were tested can be used with the equipment and that the end user cannot easily use and unapproved antenna. (v) This module was tested inside the grantee’s own Barcode Printer , Model S-84-ex. For conducted emissions as this is representative of a typical installation. This is a limited modular approval for use in the grantee’s own Bluetooth Module, Model BT301(VRB4123-0102E). (vi) The Barcode Printer S-84 /86 series will be labeled with "Contains FCC ID: MMFS8486EX-BT" (vii) This module complies with requirements of part 15.207 for AC power line conducted emissions and part 15.247 for operation in 2.4 GHz frequency band and must only be used with the following antenna that were tested in this filing: (viii) This module complies with the general population/uncontrolled exposure requirements of 1.1310 for fixed indoor and outdoor applications at a distance of 20 cm or more from the radiating element using antennas that were tested in this filing. Dated this 22 Day of July 20 14 Agency agreement expiration date: Usually Give 8 - 12 Months By: Mamoru Kido Signature Printed Title: Group Manager On behalf of : Sato Corplation Telephone: +81-3-5745-3450

Prediction of MPE limit at a given distanc e Equation from pa g e 18 of OET Bulletin 65, Edition 97-01 where: S = p ower densit y P = p ower in p ut to the antenna G = p ower g ain of the antenna in the direction of interest relative to an isotro p ic radiato r R = distance to the center of radiation of the antenna Maximum p eak out p ut p ower at antenna in p ut terminal: 1.16 ( dBm ) Maximum p eak out p ut p ower at antenna in p ut terminal: 1.31 ( mW ) A ntenna g ain ( t yp ical ) : 2.0 ( dBi ) Maximum antenna g ain: 1.58 ( numeric ) Prediction distance: 20 ( cm ) Prediction fre q uenc y : 2441 ( MHz ) MPE limit for uncontrolled ex p osure at p rediction fre q uenc y : 1 ( mW/cm^2 ) Power densit y at p rediction fre q uenc y : 0.000412 ( mW/cm^2 ) Power densit y at p rediction fre q uenc y : 0.00412 ( W/m^2 ) Maximum allowable antenna g ain: 35.9 ( dBi ) Mar g in of Com p liance: 33.9 ( dB ) 2 4 R PG S  

Page 2 of 44 Test Report No. R121647-1 Rev.01 List of Contents Page 1. General Information............................................................................................................................3 1.1 Product Description........................................................................................................................3 1.2 Antenna Description......................................................................................................................3 1.3 Tested System Details....................................................................................................................4 1.4 Test Methodology...........................................................................................................................5 1.5 Test Facility....................................................................................................................................5 1.6 Traceability.....................................................................................................................................5 2. Test Condition (Manufacturer’s Specification)..................................................................................5 2.1 Mode of Operation..........................................................................................................................5 2.2 Test Configuration.........................................................................................................................6 2.3 EUT Angle....................................................................................................................................10 3. Summary of Test Results..................................................................................................................10 4. Measurement Result..........................................................................................................................11 4.1 15.207 AC Power Line Conducted Emission.............................................................................11 4.2 15.209 Radiated Spurious Emission..........................................................................................18 4.3 15.215(c) 20 dB bandwidth.........................................................................................................26 4.4 15.247(b) Maximum Peak Conducted Output Power................................................................29 4.5 15.247(a) Carrier Frequency Separation...................................................................................33 4.6 15.247(a) Number of Channels...................................................................................................35 4.7 15.247(a) Time of Occupancy......................................................................................................36 4.8 15.247(d) Conducted Spurious Emission...................................................................................38 4.9 15.247(d) Band Edge Measurement...........................................................................................40 5. List of Test Measurement Instruments............................................................................................42 6. Appendix.............................................................................................................................................44 ERF130328 Cosmos Corporation QAF1466 Issued: 13//03/01 Revised: 14/02/12 Page 3 of 44 Test Report No. R121647-1 Rev.01 1. General Information 1.1 Product Description SATO Corporation, Model BT301(VRB4123-0102E) (referred to as the EUT in this report) is Bluetooth Module. Manufacturer SATO Corporation Model (referred to as the EUT) BT301(VRB4123-0102E) Transmitter Type WLAN Bluetooth Zigbee RFID Other ( ) Nominal VoltageDC 5 V Type of ModulationFSK, PSK (FHSS) Mode of Operation Simplex D uplex O ther Type of the Equipment Stand-alone Combined Equipment Plug-In Card Other ( Module unit ) Type of the AntennaIntegral E xternal Other Type of Power Source AC mains Dedicated AC adapter ( V ) DC Voltage Battery Type of Battery (if applicable)None Type of OperationContinuous Burst Intermittent Frequency Band Lower limit Upper limit 2400 MHz 2483.5 MHz Frequency of Operation 2402 MHz to 2480 MHz Thermal Limitation 5 °C to 40 °C 1.2 Antenna Description It is impossible for end users to replace the antenna, because the antenna is mounted inside of the EUT. Therefore, the equipment complies with the antenna requirement of Section 15.203. No.ModelGainAntenna TypeRemarks 1ANT8030-01A2.0 dBi Multilayer Chip Antenna Integral ERF130328 Cosmos Corporation QAF1466 Issued: 13//03/01 Revised: 14/02/12 Page 4 of 44 Test Report No. R121647-1 Rev.01 1.3 Tested System Details InstrumentModelSerial No.FCC IDRating EUT1 (Bluetooth Module) BT301(VRB4123- 0102E) KFCY0012 * 1 --- DC 5 V EUT2 (Bluetooth Module) BT301(VRB4123- 0102E) KFCY0017 * 2 --- DC 5 V Barcode Printer S84-ex (203dpi, RH) * 3 * 5 3K-002--- AC 100-240 V, 50-60 Hz, 7 A Barcode Printer S84-ex (203dpi, LH) * 4 * 5 3K-009--- AC 100-240 V, 50-60 Hz, 7 A Personal Computer0DW634 CN-0DW634-70166- 9B8-G08U-A04 DoC DC 19.5 V, 4.62 A AC Adapter LA90PE0-01 CN-03T6XF-71615- 05B-223A-A01 --- AC 100-240 V, 50-60 Hz, 1.5 A USB Mouse AMU1402JP0605000678DoC DC 5 V Note: * 1 :This instrument was used during the test of AC Power Line Conducted Emission, Radiated Spurious Emission and Band Edge Measurement. * 2 :This instrument was used during the test of 20 dB Bandwidth, Maximum Peak Conducted Output Power, Carrier Frequency Separation, Number of Channels, Time of Occupancy and Conducted Spurious Emission. * 3 :This instrument was used during the test of Radiated Spurious Emission and Band Edge Measurement. * 4 :This instrument was used during the test of AC Power Line Conducted Emission. * 5 :The difference between "S84-ex(203dpi, RH)" and "S84-ex(203dpi, LH)" is the position of communication ports:USB, RS-232C etc. The position of R…

Text truncated - open the document above for the full version.

Page 1 of 4 Rev.00 Test Report No. R121647-1 Appendix 3 Setup Photos AC Power Line Conducted Emission ERF130328 Cosmos Corporation QAF1466 Issued: 13//03/01 Revised: 14/02/12 Page 2 of 4 Rev.00 Appendix 3 (Continued) Radiated Emission (30 MHz to 1 GHz) ERF130328 Cosmos Corporation QAF1466 Issued: 13//03/01 Revised: 14/02/12 Page 3 of 4 Rev.00 Appendix 3 (Continued) Radiated Emission (1 GHz to 25 GHz) ERF130328 Cosmos Corporation QAF1466 Issued: 13//03/01 Revised: 14/02/12 Page 4 of 4 Rev.00 Appendix 3 (Continued) 20 dB Bandwidth / Maximum Peak Conducted Output Power / Carrier Frequency Separation Number of Channels / Time of Occupancy / Conducted Spurious Emission ERF130328 Cosmos Corporation QAF1466 Issued: 13//03/01 Revised: 14/02/12
