MNJ-MO140TXTechTouch Digital Color Video Monitor

User Guide MO140 10/7/13 4358-6519 Registerforour eNewsletterand watch our experts on Safety 1 st TV safety1st.com 20 Please read the following instructions and warnings carefully. Keep these instructions for future reference. Tool needed: Flathead Screwdriver (not included) Thank you for purchasing a Safety 1st product. We are not only about safety, we're also about your satisfaction. If you have any questions or comments, please call our Consumer Relations department at 1-800-544-1108 or e-mail us at [email protected] Strangulation Hazard - Children have STRANGLED in cords. Keep cords out of reach of children more than 3 feet (0.9 m) away. WARNING! ©2013 Cosco Management, Inc. All Rights Reserved. Todos derechos reservados. www.djgusa.com (800) 544-1108 www.safety1st.com Made in CHINA. Hecho en CHINA. Styles and colors may vary. Los estilos y los colores pueden variar. Distributed by (distribuido por) Dorel Juvenile Group, Inc., 2525 State St., Columbus, IN 47201-7494 Dorel Distribution Canada, 873 Hodge, St. Laurent, QC H4N 2B1 TechTouch Digital Color Video Monitor For more help and resources, call 1-800-544-1108 or visit www.safety1st.com32 Important Warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 Features & Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 Icon Description/Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 Installing & Charging Batteries. . . . . . . . . . . . . . . . . . . . . . . . . 5 Quick Start Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 & 7 Using Your Monitor: Parent Unit (Receiver) • Power On/off Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 • Lock Screen/Unlock Screen . . . . . . . . . . . . . . . . . . . . . . 8 • Tri-Color Sound Lights (5 LEDs) . . . . . . . . . . . . . . . . . . 8 • Auto-Rotation Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 • Zoom Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 • Pan/Tilt Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 • Brightness Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 • Status Bar . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 • Volume Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10 • Talk to Baby Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10 • Quick View - Video On/Off Button . . . . . . . . . . . . . . . 10 • Belt Clip & Stand . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10 • Toolbox . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10 • Secondary Touchscreen Menu . . . . . . . . . . . . . . . . . . . 10 • Clock Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11 • Temperature Display . . . . . . . . . . . . . . . . . . . . . . . . . . . 11 • Help Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11 Camera (Baby Unit) • Adding Additional Cameras . . . . . . . . . . . . . . . . . . . . . 12 • Camera Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12 • To Add a Camera . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12 • To Disable/Recativate a Previously Added Camera. 13 • Auto-Scan on/Off Toggle Button . . . . . . . . . . . . . . . . 13 • Nightlight Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13 Use & Care . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14 • Proper Positioning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14 • Check Reception . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14 • Wall Mounting the Camera . . . . . . . . . . . . . . . . . . . . . . 14 • Care and Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14 Safety Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15 Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16 & 17 FCC Statement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18 Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19 Important Warnings Table of Contents This monitor is not intended to be used as a medical monitor and its use should not replace proper adult supervision. You should check your child’s activity at regular intervals as this monitor will not alert parents to the silent activities of a child. CAUTION! To protect your privacy, always turn the monitor off when not in use. Although encryption makes it less likely that sound and video can be decoded by other devices outside your home, it is not a guarantee. CAUTION! For indoor use only. To reduce the risk of fire or electrical shock, do not expose this product to water or moisture. NEVER attempt to disassemble the product. This is dangerous and will void the warranty. WARNING! Important! • Please read all warnings and assembly instructions carefully before using the video monitor. Parent Unit is a Receiver. Baby Unit is a Transmitter. • Check your child’s activity at regular intervals, as this monitor will not alert parents to the silent activities of a child. • To prevent entanglement with the adapter cord, NEVER PLACE THE CORD IN OR NEAR A CRIB OR PLAYPEN. DO NOT place the Receiver anywhere its AC adapter cord is near children. • ALWAYS KEEP TRANSMITTER, RECEIVER AND AC ADAPTERS OUT OF REACH OF CHILDREN • This product is not a medical monitor and its use should not replace adult supervision. • Check the reception regularly. • NEVER use the Transmitter or Receiver near water. For example, do not use near a bath tub, bathroom sink, laundry tub, kitchen sink, in a wet basement, etc. • Always unplug the AC adapters from wall outlets during long periods of non-use. • Check to make sure outlet plates are not unusually hot to the touch. If they are, immediately unplug cords from the…

Text truncated - open the document above for the full version.

Dorel Juvenile Group ADD: 2525 State Street, Columbus, Indiana, 47201-7494, United States Tel: 508-216-1850 Fax: 508-216-1812 FCC Authorization Date: 2013-10-23 FEDERAL COMMUNICATIONS COMMISSIONS Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Subject: Agent Authorization To whom it may concern: We , Dorel Juvenile Group, the undersigned, Hereby authorizes Bay Area Compliance Laboratories Corporation to act on its behalf in all matters relating to application for Equipment authorization, including the signing of all documents relating to these matters. All acts carried out by Bay Area Compliance Laboratories Corp. on our behalf shall have the same effect as our own action. We, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). This authorization is valid until further written notice from the applicant. Sincerely Yours, Tony Fernandes Director, Regulatory Affairs & Compliance

Dorel Juvenile Group ADD: 2525 State Street, Columbus, Indiana, 47201-7494, United States Tel: 508-216-1850 Fax: 508-216-1812 FCC Confidential Authorization Date: 2013-10-23 FEDERAL COMMUNICATIONS COMMISSIONS Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Confidentiality Request regarding application for certification of FCC ID: MNJ-MO140TX Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below:  Detailed Circuit Schematics of EUT--- (Long term)  Block Diagram--- (Long term)  Circuit Description--- (Long term) The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely Yours, Tony Fernandes Director, Regulatory Affairs & Compliance

EXHIBIT B - EUT EXTERNAL PHOTOGRAPHS EUT– All View EUT– Front Side View EUT– Rear Side View EUT– Left Side View EUT –Right Side View EUT – Antenna View EUT – Adapter View EUT – Adapter Label View

EXHIBIT A - FCC ID LABELING AND LOCATION FCC ID Label FCC ID Label Location The label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time purchase (Labeling requirements per 2.925) Label Here

EXHIBIT C - EUT INTERNAL PHOTOGRAPHS EUT – Base Uncover View EUT – Speaker Top View EUT – Speaker Bottom View EUT – Base Cover Off View EUT – Main Board Top View EUT – Main Board Bottom View EUT – Direction Control Board Top View EUT – Direction Control Board Bottom View EUT – Motor Uncover View EUT – Motor Top View EUT – Motor Bottom View EUT – Control Uncover View EUT – Front Cover Off View EUT – Camera Off View EUT – Camera Board Top View EUT – Camera Board Bottom With Shielding View Antenna EUT – Camera Board Bottom Without Shielding View EUT – RF Module View EUT – Camera Board Uncover View EUT – Camera Chip View

Bay Area Compliance Laboratories Corp. (Dongguan) Report No.: R2DG131017002-00 FCC Part 15.247 Page 9 of 39 FCC §15.247 (i) & §1.1310 & §2.1091- MAXIMUM PERMISSIBLE EXPOSURE (MPE) Applicable Standard According to subpart 15.247(i) and subpart §1.1310, systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. Limits for Maximum Permissible Exposure (MPE) (§1.1310, §2.1091) (B) Limits for General Population/Uncontrolled Exposure Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Averaging Time (minutes) 0.3–1.34 614 1.63 *(100) 30 1.34–30 824/f 2.19/f *(180/f²) 30 30–300 27.5 0.073 0.2 30 300–1500 / / f/1500 30 1500–100,000 / / 1.0 30 f = frequency in MHz; * = Plane-wave equivalent power density; According to §1.1310 and §2.1091 RF exposure is calculated. Calculated Formulary: Predication of MPE limit at a given distance S = PG/4πR² = power density (in appropriate units, e.g. mW/cm 2 ); P = power input to the antenna (in appropriate units, e.g., mW); G = power gain of the antenna in the direction of interest relative to an isotropic radiator, the power gain factor, is normally numeric gain; R = distance to the center of radiation of the antenna (appropriate units, e.g., cm); Calculated Data: Frequency (MHz) Antenna Gain Conducted Power Evaluation Distance (cm) Power Density (mW/cm 2 ) MPE Limit (mW/cm 2 ) (dBi) (numeric) (dBm)(mW) 2410.875 0.7 1.175 18.1665.46 20 0.015 1.0 2437.875 0.7 1.175 18.0764.12 20 0.015 1.0 2468.25 0.7 1.175 17.9462.23 20 0.015 1.0 Result: The device meet FCC MPE at 20 cm distance

EXHIBIT D - TEST SETUP PHOTOGRAPHS Conducted Emission--Front View Conducted Emission – Side View Radiated Emission –Front View (Below 1GHz) Radiated Emission –Rear View (Below 1GHz) Radiated Emission- Front View (Above 1GHz) Radiated Emission- Rear View (Above 1GHz)
