MNJ-MO065Baby Monitor - Baby unit

MO065 MO096 User Guide Birth & Up Please read the following instructions and warnings carefully. Keep these instructions for future reference. Tool needed: Flat Head Screwdriver (not included) Thank you for purchasing a Safety 1st product. We are not only about safety, we're also about your satisfaction. If you have any questions or comments, please call our Consumer Relations department at 1-800-544-1108 or e-mail us at [email protected] STRANGULATION HAZARD! Children have STRANGLED in cords. NEVER place cords within 6 feet of the crib. Do not use with extension cord. Only use the AC adapters provided. WARNING! BATTERY INSTALLATION: 1. Move belt clip out of way. Unscrew battery compartment cover as shown. 2. Insert 3 AAA batteries. 3. Replace the battery compartment cover and tighten screw. To obtain maximum performance, ALWAYS use alkaline type batteries in this monitor. BATTERY WARNING • DO NOT mix old and new batteries. • DO NOT mix alkaline, standard (carbon zinc), or rechargeable (nickel-cadmium) batteries. • Non rechargeable batteries are not to be recharged. • Only batteries of the same or equivalent type as recommended are to be used. • Batteries are to be inserted with the correct polarity. • Exhausted batteries are to be removed from the unit. • The supply terminals are not to be short-circuited. • Check that all contact surfaces are clean and bright before installing batteries. • Keep batteries out of child’s reach. Swallowing a battery could be fatal. Batteries should not be placed into extreme heat as they may explode. • Used batteries should be disposed of properly. Do not dispose of batteries in fire - they may explode or leak and cause injury. • CAUTION: Replace only with AAA alkaline batteries. Use of other types of batteries may present a risk of fire or rupture. • Remove batteries when stored for long periods of non-use. • DO NOT use audio monitor system in portable mode when batteries are low. • Use care when changing batteries. Keep batteries out of child’ reach. Ensure that the battery compartment is completely secure after replacing batteries. • Discontinue use of the product if battery compartment cannot be completely secured. IMPORTANT: Please read all warnings and assembly instructions carefully before using the audio monitor. • Parent Unit is a Receiver. Baby Unit is a Transmitter. • To prevent entanglement with the adapter cord, NEVER PLACE THE CORD IN OR NEAR A CRIB OR PLAYPEN. DO NOT place the Receiver anywhere its AC adapter cord is near children. • Check the reception regularly. • Certain electronic devices are sensitive to magnetic fields and may be damaged permanently or temporarily disabled if exposed to a magnetic field that is too strong. Video screen will become distorted and/or discolored if exposed to a strong magnetic field. • To remove AC adapter from the outlet, firmly grasp the adapter "brick." DO NOT pull on the cord, as this could damage it. • The LEDs emit IR (infra red) light that is not harmful. To prevent electric shock, NEVER use the Transmitter or Receiver near water, such as a bathtub, sink, laundry tub, in a wet basement, etc. DANGER! TO REDUCE THE RISK OF FIRE OR ELECTRICAL SHOCK, DO NOT EXPOSE THIS PRODUCT TO WATER OR MOISTURE. NEVER ATTEMPT TO DISASSEMBLE THE PRODUCT. THIS IS DANGEROUS AND WILL VOID THE WARRANTY. WARNING! CAUTION: THIS MONITOR IS NOT INTENDED TO BE USED AS A MEDICAL MONITOR AND ITS USE SHOULD NOT REPLACE PROPER ADULT SUPERVISION. YOU SHOULD CHECK YOUR CHILD’S ACTIVITY AT REGULAR INTERVALS AS THIS MONITOR WILL NOT ALERT PARENTS TO THE SILENT ACTIVITIES OF A CHILD. HEED WARNINGS: All warnings on the Monitor and operating instructions should be adhered to. ALWAYS KEEP THE PARENT UNIT, BABY UNIT AND AC ADAPTERS OUT OF REACH OF CHILDREN. This Monitor is intended for indoor use only. FOLLOW INSTRUCTIONS: All operating instructions should be followed. WATER AND MOISTURE: The Monitor should not be used near water; for example, near a bath tub, wash bowl, kitchen sink, laundry tub in a wet basement, or near a swimming pool, etc. VENTILATION: The Monitor should not be situated on a bed, sofa, rug, or similar surface that may block the ventilation openings, or placed in an enclosed installation, such as a book case or cabinet that may impede the flow of air through the ventilation openings. • Position the Transmitter, Receiver and AC adapters to allow adequate ventilation and prevent these components from overheating. • To prevent overheating, keep the Transmitter, Receiver and AC adapters away from heat sources such as radiators, heat registers, stoves or other appliances (including amplifiers) that produce heat. Also keep these components out of direct sunlight. HEAT: The Monitor should be situated away from heat sources such as radiators, heat registers, stoves, or other appliances that produce heat. POWER SOURCE: The Monitor should be connected to a power supply only of the type described in these operating instructions. POWER CORD PROTECTION: The power supply cord should be routed so that it is not likely to be walked on or pinched by items placed upon or against it. Pay particular attention to the cord at the plug, convenience receptacle, and at the point it exits from the Monitor. NOTE: Do not place adapter under a window where a child might use it to step on and reach something that might be dangerous. Do not use with extension cord. • Check to make sure outlet plates are not unusually hot to the touch. If they are, immediately unplug cords from these outlets. Check that all outlet connections are in good condition so that adapter is not loose or that no wiring is exposed. Have a qualified, licensed electrician check the wiring as soon as possible. CLEANING: Use a dry cotton cloth to keep the Monitor free of dust. Do Not Use Water. NON-USE PERIODS: The power cord of the Monitor should be unplugged from the outlet when unused for a long period of time. Battery should be removed from Parent Unit. OBJECT AND LIQUID…

Text truncated - open the document above for the full version.

Agents letter (for TCB – TCB approval): Dorel Juvenile Group Date (21/09/2011) BABT FCB Forsyth House, Churchfield Road, Walton-on-Thames, Surrey, KT12 2TD Dear Sir or Madam, We, ( Dorel Juvenile Group Address: 25 Forbes Blvd, Suite 4, Foxboro, MA 02035，USA), hereby authorize (John Zhi Address: TUV SUD China, 6/F, H Hall, Century Craftwork Culture Square No. 4001 Fuqiang Road, Futian District ShenZhen China Tel: 86-755-3332-3485) to act as our agent in all matters relating to applications for equipment authorization, including the signing of all documents relating to these matters. This authorization expires on 30/03/2012 Sincerely, Company Officer: Tony Fernandes Telephone Number: 508 216-1850 Email: [email protected]

Dorel Juvenile Group Date (21/09/2011) BABT TCB Forsyth House, Churchfield Road, Walton-on-Thames, Surrey, KT12 2TD Confidentiality Request FCC ID:MNJ-MO065 Pursuant to Sections 0.457(d)(1)(ii) and 0.459 of the Commission’s Rules,Dorel Juvenile Group hereby requests permanent confidential treatment of information accompanying this application as outlined below: Common exhibits for which confidentiality is requested are: Schematics Bill of Materials/Parts List Block Diagrams Theory of Operation The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457(d)(1)(ii), disclosure of this Application and all accompanying materials will not be made before the date of the Grant for this Application. Yours sincerely, Company Officer: Tony Fernandes Telephone Number: 1-508 216-1850 Email:[email protected]

Report No.: 68.870.11.004.01F APPENDIX B – External of EUT Page 1 of 2 TÜV SÜD China. 6thFloor, H Hall, Century Craftwork Culture Square, No. 4001, Fuqiang Road, Futian District, Shenzhen, China. Report No.: 68.870.11.004.01F APPENDIX B – External of EUT Page 2 of 2 TÜV SÜD China. 6thFloor, H Hall, Century Craftwork Culture Square, No. 4001, Fuqiang Road, Futian District, Shenzhen, China. Bab y Unit

Report No.: 68.870.11.004.01F APPENDIX C– Internal of EUT Page 1 of 2 TÜV SÜD China. 6thFloor, H Hall, Century Craftwork Culture Square, No. 4001, Fuqiang Road, Futian District, Shenzhen, China. Report No.: 68.870.11.004.01F APPENDIX C– Internal of EUT Page 2 of 2 TÜV SÜD China. 6thFloor, H Hall, Century Craftwork Culture Square, No. 4001, Fuqiang Road, Futian District, Shenzhen, China. Bab y Unit

Date: 2011-08-25TEST REPORT Report No.: 68.870.11.004.01F Page 1 of 20 TÜV SÜD China. 6thFloor, H Hall, Century Craftwork Culture Square, No. 4001, Fuqiang Road, Futian District, Shenzhen, China. Applicant: Dorel Juvenile Group 2525 State, Columbus, Indiana, United States, 47201-7494 Description of Samples:Model name: Baby Monitor(Transmitter) Brand name: Dorel Model no.:MO065T,MO066T,MO077T,MO096T FCCID:MNJ-MO065 Date Samples Received:2011-08-16 Date Tested:2011-08-16 to 2011-08-23 Investigation Requested:FCC Part 15 Subpart C, Section 15.235 Conclusions:The submitted product COMPLIED with the requirements of Federal Communications Commission [FCC] Rules and Regulations Part 15. The tests were performed in accordance with the standards described above and on Section 2.2 in this Test Report. Remarks:---- Checked by:Approved by:- John ZhiNicolas Cheng Project EngineerProject Manager Wireless & Telecom departmentWireless & Telecom department Report No.: 68.870.11.004.01F Page 2 of 20 TÜV SÜD China. 6thFloor, H Hall, Century Craftwork Culture Square, No. 4001, Fuqiang Road, Futian District, Shenzhen, China. CONTENT: Cover Page 1 of 20 Content Page 2 of 20 1.0General Details 1.1Test Laboratory Page 3 of 20 1.2Applicant Details Page 3 of 20 1.3Equipment Under Test [EUT] Page 4 of 20 1.4 Equipment Modification Page 4 of 20 1.5 Related Submittal(s) Grants Page 4 of 20 2.0Technical Details 2.1Investigations Requested Page 5 of 20 2.2Test Standards and Results Summary Page 5 of 20 3.0Test Methodology 3.1Radiated Emission Page 6 of 20 3.2Field Strength Calculation Page 6 of 20 3.3Conducted Emission Page 6 of 20 4.0Test Results 4.1Radiated Emission of Fundamental Frequency Page 7-8 of 20 4.2Spurious Radiated Emission Page 9-14 of 20 4.3Conducted Emission Page 15-17 of 20 4.4Bandwidth Measurement Page 18-19 of 20 5.0List of Measurement Equipments Page 20 of 20 Appendix A Photos of Test Setup Appendix B External EUT Photos Appendix C Internal EUT Photos Report No.: 68.870.11.004.01F Page 3 of 20 TÜV SÜD China. 6thFloor, H Hall, Century Craftwork Culture Square, No. 4001, Fuqiang Road, Futian District, Shenzhen, China. 1.0General Details 1.1Test Laboratory Neutron Engineering Inc. EMC Laboratory registered by FCC with FCC Registration Number: 538587 Test By˖ Ares Liu 1.2Applicant Details Applicant Dorel Juvenile Group 2525 State, Columbus, Indiana, United States, 47201-7494 Manufacturer MC Device Co., Ltd. 516, BLD 4, Software Park, Kejizhong RD, Shenzhen Hi- Tech Park, Shenzhen, Guangdong, China, 518057 Report No.: 68.870.11.004.01F Page 4 of 20 TÜV SÜD China. 6thFloor, H Hall, Century Craftwork Culture Square, No. 4001, Fuqiang Road, Futian District, Shenzhen, China. 1.3Equipment Under Test [EUT] Description of EUT Model Name:Baby Monitor(Transmitter) Brand Name: Dorel Model Number: MO065T,MO066T,MO077T,MO096T FCCID:MNJ-MO065 Rating:Input:120VAC/60Hz Output:DC9V/200mA(adaptor) Antenna Type:Integral Operated Frequency:49.85MHz,49.87MHz No. of Channel:2 Accessories and Auxiliary Equipment:None EUT Exercising Software:None Note:As per Client Declaration,MO065T, MO066T, MO077TandMO096T,Utilize the identical circuit design, PCB layout, shielding and interface with (basic MO065T), only the cosmetic is difference. Therefore this application can be regarded as identical in performance to the submitted test sample. So we use MO065T as a representative model to perform all testing. General Operation of EUT The Equipment Under Test (EUT) is ababy monitoroperated at49MHz totransmittheaudiosignal of the baby to its associated receiver. 1.4Equipment Modification No modification was made to the tested unit by TUV SUDChina 1.5Related Submittal(s) Grants This is a single application for certification of the transmitter. Report No.: 68.870.11.004.01F Page 5 of 20 TÜV SÜD China. 6thFloor, H Hall, Century Craftwork Culture Square, No. 4001, Fuqiang Road, Futian District, Shenzhen, China. 2.0Technical Details 2.1Investigations Requested Perform ElectroMagnetic Interference measurement in accordance with FCC 47CFR [Codes of Federal Regulations] Part 15: 2009 and ANSI C63.4: 2003 for FCC Verification. 2.2Test Standards and Results SummaryTables EMISSION Results Summary Test ConditionTest RequirementTest Result PassFailedN/A Conducted Emission, 0.15MHz to 30 GHz Part 15.207(a) Radiated Emission, 30MHz to 1GHz Part 15.209(a) Radiated Emission of Carrier Frequency Part 15.235(a) Out of Band Edges Emission Measurement Part 15.235(b) Home-built Intentional Radiator Part 15.235(c) Bandwidth Measurement Part 15.215(c) Note: N/A - Not Applicable Report No.: 68.870.11.004.01F Page 6 of 20 TÜV SÜD China. 6thFloor, H Hall, Century Craftwork Culture Square, No. 4001, Fuqiang Road, Futian District, Shenzhen, China. 3.0Test Methodology 3.1Radiated Emission The sample was placed 0.8m above the ground plane on a standard emission test site *. Measurements in both horizontal and vertical polarities were performed. During the test, each emission was maximized by: having the EUT continuously working, investigated all operating modes, rotated about all 3 axis (X, Y & Z) and considered typical configuration to obtain worst position, manipulating interconnecting cables, rotating turntable, varying antenna height from 1m to 4m in both horizontal and vertical polarizations. The emissions worst-case are shown in Test Results of the following pages. *On astandard emission test sitewith a metal ground plane filed with the FCC pursuant to section 2.948 of the FCC rules, with Registration Number: 538587. 3.2Field Strength Calculation The field strength at 3 m was established by adding the meter reading of the spectrum analyzer to the factors associated with antenna correction factor, cable loss, preamplifiers and filter attenuation. The equation is expressed as follow: FS = R + System Factor System Factor = AF + CF + FA – PA Where FS = Net Field Strength in dBuV/m at 3 meters. R = Reading of Spectrum Analyzer / Test Receiver in dBuV. AF = Antenna Fac…

Text truncated - open the document above for the full version.

68.870.11.004.01F APPENDIX A – Photos of Test Setup Page 1 of 1 TÜV SÜD China. 6thFloor, H Hall, Century Craftwork Culture Square, No. 4001, Fuqiang Road, Futian District, Shenzhen, China. Conducted Emission Radiated Emission
